User Manual
$POHSBUVMBUJPOT
on purchasing your new VTech product.
Before using this product, please read
*NQPSUBOUTBGFUZJOTUSVDUJPOT.
This user’s manual provides you with installation
and use instructions. Please read this manual
thoroughly to ensure proper installation and
operation of this VTech product.
For support, shopping, and everything new at
VTech, visit our website at
XXXWUFDIQIPOFTDPN.
*NQPSUBOUTBGFUZJOTUSVDUJPOT
When using your telephone equipment, basic
safety precautions should always be followed to
reduce the risk of fire, electric shock and injury,
including the following:
Read and understand all instructions.
Follow all warnings and instructions marked
on the product.
Unplug this product from the wall outlet
before cleaning. Do not use liquid or aerosol
cleaners. Use a dry non-abrasive cloth for
cleaning.
Do not use this product near water such as
near a bath tub, wash bowl, kitchen sink,
laundry tub or a swimming pool, or in a wet
basement or shower.
Do not place this product on an unstable
table, shelf, stand or other unstable surfaces.
Slots and openings in the back or bottom
of the telephone base and handset are
provided for ventilation. To protect them
from overheating, these openings must not
be blocked by placing the product on a soft
surface such as a bed, sofa or rug. This
product should never be placed near or
over a radiator or heat register. This product
should not be placed in any area where
proper ventilation is not provided.
This product should be operated only from
the type of power source indicated on the
marking label. If you are not sure of the
type of power supply in your home or office,
consult your dealer or local power company.
Do not allow anything to rest on the power
cord. Do not install this product where the
cord may be walked on.
Never push objects of any kind into this product
through the slots in the telephone base or
handset because they may touch dangerous
voltage points or create a short circuit. Never
spill liquid of any kind on the product.
To reduce the risk of electric shock, do
not disassemble this product, but take it to
an authorized service facility. Opening or
removing parts of the telephone base or
handset other than specified access doors
may expose you to dangerous voltages
or other risks. Incorrect reassembling can
cause electric shock when the product is
subsequently used.
Do not overload wall outlets and extension
cords.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Unplug this product from the wall outlet
and refer servicing to an authorized service
facility under the following conditions:
When the power supply cord or plug is
damaged or frayed.
If liquid has been spilled onto the product.
If the product has been exposed to rain or
water.
If the product does not operate normally
by following the operating instructions.
Adjust only those controls that are covered
by the operation instructions. Improper
adjustment of other controls may result in
damage and often requires extensive work
by an authorized technician to restore the
product to normal operation.
If the product has been dropped and the
telephone base and/or handset has been
damaged.
If the product exhibits a distinct change in
performance.
Avoid using a telephone (other than cordless)
during an electrical storm. There is a remote
risk of electric shock from lightning.
Do not use the telephone to report a gas
leak in the vicinity of the leak. Under certain
circumstances, a spark may be created
when the adapter is plugged into the wall
outlet, or when the handset is replaced in its
cradle. This is a common event associated
with the closing of any electrical circuit. The
user should not plug the phone into a wall
outlet, and should not put a charged handset
into the cradle, if the phone is located in
an environment containing concentrations
of flammable or flame-supporting gases,
unless there is adequate ventilation. A spark
in such an environment could create a fire or
explosion. Such environments might include:
medical use of oxygen without adequate
ventilation; industrial gases (cleaning
solvents; gasoline vapors; etc.); a leak of
natural gas; etc.
Only put the handset of your telephone next
to your ear when it is in normal talk mode.
The power adapter is intended to be correctly
oriented in a vertical or floor mount position.
The prongs are not designed to hold the plug
in place if it is plugged into a ceiling, under-
the-table or cabinet outlet.
4"7&5)&4&*/4536$5*0/4
12.
•
•
•
•
•
•
13.
14.
15.
16.
#BUUFSZ
Use only the battery provided or equivalent.
To order a replacement, visit our website at
XXXWUFDIQIPOFTDPN or call
. In Canada, go to
XXXWUFDIDBOBEBDPN or call
Do not dispose of the battery in a fire. Check
with local waste management codes for
special disposal instructions.
Do not open or mutilate the battery. Released
electrolyte is corrosive and may cause burns
or injury to the eyes or skin. The electrolyte
may be toxic if swallowed.
Exercise care in handling batteries in order
not to create a short circuit with conductive
materials.
Charge the battery provided with or identified
for use with this product only in accordance
with the instructions and limitations specified in
this manual.
1SFDBVUJPOTGPSVTFSTPGJNQMBOUFE
DBSEJBDQBDFNBLFST
Cardiac pacemakers (applies only to digital
cordless telephones):
Wireless Technology Research, LLC (WTR),
an independent research entity, led a
multidisciplinary evaluation of the interference
between portable wireless telephones and
implanted cardiac pacemakers. Supported by
the U.S. Food and Drug Administration, WTR
recommends to physicians that:
1BDFNBLFSQBUJFOUT
Should keep wireless telephones at least six
inches from the pacemaker.
Should NOT place wireless telephones
directly over the pacemaker, such as in a
breast pocket, when it is turned ON.
Should use the wireless telephone at the ear
opposite the pacemaker.
WTR’s evaluation did not identify any risk to
bystanders with pacemakers from other persons
using wireless telephones.
•
•
•
•
•
•
•
•
"CPVUDPSEMFTTUFMFQIPOFT
1SJWBDZ The same features that make a
cordless telephone convenient create some
limitations. Telephone calls are transmitted
between the telephone base and the
cordless handset by radio waves, so there
is a possibility that the cordless telephone
conversations could be intercepted by radio
receiving equipment within range of the
cordless handset. For this reason, you should
not think of cordless telephone conversations
as being as private as those on corded
telephones.
&MFDUSJDBMQPXFSThe telephone base of this
cordless telephone must be connected to a
working electrical outlet. The electrical outlet
should not be controlled by a wall switch.
Calls cannot be made from the cordless
handset if the telephone base is unplugged,
switched off or if the electrical power is
interrupted.
1PUFOUJBM57JOUFSGFSFODFSome cordless
telephones operate at frequencies that may
cause interference to televisions and VCRs.
To minimize or prevent such interference, do
not place the telephone base of the cordless
telephone near or on top of a TV or VCR.
If interference is experienced, moving the
cordless telephone farther away from the
TV or VCR often reduces or eliminates the
interference.
3FDIBSHFBCMFCBUUFSJFTExercise care in
handling batteries in order not to create a
short circuit with conducting material such
as rings, bracelets and keys. The battery or
conductor may overheat and cause harm.
Observe proper polarity between the battery
and the battery charger.
/JDLFMNFUBMIZESJEFSFDIBSHFBCMF
CBUUFSJFT Dispose of these batteries in a
safe manner. Do not burn or puncture the
battery. Like other batteries of this type, if
burned or punctured, they could release
caustic material which could cause injury
p
p
p
p
p
1BSUTDIFDLMJTU
Your product package contains the following
items. Save your sales receipt and original
packaging in the event warranty service is
necessary.
)BOETFUPWFSWJFX
FU
q$)"3(&MJHIU
q-$%EJTQMBZ
q4PGULFZT
• Press to select the menu item displayed
above the key.
• While in a menu, press to select an item; or
save an entry or setting.
q $&--BOE $&--
• Make or answer a cell call.
• Answer an incoming cell call when you hear a
call waiting alert.
q )0.&'-"4)
• Make or answer a home call.
• Press to put the current call on hold.
• Answer an incoming home call when you hear
a call waiting alert.
q
• Press repeatedly to add or remove in front
of the caller ID log entry before dialing or
saving it to the directory.
