USERS MANUAL

R623

User Manual

Thank you for purchasing the R623 mobile phone

Introduction

Welcome to choose the R623 mobile phone. This user manual

states the outstanding performance of the R623 mobile phone in

detail. In addition to the basic call features, the R623 mobile phone

and the system network also provide you with a variety of useful

features and services to facilitate your work and leisure activities.

The Company reserves the right to make any amendment on the

technical specifications without any advance notice.

Reading Statement for the Manual

In manual, different typesetting styles are used to interpret different

operating details, and the specific interpretation is as follows:

Operation Description of Contents Example

Showing

contents Show with normal characters 0-9

General

key

All the keys except functional

keys are shown by normal

characters with frames

0-9

Functional

key

Functional key is shown with

bold and frame OK

item Show in bold italics Edit

Note:

The pictures shown in the manual are only used as function

hint which may be different from the phone, and the ones in

your phone shall prevail.

CONTENT

INTRODUCTION.............................................................................. II

SECURITY AND PERFORMANCE................................................. 1

1 START USING.......................................................................... 3

1.1 BATTERY ............................................................................. 3

1.2 SIM CARD............................................................................ 3

1.3 PLUG THE MEMORY CARD ..................................................... 4

1.4 PLUG THE EARPHONE ........................................................... 4

1.5 STATUS BAR AND CONTENT................................................... 4

1.5.1 Keys ........................................................................... 5

1.5.2 Text input and edit window ........................................ 6

2 DIAL AND ANSWER THE CALL............................................. 6

2.1 DIALING A CALL .................................................................... 7

2.2 ANSWERING A CALL .............................................................. 7

2.3 EMERGENCY CALL................................................................ 8

3 MENU OPERATION................................................................. 8

4 APPLICATIONS ....................................................................... 8

5 PHONEBOOK .......................................................................... 8

6 CALL CENTER......................................................................... 8

6.1 CALL HISTORY...................................................................... 8

6.2 CALL SETTINGS .................................................................... 9

6.2.1 SIM1/SIM2 call settings ............................................. 9

6.2.2 Advanced settings...................................................... 9

7 CONNECTIVITY ....................................................................... 9

8 SNS......................................................................................... 10

9 MESSAGING.......................................................................... 10

10 SERVICES.............................................................................. 11

11 FILE MANAGER..................................................................... 11

12 ORGANIZER .......................................................................... 11

13 MULTIMEDIA ......................................................................... 12

14 SETTINGS.............................................................................. 13

14.1 USER PROFILES ................................................................. 13

14.2 NETWORK SETTINGS........................................................... 13

14.3 SECURITY SETTINGS........................................................... 13

14.4 RESTORE FACTORY SETTINGS............................................. 14

15 CAMCORDER ........................................................................ 14

16 OTHER FUNCTIONS ............................................................. 15

17 COMMON QUESTIONS......................................................... 15

18 MAINTENANCE GUIDELINE................................................. 16

Security and performance

◆In thunder raining days, please do not use the mobile phone when

charge it or outdoor, so as to avoid being struck by thunder or other

injuries.

◆Please do not put the battery in high-temperature environment

(high temperature will lead to heat of the battery upgrading), and

keep the phone being charged and the charger away from people or

other flammable and explosive articles in order to avoid fire,

explosion or other dangers!

◆Please strictly adhered to the rules and do shut down the mobile

phone on occasions which use of mobile phone is prohibited!

◆Please do not arbitrarily refit or teardown the phone and

accessories. Only the authorized organizations can repair the phone.

◆Please do not use batteries, charger or accessories of

non-standard original models.

◆Please do not join the two poles of the battery, so as not to result

in battery short-circuit.

◆Please do not use the mobile phone when driving. In case of

emergency, please use hand-free devices (which may be bought

separately).

