CS6859

CS6859-2

CS6859-3

CS6859-4

DECT 6.0 cordless telephone

Go to www.vtechphones.com

to register your product for

enhanced warranty support and

the latest VTech product news.

User’s manual

Congratulations

on purchasing your new VTech product. Before

using this telephone, please read

Important safety instructions.

This manual has all the feature operations

and troubleshooting necessary to install and

operate your new VTech telephone. Please

review this manual thoroughly to ensure proper

installation and operation of this innovative and

feature rich VTech product.

For support, shopping, and everything new at

VTech, visit our website at

www.vtechphones.com.

In Canada, please visit

www.vtechcanada.com.

Telephones identiﬁed with this

logo have reduced noise and

interference when used with

most T-coil equipped hearing

aids and cochlear implants.

The TIA-1083 Compliant

Logo is a trademark of the

Telecommunications Industry

Association. Used under

license.

Important safety

instructions

When using your telephone equipment,

basic safety precautions should always

be followed to reduce the risk of ﬁre,

electric shock and injury, including the

following:

Read and understand all instructions.

Follow all warnings and instructions

marked on the product.

Unplug this product from the wall

outlet before cleaning. Do not use

liquid or aerosol cleaners. Use a

damp cloth for cleaning.

Do not use this product near water

such as near a bath tub, wash bowl,

kitchen sink, laundry tub or swimming

pool, or in a wet basement or shower.

Do not place this product on an

unstable table, shelf, stand or other

unstable surfaces.

Avoid placing the telephone system

in places with extreme temperature,

direct sunlight, or other electrical

devices. Protect your phone from

moisture, dust, corrosive liquids and

fumes.

Slots and openings in the back or

bottom of the telephone base and

handset are provided for ventilation.

To protect them from overheating,

these openings must not be blocked

by placing the product on a soft

surface such as a bed, sofa or

rug. This product should never be

placed near or over a radiator or heat

placed in any area where proper

ventilation is not provided.

This product should be operated

only from the type of power source

indicated on the marking label. If

you are not sure of the type of power

supply in your home or ofﬁce, consult

your dealer or local power company.

Compatible with

Hearing Aid T-Coil

TIA-1083

Do not allow anything to rest on

the power cord. Do not install this

product where the cord may be

walked on.

Never push objects of any kind into

this product through the slots in the

telephone base or handset because

they may touch dangerous voltage

points or create a short circuit. Never

spill liquid of any kind on the product.

To reduce the risk of electric shock,

do not disassemble this product,

but take it to an authorized service

facility. Opening or removing parts of

the telephone base or handset other

than speciﬁed access doors may

expose you to dangerous voltages or

other risks. Incorrect reassembling

can cause electric shock when the

product is subsequently used.

Do not overload wall outlets and

extension cords.

Unplug this product from the wall

outlet and refer servicing to an

authorized service facility under the

following conditions:

When the power supply cord or

plug is damaged or frayed.

If liquid has been spilled onto the

product.

If the product has been exposed

to rain or water.

If the product does not operate

normally by following the

operating instructions. Adjust only

those controls that are covered

by the operation instructions.

Improper adjustment of other

controls may result in damage and

often requires extensive work by

an authorized technician to restore

the product to normal operation.

If the product has been dropped

and the telephone base and/or

handset has been damaged.

10.

11.

12.

13.

•

If the product exhibits a distinct

change in performance.

14. Avoid using a telephone (other than

cordless) during an electrical storm.

There is a remote risk of electric

shock from lightning.

15. Do not use the telephone to report

a gas leak in the vicinity of the leak.

Under certain circumstances, a spark

may be created when the adapter

is plugged into the power outlet,

or when the handset is replaced in

its cradle. This is a common event

associated with the closing of any

electrical circuit. The user should not

plug the phone into a power outlet,

and should not put a charged handset

into the cradle, if the phone is

located in an environment containing

concentrations of ﬂammable or

ﬂame-supporting gases, unless there

is adequate ventilation. A spark in

such an environment could create a

ﬁre or explosion. Such environments

might include: medical use of

oxygen without adequate ventilation;

industrial gases (cleaning solvents;

gasoline vapors; etc.); a leak of

natural gas; etc.

16. Only put the handset of your

telephone next to your ear when it is

in normal talk mode.

17. The power adapters are intended to

be correctly oriented in a vertical or

ﬂoor mount position. The prongs are

not designed to hold the plug in place

if it is plugged into a ceiling,

under-the-table or cabinet outlet.

SAVE THESE INSTRUCTIONS

Battery

CAUTION: Use Only Supplied

Battery.

Do not dispose of the battery in a fire.

Check with local waste management

•

codes for special disposal instructions.

Do not open or mutilate the battery.

Released electrolyte is corrosive and

may cause burns or injury to the eyes

or skin. The electrolyte may be toxic if

swallowed.

Exercise care in handling batteries in

order not to create a short circuit with

conductive materials.

Charge the battery provided with this

product only in accordance with the

instructions and limitations specified

in this manual.

Precautions for users of implanted

cardiac pacemakers

Cardiac pacemakers (applies only to

digital cordless telephones):

Wireless Technology Research, LLC

(WTR), an independent research entity,

led a multidisciplinary evaluation of the

interference between portable wireless

telephones and implanted cardiac

pacemakers. Supported by the U.S.

Food and Drug Administration, WTR

recommends to physicians that:

Pacemaker patients

Should keep wireless telephones at

least six inches from the pacemaker.

Should NOT place wireless telephones

directly over the pacemaker, such as in

a breast pocket, when it is turned ON.

Should use the wireless telephone at

the ear opposite the pacemaker.

WTR’s evaluation did not identify any

risk to bystanders with pacemakers

from other persons using wireless

telephones.

About cordless telephones

Privacy: The same features that make

a cordless telephone convenient

create some limitations. Telephone

calls are transmitted between the

telephone base and the cordless

•

handset by radio waves, so there is a

possibility that the cordless telephone

conversations could be intercepted

by radio receiving equipment within

range of the cordless handset. For

this reason, you should not think of

cordless telephone conversations as

being as private as those on corded

telephones.

Electrical power: The telephone

base of this cordless telephone must

be connected to a working electrical

outlet. The electrical outlet should not

be controlled by a wall switch. Calls

cannot be made from the cordless

handset if the telephone base is

unplugged, switched off or if the

electrical power is interrupted.

Potential TV interference: Some

cordless telephones operate

at frequencies that may cause

interference to televisions and

VCRs. To minimize or prevent

such interference, do not place

the telephone base of the cordless

telephone near or on top of a TV or

VCR. If interference is experienced,

moving the cordless telephone farther

away from the TV or VCR often

reduces or eliminates the interference.

Rechargeable batteries: Exercise

care in handling batteries in order

not to create a short circuit with

conducting material such as rings,

bracelets and keys. The battery or

conductor may overheat and cause

harm. Observe proper polarity

between the battery and the battery

charger.

Nickel-metal hydride rechargeable

batteries: Dispose of these batteries

in a safe manner. Do not burn or

puncture the battery. Like other

batteries of this type, if burned or

punctured, they could release caustic

material which could cause injury.

