VTech Telecommunications Ltd 1.9GHz DECT cordless Phone with Bluetooth (DECT Portion)
User Manual
1
DS6751/DS6751-2/DS6751-3
DECT 6.0 cordless telephone with
BLUETOOTH
®
wireless technology
Abridged user’s manual
Introduction
To protect our environment and conserve natural resources, this
Abridged user’s manual provides you with basic installation and use instructions.
A limited set of features are described in abbreviated form.
Before using this VTech product, please read Important safety instructions on
page 12 of this user’s manual.
ECO mode
This power conserving technology reduces power
consumption for optimal battery performance.
The ECO mode activates automatically whenever
the handset is synchronized with the telephone base.
The handset shows ECO when the ECO mode activates.
Parts checklist
Your package contains:
BC
Telephone base
Handset
(1 for DS6751)
(2 for DS6751-2)
(3 for DS6751-3)
Telephone line cord
Telephone base power adapter
Battery compartment cover
(1 for DS6751)
(2 for DS6751-2)
(3 for DS6751-3)
•
•
•
•
•
Battery
(1 for DS6751)
(2 for DS6751-2)
(3 for DS6751-3)
Charger with power adapter
(1 for DS6751-2)
(2 for DS6751-3)
Abridged user’s manual
Quick start guide
•
•
•
•
ECO
HANDSET 1
10:15 P M
12/18
ECO
2
Telephone base and handset charger installation
Install the telephone base and handset charger as shown below.
Even if you do not subscribe to any conventional telephone service, you can still
use the cell line alone without plugging in a telephone line cord.
If you subscribe to telephone service from a cable company or a VoIP service
provider, contact your cable/VoIP service provider for more information.
•
•
Handset battery installation and charging
Install the battery as shown below.
IMPORTANT:
Check for a dial tone by pressing /HOME. If you hear a dial tone, the installation
is successful.
If you do not hear a dial tone:
Make sure the installation procedures described above are properly done.
It may be a wiring problem. If you have changed your telephone service to digital service
from a cable company or a VoIP service provider, the telephone line may need to be
rewired to allow all existing telephone jacks to work. Contact your cable/VoIP service
provider for more information.
•
•
Charge for at least 30 minutes before initial settings.
Charge for 11 hours before initial use.
12
4
3
Click!
Plug!
Battery Pack / Bloc-piles :
(2.4V Ni-MH)
WARNING / AVERTISSEMENT :
DO NOT BURN OR PUNCTURE BATTERIES.
NE PAS INCINÉRER OU PERCER LES PILES.
Made in China / Fabriqué en chine
THIS SIDE UP / CE CÔTÉ VERS LE HAUT
Battery Pack / Bloc-piles :
(2.4V Ni-MH)
WARNING / AVERTISSEMENT :
DO NOT BURN OR PUNCTURE BATTERIES.
NE PAS INCINÉRER OU PERCER LES PILES.
Made in China / Fabriqué en chine
THIS SIDE UP / CE CÔTÉ VERS LE HAUT
Plug!
DSL lter
TEL. LINE
Use Only
Supplied Adapter
DC 6V
Click!
Click! Plug!
Plug!
Light on!
3
Telephone base wall mount installation
Install the telephone base on the wall as shown below.
1 2
3 4
5 6
Push to open!
TEL. LINE
Use Only
Supplied Adapter
DC 6V
Unplug! Unplug!
Flip down!
Plug!
Click!
Click!
4
Bluetooth
To use a Bluetooth enabled cell phone with your DS6751, you must rst pair and
connect your Bluetooth cell phone(s) with the telephone base. All DS6751 handsets
can be used to make or answer calls on the cell line.
Bluetooth wireless technology operates within a short range (a maximum of
approximately 30 feet). When you pair a Bluetooth cell phone to the telephone
base, make sure your Bluetooth cell phone is close to the telephone base to
maintain sufcient signal strength. For optimal performance, keep your cell phone
within 15 feet of the telephone base while using the cell line.
Pair and connect your rst Bluetooth cell phone
Press 1/ 2 on the telephone base. You hear two beeps. The telephone base
screen displays Pairing D1... and the 1 light blinks.
Turn on the Bluetooth feature of your cell phone. Once your cell phone nds your
VTech phone (VTech DS6751), press the appropriate key on your cell phone to
continue the pairing process.
Your cell phone may prompt you to enter the PIN of the telephone base. The
default PIN of the telephone base is 0000.
Download directory
Press MENU when the phone is not in use.
Scroll to Bluetooth, then press SELECT.
Scroll to Download dir, then press SELECT.
Scroll to select the desired cell phone, then press SELECT.
For Android and Blackberry cell phones, you may also download your cell phone
directory to your DS6751 via the VTech Contact Share application.
Using the handset menu
Press MENU when the phone is not in use.
Press or until the screen displays the desired
feature menu.
Press SELECT to enter that menu.
To return to the previous menu, press CANCEL.
To return to idle mode, press and hold CANCEL.
Telephone settings
Default settings are indicated by asterisks (*).
Settings menu Description Options
LCD language Set the screen display language. English*;
Français;
Español
Voicemail # Set the voicemail number for speed dialing. Voicemail #
_
Clr voicemail Turn off the voicemail indicators (see the
note below).
Reset VM Icon?
Key tone Turn an audible beep on or off whenever a
key is pressed.
Key tone:On*;
Key tone:Off
Home area code Set the home area code so that the
caller ID log stores only seven digits for
local telephone numbers.
