VTech Telecommunications 80-1429-00 Remote Ringer User Manual
VTech Telecommunications Ltd Remote Ringer
User Manual
Replace a remote ringer
If you have purchased this new SN7014
accessory remote ringer to replace an old
one, you must deregister the old remote
ringer first, and then register this new
remote ringer to your CareLine telephone
base (SN5127/SN5147).
Deregister remote ringer
If you want to replace a remote ringer, you
must deregister all the devices, and then
individually register each device.
If you want to register a remote ringer
to another telephone base, you must
deregister all devices, and then register
each device individually to the desired
telephone base.
To deregister all devices from the telephone
base:
1. Press and hold PAGE on the telephone
base for about five seconds until the
visual indicator light on the telephone
base turns on. Keep holding PAGE until
the visual ringer indicator light begins to
flash. Release PAGE.
2. Immediately press PAGE again while the
light is still flashing.
You hear a confirmation tone when the
deregistration process completes. It
takes about 10 seconds to complete the
deregistration.
Operating range
The operating range of the remote ringer
is up to 1,000 feet outdoors or 150 feet
indoors. The actual operating range may
vary depending on the environmental
conditions and other interferences such as
walls, doors and other obstructions.
3. Insert the screws into the holes and
tighten the screws until only 1/4 inch of
the screws are exposed.
4. Align the wall mount holes of the remote
ringer with the screws on the wall. Slide
the remote ringer down until it locks into
place.
5. If you choose to run your remote ringer
with a power supply, connect the power
adapter to the remote ringer and a
power supply not controlled by a wall
switch.
2. Press and hold on the remote ringer
until the green LED light on the remote
ringer flashes, then release .
It takes up to 60 seconds to complete
the registration. When the registration is
successful, the green LED lights on the
remote ringer turns to steady on, and the
telephone base beeps and its visual ringer
indicator light turns off.
If registration fails, start again from Step 1
above.
Note
• You cannot register a remote ringer if any
other system device is in use.
2. Press and hold on the remote ringer
until the green LED light on the remote
ringer flashes, then release .
It takes up to 60 seconds to complete
the registration. When the registration is
successful, the green LED lights on the
remote ringer turns to steady on, and the
telephone base beeps and its visual ringer
indicator light turns off.
If registration fails, start again from Step 1
above.
Note
• You cannot register a remote ringer if any
other system device is in use.
To register a remote ringer to the
SN5147 telephone base:
Connect the remote ringer to a power
supply or install the batteries before
registering it to the telephone base.
1. When the telephone is not in use,
Press and hold at the telephone
base for about five seconds until the
visual ringer indicator light turns on.
Release .
SN7014
Remote ringer
for use with
VTech CareLine®
SN5127/SN5147
User’s manual
Go to www.vtechphones.com
to register your product for enhanced
warranty support and latest VTech
product news
Install the battery
If you choose to run your remote ringer
on batteries, install the batteries as shown
below.
Notes
• You need to purchase 3 AA alkaline batteries
separately to run your remote ringer
wirelessly.
• If the remote ringer will not be used for
a long time, disconnect and remove the
batteries to prevent possible leakage.
Handset overview
1 – PAIR button
• Press and hold to enter pairing mode.
2 – Power jack
3 – LED lights
• Red when the battery is low.
• Green when the remote ringer
is powered on.
• Amber while checking signal
strength.
4 – Loud speaker
5 – Visual ringer indicator (white LED)
• Flashes when receiving an incoming
call, or when there is an event
triggered on another registered
device, for example, when the audio
door bell is ringing or when reminder
alarm is triggered.
6 – Ringer volume
• Slide the switch to adjust the ringer
volume between:
- Low;
- Medium; and
- High.
Caution
• For hearing protection, do not put
the remote ringer near your ear as
loud ringer sound may damage your
hearing. Adjust the volume to lower
the ringer sound if you find it too loud.
7 – Alert modes
• Slide the switch to change the alert
mode between:
Flash only
The LED light flashes when there is an
incoming call or event triggered.
Play melody only
The ringer plays the melody when
there is an incoming call or event
triggered.
Flash and play melody
The ringer plays the melody and the
LED light flashes when there is an
incoming call or event triggered.
