VTech Telecommunications Ltd Video Monitor - Baby Unit
User Manual
User’s manual
VM5231
Accessory baby unit
for use with VTech model
VM5271 / VM5271-2
Congratulations
on purchasing your new VTech product.
Before using this product, please read
Important safety instructions.
This manual has instructions on how to set
up and pair your new baby unit. For complete
instructions on using the baby unit, see the
user’s manual that comes with your video and
audio monitor.
For support, shopping, and everything new at
VTech, visit our website at
www.vtechphones.com.
Register online to get an additional
3-month warranty!
Visit www.vtechphones.com.
Registration
Register your product online for
enhanced warranty support.
Product news
Learn about the latest VTech
products.
What’s in the box
Connect the baby unit
NOTE
S
• Use only the power adapter supplied with this
product.
• Make sure the electrical outlet is not controlled by
a wall switch.
• The power adapter is intended to be correctly
oriented in a vertical or floor mount position. The
prongs are not designed to hold the plug in place
if they are plugged into a ceiling, under-the-table
or cabinet outlet.
• Make sure the baby unit and the power adapter
cord are out of reach of children.
Overview 1Motorized lens with 6x optical zoom
2Light sensor
3Microphone
4Speaker
5Skip
• Press to play the next lullaby.
6 Play/Stop
• Press to play or stop lullaby on the
baby unit.
7- VOLUME +
• Press to adjust the baby unit
speaker volume. It determines the
lullaby volume and talkback volume
transmitted from the parent unit.
8POWER light
• On when the baby unit is turned on
and is paired to the parent unit.
• Flashes when the baby unit is not
being viewed; or when the link to the
parent unit is lost.
9Antenna
10 Temperature sensor
11 Power jack
12 ON/OFF switch
• Slide to turn on or off the baby unit.
13 PAIR
• Your baby units and parent unit
provided are already paired.
• Press and hold on accessory baby
units to pair to the parent unit.
14 Threaded socket
• For wall mount installation use.
Before use
Pair new baby unit
Each newly purchased baby unit (VM5231)
must be paired to your video and audio monitor
system (VM5271
/
VM5271-2).
NOTE
S
• You can pair a maximum of four baby units to your
parent unit. Each new baby unit must be paired to
the parent unit before use.
• Make sure you power on the parent unit before
pairing.
1. Press MENU when the parent unit is idle.
2. Press or to choose Pair/Unpair CAM,
then press SELECT.
3. Press SELECT again to choose Pair CAM.
4. Press or to choose an empty baby unit
slot, then press SELECT.
5. The parent unit screen displays Press
and hold the pair button at the CAM
for 5 seconds until the power indicator
flashes.. Immediately press and hold PAIR
on the bottom of the baby unit. The LED
light flashes quickly.
When pairing is successful, the screen
displays the view of newly paired baby unit in
SINGLE-CAM mode. The LED light on the
new baby unit remains on.
NOTE
S
• If pairing fails, the screen displays Pairing failed.
Try the pairing process again.
• Only one baby unit can be paired at a time.
Positioning the baby monitor
CAUTION
• Keep the baby units out of the reach of your baby.
Never place or mount the baby units inside the
baby’s crib or playpen.
NOTE
• To avoid interference from other electronic
devices, place your baby monitor far away from
devices such as wireless routers, microwaves, cell
phones and computers.
1. Place the baby units more than 1 meter
(3 feet) away from your baby.
> 1m (3ft)
> 1m (3ft)
2. Adjust the angle of the baby unit camera to
aim at your baby.
3. Place the parent unit more than 1 meter
(3 feet) away from the baby units.
CAUTION
• This baby monitoring system includes a
special lens which is capable of optical zoom
and requires delicate treatment. Please avoid
disassembling, dropping, or any other rough
handling.
• The default volume of your parent unit is level 4.
If you experience high-pitched screeching noise
from your baby monitor while positioning:
-Make sure your baby units and parent unit are
more than 1 meter (3 feet) apart, OR
-Turn down the volume of your parent unit.
