VTech Telecommunications 80-0443-00 Storytelling Soother User Manual
VTech Telecommunications Ltd Storytelling Soother
User Manual
Congratulations
on purchasing your new VTech product.
Before using this product, please read
Important safety instructions.
This manual has all the feature operations
and troubleshooting necessary to install and
operate your new VTech product. Please
review this manual thoroughly to ensure
proper installation and operation of this
innovative and feature rich VTech product.
For support, shopping, and everything
new at VTech, visit our website at
www.vtechphones.com.
What’s in the box
User’s manual
Connect the soother
NOTES
Use only the power adapter supplied with this
product.
Make sure the electrical outlet is not controlled
by a wall switch.
The power adapter is intended to be correctly
oriented in a vertical or floor mount position. The
prongs are not designed to hold the plug in place
if they are plugged into a ceiling, under-the-table
or cabinet outlet.
Make sure the soother and the power adapter
cord are out of reach of children.
Position the soother
CAUTION
Keep the soother out of the reach of your baby.
Never place the soother inside the baby’s crib or
playpen.
Place the soother more than 1 meter (3 feet)
away from your baby.
> 1m (3ft)
•
•
•
•
•
Overview
12
13
1
2
4
3
5
6
7
8
9
11
10
12
13
1
2
4
3
5
6
7
8
9
11
10
12
13
1
2
4
3
5
6
7
8
9
11
10
1Speaker
2Dimmable soft-glow night light
3Turtle shell
Rock the shell backward to power
on the soother.
Rock the shell forward to power off the shell forward to power off
the soother.
•
•
4
/
Night light brightness switch
Slide to select dim light or bright
light mode.
•
5 Night light
Press to turn on or off the night light.•
6Display window
7 Auto-off timer
Press to turn on an auto-off timer
while playing story, lullaby or
soothing sound. It will automatically
stop the tracks after playing for
30/45/60 minutes.
•
8 Story
Press to play or stop the story.•
9vol +
Press to increase the speaker
volume.
vol -
Press to decrease the speaker
volume.
While playing a story, lullaby or
soothing sound, press to play the
next track.
While playing a story, lullaby or
soothing sound, press to play the
previous track.
•
•
•
•
10 Lullaby
Press to play or stop the lullaby.•
11 Soothing sound
Press to play or stop the soothing
sound.
•
12 Wi-Fi
Press to turn on or off the soother’s
Wi-Fi network (for using with the
Tommy the Turtle Storytelling
Soother app).
•
13 Power jack
User’s manual
BC8311
Safe & Sound®
Storytelling Soother
Tommy the Turtle
Go to www.vtechphones.com
to register your product for
enhanced warranty support and
the latest VTech product news.
Use the soother
Power on or off the soother
Rock the turtle shell backward to power on
the soother.
Rock the turtle shell forward to power off
the soother.
NOTES
Make sure the soother is on before using other
features.
Play the story
Press to start playing stories.
Press to skip to the next story.
Press to play the previous story.
While a story is playing, press to stop
the story.
NOTES
The display window will show you the track
number of the story currently playing.
The soother will play the stories continuously
unless you manually stop the stories or turn on
the auto-off timer feature.
When a story ends, the soother automatically
skips to the next story. After the soother plays the
last story in the story list, it restarts playing from
the first story again.
•
•
•
•
•
•
•
•
•
•
Play the lullaby
Press to start playing lullabies.
Press to skip to the next lullaby.
Press to play the previous lullaby.
While a lullaby is playing, press to stop
the lullaby.
NOTES
The display window will show you the track
number of the lullaby currently playing.
The soother will play the lullabies continuously
unless you manually stop the lullabies or turn on
the auto-off timer feature.
When a lullaby ends, the soother automatically
skips to the next lullaby. After the soother plays
the last lullaby in the lullaby list, it restarts playing
from the first lullaby again.
Play the soothing sound
Press to start playing soothing sounds.
Press to play the next soothing sound.
Press to play the previous soothing
sound.
While a soothing sound is playing,
press to stop the soothing sound.
NOTES
The display window will show you the track
number of the soothing sound currently playing.
The soother will play the soothing sounds
continuously unless you manually stop the
soothing sounds or turn on the auto-off timer
feature.
The soother will repeat the same soothing sound
again and again unless you skip to the other
soothing sounds.
