PJ559D

LIGHT, BRIGHT AND

PORTABLE PROJECTOR

with BrilliantColor™

The ViewSonic® PJ559D DLP® projector features 2,700 lumens, native

1024x768 resolution, ultra-high 2000:1 contrast ratio and BrilliantColor™

technology for precise images in any lighting condition. This full-featured

projector includes MULTIPLE INPUTS for connecting several display

sources simultaneously, dual 5-watt speakers for complete multimedia

presentations, VERTICAL KEYSTONE CORRECTION for easy image

adjustment and DIRECT OFF FEATURE. Choose from whiteboard,

blackboard or greenboard mode for the best picture on your projected

surface. Eco-mode extends lamp life and reduces fan noise as low as

33 dB. Protect your projector from theft and unauthorized use with the

Kensington® security port and PIN lock password.

High brightness,

full-featured projector.

BRILLIANT PRESENTATIONS MADE EASY

Bright in virtually any setting with 2,700 lumens

Packs 2,700 lumens in just 6 pounds. It’s the bright choice

for mobile presenters.

BrilliantColor™ technology

DLP® projectors with BrilliantColor™ feature multi-color processing

to produce nearly 50% brighter colors for a vibrant image on the

screen that won’t fade over time.

Ultimate video source flexibility

Connect a computer or add a video source for dynamic

meetings and presentations.

Supports HD signals including 720p and 1080i

Capable of displaying HDTV signals as well as other

video and data sources.*

Mulitple color correction modes

Blackboard, greenboard and whiteboard modes give you the

best possible picture regardless of the projection surface.

OnView® controls for superior screen adjustability

Screen geometry and color adjustments are precisely

made via an easy-to-use on-screen menu.

Eco-mode extends lamp life

Extend the life of your lamp up to

4,000 hours** and reduce noise output.

My Screen Startup

Customize your startup with a company

logo or favorite picture using the

MyScreen function.

>

>

>

>

>

>

>

>

PJ559D

LIGHT, BRIGHT AND PORTABLE PROJECTOR WITH BrilliantColor™

PROJECTOR Type 0.55 DDR DMD, DLP®

Pixel Format 1024x768 XGA

Lens Manual zoom, manual focus

Zoom Factor 1.1

Keystone Vertical ± 40º

DISPLAY Size 27.2"–250" (diagonally)

Throw Distance 47.2"–393.6"

Throw Ratio 1.97–2.6:1

Lamp 200W, 3,500 hrs. normal, up to 4,000 hrs. eco-mode**

Brightness (max) 2,700 ANSI lumens

Contrast Ratio 2,000:1

Aspect Ratio 4:3 (native), 16:9

AUDIO Speakers 2x5-watt

INPUT SIGNAL Computer and Video RGB analog, NTSC, NTSC 4.43, PAL, SECAM, HDTV (480p, 720p, 1080i)

Frequency Fh:31–79kHz; Fv:56–85Hz

COMPATIBILITY PC Analog: from VGA up to SXGA (scaled)

Mac®† Analog: up to SXGA

CONNECTOR RGB (input/output) 15-pin HD, D-sub (x2)

Composite Video (input) RCA jack

S-video (input) Mini-Din 4-pin

Component Video (input) VGA DB-15 to HDTV/component cable*

Audio (input/output) Stereo mini-jack

RS-232 6-pin D-sub

USB Type B for mouse control only

POWER Voltage 100–240VAC, 50–60Hz (universal)

Consumption 200W (typ)

CONTROLS Basic Standby/on, input, menu

OnView® Display mode, brightness, contrast, keystone, aspect ratio,

blank screen, gamma, white peaking, color temperature,

user color, video (sharpness, saturation, tint), display (phase,

tracking, H. postion, V. postion), advance (auto source,

select, rear, ceiling, eco-mode, lamp hours, lamp reset,

auto shutdown, OSD timeout, menu position, factory reset),

audio (audio mute)

OPERATING Temperature 32–104ºF (0–40ºC)

CONDITIONS Humidity 10–90% (non-condensing)

Altitude 0–10,000 ft.

NOISE LEVELS Normal / Eco-mode 35 dB (typ) / 33 dB (typ)

DIMENSIONS Physical (W x H x D) 8.9" x 4.3" x 8.8" (277mm x 109mm x 223mm)

WEIGHT Net 6.0 lb. (2.7 kg)

Gross 13.0 lb. (5.9 kg)

REGULATIONS UL/cUL, FCC-B, CE, CB, CCC, NOM, ICES 003, IRAM,

TUV/GS, GOST-R, HYGIENIC, SASO, UKrSEPRO, RoHS

RECYCLE/DISPOSAL The lamp in this product contains mercury. Please

dispose of in accordance with local, state or federal laws.

PACKAGE CONTENTS Projector, power cable, VGA cable, S-video cable, remote

control with built-in laser, soft case, lens cap, Quick Start

Guide, ViewSonic Wizard CD (with User Guide)

WARRANTY 3-year limited warranty on parts and labor, 1-year limited

warranty on lamp, 1-year free Express Exchange® service.***

For more product information, visit us on the web at ViewSonic.com

Sales: (888) 881-8781 • SalesInfo@ViewSonic.com • ViewSonic.com

*Optional cables required. **Running eco-mode exclusively can extend lamp life. ***See ViewSonic.com for full details. †Adapter may be required. Analog adapter available from ViewSonic. DLP® and the DLP logo are

registered trademarks of Texas Instruments and BrilliantColor™ is a trademark of Texas Instruments. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic

representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2007 ViewSonic Corporation. All rights reserved. [13727-01B-12/07] PJ559D-1

ViewSonic Corporation’s QMS & EMS have been

registered to ISO 9001 & ISO 14001, respectively,

by the British Standards Institution.

Optional Accessories

• Replacement lamp ............................RLC-36

• Soft case with wheels ........................CASE-006

• Extended Express Exchange® ..........PRJ-EE-05-03

• Universal ceiling mount kit ...............WMK-005

• VGA to component video adapter ...ADPT-002

• Wireless G Presentation Gateway .... WPG-150