◆Please do not put the phone on car insurance airbag or region

reachable by the airbag after spreading. Otherwise when the airbag

expands or ruptures, the mobile phone is likely to cause serious

damage to the people in the car due to strong external force.

◆In order to comply with provisions of RF leakage, when you wear

a phone or use the data functions, please maintain the distance

between the antenna and the body at least 1 inch (2.5 cms).

◆Do not use chemical lotion, scrubbing cleanser to wipe the mobile

phone or the charger, otherwise it may damage the components or

cause fire. Slightly wet and anti-static soft clean cloth can be used.

◆Please do not throw the old and abandoned lithium batteries into

trash can, send them to the designated locations.

◆Please do not use the phone to make bold to camera, video and

recording that may infract the rights of the copyright owners. The

company will not be responsible for any losses caused by not

recording, deleting, destructing or damage of the photos, video and

recordings caused by its accessories or software on the use of the

functions including camera, video and audio.

◆In the use of network function, if the users download a file with

virus, which make the mobile phone cannot be used normally; the

company does not undertake any responsibility arising therefore.

Warning: The original manufacturer will not take on any

responsibility for the users who are not in compliance with the above

advices or improperly use the mobile phone.

Note: The application of value-added services of the mobile phone

is provided by relevant service providers. Please refer to the

relevant help or providers’ notes for detailed information.

Statement: The Company reserves the right to improve the

product without making any advance notice, and keeps final

interpreting rights on the product performance. Such changes

are not notified additionally, your understanding is appreciated.

1 Start Using

1.1 Battery

Battery is attached with the phone. Please recharge it for use after

completely using up the battery for the first three times, which

makes this battery easier to achieve the best using state.

In actual use, the standby time and talk time of the phone varies with

the network status, working environment and different using

manners.

For install the battery, you should put the back of the phone upward,

push the rear cover, move the battery cover button to the right for

releasing the cover, and then take off the rear cover. Then insert the

battery in place. After install the rear cover, you should move the

battery cover button to the left for locking the cover.

1.2 SIM card

The SIM card is the key for accessing to the digital GSM network.

Prior to using the phone, you need to insert effective SIM card

in the phone.

In order to prevent illegal use, SIM card adopts PIN code (personal

identification code) encryption protection.

If this function is selected, PIN code should be input correctly each

time when you power on the phone, thus to unlock the SIM card for

normal use. Users can disarm the SIM card protection but illegal

use of the SIM card cannot be prevented.

If the PIN code input is error for three consecutive times, your SIM

card will be locked by the network. There will enquire the PUK code

which provided by your network operator. If the PUK code input is

wrong for 10 times, the SIM card will be permanently barred.

Note:

Your network operator will set a standard PIN code and you

should change it to private password.

1.3 Plug the memory card

Open the memory card holder, and insert the memory card into the

slot at the bottom according to the chat below, then close the

memory card holder.

1.4 Plug the earphone

Open the USB cover and insert the connector of the earphone to the

earphone jack at the bottom of the mobile phone. Gently pull out the

earphone to remove it.

1.5 Status bar and content

In standby screen you can get the information that you need from

the indication icons on the screen.

Indicating that the SIM1 is connecting network currently

Indicating there is text message not read of SIM1

Indicating there is MMS not read of SIM 1

Divert all voice calls has been set of SIM1

Indicating missed call of SIM1

The current alert type is ring only

The current alert type is vib. Only

The current alert type is vib. And ring

The current alert type is vib. Then ring

Indicating that silent mode activated

The mobile phone is locked

Indicating that earphone has been inserted

Indicating that the Bluetooth has been activated

Indicateing that WLAN has been connected

Indicating that alarm has been set

T-flash card is inserted and recognized

1.5.1 Keys

Functions of the keys are described as following:

SN Keys Function description

1 Send key

(Snd)

Making a call; in standby screen press

the key to enter Call history.

2 End key

Hang up a call; go back to the standby

screen; long press to power on/off the

phone.