Adjust the speaker volume
Press vol- or vol+ at any time.
NOTES
The soother beeps to notify you when the
speaker volume is already at the highest or
lowest setting while adjusting.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Set the auto-off timer
While the soother is playing story, lullaby or
soothing sound, the auto-off timer feature
helps you automatically stop the story, lullaby
or soothing sound after playing for 30/45/60
minutes.
While a story, lullaby or soothing sound is
playing, press to set the auto-off timer.
Press or to choose 30, 45 or 60
minutes as shown on the display window.
Press to confirm. The soother starts
counting down 30/45/60 minutes.
The light turns on.
After 30/45/60 minutes, the soother will
automatically stop any story, lullaby or
soothing sound. The auto-off timer feature
and the light turn off.light turn off.
NOTES
You can only turn on the auto-off timer feature
when the soother is playing story, lullaby or
soothing sound.
The auto-off timer feature will not power off
the soother or turn off the night light after the
countdown.
You can press again to turn off the auto-off
timer feature during the countdown.
If you manually stop the story, lullaby or soothing
sound while the auto-off timer is counting down,
the auto-off timer will turn off.
Turn on or off the dimmable
soft-glow night light
While the soother is on, press to turn on
the night light.
Slide the night light switch to to select
dim light, or to to select bright light.
Press again to turn off the night light.
1.
2.
3.
•
•
•
•
•
•
•
Turn on or off the soother’s
Wi-Fi network (for app usage)
You can turn on the soother’s Wi-Fi network for
using the soother with the Tommy the Turtle
Storytelling Soother mobile app.
Press to turn on the Wi-Fi network.
The light turns on.
Press again to turn off the Wi-Fi
network. The light turns off.
NOTES
Turning on the soother’s Wi-Fi network will stop
all story, lullaby and soothing sound from playing.
Make sure you turn off the soother’s Wi-Fi
network before playing any sounds.
The display window shows - - when the soother’s
Wi-Fi network is on.
The soother’s Wi-Fi network will be automatically
off after 30 minutes if there is no data transfer.
For more information about the app, see
About Tommy the Turtle Storytelling
Soother app.
•
•
•
•
•
About Tommy the Turtle
Storytelling Soother app
To enhance your experience on using the
soother, you can use your BC8311 storytelling
soother with the free, compatible Tommy the
Turtle Storytelling Soother mobile app.
Main features of the app:
My Library stores extra free stories,
lullabies and soothing sounds exclusive to
the app. You can update your soother using
the app and play these additional tracks on
your soother.
Record Stories allows you to record your
own stories and messages. You can play
these recordings on your soother.
NOTES
Make sure your mobile device meets the
minimum requirement for the mobile app:
- Android® 4.3 or later; and
- iOS 8.1 or later.
Install the app on your mobile
device
Scan the QR codes below, or search
“tommy the turtle” in the �oogle Playthe turtle” in the �oogle Play” in the �oogle Play® store
or App store.
Android iOS
Download and install the Tommy the
Turtle Storytelling Soother app.
•
•
•
1.
2.
Connect your mobile device to
the soother
To access all features of the app, you need to
connect your mobile device to the soother’s
Wi-Fi network first.
If it is the first time you launch the app, the
app prompts you to follow the instructions
shown on screen to connect your mobile
device to the soother’s Wi-Fi network.
If your have launched the app before:
On the app home page, tap .
Select Connect to soother.
Follow the instructions shown on screen
to connect your mobile device to the
soother’s Wi-Fi network.
NOTES
The soother’s Wi-Fi network is displayed as
Tommy Turtle Soother_XXXX on the Wi-Fi list
(XXXX are four random characters). The default
Wi-Fi password is SStoryteller (case-sensitive).
Up to three mobile devices can be connected
to the soother’s Wi-Fi network. Only one of the
mobile devices can use the My Library feature
at a time.
Access the app manual
For all instructions and troubleshooting on
using the app, access the app manual and
frequently asked questions in the app.
On the app home page, tap .
Select App Manual or FAQ to find the
desired information.
•
•
1.
2.
3.
•
•
1.
2.
relativement à l’utilisation de l’appareil par une
personne responsable de leur sécurité.
