VXi BlueParrott®B350-XT™

Quick-Start Guide

Wearing and Adjusting the B350-XT

To get the best performance from our noise-canceling technology, position the microphone near the corner of your mouth.

Positioning is important; small adjustments in microphone placement can improve performance.

1) Place the headset on your head.

2) Position the speaker directly on your ear. You can slide the headband in or

out of the side support for proper fit.

3) Position the microphone about one finger’s width away from your face at the corner of your mouth.

4) The headband can be adjusted by gently flexing it outward to loosen or inward to tighten.

Charging

Connect charger cord to the headset’s charging port. The headset LED will glow red when charging and blue when fully

charged.

Turning Headset On/Off

Turn Headset On: Hold down the MFB for approximately 2-3 seconds, until you hear a voice prompt,

“Power On.” The blue light will flash twice every second.

Turn Headset Off: Hold down the MFB for approximately 3-4 seconds, until you hear a voice prompt,

“Power Off.” A red light will flash 4 times and the headset will turn off.

One-Touch Pairing (NFC)

1) Make sure that NFC is enabled on your cell phone.

2) Place the NFC zone of your cell phone against the NFC zone of the

headset and hold together until your cell phone confirms pairing is successful.

Note: NFC and One-Touch Pairing are dependent on your cell phone. The size

and sensitivity of your phone’s NFC zone and the specific way to connect the

headset may vary between devices.

Manual Pairing

Placing Headset into Pairing Mode: With the headset powered off, press and hold the MFB. You will hear the voice prompt

“Power On”. Keep holding the MFB for approximately 10 seconds, until you hear “Discovering”. Indicator lights will

alternately flash between red and blue. Headset will be visible for pairing to devices for 120 seconds.

Pairing to a Cell Phone:

1) Make sure that other Bluetooth devices are turned off or out of range.

2) Place headset into pairing mode.

3) Put your cell phone in Bluetooth Search/Scan Mode per the manufacturer’s instructions.

4) Select “VXi B350-XT” to pair. (Passcode is “0000” if needed.)

5) When connected, the headset will give you the voice prompt, “Your headset is connected”.

Multi-Point Mode

In multi-point mode, the headset can be simultaneously paired and connected to two cell phones. The headset will

automatically switch between phones when there is an incoming call.

To use Multi-Point:

1) Pair each device you wish to use with the headset. Power off the headset.

2) Enable Bluetooth, or power on both paired devices, then power on the headset.

3) You should hear the voice prompt “Your headset is connected” twice, as the headset connects to each device.

Parrott Button

The Parrott Button provides an easy way to mute the headset. In the future, it will also be programmable for other functions.

Check back at www.vxicorp.com for updates and more information.

IMPORTANT: CHARGE HEADSET FULLY PRIOR TO FIRST USE

IMPORTANT SAFETY NOTE: Prolonged exposure to high volume levels can damage your hearing. To avoid injury, set the

volume to the lowest comfortable level. If you experience ringing in your ears, or voices sound muffled, stop using the

headset. Avoid turning up the volume to block noisy surroundings. Your ears may adapt to volume that is too high,

which could result in permanent hearing damage without any noticeable discomfort.

1. B350-XT™ Headset

2. Spare Foam Ear Cushion

3. Spare Microphone Windscreen

4. USB Charging Cable

5. Auto Adapter

6. AC/DC Wall Charger

7. Quick-Start Guide

Features and Functions

A. Flexible Microphone Boom

B. Volume Down

C. Volume Up/Mute

D. Multifunction Button (MFB)

E. Indicator Lights

F. Parrott Button

Package Contents

Function

Power On

Power Off

Enable Pairing Mode

Volume Up

Volume Down

Mute (On/Off)

Answer a Call/Active Call

End a Call

Transfer Audio

Low Battery

Button/Duration of Press

MFB (2-3 seconds)

MFB (3-4 seconds)

MFB (5-15 seconds)

Volume Up (quick press)

Volume Down (quick press)

Parrott Button (quick press)

MFB (quick press)

Volume Down (1-2 seconds)

n/a

LED Indicator

Blue, double flash (1 second)

All LEDs turn off

Alternating red and blue flash

NONE

Blue flash, once per second

Blue flash, every 4 seconds

NONE

Red flash

Audio Indicator

Short tone

NONE

Single tone

Single tone, reminder

tone every 10 seconds

Two rising tones

Two falling tones

NONE

Voice Indicator

“Power on”

“Power off”

“Discovering”

NONE

“Battery low”

Quick-Reference Tables

Multiple Device Pairing and Advanced Features

The VXi BlueParrott B350-XT can pair with up to eight (8) devices. However, only two (2) devices may be connected to the

headset at one time (Multi-Point). For more information on advanced features, please refer to the complete user guide,

available online.

For the full user guide, technical notes, and available accessories, go to www.vxicorp.com.