Home area code
_ _ _
Dial mode Set the telephone to be touch-tone or
pulse dialing.
Touch-tone*;
Pulse
Use the Clr voicemail feature when the telephone indicates there is new voicemail but
there is none. For example, when you have accessed your voicemail while away from
home. The Clr voicemail feature only turns off the indicators; it does not delete your
voicemail messages. As long as you have new voicemail messages, your telephone
service provider continues to send the signal that turns on the indicators.
1.
2.
•
1.
2.
3.
4.
1.
2.
3.
•
•
5
The following are some of the telephone features you may wish to set. Refer to
Telephone settings in the online Complete user’s manual for detailed instructions
on setting all telephone features.
Set date and time
If you subscribe to caller ID service, the day, month and time are set automatically
with each incoming call. You can also set the date and time manually.
Press MENU when the telephone base/handset is not in use.
Scroll to Set date/time, then press SELECT.
Enter the month (MM), date (DD) and year (YY), then press SELECT.
Enter the hour (HH) and minute (MM). Then scroll to AM or PM.
Press SELECT.
Ringer volume
You can adjust the ringer volume level, or turn the ringer off.
Press MENU when the telephone base/handset is not in use.
Scroll to Ringers, then press SELECT.
Scroll to Home volume or Cell volume, then press SELECT.
Scroll to adjust the volume, then press SELECT.
If the ringer volume is set to Off, the handset still rings when you press
FIND HANDSET on the telephone base.
Quiet mode
You can turn on the quiet mode for a period of time. During this period, all tones
(except paging tone) and the call screening are muted. When you turn on the quiet
mode, the answering system turns on automatically.
Press and hold QUIET# when the telephone base/handset is not in use.
Enter the desired duration, then press SELECT.
To turn off the quiet mode, press and hold QUIET# when the telephone base/
handset is not in use.
Telephone operation
Make a home call with a handset:
Press /HOME or , and then dial the telephone number.
Make a home call at the telephone base:
Press /HOME, then dial the telephone number.
Make a cell call with a handset:
Press /CELL. Scroll to select the desired cell phone when
necessary, then press SELECT.
Enter the telephone number and then press /CELL to dial.
While using the cell line, place your cell phone closer to the
telephone base, and make sure that there are no physical
obstacles between the telephone base and the cell phone,
such as large furniture or thick walls.
Make a cell call at the telephone base:
Press /CELL. Scroll to select the desired cell phone when
necessary, then press SELECT.
Enter the telephone number and then press /CELL or
SELECT to dial.
Answer a home/cell call with a handset:
Press /HOME, /CELL, or any dialing key.
Answer a home/cell call at the telephone base:
Press /HOME, /CELL or any dialing key.
End a home/cell call with a handset:
Press OFF or return the handset to the telephone base or handset charger.
End a home/cell call at the telephone base:
For a home line call, press /HOME.
For a cell line call, press /CELL.
1.
2.
3.
4.
5.
1.
2.
3.
4.
1.
2.
•
•
•
1.
2.
1.
2.
•
•
•
•
•
6
Handset speakerphone:
During a call, press to switch between the speakerphone and handset earpiece.
Volume
To adjust the listening volume on a handset:
During a call, press /VOLUME or /VOLUME.
To adjust the listening volume at the telephone base:
During a call, press VOL or VOL .
The handset earpiece volume setting and speakerphone volume setting
are independent.
Mute
The mute function allows you to hear the other party but the other party cannot hear you.
To mute a call on a handset, press MUTE. The handset displays Muted. Press
MUTE again to resume the conversation.
To mute a call at the telephone base, press MUTE. The telephone base
displays Muted and the MUTE light turns on. Press MUTE again to resume the
conversation.
Call waiting
When you subscribe to call waiting service from your telephone service provider, you
hear an alert tone if there is an incoming call while you are already on another call.
Call waiting on the home line:
Press FLASH to put the current call on hold and take the new call.
Press FLASH at any time to switch back and forth between calls.
Call waiting on the cell line:
Press /CELL on the handset or FLASH on the telephone base to put the
current call on hold and take the new call.
Press /CELL on the handset or FLASH on the telephone base at any time to
switch back and forth between calls.
Temporary ringer silencing
When the telephone is ringing, you can temporarily silence the telephone base/
handset ringer without disconnecting the call. The next call rings normally at the
preset volume.
To silence the handset ringer, press OFF or MUTE on the handset. displays
and Ringer muted displays briey.
To silence the telephone base ringer, press MUTE, CANCEL or /VOL on the
telephone base. displays and Ringer muted displays briey.
Temporary tone dialing
If you have pulse (rotary) service only, you can switch from pulse to tone dialing
temporarily during a call.
During a call, press TONE .
Use the dialing keys to enter the relevant number. The telephone sends
touch-tone signals. It automatically returns to pulse dialing mode after you
end the call.
Find handset
Use this feature to nd all system handsets.
To start paging:
Press FIND HANDSET at the right side of the telephone base
and it displays ** Paging **. All idle handsets ring and display
** Paging **.
To end paging:
Press /HOME, /CELL, , OFF or any dialing key on
a handset.
-OR-
Return the handset to the telephone base or handset charger.
-OR-
Press FIND HANDSET on the telephone base.
Do not press and hold FIND HANDSET for more than four seconds. It may lead to
handset deregistration.
•
•
•
•
•
•
•
•
•
•
•
1.
2.
•
•
•
•
7
Redial list
Each handset and the telephone base store the last 10 telephone numbers dialed.