Turn off both flash and melody
The ringer does not play the melody
and the LED light does not flash
when there is an incoming call or
event triggered.
8 – Melodies
• Slide the switch to change between
the three melodies.
9 – Battery compartment cover
10 – Wall mounting holes
General product care
To keep this product working well and looking
good, follow these guidelines:
• Avoid putting it near heating appliances and
devices that generate electrical noise (for
example, motors or fluorescent lamps).
• DO NOT expose it to direct sunlight or
moisture.
• Avoid dropping the product or treating it
roughly.
• Clean with a soft cloth.
• DO NOT immerse the remote ringer in water
and do not clean them under the tap.
• DO NOT use cleaning spray or liquid
cleaners.
• Make sure the remote ringer is dry before
you connect it to the mains again.
Storage
When you are not going to use the remote
ringer for some time, remove the batteries
from the remote ringer. Store the remote
ringer and the power adapter in a cool and
dry place.
Frequently asked questions
Below is the question most frequently asked
about the remote ringer. If you cannot find the
answer to your question in the below table,
visit our website at www.vtechphones.com
or call
1 (800) 595-9511 for customer service. In
Canada, go to www.vtechcanada.com or call
1 (800) 267-7377.
The remote
ringer doesn’t
work with the
telephone
system
equipment.
Make sure the 3 AA alkaline
batteries are installed.
The remote ringer may be
deregistered from your
telephone system. Refer to
Add and register a remote
ringer and register the
remote ringer back.
The remote ringer may be
out of range. Move the
remote ringer closer to
your telephone system.
If the above suggestions
do not work, deregister all
devices and register them
to the telephone base
again.
Connect to power supply
The remote ringer runs on 3 AA alkaline
batteries (not included), or you can connect
your remote ringer to a power supply.
Connect Remote ringer to power supply
Notes:
• Use only the power adapter provided.
• Make sure the electrical outlet is not
controlled by a wall switch.
• The power adapter is intended to be
correctly oriented in a vertical or floor mount
position. The prongs are not designed to
hold the plug in place if it is plugged into a
ceiling, under-the-table or cabinet outlet.
• Make sure the remote ringer and the power
adapter cord are out of reach of children.
Before use
Add and register a remote ringer
Register each new SN7014 remote
ringer to your CareLine® telephone
base (SN5127/SN5147) before use. Your
telephone system supports a maximum
of four handsets and 30 compatible ULE
devices.
Notes
• Connect the remote ringer to a power
supply or install the batteries before
registering it to the telephone base.
• Visit www.vtechphones.com for a list
of ULE devices that are compatible with
your CareLine telephone base SN5127/
SN5147.
To register a remote ringer to the
SN5127 telephone base:
Connect the remote ringer to a power
supply or install the batteries before
registering it to the telephone base.
1. When the telephone is not in use,
Press and hold PAGE at the telephone
base for about five seconds until the
visual ringer indicator light turns on.
Release PAGE.
Congratulations
on purchasing your new VTech product.
Before using this product, please read
Important safety instructions.
This user’s manual provides you with
installation and operation instructions.
Please read this manual thoroughly to
ensure proper installation and operation of
this VTech product.
For support, shopping, and everything new
at VTech, visit our website at
www.vtechphones.com. In Canada, please
visit www.vtechcanada.com.
User’s manual
What’s in the box
Your product package contains the
following items. Save your sales receipt
and original packaging in the event
warranty service is necessary.
1
2
3
4
5
7
8
6
9
10
2
1
1
2
3
Match the polarity markings (+ and -)
inside the battery compartment.
Mount the remote ringer
Notes
• You will need to purchase the following items
separately to mount your remote ringer:
• Before mounting your remote ringer, make
sure you have installed the batteries if you
choose to run your remote ringer with
batteries.
1. Use a pencil to mark two holes in
parallel. Make sure they are the same
distance apart as the wall mount holes on
the remote ringer.
• Check for signal strength before
drilling the holes.
2. Drill two holes in the wall (7/32” drill bit).
• If you drill the holes into an object
other than a stud, insert the wall
anchors into the holes and tap gently
on the ends with a hammer until the
wall anchors are flush with the wall.
