Enter a new dimension with this brilliant display.
The ViewSonic VPW5500 55" plasma delivers amazing images thanks to
Clear Pictureelectronics that optimize the 1,000 cd/m2brightness (typ).
The INNOVATIVE TECHNOLOGY ELIMINATES SIGNAL NOISE and
motion artifacts to generate the smoothest picture possible. The 1366x768
ALIS PANEL ENHANCES BRIGHTNESS LEVELS and elevates
sharpness for film-like quality. Customize your viewing
experience using any of the video inputs including
composite, component,
S-video, analog RGB and
DVI/HDCP. Further personalize
your visual entertainment with
the extensive array of image
controls, picture-in-picture,
split screen, and parental
controls. For pure enjoyment,
choose ViewSonic’s VPW5500.
Immerse, indulge, enjoy.
NextVision®VPW5500 Plasma
Crystal-clear, HD-ready 55" Plasma Display
The bi
g
>Clear Picture advanced screen technology
Clear Picture electronics eliminate noise, increase contrast and
detail, and optimize color for a rich, vibrant image. High-definition
images look amazing and even standard television images are
unbelievably smooth and sharp.
>Image is everything
With 1366x768 resolution, you see every detail of both standard and
high-definition images. The flat screen and advanced anti-glare
treatment eliminate image distortion and reflection for a clear picture
at any angle.
>Multiple window capability
Picture-in-picture and split screen capability let you surf the web while
you watch a movie; or get stock reports from TV while working on the
computer.
>Ultimate viewing versatility
Multiple inputs including composite, component, S-video, analog RGB
and DVI/HDCP ensure the highest quality connection possible.
Extensive user controls allow you to optimize various picture features
for your personal viewing pleasure.
>Professional features and functions
Audio amplifier, six different display-life maximizing functions, and
external RS-232C control interfacemake this display ideal for
corporate digital signage and commercial applications.
>
1-year limited
ON-SITE
warranty*
>
2ND AND 3RD year extended warranty
available
2nd and 3rd year extended warranty available for purchase
in U.S. and Canada. A repair technician will be
dispatched to your location within 48 hours** of your
call, so you’ll be up and running again in no time!
21% more
viewing area than
a 50"plasma
21% more
viewing area than
a 50"plasma
NextVision®VPW5500 Plasma
Crystal-clear, HD-ready 55" Plasma Display
s
p
ecifications
Optional Accessories and Services
Wall Mount WMK-001
Swivel Stand PLS-STND-002
Extended Warranty PLM-50-EW-02
For more product information, visit us on the web at ViewSonic.com
*On-site service free for the first year. **Excludes major U.S. and Canadian holidays. †RS-232C cable is optional. ††Optional tuner required. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate
names, trademarks stated herein are the property of their respective companies. Copyright © 2004 ViewSonic Corporation. All rights reserved. [12012-01B-09/04] VPW5500-1
ViewSonic Corporation • 381 Brea Canyon Road, Walnut, CA 91789
Phone (800) 888-8583 or (909) 444-8888 • In Canada (866) 262-1967 • Fax (909) 839-7922 • SalesInfo@ViewSonic.com • ViewSonic.com
55" PLASMA DISPLAY WITH ADVANCED IMAGE TECHNOLOGY
PANEL Resolution 1366x768 video
Aspect Ratio 16:9
Display Area 48.4" horizontal x 27.2" vertical; 55" diagonal
Viewing Angle 160º horizontal, 160º vertical
Brightness 1,000 cd/m2
Color Depth 8-bits/color (16.7 million)
CONNECTOR Video Input S-video, composite (RCA jack), YCbCr or YPbPr signal (component 1 & 2),
RGB, DVI, RS-232C, SCART
Audio Input L/R +6 (component 1 & 2/S-video/composite/PC/DVI)
Video Output Composite (RCA jack)
Audio Output Output RCA jack (x2), speaker (internal connection), sub-woofer output
(RCA jack x1)
VIDEO INPUT Frequency Fh: 31~60kHz; Fv: 50~85Hz
COMPATIBILITY PC/Mac®VGA (expanded), SVGA (native), XGA (expanded), wide XGA (expanded),
SXGA (compressed)
Video†† NTSC, NTSC 4.43, PAL, SECAM
Scanning Format SDTV: 480i, EDTV: 480p, HDTV: 720p, 1080i
POWER Voltage 100–240V AC
Frequency 50–60 Hz
Consumption 530W
OPERATING Temperature 41–95°F (5–35°C)
CONDITIONS Humidity 20–80% (non-condensing)
DIMENSIONS Physical 54.9" x 33.7" x 4.1"
(W x H x D) 1394mm x 857mm x 405mm
WEIGHT Net 140 lb. (63.5 kg)
Gross 165.4 lb. (75.0 kg)
REGULATIONS UL, FCC-B, CSA
ACCESSORIES Power cord 3m, remote control, AA battery (x2), Quick Start Guide, User Guide
WARRANTY One-year limited parts and labor. Extended warranty available. On-site service
available in U.S. and Canada.*
ViewSonic Corporation’s QMS & EMS have been registered to
ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
Ultra-slim, 4.1" panel extends your display options
because the VPW5500 can be mounted just about
anywhere.
ViewSonic’s exclusive Clear Picture
electronics
eliminate signal noise, increase contrast and
detail, and optimize color. In addition to the
Detail Enhancement and Color Management
shown here, ViewSonic’s VPW5500 Clear
Picture electronics include Low Contrast
Image Enhancement, Contrast Enhancement
and Motion Enhancement for clearly superior
picture quality.
Detail Enhancement increases your ability to
perceive details. It finds areas of detail in an
image – like fuzz on a peach or freckles – and
increases the contrast relative to neighboring
parts of the image. This makes those fine
details on the image stand out more.
Color Management
gives you ultimate
control over the colors on the screen. Using
the color management feature, you can
adjust individual colors in the image.
Customize the image’s red, green and blue
content to levels that look best to you and
adjust the overall white level for warmer skin
tones or cooler, brighter skylines.