3 Left soft key

(LSK)

OK; pop-up menu; short press in

standby screen to enter main menu.

4 Right soft key

(RSK) Clear; back to previous screen.

5 OK key

OK; short press to enter the dedicated

application; long press the key to lock

the keypad.

6 Navigation

key

Use the navigation key to moving to

the upward/ downward/left/right.

7 Keypad

Input; in the main menu screen short

press the number key to enter

corresponding menu; in standby

screen, long press 2-9 key to speed

dial (need set); long press # key to

active Silent mode.

8 Receiver Listen to the voice of the other side

when calling.

9 Volume key Press to adjust volume in standby

screen.

10 USB jack Connecting USB cable, earphone or

charger.

11 Speaker Listen audio or calls in hands-free

mode.

12 Camera For finding a view with the camera.

13 Cover button Move to the left to lock the cover; move

to the right to release the cover.

1.5.2 Text input and edit window

Enter the text input screen, you can short press the Sym key to

enter the symbols selecting screen; short press key to switch

input method; short press key to switch detailed input method.

2 Dial and answer the call

2.1 Dialing a call

When the network operator’s logo appears on the screen, the

mobile phone enters into the normal standby state in which you can

dial or answer a call. The call quality is relatively largely impacted by

obstacles. Therefore, movement in a small range can effectively

improve the signal strength.

In the standby screen, input the call numbers or select contact in

phonebook, and then press the Snd key to make the call.

If the speed dial function is activated, in standby screen, long press

the number keys 2-9 to dial the number that has been set up

automatically. If speed dial has not been set for the number key you

long pressed, the mobile phone will hint you “No speed dial

number”.

2.2 Answering a call

If there is a new incoming call when in call progress, the phone will

pop up caller screen (call waiting is activated). When you answer

the new call, the original call will enter holding status. At this time,

you can activate Options to select Swap to active the original call,

and the new call will enter holding status.

Note:

When you are in call progress, the new call to another SIM card

can’t be dialed in.

If two calls are connected, activate Options, and you can operate

as follows:

Conference: when making conference call, you can have a talk

separately with designated conference participant. In conference

call mode, all the others can hear your voice.

Transfer (network support is required): transfer the current call to

your designated phone number.

DTMF: on/off settings can be conducted. If the function is activated,

when calling the telephone exchange, you can call the extension in

accordance with voice clews; the aforesaid functions are

unavailable if the function is off.

2.3 Emergency call

If you are in the network coverage area (you can check the network

signal strength at the top of standby screen), even without the SIM

card, you are also able to make an emergency call.

Note:

The emergency call numbers in different countries or regions

are different. Please refer to the local numbers for specific

emergency service numbers.

3 Menu operation

In the standby screen, press LSK to enter the main menu, you can

press navigation keys or corresponding number key to select the

function you want to enter.

Fun&Games Phonebook Call center Connectivity

SNS Messaging Services File manager

Organizer Multimedia Settings Camcorder

4 Applications

For richness your entertainment life, there provides you the

interesting application. Please get more information in the

instructions of the phone.

5 Phonebook

In phonebook list, input the first letter of name, you can search the

accordant records. When the record is not empty, activate Options

you can conduct the following operations: send message, edit,

delete, send business card, mark several, in phonebook settings,

you can set preferred storage, caller groups, speed dial, my number,

extra numbers, import contacts, delete duplicated contacts, and you

can also view memory status.

6 Call center

6.1 Call history

Enter call history, you can press left/right navigation key to switch to

other sheet, activate Options, you can operate as follow: view, call,

send message, save to phonebook, add to blacklist, add to whitelist,

edit before call, delete, delete all and advanced.

6.2 Call settings

6.2.1 SIM1/SIM2 call settings

Caller ID: you can set whether to allow your phone number being

displayed or not. This function needs to be supported by the

network service provider.