SN5127 base SN5147 base
Test the signal strength
You can mount the remote ringer on a wall.
Before you mount the remote ringer,
follow the instructions below to check the
signal strength between the remote ringer
and the telephone base. Make sure you
mount the device in a location where the
signal strength is good.
Test device signal strength with your
SN5127/SN5147 telephone
1. Press MENU on the cordless handset
when the telephone is not in use.
2. Press or to scroll to Device setup,
and then press SELECT.
3. Press SELECT to select Check signal.
4. Scroll to select Remote ringer, and then
press SELECT.
5. When the handset screen displays PLS
TRIGGER THE DEVICE, make sure your
remote ringer is powered on, and then
press SELECT.
6. The handset screen displays AWAITING
SIGNAL.
• If the handset screen displays NO
SIGNAL, press SELECT, and then
repeat from step 2 to test again.
• If the handset screen displays WEAK
SIGNAL, move the remote ringer
closer to the base, and then adjust
the remote ringer’s location to
improve the signal. Press SELECT, and
then repeat from step 2 to test again.
7. When the handset screen displays
GOOD, press SELECT. The testing is
complete.
x 2 x 2
VTech Communications, Inc.
A member of THE VTECH GROUP OF COMPANIES.
VTech is a registered trademark of VTech Holdings Limited.
Specifications are subject to change without notice.
© 2018 VTech Communications, Inc.
All rights reserved. 03/18. SN7014_CIB_V1.0
Document order number: 91-010998-010-100
Designed to fit your home.
And your life.
Precautions for users of implanted cardiac
pacemakers
Cardiac pacemakers (applies only to digital
cordless devices):
Wireless Technology Research, LLC (WTR),
an independent research entity, led a
multidisciplinary evaluation of the interference
between portable wireless devices and
implanted cardiac pacemakers. Supported by
the U.S. Food and Drug Administration, WTR
recommends to physicians that:
Pacemaker patients
• Should keep wireless devices at least six
inches from the pacemaker.
• Should NOT place wireless devices directly
over the pacemaker, such as in a breast
pocket, when it is turned ON.
WTR’s evaluation did not identify any risk
to bystanders with pacemakers from other
persons using wireless devices.
Electromagnetic fields (EMF)
This VTech product complies with all standards
regarding electromagnetic fields (EMF).
If handled properly and according to the
instructions in this user’s manual, the product
is safe to be used based on scientific evidence
available today.
FCC and IC regulations
FCC Part 15
NOTE: This equipment has been tested and
found to comply with the requirements for
a Class B digital device under Part 15 of the
Federal Communications Commission (FCC)
rules. These requirements are intended to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/
TV technician for help.
WARNING: Changes or modifications to this
equipment not expressly approved by the party
responsible for compliance could void the
user’s authority to operate the equipment.
This device complies with Part 15 of the FCC
rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.
To ensure safety of users, the FCC has
established criteria for the amount of radio
frequency energy that can be safely absorbed
by a user or bystander according to the
intended usage of the product. This product
has been tested and found to comply with the
FCC criteria. The remote ringer shall be installed
and used such that parts of all persons’ body
are maintained at a distance of approximately
20 cm (8 inches) or more.
This Class B digital apparatus complies with
Canadian requirement:
CAN ICES-3 (B)/NMB-3(B)
Industry Canada
This device complies with Industry Canada
licence-exempt RSS standard(s).
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.
The term ‘’IC:‘’ before the certification/
registration number only signifies that the
Industry Canada technical specifications were
met.
This product meets the applicable Innovation,
Science and Economic Development Canada
technical specifications.
RF radiation exposure statement
The remote ringer complies with FCC RF
radiation exposure limits set forth for an
uncontrolled environment. The remote
ringer should be installed and operated
with a minimum distance of 20 cm (8 inches)
between the remote ringer and all persons’
body. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
This transmitter must not be co-located or
operating in conjunction with any other antenna
or transmitter. This equipment complies also
with Industry Canada RSS-102 with respect
to Canada’s Health Code 6 for Exposure of
Humans to RF Fields.