CONSERVEZ CES INSTRUCTIONS
Mises en garde
Utilisez et entreposez le produit à une
température entre 0˚ C (32˚F) et 40˚C (104˚ F).
N’exposez pas cet appareil à des froids ou des
chaleurs extrêmes, ainsi qu’à la lumière directe
du soleil. Ne l’installez pas près d’une source de
chauffage.
Assurez-vous que le produit et le cordon de
l’adaptateur se trouvent toujours hors de portée
de bébé, à au moins 1 mètre (3 pieds) de
bébé ou du berceau, afin d’éviter les risques
d’étranglement.
Ne placez jamais le produit à l’intérieur du
berceau ou du parc de bébé. Ne couvrez jamais
le produit d’une serviette ou une couverture.
D’autres appareils électroniques peuvent
causer des interférences avec le produit. Tentez
d’installer le produit le plus loin possible de
ces dispositifs électroniques : routeurs sans
fil, radios, téléphones cellulaires, interphones,
moniteurs de la pièce, téléviseurs, ordinateurs
personnels, appareils électroménagers et
téléphones sans fil.
Stimulateurs cardiaques implantés dans
l’organisme
Les simulateurs cardiaques (ne s’applique qu’aux
dispositifs numériques sans fil) :
L’organisme ‘Wireless Technology Research, LLC
(WTR)’, une firme de recherche indépendante,
a mené une évaluation pluridisciplinaire des
interférences entre les téléphones sans fil portatifs
et les stimulateurs cardiaques implantés dans
l’organisme. Appuyée par l’Administration des
aliments et drogues (FDA) des États-Unis, la firme
WTR recommande aux médecins:
Avis aux détenteurs de stimulateurs cardiaques
Vous devriez maintenir les dispositifs sans fil à au
moins six pouces du simulateur cardiaque.
Ils ne doivent PAS placer le téléphone sans fil
directement sur le stimulateur cardiaque, tel que
dans une poche de chemise, lorsque celui-ci est
en marche.
L’étude effectuée par l’organisme WRS n’a pas
identifié de risque pour les détenteurs de simulateurs
cardiaques causés par les gens qui utilisent
dispositifs sans fil à proximité de ceux-ci.
Champs électromagnétiques (EMF)
Ce produit de VTech est conforme à toutes
les normes se rapportant aux champs
électromagnétiques (EMF) standard. Si vous le
manipulez correctement en suivant les instructions
de ce guide, son utilisation sera sécuritaire pendant
de nombreuses années, selon les meilleures
évidences scientifiques dont nous disposons
aujourd’hui.
1.
2.
3.
4.
5.
•
•
Limited warranty
What does this limited warranty cover?
The manufacturer of this VTech Product warrants to
the holder of a valid proof of purchase (“Consumer”
or “you”) that the Product and all accessories
provided in the sales package (“Product”) are
free from defects in material and workmanship,
pursuant to the following terms and conditions, when
installed and used normally and in accordance
with the Product operating instructions. This limited
warranty extends only to the Consumer for Products
purchased and used in the United States of America
and Canada.
What will VTech do if the Product is not free from
defects in materials and workmanship during
the limited warranty period (“Materially Defective
Product”)?
During the limited warranty period, VTech’s
authorized service representative will repair
or replace at VTech’s option, without charge,
a Materially Defective Product. If we repair
the Product, we may use new or refurbished
replacement parts. If we choose to replace the
Product, we may replace it with a new or refurbished
Product of the same or similar design. We will retain
defective parts, modules, or equipment. Repair or
replacement of the Product, at VTech’s option, is
your exclusive remedy. VTech will return the repaired
or replacement Products to you in working condition.
You should expect the repair or replacement to take
approximately 30 days.
How long is the limited warranty period?
The limited warranty period for the Product extends
for ONE (1) YEAR from the date of purchase. If
VTech repairs or replaces a Materially Defective
Product under the terms of this limited warranty,
this limited warranty also applies to the repaired
or replacement Product for a period of either (a)
90 days from the date the repaired or replacement
Product is shipped to you or (b) the time remaining
on the original one-year warranty; whichever is
longer.
What is not covered by this limited warranty?