• Press and hold to set or dial your voicemail
number.
q
• While you have set the dial mode to pulse
and on a call, press to switch to tone dialing
temporarily.
q
• Make or answer a call using the handset
speakerphone.
• During a call, press to switch between the
speakerphone and the handset.
q3&%*"-1"64&
• Press repeatedly to review the redial list.
• Press and hold to insert a dialing pause while
entering a number.
q&BSQJFDF
q164)505"-,
• Press to display the Push to talk (PTT) menu to
begin a PTT call.
• Press and hold to begin a one-to-group PTT call.
• Press and hold while talking in a PTT call.
q70-6.&
• Review the directory when the phone is not
in use.
• Increase the listening volume during a call or
message playback.
• Scroll up while in a menu, or in the directory,
caller ID log, or redial list.
• Move the cursor to the right when entering
numbers or names.
70-6.& $*%
• Review the caller ID log when the phone is
not in use.
• Decrease the listening volume during a call or
message playback.
• Scroll down while in a menu, or in the
directory, caller ID log, or redial list.
• Move the cursor to the left when entering
numbers or names.
q0''$"/$&-
• Hang up a call.
• Silence the ringer temporarily while the
handset is ringing.
•
Press and hold to erase the missed call
indicator while the phone is not in use.
• Press to return to the previous menu, or
press and hold to return to idle mode, without
making changes.
q
• Press to add a space when entering names.
q
• Press and hold to enter quiet mode.
• Press repeatedly to show other dialing options
when reviewing a caller ID log entry.
q.65&%&-&5&
• Mute the microphone during a call.
• Delete digits or characters while using the
dialing keys.
• Delete the playing message on the handset.
• Silence the ringer temporarily while the
handset is ringing.
q.JDSPQIPOF
5FMFQIPOFCBTFPWFSWJFX
q4PGULFZT
• Press to select the menu item displayed
above the key.
• While in a menu, press to select an item; or
save an entry or setting.
q
• Press repeatedly to add or remove in front
of the caller ID log entry before dialing or
saving it to the directory.
• Press and hold to set or dial your voicemail
number.
q$"/$&-
• Hang up a call.
• Silence the ringer temporarily while the
telephone base is ringing.
•
Press and hold to erase the missed call
indicator while the phone is not in use.
• Press to return to the previous menu, or
press and hold to return to idle mode, without
making changes.
q '*/%)"/%4&5
• Press to page all system handsets.
q'-"4)
• Press to put the current home call on hold.
• Answer an incoming home call when you hear
a call waiting alert.
q 70-
• Adjust the volume during a call or message
playback.
• Adjust the telephone base ringer volume when
the phone is not in use.
q
• While you have set the dial mode to pulse and on
a call, press to switch to tone dialing temporarily.
q$IBSHJOHQPMF
q155
• Press to display the PTT menu to begin a
PTT call.
• Press and hold to begin a one-to-group PTT call.
• Press and hold while talking in a PTT call.
q.*$.JDSPQIPOF
q
• Press to add a space when entering names.
q$&--BOE $&--)&"%4&5 MJHIUT
• On when the telephone base is paired and
connected with a Bluetooth device.
• Flash when the telephone base is in
discoverable mode.
q-$%EJTQMBZ
q3&%*"-1"64&
• Press repeatedly to review the redial list.
• Press and hold to insert a dialing pause while
entering a number.
q$"--&3*%
• Review the caller ID log when the phone is
not in use.
• Scroll down while in a menu, or in the
directory, caller ID log, or redial list.
• Move the cursor to the left when entering
numbers or names.
q1)0/�,
• Review the directory when the phone is not
in use.
• Scroll up while in a menu, or in the directory,
caller ID log, or redial list.
• Move the cursor to the right when entering
numbers or names.
q "/40/0''
• Turn the answering system on or off.
q $&--BOE $&--
• Make or answer a cell call.
• Answer an incoming cell call when you hear a
call waiting alert.
q9%&-&5&
• Delete digits or characters while using dialing
keys.
• Delete the playing message.
• Press twice to delete all previously reviewed
messages when the phone is not in use.
q 3&1&"5
• Press to repeat a message.
• Press twice to play the previous message.
q 4,*1
• Skip to the next message
q 1-":4501
• Play messages.
• Stop playing messages.
q )0.&
• M
ake or answer a home call.
• Hang up a home call.
q.65&
• Mute the microphone during a call.
• Silence the ringer temporarily while the
telephone base is ringing.
q64#QPSU
• The standard size USB port in the telephone
base is used for charging your cell phones.
q
• Press and hold to enter quiet mode.
• Press repeatedly to show other dialling options
when reviewing a caller ID log entry
$IBSHFSPWFSWJFX
q$IBSHJOHQPMF
$POOFDU
$POOFDUUIFUFMFQIPOFCBTF
$POOFDUUIFDIBSHFS
Use only the power adapters supplied with
this product.
Even if you do not subscribe to any
conventional telephone service, you can
pair a Bluetooth enabled cell phone to your
telephone base (see Bluetooth), and use
the cell line alone without plugging in a
telephone line cord.
If you subscribe to telephone service
from a cable company or a VoIP service
provider, contact your cable/VoIP service
provider for more information.
Install the battery
Install the battery as shown below.
Use only the battery provided or equivalent.
If the handset will not be used for a long
time, disconnect and remove the battery to
prevent possible leakage.
•
•
•
•
•
Charge the battery
Once you have installed the battery, the battery
indicators show the battery status (see the table
below).
For best per formance, keep the handset
in the telephone base or charger when not
in use.
The battery is fully charged after 12 hours
of continuous charging.
The following table summarizes the battery
charge indicators and actions to take.
#BUUFSZ
JOEJDBUPST
#BUUFSZTUBUVT "DUJPO
The screen
is blank, or
shows 1MBDF
JODIBSHFS
and
flashes.
The battery
has no charge
or very little
charge. The
handset cannot
be used.
Charge without
interruption
(at least 30
minutes).
The screen
shows -PX
CBUUFSZ and
flashes.
The battery has
enough charge
to be used for a
short time.
Charge without
interruption
(at least 30
minutes).
The screen
shows
)"/%4&59.
The battery is
charged.
To keep the
battery charged,
place it in the
telephone base
or charger when
not in use.
5BCMFUPQUPXBMMNPVOUJOTUBMMBUJPO
The telephone comes ready for tabletop use.
If you have already installed the telephone for
tabletop use, unplug the telephone line cord
from the telephone wall jack, and unplug the
telephone base power adapter from the wall
outlet before mounting your telephone on a wall.
Follow the steps below to mount your telephone
on a wall.
•
•
#FGPSFVTF
After you install your telephone or power returns
following a power outage, the handset or
telephone will prompt you to set the date and time.
If you choose to set up the date and time, you
can do it manually.
4FUEBUFBOEUJNF
Use the dialing keys (-) to enter the month,
date, and year, and then press /&95 .
Use the dialing keys (-) to enter the hour
and minute.
Scroll to choose ". or 1., and then press
4"7& to save.
5PTLJQTFUUJOHQSFTT$"/$&-
*.1035"/5
Check for a dial tone by pressing )0.&.
If you hear a dial tone, the installation is
successful.
*GZPVEPOPUIFBSBEJBMUPOF
Make sure the installation procedures
described above are properly done.
It may be a wiring problem. If you have
changed your telephone service to digital
service from a cable company or a VoIP
service provider, the telephone line may
need to be rewired to allow all existing
telephone jacks to work. Contact your cable/
VoIP service provider for more information.
0QFSBUJOHSBOHF
This cordless telephone operates with the
maximum power allowed by the Federal
Communications Commission (FCC). Even
so, this handset and telephone base can
communicate over only a certain distance
- which can vary with the locations of the
telephone base and handset, the weather, and
the layout of your home or office.