For C-UL compliance only
Mesures de sécurité importantes
Lorsque vous utilisez votre appareil, vous
devriez toujours suivre certaines mesures de
précaution de base afin de réduire les risques
d’incendie, d’électrocution et de blessures
corporelles, dont ceux qui suivent :
1. Lisez et comprenez bien toutes les
instructions.
2. Observez toutes les instructions et mises en
garde inscrites sur l’appareil.
3. Débranchez ce produit de la prise de
courant avant de procéder au nettoyage.
N’utilisez pas de nettoyants en aérosols.
Utilisez un chiffon humide pour le nettoyer.
4. N’utilisez pas ce produit près de l’eau, tel
que près d’un bain, d’un lavabo, d’un évier
de cuisine, d’un bac de lavage ou d’une
piscine, ou dans un sous-sol humide ou sous
la douche.
5. Ne placez pas cet appareil sur un chariot,
support ou table chancelants. L’appareil
pourrait tomber et être sérieusement
endommagé.
6. Ne coupez pas les cordons d’alimentation
pour remplacer les fiches, car ceci peut
présenter un danger potentiel.
7. Évitez d’installer le appareil dans les endroits
soumis à une température extrême, à la
lumière directe du soleil ou à proximité
immédiate d’autres appareils électriques
ou électroniques. Protégez votre appareil
contre les sources d’humidité, la poussière,
les vapeurs et les liquides corrosifs.
8. Le boîtier de l’appareil est doté de fentes
et d’ouvertures d’aération situées à
l’arrière ou en dessous. Afin d’empêcher la
surchauffe, ces ouvertures ne doivent pas
être obstruées en plaçant l’appareil sur un
lit, divan, tapis ou autre surface similaires.
Ne placez pas cet appareil à proximité d’un
élément de chauffage ni d’une plinthe
électrique. De plus, ne l’installez pas dans
une unité murale ou un cabinet fermé qui ne
possède pas d’aération adéquate.
9. Ne faites fonctionner cet appareil
qu’avec le type d’alimentation indiqué
sur les étiquettes de l’appareil. Si vous
ne connaissez pas le voltage de votre
maison, consultez votre marchand ou votre
fournisseur d’électricité.
10. Ne laissez aucun objet reposer ni appuyer
sur le cordon d’alimentation. N’installez
pas cet appareil dans un endroit oùê l’on
risque d’écraser le cordon d’alimentation
ou de le piétiner.
11. N’insérez jamais d’objets à travers les
fentes et ouvertures de cet appareil, car ils
pourraient toucher à des points de tension
dangereux ou court-circuiter des pièces,
ce qui constituerait un risque d’incendie
ou d’électrocution. N’échappez pas de
liquides dans l’appareil.
12. Afin de réduire les risques d’électrocution,
ne démontez pas l’appareil, mais
apportez-le plutôt à un centre de service
qualifié s’il doit être réparé. En enlevant
le couvercle, vous vous exposez à des
tensions dangereuses ou autres dangers
similaires. Un remontage inadéquat peut
être à l’origine d’une électrocution lors
d’une utilisation ultérieure de l’appareil.
Débranchez l’appareil avant de procéder
au nettoyage. Utilisez un chiffon humide et
doux.
13. Ne surchargez pas les prises de courant et
les rallonges.
14. Débranchez cet appareil de la prise
de courant et communiquez avec le
département de service à la clientèle de
VTech dans les cas suivants:
• Lorsque le cordon d’alimentation est
endommagé ou écorché.
• Si du liquide a été échappé dans
l’appareil.
• Si l’appareil a été exposé à une source
d’humidité telle que la pluie ou l’eau.
• Si le produit ne fonctionne pas normale-
ment en respectant les instructions de
fonctionnement. Réglez uniquement
les commandes indiquées dans le les
instructions de fonctionnement. Les
réglages incorrects des autres com-
mandes pourraient provoquer un
dommage qui pourrait exiger un travail
exhaustif de la part d’un technicien au-
torisé afin de rétablir le fonctionnement
normal de l’appareil.
• Si le produit a été échappé ou endom-
magé.
• Si le produit affiche une nette diminution
de sa performance.
15. Évitez d’utiliser l’appareil pendant un orage.