Function

Power On

Power Off

Enable Pairing Mode

Volume Up

Volume Down

Mute (On/Off)

Answer a Call/Active Call

End a Call

Transfer Audio

Low Battery

Button/Duration of Press

MFB (2-3 seconds)

MFB (3-4 seconds)

MFB (5-15 seconds)

Volume Up (quick press)

Volume Down (quick press)

Parrott Button (quick press)

MFB (quick press)

Volume Down (1-2 seconds)

n/a

LED Indicator

Blue, double flash (1 second)

All LEDs turn off

Alternating red and blue flash

NONE

Blue flash, once per second

Blue flash, every 4 seconds

NONE

Red flash

Audio Indicator

Short tone

NONE

Single tone

Single tone, reminder

tone every 10 seconds

Two rising tones

Two falling tones

NONE

Voice Indicator

“Power on”

“Power off”

“Discovering”

NONE

“Battery low”

Multiple Device Pairing and Advanced Features

The VXi BlueParrott B350-XT can pair with up to eight (8) devices. However, only two (2) devices may be connected to the

headset at one time (Multi-Point). For more information on advanced features, please refer to the complete user guide,

available online.

For the full user guide, technical notes, and available accessories, go to www.vxicorp.com.

271 Locust Street

Dover, NH 03820

Toll Free: 800-742-8588

Phone: 603-742-2888

www.vxicorp.com

VXi BlueParrott®B350-XT™

Quick-Start Guide

Wearing and Adjusting the B350-XT

To get the best performance from our noise-canceling technology, position the microphone near the corner of your mouth.

Positioning is important; small adjustments in microphone placement can improve performance.

1) Place the headset on your head.

2) Position the speaker directly on your ear. You can slide the headband in or

out of the side support for proper fit.

3) Position the microphone about one finger’s width away from your face at the corner of your mouth.

4) The headband can be adjusted by gently flexing it outward to loosen or inward to tighten.

Charging

Connect charger cord to the headset’s charging port. The headset LED will glow red when charging and blue when fully

charged.

Turning Headset On/Off

Turn Headset On: Hold down the MFB for approximately 2-3 seconds, until you hear a voice prompt,

“Power On.” The blue light will flash twice every second.

Turn Headset Off: Hold down the MFB for approximately 3-4 seconds, until you hear a voice prompt,

“Power Off.” A red light will flash 4 times and the headset will turn off.

One-Touch Pairing (NFC)

1) Make sure that NFC is enabled on your cell phone.

2) Place the NFC zone of your cell phone against the NFC zone of the

headset and hold together until your cell phone confirms pairing is successful.

Note: NFC and One-Touch Pairing are dependent on your cell phone. The size

and sensitivity of your phone’s NFC zone and the specific way to connect the

headset may vary between devices.

Manual Pairing

Placing Headset into Pairing Mode: With the headset powered off, press and hold the MFB. You will hear the voice prompt

“Power On”. Keep holding the MFB for approximately 10 seconds, until you hear “Discovering”. Indicator lights will

alternately flash between red and blue. Headset will be visible for pairing to devices for 120 seconds.

Pairing to a Cell Phone:

1) Make sure that other Bluetooth devices are turned off or out of range.

2) Place headset into pairing mode.

3) Put your cell phone in Bluetooth Search/Scan Mode per the manufacturer’s instructions.

4) Select “VXi B350-XT” to pair. (Passcode is “0000” if needed.)

5) When connected, the headset will give you the voice prompt, “Your headset is connected”.

Multi-Point Mode

In multi-point mode, the headset can be simultaneously paired and connected to two cell phones. The headset will

automatically switch between phones when there is an incoming call.

To use Multi-Point:

1) Pair each device you wish to use with the headset. Power off the headset.

2) Enable Bluetooth, or power on both paired devices, then power on the headset.

3) You should hear the voice prompt “Your headset is connected” twice, as the headset connects to each device.

Parrott Button

The Parrott Button provides an easy way to mute the headset. In the future, it will also be programmable for other functions.

Check back at www.vxicorp.com for updates and more information.

IMPORTANT SAFETY NOTE: Prolonged exposure to high volume levels can damage your hearing. To avoid injury, set the

volume to the lowest comfortable level. If you experience ringing in your ears, or voices sound muffled, stop using the

headset. Avoid turning up the volume to block noisy surroundings. Your ears may adapt to volume that is too high,

which could result in permanent hearing damage without any noticeable discomfort.

1. B350-XT™ Headset

2. Spare Foam Ear Cushion

3. Spare Microphone Windscreen

4. USB Charging Cable

5. Auto Adapter

6. AC/DC Wall Charger

7. Quick-Start Guide

Features and Functions

A. Flexible Microphone Boom

B. Volume Down

C. Volume Up/Mute

D. Multifunction Button (MFB)

E. Indicator Lights

F. Parrott Button

Package Contents

NFC Zone

IMPORTANT: CHARGE HEADSET FULLY PRIOR TO FIRST USE

Quick-Reference Tables

271 Locust Street

Dover, NH 03820

Toll Free: 800-742-8588

Phone: 603-742-2888

www.vxicorp.com

VXiWarrantyandComplianceStatementsforWirelessProducts



VXiWARRANTYSTATEMENT



(1)VXiwarrantsthatyourproductwillbefreefromdefectsinmaterialandworkmanshipforoneyearfrom

thedateofpurchase.If,duringthefirstyearfromthedateofpurchase,yourproductfailstoworkduetoa

defectinmaterialorworkmanship,VXiwillrepairorreplacetheproduct,atitselection,freeofcharge.