Mount the baby monitor (optional)
NOTE
• Check for reception strength and camera angle
before drilling the holes.
1. Place the wall mount bracket on a wall and
then use a pencil to mark the top and the
bottom holes as shown. Remove the wall
mount bracket and drill two holes in the wall
(7/32 inch drill bit).
2. If you drill the holes into a stud, go to step 3.
-OR-
If you drill the holes into an object other than
a stud, insert the wall anchors into the holes.
Tap gently on the ends with a hammer until
the wall anchors are flush with the wall.
3. Align the wall mount bracket and screws
with the holes in the wall as shown. Tighten
the screw in the middle hole first, so that the
wall mount bracket position is fixed. You can
tighten the other screw in the top hole.
Place the baby unit on the wall mount
bracket. Tighten the screw into the threaded
socket at the bottom to secure the baby unit.
-OR-
Insert the screws into the holes and tighten
the screws until only 1/4 inch of the screws
are exposed.
Place the baby unit on the wall mount bracket.
Tighten the screw into the threaded socket
at the bottom to secure the baby unit. Align
the holes on the wall mount bracket with the
screws on the wall, and slide the wall mount
bracket down until it locks into place.
4. The default angle of the wall mount bracket
is 90 degrees. You can maximize your
baby unit’s viewing angles by tilting the wall
mount bracket.
Hold the baby unit, and then rotate the knob
in anticlockwise direction. This will loosen
the joint of the wall mount bracket.
Tilt your baby unit up or down to adjust to
your preferred angle. Then, rotate the knob
in clockwise direction to tighten the joint and
secure the angle.
Operating range
The operating range of the baby monitor is
up to 300 meters (1,000 feet) outdoors or
50 meters (160 feet) indoors. The actual
operating range may vary depending on
the environmental conditions and other
interferences such as walls, doors and other
obstructions.
Unpair a baby unit
NOTE
Make sure you power on the baby unit and the
parent unit before unpairing the baby unit.
1. Press MENU when the parent unit is idle.
2. Press or to choose Pair/Unpair CAM,
then press SELECT.
3. Press or to choose Unpair CAM, then
press SELECT.
4. Press or to choose a desired baby unit,
then press SELECT.
5. The screen displays To unpair CAM X,
press the [ZOOM] key at the Parent
Unit.. Press on the parent unit.
6. The screen displays Then, press the
[MENU/SELECT] key to confirm.. Press
SELECT to continue.
7. When unpairing is successful, the screen
displays CAM X is unpaired and returns
to previous menu. If there is no paired
baby unit, the screen displays No CAM is
paired./No link to CAM 1?.The LED light
on the selected baby unit flashes slowly.
General product care
To keep this product working well and looking good,
follow these guidelines:
• Avoid putting it near heating appliances and
devices that generate electrical noise (for
example, motors or fluorescent lamps).
• DO NOT expose it to direct sunlight or moisture.
• Avoid dropping the product or treating it roughly.
• Clean with a soft cloth.
• DO NOT immerse the baby unit in water and do
not clean them under the tap.
• DO NOT use cleaning spray or liquid cleaners.
• Make sure the baby unit is dry before you connect
them to the mains again.
• This baby monitoring system includes a
special lens which is capable of optical zoom
and requires delicate treatment. Please avoid
disassembling, dropping, or any other rough
handling.
Important safety instructions
When using your equipment, basic safety precautions
should always be followed to reduce the risk of fire,
electric shock and injury, including the following:
1. Follow all warnings and instructions marked on
the product.
2. Adult setup is required.
3. This product is intended as an aid. It is not
a substitute for responsible and proper adult
supervision and should not be used as such.
4. This product is not intended for use as a medical
monitor.
5. Do not use this product near water. For example,
do not use it next to a bath tub, wash bowl,
kitchen sink, laundry tub or swimming pool, or in
a wet basement or shower.