•

Table of contents

What’s in the box . . . . . . . . . . . . . . . 1

Overview ......................2

Handset overview . . . . . . . . . . . . . . . . . . . 2

Telephone base overview . . . . . . . . . . . . . 3

Charger overview . . . . . . . . . . . . . . . . . . . 4

Display icons overview . . . . . . . . . . . . . . . 5

Handset and Telephone base

lights overview .....................5

Connect.......................6

Connect the charger. . . . . . . . . . . . . . . . . 6

Mount the telephone base . . . . . . . . . . . . 6

Install and charge the battery. . . . . . . . . . 7

Charge the battery . . . . . . . . . . . . . . . . . . 8

Before use.....................9

Set date and time . . . . . . . . . . . . . . . . . . 9

Check for dial tone . . . . . . . . . . . . . . . . . . 9

Operating range ....................9

Configure your telephone . . . . . . . 10

Set language ..................... 10

Set date and time . . . . . . . . . . . . . . . . . . 10

Home area code................... 11

Dial mode........................ 11

Telephone Operations . . . . . . . . . . 12

Make a call.......................12

Answer a call ..................... 12

End a call ........................ 12

Speakerphone .................... 12

Volume control ....................13

Mute ............................ 13

Join a call in progress (for multiple

handset models only) . . . . . . . . . . . . . . . 13

Call waiting.......................13

Chain dialing...................... 13

Find handset...................... 14

Transfer a call..................... 14

Intercom ......................... 15

Answer an incoming call during

an intercom call . . . . . . . . . . . . . . . . . . . 16

Call transfer using intercom . . . . . . . . . . 16

Redial list ....................17

Review a redial list entry. . . . . . . . . . . . . 17

Dial a redial list entry . . . . . . . . . . . . . . . 17

Delete a redial list entry . . . . . . . . . . . . . 17

Directory .....................18

Add a directory entry . . . . . . . . . . . . . . . 18

Review directory entries . . . . . . . . . . . . . 19

Alphabetical search . . . . . . . . . . . . . . . . 19

Delete a directory entry . . . . . . . . . . . . . 19

Dial a directory entry . . . . . . . . . . . . . . . 19

Speed dial........................ 20

Assign a speed dial entry . . . . . . . . . . . . 20

Reassign a speed dial entry. . . . . . . . . . 20

Dial a speed dial number . . . . . . . . . . . . 20

Delete a speed dial entry . . . . . . . . . . . . 21

Caller ID......................21

Review the caller ID log . . . . . . . . . . . . . 21

Memory match ....................22

Missed call indicator . . . . . . . . . . . . . . . . 22

View dialing options . . . . . . . . . . . . . . . . 22

Dial a caller ID log entry . . . . . . . . . . . . . 23

Delete the caller ID log entries . . . . . . . . 23

Sound settings . . . . . . . . . . . . . . . . 24

Key tone ......................... 24

Ringer tone....................... 24

Handset ringer volume . . . . . . . . . . . . . . 24

Telephone base ringer volume . . . . . . . . 24

Temporary ringer silencing . . . . . . . . . . . 25

Quiet mode....................... 25

Table of contents

About the built-in answering

system and voicemail service. . . . 26

Set your built-in answering

system.......................27

Turn the answering system on or off. . . . 27

Default announcement . . . . . . . . . . . . . . 27

Record your own announcement . . . . . . 27

Play your announcement . . . . . . . . . . . . 27

Delete your announcement . . . . . . . . . . 28

Set number of rings . . . . . . . . . . . . . . . . 28

Turn the call screening on or off . . . . . . . 28

Turn the message alert tone on or off. . . 28

Set the recording time . . . . . . . . . . . . . . 29

Using your built-in answering

system.......................29

Message playback . . . . . . . . . . . . . . . . . 29

Delete all messages . . . . . . . . . . . . . . . . 30

Remote access.................... 30

Set remote access code. . . . . . . . . . . . . 31

Call screening..................... 31

Call intercept...................... 32

Record, play, and delete memos . . . . . . 32

Retrieve voicemail from

telephone service . . . . . . . . . . . . . . 33

Retrieve voicemail . . . . . . . . . . . . . . . . . 33

Turn off the new voicemail indicators . . . 33

Expand your telephone system . . 33

Screen messages . . . . . . . . . . . . . . 34

Frequently asked questions . . . . . 36

General product care . . . . . . . . . . . 39

The RBRC® seal ...............39

FCC, ACTA and IC regulations . . . 40

California Energy Commission

battery charging testing

instructions...................42

For C-UL compliance only. . . . . . . 42

Limited warranty. . . . . . . . . . . . . . . 45

Technical specifications. . . . . . . . . . 47

What’s in the box

Your telephone package contains the following

items. Save your sales receipt and original

packaging in case it is necessary to ship your

telephone for warranty service.

NOTE

To purchase replacement batteries or power

adapters, visit our website at

www.vtechphones.com or call

1 (800) 595-9511. In Canada, go to

www.vtechcanada.com or dial

1 (800) 267-7377.

1 set for CS6859

2 sets for CS6859-2

3 sets for CS6859-3

4 sets for CS6859-4

Abridged user’s

manual

1 set for CS6859-2

2 sets for CS6859-3

3 sets for CS6859-4

1 set for CS6859/CS6859-2/CS6859-3/

CS6859-4

1 set for CS6859/CS6859-2/CS6859-3/

CS6859-4

Important Safety

Instructions

Overview

Handset overview

1 – Handset earpiece

2 – LCD display

3 – MENU/SELECT

• Show the menu.

• While in a menu, press to select

an item, or save an entry or

setting.

4 – OFF/CANCEL

Hang up a call.

Silence the ringer temporarily

while the handset is ringing.

Press and hold to erase the

missed call indicator while the

phone is not in use.

Press to return to the previous

menu; or press and hold to return

to idle mode, without making

changes.

•

5 –

Press repeatedly to show other

dialing options when reviewing a

caller ID log entry.

6 – INT

Press to start an intercom

conversation or transfer a call (for

multi-handset models only).

7 – Microphone

8 –

• Make or answer a call using the

handset speakerphone.

• During a call, press to switch

between the speakerphone and

the handset.

9 – MUTE/DELETE

Mute the microphone during a

call.

Delete digits or characters while

using the dialing keys.

Silence the ringer temporarily

while the handset is ringing.

10 –

• While you have set the dial mode

to pulse and on a call, press to

switch to tone dialing temporarily.

11 –

Press to add a space when

entering names.

12 – 1

• Press repeatedly to add or

remove 1 in front of the caller ID

log entry before dialing or saving

it to the directory.

• Press and hold to set or dial your

voicemail number.

13 – /FLASH

• Make or answer a home call.

• Answer an incoming home call

when you hear a call waiting

alert.

•

14 – REDIAL/PAUSE

• Press repeatedly to review the

redial list.

• Press and hold to insert a dialing

pause while entering a number.

15 – VOLUME/ /

• Review the directory when the

phone is not in use.

• Increase the listening volume

during a call.

• Scroll up while in a menu, or in

the directory, caller ID log, or

redial list.

• Move the cursor to the right when

entering numbers or names.

VOLUME/ /CID

Review the caller ID log when the

phone is not in use.

Decrease the listening volume

during a call.

Scroll down while in a menu, or

in the directory, caller ID log, or

redial list.

Move the cursor to the left when

entering numbers or names.

16 – CHARGE light

• On when the handset is

charging.

•

Telephone base overview

1 – LCD display

2 – IN USE light

• Flashes when there is an incoming

call, or another telephone sharing

the same line is in use.

• On when the handset is in use.

3 – MENU/SELECT

• Show the menu.

• While in a menu, press to select

an item, or save an entry or

setting.

FLASH

• Answer an incoming home call

when you hear a call waiting

alert.

• Review the directory when the

phone is not in use.

• Scroll up while in a menu, or in

the directory, caller ID log, or

redial list.

• Move the cursor to the right when

entering numbers or names.

CID

Review the caller ID log when the

phone is not in use.

Scroll down while in a menu, or

in the directory, caller ID log, or

redial list.

•

Move the cursor to the left when

entering numbers or names.

OFF/CANCEL

Press and hold to erase the

missed call indicator while the

phone is not in use.

Press to return to the previous

menu; or press and hold to return

to idle mode, without making

changes.

4 – X/DELETE

• Press to delete the playing

message.

• When the phone is not in use,

press twice to delete all previously

reviewed messages.

/REPEAT

• Press to repeat the playing

message.

• Press twice to play the previous

message.

/SKIP

• Press to skip to the next message.

/PLAY/STOP

• Press to play messages.

• Press to stop message playback.

5 – /FIND HANDSET

• Press to page all system

handsets.

6 – ANS ON/OFF

• Press to turn the answering

system on or off.

7 – /SPEAKER

• Press to make or answer a call.

8 – MUTE

Mute the microphone during a

call.

Silence the ringer temporarily

while the handset is ringing.

•

9 –

Press repeatedly to show other

dialing options when reviewing a

caller ID log entry.

10 –

Press to add a space when

entering names.

11 –

• While you have set the dial mode

to pulse and on a call, press to

switch to tone dialing temporarily.

12 – Microphone

13 – REDIAL/PAUSE

• Press repeatedly to review the

redial list.

• Press and hold to insert a dialing

pause while entering a number.

14 – Charging pole

15 – /VOL/

• Adjust the listening volume

during a call or message

playback.

• When the phone is not in use,

press to adjust the telephone

base ringer volume.

16 – INT

Press to start an intercom

conversation or transfer a call (for

multi-handset models only).

Charger overview

1 – Charging pole

•

Display icons overview

Handset icons

The battery icon flashes

when the battery is low and

needs charging.

The battery icon animates

when the battery is

charging.

The battery icon becomes

solid when the battery is

fully charged.

The handset ringer is off.

There are new voicemail

received from your

telephone service provider.

