Specifications EUM3006

LMS4000 Technical Specifications
WaveRider EUM3006 Outdoor Modem with Integrated Antennna and Power over Ethernet
WaveRider’s LMS4000 is the world’s most advanced NLOS (non-line-of-sight) broadband
wireless system designed specifically for the 900 MHz spectrum.
The EUM3006 Integrated Outdoor Modem is the latest modem for the LMS4000 system and
significantly enhances key system capabilities: outdoor unit with extended temperature range;
integrated, high-gain, active diversity antenna; 802.3af compatible, 48 VDC Power over
Ethernet; higher output power; improved Rx Sensitivity; DHCP Enabled; Auto CCU Discovery,
Automatic Remote Configuration; easy-to-use Setup menu and MDB1000 alignment tools; VoIP
support.
Features
The EUM3006 is a major step in the evolution of the LMS4000 900MHz Wireless
Internet Modems offered by WaveRider. It has many new features that provide
improved RF performance, ease of installation, and improved remote management.
These features include:
Outdoor Installation
The EUM3006 is tested to meet ETSI 300-019 environmental standards for outdoor
installations, with an extended temperature range of -40º C to 50º C plus solar
loading. The EUM3006 can also work in uninhabited indoor locations, such as attics,
if there is an adequate RF signal. The advantages of an integrated outdoor unit
include:
• More flexible installations.
• Improved range since there are no RF losses from long cable runs.
• Lower installation costs.
Integrated high-gain, diversity antenna
There are many advantages to the EUM3006’s integrated antenna:
• Integrated, so that there are no RF losses due to long cable runs.
• High-gain (10 dBi), so that the EUM3006 can generate the maximum RF
signal allowed by FCC and increase the overall operating range.
• Active diversity, which is done on a packet by packet basis, so that the
EUM3006 performs better in a multi-path fading environment.
• Polarization diversity, so that the installer need not worry about what
polarization the CCU is. Sector polarization can be readily changed at the
base stations, with the EUMs automatically adjusting.
EUM3006
900 MHz Non-Line-of-Sight Integrated
Outdoor Modem
LMS4000 Advantages
Over-the-air data rates of
2.75 Mbps and access
speeds of 2.0 Mbps
Average range of 5 miles
NLOS, outdoor
LOS range up to 25 miles
Up to 300 users per base
station radio
Dynamic Polling MAC
VoIP support
Built-in spectrum analyzer
Mobile-survey utility
Supports RADIUS AAA
SNMP management
PPPoE support
Supports a profitable
business model
EUM3006 Outdoor Modem
LMS4000 Technical Specifications
Power over Ethernet (PoE)
The EUM3006 is powered by standard 48 VDC Power over Ethernet (802.3af Mode B compatible). Since the antenna is
integrated, there is no need for an RF cable. With PoE, there is no need for a separate power and Ethernet cable. So the
EUM3006 has only one standard flexible cable, making installation simpler.
Using 48 VDC power allows the EUM3006 to have up to 100 m of Ethernet cable to the end-user’s PC, which is the
maximum by the Ethernet standard. The PoE injector can be located anywhere along this 100 m of cable. This provides
great flexibility in placing the EUM3006 to get the best RF signal.
Higher RF Power
Taking advantages of changes to the FCC rules, the EUM3006 makes best use of its high-gain antenna to generate a full
36 dBm AVERAGE EIRP out of the antenna. This represents an increase of about 4 dB from the previous generations of
EUMs with approved high gain antenna systems.
Improved RX Sensitivity
Each EUM3006 is tested to ensure that its RX Sensitivity is -89 dBm or better (average received signal). Combined with
the antenna gain of 10 dBi, the EUM3006 can receive signals at -99 dBm.
DHCP Client
The EUM3006 can obtain its IP address, subnet mask and IP gateway information from a DHCP server, reducing the
amount of configuration needed for installation. This also allows the Network Operator to re-assign IP addresses to EUMs
without having to access the EUM itself.
Auto CCU Discovery
The EUM3006 searches the full RF frequency range to locate CCUs. It then selects the CCU with the best RF signal that
allows it to register. With this and DCHP Client enabled (factory defaults), the installer does not need to enter ANY
configuration parameters into the EUM3006 in order to install it.