When the handset is out of range, the handset
displays 0VUPGSBOHF03 OPQPXFSBUCBTF
alternately.
If there is a call while the handset is out of
range, it may not ring, or if it does ring, the call
may not connect well when you press )0.&
or $&--.Move closer to the telephone base,
and then press )0.& or $&-- to answer
the call. If the handset moves out of range
during a telephone conversation, there may be
interference. To improve reception, move closer
to the telephone base.
1.
2.
3.
p
•
•
#MVFUPPUI
To use a Bluetooth enabled cell phone or
headset with your %4, you must first pair
and connect your Bluetooth cell phone or headset
with the telephone base.
Bluetooth wireless technology operates within
a short range (a maximum of approximately
30 feet). When you pair a Bluetooth cell phone
to the telephone base, place your Bluetooth
cell phone closer to the telephone base to
maintain sufficient signal strength. For optimal
performance, keep your cell phone within 15 feet
of the telephone base while using the cell line.
1BJSBOEDPOOFDUZPVS#MVFUPPUIFOBCMFE
DFMMQIPOF
Press .&/6 on the telephone base when idle.
Press $"--&3*% or 1)0/�, to
scroll to #MVFUPPUI, and then press 4&-&$5 .
Press 4&-&$5 to choose "EEEFWJDF.
Press 4&-&$5 to choose "EEDFMMVMBS.
Disconnect your cell phone from any
Bluetooth device, and then press /&95.
Place your cell phone next to the telephone
base, and then press /&95.
Turn on the Bluetooth feature of your cell
phone and search for or add new devices.
Once your cell phone finds 75FDI%4,
press the appropriate key on your cell phone
to continue the pairing process.
Enter the PIN of your cell phone if
required. The PIN for most Bluetooth
devices is (refer to the user’s
manual of your cell phone), and then
press 4&-&$5.
When the cell phone is connected to the
telephone base, the corresponding status icon
(1 or 2) displays when idle. The corresponding
device light ($&-- or $&--)&"%4&5 )
turns on.
If the pairing fails, turn off the Bluetooth
feature on your cell phone. Then repeat the
steps above to pair and connect again. In
some cases, it may take you a few attempts to
complete the pairing process.
1.
2.
3.
4.
5.
6.
7.
•
1BJSBOEDPOOFDUZPVS#MVFUPPUIFOBCMFE
IFBETFU
Press .&/6 on the telephone base when idle.
Press $"--&3*% or 1)0/�, to
scroll to #MVFUPPUI, and then press 4&-&$5 .
Press 4&-&$5 to choose "EEEFWJDF.
Press $"--&3*% or 1)0/�, to
scroll to "EEIFBETFU, and then press 4&-&$5 .
Disconnect your headset from any Bluetooth
device, and then press /&95.
6. Set your headset to discoverable mode, and
then press /&95.
Scroll to highlight your headset if
necessary, and then press 4&-&$5.
Enter the PIN of your headset if required.
The PIN for most Bluetooth devices is
(refer to the user’s manual of your
headset), and then press 4&-&$5.
When the headset is successfully paired and
connected to the telephone base, the icon
displays. The $&--)&"%4&5 light turns on.
75FDI$POOFDUUP$FMM5.BQQMJDBUJPO
This application helps you integrate
your Android phones with your %4.
For more information and application
download, scan the QR code on the
right, or go to
IUUQXXXWUFDIQIPOFTDPNBQQ@DPOOFDU@UP@DFMM
%PXOMPBEDPOUBDUTGSPNZPVS#MVFUPPUI
DFMMQIPOF
Press .&/6 on the telephone base when idle.
Scroll to #MVFUPPUI, and then press 4&-&$5.
Scroll to %PXOMPBEEJS, and then press 4&-&$5.
Scroll to choose among 1IPOFNFNPSZ,
4*.DBSEPOMZ, or 1IPOFBOE4*., and then
press 4&-&$5.
If you have downloaded contacts before,
press /&95 to start downloading.
5. Press 0, to exit when the download is
completed.
For certain cell phones, you may need to
press a key on your cell phone to confirm
the directory download.
The performance of directory download
feature depends on the compatibility of
your Bluetooth cell phone. Refer to the
user’s manual of your cell phone for more
information about how that device uses
Bluetooth connectivity.
Certain cell phones do not support SIM
card download. If this is the case, transfer
the contacts from your SIM card to your
cell phone memory first. Then download
from your cell phone memory. For more
information on how to transfer contacts from
your SIM card to your cell phone memory,
see the user’s manual of your cell phone.
1.
2.
3.
4.
5.
•
•
1.
2.
3.
4.
•
•
•
•
For Android cell phones, you may
also download your cell phone
contacts to your %4 via the
VTech Contact Share application.
Scan the QR code on the right, or
go to
XXXWUFDIQIPOFTDPNBQQTDPOUBDU@TIBSF
for application download.
6TJOHUIFNFOV
Press .&/6 on the handset or telephone
base when idle.
Press
or
on the handset, or press
or on the telephone base to scroll until
the screen displays the desired feature menu.
Press 4&-&$5 to enter that menu.
To return to the previous menu, press $"/$&-.
To return to idle mode, press and hold $"/$&-.
5FMFQIPOFTFUUJOHT
Default settings are indicated by asterisks(*).
4FUUJOHT
NFOV %FTDSJQUJPO 0QUJPOT
-$%
MBOHVBHF Set the screen display
language. &OHMJTI
'SBO¿BJT
&TQBñPM
7PJDF
MBOHVBHF Set the voice prompt
language. &OHMJTI
'SBO¿BJT
7PJDFNBJMSave the speed dial
voicemail number to 1 .7PJDFNBJM
@
$MFBS
WPJDFNBJM Turn off the voicemail
indicators (see the note
below).
3FTFU
7PJDFNBJM
JOEJDBUJPO
,FZUPOF Turn an audible beep on
or off whenever a key is
pressed.
0GG
$*%UJNF
TZOD Turn the $*%UJNFTZOD
feature on or off. (see the
note below).
0O
0GG
%JBMNPEF Set the telephone to
be touch-tone or pulse
dialing.
5PVDIUPOF
1VMTF
Use the $MFBSWPJDFNBJM feature when the
telephone indicates there is new voicemail
but there is none. For example, when you
have accessed your voicemail while away
from home. The $MFBSWPJDFNBJM feature
only turns off the indicators; it does not
delete your voicemail messages. As long
as you have new voicemail messages, your
telephone service provider continues to
send the signal that turns on the indicators.
When the $*%UJNFTZODfeature is on, the
day, month, and time are set automatically
with each incoming call if you subscribed to
caller ID service.
•
1.
2.
3.
•
•
•
•
BC
DS6291
DS6291-2
DS6291-3
DECT 6.0 cordless telephone with
BLUETOOTH® wireless technology
Go to www.vtechphones.com
to register your product for
enhanced warranty support and
latest VTech product news
Telephone base
Charger adapter
(1 for DS6291-2)
(2 for DS6291-3)
Battery
(1 for DS6291)
(2 for DS6291-2)
(3 for DS6291-3)
Charger
(1 for DS6291-2)
(2 for DS6291-3)
Handset
(1 for DS6291)
(2 for DS6291-2)
(3 for DS6291-3)
Telephone line cord
Telephone base
adapter
1
3
THIS SIDE UP
1. Press down on the tabs on the wall mount bracket
on the telephone base to release it from tabletop
orientation.
2. Rotate the wall mount bracket down to wall mount
position and then push it into the telephone base
until it clicks into place.
