1

W W W . V I N O T E M P . C O M

A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y

O W N E R ’ S M A N U A L

B e v e r a g e C o o l e r

V T - 3 2 B C S B

2

2

W W W . V I N O T E M P . C O M

S N 3 2 B C H D 1 7 V T - S 1

Y o u r

Y o u r Y o u r

Y o u r B e v e r a g e

B e v e r a g eB e v e r a g e

B e v e r a g e C

C C

C o o l e r

o o l e ro o l e r

o o l e r

This unit can be used for Storage and/or Service. The unit has a glass

door and soft interior light that you can leave on to elegantly display your

beverage.

General Operating Instructions

Remove all external and internal packaging from your beverage cooler. Be

sure that all parts have been included before discarding any packaging

materials. You may want to keep the box and packing materials for use at

a later date.

Upon receipt and inspection of unit, the power cord must be replaced if it

is damaged. Contact our customer service at 1-800-777-8466 or

info@vinotemp.com.

• Let the unit rest UNPLUGGED for 24 hours once you have it placed

in your home.

• Please fully read the instruction manual.

• Save these instructions.

Please read and follow all safety rules

and operating instructions before using.

3

1 7 6 3 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1

i n f o @ v i n o t e m p . c o m

S N 3 2 B C H D 1 7 V T - S 1

Table of Contents

PARTS AND SPECIFICATIONS ...................................................... 4

IMPORTANT SAFETY INSTRUCTIONS............................................. 5

CORD INSTRUCTIONS ................................................................ 6

BEVERAGE COOLER INSTALLATION .............................................. 6

TEMPERATURE CONTROL ............................................................ 7

REVERSAL OF DOOR SWING ....................................................... 8

CLEANING AND CARE................................................................. 9

MOVING YOUR BEVERAGE COOLER .............................................. 9

TROUBLESHOOTING .................................................................10

TERMS OF SALE AND WARRANTY ................................................11

SERVICE & IMPORTANT NOTICE..................................................12

4

4

W W W . V I N O T E M P . C O M

S N 3 2 B C H D 1 7 V T - S 1

PARTS AND SPECIFICATIONS

1. Glass Door

2. Grill

3. Adjustable Leveling Legs

4. Shelf

5. Cabinet

6. PVC Control Panel

7. LED Temperature Indicator

8. Light Switch

9. Temperature Adjustment Button

Item Number VT-32BCSB

Dimension (HxWxD) without handle 34.4"×15.0"×22.7"

Weight 74 Lbs

Power Consumption 1.8 kW.h/24h

Cooling System R134a

Ambient Temp. Range 60～90°F

Temperature Range 40～65°F

Rated Voltage 115V

Rated Frequency 60Hz

Input Power 120W

5

1 7 6 3 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1

i n f o @ v i n o t e m p . c o m

S N 3 2 B C H D 1 7 V T - S 1

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should be followed

to reduce the risk of fire, electric shock, and personal injury.

1. Use this appliance only as described in this manual. Other uses are

not recommended and may cause fire, electric shock or injury.

2. This product is intended for indoor, household use only.

3. To protect against electric shock, do not immerse unit, plug or

cord in water or other liquids. Avoid locating the unit in moist

areas.

4. Never allow children to operate, play with, or crawl inside the unit.

5. Unplug from the outlet when not in use, when moving from one

location to another, or before cleaning.

6. To disconnect the appliance, grip the plug and pull it from the wall

outlet. Never pull by the cord.

7. Do not operate the appliance in the presence of explosive and/or

flammable fumes.

8. Do not place the appliance or any of its parts near an open flame,

cooking or other heating appliance.

9. Do not operate the appliance with a damaged cord or plug. If the

product malfunctions, or if it is dropped or damaged in any

manner, do not use.

10. The use of attachments is not recommended and may be

hazardous.

11. Do not operate if the housing is removed or damaged.

12. A loose fit plug may cause overheating and a distortion of the plug.

Contact a qualified electrician to replace loose or worn outlet.

13. This appliance is designed to be built-in (fully recessed) or free

standing.

14. The beverage cooler is intended for use in a controlled ambient

location such that the ambient temperature does not exceed 90°F

(32°C).

15. Locate the unit away from direct sunlight and sources of heat

(stove, heater, radiator, etc.). Direct sunlight may affect/alter the

outside color of the appliance.

WARNING: To reduce the risk of fire, electric shock or personal injury,

unplug or disconnect the appliance from the power supply before

servicing.