ECO The ECO mode activates

automatically to reduce

power consumption when

the handset is within range

from the telephone base.

NEW There are new caller ID log

entries.

Telephone base icons

The telephone base ringer

is turned off.

There are new voicemail

received from the telephone

service provider.

MSG #

1 The message number

currently playing, or the

total number of messages

recorded..

NEW The caller ID log entry you

are reviewing is new.

The message you are

listening is new.

Handset and Telephone base

lights overview

Handset lights

On when the handset

speakerphone is in use.

CHARGE On when the handset is

charging in the telephone

base or handset charger.

Telephone base lights

IN USE On when the telephone line

is in use.

On when you are

registering a handset.

Flashes quickly when there

is an incoming call.

Flashes when another

telephone sharing the same

line is in use.

Flashes when you are

deregistering all handsets.

ANS

ON/OFF

On when the answering

system is turned on.

MUTE On when the mute function

is turned on during a call.

/PLAY/

STOP

Flashes when there are

new messages or memos in

the answering system.

SPEAKER

On when the telephone

base speakerphone is in

use.

Connect

You can choose to connect the telephone

base for desktop usage or wall mounting.

NOTES

Use only the power adapters supplied with

this product.

Make sure the electrical outlets are not

controlled by wall switches.

The adapters are intended to be correctly

oriented in a vertical or ﬂoor mount

position. The prongs are not designed to

hold the plug in place if it is plugged into a

ceiling, under-the-table or cabinet outlet.

TIP

If you subscribe to digital subscriber line

(DSL) high-speed Internet service through

your telephone line, make sure you install

a DSL filter (not included) between the

telephone line cord and telephone wall

jack. Contact your DSL service provider

for more information.

Connect the telephone base

•

Connect the charger

Mount the telephone base

1. Unplug the telephone line cord (or the

DSL ﬁlter) from the telephone wall

jack. Unplug the power adapter from

the electrical outlet. Slide the wall

mount bracket up and remove it from

the wall mount plate.

2. Press down on the tabs on the wall

mount bracket on the telephone base

to release it from tabletop orientation.

Rotate the wall mount bracket down

to wall mount position and then push

it into the telephone base until it

clicks into place.

Install and charge the battery

Install the battery as shown below.

NOTES

Use only supplied battery.

If the handset will not be used for a long

time, disconnect and remove the battery

to prevent possible leakage.

•

3. Plug the telephone line cord (or DSL

ﬁlter) into the wall jack. Align the

holes on the back of the telephone

base with the standard wall plate.

Slide the bracket down until it clicks

securely in place. Connect the power

adapter to the telephone base and

an electrical outlet not controlled by

a wall switch.

4. Slide the telephone base down until

it clicks securely in place. Bundle

the telephone line cord and power

adapter cord neatly with twist ties if

necessary.

Charge the battery

Place the handset in the telephone base

or the charger to charge.

Once you have installed the battery,

the handset LCD display indicates the

battery status (see the table below).

NOTES

For best performance, keep the handset in

the telephone base or charger when not

in use.

The battery is fully charged after 12 hours

of continuous charging.

If you place the handset in the telephone

base or the charger without plugging

in the battery, the screen displays

No battery.

Battery

indicators

Battery

status

Action

The screen

is blank, or

shows Put

in charger

and

ﬂashes.

The battery

has no

charge or

very little

charge. The

handset

cannot be

used.

Charge

without

interruption

(at least 30

minutes).

The screen

shows Low

battery and

ﬂashes.

The battery

has enough

charge to be

used for a

short time.

Charge

without

interruption

(at least 30

minutes).

The screen

shows

HANDSET X.

The battery is

charged. To keep

the battery

charged,

place it in the

telephone

base or

charger when

not in use.

•

When it is fully charged, you can expect the

following performance:

Operation Operating time

While in handset

use (talking*) Seven hours

While in

speakerphone

mode (talking*)

Three hours and 30

minutes

While not in use

(standby**) Five days

* Operating times vary depending on your actual

use and the age of the battery.

** Handset is not charging or in use.

Before use

After you install your telephone or

power returns following a power outage,

the handset will prompt you to set the

date and time.

Set date and time

NOTE

Make sure you set the date and time

including the year correctly; otherwise the

answering system does not announce the

correct day of the week for your recorded

messages time stamp.

Use the dialing keys (0-9) to enter

the month (MM), date (DD) and year

(YY). Then press SELECT.

2. Use the dialing keys (0-9) to enter the

hour (HH) and minute (MM). Then

press or to choose AM or PM.

3. Press SELECT to save.

Check for dial tone

Press . If you hear a dial tone, the

installation is successful.

If you do not hear a dial tone:

Make sure the installation procedures

described above are properly done.

It may be a wiring problem. If you

have changed your telephone

service to digital service from a

cable company or a VoIP service

provider, the telephone line may need

to be rewired to allow all existing

telephone jacks to work. Contact your

cable/VoIP service provider for more

information.

•

Operating range

This cordless telephone operates with

the maximum power allowed by the

Federal Communications Commission

(FCC). Even so, this handset and

telephone base can communicate over

only a certain distance - which can

vary with the locations of the telephone

base and handset, the weather, and the

layout of your home or ofﬁce.

When the handset is out of range, the

handset displays Out of range or no pwr

at base.

If there is a call while the handset is

out of range, it may not ring, or if it

does ring, the call may not connect well

when you press . Move closer to the

telephone base, and then press

to answer the call. If the handset

moves out of range during a telephone

conversation, there may be interference.

To improve reception, move closer to the

telephone base.

Configure your telephone

Press MENU when the phone is not

in use.

Press or until the screen displays

the desired feature menu.

Press SELECT to enter that menu.

To return to the previous menu, press

CANCEL on the handset.

To return to idle mode, press and hold

CANCEL on the handset.

Set language

The LCD language is preset to English.

You can select English, French or

Spanish to be used in all screen displays.

Press MENU when the handset is not

in use.

Press or to highlight Settings,

and then press SELECT.

Press SELECT to select

LCD language.

Press or to highlight English,

Français or Español, and then press

SELECT.

The screen displays Set English?

when you choose English.

The screen displays Set Français?

when you choose Français.

The screen displays Set Español?

when you choose Español.

5. Press SELECT to save your

selection. You hear a conﬁrmation

tone

NOTE

If you accidentally changed the LCD

language to French or Spanish, you can

reset it to English easily by pressing MENU

and then entering 364 .

•

Set date and time

NOTE

Make sure you set the date and time

including the year correctly; otherwise the

answering system does not announce the

correct day of the week for your recorded

messages time stamp.

Press MENU when the handset is not

in use.

Press or to highlight Set date/time,

and then press SELECT.

Use the dialing keys (0-9) to enter

the month (MM), date (DD) and year

(YY). Then press SELECT.

4. Use the dialing keys (0-9) to enter the

hour (HH) and minute (MM). Then

press or to choose AM or PM.

5. Press SELECT to save.

•

Home area code

If you dial your local calls using only

seven digits (area code not required),

you can program your home area code

so that when you receive a call within

your local area, the telephone number

is automatically stored without the area

code in the caller ID log.

Press MENU when the phone is not

in use.

Press or to highlight Settings,

and then press SELECT.

Press or to highlight Home area

code, and then press SELECT.

Use the dialing keys to enter a

three-digit home area code.

Press SELECT to save your

selection. Then the handset returns

to the previous menu. You hear a

conﬁrmation tone.

NOTE

If, in the future, your telephone service

provider requires you to dial the area code

when making a local call, or, if you move to

a location that requires it, delete the home

area code you have already programmed,

following the steps above. After you have

deleted the home area code, _ _ _ will

appear on the display.

Dial mode

The dial mode is preset to touch-tone

dialing. If you have pulse (rotary)

service, you must change the dial

mode to pulse dialing before using the

telephone to make a call.

Press MENU when the phone is not

in use.

Press or to highlight Settings,

and then press SELECT.

Press or to highlight Dial mode,

and then press SELECT.

Press or to choose Touch-tone

or Pulse.

Press SELECT to save your

selection. Then the handset returns

to the previous menu. You hear a

conﬁrmation tone.

Temporary tone dialing

If you have pulse (rotary) service only,

you can switch from pulse to touch-tone

dialing temporarily during a call. This

is useful if you need to send touch-

tone signals to access your telephone

banking or long distance services.

During a call, press .

Use the dialing keys to enter the

number you wish to dial.

The telephone sends touch-tone

signals. The telephone automatically

returns to pulse dialing mode after

you end the call.