This limited warranty does not cover:
Product that has been subjected to misuse,
accident, shipping or other physical damage,
improper installation, abnormal operation or
handling, neglect, inundation, fire, water or other
liquid intrusion; or
Product that has been damaged due to repair,
alteration or modification by anyone other than
an authorized service representative of VTech; or
Product to the extent that the problem
experienced is caused by signal conditions,
network reliability, or cable or antenna systems;
or
Product to the extent that the problem is caused
by use with non-VTech accessories; or
Product whose warranty/quality stickers, product
serial number plates or electronic serial numbers
have been removed, altered or rendered illegible;
or
Product purchased, used, serviced, or shipped
for repair from outside the United States of
America or Canada, or used for commercial or
institutional purposes (including but not limited to
Products used for rental purposes); or
Product returned without a valid proof of
purchase (see item 2 on the next page); or
Charges for installation or set up, adjustment of
customer controls, and installation or repair of
systems outside the unit.
How do you get warranty service?
To obtain warranty service in the USA, please visit
our website at www.vtechphones.com or
call 1 (800) 595-9511. In Canada, go to
www.vtechcanada.com or call 1 (800) 267-7377.
NOTE: Before calling for service, please review the
user’s manual - a check of the Product’s controls and
features may save you a service call.
Except as provided by applicable law, you assume
the risk of loss or damage during transit and
transportation and are responsible for delivery or
handling charges incurred in the transport of the
Product(s) to the service location. VTech will return
repaired or replaced Product under this limited
warranty. Transportation, delivery or handling
charges are prepaid. VTech assumes no risk for
damage or loss of the Product in transit. If the
Product failure is not covered by this limited warranty,
or proof of purchase does not meet the terms of
this limited warranty, VTech will notify you and will
request that you authorize the cost of repair prior to
any further repair activity. You must pay for the cost
of repair and return shipping costs for the repair
of Products that are not covered by this limited
warranty.
1.
2.
3.
4.
5.
6.
7.
8.
What must you return with the Product to get
warranty service?
Return the entire original package and
contents including the Product to the VTech
service location along with a description of the
malfunction or difficulty; and
Include a “valid proof of purchase” (sales receipt)
identifying the Product purchased (Product
model) and the date of purchase or receipt; and
Provide your name, complete and correct mailing
address, and telephone number.
Other limitations
This warranty is the complete and exclusive
agreement between you and VTech. It supersedes
all other written or oral communications related to
this Product. VTech provides no other warranties for
this Product. The warranty exclusively describes all
of VTech’s responsibilities regarding the Product.
There are no other express warranties. No one is
authorized to make modifications to this limited
warranty and you should not rely on any such
modification.
State/Provincial Law Rights: This warranty gives you
specific legal rights, and you may also have other
rights, which vary from state to state or province to
province.
Limitations: Implied warranties, including those of
fitness for a particular purpose and merchantability
(an unwritten warranty that the Product is fit for
ordinary use) are limited to one year from the date
of purchase. Some states/provinces do not allow
limitations on how long an implied warranty lasts,
so the above limitation may not apply to you. In no
event shall VTech be liable for any indirect, special,
incidental, consequential, or similar damages
(including, but not limited to lost profits or revenue,
inability to use the Product or other associated
equipment, the cost of substitute equipment, and
claims by third parties) resulting from the use of this
Product. Some states/provinces do not allow the
exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may
not apply to you.
Please retain your original sales receipt as proof
of purchase.
1.
2.
3.
Technical specications
Frequency 2412 - 2462 MHz
Channels 11
Nominal
effective
range
Maximum power allowed by FCC
and IC. Actual operating range may
vary according to environmental
conditions at the time of use.
Power
requirements Power adapter:
Input: 100-120V AC 200mA 60Hz;
Output: 6V DC 600mA
Credits:
The Background Noise sound file was created by Caroline
Ford, and is used under the Creative Commons license.
The Stream Noise sound file was created by Caroline Ford,
and is used under the Creative Commons license.
The Crickets At Night sound file was created by Mike
Koenig, and is used under the Creative Commons license.
The 20121230_vacuum.cleaner.working.01.wav sound file
was created by dobroide, and is used under the Creative
Commons license.
The Heartbeat 5sec Int sound file was created by
Benboncan, and is used under the Creative Commons
license.
The junction_night_traffic.wav sound file was created by
ivolipa, and is used under the Creative Commons license.
The SHHHH SHHH Shush sound sound file was created
by JohnsonBrandEditing, and is used under the Creative
Commons license.
