Vx670 Certifications and Regulations
VeriFone Part Number: 24000 Revision C
*24000*
continued on rear cover
Electrical
Power Packs
Before you connect the terminal power pack to an electrical outlet, check that the on/off power switch on the terminal is off. If the terminal
does not have an on/off switch, check that the power cable connector is removed from the terminal’s power port.
or
When connecting the terminal to a power pack, always connect the plug of the power pack to an electrical wall outlet first. Then connect
the power cable to the terminal’s power port.
The power pack is rated as follows:
Input Voltage: 100 - 240 V AC, 50/60 Hz
Output Voltage: 12 V DC, 2 A
AC Adapter
The AC adapter is designed to ensure your personal safety and to be compatible with this equipment. Please follow these guidelines:
• Do not use the adapter in a high moisture environment. Never touch the adapter when your hands or feet are wet.
• Allow adequate ventilation around the adapter. Avoid locations with restricted airflow.
• Connect the adapter to a proper power source. The voltage and grounding requirements are found on the product case and/or
packaging.
• Do not use the adapter if the cord becomes damaged.
• Do not attempt to service the adapter. There are no serviceable parts inside. Replace the unit if it is damaged or exposed to excess
moisture.
Separate Power Sources
Some peripherals require a separate power source. Before connecting a check reader or similar device, remove the power cable
connector from the terminal’s power port.
Peripherals
Before connecting any peripheral device, turn off power to the terminal and check that the power cable connector is removed from the
terminal’s power port. Turn on power only after you are finished connecting the peripheral device(s). For complete information about
peripheral installation and use, please refer to the user documentation supplied with those devices.
Telecommunication Cord
Caution: To reduce the risk of fire, use only No. 26 AWG or larger UL Listed or CSA Certified Telecommunication Line Cord.
Disconnecting Power
Disconnecting power during a transaction may cause transaction data files that are not yet stored in terminal memory to be lost.
Location – Electrical Considerations
CAUTION: Due to risk of electrical shock or terminal damage, do not use the terminal near water, including a bathtub, wash bowl, kitchen
sink or laundry tub, in a wet basement, or near a swimming pool. Also, avoid using this product during electrical storms.
Avoid locations near electrical appliances or other devices that cause excessive voltage fluctuations or emit electrical noise (for example,
air conditioners, neon signs, high-frequency or magnetic security devices, or electric motors).
Equipment
Repairs
Do not, under any circumstances, attempt any service, adjustments, or repairs on this equipment. Instead, contact your local VeriFone
distributor or service provider for assistance. Failure to comply may void the product warranty.
Location – Environmental Considerations
Do not plug the power pack into an outdoor outlet or operate the terminal outdoors. It is not waterproof or dustproof, and is for indoor use
only. Any damage to the unit from exposure to rain or dust may void your warranty.
Do not use the terminal where there is high heat, dust, humidity, moisture, or caustic chemicals or oils. Keep the terminal away from direct
sunlight and anything that radiates heat, such as a stove or a motor.
Battery Pack Instructions
Dispose of the battery pack in accordance with all national, state, and local laws and regulations as regionally required. Some batteries
Vx670 Certifications and Regulations
FCC Compliance
The following device has been tested and certified as compliant with the regulations and guidelines set forth in Part 68 of FCC
Rules:
Manufacturer: VeriFone, Inc.
Brand, Model: Vx670
Part 15 of FCC Rules
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1this device may not cause harmful interference, and
2this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: changes or modifications not expressly approved by the party responsible for compliance could void yout authority to
operate this equipment.
Part 68 of FCC Rules
This equipment complies with Part 68 of the FCC Rules. On the modem board inside full featured base stations is a label that
contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment. If
requested, this information may be provided to the telephone company.
The REN is used to determine the quantity of devices that may be connected to the telephone line. Excessive RENs on the
telephone line may result in the device not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs
should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total
RENs, contact the telephone company to determine the maximum RENs for the calling area.
This terminal cannot be used on telephone-company-provided coin service. Connection to Party Line Service is subject to state
tariffs.
This equipment uses the following USOC jacks: (RJ11C).
An FCC-compliant telephone cord and modular plug is provided with this equipment. This equipment is designed to be connected
to the telephone network or premises wiring using a compatible modular jack that is Part 68 compliant.
If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary
discontinuance of service may be required. If advance notice is not practical, the telephone company will notify the customer as
soon as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of
this equipment. If this happens, the telephone company will provide advance notice in order for you to make the necessary
modifications to maintain uninterrupted service.
If trouble is experienced with this equipment, please contact VeriFone, or your local VeriFone distributor or service center in the
U.S.A. for repair and/or warrant information. If the trouble is causing harm to the telephone network, the telephone company may
request you to remove this equipment from the network until the problem is resolved. No repairs can be done by a customer on this
equipment.
It is recommended that the customer install an AC surge arrestor in the AC outlet to which this device is connected. This is to avoid
damage to the equipment caused by local lightning strikes and other electrical surges.
RF Exposure Information
This device was verified for RF exposure and found to comply with Council Recommendation 1999/519/EC and FCC OET-65 RF
exposure requirements.
Wi-Fi Only
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. For additional compliance
information, please reference FCC ID: B32VX670WIFI.
SAR Labeling
GSM/GPRS
USA
Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly
and must provide at least 15mm separation between the device and the user's body. The highest reported SAR values are: Part 22
Body-worn 0.21W/kg, Part 24 Body-worn 0.25W/kg.
Australia Required Warning Statement
Please switch off and do not operate the equipment when in an area with a potentially explosive atmosphere, such as refueling
points, fuel depots or storage areas, chemical plants, and blasting operations.
Recycling: DO NOT DISCARD!
UNIT MUST BE RECYCLED OR DISPOSED OF PROPERLY
For proper disposal instructions go to http://recycle.verifone.com/ Please retain this sheet for future reference.