Telephone Operations Make a call

Press or on the handset.on the handset.

When you hear a dial tone, dial the

number.

The handset displays Unable to

call if the telephone line is in use.

NOTES

The handset shows the elapsed time as

you talk (in hours, minutes and seconds).

While entering numbers, press and hold

PAUSE to insert a dialing pause

(a p appears).

Predial a call

Enter the telephone number.

Press or to dial.to dial.

NOTES

The handset displays Unable to call if

the telephone line is in use.

The handset shows the elapsed time as

you talk (in hours, minutes and seconds).

While entering numbers, press DELETE

or CANCEL to make corrections;

press and hold PAUSE to insert a dialing

pause (a p appears).

Answer a call

Press , , or any dialing key (0-9,

, or ) to answer.

End a call

Press OFF on the handset, or place the

handset in the telephone base or

handset charger.

Speakerphone

When the handset is on a call, press

to switch between the speakerphone

and the handset earpiece. When the

speakerphone is active, the handset

displays Speaker.

•

Handset control key panel:

Volume control

To adjust the listening volume at

the handset:

During a call, press /VOLUME/ .

To adjust the listening volume at

the telephone base:

During a call, press /VOL/ to adjust

the listening volume.

NOTES

The handset and speakerphone volume

settings are independent.

When the volume reaches the minimum

or maximum setting, you hear two beeps.

Mute

The mute function allows you to hear

the other party but the other party

cannot hear you.

During a call, press MUTE. The

handset displays Muted until the

mute function is turned off.

Press MUTE again to resume the

conversation. The handset briefly

displays Microphone on.

Join a call in progress (for

multiple handset models only)

Another handset can join you on a

home call. That call continues until

all parties hang up. You can share an

outside call with up to two handsets at

the same time.

You can buy additional expansion

handsets (CS6709) for this telephone

base. You can register up to ﬁve devices

to the telephone base.

•

To join a call::

When a handset is already on a call,

press or on another handset to

join the call.

Press OFF or place the handset

in the telephone base or handset

charger to exit the call. The call

continues on the other handset until

both handsets hang up.

Call waiting

When you subscribe to call waiting

service with your telephone service

provider, the handset ﬂashes and you

hear a beep if someone calls while you

are already on a call.

Press FLASH on the handset to put

your current call on hold and take the

new call.

Press FLASH on the handset at any

time to switch back and forth

between calls.

Chain dialing

Use this feature to initiate a dialing

sequence from numbers stored in the

directory, caller ID log or redial list while

you are on a call.

Chain dialing can be useful if you wish

to access other numbers (such as bank

account numbers or access codes)

from the directory, caller ID log or

redial list.

To access a number from the

directory while on a call:

Press MENU.

Press SELECT to select Directory.

Press or to scroll to the desired

entry.

Press SELECT to dial the displayed

number.

•

To access a number from the

caller ID log while on a call:

Press MENU.

Press or to highlight Caller ID

log, and then press SELECT.

Press or to scroll to the desired

entry.

Press SELECT to dial the displayed

number.

To access a number from the

redial list while on a call:

Press REDIAL to enter the redial list.

Press , , or REDIAL repeatedly to

browse to the desired entry.

Press SELECT to dial the displayed

number.

Find handset

This feature helps you ﬁnd misplaced

handsets.

To start the paging tone:

Press /FIND HANDSET on the

telephone base.

All idle handsets ring and their

screens display ** Paging **.

To stop the paging tone:

Press , OFF, or any dialing key

(0-9, , or ) on a handset.

•

Transfer a call

While on an outside call, you can

transfer the call from one handset to

another.

During a call, press MENU.

Press or to scroll to Transfer,

then press SELECT.

If you have one handset, your

handset displays Calling base and

then Transferred.

If you have two or more handsets,

your handset displays Transfer to:

Press 7 for the telephone base or

1-5 for HANDSET 1 or

HANDSET 5. Your handset

displays Calling base or Calling

HS X and then Transferred.

The destination device rings and its

screen displays Incoming call.

3. To answer on the destination device,

press , , or any dialing key

(0-9, , or ) on the destination

handset, or press /SPEAKER or

any dialing key (0-9, , or ) on

the telephone base.

NOTES

If the destination device does not answer

the call within 30 seconds, the call will

be reverted to the originating handset. If

you do not press , , or any dialing

key (0-9, , or ) on your handset

to reconnect the outside call within 30

seconds, the call ends automatically.

If the destination device is in the directory

or caller ID log, or is out of range, the

originating handset displays Unable to

call and then reconnects to the outside

call.

•

Intercom

Use the intercom feature for

conversations between two devices. You

can buy additional expansion handsets

(CS6709) for this telephone base. You

can register up to ﬁve handsets to the

telephone base.

To initiate an intercom call with a

cordless handset:

Press INT on your handset when not

in use.

If you have one handset, your

handset displays Calling base.

If you have two or more handsets,

your handset displays Intercom

to: Press 7 for the telephone base

or 1-5 for HANDSET 1 or

HANDSET 5. Your handset

displays Calling base or Calling

HS X.

The destination device rings and its

screen displays HS X is calling.

2. To answer the intercom call on the

destination handset, press , , INT

or any dialing key (0-9, , or ) .

Both handsets now display Intercom.

- OR -

To answer the intercom call at the

telephone base, press /SPEAKER,

INT or any dialing key (0-9, , or

) . Both devices now display

Intercom.

3. To end the intercom call on either

handset, press OFF or place the

handset back in the telephone base

or charger. Both handsets display

Intercom ended.

- OR -

To end the intercom call at the

telephone base, press /SPEAKER

or INT. Both devices display

Intercom ended.

•

NOTES

You can cancel the intercom call before it

is answered by pressing OFF or INT.

If the destination device does not answer

the intercom call within 100 seconds, is

accessing the answering system, on a call

or out of range, the originating handset

displays Unable to call and returns to

idle mode.

You can press OFF or MUTE on the

destination handset, or CANCEL

or MUTE on the telephone base to

temporarily silence the intercom ringer.

You can use four devices on two pairs of

intercom calls. For example, when four

devices are used on two pairs of intercom

calls, use the fifth device for an outside call.

If there is an incoming call while the

originating handset displays Calling HS X

or Calling base, the intercom request will

be stopped and the screen displays

Incoming call.

To initiate an intercom call at the

telephone base:

Press INT on the telephone base

when not in use.

If you have only one handset, the

telephone base displays Calling

HS 1.

If you have two or more handsets,

the telephone base displays

Intercom to: Press 1-5 for

HANDSET 1 to HANDSET 5. The

telephone base displays Calling

HS X.

The destination handset rings and its

screen displays Base is calling.

2. To answer the intercom call on the

destination handset, press , , INT

or any dialing key (0-9, , or ) .

Both handsets now display Intercom.

3. To end the intercom call at the

telephone base, press /SPEAKER

or INT. Both devices display

Intercom ended.

•

- OR -

To end the intercom call on the

destination handset, press OFF

or place the handset back in the

telephone base or charger. Both

devices display Intercom ended.

NOTES

If you do not have any handset registered

to the telephone base, you will hear

two beeps when you press INT on the

telephone base.

You can cancel the intercom call before it

is answered by pressing CANCEL or INT.

If the destination handset does not answer

the intercom call within 100 seconds, is

accessing the answering system, on a

call or out of range, the telephone base

displays Unable to call and returns to

idle mode.

Answer an incoming call during

an intercom call

When you receive an outside call during

an intercom call, there is an alert tone.

To answer on a cordless handset:

To answer the call, press . The

intercom call ends automatically.

To end the intercom call without

answering the call, press OFF. The

intercom call ends and the telephone

continues to ring.

To answer at the telephone base:

To answer the call, press

/SPEAKER twice. The intercom call

ends automatically.

To end the intercom call without

answering the call, press

/SPEAKER. The intercom call ends

and the telephone continue to ring.

•

Call transfer using intercom

Use the intercom feature to transfer an

outside call from one device to another.

During a call, press INT on your

handset or telephone base

If you have one handset, the

outside call is put on hold and your

handset displays Calling base

or the telephone base displays

Calling HS 1.

If you have two or more handsets,

your handset/telephone base

displays Intercom to/Intercom to:

Press 7 for the telephone base or

1-5 for HANDSET 1 or

HANDSET 5. Your handset displays

Calling base or Calling HS X.

The destination device rings and its

screen displays HS X is calling or

Base is calling.