3. Plug the telephone line cord (or DSL filter) into
the wall jack. Align the holes on the back of the
telephone base with the standard wall plate.
Slide the bracket down until it clicks securely in
place. Connect the power adapter to the telephone
base and an electrical outlet not controlled by a
wall switch.
4. Slide the telephone base down until it clicks securely
in place. Bundle the telephone line cord and power
adapter cord neatly with twist ties if necessary.
Abridged
user’s manual
Telephones identified with this
logo have reduced noise and
interference when used with
most T-coil equipped hearing
aids and cochlear implants.
The TIA-1083 Compliant
Logo is a trademark of the
Telecommunications Industry
Association. Used under license.
T
Compatible with
Hearing Aid T-Coil
TIA-1083
Abridged user’s
manual
Abridged user’s manual Quick start
guide
Quick start guide
$)"3(& light
remains on
when charging.
6TFUIFCVJMUJOBOTXFSJOHTZTUFN
BOEWPJDFNBJMTFSWJDF
You can use your answering system and
voicemail service together by setting your
answering system to answer before voicemail
service answers as described below. To learn
how to program your voicemail settings, contact
your telephone service provider.
If you are on a call, or if the answering system
is busy recording a message and you receive
another call, the second caller can leave a
voicemail message.
Set your answering system to answer calls
at least two rings earlier than your voicemail
service is set to answer. For example, if your
voicemail service answers after six rings, set
your answering system to answer after four
rings. Some voicemail service providers may
program the delay before answering calls in
seconds instead of rings. In this case, allow
six seconds per ring when determining the
appropriate setting.
3FUSJFWFWPJDFNBJMGSPNUFMFQIPOFTFSWJDF
3FUSJFWFWPJDFNBJM
When you received a voicemail, the handset
displays and /FXWPJDFNBJM. To retrieve,
you typically dial an access number provided by
your telephone service provider, and then enter
a security code. Contact your telephone service
provider for instructions on how to configure the
voicemail settings and listen to messages.
&YQBOEZPVSUFMFQIPOFTZTUFN
"EEBOESFHJTUFSBIBOETFU
You can add new cordless handsets, DECT 6.0 cordless
headsets or speakerphones to your telephone system
(purchased separately). Visit XXXWUFDIDBOBEBDPN
for a list of compatible devices. Your telephone system
supports a maximum of 12 devices.
Additional devices registered to the telephone system
are assigned numbers in the sequential order. Register
each device with the telephone base before use.
When first purchased and properly charged, each
expansion handset shows 5PSFHJTUFS)4TFF
NBOVBM Charge the handset before registering it to the
telephone base.
To register a DECT 6.0 cordless headset or speakerphone
to this telephone system, please refer to the user’s
manual of the respective product for more details.
To register a cordless handset, see below.
5PSFHJTUFSBIBOETFU
Place the new/non-registered handset in the
telephone base. The handset and telephone base
show 3FHJTUFSJOH1MFBTFXBJU.
•
The handset and telephone base show )"/%4&59
SFHJTUFSFE and you hear a beep when the registration
process completes. The registration process takes about
90 seconds to complete.
%FSFHJTUFSBMMEFWJDFT
To replace a handset or reassign the designated
handset number of a registered handset, you must
deregister all devices and then individually register
each handset.
5PEFSFHJTUFSBMMEFWJDFT
Press and hold '*/%)"/%4&5 on the
telephone base for about 10 seconds, when the
telephone base shows %FSFHJTUFSBMMEFWJDFT ,
Immediately press '*/%)"/%4&5 again within
2 seconds.
All handsets show5PSFHJTUFS)4TFFNBOVBM
alternately when the deregistration process completes.
The deregistration process takes about 10 seconds
to complete.
&$0NPEF
This power conserving technology reduces power
consumption for optimal battery performance. The ECO
mode activates automatically whenever the handset is
synchronized with the telephone base.
(FOFSBMQSPEVDUDBSF
Remember that electrical appliances can
cause serious injury if used when you are wet
or standing in water. If the telephone base
should fall into water, DO NOT RETRIEVE IT
UNTIL YOU UNPLUG THE POWER CORD
AND TELEPHONE LINE CORD FROM THE
WALL. Then remove the telephone by the
unplugged cords.
5BLJOHDBSFPGZPVSUFMFQIPOF
Your cordless telephone contains sophisticated
electronic parts, so it must be treated with care.
"WPJESPVHIUSFBUNFOU
Place the handset down gently. Save the original
packing materials to protect your telephone if you ever
need to ship it.
"WPJEXBUFS
Your telephone can be damaged if it gets wet. Do not
use the handset outdoors in the rain, or handle it with
wet hands. Do not install the telephone base near a
sink, bathtub or shower.
&MFDUSJDBMTUPSNT
Electrical storms can sometimes cause power surges
harmful to electronic equipment. For your own safety, take
caution when using electrical appliances during storms.
$MFBOJOHZPVSUFMFQIPOF
Your telephone has a durable plastic casing that should
retain its luster for many years. Clean it only with a
dry non-abrasive cloth. Do not use dampened cloth or
cleaning solvents of any kind.
1.
2.
4UPSBHF
When you are not going to use the handset for
some time, remove the rechargeable battery from
the handset. Store the handset, the charger and the
adapter in a cool and dry place.
'SFRVFOUMZBTLFERVFTUJPOT
Below are the questions most frequently asked about
the cordless telephone. If you cannot find the answer to
your question, contact customer service by visiting our
website at XXXWUFDIQIPOFTDPN or call
. In Canada, visit
XXXWUFDIDBOBEBDPN or call .
My telephone
does not work
at all.
Make sure the telephone base is
installed properly, and battery is
installed and charged correctly.
For optimum daily performance,
return the handset to the telephone
base after use.
•
Make sure the handset has
registered to the telephone base.
•
The display
shows No Line.
I cannot dial
out or get a dial
tone.
Make sure the telephone line cord
is plugged into the telephone base
properly.
Contact your telephone service
provider (chargers may apply).
•
•
I cannot add
and connect my
cell phone or
headset to the
telephone base.
Make sure you have cellular
coverage and the Bluetooth
function of your cell phone or
headset is turned on. See the
user’s manual of your cell phone or
headset for more information.
Make sure that the telephone base
is in discoverable mode.
Carefully follow the pairing
instructions in this manual. Make
sure that your Bluetooth cell phone
or headset is not connected to
any other Bluetooth device, and is
connected to the telephone base
and active on the device list.
Turn off your cell phone or
headset, and then turn it on again.
•
•
•
•
The cell phone
reception in my
house is poor
and I cannot
connect it to my
%4.
If there is a location in your house
with better reception, you can
leave your cell phone at that
location while you use the %4
cell line. In order for this to work,
the telephone base must be within
30 feet of the cell phone.
•
The answering
system does
not answer after
correct number
of rings or does
not record
messages.
Make sure the answering system is
on. When the answering system is
on, the telephone base and handset
show "/40/ and the "/40/
light on the telephone base is on.
•
If toll saver is selected, the number
of rings changes to two when there
are new messages.
•
5IF3#3$TFBM
The RBRC® seal on the nickel-metal hydride battery
indicates that VTech Communications, Inc. is voluntarily
participating in an industry program to collect and
recycle these batteries at the end of their useful lives,
when taken out of service within the United States and
Canada.
The RBRC® program provides a convenient alternative
to placing used nickel-metal hydride batteries into the
trash or municipal waste, which may be illegal in your
area.
VTech’s participation in RBRC® makes it easy for you to
drop off the spent battery at local retailers participating
in the RBRC® program or at authorized VTech product
service centers. Please call #"55&3:5. for
information on Ni-MH battery recycling and disposal
bans/restrictions in your area. VTech’s involvement in
this program is part of its commitment to protecting our
environment and conserving natural resources.
