Venstar SKYPORT1 Wi-Fi Accessory User Manual Manual Venstar ACC0454 Wi Fi Key

Venstar Inc Wi-Fi Accessory Manual Venstar ACC0454 Wi Fi Key

Users Manual

Package Contents: 1) Skyport Wi-Fi Key, 1) Locking Clip, 1) Instruction Sheet
Insert the Sykport Wi-Fi Key all the way into the
SD slot of the ColorTouch Thermostat.
The ‘cut corner’ of the Key’s circuit board faces
up as shown in figure 1.
A Locking Clip is included for added security.
The Locking Clip helps prevent unauthorized
removal of the Skyport Key.
Please refer to the steps below for installation
of the Locking Clip.
Copyright 2012, Venstar, Inc. All Rights Reserved 88-954 Rev.1
VENSTAR
VENSTAR
ACC0454
Installation
Instructions
Skyport Wi-Fi Key
Cut
corner up
fig. 1
fig. 2
fig. 3
INSERT
With the thermostat removed
from the backplate, insert the
Skyport Key.
Install the Locking Clip as
shown in figure 2.
The Locking Clip is seated
all the way down next to the
circuit board as shown in
figure 3. Reinstall the
thermostat on the backplate.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes or modifications not expressly
approved by the party responsible for compliance could void the user’s authority to operate the equipment.
C
c
FSkyport Key
ACC0454
FCC ID MUH-SKYPORT1
This device must be installed properly and operated more than 20 cm from the human body.