2. To answer the intercom call on the

destination handset, press , , INT

or any dialing key (0-9, , or ) .

Both handsets now display Intercom.

- OR -

To answer the intercom call at the

telephone base, press /SPEAKER,

INT or any dialing key (0-9, , or

) . Both devices now display

Intercom.

The outside call is still on hold and

both devices now display Intercom.

You can now have a private

conversation with the destination

device.

NOTES

To cancel the intercom call before it is

answered, press OFF, or INT on your

handset, or press /SPEAKER or INT on

the telephone base.

•

If the destination device does not answer

within 100 seconds, is in use, on a

call or is out of range, the originating

device displays Unable to call and then

reconnects to the outside call.

3. From this intercom call, you have the

following options:

You can let the destination device

join you on the outside call in a

three-way conversation. Press and

hold INT on the originating device.

You can transfer the call. Press

OFF or place your handset back in

the telephone base or charger, or

press /SPEAKER on the

telephone base. The originating

device displays Transferred. The

destination device is then

connected to the outside call.

You can press INT to switch

between the outside call (Outside

call displays) and the intercom call

(Intercom displays).

•

Redial list

Each handset stores the last

10 telephone numbers dialed (up to

30 digits). When there are already

10 entries, the oldest entry is deleted

to make room for the new entry.

Review a redial list entry

Press REDIAL to enter the redial list.

Press , , or REDIAL repeatedly

to browse until the desired entry

displays.

Dial a redial list entry

Press REDIAL to enter the redial list.

Press , , or REDIAL repeatedly

to browse until the desired entry

displays.

Press or to dial.

-OR-

Press or to take the line.

Press REDIAL to enter the redial list.

Press , , or REDIAL repeatedly

to browse until the desired entry

displays.

Press SELECT to dial the displayed

number.

Delete a redial list entry

Press REDIAL to enter the redial list.

Press , , or REDIAL repeatedly

to browse until the desired entry

displays.

When the handset displays the number

you want to delete, press DELETE.

•

Directory

full

The directory is full.

You cannot save any

new entry unless you

delete some current

entries.

Ended You have just ended

a call.

Failed The handset

registration is not

successful.

HS X is

calling

(for models with two

or more handsets

only)

Another handset is

calling (for intercom

calls).

Incoming

call

There is an incoming

call.

Intercom The handset is on an

intercom call.

Intercom

ended

The intercom call has

just ended.

Intercom to

(for models with

three or more

handsets only)

You have started the

intercom process or

started transferring a

call, and need to enter

the desired handset

number.

Line in use A system handset or

another telephone on

the same line is

in use.

Low battery The battery needs to

be recharged.

Microphone

MUTE is turned off

and the person on the

other end can hear

you.

Muted You have turned

off the handset

microphone. The

other party cannot

hear you but you can

hear the other party.

New

voicemail

There are new

voicemail message(s)

from your telephone

service provider.

No battery You place the handset

in the telephone base

or charger without

installing a battery

in it.

No line There is no telephone

line connected.

No message There are no

message in the

answering system.

No old

messages

There are no old

messages in the

answering system.

You have no old

messages to be

deleted.

Not

available

Another handset

is already in the

directory or caller ID

log.

Number

repeated

The telephone

number you have

entered is already

stored in the directory.

Out of range

or no pwr at

base

The telephone base

has lost power, or

the handset is out of

range.

Phone The handset is on a

call.

Put in

charger

The battery is very

low. Put the handset

in the telephone

base or charger for

recharging.

Quiet mode

off

The quiet mode is

turned off.

Quiet mode

The quiet mode is

turned on.

Rec mem full The answering

system has no

recording time left.

Rec mem low The answering

system has less than

three minutes of

recording time left.

Registering... The handset

registration is in

progress.

Ringer muted The handset ringer

is muted temporarily

during an incoming

call.

Ringer off The handset ringer is

turned off.

Saved Your selection has

been saved.

Speaker The handset

speakerphone is in

use.

To register

HS...

...see manual

Screen display on

a non-registered

handset.

Transferred You have transferred

an outside call to

another cordless

handset.

Unable to

call

The handset is out of

range while on a call.

Failed phone call (the

telephone line is in

use).

Failed intercom call

(there are already two

handsets being used).

XX missed

calls

There are new calls in

the caller ID log.

XX new

messages

There are new

messages in the

answering system.

** Paging ** All system handsets

are being paged.

Frequently asked

questions

Below are the questions most frequently

asked about the cordless telephone.

If you cannot ﬁnd the answer to your

question, visit our website at

www.vtechphones.com or call

1 (800) 595-9511 for customer service.

My telephone

does not work

at all.

Make sure the telephone

base is installed properly,

and battery is installed

and charged correctly.

For optimum daily

performance, return the

handset to the telephone

base after use.

The display

shows No line.

I cannot hear

the dial tone.

Disconnect the

telephone line cord from

your telephone and

connect it to another

telephone. If there is

no dial tone on that

other telephone either,

then the telephone line

cord may be defective.

Try installing a new

telephone line cord.

If changing telephone

line cord does not

help, the wall jack (or

the wiring to this wall

jack) may be defective.

Contact your telephone

service provider.

You may be using a new

cable or VoIP service,

the existing telephone

jacks in your home may

no longer work. Contact

your service provider for

solutions.

I cannot dial

out. Make sure there is a dial

tone before dialing. It is

normal if the handset

takes a second or two

to synchronize with the

telephone base before

producing a dial tone.

Wait an extra second

before dialing.

Eliminate any

background noise.

Mute the handset

before dialing, or dial

from another room in

your home with less

background noise.

The display

shows To

and ...see

manual

alternately. The

handset does

not work at all.

The handset is

deregistered from the

telephone base.

Place the handset in

the telephone base

to register it back.

The handset shows

Registered and you

hear a beep when the

registration process

completes. This process

takes about 90 seconds

to complete.

The display

shows Low

battery.

Place the handset in

the telephone base or

charger for charging.

The battery

does not

charge in the

handset or the

handset battery

does not

accept charge.

Make sure the handset is

placed in the telephone

base or charger correctly.

If the battery is

completely depleted,

charge the battery for at

least 30 minutes before

use.

You may need to

purchase a new battery.

The telephone

does not ring

when there is

an incoming

call.

Make sure the ringer

volume is not set to off.

The handset may be too

far from the telephone

base. Move it closer to

the telephone base.

My handset

beeps and is

not performing

normally.

Move the handset closer

to the telephone base. It

may be out of range.

I hear other

calls when

using the

telephone.

Disconnect the telephone

base from the telephone

wall jack. Plug in a different

telephone. If you still hear

other calls, the problem is

probably in the wiring or

telephone service. Contact

your telephone service

provider.

I hear noise on

the cordless

handset and

the keys do not

work.

Make sure the telephone

line cord is plugged in

securely.

There is

interference

during a

telephone

conversation.

My calls fade

out when

I am using

the cordless

handset.

The handset may be out

of range. Move it closer

to the telephone base.

If you subscribe to high-

speed Internet service

(DSL - digital subscriber

line) through your

telephone line, you must

install a DSL ﬁlter between

the telephone line cord

and the telephone wall

jack. The ﬁlter prevents

noise and caller ID

problems caused by DSL

interference. Contact your

DSL service provider for

more information about

DSL ﬁlters.

Appliances or other

cordless telephones

plugged into the

same circuit as the

telephone base can

cause interference. Try

moving the appliance

or telephone base to

another outlet.

The location of your

telephone base can

impact the performance

of your cordless phone.

For better reception,

install the telephone base

in a centralized location

within your home or

ofﬁce, away from walls

or other obstructions.

In many environments,

elevating the telephone

base improves overall

performance.

The telephone

does not

receive caller

ID or the

telephone does

not show caller

ID during call

waiting.

Caller ID is a subscription

service. You must

subscribe to this service

from your telephone

service provider for this

feature to work on your

telephone.

Both your and the

caller’s telephone service

providers must use

equipment compatible

with the caller ID service.

The caller may not be

calling from an area

which supports caller ID.

The caller ID information

displays after the ﬁrst or

second ring.

The display

shows Out of

range or no

pwr at base.

The handset may be out

of range. Move it closer

to the telephone base.

Make sure the power

cord is securely plugged

into the telephone base.

Use a working electrical

outlet not controlled by a

wall switch.

I subscribe to a

nontraditional

telephone

service that

uses my

computer

to establish

connections,

and my

telephone

doesn’t work.

Make sure your

computer is powered

on, and your Internet is

working properly.