3#3$JTBSFHJTUFSFEUSBEFNBSL
PG3FDIBSHFBCMF#BUUFSZ3FDZDMJOH
$PSQPSBUJPO
'$$BOE*$SFHVMBUJPOT
'$$1BSU
This equipment has been tested and found to comply
with the requirements for a Class B digital device under
Part 15 of the Federal Communications Commission
(FCC) rules. These requirements are intended
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance
with the instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can
be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
Changes or modifications to this equipment not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
•
•
•
•
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
To ensure safety of users, the FCC has established
criteria for the amount of radio frequency energy
that can be safely absorbed by a user or bystander
according to the intended usage of the product. This
product has been tested and found to comply with the
FCC criteria. The base shall be installed and used
such that parts of all persons’ body are maintained at a
distance of approximately 8 in (20 cm) or more.
This Class B digital apparatus complies with Canadian
requirement:
CAN ICES-3 (B)/NMB-3(B)
'$$1BSUBOE"$5"
This equipment complies with Part 68 of the FCC
rules and with technical requirements adopted by
the Administrative Council for Terminal Attachments
(ACTA). The label on the back or bottom of this
equipment contains, among other things, a product
identifier in the format US:AAAEQ##TXXXX. This
identifier must be provided to your telephone service
provider upon request.
The plug and jack used to connect this equipment
to premises wiring and the telephone network must
comply with applicable Part 68 rules and technical
requirements adopted by ACTA. A compliant telephone
cord and modular plug is provided with this product. It is
designed to be connected to a compatible modular jack
that is also compliant. An RJ11 jack should normally
be used for connecting to a single line and an RJ14
jack for two lines. See the installation instructions in the
user’s manual.
The Ringer Equivalence Number (REN) is used to
determine how many devices you may connect to your
telephone line and still have them ring when you are
called. The REN for this product is encoded as the 6th
and 7th characters following the US: in the product
identifier (e.g., if ## is 03, the REN is 0.3). In most, but
not all areas, the sum of all RENs should be five (5.0) or
less. For more information, please contact your telephone
service provider.
This equipment may not be used with Party Lines.
If you have specially wired alarm dialing equipment
connected to your telephone line, ensure the
connection of this equipment does not disable your
alarm equipment. If you have questions about what
will disable alarm equipment, consult your telephone
service provider or a qualified installer.
If this equipment is malfunctioning, it must be
unplugged from the modular jack until the problem has
been corrected. Repairs to this telephone equipment
can only be made by the manufacturer or its authorized
agents. For repair procedures, follow the instructions
outlined under the Limited warranty.
If this equipment is causing harm to the telephone
network, the telephone service provider may
temporarily discontinue your telephone service. The
telephone service provider is required to notify you
before interrupting service. If advance notice is not
practical, you will be notified as soon as possible. You
will be given the opportunity to correct the problem and
the telephone service provider is required to inform
you of your right to file a complaint with the FCC. Your
telephone service provider may make changes in its
facilities, equipment, operation, or procedures that
could affect the proper functioning of this product. The
telephone service provider is required to notify you if
such changes are planned.
If this product is equipped with a corded or cordless
handset, it is hearing aid compatible.
If this product has memory dialing locations, you may
choose to store emergency telephone numbers
(e.g., police, fire, medical) in these locations. If you do
store or test emergency numbers, please:
Remain on the line and briefly explain the reason for
the call before hanging up.
Perform such activities in off-peak hours, such as early
morning or late evening.
*OEVTUSZ$BOBEB
This device complies with Industry Canada
licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
1SJWBDZPGDPNNVOJDBUJPOTNBZOPUCFFOTVSFEXIFO
VTJOHUIJTUFMFQIPOF
The term ‘’IC:‘’ before the certification/registration
number only signifies that the Industry Canada
technical specifications were met.
The Ringer Equivalence Number (REN) for this
terminal equipment is 0.1. The REN is an indication
of the maximum number of devices allowed to be
connected to a telephone interface. The termination on
an interface may consist of any combination of devices
subject only to the requirement that the sum of the
RENs of all the devices does not exceed five.
This product meets the applicable Industry Canada
technical specifications.
3'SBEJBUJPOFYQPTVSFTUBUFNFOU
The handset complies with FCC RF radiation exposure
limits set forth for an uncontrolled environment. The
base should be installed and operated with a minimum
distance of 8 in (20 cm) between the base and
all persons’ body. Use of other accessories may not
ensure compliance with FCC RF exposure guidelines.
This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.
This equipment complies also with Industry Canada
RSS-102 with respect to Canada’s Health Code 6 for
Exposure of Humans to RF Fields.
1.
-JNJUFEXBSSBOUZ
8IBUEPFTUIJTMJNJUFEXBSSBOUZDPWFS
The manufacturer of this VTech Product warrants to
the holder of a valid proof of purchase (“Consumer” or
“you” ) that the Product and all accessories provided
in the sales package ( “Product ”) are free from
defects in material and workmanship, pursuant to the
following terms and conditions, when installed and
used normally and in accordance with the Product
operating instructions. This limited warranty extends
only to the Consumer for Products purchased and
used in the United States of America and Canada.
8IBUXJMM75FDIEPJGUIF1SPEVDUJTOPUGSFFGSPN
EFGFDUTJONBUFSJBMTBOEXPSLNBOTIJQEVSJOH
UIFMJNJUFEXBSSBOUZQFSJPEn.BUFSJBMMZ%FGFDUJWF
1SPEVDUo
During the limited warranty period, VTech’s authorized
service representative will repair or replace at VTech’s
option, without charge, a Materially Defective Product. If
we repair the Product, we may use new or refurbished
replacement parts. If we choose to replace the Product,
we may replace it with a new or refurbished Product
of the same or similar design. We will retain defective
parts, modules, or equipment. Repair or replacement
of the Product, at VTech’s option, is your exclusive
remedy. VTech will return the repaired or replacement
Products to you in working condition. You should expect
the repair or replacement to take approximately 30 days.
)PXMPOHJTUIFMJNJUFEXBSSBOUZQFSJPE
The limited warranty period for the Product extends for
ONE (1) YEAR from the date of purchase. If VTech
repairs or replaces a Materially Defective Product
under the terms of this limited warranty, this limited
warranty also applies to the repaired or replacement
Product for a period of either (a) 90 days from the
date the repaired or replacement Product is shipped to
you or (b) the time remaining on the original one-year
warranty; whichever is longer.
8IBUJTOPUDPWFSFECZUIJTMJNJUFEXBSSBOUZ
This limited warranty does not cover:
Product that has been subjected to misuse,
accident, shipping or other physical damage,
improper installation, abnormal operation or
handling, neglect, inundation, fire, water or other
liquid intrusion; or
Product that has been damaged due to repair,
alteration or modification by anyone other than an
authorized service representative of VTech; or
Product to the extent that the problem experienced
is caused by signal conditions, network reliability,
or cable or antenna systems; or
Product to the extent that the problem is caused by
use with non-VTech accessories; or
Product whose warranty/quality stickers, product
serial number plates or electronic serial numbers
have been removed, altered or rendered illegible; or
Product purchased, used, serviced, or shipped for
repair from outside the United States of America
or Canada, or used for commercial or institutional
purposes (including but not limited to Products
used for rental purposes); or
Product returned without a valid proof of purchase
(see item 2 on the next page); or
Charges for installation or set up, adjustment
of customer controls, and installation or repair of
systems outside the unit.
1.
2.
3.
4.
5.
6.
7.
8.
