Valve 1004 SteamVR Tracking 2.0 Base Station User Manual Warning

Valve Corporation SteamVR Tracking 2.0 Base Station Warning

Contents

Warning

SteamVR Tracking 2.0 Base Station
Safe Setup, Use, and Care
Follow these instructions for the safe setup, use, and care of the SteamVR Tracking 2.0
Base Stations (“Base Stations”) to reduce the risk of tripping, entanglement, or colliding with the Base
Stations and electrical and fire hazards. Additionally, read the user documentation provided by the
manufacturer of your Virtual Reality Kit (“VR Kit”) for full system instructions and safety information.
Base Station Components
Each Base Station box includes the following items:
• Base Station(s)
• Mounting kits
• Power cord
• Regional electric plug adaptors
• Power supplies
Setting up the Base Stations
1. Plan a safe play area. Follow the guidance provided by the manufacturer of your VR Kit. In general,
when creating a safe play area:
• Choose a play space that gives you enough room that your outstretched arms, including
controllers, will not touch walls or objects around you, including anything above you such as
ceiling, fans, or lights.
• Be sure there is nothing dangerous around the play space. For example, do not set up your play
area near windows, balconies, stairs or other places you could fall.
• Clear the floor of things that could make you trip or slip.
• Clear the area of things you could collide with.
• Take precautions to keep pets and children from entering the play area.
2. Select locations for your Base Stations.
• The included Base Station mounting kit may be used for placement on a wall or ceiling, or the
Stations may be placed on a stable bookshelf, light stand, cargo pole, or tripod. The Base
Stations should be securely attached.
• Locate Base Stations outside of the play area, far enough that a player will not strike them. The
Base Stations are precision electronic devices and drops, bumps or other contact may negatively
affect performance.
• Space Base Stations appropriately. Set up your Base Stations near electrical outlets and at
opposite corners of your space, diagonally and above head height, ideally more than 2 meters
(6.5 feet) high. For proper tracking, make sure the two Base Stations are not more than 5 meters
(16 feet) apart. Avoid areas with bright light, which might degrade the performance of the Base
Stations.
3. Mount the Base Stations according to the mounting kit instructions.
4. Use only the Base Station power supply accompanying your VR Kit. The power supply has a unique
adapter designed to fit in the Base Station. Other power supplies that are not designed to work with
the Base Station may pose an electrical or fire hazard.
5. Safely route electrical cords, so they are clear of the play area or any area that may lead to tripping
or entanglement with the cords.
6. Follow instructions provided by the manufacturer of your VR kit to complete setup.
Use and care
1. Base Station care and cleaning. Keep the Base Stations dry and away from liquids. Exposing the
Base Station power supplies to liquid could create a shock hazard. If you need to clean the Base
Stations, unplug, then use a lightly moistened cloth. Do not use cleaning chemicals; these may
damage the Base Stations.
2. Humidity. If you operate the Base Stations in an area with high humidity, moisture may collect in
the Base Stations causing them to operate incorrectly. If that occurs, stop using the Base Stations
until the moisture evaporates.
3. Do not attempt to open or service the Base Stations. Contact the manufacturer of your VR Kit if
there is a problem.
4. Radio Frequency and potential medical device interference.
• Each Base Station contains radio-emitting technology that may interfere with the normal
operation of nearby electronic devices. It uses a 2.4GHz BLUETOOTH® -band radio with GFSK
modulation and custom low-latency protocol. While it has been tested for non-interference with
common devices, do not operate around critical electronic equipment (e.g. in hospitals).
• Consult your doctor prior to using the Base Stations if you have implanted electronic devices
(e.g. pacemaker) to confirm that these devices will not be impacted. Do not use the Base
Stations if your medical device will be affected by the emitted radio waves.
SteamVR Tracking 2.0 Base Station Regulatory Information
United States
FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT
SteamVR Tracking 2.0 Base Station FCC ID: 2AES41004
This equipment is tested to comply with FCC (Federal Communication Commission) Standards. For home
and office use. Not intended for use in machinery, medical, or industrial applications. This device is for
use with NRTL- listed (UL, CSA, ETL etc.) and/or IEC/EN 60950 compliant (CE marked) IT equipment. No