WARNING: Risk of child entrapment. Before you throw away your old

beverage cooler, take off the door and leave the shelves in place so that

children may not easily climb inside.

6

6

W W W . V I N O T E M P . C O M

S N 3 2 B C H D 1 7 V T - S 1

CORD INSTRUCTIONS

For your protection, this unit should be properly

grounded. Unit is equipped with a 3-conductor

cord set that has a molded 3-prong grounding-

type plug, and should be used in combination

with a properly connected grounding-type outlet

as shown in figure A.

It is not recommended to use this beverage

cooler with an extension cord or power board. Please ensure that the

appliance is plugged directly into the electrical outlet.

BEVERAGE COOLER INSTALLATION

• Remove the exterior and interior packaging before use.

• Check to be sure you have all of the parts and 1 owner’s manual.

• Place your beverage cooler on a flat, dry surface that is strong enough

to support the unit when fully loaded.

• This unit is designed to be built-in (fully recessed) or free standing.

• Do not place heavy objects on top of the unit.

• Unit is not designed for installation in a garage, basement, or any

other location where a controlled ambient environment between 60°

and 90°F cannot be maintained.

• Do not place the unit in direct sunlight or near sources of heat.

Extreme hot and cold ambient temperatures may cause the unit not to

perform properly or increase electrical consumption.

• Do not place the unit next to a major appliance that emits large

amounts of heat, such as a dishwasher, microwave, oven, etc.

• Do not plug unit into the same outlet as a refrigerator or microwave.

• Before connecting the appliance to the power source, let it stand

upright for approximately 24 hours. This will reduce the possibility of a

malfunction in the cooling system from handling during transportation.

• Clean the interior surface with lukewarm water using a soft cloth

before first use.

7

1 7 6 3 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1

i n f o @ v i n o t e m p . c o m

S N 3 2 B C H D 1 7 V T - S 1

OPERATING INSTRUCTIONS

1. Gently place/slide the racks into the beverage cooler.

2. Determine the best temperature setting to use.

3. Place bottles/cans inside the cooler.

4. Plug the power cord into a standard grounded electrical outlet.

5. Limit the frequency of opening the door to conserve energy and

maintain proper storage temperature.

6. You can turn the interior light on and off by touching the button

labeled with a light on the control panel.

Important: When using the beverage cooler for the first time, allow at

least 24 hours for the internal temperature to adjust properly. Make sure

there are at least 3 to 5 bottles in the unit.

TEMPERATURE CONTROL

Important: In order to operate efficiently, this product should be

in an environment with an ambient temperature of less than 90°F

(32°C).

Temperature preset:

For your convenience, the beverage cooler is programmed at storing

temperature. The temperature pre-set by the manufacturer is 48°F (9°C).

Setting the temperature:

You can manually adjust the temperature. Simply press the “ ” button

on the control panel to decrease the temperature and the “ ” button to

increase the temperature by 1 degree increments inside the beverage

cooler. The temperature range for this unit is from 40°F (4°C) to 65°F

(18°C).

When the cabinet temperature is too low, the LED will display “LL”. When

the temperature is too high, it will display “HH”. The “ER” display shows

when there has been a power disruption.

8

8

W W W . V I N O T E M P . C O M

S N 3 2 B C H D 1 7 V T - S 1

REVERSAL OF DOOR SWING

This beverage cooler is built with a reversible door. You have the choice of

either opening it from the left or the right side. In order to reverse the

opening direction of your door, please follow these simple instructions.

.

CAUTION: To avoid personal injury to yourself and/or property,

we recommend someone assist you during the door reversal

process.

1. Remove the top hinge assembly and

keep for later use.

2. Remove the plug buttons from the

upper left holes and transfer them to

the uncovered holes at the right side.

Be sure to press the plug buttons

firmly into the holes.

3. Remove the door assembly and keep

for later use.

4. Remove the right bottom hinge and

left bottom hinge and install them on

the opposite sides.

5. Re-install the door assembly with

the door handle on the opposite side

(Rotating the door assembly for

180°). Make sure the door assembly

is properly aligned on the cabinet.

6. Re-install the top hinge assembly

previously removed in step 1 on the

opposite side and tighten the screws.

The process is now complete.

Note: 1. If desired, change the door swing before installation.

2. Please remember, do not power up the unit for 48 hours after

cooler has been out of an upright position to allow the coolants

to settle inside the compressor.