)PXEPZPVHFUXBSSBOUZTFSWJDF
NOTE: Before calling for service, please review the
user’s manual - a check of the Product’s controls and
features may save you a service call.
Except as provided by applicable law, you assume the
risk of loss or damage during transit and transportation
and are responsible for delivery or handling charges
incurred in the transport of the Product(s) to the service
location. VTech will return repaired or replaced Product
under this limited warranty. Transportation, delivery
or handling charges are prepaid. VTech assumes no
risk for damage or loss of the Product in transit. If the
Product failure is not covered by this limited warranty,
or proof of purchase does not meet the terms of this
limited warranty, VTech will notify you and will request
that you authorize the cost of repair prior to any further
repair activity. You must pay for the cost of repair and
return shipping costs for the repair of Products that are
not covered by this limited warranty.
8IBUNVTUZPVSFUVSOXJUIUIF1SPEVDUUPHFU
XBSSBOUZTFSWJDF
Return the entire original package and contents
including the Product to the VTech service location
along with a description of the malfunction or
difficulty; and
Include a “valid proof of purchase” (sales receipt)
identifying the Product purchased (Product model)
and the date of purchase or receipt; and
Provide your name, complete and correct mailing
address, and telephone number.
0UIFSMJNJUBUJPOT
This warranty is the complete and exclusive agreement
between you and VTech. It supersedes all other
written or oral communications related to this Product.
VTech provides no other warranties for this Product.
The warranty exclusively describes all of VTech’s
responsibilities regarding the Product. There are no
other express warranties. No one is authorized to make
modifications to this limited warranty and you should
not rely on any such modification.
State/Provincial Law Rights: This warranty gives you
specific legal rights, and you may also have other rights,
which vary from state to state or province to province.
Limitations: Implied warranties, including those of
fitness for a particular purpose and merchantability (an
unwritten warranty that the Product is fit for ordinary
use) are limited to one year from the date of purchase.
Some states/provinces do not allow limitations on how
long an implied warranty lasts, so the above limitation
may not apply to you. In no event shall VTech be liable
for any indirect, special, incidental, consequential,
or similar damages (including, but not limited to lost
profits or revenue, inability to use the Product or
other associated equipment, the cost of substitute
equipment, and claims by third parties) resulting from
the use of this Product. Some states/provinces do
not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or
exclusion may not apply to you.
1MFBTFSFUBJOZPVSPSJHJOBMTBMFTSFDFJQUBT
QSPPGPGQVSDIBTF
1.
2.
3.
5FDIOJDBMTQFDJGJDBUJPOT
Frequency
control
Crystal controlled PLL synthesizer
Transmit
frequency
DECT frequency: 1921.536-1928.448 MHz
Bluetooth frequency: 2402.000-2480.000MHz
Channels DECT: 5
Bluetooth: 79
Nominal
effective
range
Maximum power allowed by FCC and IC.
Actual operating range may vary according
to environment conditions at the time of use.
Power
requirements
Handset: 2.4V 400mAH AAAx2 Ni-MH battery
Telephone base: dual output, 6VDC @ 600mA;
5.1VDC @1000mA
Charger: 6V AC @ 300mA
Memory Directory:
Home line: 200 memory locations, up to 30
digits and 15 characters
Each cell line: 1500 memory locations, up to
30 digits and 15 characters
Caller ID log:
50 memory locations; up to 24 digits and
15 characters
The following are some of the telephone
features you may wish to set.
3JOHFSWPMVNFIBOETFU
You can adjust the handset ringer volume level,
or turn the ringer off.
Press .&/6 on the handset when idle.
Scroll to 3JOHFST, and then press 4&-&$5.
Press 4&-&$5 to select 3JOHFSWPMVNF.
Scroll to adjust the volume, and then press
4&5 to save.
If the handset ringer volume is set to off, that
handset is silenced for all incoming calls
except paging tone.
3JOHFSWPMVNFUFMFQIPOFCBTF
You can adjust the base ringer volume level
when idle by pressing 70- .
3JOHFSUPOF
You can choose from different ringer tones.
Press .&/6 on the handset or telephone
base when idle.
Scroll to 3JOHFST, and then press 4&-&$5.
Scroll to 3JOHFSUPOF, and then press
4&-&$5.
Scroll to choose "MMMJOFT,)PNF, $FMM, or
$FMM, and then press 4&-&$5.
Scroll to sample each ringer tone, and then
press 4&-&$5 to save.
If you turn off the ringer volume, you will not
hear ringer tone samples.
4FUEBUFBOEUJNF
If you subscribe to caller ID service, the day,
month, and time are set automatically with each
incoming call. You can also set the date and time
manually.
Press .&/6 on the handset or telephone
base when idle.
Scroll toto 4FUEBUFUJNF, and then press
4&-&$5.
Use the dialing keys (-) to enter the month,
date, and year, and then press /&95.
Use the dialing keys (-) to enter the hour and
minute.
Scroll to choosechoose ". or 1., and then press
4"7& to save.
2VJFUNPEF
You can turn on the quiet mode for a period of
time. During this period, all tones (except paging
tone) and call screening are muted. When you
turn on the quiet mode, the answering system
turns on automatically.
1.
2.
3.
4.
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
Press and hold on the handset or
telephone base when idle.
Use the dialing keys (-) to enter the
duration, and then press 4&-&$5 to save.
To turn off the quiet mode, press and hold
on the handset or telephone base
when idle.
$BMMFS*%BOOPVODF
The caller ID announce feature lets you know
who’s calling without having to look at the
display. When you have an incoming call, the
handset speaks “Call fr om...” and the name of
the caller based on the phonebook or caller
ID information. If the caller’s name is private
or unknown, the phone number up to the last
11 digits will be announced. If the caller’s
phone number is also private or unknown, no
information will be announced.
Press .&/6 on the handset or telephone
base when idle.
Scroll toto "OOD$BMMFS*%, and then press
4&-&$5.
Scroll to choosechoose 0Oor 0GG, and then press
4&-&$5 to save.
To use the caller ID announce feature, you
must subscribe to caller ID service from
your telephone service provider.
When there are up to five handsets
registered, the telephone system supports
caller ID announce for all handsets.
If six or more handsets are registered, the
system supports caller ID announce for the
first four registered handsets only.
5FMFQIPOFPQFSBUJPO
.BLFBIPNFDBMM
Press )0.& or , and then dial the
telephone number.
.BLFBDFMMDBMM
Press $&-- or $&-- on the handset
or base. Enter the telephone number, and then
press %*"- to dial.
03
Enter the telephone number on the handset or
base, and then press $&-- or
$&-- to dial.
After first pressing $&-- or $&--,
you may need to choose a cell device.
Scroll to select the desired cell device when
necessary, and then press 4&-&$5.
While using the cell line, place your cell
phone closer to the base, and make sure
that there are no physical obstacles between
the base and the cell phone, such as large
furniture or thick walls.
1.
2.
•
1.
2.
3.
•
•
•
•
•
"OTXFSBIPNFDFMMDBMM
Press )0.&, $&--, $&--,,
or any dialing key.
&OEBIPNFDFMMDBMM
Press0'' on the handset, or put the handset
to the base or charger.
03
Press )0.&, $&--, or $&--
on the base.
$POGFSFODFDBMMT
When you have calls established on the home and/or
cell lines, you can create a 3-way conference.
5PDPOGFSFODFIPNFBOEPSDFMMDBMMT
Press015*0/ on the handset or telephone
base during a call.
Scroll to $POGFSFODF, and then press
4&-&$5. The conferencing devices’ screens
display $POG.
5PTFMFDUBOPQUJPOEVSJOHBDPOGFSFODF
Press015*0/ on the handset or base.