Make sure to plug your

USB telephone adapter

into a dedicated USB

port on your computer.

Do not plug into a

multiple port USB hub

(USB splitter) that is not

powered.

In a few rare instances,

the USB port on your

computer may not have

enough power. In these

instances, try using a

USB hub with its own

external power supply.

If you are using a

ﬁrewall, it may prevent

access to your

nontraditional telephone

service. Contact your

service provider for more

information.

The answering

system does

not record

messages.

Make sure the answering

system is on. When the

answering system is on,

ANS ON should display

on the handset and the

telephone base.

When the answering

machine memory is full,

it does not record new

messages until some old

messages are deleted.

If you subscribe to

voicemail service,

change the number

of rings so that your

answering system

answers before your

voicemail service

answers. To determine

how many rings activate

your voicemail service,

contact your telephone

service provider.

The answering

system does

not announce

the correct day

of the week

for recorded

messages time

stamp.

Make sure you have

set the date and time.

See Configure your

telephone section.

The messages

on the

answering

system are

incomplete.

If a caller leaves a very

long message, part

of it may be lost when

the answering system

disconnects the call after

the preset recording time.

If the memory on the

answering system

becomes full during a

message, the answering

system stops recording

and disconnects the call.

I accidentally

set my LCD

language to

Spanish or

French, and I

don’t know how

to change it

back to English.

While the handset is

not in use or is on a

call, press MENU and

then enter 364# to

change the handset

LCD language back to

English.

ECO mode

This power conserving technology

reduces power consumption for optimal

battery performance. The ECO mode

activates automatically whenever

the handset is synchronized with the

telephone base.

The handset shows ECO when the

ECO mode activates.

General product care

Taking care of your telephone

Your cordless telephone contains

sophisticated electronic parts, so it must

be treated with care.

Avoid rough treatment

Place the handset down gently. Save the

original packing materials to protect your

telephone if you ever need to ship it.

Avoid water

Your telephone can be damaged if

it gets wet. Do not use the handset

outdoors in the rain, or handle it with wet

hands. Do not install the telephone base

near a sink, bathtub or shower.

Electrical storms

Electrical storms can sometimes cause

power surges harmful to electronic

equipment. For your own safety, take

caution when using electrical appliances

during storms.

Cleaning your telephone

Your telephone has a durable plastic

casing that should retain its luster for

many years. Clean it only with a dry non-

abrasive cloth. Do not use dampened

cloth or cleaning solvents of any kind.

The RBRC® seal

The RBRC® seal on the nickel-metal

hydride battery indicates that VTech

Communications, Inc. is voluntarily

participating in an industry program to

collect and recycle these batteries at the

end of their useful lives, when taken out

of service within the United States and

Canada.

The RBRC® program provides a

convenient alternative to placing used

nickel-metal hydride batteries into the

trash or municipal waste, which may be

illegal in your area.

VTech’s participation in RBRC® makes it

easy for you to drop off the spent battery

at local retailers participating in the

RBRC® program or at authorized VTech

product service centers. Please call

1 (800) 8 BATTERY

for information on

Ni-MH battery recycling and disposal

bans/restrictions in your area. VTech’s

involvement in this program is part of its

commitment to protecting our environment

and conserving natural resources.

RBRC® and 1 (800) 8 BATTERY® are

registered trademarks of the

Rechargeable Battery Recycling

Corporation.

FCC, ACTA and IC

regulations

FCC Part 15

This equipment has been tested and

found to comply with the requirements

for a Class B digital device under Part

15 of the Federal Communications

Commission (FCC) rules. These

requirements are intended to provide

reasonable protection against harmful

interference in a residential installation.

This equipment generates, uses and

can radiate radio frequency energy and,

if not installed and used in accordance

with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does

cause harmful interference to radio

or television reception, which can be

determined by turning the equipment off

and on, the user is encouraged to try to

correct the interference by one or more

of the following measures:

Reorient or relocate the receiving

antenna.

Increase the separation between the

equipment and receiver.

Connect the equipment into an outlet

on a circuit different from that to which

the receiver is connected.

Consult the dealer or an experienced

radio/TV technician for help.

Changes or modiﬁcations to this

equipment not expressly approved by

the party responsible for compliance

could void the user’s authority to

operate the equipment.

This device complies with Part 15 of the

FCC rules. Operation is subject to the

following two conditions: (1) this device

may not cause harmful interference,

•

and (2) this device must accept

any interference received, including

interference that may cause undesired

operation. Privacy of communications

may not be ensured when using this

telephone.

To ensure safety of users, the FCC

has established criteria for the amount

of radio frequency energy that can be

safely absorbed by a user or bystander

according to the intended usage of the

product. This product has been tested

and found to comply with the FCC

criteria. The handset may be safely

held against the ear of the user. The

telephone base shall be installed and

used such that parts of the user’s body

other than the hands are maintained at

a distance of approximately 20 cm

(8 inches) or more.

This Class B digital apparatus complies

with Canadian requirement:

CAN ICES-3 (B)/NMB-3(B)

FCC Part 68 and ACTA

This equipment complies with

Part 68 of the FCC rules and with

technical requirements adopted by the

Administrative Council for Terminal

Attachments (ACTA). The label on

the back or bottom of this equipment

contains, among other things, a

product identiﬁer in the format US:

AAAEQ##TXXXX. This identiﬁer must

be provided to your telephone service

provider upon request.

The plug and jack used to connect this

equipment to premises wiring and the

telephone network must comply with

applicable Part 68 rules and technical

requirements adopted by ACTA. A

compliant telephone cord and modular

plug is provided with this product. It is

designed to be connected to a compatible

modular jack that is also compliant. An

RJ11 jack should normally be used for

connecting to a single line and an RJ14

jack for two lines. See the installation

instructions in the user’s manual.

The Ringer Equivalence Number (REN)

is used to determine how many devices

you may connect to your telephone

line and still have them ring when you

are called. The REN for this product is

encoded as the 6th and 7th characters

following the US: in the product identiﬁer

(e.g., if ## is 03, the REN is 0.3). In

most, but not all areas, the sum of

all RENs should be ﬁve (5.0) or less.

For more information, contact your

telephone service provider.

This equipment may not be used with

Party Lines. If you have specially wired

alarm dialing equipment connected

to your telephone line, ensure the

connection of this equipment does not

disable your alarm equipment. If you

have questions about what will disable

alarm equipment, consult your telephone

service provider or a qualiﬁed installer.

If this equipment is malfunctioning, it

must be unplugged from the modular jack

until the problem has been corrected.

Repairs to this telephone equipment can

only be made by the manufacturer or its

authorized agents. For repair procedures,

follow the instructions outlined under the

Limited warranty.

If this equipment is causing harm to

the telephone network, the telephone

service provider may temporarily

discontinue your telephone service. The

telephone service provider is required

to notify you before interrupting service.

If advance notice is not practical, you

will be notiﬁed as soon as possible. You

will be given the opportunity to correct

the problem and the telephone service

provider is required to inform you of

your right to ﬁle a complaint with the

FCC. Your telephone service provider

may make changes in its facilities,

equipment, operation, or procedures

that could affect the proper functioning

of this product. The telephone service

provider is required to notify you if such

changes are planned.

If this product is equipped with a corded

or cordless handset, it is hearing aid

compatible.

If this product has memory dialing

locations, you may choose to store

emergency telephone numbers (e.g.,

police, ﬁre, medical) in these locations.

If you do store or test emergency

numbers, please:

Remain on the line and brieﬂy explain

the reason for the call before hanging up.

Perform such activities in off-peak hours,

such as early morning or late evening.

Industry Canada

Operation is subject to the following

two conditions: (1) this device may not

cause harmful interference, and (2) this

device must accept any interference

received, including interference that

may cause undesired operation.

Privacy of communications may not be

ensured when using this phone.

The term ‘’IC:‘’ before the certiﬁcation/

registration number only signiﬁes

that the Industry Canada technical

speciﬁcations were met.

The Ringer Equivalence Number (REN)

for this terminal equipment is 0.1. The

REN is an indication of the maximum

number of devices allowed to be connected

to a telephone interface. The termination

on an interface may consist of any

combination of devices subject only to

the requirement that the sum of the RENs

of all the devices does not exceed ﬁve.

This product meets the applicable

Industry Canada technical

speciﬁcations.

California Energy

Commission battery

charging testing

instructions

This telephone meets the California Energy

Commission (CEC) regulations for energy

consumption. It is not necessary to activate

the energy conserving mode during normal

usage, unless you want to charge the battery

only and disable all telephone functions.