9

1 7 6 3 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1

i n f o @ v i n o t e m p . c o m

S N 3 2 B C H D 1 7 V T - S 1

CLEANING AND CARE

• Always unplug the beverage cooler before cleaning.

• Do not use benzene, scrubbing brushes or chemical cleaners as these

will damage the unit.

• Use only a mild, nonabrasive cleanser to clean the exterior of the

cabinet.

• Clean the stainless steel door and handle by wiping with a warm water

and baking soda solution. The solution should be about 2 tablespoons

of baking soda to a quart of water.

• Wash the racks with a mild detergent solution.

• Always dry all parts with a clean dry cloth before plugging the

beverage cooler back into the receptacle.

MOVING YOUR BEVERAGE COOLER

• Always unplug the beverage cooler before moving.

• Always remove all beverages before moving the beverage cooler.

• Securely tape down all loose items (shelves) inside your appliance.

• Turn the leveling legs up to the base to avoid damage.

• Tape the door shut.

• Be sure the beverage cooler stays in the upright position during

transportation

• Protect the outside of appliance with a blanket or similar item when

moving as needed.

1

10

W W W . V I N O T E M P . C O M

S N 3 2 B C H D 1 7 V T - S 1

TROUBLESHOOTING

You can solve many common beverage cooler problems easily, saving you

the cost of a possible service call. Try the suggestion below to see if you

can solve the problem before contacting Vinotemp at info@vinotemp.com.

SYMPTOM POSSIBLE CAUSE

Door will not

close properly.

• The beverage cooler is not level.

• The shelves are out of position.

• The door was reversed and not properly installed.

• The door gasket is dirty.

Unit does not

operate—does

not have power

• Check that unit is plugged into the wall socket.

• Make sure the wall socket has power. If outlet is

controlled by a wall switch, make sure switch is set to

on. Test wall socket functionality by testing another

electrical appliance in the power socket.

Power is ON but

the unit will not

cool.

• Make sure there are at least 3 to 5 bottles in the unit.

When using the unit for the first time, it can take up

to 24 hours to reach the desired temperature.

• If the room temperature is above 90°F (32°C), the

unit will not get below 51°F (11°C). Humidity does

not affect the cooling ability of the unit.

• To achieve accurate temperature control, the unit

should not be used or operated in any of the

following locations:

o In a sunny place

o In a room with poor air circulation such as a

garage near another heat-producing appliance

such as a dishwasher, oven or refrigerator.

o With an outlet shared with a refrigerator, as the

refrigerator will drain power from the beverage

cooler.

o In a cabinet or closet.

• Make sure the cooling vents are not obstructed.

Fan is always

running.

• This is simply a function of the cooling system. The

lower the setting, the more the fan will run. If the

room is warmer than 90°F (32°C), it will run more.

• The unit has been designed to run continuously when

operating at the lower temperatures.

Vibrations • Check to make sure the beverage cooler is level.

11

1 7 6 3 1 S o u t h S u s a n a R o a d , R a n c h o D o m i n g u e z , C a l i f o r n i a 9 0 2 2 1

i n f o @ v i n o t e m p . c o m

S N 3 2 B C H D 1 7 V T - S 1

TERMS OF SALE AND WARRANTY

Vinotemp International (“Seller”) and the person or entity that acquires these goods from Seller (“Purchaser”)

hereby fully agree to the following terms and conditions of the sale: Shipping fees are the responsibility of the

Purchaser whether freight prepaid or freight collect. Seller assumes no responsibility for the goods sold to the

Purchaser once the goods have left the Seller’s premises, including, but not limited to, late delivery by the

moving carrier, or for events caused by any difficulty carrier incurs in attempting to fit the goods into the

Purchaser’s place of business or residence due to the size of the goods or otherwise. Purchaser assumes all

responsibility for delivery, payment of freight, access, measurement, installation, hook-up, wiring, moving and

storage of the goods. The transportation of all goods is subject to the terms and conditions which the moving

carrier imposes on Purchaser including, but not limited to, additional charges imposed per flight of stairs,

and/or additional charges resulting from the carrier’s inability to safely and/or adequately use the building

elevator to lift the goods to an upper floor. Any claim for damages incurred during shipment by the carrier of

the goods are insured and handled directly with the carrier. Any damages due to manufacture defects will be

handled directly with Vinotemp International, subject to the limited warranty.