Scroll to &OE)PNFMJOF,&OE$FMMMJOF,
&OE$FMMMJOF,&RVBMJ[FS,$BMMFS*%MPH, or
%JSFDUPSZ, and then press 4&-&$5.
5PFOEDPOGFSFODF
Press0'' on the handset, or put the handset
to the telephone base or charger.
03
Press )0.&, $&--, or $&--
on the telephone base.
)BOETFUTQFBLFSQIPOF
During a call, press on the handset to switch
between speakerphone and normal handset use.
7PMVNF
During a call, press 70-6.& on the
handset or 70- on the telephone base
to adjust the listening volume.
The volume settings of handset earpiece,
handset speakerphone, and base
speakerphone are independent.
.VUF
The mute function allows you to hear the other
party but the other party cannot hear you.
During a call, press .65& on the handset or
telephone base. The screen displays .VUFE.
Press .65& again to resume the conversation.
The screen displays .JDSPQIPOF0/.
$BMMXBJUJOH
When you subscribe to call waiting service from
your telephone service provider, you hear an
alert tone if there is an incoming call while you
are on another call.
•
•
•
1.
2.
1.
2.
•
•
•
•
1.
2.
$BMMXBJUJOHPOUIFIPNFMJOF
Press '-"4) to put the current call on hold
and take the new call.
Press '-"4) to switch back and forth
between calls.
$BMMXBJUJOHPOUIFDFMMMJOF
Press $&--or $&--, to put the
current call on hold and take the new call.
Press $&-- or $&-- to switch
back and forth between calls.
5FNQPSBSZSJOHFSTJMFODJOH
When the telephone is ringing, you can
temporarily silence the ringer of the handset
without disconnecting the call. The next call rings
normally at the preset volume.
Press .65&, .65&, $"/$&-, oron
the handset or telephone base. The screen
displays
5FNQPSBSZUPOFEJBMJOH
If you have pulse (rotary) service only, you can
switch from pulse to tone dialing temporarily
during a call.
During a call, press .
Use the dialing keys to enter the relevant
number. The telephone sends touch-tone
signals. It automatically returns to pulse
dialing mode after you end the call.
'JOEIBOETFU
Use this feature to find all system handsets.
5PTUBSUQBHJOH
Press '*/%)"/%4&5 on the base. All idle
handsets ring and display 1BHJOH.
5PNVUFQBHJOH
Press .65&, .65&, $"/$&-, or on
the handset.
5PFOEQBHJOH
Press '*/%)"/%4&5 or 4501 on the base.
03
Press )0.&, $&--, $&--, ,
or any dialing key on the handset.
Do not press and hold '*/%)"/%4&5
for more than four seconds. It may lead to
handset deregistration.
3FEJBMMJTU
The base and each handset store the last 10
telephone numbers dialed. When there are
already 10 entries, the oldest entry is deleted to
make room for the new entry.
5PSFWJFXBOEEJBMBOVNCFSGSPNUIFSFEJBMMJTU
Press 3&%*"- on the handset or telephone
base when idle.
•
•
•
•
•
1.
2.
•
•
•
•
1.
Scroll or press 3&%*"- repeatedly until the
desired entry displays.
Press )0.&, $&--, $&--, or
to dial.
5PEFMFUFBSFEJBMFOUSZ
When the desired redial entry displays, press
%&-&5&.
+PJOBDBMMJOQSPHSFTT
You can use up to four system handsets at a
time on a home line call. You can buy additional
expansion handsets for this telephone base.
You can register up to five handsets to the
telephone base.
When a device is on a home call, press )0.&
oron another device to join the call.
Press 0'' on the handset or )0.& on the
base to exit the call. The call continues until all
devices hang up.
1VTIUPUBML155
You can directly broadcast messages from one
device to the speakerphone of one or multiple
devices.
5PTUBSUB155DPNNVOJDBUJPO
Press 164)505"-, on the handset or 155
on the base when idle.
Scroll to a desired device or (SPVQ, and then
press 4&-&$5.
Only one device can talk at a time.
Press and hold 164)505"-, while you
are talking. Release 164)505"-, to
let the other party respond.
*OUFSDPN
Use the intercom features for conversations
between two devices.
Press.&/6 on then handset or telephone
base when idle.
Scroll to *OUFSDPN, and then press 4&-&$5.
Use the dialing keys to enter a destination
device number.
To answer the intercom call, press )0.&,
$&--, $&--, , or any dialing key
on the destination device.
To end the intercom call, press &/%.
5SBOTGFSBDBMM
While on an outside call, you can use the
intercom feature to transfer the call from one
handset to another.
Press015*0/ on the handset or telephone
base during a call.
Scroll to *OUFSDPN, and then press 4&-&$5.
The current call is put on hold. Use the dialing
keys to enter a destination device number.
2.
3.
•
•
1.
2.
•
•
1.
2.
3.
4.
1.
2.
To answer the intercom call, press )0.&,
$&--, $&--, , or any dialing
key on the destination handset. You can
now have a private conservation before
transferring the call.
To transfer the call, press 015*0/ on the
initiating device, and then press 4&-&$5 to
select 5SB O T G F S.
"OTXFSBOJODPNJOHDBMMEVSJOHBOJOUFSDPNDBMM
If you receive an incoming call during an
intercom call, there is an alert tone.
To answer a home call, press )0.&. The
intercom call ends automatically.
To end the intercom call without answering
the outside call, press&/%. The intercom call
ends and the telephone continues to ring.
To answer a cell call, press &/% to end the
intercom call. The telephone continues to
ring. Then press $&--.
%JSFDUPSZ
The home directory stores up to 200 entries
with up to 30 digits for each phone number
and 15 characters for each name. Each of the
downloaded directories stores up to 1,500 entries
with up to 30 digits for each phone number and
15 characters for each name.
5PBEEBEJSFDUPSZFOUSZ
Press .&/6 on the handset or telephone
base when idle.
Scroll to %JSFDUPSZ then press 4&-&$5.
Press 015*0/ to select )PNF.
Press 4&-&$5 to choose "EEDPOUBDU.
Use the dialing keys to enter the number (up
to 30 digits), and then press /&95.
Scroll to select )PNF, $FMM, 8PSL, or 0UIFS,
and then press /&95.
7. Use the dialing keys to enter the name (up to
15 characters). Additional key presses show
other characters of that particular key.
8. Press 4"7& to save.
While entering numbers and names, you can:
Press%&-&5& to erase a digit or character.
Press and hold %&-&5& to erase the entire entry.
Scroll to move the cursor to the left or right.
Press and hold 1"64& to insert a dialing
pause (for entering phone numbers only).
Press to add a space (for entering names only).
Press to add or to add
(for
entering phone numbers only)
.
3.
4.
•
•
•
1.
2.
3.
4.
5.
6.
•
•
•
•
•
•
5PSFWJFXBOEEJBMGSPNUIFEJSFDUPSZ
Entries are sorted alphabetically.
Press or 1)0/�, when idle.
Scroll to the desired directory, and then
press 3&7*&8.
Scroll to browse through the directory, or use
the dialing keys to start a name search (you
can enter up to 3 characters for the search).
When the desired entry appears, press
)0.&, $&--, $&--, or to dial.
5PFEJUBEJSFDUPSZFOUSZ
When the desired entry displays, press &%*5.
Use the dialing keys to edit the number, and
then press /&95.
Scroll to select )PNF, $FMM, 8PSL, or 0UIFS,
and then press /&95.
Use the dialing keys to edit the name, and
then press 4"7& to save.
5PEFMFUFBEJSFDUPSZFOUSZ
When the desired entry displays, press
%&-&5&.
When the screen displays %FMFUFDPOUBDU ,
press:&4 to confirm delete.
