ViewSonic VS14905 Tablet PC User Manual A72B EN STD 20120221
ViewSonic Corporation Tablet PC A72B EN STD 20120221
User manual
TABLET PC Security Alert
For safety and effective using the tablet PC, you should read the
basic safety precautions carefully.
·
·
·
·
·
·
Keep the computer away from heat, cold, moisture and dust.
Don't spill any liquid onto the tablet PC to damage it or cause a fire.
Don't use liquid or to wipe the tablet PC.
Don't insert any object into the computer's air vents or other slots.
Don't place heavy objects on the tablet PC.
Don't disassemble the tablet PC, let the qualified professional for
the service to keep safe.
chemically cleaner
Quick Start Guide
[Note]: The appearance, color, features, and pictures in the
manual are for reference only; if any difference, please see
the actual products.
The company reserves the right to update the products and the
manual without prior notice.
Part Names and Functions: Camera
DC-In Jack
USB Port
Mini-HDMI Port
Built-in speaker
Volume button
Volume button
Back key
Micro-
Micro-SD
Taking pictures or recording video
Audio output,connect to headphone
Connect to the DC power supply
Connect USB device
Sound output
If the light being amber means the battery is charging,
if the light being blue means it's been fully charged.
Decrease the volume
Micro-
External Micro-SD card to extend storage
Increase the volume
Back to the previous interface from the current interface
External mini high-definition Multimedia monitor
Battery status
indicator
Cut power
Forced off with needle insert the reset hole, you
can't turn off the tablet PC by press power button
4S, when the system stuck
Built-in microphone
Audio output Interface
1
2
3
5
6
7
8
9
12
13
14
4
10
Home Screen Use Instructions
·Press Power for 3 seconds, after booting picture enters the home
screen as below:
Press for more than 4 seconds to turn on/off; press
once for screensaver, press again to wake it up
Power button
11
Application:touch and goes to Application interface where all
the applications shown
Back: touch and return menu
Home: touch and return home screen
muti-task switch;click here to open the procedure list applied
recently
11 12 13 14
10
9
8 7 6 5 4 3 2
9
1
Used for video Conference,dubbing and simple recording
105.00 mm
105.00 mm
290.00 mm
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
IC STATEMENT
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement set forth for an
uncontrolled enviroment.
End users must maintain 0.5 cm distance away from the Tablet PC and its antenna.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
