ViVOpay 3000 USER GUIDE
The ViVOpay is equipped with 4 LEDs on it's translucent cover as well as sound
interface to provide consumers feedback on the read process. Upon a successful
transaction all 4 LEDs will turn on and a beep will sound to let the customer know
that the transaction is completed.
Idle: Just first LED is ON
Read SUCCESS: all LEDs will be turned
on while the module emits a sound
acknowledging the success.
Read ERROR: If there's an error while
reading a card the LEDs will not turn
On and no sound will be emitted
3. The ViVOpay quickly reads the information from the card
through RF technology - no physical contact is necessary. In
a fraction of a second the reader validates the card, and
secures the transaction.
(As the reader is facing the customer and probably the clerk
won't be seeing the LEDs, a beep will let the clerk know that
the read was successful).
4. ViVOpay 3000 automatically sends the information to the
POS, which processes it as a conventional magnetic stripe
card, though with increased security.
(Besides mentioning contactless payments and pointing to
the ViVOpay unit no intervention from the clerk is necessary
during the entire procedure).
5. The POS terminal prints the receipt, which the clerk gives
to the consumer for signature as with any other purchase.
Consumers just need
to hold their Paypass
devices in front of
the ViVOpay
The merchant operation of the ViVOpay 3000 is very simple and almost entirely
automated. Once installed, the clerk's role on the operation of the system is simply to
guide new customers to hold their cell phones or plastic cards enabled with a
contactless RF chip in front of the Reader Module. The information is automatically
transferred to POS system and processed in the same way a standard magnetic card
would be.
Typical Usage