To activate the CEC battery charging

testing mode:

1. Unplug the telephone base power

adapter from the power outlet. Make sure

all handsets are plugged with charged

batteries before proceeding.

2. While you press and hold

/FIND HANDSET, plug the telephone base

power adapter back to the power outlet.

3. After about 20 seconds, when the

IN USE light starts ﬂashing, release

/FIND HANDSET and then press it again

within 2 seconds.

The process takes up to one minute to

complete. When the phone successfully

enters the CEC battery charging testing

mode, the IN USE light turns off and all

handsets display To register HS... and

...see manual alternately.

When the phone fails to enter this mode,

repeat Step 1 through Step 3 above. The

telephone base will be powered up as

normal if you fail to press /FIND HANDSET

within 2 seconds in Step 3.

To deactivate the CEC battery charging

testing mode:

1. Unplug the telephone base power adapter

from the power outlet, and then plug

it back in. Then the telephone base is

powered up as normal.

2. Place the handset in the telephone base

to register it back. The handset displays

Registering....

NOTE

The handset shows Registered and you

hear a beep when the registration process

completes. The registration process takes

about 90 seconds to complete.

•

For C-UL compliance only

Mesures de sécurité importantes

Aﬁn de réduire les risques d’incendie,

de blessures corporelles ou

d’électrocution, suivez toujours ces

mesures préventives de base lorsque

vous utilisez votre téléphone :

Lisez et comprenez bien toutes les

instructions.

Observez toutes les instructions

et mises en garde inscrites sur

l’appareil.

Débranchez ce téléphone de la prise

murale avant de le nettoyer. N’utilisez

pas de nettoyeurs liquides ni en

aérosol. N’utilisez qu’un chiffon doux

et légèrement humecté.

N’utilisez pas ce produit près de l’eau,

tel que près d’un bain, d’un lavabo,

d’un évier de cuisine, d’un bac de

lavage ou d’une piscine, ou dans un

sous-sol humide ou sous la douche.

Ne déposez pas ce téléphone sur un

chariot, support ou table chancelants.

L’appareil pourrait tomber et être

sérieusement endommagé.

Évitez d’installer le système

téléphonique dans les endroits

soumis à une température

extrême, à la lumière directe du

soleil ou à proximité immédiate

d’autres appareils électriques

ou électroniques. Protégez votre

téléphone contre les sources

d’humidité, la poussière, les vapeurs

et les liquides corrosifs.

Le boîtier de l’appareil est doté de

fentes et d’ouvertures d’aération

situées à l’arrière ou en dessous.

Aﬁn d’empêcher la surchauffe,

ces ouvertures ne doivent pas être

obstruées en plaçant l’appareil sur

un lit, divan, tapis ou autre surface

similaires. Ne placez pas cet

appareil à proximité d’un élément de

chauffage ni d’une plinthe électrique.

De plus, ne l’installez pas dans une

unité murale ou un cabinet fermé qui

ne possède pas d’aération adéquate.

Ne faites fonctionner cet appareil

qu’avec le type d’alimentation indiqué

sur les étiquettes de l’appareil. Si

vous ne connaissez pas le voltage

de votre maison, consultez votre

marchand ou votre fournisseur

d’électricité.

Ne déposez rien sur le cordon

d’alimentation. Installez cet appareil

dans un endroit sécuritaire, là où

personne ne pourra trébucher sur

la ligne d’alimentation ni le cordon

téléphonique modulaire.

N’insérez jamais d’objets à travers

les fentes et ouvertures de cet

appareil, car ils pourraient toucher

à des points de tension dangereux

ou court-circuiter des pièces, ce qui

constituerait un risque d’incendie ou

d’électrocution. N’échappez pas de

liquides dans l’appareil.

Aﬁn de réduire les risques

d’électrocution, ne démontez pas

l’appareil, mais apportez-le plutôt

à un centre de service qualiﬁé s’il

doit être réparé. En enlevant le

couvercle, vous vous exposez à des

tensions dangereuses ou autres

dangers similaires. Un remontage

inadéquat peut être à l’origine d’une

électrocution lors d’une utilisation

ultérieure de l’appareil. Débranchez

l’appareil avant de procéder au

nettoyage. Utilisez un chiffon humide

et doux.

Ne surchargez pas les prises de

courant et les rallonges.

Débranchez cet appareil de la prise

de courant et communiquez avec le

département de service à la clientèle

de VTech dans les cas suivants:

Lorsque le cordon d’alimentation

est endommagé ou écorché.

10.

11.

12.

13.

•

Si du liquide a été échappé dans

l’appareil.

Si l’appareil a été exposé à une

source d’humidité telle que la

pluie ou l’eau.

Si le produit ne fonctionne pas

normalement en respectant les

instructions de fonctionnement.

Réglez uniquement les

commandes indiquées dans le les

instructions de fonctionnement.

Les réglages incorrects des autres

commandes pourraient provoquer

un dommage qui pourrait exiger

un travail exhaustif de la part d’un

technicien autorisé aﬁn de rétablir

le fonctionnement normal de

l’appareil.

Si le produit a été échappé et que

le socle et/ou le combiné a été

endommagé.

Si le produit afﬁche une nette

diminution de sa performance.

14. Évitez d’utiliser un téléphone (autre

qu’un sans ﬁl) pendant un orage.

Les éclairs peuvent être à l’origine

d’une électrocution.

15. N’utilisez pas le téléphone pour

rapporter une fuite de gaz à

proximité de la fuite. En certaines

circonstances, une ﬂammèche

pourrait être provoquée lorsque

l’adaptateur est branché à une

prise de courant, ou lorsque le

combiné est déposé sur le socle.

Ceci est un événement commun

associé à la fermeture d’un circuit

électrique. L’utilisateur ne devrait pas

brancher le téléphone à une prise de

courant, et ne devrait pas déposer

le combiné chargé sur le socle, si

le téléphone se trouve à proximité

d’un endroit comportant des

concentrations de gaz inﬂammables,

à moins que la ventilation soit

adéquate. Une ﬂammèche dans

un tel endroit pourrait provoquer

•

un incendie ou une explosion.

De tels environnements peuvent

comprendre: des endroits où l’on

utilise de l’oxygène médical sans

ventilation adéquate; des gaz

industriels (dissolvants de nettoyage,

des vapeurs d’essence, etc.); une

fuite de gaz naturel, etc.

16. Ne placez que le combiné de votre

téléphone près de votre oreille

lorsqu’en mode de conversation.

17. Ces adaptateurs ont été conçus pour

être orientés en position verticale

ou montés au sol. Les broches ne

sont pas conçues pour maintenir

l’adaptateur en place si celui-ci est

barnché dans une prise au plafond

ou sous une table/ armoire.

CONSERVEZ CES INSTRUCTIONS

Pile

MISE EN GARDE : N’utilisez que la

pile incluse.

Ne jetez pas la pile au feu. Vérifiez

les instructions spécifiques de mise

aux rebus aupr

s des autorités

locales.

N’ouvrez pas et ne mutilez pas la

pile. L’électrolyte qui s’en échapperait

est corrosif et pourrait causer des

brûlures ou des blessures aux yeux

ou à la peau. L’électrolyte est toxique

si avalé.

Soyez prudents lorsque vous

manipulez les piles afin d’éviter les

courts-circuits provoqués par des

matériaux conducteurs.

Rechargez la pile incluse avec cet

appareil, selon les instructions et

limites spécifiées dans ce guide

d’utilisation.

Stimulateurs cardiaques implantés

dans l’organisme

Les simulateurs cardiaques (s’applique

uniquement aux téléphones numériques

•

sans fil):

L’organisme ‘Wireless Technology

Research, LLC (WTR)’, une firme

de recherche indépendante, a mené

une évaluation pluridisciplinaire des

interférences entre les téléphones

sans fil portatifs et les stimulateurs

cardiaques implantés dans l’organisme.

Appuyée par l’Administration des

aliments et drogues (FDA) des États-

Unis, la firme WTR recommande aux

médecins:

Avis aux détenteurs de stimulateurs

cardiaques

Ils doivent tenir le téléphone sans fil

à une distance d’au moins six pouces

du stimulateur cardiaque.

Ils ne doivent PAS placer le téléphone

sans fil directement sur le stimulateur

cardiaque, tel que dans une poche

de chemise, lorsque celui-ci est en

marche.

Ils doivent utiliser le téléphone sans

fil en l’appuyant sur l’oreille qui se

trouve dans la direction opposée au

stimulateur cardiaque.