When there are already 10 entries, the oldest entry is deleted to make room for the
new entry.
To review and dial a number from the redial list:
Press REDIAL when the telephone base/handset is not in use.
Press , , oror REDIAL repeatedly until the desired entry displays.
Press /HOME or /CELL to dial.
To delete a redial entry:
When the desired redial entry displays, press DELETE.
Join a call in progress
You can use the telephone base and a handset, or two handsets at a time on
a home line call. You can buy additional expansion handsets (DS6701) for this
telephone base. You can register up to ve handsets to the telephone base.
When a device is on a home line call, press /HOME or on another handset,
or press /HOME on the telephone base.
To exit the call, press OFF on the handset, return it to the telephone base or
handset charger, or press /HOME on the telephone base. The call continues
until all devices hang up.
Transfer a call
While on an outside call, you can transfer the call from one system device to another.
Using a handset:
During a call, press MENU.
Scroll to Transfer, then press SELECT. When you have more than one handset,
enter a destination device number (7 for the telephone base, or 1 to 5 for
HANDSET 1 to HANDSET 5).
To answer the call on the telephone base or a handset, press /HOME,
/CELL, or any dialing key.
Using the telephone base:
During a call, press MENU.
When you have only one handset, the screen displays Transfer call?
Press SELECT.
-OR-
When you have more than one handset, enter a destination handset number
(1 to 5 for HANDSET 1 to HANDSET 5).
To answer the call on a handset, press /HOME, /CELL or any dialing key.
Intercom
Use the intercom feature for conversations between the telephone base and a
handset, or two handsets.
Press MENU on the telephone base/handset when not in use.
Scroll to Intercom, then press SELECT. When you have more than one
handset, enter a destination device number (7 for the telephone base, or 1 to 5
for HANDSET 1 to HANDSET 5).
To answer the intercom call with the destination handset, press /HOME,
/CELL, or any dialing key.
-OR-
To answer the intercom call with the telephone base, press /HOME, /CELL
or any dialing key.
To end the intercom call while using a handset, press OFF or return the handset
to the telephone base or handset charger.
-OR-
To end the intercom call while using the telephone base, press /HOME.
Answer an incoming call during an intercom call
If you receive an outside call during an intercom call, there is an alert tone.
Using a handset:
To answer a home call, press /HOME. The intercom call ends automatically.
To answer a cell call, press OFF to end the intercom call. The telephone
continues to ring. Then press /CELL.
To end the intercom call without answering the outside call, press OFF. The
intercom call ends and the telephone continues to ring.
Using the telephone base:
To answer a home call, press /HOME to end the intercom call. The telephone
continues to ring. Then press /HOME.
To answer a cell call, press /HOME to end the intercom call. The telephone
continues to ring. Then press /CELL.
To end the intercom call without answering the outside call, press /HOME.
The intercom call ends and the telephone continues to ring.
1.
2.
3.
•
•
•
1.
2.
3.
1.
2.
3.
1.
2.
3.
4.
•
•
•
•
•
•
8
Directory
The directory can store up to 200 entries which are shared by the telephone base
and all system handsets.
To add a directory entry:
Press MENU when the phone is not in use.
Scroll to Directory, then press SELECT.
Scroll to Add contact, then press SELECT.
Enter the number (up to 30 digits).
-OR-
Copy a number from the redial list by pressing REDIAL and then press , or
REDIAL repeatedly to select a number. Press SELECT.
Press SELECT to move to the name.
Enter the name (up to 15 characters). Additional key presses show other
characters of that particular key.
Press SELECT to save.
While entering names and numbers, you can:
Press DELETE to backspace and erase a digit or character.
Press and hold DELETE to erase the entire entry.
Press and hold PAUSE to insert a dialing pause (for entering phone numbers only).
Press or to move the cursor to the left or right.
Press 0 to add a space (for entering names only).
To review and dial from the directory:
Entries are sorted alphabetically.
Press when the phone is not in use.
Scroll to browse through the directory, or use the dialing keys to start a
name search.
To dial the displayed entry with the handset, press /HOME, /CELL, or .
-OR-
To dial the displayed entry with the telephone base, press /HOME
or /CELL.
To edit a directory entry:
When the desired entry displays, press SELECT.
Use the dialing keys to edit the number, then press SELECT.
Use the dialing keys to edit the name, then press SELECT.
To delete a directory entry:
When the desired entry displays, press DELETE.
When the screen displays Delete contact?, press SELECT.
To delete all directory entries:
Press MENU when the phone is not in use.
Scroll to Directory, then press SELECT.
Scroll to Del all conts, press SELECT.
When the screen displays Delete all?, press SELECT.
Speed dial
You can copy up to nine directory entries into the speed dial locations (0 and 2-9)
so that you can dial these numbers via the home line more quickly.
To assign a speed dial entry:
Press MENU when the phone is not in use.
Scroll to Directory, then press SELECT.
Scroll to Speed dial, then press SELECT.
Scroll to a desired speed dial location, then press SELECT.
Scroll to a desired directory entry, then press SELECT.
To dial a speed dial entry:
Press and hold a dialing key (0 or 2-9) to dial the number stored in the
corresponding location.
To delete a speed dial entry:
Press MENU when the phone is not in use.
Scroll to Directory, then press SELECT.
Scroll to Speed dial, then press SELECT.
Scroll to a desired speed dial location, then press DELETE. The screen displays
Clear SD #X? Press SELECT.
1.
2.
3.
4.