$BMMFS*%
This product supports caller ID services provided
by most telephone service providers. Depending
on your service subscription, you may see the
caller’s name, number, date and time of calls that
are sent by your telephone service provider after
the first or second ring.
$BMMFS*%MPH
The caller ID log stores up to 50 entries. If
you answer a call before the caller information
appears, it will not be saved in the caller ID log.
The screens display 99NJTTFEDBMMT when
there are calls that have not been reviewed in
the caller ID log.
If you want to erase the missed call indicator,
press and hold $"/$&-or press $*%when idle.
5PSFWJFXBOEEJBMBOVNCFSJOUIFDBMMFS*%MPH
Press $*% or $"--&3*% when idle.
Scroll to browse through the caller ID log.
When the desired entry appears:
Press repeatedly to show different
dialing options.
Press repeatedly if you need to add or
remove 1 in front of the phone number.
3. Press )0.&, $&--, or $&--
to dial the displayed number.
1.
2.
3.
4.
1.
2.
3.
4.
1.
2.
•
•
1.
2.
•
•
5PTBWFBDBMMFS*%MPHFOUSZUPUIFEJSFDUPSZ
When the desired caller ID log entry
displays, press 4"7&.
2. Use the dialing keys and #"$,41 to edit
the number, and then press /&95.
3. Scroll to select )PNF, $FMM, 8PSL, or 0UIFS,
and then press /&95.
4. Use the dialing keys to edit the name, and
then press 4"7& to save.
5PEFMFUFBDBMMFS*%MPHFOUSZ
When the desired caller ID log entry displays,
press %&-&5&.
5PEFMFUFBMMDBMMFS*%MPHFOUSJFT
Press .&/6 on the handset or telephone
base when idle.
Scroll to $BMMFS*%MPHand then press
4&-&$5.
Scroll to %FMBMMDBMMT and then press
4&-&$5.
When the screen displays %FMFUFBMMDBMMT ,
press:&4 to confirm delete.
"CPVUBOTXFSJOHTZTUFNBOEWPJDFNBJM
For message recording, your telephone has a
built-in answering system, and it also support
voicemail service offered by your telephone
service provider (subscription is required, and
fee may apply).
The main differences between them are as follows:
$BUFHPSZ #VJMUJOBOTXFSJOH
TZTUFN
7PJDFNBJMGSPN
UFMFQIPOFTFSWJDF
Storage Messages are
stored in the
telephone base.
Messages are
stored in a server
or system provided
by your telephone
service.
Maximum
number of
messages
This depends
on the design of
telephone base. You
cannot change the
maximum number of
messages that can
be recorded.
This may vary with
your telephone
service plan
(fee may apply).
Contact your
telephone service
provider for more
information.
Method
to retrieve
messages
Usually, there are
two ways to retrieve
messages:
Press a button
on the telephone
base; or
Access remotely
with an access
code.
•
•
To retrieve
messages, you
need an access
number and/or
a secret code
provided by your
service provider.
1.
•
1.
2.
3.
4.
4FUZPVSCVJMUJOBOTXFSJOHTZTUFN
Your answering system has various features,
read below for the basic settings.
Default settings are indicated by asterisks(*).
.FOV %FTDSJQUJPO 0QUJPOT
"OOPVODFNFOU Play, record, or reset the
announcement for incoming calls.
3FDPSEBOOD
1MBZBOOD
3FTFUBOOD
%FMFUFBMMPME Delete all old (reviewed)
messages.
/"
3FDPSENFNP Record a memo as reminders
for yourself or others using the
answering system.
/"
"OTXFS
0/0''
Turn on or off the answering
system.
0O
0GG
"OTTZTTFUVQ Change the settings of call
screening, number of rings, remote
code, message alert alone, or
recording time
Call
screening
•Set whether you hear the
callers while they are leaving
messages to you.
0O
0GG
# of rings• Set the number of times the
telephone rings before the
answering system answers.
5PMMTBWFS
Remote
code
•Set a two-digit security code to
access the answering system
remotely from any touch-tone
telephone.
Msg alert
tone
•Set to alert you when you have
new messages.
0O
0GG
Recording
time
•Set a two-digit security code to
access the answering system
remotely from any touch-tone
telephone.
NJOVUFT
NJOVUFT
NJOVUF
3FDPSEZPVSPXOBOOPVODFNFOU
You can use the preset announcement to
answer calls, or replace it with your own
recorded announcement. It can be up to
90 seconds in length.
Press .&/6 on the handset or telephone
base when idle.
Scroll to "OTXFSJOHTZT and then press
4&-&$5.
Press 4&-&$5 to select "OOPVODFNFOU.
Press 4&-&$5 to select 3FDPSEBOOD.
The handset or telephone base announces
n3FDPSEBGUFSUIFUPOF1SFTT4501XIFOZPV
BSFEPOFo After the tone, speak towards the
handset microphone. Press 4501 when done.
4FUOVNCFSPGSJOHT
You can set the answering system to answer an
incoming call after 2, 3, 4, 5 or 6 rings; or toll saver. If
you choose toll saver, the answering system answers
after 2 rings when you have new messages, or after
4 rings when you have no new messages.
1.
2.
3.
4.
5.
Press .&/6on the handset or telephone
base when idle.
Scroll to "OTXFSJOHTZT then press
4&-&$5.
Scroll to "OTTZTTFUVQ then press
4&-&$5.
Scroll to PGSJOHT then press 4&-&$5.
Scroll to choose , , , , or 5PMMTBWFS,
and then press 4&-&$5.
6TFZPVSCVJMUJOBOTXFSJOHTZTUFN
5VSOUIFBOTXFSJOHTZTUFNPOPSPGG
The answering system must be turned on to
answer and record messages.
Press "/40/0'' on the telephone base
to turn the built-in answering system on or off.
.FTTBHFQMBZCBDLBUUIFUFMFQIPOFCBTF
When you received a message on your
answering system, displays on both the
handset and telephone base, 99OFXNTHT
displays on the handset, and 99OFXNFTTBHF
displays on the telephone base. To retrieve,
press 1-":when the phone is not in use.
It can record up to 99 messages, depending
on the length of each message. Each message
can be up to three minutes in length. The total
recording time is approximately 11 minutes.
0QUJPOTEVSJOHQMBZCBDL
Press 70- to adjust the speaker volume.
Press 4,*1 to skip to the next message.
Press 3&1&"5 to repeat the message
currently playing. Press 3&1&"5 twice to
listen to the previous message.
Press 9%&-&5& to delete the playing message.
The system advances to the next message.
Press 4501 to stop.
Press )0.&, $&--, or $&-- to
call back the caller if the message contains
caller ID information. The telephone base
screen displays $BMMCBDL with the caller ID
information.
Press $"-- to call back the caller.
Press #"$, to restart the message
playback.
%FMFUFBMMPMENFTTBHFTBUUIFUFMFQIPOFCBTF
Press 9%&-&5& twice when the phone is not in use.
$BMMJOUFSDFQU
If you want to talk to the person whose message
is being recorded, press )0.& or .
1.
2.
3.
4.
5.
•
•
•
•
•
•
•
•
•
•
The#MVFUPPUIword mark and logos are owned by
Bluetooth SIG, Inc. and any use of such marks by VTech
Holdings Limited is under license. VTech Holdings Limited
is a member of Bluetooth SIG, Inc. Other trademarks and
trade names are those of their respective owners.
Specifications are subject to change without notice.
© 2014 for VTech Technologies Canada Ltd.VTech Technologies Canada Ltd.
All rights reserved. 04/14. DS6291_CAN_ACIB_V1.0
Document order number: 91-007716-010-100