6. Use only the adapters included with this product.
Incorrect adapter polarity or voltage can
seriously damage the product.
Baby unit power adapter: Output: 6V DC 600mA
7. The power adapters are intended to be correctly
oriented in a vertical or floor mount position. The
prongs are not designed to hold the plug in place
if it is plugged into a ceiling, under-the-table or
cabinet outlet.
8. For pluggable equipment, the socket-outlet
shall be installed near the equipment and shall
be easily accessible.
9. Unplug this product from the wall outlet before
cleaning. Do not use liquid or aerosol cleaners.
Use a damp cloth for cleaning.
10. Do not cut off the power adapters to replace them
with other plugs, as this causes a hazardous
situation.
11. Do not allow anything to rest on the power cords.
Do not install this product where the cords may
be walked on or crimped.
12. This product should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of power
supply in your home, consult your dealer or local
power company.
13. Do not overload wall outlets or use an extension
cord.
14. Do not place this product on an unstable table,
shelf, stand or other unstable surfaces.
15. This product should not be placed in any area
where proper ventilation is not provided. Slots
and openings in the back or bottom of this
product are provided for ventilation. To protect
them from overheating, these openings must
not be blocked by placing the product on a soft
surface such as a bed, sofa or rug. This product
should never be placed near or over a radiator
or heat register.
7
8
2
4
5
1
3
6
9
11
10
12
13
14
＜1m (3ft)
＞1m (3ft)
16. Never push objects of any kind into this product
through the slots because they may touch
dangerous voltage points or create a short circuit.
Never spill liquid of any kind on the product.
17. To reduce the risk of electric shock, do not
disassemble this product, but take it to an
authorized service facility. Opening or removing
parts of the product other than specified access
doors may expose you to dangerous voltages
or other risks. Incorrect reassembling can cause
electric shock when the product is subsequently
used.
18. You should test the sound reception every
time you turn on the units or move one of the
components.
19. Periodically examine all components for damage.
20. Be aware of possible loss of privacy while using
public airwaves. Conversations may be picked
up by other nursery monitors, cordless phones,
scanners, etc.
21. Children should be supervised to ensure that
they do not play with the product.
22. The product is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
SAVE THESE INSTRUCTIONS
Cautions
1. Use and store the product at a temperature
between 32oF and 104oF.
2. Do not expose the product to extreme cold,
heat or direct sunlight. Do not put the product
close to a heating source.
3. Make sure the baby unit(s) and the adapter
cord(s) are always out of reach of the baby,
at least 3 feet away from the baby or crib, to
avoid a possible strangulation hazard.
4. Never place the baby unit(s) inside the baby’s
crib or playpen. Never cover the baby unit(s)
with anything such as a towel or a blanket.
5. Other electronic products may cause
interference with your baby monitor. Try
installing your baby monitor as far away
from these electronic devices as possible:
wireless routers, radios, cellular telephones,
intercoms, room monitors, televisions,
personal computers, kitchen appliances and
cordless telephones.
Precautions for users of implanted cardiac
pacemakers
Cardiac pacemakers (applies only to digital cordless
devices):
Wireless Technology Research, LLC (WTR), an
independent research entity, led a multidisciplinary
evaluation of the interference between portable
wireless devices and implanted cardiac
pacemakers. Supported by the U.S. Food and Drug
Administration, WTR recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six inches
from the pacemaker.
• Should NOT place wireless devices directly over
the pacemaker, such as in a breast pocket, when
it is turned ON.
WTR’s evaluation did not identify any risk to
bystanders with pacemakers from other persons
using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards
regarding electromagnetic fields (EMF). If handled
properly and according to the instructions in this
user’s manual, the product is safe to be used based
on scientific evidence available today.
The RBRC® seal
The RBRC® seal on the lithium-ion battery indicates
that VTech Communications, Inc. is voluntarily
participating in an industry program to collect and
recycle these batteries at the end of their useful
lives, when taken out of service within the United
States and Canada.