5.
6.
7.
•
•
•
•
•
1.
2.
3.
1.
2.
3.
1.
2.
1.
2.
3.
4.
1.
2.
3.
4.
5.
•
1.
2.
3.
4.
9
Caller ID
This product supports caller ID services provided by most telephone service
providers. Depending on your service subscription, you may see the caller’s name,
number, date and time of calls that are sent by your telephone service provider after
the rst or second ring.
Caller ID log
The caller ID log stores up to 50 entries. If you answer a call before the caller
information appears, it will not be saved in the caller ID log.
The telephone base and handset display XX missed calls when there are calls
that have not been reviewed in the caller ID log.
If you want to erase the missed call indicator, press and hold CANCEL when the
telephone base/handset is not in use.
To review and dial a number in the caller ID log:
Press CID when the phone is not in use.
Scroll to browse through the caller ID log. When the desired entry appears:
Press QUIET# repeatedly to show different dialing options.
Press 1 repeatedly if you need to add or remove 1 in front of the phone number.
To dial the displayed number with a handset, press /HOME, /CELL or .
-OR-
To dial the displayed number with the telephone base, press /HOME
or /CELL.
To save a caller ID log entry to the directory:
When the desired caller ID log entry displays, press SELECT.
Use the dialing keys to modify the number, then press SELECT.
Use the dialing keys to modify the name, then press SELECT to save.
To delete one caller ID log entry:
When the desired caller ID log entry displays, press DELETE.
To delete all caller ID log entries:
Press MENU when the phone is not in use.
Scroll to Caller ID log, then press SELECT.
Scroll to Del all calls, then press SELECT twice.
About answering system and voicemail
Your telephone has separate indicators for two different types of voice messages:
those left on its built-in answering system and those left at your telephone service
provider’s voicemail. Each alerts you to new messages differently.
If /PLAY/STOP on the telephone base ashes, and XX new messages
displays on the handsets and telephone base, there are new messages in the
built-in answering system. It can record up to 99 messages, depending on the
length of each message. Each message can be up to three minutes in length.
The total recording time is approximately 14 minutes.
If and New voicemail display on the handsets and the telephone base, your
telephone service provider is indicating that it has new voicemail for you.
Contact your telephone service provider for more information on how to access
your voicemail.
Answering system settings
Default settings are indicated by asterisks (*).
Settings menu Description Options
Call screening Set whether you hear the callers while they are
leaving messages to you.
Screening: On*;
Screening: Off
# of rings Set the number of times the telephone rings
before the answering system answers.
6; 5; 4; 3*; 2;
Toll saver
Remote code Set a two-digit security code to access the
answering system remotely from any touch-tone
telephone.
19*
Msg alert tone Set to alert you when you have new messages. Tone: Off*;
Tone: On
Recording time Set the recording time for each incoming
message.
3 minutes*;
2 minutes;
1 minute
•
•
1.
2.
•
•
3.
1.
2.
3.
•
1.
2.
3.
•
•
10
Set number of rings
You can set the answering system to answer an incoming call after two, three,
four, five or six rings; or toll saver. If you choose toll saver, the answering system
answers a call after two rings when you have new messages, or after four rings
when you have no new messages.
Press MENU when the phone is not in use.
Scroll to Answering sys, then press SELECT.
Scroll to Ans sys setup, then press SELECT.
Scroll to # of rings, then press SELECT.
Scroll to 6, 5, 4, 3, 2 or Toll saver and then press SELECT.
Record your own announcement
You can use the preset announcement to answer calls, or replace it with your own
recorded announcement. The announcement can be up to 90 seconds in length.
Press MENU when the phone is not in use.
Scroll to Answering sys, then press SELECT twice.
The system announces, “To play, press 2. To record, press 7.” Then press 7
to record.
The system announces, “Record after the tone. Press 5 when you are done.”
After the tone, speak towards the microphone.
Press 5 when done.
Answering system operation
Turn the answering system on or off
The answering system must be turned on to answer and record messages.
Press /ANS ON/OFF on the telephone base to turn the built-in answering
system on or off.
Message playback at the telephone base
Press /PLAY when the telephone base is not in use.
Options during playback:
Press VOL or VOL to adjust the speaker volume.
Press /SKIP to skip to the next message.
Press /REPEAT to repeat the message currently playing. Press /REPEAT
twice to listen to the previous message.
Press X/DELETE to delete the playing message. The system advances to the
next message.
Press /STOP to stop.
Call intercept
If you want to talk to the person whose message is being recorded:
On a handset, press /HOME or .
-OR-
On the telephone base, press /HOME.
Add and register a handset
The handsets provided with your telephone system are already registered.
Each handset is assigned a number that displays on the handset. Additional
handsets registered to the telephone system are assigned numbers in the
sequential order. This telephone system accommodates up to ve handsets.
You can add new handsets (DS6701, purchased separately) to your telephone
system. Each handset must be registered with the telephone base before use.
When rst purchased and properly charged, each expansion handset displays
To register HS... and ...see manual alternately. Charge the handset before
registering it to the telephone base.
To register a handset:
Place the new/non-registered handset in the telephone base.
The handset shows Registering... Then both the telephone base and handset
show Registered and you hear a beep when the registration process completes.
The registration process takes about 60 seconds to complete.
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
•
•
•
•
•
•
•
•
•
1.
2.
Do not place the handset in the charger.
11
Deregister handsets
If you want to replace a handset or reassign the designated handset number of a
registered handset, you must deregister all handsets and then individually register
each handset.