Les éclairs peuvent être à l’origine d’une
électrocution.
16. Ces adaptateurs ont été conçus pour être
orientés en position verticale ou montés au
sol. Les broches ne sont pas conçues pour
maintenir l’adaptateur en place si celui-ci est
barnché dans une prise au plafond ou sous
une table/ armoire.
17. Pour les PRODUITS À BRANCHER À UNE
PRISE DE COURANT, la prise de courant doit
être installée près du produit, afin d’assurer
une accessibilité sécuritaire à la prise de
courant.
18. Examinez les composantes afin de vérifier si
celles-ci ne sont pas endommagées.
19. MISE EN GARDE : Il peut y avoir un risque
d’explosion si vous utilisez le mauvais type
de piles. Utilisez uniquement les piles
indiquées dans ce manuel. N’incinérez pas
les piles. Celles-ci risqueraient d’exploser.
20. N’utilisez que les adaptateur inclus avec ce
produit. L’utilisation d’un adaptateur dont
la polarité ou la tension serait inadéquate
risque d’endommager sérieusement le
produit et mettre votre sécurité en péril.
Adaptateur: Sortie : 6 V CC 450 mA
CONSERVEZ CES INSTRUCTIONS
Pile
• MISE EN GARDE: Afin de prévenir les risques
d’incendie ou d’explosion de la pile, replacez
la pile avec une pile du même type.
• Jetez les piles épuisées en respectant les
instructions.
• Le bloc-piles ne doit pas être exposé la
chaleur excessive telle que la lumièêre du
soleil ou au feu.
• Ne jetez pas la pile au feu. Vérifiez les
instructions spécifiques de mise aux rebus
auprès des autorités locales.
• N’ouvrez pas et ne mutilez pas la pile.
L’électrolyte qui s’en échapperait est corrosif
et pourrait causer des brûlures ou des
blessures aux yeux ou à la peau. L’électrolyte
est toxique si avalé.
• Soyez prudents lorsque vous manipulez
les piles afin d’éviter les courts-circuits
provoqués par des matériaux conducteurs.
Stimulateurs cardiaques implantés dans
l’organisme
Les simulateurs cardiaques (s’applique
uniquement aux téléphones numériques sans
fil) :
L’organisme ‘Wireless Technology Research, LLC
(WTR)’, une firme de recherche indépendante,
a mené une évaluation pluridisciplinaire
des interférences entre les téléphones sans
fil portatifs et les stimulateurs cardiaques
implantés dans l’organisme. Appuyée par
l’Administration des aliments et drogues (FDA)
des États-Unis, la firme WTR recommande aux
médecins :
Avis aux détenteurs de stimulateurs cardiaques
• Vous devriez maintenir les dispositifs sans fil
au moins six pouces du simulateur cardiaque.
• Ils ne doivent PAS placer les dispositifs sans
fil directement sur le stimulateur cardiaque,
tel que dans une poche de chemise, lorsque
celui-ci est en marche.
L’étude effectuée par l’organisme WRS n’a
pas identifié de risque pour les détenteurs de
simulateurs cardiaques causés par les gens qui
utilisent un téléphone sans fil à proximité de
ceux-ci.
Limited warranty
What does this limited warranty cover?
The manufacturer of this VTech Product
warrants to the holder of a valid proof of
purchase (“Consumer” or “you”) that the
Product and all accessories provided in the
sales package (“Product”) are free from defects
in material and workmanship, pursuant to the
following terms and conditions, when installed
and used normally and in accordance with the
Product operating instructions. This limited
warranty extends only to the Consumer for
Products purchased and used in the United
States of America and Canada.
What will VTech do if the Product is not free
from defects in materials and workmanship
during the limited warranty period (“Materially
Defective Product”)?
During the limited warranty period, VTech’s
authorized service representative will repair
or replace at VTech’s option, without charge,
a Materially Defective Product. If we repair
the Product, we may use new or refurbished
replacement parts. If we choose to replace
the Product, we may replace it with a new or
refurbished Product of the same or similar
design. We will retain defective parts, modules,
or equipment. Repair or replacement of the
Product, at VTech’s option, is your exclusive
remedy. VTech will return the repaired or
replacement Products to you in working
condition. You should expect the repair or
replacement to take approximately 30 days.