The RBRC® program provides a convenient
alternative to placing used lithium-ion batteries into
the trash or municipal waste, which may be illegal in
your area.
VTech’s participation in RBRC® makes it easy for
you to drop off the spent battery at local retailers
participating in the RBRC® program or at authorized
VTech product service centers. Please call
1 (800) 8 BATTERY® for information on Li-ion
battery recycling and disposal bans/restrictions in
your area. VTech’s involvement in this program is
part of its commitment to protecting our environment
and conserving natural resources.
RBRC® and 1 (800) 8 BATTERY®
are registered trademarks of the
Rechargeable Battery Recycling
Corporation.
FCC and IC regulations
FCC Part 15
This equipment has been tested and found to
comply with the requirements for a Class B digital
device under Part 15 of the Federal Communications
Commission (FCC) rules. These requirements are
intended to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
WARNING: Changes or modifications to this
equipment not expressly approved by the party
responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
To ensure safety of users, the FCC has established
criteria for the amount of radio frequency energy
that can be safely absorbed by a user or bystander
according to the intended usage of the product. This
product has been tested and found to comply with
the FCC criteria. The baby unit shall be installed
and used such that parts of all persons’ body are
maintained at a distance of approximately 8 in (20
cm) or more.
This Class B digital apparatus complies with
Canadian requirement:
CAN ICES-3 (B)/NMB-3(B)
Industry Canada
This device complies with Industry Canada licence-
exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference,
including interference that may cause undesired
operation.
The term ‘’IC:‘’ before the certification/registration
number only signifies that the Industry Canada
technical specifications were met.
This product meets the applicable Innovation, Science
and Economic Development Canada technical
specifications.
RF radiation exposure statement
The baby unit complies with FCC RF radiation
exposure limits set forth for an uncontrolled
environment. The baby unit should be installed and
operated with a minimum distance of 8 in (20 cm)
between the baby unit and all persons’ body. Use of
other accessories may not ensure compliance with
FCC RF exposure guidelines. This transmitter must
not be co-located or operating in conjunction with
any other antenna or transmitter. This equipment
complies also with Industry Canada RSS-102 with
respect to Canada’s Health Code 6 for Exposure of
Humans to RF Fields.
For cETL compliance only
Mesures de sécurité importantes
Lorsque vous utilisez votre appareil, vous devriez
toujours suivre certaines mesures de précaution
de base afin de réduire les risques d’incendie,
d’électrocution et de blessures corporelles, dont
ceux qui suivent :
1. Observez toutes les instructions et mises en
garde inscrites sur l’appareil.
2. L’installation par un adulte est requise.
3. Ce produit a été conçu pour être un dispositif
d’appoint seulement. Il n’est pas le remplacement
d’une supervision responsable et adéquate par
un adulte et ne devrait pas être utilisé comme telle.
4. Ce produit n’est pas conçu pour être utilisé en
tant que moniteur médical.
5. N’utilisez pas cet appareil près de l’eau ni de
toute autre source d’humidité, par exemple, près
d’une baignoire, cuve à lessive, évier de cuisine,
dans un sous-sol humide ni près d’une piscine,
dans un soussol humide ou une douche.
6. N’utilisez que les adaptateurs inclus avec ce
produit. L’utilisation d’un adaptateur dont la
polarité ou la tension serait inadéquate risque
d’endommager sérieusement le produit et mettre
votre sécurité en péril.
Adaptateur de l’unité du bébé : Sortie : 6 V CC
600mA
7. Pour les PRODUITS À BRANCHER À UNE
PRISE DE COURANT, la prise de courant doit
être installée près du produit, afin d’assurer une
accessibilité sécuritaire à la prise de courant.
8. Lorsqu’ils sont branchés dans une prise de
courant, les adaptateurs secteur ont été conçus
pour être orientés correctement, soit à la
verticale ou au plancher. Les broches n’ont pas
été conçues pour supporter le poids du bloc
d’alimentation et le maintenir en place si celuici
est branché dans une prise au plafond, sous une
table ou dans un meuble.