Withoutproofofpurchase,thewarrantyperiodbeginsonthedateofmanufacture.Consumablecomponents

(forexample,cushions,batteryandfuse)arenotincludedinthisone‐yearwarranty.(2)Theforegoinglimited

warrantydoesnotcoverequipmentfailureattributabletoaccident,improperoperation,misuse,abuse,or

anycauseotherthandefectsinthematerialsorworkmanshipofVXi’sproducts.(3)VXi’sobligationsunder

thiswarrantyarelimitedtorepairorreplacement(atouroption)ofanydefectivepartreturnedtoVXiatthe

customer’sexpense.ReturnedproductsrequireaReturnAuthorizationthatmaybeobtainedbycalling603‐

742‐2888orvisitingwww.vxicorp.com.ProductsreturnedtoVXiforrepairunderthiswarrantywillbereturn

shippedtothecustomeratVXi’sexpense.(4)THISLIMITEDWARRANTYISINLIEUOFALLOTHER

WARRANTIES,EXPRESSEDORIMPLIED,INCLUDINGTHEIMPLIEDWARRANTIESOFMERCHANTABILITYAND

FITNESSFORAPARTICULARPURPOSE.Somejurisdictionsdonotpermittheexclusionofimpliedwarranties

andtheforegoingexclusionsmaynotapplytoyou.(5)InnoeventshallVXiberesponsibleforanyother

damageswhatsoever,includingdirect,indirect,special,incidental,consequential,orotherdamagesforbreach

ofthisoranyotherwarranty,expressedorimplied.



FCCNOTICETOUSERS



Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwoconditions:(1)

Thisdevicemaynotcauseharmfulinterference,and(2)Thisdevicemustacceptanyinterferencereceived,

includinginterferencethatmaycauseundesiredoperation.Usersarenotpermittedtomakechangesor

modifythedeviceinanyway.ChangesormodificationsnotapprovedbyVXiCorporationwillvoidtheuser’s

authoritytooperatetheequipment.NOTE:Thisequipmenthasbeentestedandfoundtocomplywiththe

limitsforaClassBdigitaldevicepursuanttopart15oftheFCCrules.Theselimitsaredesignedtoprovide

reasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,

usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,

maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterference

willnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor

televisionreception,whichcanbedeterminedbyturningtheequipmentonandoff,theuserisencouragedto

trytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

–Reorientorrelocatethereceivingantennae.

–Increasetheseparationbetweentheequipmentandthereceiver.

–Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.

–Consultthedealeroranexperiencedradio/TVtechnicianforhelp.



ICNOTICETOCANADIANUSERS



ThisdevicecomplieswithIndustryCanadalicense‐exemptRSSstandard(s).Operationissubjecttothe

followingtwoconditions:(1)Thisdevicemaynotcauseinterference,and(2)Thisdevicemustacceptany

interference,includinginterferencethatmaycauseundesiredoperationofthedevice.Thisdevicecomplies

withRSS‐310ofIndustryCanada.Operationissubjecttotheconditionthatthisdevicedoesnotcauseharmful

interference.ThisClassBdigitalapparatuscomplieswithCanadianICES‐003(Cetappareilnumériquedela

ClasseBconformeàlanormeNMB‐003duCanada).

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de

licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de

brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le

brouillage est susceptible d'en compromettre le fonctionnement.



CENOTICETOUSERS



Item1.(Temperature)

Donotusetheheadsetintheenvironmentattoohighortoolowtemperature,

neverexposetheheadsetunderstrongsunshineortoowetenvironment.

Thesuitabletemperaturefortheheadsetandaccessoriesis5C‐50C.



Whencharging,pleaseplacetheheadsetinanenvironmentthathasanormalroom

temperatureandgoodventilation.Itisrecommendedtochargetheheadsetinanenvironment

withatemperaturethatrangesfrom5C~50C.Pleaseensuretouseonlythechargeroffered

bythemanufacturer.Usingunauthorizedchargermaycausedangerandviolatetheauthorizationofthe

headsetandtheguarantee.



Themaximumoperatingambienttemperatureoftheequipmentdeclaredbythemanufactureris50Ԩ



Item2.(SoundPressure)

Excessivesoundpressurefromearphonesandheadphonescancausehearingloss.



Item3.RTTE

EURegulatoryConformance

ThisequipmentisincompliancewiththeessentialrequirementsandotherrelevantprovisionsofDirective

1999/5/EC.



271LocustStreet|Dover,NH03820|TollFree:800‐742‐8588|Phone:603‐742‐2888|www.vxicorp.com



VXI 203475 BLUETOOTH HEADSET User Manual

VXI Corporation BLUETOOTH HEADSET

User Manual

Navigation menu

Namespaces

Views

Navigation