The Washing Machine sound file was created by
nebulousflynn, and is used under the Creative Commons
license.
The Hairdryer.wav sound file was created by ryanharding95,
and is used under the Creative Commons license.
The shower.mp3 sound file was created by geodylabs, and
is used under the Creative Commons license.
The Steady Rain.wav sound file was created by pulswelle,
and is used under the Creative Commons license.
The In Car Driving.aif sound file was created by
RutgerMuller, and is used under the Creative Commons
license.
The fetal_doppler_stethoscope.wav sound file was created
by wjoojoo, and is used under the Creative Commons
license.
The HairDryer.wav sound file was created by
jakobhandersen, and is used under the Creative Commons
license.
The Fan.wav sound file was created by Q.K., and is used
under the Creative Commons license.
The Waves.wav sound file was created by juskiddink, and is
used under the Creative Commons license.
The birds3.aif sound file was created by man, and is used
under the Creative Commons license.
The BIRDS sound file was created by Julien Nicolas, and is
used under the Creative Commons license.
The train1.wav sound file was created by mlekoman, and is
used under the Creative Commons license.
The woman sexy shhh.wav sound file was created by
JanJanTO, and is used under the Creative Commons
license.
Specifications are subject to change without notice.
© 2016 VTech Communications, Inc.
All rights reserved. 06/16. BC8311_CIB_V2
Document order number: 91-010166-010-100
General product care
To keep this soother working well and looking good,
follow these guidelines:
Avoid putting the soother near heating appliances
and devices that generate electrical noise (for
example, motors or fluorescent lamps).
Avoid dropping the soother or treating it roughly.
DO NOT expose the soother to direct sunlight or
moisture.
DO NOT use the soother in the rain, or handle it
with wet hands.
Clean with a soft cloth.
DO NOT immerse the soother in water and do not
clean it under the tap.
DO NOT use cleaning spray or liquid cleaners.
Make sure the soother is dry before you connect
it to the any power sources.
Frequently asked questions
Below are the questions most frequently asked about
the soother. If you cannot find the answer to your
question, visit our website at www.vtechphones.com,
or contact 1 (800) 595-9511 for customer service. In
Canada, visit our website at www.vtechcanada.com
or call 1 (800) 267-7377.
The soother
does not play
sounds.
The soother is not turned on.
Make sure the power adapter is
securely plugged into the soother
and electrical outlet. Slide the
turtle shell backward to turn on
the soother.
You may have turned on the
soother’s Wi-Fi network.
Make sure the soother’s Wi-Fi
network is off before you play
any sounds. The light should
be off.
The night light
does not turn
on.
The soother is not turned on.
Make sure the power adapter is
securely plugged into the soother
and electrical outlet. Slide the
turtle shell backward to turn on
the soother.
When I press
to turn on
the auto-off
timer, the
soother beeps.
The auto-off timer feature is not
turned on.
Make sure you press when the
soother is playing a story, lullaby
or soothing sound.
•
•
•
•
•
•
•
•
Important safety instructions
When using your equipment, basic safety precautions
should always be followed to reduce the risk of fire,
electric shock and injury, including the following:
Follow all warnings and instructions marked on
the product.
Adult setup is required.
Do not use this product near water. For example,
do not use it next to a bath tub, wash bowl,
kitchen sink, laundry tub or swimming pool, or in
a wet basement or shower.
Use only the adapters included with this
product. Incorrect adapter polarity or voltage can
seriously damage the product.
Power adapter: Input: 100-120V AC 200mA
60Hz; Output: 6V DC 600mA
The power adapters are intended to be correctly
oriented in a vertical or floor mount position. The
prongs are not designed to hold the plug in place
if it is plugged into a ceiling, under-the-table or
cabinet outlet.
For pluggable equipment, the socket-outlet shall
be installed near the equipment and shall be
easily accessible.
Unplug this product from the wall outlet before
cleaning. Do not use liquid or aerosol cleaners.
Use a damp cloth for cleaning.
Do not cut off the power adapters to replace
them with other plugs, as this causes a
hazardous situation.
Do not allow anything to rest on the power cords.
Do not install this product where the cords may
be walked on or crimped.
This product should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of power
supply in your home, consult your dealer or local
power company.
Do not overload wall outlets or use an extension
cord.