9. Débranchez ce produit de la prise de courant
avant de procéder au nettoyage. N’utilisez pas de
nettoyants en aérosols. Utilisez un chiffon humide
pour le nettoyer.
10. Ne coupez pas les cordons d’alimentation pour
remplacer les fiches, car ceci peut présenter un
danger potentiel.
11. Ne laissez aucun objet reposer ni appuyer sur
le cordon d’alimentation. N’installez pas cet
appareil dans un endroit où l’on risque d’écraser
le cordon d’alimentation ou de le piétiner.
12. Ne faites fonctionner cet appareil qu’avec le
type d’alimentation indiqué sur l’étiquette. Si
vous ne connaissez pas le type d’alimentation
que vous possédez à votre domicile, consultez
votre marchand ou votre compagnie locale
d’électricité.
13. Ne surchargez pas les prises de courant
murales ni les rallonges électriques.
14. Ne placez pas cet appareil sur un chariot,
meuble, trépied, support de montage ni table
chancelants.
15. Les trous et ouvertures du boîtier, situés à
l’arrière de l’appareil ou sous celui-ci, servent à
aérer l’appareil. Pour l’empêcher de surchauffer,
ne bloquez sous aucun prétexte ces ouvertures
et n’empêchez pas l’aération adéquate de
l’appareil en le plaçant sur un lit, divan, tapis ou
toute autre surface similaire. De même, ne le
positionnez pas à proximité ni au-dessus d’une
source de chaleur ou d’un calorifère. De plus,
ne placez pas l’appareil dans un endroit avant
de vous assurer qu’il y ait une bonne circulation
d’air.
16. N’enfoncez jamais d’objets à travers les
ouvertures de cet appareil, car ils pourraient
entrer en contact avec des points de tension
dangereux ou causer des courts-circuits qui
peuvent dégénérer en incendies ou en risques
d’électrocution. Ne renversez jamais de liquide
dans ce produit.
17. Afin de réduire les risques d’électrocution, ne
démontez pas cet appareil, mais apportez-le
dans un centre de service autorisé. L’ouverture
du boîtier ou le retrait de toutes pièces que
contient cet appareil, à l’exception de l’accès
autorisé à certaines portes ou ouvertures,
risque de vous exposer à des points de tension
dangereux ou d’autres dangers. Un remontage
incorrect peut par la suite présenter des risques
d’électrocution.
18. Vous devriez tester la réception chaque fois que
vous mettez l’appareil en fonction.
19. Examinez les composantes afin de vérifier si
celles-ci ne sont pas endommagées.
20. Soyez avisé de la perte de la confidentialité
lorsque vous utilisez les ondes publiques. Les
conversations peuvent être entendues par
d’autres moniteurs de bébé, des téléphones
sans fil, des scanneurs, etc.
21. Les enfants devraient être supervisés afin de
vous assurer qu’ils ne jouent pas avec l’appareil.
22. Le produit n’est pas conçu pour être utilisé
par des personnes (incluant des enfants) aux
capacités physiques, sensorielles ou mentales
réduites ou qui manquent d’expérience et de
connaissances, à moins qu’on leur ait donné
suffisamment de supervision ou d’instructions
relativement à l’utilisation de l’appareil par une
personne responsable de leur sécurité.
CONSERVEZ CES INSTRUCTIONS
Mises en garde
1. Utilisez et entreposez le produit à une
température entre 0˚ C (32˚F) et 40˚C (104˚ F).
2. N’exposez pas cet appareil à des froids ou des
chaleurs extrêmes, ainsi qu’à la lumière directe
du soleil. Ne l’installez pas près d’une source de
chauffage.
3. Assurez-vous que le moniteur et le cordon
de l’adaptateur sont toujours hors de portée
des enfants, à au moins 1 mètre (3 pieds) de
l’enfant ou du berceau, pour éviter tout risque de
strangulation.