How long is the limited warranty period?
The limited warranty period for the Product
extends for ONE (1) YEAR from the date
of purchase. If VTech repairs or replaces a
Materially Defective Product under the terms of
this limited warranty, this limited warranty also
applies to the repaired or replacement Product
for a period of either (a) 90 days from the date
the repaired or replacement Product is shipped
to you or
(b) the time remaining on the original
one-year warranty; whichever is longer.
What is not covered by this limited warranty?
This limited warranty does not cover:
1. Product that has been subjected to misuse,
accident, shipping or other physical
damage, improper installation, abnormal
operation or handling, neglect, inundation,
fire, water or other liquid intrusion; or
2. Product that has been damaged due
to repair, alteration or modification by
anyone other than an authorized service
representative of VTech; or
3. Product to the extent that the problem
experienced is caused by signal conditions,
network reliability, or cable or antenna
systems; or
4. Product to the extent that the problem is
caused by use with non-VTech accessories;
or
5. Product whose warranty/quality stickers,
product serial number plates or electronic
serial numbers have been removed, altered
or rendered illegible; or
6. Product purchased, used, serviced, or
shipped for repair from outside the United
States of America or Canada, or used
for commercial or institutional purposes
(including but not limited to Products used
for rental purposes); or
7. Product returned without a valid proof of
purchase (see item 2 on the next page); or
8. Charges for installation or set up, adjustment
of customer controls, and installation or
repair of systems outside the unit.
How do you get warranty service?
To obtain warranty service in the USA, please
visit our website at www.vtechphones.com or
call 1 (800) 595-9511. In Canada, go to
www.vtechcanada.com or call 1 (800) 267-7377.
NOTE: Before calling for service, please review
the user’s manual - a check of the Product’s
controls and features may save you a service
call.
Except as provided by applicable law, you
assume the risk of loss or damage during
transit and transportation and are responsible
for delivery or handling charges incurred in
the transport of the Product(s) to the service
location. VTech will return repaired or
replaced Product under this limited warranty.
Transportation, delivery or handling charges
are prepaid. VTech assumes no risk for damage
or loss of the Product in transit. If the Product
failure is not covered by this limited warranty, or
proof of purchase does not meet the terms of
this limited warranty, VTech will notify you and
will request that you authorize the cost of repair
prior to any further repair activity. You must pay
for the cost of repair and return shipping costs
for the repair of Products that are not covered
by this limited warranty.
What must you return with the Product to get
warranty service?
1. Return the entire original package and
contents including the Product to the VTech
service location along with a description of
the malfunction or difficulty; and
2. Include a “valid proof of purchase” (sales
receipt) identifying the Product purchased
(Product model) and the date of purchase or
receipt; and
3. Provide your name, complete and correct
mailing address, and telephone number.
Other limitations
This warranty is the complete and exclusive
agreement between you and VTech.
It supersedes all other written or oral
communications related to this Product. VTech
provides no other warranties for this Product.
The warranty exclusively describes all of VTech’s
responsibilities regarding the Product. There
are no other express warranties. No one is
authorized to make modifications to this limited
warranty and you should not rely on any such
modification.
State/Provincial Law Rights: This warranty gives
you specific legal rights, and you may also have
other rights, which vary from state to state or
province to province.
Limitations: Implied warranties, including
those of fitness for a particular purpose and
merchantability (an unwritten warranty that
the Product is fit for ordinary use) are limited
to one year from the date of purchase. Some
states/provinces do not allow limitations on how
long an implied warranty lasts, so the above
limitation may not apply to you. In no event
shall VTech be liable for any indirect, special,
incidental, consequential, or similar damages
19. CAUTION: Use only the batteries indicated in
this manual. There may be a risk of explosion
if a wrong type of battery is used for the
remote ringer. Do not dispose of batteries in
a fire. They may explode.
20. Use only the adapter included with this
product. Incorrect adapter polarity or
voltage can seriously damage the product.
Charger power adapter: Output:
6V DC @ 450mA.