To deregister all handsets:
Press and hold FIND HANDSET on the telephone base for about 10 seconds
until the telephone base shows Registering... then De-register?
Immediately press and release MENU/SELECT or FIND HANDSET. The
telephone base displays Please wait.
All handsets show To register HS... and ...see manual alternately when the
deregistration process completes. The deregistration process takes about
10 seconds to complete.
Troubleshooting
If you have difculty with your telephone, please try the suggestions below.
I cannot add and connect my cell phone to the telephone base.
Make sure you have cellular coverage.
Make sure your cell phone is compatible with your DS6751.
Make sure the Bluetooth function of your cell phone is turned on. See the user’s manual of
your cell phone for more information.
Make sure that your Bluetooth cell phone is not connected to any other Bluetooth device.
To connect your cell phone, make sure that your cell phone is connected and active on the
device list.
Remove VTech DS6751 from your cell phone’s handsfree device history list (see the
user’s manual of your cell phone for more information).
Carefully follow the pairing instructions on page 4 and make sure that your cell phone is not
connected to any other Bluetooth device.
Turn off your cell phone, then turn it on again.
For some cell phones, you must authorize VTech DS6751 device in your cell phone’s
Bluetooth feature. See the user’s manual of your cell phone for more information.
Manually connect your cell phone to VTech DS6751. Refer to the user’s manual of your
cell phone for more information.
Reset the telephone base. Unplug the unit’s electrical power. Wait for approximately
15 seconds, then plug it back in. Repeat the above suggestions.
The PIN on the telephone base does not work.
Make sure you enter the correct PIN. The default PIN is 0000.
Can the DS6751 help the poor cell phone reception in my house?
If your cell phone has poor reception in your home, the DS6751 cannot improve the
reception. However, if there is a location in your house with better reception, you can leave
your cell phone at that location while you use the DS6751 cell line. In order for this to work,
the telephone base must be within 30 feet of the cell phone.
My telephone does not work at all.
Make sure the battery is installed and charged correctly. For optimum daily performance,
return the handset to the charger after use.
Make sure the power adapter is securely plugged into an outlet not controlled by a wall switch.
Make sure the telephone line cord is plugged rmly into the telephone base and the wall jack.
Unplug the electrical power to the telephone base. Wait for approximately 15 seconds, then plug it
back in. Allow up to one minute for the cordless handset and telephone base to synchronize.
Charge the battery in the cordless handset for at least 11 hours. For optimum daily
performance, return the cordless handset to the handset charger after use.
If the battery is completely depleted, charge the cordless handset for at least 30 minutes
before use.
Remove and install the battery again. If that still does not work, it may be necessary to
purchase a new battery.
Disconnect the telephone base from the telephone wall jack and plug in a working
telephone. If the other telephone does not work, the problem is probably in the wiring or
telephone service. Contact your telephone service provider.
I have accidentally set my handset/telephone base LCD language to Spanish or French,
and I don’t know how to change it back to English.
While the handset/telephone base is not in use, press MENU, then enter 364#.
While the handset is on a call, press MENU, then enter 364#. The call ends.
The answering system does not record messages.
Make sure the answering system is on.
Make sure the memory of the answering system is not full. When the answering machine
memory is full, it does not record new messages until some old messages are deleted.
If you subscribe to voicemail service, change the number of ring so that your answering
system answers before your voicemail answers. To determine how many rings activate
your voicemail, contact your telephone service provider.
If there is a fax machine connected to the same telephone line, try disconnecting the
fax machine. If that solves the problem, consult your fax machine documentation for
information on compatibility with answering systems.
1.
2.
3.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
12
Common cure for electronic equipment.
If the telephone is not responding normally, put the cordless handset in the handset charger.
If this does not x the problem, do the following (in the order listed):
Disconnect the power to the telephone base.
Disconnect the battery on the cordless handset.
Wait a few minutes before connecting power to the telephone base.
Install the battery again and place the cordless handset in the handset charger.
Wait for the cordless handset to synchronize with the telephone base. Allow up to one
minute for this to take place.
Important safety instructions
When using your telephone equipment, basic safety precautions should always be followed to reduce the risk
of re, electric shock and injury, including the following:
Read and understand all instructions.
Follow all warnings and instructions marked on the product.
Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a
damp cloth for cleaning.
Do not use this product near water such as near a bath tub, wash bowl, kitchen sink, laundry tub or
swimming pool, or in a wet basement or shower.
Do not place this product on an unstable table, shelf, stand or other unstable surfaces.
Slots and openings in the back or bottom of the telephone base and handset are provided for ventilation.
To protect them from overheating, these openings must not be blocked by placing the product on a soft
surface such as a bed, sofa or rug. This product should never be placed near or over a radiator or heat
register. This product should not be placed in any area where proper ventilation is not provided.
This product should be operated only from the type of power source indicated on the marking label. If you
are not sure of the type of power supply in your home or ofce, consult your dealer or local power company.
Do not allow anything to rest on the power cord. Do not install this product where the cord may be walked on.
Never push objects of any kind into this product through the slots in the telephone base or handset because
they may touch dangerous voltage points or create a short circuit. Never spill liquid of any kind on the product.
To reduce the risk of electric shock, do not disassemble this product, but take it to an authorized service
facility. Opening or removing parts of the telephone base or handset other than specied access doors
may expose you to dangerous voltages or other risks. Incorrect reassembling can cause electric shock
when the product is subsequently used.
Do not overload wall outlets and extension cords.