4. Ne jamais placer le moniteur à l’intérieur du
berceau ou du parc de bébé. Ne jamais couvrir
le moniteur ou l’unité (s) portative avec un article
tel une serviette ou une couverture.
5. D’autres équipements électroniques peuvent
produire des interférences sur votre moniteur
vidéo et audio. Tentez d’installer votre
moniteur vidéo ou audio à l’écart des appareils
électroniques tels que des routeurs sans fil,
radios, téléphones cellulaires, interphones,
moniteurs, téléphones, ordinateurs personnels,
électroménagers et téléphones sans fil.
Stimulateurs cardiaques implantés dans
l’organisme
Les simulateurs cardiaques (ne s’applique qu’aux
dispositifs numériques sans fil) :
L’organisme ‘Wireless Technology Research, LLC
(WTR)’, une firme de recherche indépendante,
a mené une évaluation pluridisciplinaire des
interférences entre les téléphones sans fil portatifs
et les stimulateurs cardiaques implantés dans
l’organisme. Appuyée par l’Administration des
aliments et drogues (FDA) des États-Unis, la firme
WTR recommande aux médecins:
Avis aux détenteurs de stimulateurs cardiaques
• Vous devriez maintenir les dispositifs sans fil à au
moins six pouces du simulateur cardiaque.
• Ils ne doivent PAS placer le téléphone sans fil
directement sur le stimulateur cardiaque, tel que
dans une poche de chemise, lorsque celui-ci est
en marche.
L’étude effectuée par l’organisme WRS n’a pas
identifié de risque pour les détenteurs de simulateurs
cardiaques causés par les gens qui utilisent
dispositifs sans fil à proximité de ceux-ci.
Champs électromagnétiques (EMF)
Ce produit de VTech est conforme à toutes
les normes se rapportant aux champs
électromagnétiques (EMF) standard. Si vous le
manipulez correctement en suivant les instructions
de ce guide, son utilisation sera sécuritaire pendant
de nombreuses années, selon les meilleures
évidences scientifiques dont nous disposons
aujourd’hui.
Limited warranty
What does this limited warranty cover?
The manufacturer of this VTech Product warrants to
the holder of a valid proof of purchase (“Consumer”
or “you”) that the Product and all accessories
provided in the sales package (“Product”) are free
from defects in material and workmanship, pursuant
to the following terms and conditions, when
installed and used normally and in accordance
with the Product operating instructions. This
limited warranty extends only to the Consumer for
Products purchased and used in the United States
of America and Canada.
What will VTech do if the Product is not free from
defects in materials and workmanship during
the limited warranty period (“Materially Defective
Product”)?
During the limited warranty period, VTech’s
authorized service representative will repair
or replace at VTech’s option, without charge,
a Materially Defective Product. If we repair
the Product, we may use new or refurbished
replacement parts. If we choose to replace the
Product, we may replace it with a new or refurbished
Product of the same or similar design. We will
retain defective parts, modules, or equipment.
Repair or replacement of the Product, at VTech’s
option, is your exclusive remedy. VTech will return
the repaired or replacement Products to you in
working condition. You should expect the repair or
replacement to take approximately 30 days.
How long is the limited warranty period?
The limited warranty period for the Product extends
for ONE (1) YEAR from the date of purchase. If
VTech repairs or replaces a Materially Defective
Product under the terms of this limited warranty,
this limited warranty also applies to the repaired
or replacement Product for a period of either (a)
90 days from the date the repaired or replacement
Product is shipped to you or (b) the time remaining
on the original one-year warranty; whichever is
longer.
What is not covered by this limited warranty?