SAVE THESE INSTRUCTIONS
Battery
• CAUTION: To prevent risk of fire or battery
explosion, replace with the correct battery
type.
• Dispose of used batteries according to the
instructions.
• Batteries should not be exposed to excessive
heat such as bright sunshine or fire.
• Do not dispose of the batteries in a fire.
Check
with local waste management codes for
special disposal instructions.
• Do not open or mutilate the batteries.
Released electrolyte is corrosive and may
cause burns or injury to the eyes or skin. The
electrolyte may be toxic if swallowed.
• Exercise care in handling batteries in order
not to create a short circuit with conductive
materials.
Important safety instructions
When using your remote ringer, basic safety
precautions should always be followed to
reduce the risk of fire, electric shock and injury,
including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked
on the product.
3. Unplug this product from the wall outlet
before cleaning. Do not use liquid or aerosol
cleaners. Use a dry non-abrasive cloth for
cleaning.
4. Do not use this product near water such as
near a bath tub, wash bowl, kitchen sink,
laundry tub or a swimming pool, or in a wet
basement or shower.
5. Do not place this product on an unstable
table, shelf, stand or other unstable surfaces.
6. Do not cut off the power adapters to replace
them with other plugs, as this causes a
hazardous situation.
7. Avoid placing the device in places with
extreme temperature, direct sunlight, or
other electrical devices. Protect your remote
ringer from moisture, dust, corrosive liquids
and fumes.
8. This product should not be placed in
any area where proper ventilation is not
provided. Slots and openings in the back
or bottom of this product are provided
for ventilation. To protect them from
overheating, these openings must not be
blocked by placing the product on a soft
surface such as a bed, sofa or rug. This
product should never be placed near or
over a radiator or heat register.
9. This product should be operated only from
the type of power source indicated on the
marking label. If you are not sure of the type
of power supply in your home, consult your
dealer or local power company.
10. Do not allow anything to rest on the power
cord. Do not install this product where the
cord may be walked on.
11. Never push objects of any kind into this
product through the slots because they may
touch dangerous voltage points or create a
short circuit. Never spill liquid of any kind on
the product.
12. To reduce the risk of electric shock, do not
disassemble this product, but take it to
an authorized service facility. Opening or
removing parts of the remote ringer other
than specified access doors may expose
you to dangerous voltages or other risks.
Incorrect reassembling can cause electric
shock when the product is subsequently
used.
13. Do not overload wall outlets and extension
cords.
14. Unplug this product from the wall outlet
and refer servicing to an authorized service
facility under the following conditions:
• When the power supply cord or plug is
damaged or frayed.
• If liquid has been spilled onto the
product.
• If the product has been exposed to rain
or water.
• If the product does not operate normally
by following the operating instructions.
Adjust only those controls that are
covered by the operation instructions.
Improper adjustment of other controls
may result in damage and often requires
extensive work by an authorized
technician to restore the product to
normal operation.
• If the product has been dropped or
damaged.
• If the product exhibits a distinct change in
performance.
15. Avoid using the product during an electrical
storm. There is a remote risk of electric shock
from lightning.
16. The power adapter is intended to be
correctly oriented in a vertical or floor mount
position. The prongs are not designed to
hold the plug in place if it is plugged into a
ceiling, under-the-table or cabinet outlet.
17. For pluggable equipment, the socket-outlet
shall be installed near the equipment and
shall be easily accessible.
18. Periodically examine all components for
damage.
(including, but not limited to lost profits or
revenue, inability to use the Product or other
associated equipment, the cost of substitute
equipment, and claims by third parties)
resulting from the use of this Product. Some
states/provinces do not allow the exclusion
or limitation of incidental or consequential
damages, so the above limitation or exclusion
may not apply to you.
Please retain your original sales receipt as
proof of purchase.
Technical specifications
Frequency
control
Crystal controlled PLL
synthesizer
Transmit
frequency
1921.536-1928.448 MHz
Channels 5
Nominal
effective
range
Maximum power allowed by
FCC and IC. Actual operating
range may vary according to
environmental conditions at the
time of use.
Power
requirements
Battery:
3 x AA Alkaline battery
Power adapter:
6V DC @ 450mA