All sales are final, and unless authorized in writing by the Seller, Purchaser may not return the goods, under

any circumstance. If Purchaser refuses to accept the goods, under any circumstance, the Purchaser is liable for

the return and cost of freight both ways, and if Seller does take back the goods, there will be a restocking

charge that is 35% of the purchase price of the goods. Purchaser must notify Seller of non-conforming goods

within four days of delivery, after which time all goods are deemed accepted.

If Purchaser tenders payment with a check that has insufficient funds (NSF), or stops payment on a check or

credit card for any reason, Purchaser agrees to pay for all costs associated with the Seller’s connection or

litigation of such a claim, including without limitation extra damages, court costs and attorneys’ fees. Finance

charges begin the date of invoice. Collection fees plus NSF fee of $50 will be added to your invoice, which you

agree to promptly pay. Title to the goods does not pass until payment is received in full by Seller and Seller

retains a security interest in the goods until they are paid for in full.

LIMITED WARRANTY: Seller warrants that the goods will be free of defects in materials and workmanship as

follows: Metal cabinet wine, beverage, refrigerator and freezer units: parts and labor for cooling system and

cabinetry for a period of 12 (twelve) months from date of sale, removal and re-installation of unit is not

included in warranty. For a scratch and dent or refurbished unit, warranty is 3 months from your dated invoice

(parts for function only, not cosmetic). There is no warranty on parts purchased separately. Purchaser’s

exclusive remedy is limited, at Seller’s option; to repair or replace defective part[s] with either new or factory

reconditioned part[s]. Purchaser is responsible for shipping the unit pre-paid to designated facility and Seller

will pay return shipping charges in the continental United States for items repaired under warranty within 12

months from date of sale. Improper placement of the unit will void the warranty. This limited warranty does

not cover damage due to such things as accident, misuse, abuse, mishandling, neglect, acts of God, fires,

earthquakes, floods, high winds, government, war, riot or labor trouble, strikes, lockouts, delay of carrier,

unauthorized repair, or any other cause beyond the control of the Seller, whether similar or dissimilar to the

foregoing. Seller is not responsible for any damages caused to Seller’s property resulting from the good. This

limited warranty applies only inside the Continental US. (Alaska, Puerto Rico and Hawaii are not warranted).

Purchaser understands and acknowledges that the goods sold here are beverage coolers and/or other similar

units which house beverage. Purchaser assumes all risk of using these units, including risk of spoilage,

humidity variations, temperature variations, leaks, fire, water damage, mold, mildew, dryness and similar and

any other perils that might occur.

Seller is not responsible for incidental or consequential damages, and there are no warranties, expressed or

implied, which extend beyond the Limited Warranty described above. The implied warranties of merchantability

and of fitness for a particular purpose are hereby expressly disclaimed. Some states do not allow the exclusion

of incidental or consequential damages, or a waiver of the implied warranties of fitness and/or merchantability,

so the above limitations may not apply to you. This warranty gives you specific legal rights and you may also

have other rights which vary from state to state.

In the event of any dispute between Seller and Purchaser arising out of or relating to these terms and

conditions or to the goods sold generally, Purchaser must first file a written claim with Seller within ten days of

the occurrence giving rise to the claim and wait an additional thirty days for a response before initiating any

legal action. The sale and all terms are subject to California law. Any legal proceeding arising out of or relating

to these terms and conditions or to the goods sold generally shall be brought solely and exclusively in the

County of Los Angeles. In no event may Purchaser initiate any legal proceeding more than six months after the

occurrence of the event giving rise to the dispute.

The above terms and conditions are the only ones governing this transaction and Seller makes no oral

representations of any kind. These Terms and Conditions can only be modified in writing, signed by both

Purchaser and Seller. 07/08

1

12

W W W . V I N O T E M P . C O M

S N 3 2 B C H D 1 7 V T - S 1

SERVICE & IMPORTANT NOTICE

Upon receipt and inspection of unit, the supply cord must be replaced if it is

damaged. Contact our customer service at 1-800-777-8466 or

info@vinotemp.com.

The manufacturer has a policy of continuous improvement on its products

and reserves the right to change materials and specifications without notice.

WARNING:

Please do not place the unit within reach of children.

For adult use only.

Contact info@vinotemp.com with any questions or visit:

www.vinotemp.com

17631 S. Susana Road

Rancho Dominguez, CA 90221

www.vinotemp.com

Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject

to change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim

liability for errors, omissions, or future changes.

© 2008 Vinotemp International. All rights reserved.