Call waiting: If the function is activated, when a new call incoming

in calling process, your phone will display the new call screen. If the

function is deactivated, new incoming calls cannot be reached.

Call divert: this function is used to transfer the call to your designated

number. The function is related with the network and SIM card. The

system will give appropriate setting tips.

Note:

If the transfer call you set is a fixed phone, please add the area

code.

Call barring: this function needs network support. Network provider

will provide the corresponding network password for you activate

call barring service.

6.2.2 Advanced settings

You can set the function such as auto redial, background sound, call

time display, call time reminder, auto quick end, reject by SMS,

connect notice, answer mode and so on.

7 Connectivity

Bluetooth: enter Bluetooth screen, when power on the Bluetooth, in

My device you can select Search new device to search and

compare with other Bluetooth device. You can select Inquiry audio

device to search the hands-free device. If the Visibility state is off,

the others will not find the phone via Bluetooth.

Note:

The received file that transmitted by Bluetooth are stored in

Received folder automatically.

WLAN: enable WLAN from the menu, the available AP (Access

Point) nearby will be shown in the list of available networks.

Highlight an unconnected AP, active Options you can do the

operator of connect, add, define access point, WLAN status, disable

WLAN, power save mode and refresh. Highlight the connected AP,

active Options you can do the options of disconnect, add, edit,

delete, change priority, WLAN status, disable WLAN, power save

mode and refresh.

Conn. Management: you can view the current connection states.

Data account: with valid SIM card with GPRS function inserted,

there will show the available accounts of GSM data and GPRS. Data

account can be edited or delete.

8 SNS

Select the function such as Twitter; you can conduct the following

operations:

9 Messaging

Enter messaging; you can do many operations such as:

Conversations: you can view the messages including SMS and

MMS, each conversation includes the sent and received messages

with one contact.

Garbage box: when Blacklist state is on, the SMS sent by all

numbers in the blacklist are sent into the garbage box rather than

the inbox while other numbers not; when whitelist state is on, the

SMS sent by all numbers in the whitelist are sent into the inbox

rather than the garbage box while other numbers not.

Email: you can select and create the account from email setup

wizard, after inputting the correct user name, password and setting

the data account, you can receive the mail by connect function.

Broadcast messages:

store the broadcast messages.

Message settings: set the correlative parameter of text message

and multimedia message.

Note:

Please set correct network connections in server profile before

setup and send MMS. Here, insure your SIM card support

GPRS connection, and turned on the MMS. Please consult with

your network service provider.

10 Services

Internet service: enter Internet service; you can normally use the

WAP internet service under the premise of correctly setting the

network. This function is provided by the network operator, Please

contact with your network operator or service provider.

STK (SIM Tool Kit): the name and content of the menu are based

entirely on the services provided by the network operator. For more

information, please contact with the network operator.

Note:

This function depends on whether the network operator

provides this service and whether you have ordered this

service.

11 File manager

Enter into file manager, the capacity and surplus capacity of the

phone or memory card are displayed in the screen. You can open,

format, rename or view the details by the options.

12 Organizer

Calendar: enter calendar screen, you can check the date. Activate

Options, and you can do the operations such as view and add

event.

Tasks: this function is used for add and view task items.

Alarm: there are 5 alarms in your mobile phone. The functions and

using methods of the 5 alarms are completely same. You can set to

turn on/off respectively.

World clock: enter world clock screen, active Options you can

select the city by choosing it and pressing OK key.

Notes: enter Notes, you can create a new note through Options.

The user can view, edit, and delete each note.

Calculator: the calculator performs four operations as addition,

subtraction, multiplication and division. Enter calculator screen, you

can input numbers directly and press navigation key to switch the

operation which you need, then start calculation.

Currency converter: in this function, if you input the rate and the

amount of money in local, you can get the result of the equivalence

money of foreign.

Health: enter into health; you can select BMI to check the detail

information.

Stopwatch: in stopwatch screen, you can select the typical

stopwatch or nWay stopwatch and view records that you have

saved.