Unplug this product from the wall outlet and refer servicing to an authorized service facility under the
following conditions:
When the power supply cord or plug is damaged or frayed.
If liquid has been spilled onto the product.
If the product has been exposed to rain or water.
If the product does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operation instructions. Improper adjustment of other controls may
result in damage and often requires extensive work by an authorized technician to restore the product
to normal operation.
If the product has been dropped and the telephone base and/or handset has been damaged.
If the product exhibits a distinct change in performance.
Avoid using a telephone (other than cordless) during an electrical storm. There is a remote risk of electric
shock from lightning.
Do not use the telephone to report a gas leak in the vicinity of the leak. Under certain circumstances, a
spark may be created when the adapter is plugged into the power outlet, or when the handset is replaced
in its cradle. This is a common event associated with the closing of any electrical circuit. The user should
not plug the phone into a power outlet, and should not put a charged handset into the cradle, if the
phone is located in an environment containing concentrations of ammable or ame-supporting gases,
unless there is adequate ventilation. A spark in such an environment could create a re or explosion.
Such environments might include: medical use of oxygen without adequate ventilation; industrial gases
(cleaning solvents; gasoline vapors; etc.); a leak of natural gas; etc.
Only put the handset of your telephone next to your ear when it is in normal talk mode.
The power adapters are intended to be correctly oriented in a vertical or oor mount position. The prongs
are not designed to hold the plug in place if it is plugged into a ceiling, under-the-table or cabinet outlet.
SAVE THESE INSTRUCTIONS
Precautions for users of implanted cardiac pacemakers
Cardiac pacemakers (applies only to digital cordless telephones):
Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation
of the interference between portable wireless telephones and implanted cardiac pacemakers. Supported by
the U.S. Food and Drug Administration, WTR recommends to physicians that:
Pacemaker patients
Should keep wireless telephones at least six inches from the pacemaker.
Should NOT place wireless telephones directly over the pacemaker, such as in a breast pocket, when it is
turned ON.
Should use the wireless telephone at the ear opposite the pacemaker. WTR’s evaluation did not identify
any risk to bystanders with pacemakers from other persons using wireless telephones.
Operating range
This cordless telephone operates with the maximum power allowed by the Federal Communications Commission
(FCC). Even so, this handset and telephone base can communicate over only a certain distance - which can vary
with the locations of the telephone base and handset, the weather, and the layout of your home or ofce.
When the handset is out of range, the handset displays Out of range or no pwr at base.
If there is a call while the handset is out of range, it may not ring, or if it does ring, the call may not connect
well when you press /HOME. Move closer to the telephone base, then press /HOME to answer the call.
If the handset moves out of range during a telephone conversation, there may be interference. To improve
reception, move closer to the telephone base.
•
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
•
•
•
•
•
•
13.
14.
15.
16.
•
•
•
13
Energy-saving charging mode
When this mode is activated, all telephone functions, except handset battery charging, will be disabled.
To activate the energy-saving charging mode:
1. Unplug the telephone base power adapter from the power outlet. Make sure all handsets are plugged with
charged batteries before proceeding.
2. While you press and hold FIND HANDSET, plug the telephone base power adapter back to the
power outlet.
3. After about 20 seconds, when the telephone base shows De-register?, release FIND HANDSET and then
press FIND HANDSET again or MENU/SELECT within 2 seconds.
When the phone successfully enters the energy-saving charging mode, all handsets display
To register HS... and ...see manual alternately.
When the phone fails to enter this mode, repeat Step 1 through Step 3 above.
Note: The telephone base will be powered up as normal if you fail to press FIND HANDSET or MENU/SELECT within
2 seconds in Step 3.
To deactivate the energy-saving charging mode:
1. Unplug the telephone base power adapter from the power outlet, then plug it back in. Then the telephone
base is powered up as normal.
2. Register your handsets back to the telephone base. See page 10 for handset registration instructions.
Maintenance
Taking care of your telephone
Your cordless telephone contains sophisticated electronic parts, so it must be treated with care.
Avoid rough treatment
Place the handset down gently. Save the original packing materials to protect your telephone if you ever need
to ship it.
Avoid water
Your telephone can be damaged if it gets wet. Do not use the handset outdoors in the rain, or handle it with
wet hands. Do not install the telephone base near a sink, bathtub or shower.
Electrical storms
Electrical storms can sometimes cause power surges harmful to electronic equipment. For your own safety,
take caution when using electrical appliances during storms.
Cleaning your telephone
Your telephone has a durable plastic casing that should retain its luster for many years. Clean it only with a soft
cloth slightly dampened with water or mild soap. Do not use excess water or cleaning solvents of any kind.
About cordless telephones
Privacy: The same features that make a cordless telephone convenient create some limitations.
Telephone calls are transmitted between the telephone base and the cordless handset by radio waves,
so there is a possibility that the cordless telephone conversations could be intercepted by radio receiving
equipment within range of the cordless handset. For this reason, you should not think of cordless
telephone conversations as being as private as those on corded telephones.
Electrical power: The telephone base of this cordless telephone must be connected to a working electrical
outlet. The electrical outlet should not be controlled by a wall switch. Calls cannot be made from the cordless
handset if the telephone base is unplugged, switched off or if the electrical power is interrupted.
Potential TV interference: Some cordless telephones operate at frequencies that may cause interference
to televisions and VCRs. To minimize or prevent such interference, do not place the telephone base of
the cordless telephone near or on top of a TV or VCR. If interference is experienced, moving the cordless
telephone farther away from the TV or VCR often reduces or eliminates the interference.