Do not place this product on an unstable table,
shelf, stand or other unstable surfaces.
This product should not be placed in any area
where proper ventilation is not provided. Slots
and openings in the back or bottom of this
product are provided for ventilation. To protect
them from overheating, these openings must
not be blocked by placing the product on a soft
surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator or
heat register.
Never push objects of any kind into this product
through the slots because they may touch
dangerous voltage points or create a short
circuit. Never spill liquid of any kind on the
product.
To reduce the risk of electric shock, do not
disassemble this product, but take it to an
authorized service facility. Opening or removing
parts of the product other than specified access
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
doors may expose you to dangerous voltages
or other risks. Incorrect reassembling can cause
electric shock when the product is subsequently
used.
Periodically examine all components for damage.
Children should be supervised to ensure that
they do not play with the product.
The product is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
SAVE THESE INSTRUCTIONS
Cautions
Use and store the product at a temperature
between 32oF and 104oF.
Do not expose the product to extreme cold, heat
or direct sunlight. Do not put the product close to
a heating source.
Make sure the product and the adapter cord are
always out of reach of the baby, at least
3 feet away from the baby or crib, to avoid a
possible strangulation hazard.
Never place the product inside the baby’s crib or
playpen. Never cover the product with anything
such as a towel or a blanket.
Other electronic products may cause
interference with the product. Try installing
the product as far away from these electronic
devices as possible: wireless routers, radios,
cellular telephones, intercoms, room monitors,
televisions, personal computers, kitchen
appliances and cordless telephones.
Precautions for users of implanted cardiac
pacemakers
Cardiac pacemakers (applies only to digital cordless
devices):
Wireless Technology Research, LLC (WTR), an
independent research entity, led a multidisciplinary
evaluation of the interference between portable
wireless devices and implanted cardiac pacemakers.
Supported by the U.S. Food and Drug Administration,
WTR recommends to physicians that:
Pacemaker patients
Should keep wireless devices at least six inches
from the pacemaker.
Should NOT place wireless devices directly over
the pacemaker, such as in a breast pocket, when
it is turned ON.
WTR’s evaluation did not identify any risk to
bystanders with pacemakers from other persons
using wireless devices.
16.
17.
18.
1.
2.
3.
4.
5.
•
•
Electromagnetic fields (EMF)
This VTech product complies with all standards
regarding electromagnetic fields (EMF). If handled
properly and according to the instructions in this
user’s manual, the product is safe to be used based
on scientific evidence available today.
FCC and IC regulations
FCC Part 15
This equipment has been tested and found to
comply with the requirements for a Class B digital
device under Part 15 of the Federal Communications
Commission (FCC) rules. These requirements are
intended to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV
technician for help.
WARNING: Changes or modifications to this
equipment not expressly approved by the party
responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
To ensure safety of users, the FCC has established
criteria for the amount of radio frequency energy
that can be safely absorbed by a user or bystander
according to the intended usage of the product.
This product has been tested and found to comply
with the FCC criteria. The soother shall be installed
and used such that parts of all persons’ body are
maintained at a distance of approximately 8 in (20
cm) or more.
This Class B digital apparatus complies with
Canadian requirement:
CAN ICES-3 (B)/NMB-3(B)
•
•
•
•
Industry Canada
This device complies with Industry Canada licence-
exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference,
including interference that may cause undesired
operation.
The term ‘’IC:‘’ before the certification/registration
number only signifies that the Industry Canada
technical specifications were met.
This product meets the applicable Industry Canada
technical specifications.
RF radiation exposure statement
The soother complies with FCC RF radiation
exposure limits set forth for an uncontrolled
environment. The soother should be installed and
operated with a minimum distance of 8 in (20 cm)
between the soother and all persons’ body. Use of
other accessories may not ensure compliance with
FCC RF exposure guidelines. This transmitter must
not be co-located or operating in conjunction with
any other antenna or transmitter. This equipment
complies also with Industry Canada RSS-102 with
respect to Canada’s Health Code 6 for Exposure of
Humans to RF Fields.
For cETL compliance only
Mesures de sécurité importantes
Lorsque vous utilisez votre appareil, vous devriez
toujours suivre certaines mesures de précaution
de base afin de réduire les risques d’incendie,
d’électrocution et de blessures corporelles, dont
ceux qui suivent :
Observez toutes les instructions et mises en
garde inscrites sur l’appareil.