This limited warranty does not cover:
1. Product that has been subjected to misuse,
accident, shipping or other physical damage,
improper installation, abnormal operation or
handling, neglect, inundation, fire, water or other
liquid intrusion; or
2. Product that has been damaged due to repair,
alteration or modification by anyone other than an
authorized service representative of VTech; or
3. Product to the extent that the problem experienced
is caused by signal conditions, network reliability,
or cable or antenna systems; or
4. Product to the extent that the problem is caused
by use with non-VTech accessories; or
5. Product whose warranty/quality stickers, product
serial number plates or electronic serial numbers
have been removed, altered or rendered illegible; or
6. Product purchased, used, serviced, or shipped for
repair from outside the United States of America
or Canada, or used for commercial or institutional
purposes (including but not limited to Products
used for rental purposes); or
7. Product returned without a valid proof of purchase
(see item 2 on the next page); or
8. Charges for installation or set up, adjustment of
customer controls, and installation or repair of
systems outside the unit.
How do you get warranty service?
To obtain warranty service in the USA, please visit
our website at www.vtechphones.com or
call 1 (800) 595-9511. In Canada, go to
www.vtechcanada.com or call 1 (800) 267-7377.
NOTE: Before calling for service, please review the
user’s manual - a check of the Product’s controls
and features may save you a service call.
Except as provided by applicable law, you assume
the risk of loss or damage during transit and
transportation and are responsible for delivery
or handling charges incurred in the transport of
the Product(s) to the service location. VTech
will return repaired or replaced Product under
this limited warranty. Transportation, delivery or
handling charges are prepaid. VTech assumes no
risk for damage or loss of the Product in transit.
If the Product failure is not covered by this limited
warranty, or proof of purchase does not meet the
terms of this limited warranty, VTech will notify you
and will request that you authorize the cost of repair
prior to any further repair activity. You must pay for
the cost of repair and return shipping costs for the
repair of Products that are not covered by this limited
warranty.
What must you return with the Product to get
warranty service?
1. Return the entire original package and contents
including the Product to the VTech service
location along with a description of the malfunction
or difficulty; and
2. Include a “valid proof of purchase” (sales receipt)
identifying the Product purchased (Product model)
and the date of purchase or receipt; and
3. Provide your name, complete and correct mailing
address, and telephone number.
Other limitations
This warranty is the complete and exclusive
agreement between you and VTech. It supersedes
all other written or oral communications related to this
Product. VTech provides no other warranties for this
Product. The warranty exclusively describes all of
VTech’s responsibilities regarding the Product. There
are no other express warranties. No one is authorized
to make modifications to this limited warranty and you
should not rely on any such modification.
State/Provincial Law Rights: This warranty gives you
specific legal rights, and you may also have other
rights, which vary from state to state or province to
province.
Limitations: Implied warranties, including those of
fitness for a particular purpose and merchantability (an
unwritten warranty that the Product is fit for ordinary
use) are limited to one year from the date of purchase.
Some states/provinces do not allow limitations on
how long an implied warranty lasts, so the above
limitation may not apply to you. In no event shall
VTech be liable for any indirect, special, incidental,
consequential, or similar damages (including, but
not limited to lost profits or revenue, inability to use
the Product or other associated equipment, the cost
of substitute equipment, and claims by third parties)
resulting from the use of this Product. Some states/
provinces do not allow the exclusion or limitation of
incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
Please retain your original sales receipt as proof
of purchase.
Technical specifications
Frequency
control
Crystal controlled PLL synthesizer
Transmit
frequency
2406 - 2475 MHz
Channels 24
Nominal
effective
range
Maximum power allowed by FCC
and IC. Actual operating range may
vary according to environmental
conditions at the time of use.
Power
requirements
Output: 6V DC @ 600mA
Credits:
The Background Noise sound file was created by Caroline
Ford, and is used under the Creative Commons license.
The Stream Noise sound file was created by Caroline Ford,
and is used under the Creative Commons license.
The Crickets At Night sound file was created by Mike Koenig,
and is used under the Creative Commons license.
The Heart Beat sound file was created by Zarabadeu, and is
used under the Creative Commons license.
Specifications are subject to change without notice.
© 2017 VTech Communications, Inc.
All rights reserved. 01/17. VM5231_CIB_V1
Document order number: 91-010502-010-100