Rechargeable batteries: Exercise care in handling batteries in order not to create a short circuit with
conducting material such as rings, bracelets and keys. The battery or conductor may overheat and cause
harm. Observe proper polarity between the battery and the battery charger.
Nickel-metal hydride rechargeable batteries: Dispose of these batteries in a safe manner. Do not burn
or puncture the battery. Like other batteries of this type, if burned or punctured, they could release caustic
material which could cause injury.
The RBRC® seal
The RBRC® seal on the nickel-metal hydride battery indicates that VTech Communications, Inc. is voluntarily
participating in an industry program to collect and recycle these batteries at the end of their useful lives, when
taken out of service within the United States and Canada.
The RBRC® program provides a convenient alternative to placing used nickel-metal hydride batteries into the
trash or municipal waste, which may be illegal in your area.
VTech’s participation in RBRC® makes it easy for you to drop off the spent battery at local retailers
participating in the RBRC® program or at authorized VTech product service centers. Please call
1 (800) 8 BATTERYTM for information on Ni-MH battery recycling and disposal bans/restrictions
in your area. VTech’s involvement in this program is part of its commitment to protecting our
environment and conserving natural resources.
RBRC® is a registered trademark of Rechargeable Battery Recycling Corporation.
•
•
•
•
•
Remember that electrical appliances can cause serious injury if used when you are wet or standing in
water. If the telephone base should fall into water, DO NOT RETRIEVE IT UNTIL YOU UNPLUG THE
POWER CORD AND TELEPHONE LINE CORD FROM THE WALL. Then remove the telephone by the
unplugged cords.
14
Limited warranty
What does this limited warranty cover?
The manufacturer of this VTech Product warrants to the holder of a valid proof of purchase (“Consumer” or
“you”) that the Product and all accessories provided in the sales package (“Product”) are free from defects in
material and workmanship, pursuant to the following terms and conditions, when installed and used normally
and in accordance with the Product operating instructions. This limited warranty extends only to the Consumer
for Products purchased and used in the United States of America and Canada.
What will VTech do if the Product is not free from defects in materials and workmanship during the
limited warranty period (“Materially Defective Product”)?
During the limited warranty period, VTech’s authorized service representative will repair or replace at
VTech’s option, without charge, a Materially Defective Product. If we repair the Product, we may use new
or refurbished replacement parts. If we choose to replace the Product, we may replace it with a new or
refurbished Product of the same or similar design. We will retain defective parts, modules, or equipment.
Repair or replacement of the Product, at VTech’s option, is your exclusive remedy. VTech will return the
repaired or replacement Products to you in working condition. You should expect the repair or replacement
to take approximately 30 days.
How long is the limited warranty period?
The limited warranty period for the Product extends for ONE (1) YEAR from the date of purchase. If VTech repairs
or replaces a Materially Defective Product under the terms of this limited warranty, this limited warranty also applies
to the repaired or replacement Product for a period of either (a) 90 days from the date the repaired or replacement
Product is shipped to you or (b) the time remaining on the original one-year warranty; whichever is longer.
What is not covered by this limited warranty?
This limited warranty does not cover:
Product that has been subjected to misuse, accident, shipping or other physical damage, improper
installation, abnormal operation or handling, neglect, inundation, re, water or other liquid intrusion; or
Product that has been damaged due to repair, alteration or modication by anyone other than an
authorized service representative of VTech; or
Product to the extent that the problem experienced is caused by signal conditions, network reliability, or
cable or antenna systems; or
Product to the extent that the problem is caused by use with non-VTech accessories; or
Product whose warranty/quality stickers, product serial number plates or electronic serial numbers have
been removed, altered or rendered illegible; or
Product purchased, used, serviced, or shipped for repair from outside the United States of America or
Canada, or used for commercial or institutional purposes (including but not limited to Products used for
rental purposes); or
Product returned without a valid proof of purchase (see item 2 below); or
Charges for installation or set up, adjustment of customer controls, and installation or repair of systems
outside the unit.
How do you get warranty service?
Except as provided by applicable law, you assume the risk of loss or damage during transit and transportation and are
responsible for delivery or handling charges incurred in the transport of the Product(s) to the service location. VTech
will return repaired or replaced Product under this limited warranty. Transportation, delivery or handling charges are
prepaid. VTech assumes no risk for damage or loss of the Product in transit. If the Product failure is not covered by
this limited warranty, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and
will request that you authorize the cost of repair prior to any further repair activity. You must pay for the cost of repair
and return shipping costs for the repair of Products that are not covered by this limited warranty.
What must you return with the Product to get warranty service?
Return the entire original package and contents including the Product to the VTech service location along
with a description of the malfunction or difculty; and
Include a “valid proof of purchase” (sales receipt) identifying the Product purchased (Product model) and
the date of purchase or receipt; and
Provide your name, complete and correct mailing address, and telephone number.
Other limitations
This warranty is the complete and exclusive agreement between you and VTech. It supersedes all other written
or oral communications related to this Product. VTech provides no other warranties for this Product. The warranty
exclusively describes all of VTech’s responsibilities regarding the Product. There are no other express warranties.
No one is authorized to make modications to this limited warranty and you should not rely on any such modication.
State/Provincial Law Rights: This warranty gives you specic legal rights, and you may also have other rights,
which vary from state to state or province to province.