L’étude effectuée par l’organisme WRS

n’a pas identifié de risque pour les

détenteurs de simulateurs cardiaques

causés par les gens qui utilisent un

téléphone sans fil à proximité de ceux-ci.

À propos des téléphones sans fil

Alimentation électrique: Les mêmes

caractéristiques qui constituent

des avantages pour les téléphones

sans fil affichent également des

restrictions. Les appels téléphoniques

sont transmis entre le combiné sans

fil et le socle par le biais d’ondes

radio ; il y a donc la possibilité que

vos conversations téléphoniques

sans fil soient interceptées par

des équipements de réception

radio se trouvant dans la portée du

combiné sans fil. Pour cette raison,

•

vous ne devez pas percevoir les

communications téléphoniques sans fil

comme étant aussi confidentielles.

Alimentation électrique: Le socle

de ce téléphone sans fil doit être

branché à une prise électrique

fonctionnelle. La prise électrique

ne doit pas être contrôlée par un

interrupteur mural. Les appels ne

pourront pas être effectués du

combiné sans fil si le socle est

débranché ou mis hors tension ou si

le courant est coupé.

Possibilité d’interférences aux

téléviseurs: Certains téléphones

sans fil fonctionnent sur des

fréquences pouvant causer des

interférences aux téléviseurs et aux

magnétoscopes. Pour réduire ou

prévenir de telles interférences, ne

placez pas le socle du téléphone

sans fil près ou sur un téléviseur ou

magnétoscope. S’il y a présence de

parasites, il est conseillé d’éloigner

le téléphone sans fil du téléviseur

ou du magnétoscope afin de réduire

possiblement les interférences.

Piles rechargeables: Manipulez

les piles avec soin afin de ne pas

les court-circuiter avec des bagues,

bracelets ou clés. Les piles ou le

conducteur peut surchauffer et

causer des blessures. Respectez la

polarité adéquate entre la pile et le

chargeur.

Les bloc-piles rechargeables à

l’hydrure métallique de nickel:

Jetez ces blocs-piles de manière

écologique et sécuritaire. Ne les

incinérez pas et ne les percez pas.

Tel que les autres piles de ce type,

elles pourraient dégager une matière

toxique qui peut causer des blessures

corporelles si elles sont brûlées ou

percées.

•

Limited warranty

What does this limited warranty cover?

The manufacturer of this VTech Product

warrants to the holder of a valid proof of

purchase (“Consumer” or “you”) that the

Product and all accessories provided

in the sales package (“Product”)

are free from defects in material and

workmanship, pursuant to the following

terms and conditions, when installed

and used normally and in accordance

with the Product operating instructions.

This limited warranty extends only to the

Consumer for Products purchased and

used in the United States of America

and Canada.

What will VTech do if the Product is

not free from defects in materials

and workmanship during the

limited warranty period (“Materially

Defective Product”)?

During the limited warranty period,

VTech’s authorized service

representative will repair or replace

at VTech’s option, without charge, a

Materially Defective Product. If we

repair the Product, we may use new or

refurbished replacement parts. If we

choose to replace the Product, we may

replace it with a new or refurbished

Product of the same or similar design.

We will retain defective parts, modules,

or equipment. Repair or replacement of

the Product, at VTech’s option, is your

exclusive remedy. VTech will return the

repaired or replacement Products to

you in working condition. You should

expect the repair or replacement to take

approximately 30 days.

How long is the limited warranty

period?

The limited warranty period for the

Product extends for ONE (1) YEAR from

the date of purchase. If VTech repairs or

replaces a Materially Defective Product

under the terms of this limited warranty,

this limited warranty also applies to

the repaired or replacement Product

for a period of either (a) 90 days from

the date the repaired or replacement

Product is shipped to you or (b) the

time remaining on the original one-year

warranty; whichever is longer.

What is not covered by this limited

warranty?

This limited warranty does not cover:

Product that has been subjected

to misuse, accident, shipping or

other physical damage, improper

installation, abnormal operation or

handling, neglect, inundation, ﬁre,

water or other liquid intrusion; or

Product that has been damaged due

to repair, alteration or modiﬁcation

by anyone other than an authorized

service representative of VTech; or

Product to the extent that the

problem experienced is caused by

signal conditions, network reliability,

or cable or antenna systems; or

Product to the extent that the

problem is caused by use with non-

VTech accessories; or

Product whose warranty/quality

stickers, product serial number plates

or electronic serial numbers have

been removed, altered or rendered

illegible; or

Product purchased, used, serviced,

or shipped for repair from outside the

United States of America or Canada,

or used for commercial or institutional

purposes (including but not limited to

Products used for rental purposes); or

Product returned without a valid proof

of purchase (see item 2 on the next

page); or

Charges for installation or set up,

adjustment of customer controls,

and installation or repair of systems

outside the unit.

How do you get warranty service?

To obtain warranty service in the United

States of America, please visit our

website at www.vtechphones.com or

call 1 (800) 595-9511. In Canada, go to

www.vtechcanada.com or dial

1 (800) 267-7377.

NOTE: Before calling for service, please

review the user’s manual - a check of

the Product’s controls and features may

save you a service call.

Except as provided by applicable law,

you assume the risk of loss or damage

during transit and transportation and

are responsible for delivery or handling

charges incurred in the transport of

the Product(s) to the service location.

VTech will return repaired or replaced

Product under this limited warranty.

Transportation, delivery or handling

charges are prepaid. VTech assumes no

risk for damage or loss of the Product

in transit. If the Product failure is not

covered by this limited warranty, or proof

of purchase does not meet the terms of

this limited warranty, VTech will notify

you and will request that you authorize

the cost of repair prior to any further

repair activity. You must pay for the

cost of repair and return shipping costs

for the repair of Products that are not

covered by this limited warranty.

What must you return with the

Product to get warranty service?

Return the entire original package

and contents including the Product to

the VTech service location along with

a description of the malfunction or

difﬁculty; and

Include a “valid proof of purchase”

(sales receipt) identifying the Product

purchased (Product model) and the

date of purchase or receipt; and

Provide your name, complete

and correct mailing address, and

telephone number.

Other limitations

This warranty is the complete and

exclusive agreement between you

and VTech. It supersedes all other

written or oral communications related

to this Product. VTech provides no

other warranties for this Product. The

warranty exclusively describes all of

VTech’s responsibilities regarding the

Product. There are no other express

warranties. No one is authorized to

make modiﬁcations to this limited

warranty and you should not rely on any

such modiﬁcation.

State/Provincial Law Rights: This

warranty gives you speciﬁc legal

rights, and you may also have other

rights, which vary from state to state or

province to province.

Limitations: Implied warranties,

including those of ﬁtness for a particular

purpose and merchantability (an

unwritten warranty that the Product is

ﬁt for ordinary use) are limited to one

year from the date of purchase. Some

states/provinces do not allow limitations

on how long an implied warranty lasts,

so the above limitation may not apply to

you. In no event shall VTech be liable

for any indirect, special, incidental,

consequential, or similar damages

(including, but not limited to lost proﬁts

or revenue, inability to use the Product

or other associated equipment, the cost

of substitute equipment, and claims by

third parties) resulting from the use of

this Product. Some states/provinces do

not allow the exclusion or limitation of

incidental or consequential damages,

so the above limitation or exclusion may

not apply to you.

Please retain your original sales

receipt as proof of purchase.

Technical specifications

Frequency

control

Crystal controlled PLL

synthesizer

Transmit

frequency

Handset:

1921.536-1928.448 MHz

Telephone base:

1921.536-1928.448 MHz

Channels 5

Nominal

effective

range

Maximum power allowed

by FCC and IC. Actual

operating range may vary

according to environment

conditions at the time of

use.

Power

requirements

Handset: 2.4V Ni-MH

battery

Telephone base:

6V DC @ 400mA

Charger: 6V AC @ 300mA

Memory Handset directory:

50 memory locations;

up to 30 digits and

15 characters

Handset caller ID log:

50 memory locations;

up to 24 digits and

15 characters

VTech Communications, Inc.

A member of THE VTECH GROUP OF COMPANIES.

VTech is a registered trademark of VTech Holdings Limited.

Speciﬁcations are subject to change without notice.

Document order number: 91-007177-030-100

Designed to ﬁt your home.

And your life.

VTech CS6859 2 User Manual To The C68d058e 500f 4731 8b45 1404c1b63603

Navigation menu

Versions of this User Manual:

Views

Navigation