Ebook reader: this function can be used for reading the files

with .txt format.

13 Multimedia

Image viewer: enter the pictures list screen, if the list is empty

activate Options, you can Select folder to set the path of folder to

display, select Capture to capture new pictures to current storage.

Media player: enter the media player screen; activate Options,

select My playlists add new playlist, then activate Options, select

Add to choose the media files from storage.

Note:

When you select the folder to add the media, all of the media

files contained in you’re the folder will be added to the playlist,

maybe there have some files you don’t want to play. So, you

can also add media file one by one.

Sound recorder: enter recorder screen, press up navigation key to

start record, after saving the recorder, press down navigation key

can play the current record. If the recorder list is not empty, activate

Options; you can select Append to add record on the selected

recorder file continuously.

FM radio: insert the earphone first then enter FM radio, you can

listen to the channel program by Auto search or Manual input. You

also can Record the program for your favor..

Schedule FM record: activate the function, the phone turn on the FM

radio automatically and record current program when time out.

14 Settings

Enter Settings, you can modify parameters of the time and date,

personalized settings and phone settings. You also can add new

font from your system that in .ttf format.

14.1 User profiles

User Profiles contains predefined settings for ring tone and volume

for each SIM. You can change the existing profiles according to your

own preferences. In the standby screen, long pressing the # key will

quickly activate Silent mode. The headset profile is automatically

activated when the earphone is inserted, and all other profiles are

automatically disabled.

14.2 Network settings

You can set the SIM selection mode, dual SIM settings and

preferred mode. In SIM1/SIM2 network settings, you can select

appropriate network.

Note:

Please do not register networks inconsistent with the SIM card,

so as to prevent unavailability of normal use. For details,

please consult your service provider.

14.3 Security settings

SIM1/SIM2 security: this function can prevent others from using

your SIM card without your permission.

You can change the password of SIM1/SIM2 PIN and SIM1/SIM2

PIN2 through the system prompts.

Phone security: this function is to lock and prevent other people

from using the phone without permission (default password is 0000).

You can change the phone lock password through the system

prompts.

Auto keypad lock: activated this function, when the phone without

any operation in standby screen, the keypad will be locked

automatically after the set time. If you need to unlock the keypad,

you can press any key except end key, and then operate according

to relevant screen prompts.

Certificate manager: store the certificates.

Private security: enter Private Security, you should input the correct

password (default password is 0000). Then you can select phonebook,

messages, call log or file manager to set up the privacy protection.

Calls & SMS firewall: enter calls & SMS firewall, you can press

left/right navigation key to switch between blacklist and whitelist.

Activate Options, you can add new entity to the list or set the

parameter of the block settings.

14.4 Restore factory settings

You can carry on corresponding operation after inputting the correct

password (default password is 0000).

After running the Restore factory settings, the environment setup

(e.g. user profile) restore to factory default setting.

After running the Restore settings and data, the phone clear up the

messages saved in phone while the environment setup (e.g. contact

person and SMS that saved in phone) restore to factory default

setting.

15 Camcorder

In preview interface, press down/up navigation key to switch

functions between camera and video recorder, press OK key to

capture photos or videos. Press LSK then using left/right navigation

key to view or set the parameters.

16 Other Functions

Mass storage: this function is used to read and write files from PC

to the storage.

COM port: you can synchronize your phone with PC. Details about

the related tools, please consult with Customer Service Center.

17 Common Questions

Unable to make some calls

 Call barring has been set and barred utilization of the mobile

phone. Please check and cancel call barring.

VeryKool USA R623 GSM/GPRS DUAL-BAND MOBILE PHONE User Manual USERS MANUAL

VeryKool USA Inc GSM/GPRS DUAL-BAND MOBILE PHONE USERS MANUAL

Contents

USERS MANUAL

Navigation menu

Namespaces

Views

Navigation