serviceable parts included.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy. If not installed and used in accordance with the instructions, it may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
and correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna-Increase the distance between the equipment and the
receiver.
-Connect the equipment to outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Warning: The FCC requires that you be notified that any changes or modifications to this device not
expressly approved by the manufacturer could void the user’s authority to operate the equipment.
NOTE: The base station should be installed and operated with a minimum distance of 20 cm between
the base station and any person to comply with RF exposure guidelines.
CANADA
INDUSTRY CANADA (IC)
SteamVR Tracking 2.0 Base Station IC ID: 20207 -1004
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interferences, and (2) this device must accept
any interferences, including interferences that may cause undesired operation of the device.
Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s). L‘utilisation de ce
dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et 6
Safety Manual Draft August 17, 2017
(2) l’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce
brouillage est susceptible de compromettre le fonctionnement du dispositif.
Complies with the Canadian ICES-003 Class B specifications.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Complies with the
Canadian ICES-003 Class B specifications.
EUROPEAN ECONOMIC AREA
This device bears the CE mark in accordance with Directive 2014/53/EU. Hereby, Valve Corporation
declares that this SteamVR Tracking 2.0 Base Station is in compliance with the essential requirements
and other relevant provisions of Directive 2014/53/EU, and may be operated in all European Economic
Area (EEA) countries.
Model 1004: Operating frequencies: 2400-2483.5MHz, max EIRP: 6.24 dBm +/- 1.5 dBi.
The full declaration of conformity can be found at: http://compliance.steampowered.com/
PROPER HANDLING OF WASTE ELECTRONIC EQUIPMENT
This symbol on the product(s) and/or accompanying documents means that used electrical and
electronic products should not be mixed with general household waste. This symbol is only valid in the
European Union. For proper treatment, recovery, and recycling, please take this product(s) to
designated collection points where it will be accepted free of charge
LASER WARNING
CLASS 1 LASER PRODUCT
CAUTION - Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure.
ATTENTION – L’utilisation de commandes ou de réglages ou l’exécution de procédures autres que celles
spécifiées ici peut entraîner une exposition à des radiations dangereuses.
VARNING - Användande av kontroller eller justeringar eller utföranden av tillvägagångssätt andra än de
som är specificerade häri kan orsaka risk för strålningsexponering.
The SteamVR™ Tracking 2.0 Base Station contains a Class 3B laser, which can produce hazardous levels
of laser radiation. However, the design of this product incorporates optics, a protective housing and a
scanning safe guard such that there is no access to levels of laser radiation above Class 1. Under no
circumstances should this device be operated with the housing removed. Only trained factory
personnel should open the protective housing.
Complies with FDA performance standards for laser products except for deviations pursuant to Laser
Notice No. 50, dated June 24, 2007. Evaluated to IEC 60825-1:2014
There are no serviceable parts.
Radiation emission
This device emits radio frequency (RF) signals. It uses a 2.4GHz BLUETOOTH® band radio with GFSK
modulation and custom low-latency protocol. While it has been tested for non-interference with
common devices, do not operate around critical electronic equipment (e.g. in hospitals) and remove
batteries completely before transport by airplane.
KOREA
해당무선설비기기는 운용중 전파혼신가능성이 있음
TAIWAN
這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾，在這種情況下，使用者會
被要求採取某些適當的對策
NCC 警語
低功率電波輻射性電機管理辦法
第十二條經型式認證合格之低功率射頻電機，非經許可，公司、商號或使
用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。
第十四條低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發
現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信規定作業之無線電信。低功率射頻電機須忍受合法通信
或工業、科學及醫療用電波輻射性電機設備之干擾
Internet Connection
An internet connection is required to access and use the Steam Client software. You are responsible for
any Internet service fees.
RESPONSIBLE PARTY
Valve Corporation
10400 NE 4th St
Suite 1400
Bellevue, WA 98004, USA
MISC
© 2017 Valve Corporation. All rights reserved. Valve and Steam are trademarks and/or registered
trademarks of Valve Corporation in the US and other countries. All other trademarks are property of
their respective owners.