L’installation par un adulte est requise.
N’utilisez pas cet appareil près de l’eau ni de
toute autre source d’humidité, par exemple, près
d’une baignoire, cuve à lessive, évier de cuisine,
dans un sous-sol humide ni près d’une piscine,
dans un soussol humide ou une douche.
N’utilisez que les adaptateurs inclus avec ce
produit. L’utilisation d’un adaptateur dont la
polarité ou la tension serait inadéquate risque
d’endommager sérieusement le produit et mettre
votre sécurité en péril.
Adaptateur : Entrée : 100-120V CA 200mA 60Hz;
Sortie : 6 V CC 600mA
Pour les PRODUITS À BRANCHER À UNE
PRISE DE COURANT, la prise de courant doit
être installée près du produit, afin d’assurer une
accessibilité sécuritaire à la prise de courant.
Lorsqu’ils sont branchés dans une prise de
courant, les adaptateurs secteur ont été conçus
pour être orientés correctement, soit à la
verticale ou au plancher. Les broches n’ont pas
été conçues pour supporter le poids du bloc
1.
2.
3.
4.
5.
6.
d’alimentation et le maintenir en place si celuici
est branché dans une prise au plafond, sous une
table ou dans un meuble.
Débranchez ce produit de la prise de courant
avant de procéder au nettoyage. N’utilisez pas
de nettoyants en aérosols. Utilisez un chiffon
humide pour le nettoyer.
Ne coupez pas les cordons d’alimentation pour
remplacer les fiches, car ceci peut présenter un
danger potentiel.
Ne laissez aucun objet reposer ni appuyer sur
le cordon d’alimentation. N’installez pas cet
appareil dans un endroit où l’on risque d’écraser
le cordon d’alimentation ou de le piétiner.
Ne faites fonctionner cet appareil qu’avec le
type d’alimentation indiqué sur l’étiquette. Si
vous ne connaissez pas le type d’alimentation
que vous possédez à votre domicile, consultez
votre marchand ou votre compagnie locale
d’électricité.
Ne surchargez pas les prises de courant murales
ni les rallonges électriques.
Ne placez pas cet appareil sur un chariot,
meuble, trépied, support de montage ni table
chancelants.
Les trous et ouvertures du boîtier, situés à
l’arrière de l’appareil ou sous celui-ci, servent à
aérer l’appareil. Pour l’empêcher de surchauffer,
ne bloquez sous aucun prétexte ces ouvertures
et n’empêchez pas l’aération adéquate de
l’appareil en le plaçant sur un lit, divan, tapis ou
toute autre surface similaire. De même, ne le
positionnez pas à proximité ni au-dessus d’une
source de chaleur ou d’un calorifère. De plus,
ne placez pas l’appareil dans un endroit avant
de vous assurer qu’il y ait une bonne circulation
d’air.
N’enfoncez jamais d’objets à travers les
ouvertures de cet appareil, car ils pourraient
entrer en contact avec des points de tension
dangereux ou causer des courts-circuits qui
peuvent dégénérer en incendies ou en risques
d’électrocution. Ne renversez jamais de liquide
dans ce produit.
Afin de réduire les risques d’électrocution, ne
démontez pas cet appareil, mais apportez-le
dans un centre de service autorisé. L’ouverture
du boîtier ou le retrait de toutes pièces que
contient cet appareil, à l’exception de l’accès
autorisé à certaines portes ou ouvertures,
risque de vous exposer à des points de tension
dangereux ou d’autres dangers. Un remontage
incorrect peut par la suite présenter des risques
d’électrocution.
Examinez les composantes afin de vérifier si
celles-ci ne sont pas endommagées.
Les enfants devraient être supervisés afin de
vous assurer qu’ils ne jouent pas avec l’appareil.
Le produit n’est pas conçu pour être utilisé
par des personnes (incluant des enfants) aux
capacités physiques, sensorielles ou mentales
réduites ou qui manquent d’expérience et de
connaissances, à moins qu’on leur ait donné
suffisamment de supervision ou d’instructions
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
Android ® and Google Play ® are registered trademarks of
Google Inc.
App Store is a trademark of Apple Inc., registered in the U.S.
and other countries.