Automatic Remote Configuration
The EUM3006 will accept parameters from a RADIUS server to set other configurable parameters in the modem. These
parameters include: password, all SNMP parameters, RF Frequency (including enabling auto-discovery), and number of
customers.
Installation Tools
The EUM3006 has two new tools to make installation and alignment easy and error-free.
• MDB1000 - This hand-held, battery-powered device displays detailed key signal quality information to allow the
EUM3006 to be located and aligned to the best RF signal possible by a single installer. The MDB1000 can be in
any position near the EUM3006 to provide easy viewing.
• SETUP Menu - The EUM3006 supports the local link IP address, 169.254.10.250, on its Ethernet port at all times.
Using the local-link address, any user can use the password “setup” to call up the setup menu that allows any
user to check the RF link quality to help align the EUM3006 and troubleshoot the link. This avoids needing to
know the IP address and password of the modem.
LMS4000 Technical Specifications
EUM3006 Integrated Outdoor Specifications
Radio Specifications
Operating Frequency 902 to 928 MHz
Radio Type DSSS
Radio Modulation Complementary Code Keying (CCK)
Average Output Power +36 to 25 dBm EIRP (software selectable)
RF Rx Threshold -89 dBm (BER<10-6 ) internal antenna port, not including antenna gain
Minimum/Maximum Center Channel Frequency 905/925 MHz
Channel Bandwidth 5.5 MHz
Center Frequency Spacing Increment 0.2 MHz
Orthogonal Channels 4
Orthogonal Channel Separation 6.6 MHz
Radio Performance
Maximum Over-the-Air Raw Data Rate 2.75 Mbps
User Data Rate Up to 2.0 Mbps
Maximum Link Path Distance > 25 miles (40 km)
Antenna Specification
Antenna Package Integrated with modem in single outdoor package
Antenna Gain 10 dBi
Antenna Beamwidth 45 degrees for both Horizontal and Vertical Polarization
Front-Back Min. Ratio 15 dB
Diversity Automatic Diversity Selection of Horizontal and Vertical Polarization per packet
Power Specifications
Supply Type 48 VDC 802.3af Mode B compatible Power over Ethernet (PoE)
PoE Power Injector Input Auto-sensing 100-240 VAC, 47-63 Hz
PoE Power Injector Output 48 VDC, 350 mA max
PoE Power Consumption (typical) 10W
Interface Specifications
Physical Interface 10BaseT RJ-45 HDX Ethernet Jack (TIA - T568A)
Power Over Ethernet +48 VDC on pins 4 & 5 (pair 1) / 0 VDC on pins 7 & 8 (pair 4)
Ethernet Cable Length Supplied 25 feet CAT-5e Outdoor rated
Max. Ethernet Cable Length 330 feet (100 m)
Dimensions
L x W x H 16.25” x 8.25” x 3.5” (41.5 cm x 21 cm x 9 cm)
Weight/Shipping Weight 6.4 lb (2.9 kg)
Materials Aluminum base , plastic radome
LMS4000 Technical Specifications
Environmental Specifications
Operating Temperature -40º C to 50º C plus solar loading
Storage Temperature -40º C to 70º C
Operating Humidity 0% to 95% RH (non-condensing @ 50C)
Standards Designed for outdoor unsheltered conditions,
Compliant with ETSI-300-019-1-4, Class 4.1 with extended temp. range
(similar to NEMA-4)
Wind Loading Up to 112 mph (180 kph)
maintains alignment to better than 56 mph (90 kph)
Ice Loading Better than 1.25” (32 mm)
Mounting Interface Mounts to any secure pole from 1” to 3.5” (2.5 cm to 9 cm) via 2 gear clamps
Orientation Mounts horizontally or vertically.
Approvals
Radio Transmitter FCC Class A, CFR 47 Part 15. FCC ID: OOX-EUM3006
Safety UL, CSA
V1.0 – Nov. 2004
Note: WaveRider’s Continuous Improvement Policy means that specifications are subject to change without notice.