Limitations: Implied warranties, including those of tness for a particular purpose and merchantability (an
unwritten warranty that the Product is t for ordinary use) are limited to one year from the date of purchase.
Some states/provinces do not allow limitations on how long an implied warranty lasts, so the above limitation
may not apply to you. In no event shall VTech be liable for any indirect, special, incidental, consequential,
or similar damages (including, but not limited to lost prots or revenue, inability to use the Product or other
associated equipment, the cost of substitute equipment, and claims by third parties) resulting from the use
of this Product. Some states/provinces do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.
Please retain your original sales receipt as proof of purchase.
1.
2.
3.
4.
5.
6.
7.
8.
1.
2.
3.
15
FCC, ACTA and IC regulations
FCC Part 15
This equipment has been tested and found to comply with the requirements for a Class B digital device under
Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide
reasonable protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modications to this equipment not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Privacy of communications may not be ensured
when using this telephone.
To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can
be safely absorbed by a user or bystander according to the intended usage of the product. This product has
been tested and found to comply with the FCC criteria. The handset may be safely held against the ear of the
user. The telephone base shall be installed and used such that parts of the user’s body other than the hands
are maintained at a distance of approximately 20 cm (8 inches) or more.
This Class B digital apparatus complies with Canadian requirement:
CAN ICES-3 (B)/NMB-3(B)
FCC Part 68 and ACTA
This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the
Administrative Council for Terminal Attachments (ACTA). The label on the back or bottom of this equipment
contains, among other things, a product identier in the format US:AAAEQ##TXXXX. This identier must be
provided to your telephone service provider upon request.
The plug and jack used to connect this equipment to premises wiring and the telephone network must comply
with applicable Part 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and
modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is
also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two
lines. See the installation instructions in the user’s manual.
The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to your
telephone line and still have them ring when you are called. The REN for this product is encoded as the 6th
and 7th characters following the US: in the product identier (e.g., if ## is 03, the REN is 0.3). In most, but
not all areas, the sum of all RENs should be ve (5.0) or less. For more information, please contact your
telephone service provider.
This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment
connected to your telephone line, ensure the connection of this equipment does not disable your alarm
equipment. If you have questions about what will disable alarm equipment, consult your telephone service
provider or a qualied installer.
If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been
corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized
agents. For repair procedures, follow the instructions outlined under the Limited warranty.
If this equipment is causing harm to the telephone network, the telephone service provider may temporarily
discontinue your telephone service. The telephone service provider is required to notify you before
interrupting service. If advance notice is not practical, you will be notied as soon as possible. You will be
given the opportunity to correct the problem and the telephone service provider is required to inform you of
your right to le a complaint with the FCC. Your telephone service provider may make changes in its facilities,
equipment, operation, or procedures that could affect the proper functioning of this product. The telephone
service provider is required to notify you if such changes are planned.
If this product is equipped with a corded or cordless handset, it is hearing aid compatible.
If this product has memory dialing locations, you may choose to store emergency telephone numbers
(e.g., police, re, medical) in these locations. If you do store or test emergency numbers, please:
Remain on the line and briey explain the reason for the call before hanging up.
Perform such activities in off-peak hours, such as early morning or late evening.
Industry Canada
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference, including interference that may cause undesired operation.
The term ‘’IC:‘’ before the certication/registration number only signies that the Industry Canada technical
specications were met.
The Ringer Equivalence Number (REN) for this terminal equipment is 1.0. The REN is an indication of
the maximum number of devices allowed to be connected to a telephone interface. The termination on an
interface may consist of any combination of devices subject only to the requirement that the sum of the RENs
of all the devices does not exceed ve.
This product meets the applicable Industry Canada technical specications.
•
•
•
•
16
The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such
marks by VTech Holdings Limited is under license. VTech Holdings Limited is a member of
Bluetooth SIG, Inc. Other trademarks and trade names are those of their respective owners.
VTECH TELECOMMUNICATIONS LTD.
A member of THE VTECH GROUP OF COMPANIES.
Distributed in the U.S.A. by VTech Communications, Inc., Beaverton, Oregon 97008.
Distributed in Canada by VTech Technologies Canada Ltd., Richmond, B.C. V6W 1L5.
VTech is the registered trademark of VTech Holdings Limited.
Copyright © 2013 for VTECH TELECOMMUNICATIONS LTD.
All rights reserved. Printed in China.
Technical specications
Frequency control Crystal controlled PLL synthesizer
Transmit frequency DECT frequency: 1921.536-1928.448 MHz
Bluetooth frequency: 2402.000-2480.000 MHz
Channels DECT channel: 5
Bluetooth channel: 79
Nominal effective
range
Maximum power allowed by FCC and IC. Actual operating range may vary
according to environmental conditions at the time of use.
Power requirements Handset: 2.4V Ni-MH battery
Telephone base: 6V DC @ 400mA
Charger: 6V AC @ 300mA
Memory Directory: 200 memory locations; up to 30 digits and 15 characters
Caller ID log: 50 memory locations; up to 24 digits and 15 characters
The ENERGY STAR® program (www.energystar.gov) recognizes and encourages the
use of products that save energy and help protect our environment. We are proud to
mark this product with the ENERGY STAR® label indicating it meets the latest energy
efciency guidelines.
Telephones identied with this logo have reduced noise and interference when
used with most T-coil equipped hearing aids and cochlear implants. The TIA-1083
Compliant Logo is a trademark of the Telecommunications Industry Association.
Used under license.
T
Compatible with
Hearing Aid T-Coil
TIA-1083
