D-302416 1
KF-234 PG2
Wireless PowerG 2-Way Keyfob
Installation Instructions
1. INTRODUCTION
KF-234 PG2 is a miniature PowerG 4-button (6-function) keyfob,
designed for use with the PowerMaster-10.
Transmission is initiated by pressing any one of the four recessed
pushbuttons. Upon pressing a specific button, the KF-234 PG2
transmits a PowerG message associated with the button that was
pressed and identifiable by PowerMaster-10 control panels.
A red LED lights during transmission. When an identified command is
received by the PowerMaster-10 control panel, it acknowledges the
command. Upon acknowledgement, the green LED lights and a
happy beep is heard to indicate successful completion of the
command or the red LED lights and a sad beep is heard to indicate
that the control panel cannot perform the command.
In addition, a battery report is transmitted
with the outgoing message. PowerMaster-
10 control panels are designed to identify
this report and operate a corresponding
output, if required.
Each keyfob is supplied with a small key
ring.
Operating power is obtained from an
internal 3V Lithium battery.
Figure 1:
External View
2. SPECIFICATIONS
Frequency Band (MHz): Europe: 433, 868, USA: 915
Modulation: GFSK
Antenna: Built-in helical antenna.
Communication Protocol: PowerG.
Battery type: 3V CR-2032 Lithium battery.
Caution!
Risk of explosion if battery is replaced by an incorrect type. Dispose
of used battery according to manufacturer's instructions.
Battery Life Expectancy: 8 years (for typical use)
Power Supply: Type C
Note: If transmission is still possible despite the battery condition, the
unit will send a low battery signal to the control panel.
Transmitted Messages: Arm Away, Arm Home, Arm Latchkey,
Disarm, AUX and Panic.
Operating Temperature: 0° to 55°C (32° to 131°F).
Humidity: Average relative humidity of approximate 75% non-
condensing. For 30 days per year relative humidity may vary between
85 % and 95 % non-condensing.
Dimensions: 60 x 34.5 x 12.5 mm (2-3/8 x 1-3/8 x 1/2 in.).
Weight (including battery) : 25 g (0.9 oz).
Color: Black
Compliance with Standards:
Europe: EN 300220, EN 50131-1 Grade 2, Class II and (EN 50134-2
Class II if used for social alarm), EN 301489, EN 50130-4, EN 60950,
EN 50131-6
USA: CFR47 Part 15
Canada: RSS 210
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for
help.
Warning!
Changes or modifications to this equipment not expressly
approved by the party responsible for compliance (Visonic Ltd.)
could void the user’s authority to operate the equipment.
This equipment complies with FCC RF radiation exposure limits
set forth for an uncontrolled environment.
3. ENROLLMENT
Refer to the PowerMaster-10 Installer Guide for the device enrollment procedure.
4. MODIFY DEVICE SETTINGS
This section describes how to configure the parameters for home monitoring of people from the PowerMaster-10 control panel.
To Modify the Keyfob Device Settings
Refer to the PowerMaster-10 Installer Guide and perform the procedure for Adding A Wireless Device (section 4.5.2), or, Modifying a Device
(section 4.5.5). Then continue below to modify the device settings.
1.
DEV SETTINGS
![](/img.php?id=1408110&img=bg2.png)
2 D-302416
Here you select the function of the AUX button on the KF-234 PG2 keyfob.
2.
3. or Select between "instant", "skip exit delay" and "PGM".
4.
When exiting "ZONES / DEVICES" menu the PowerMaster-10 system displays the number of
devices that need to be updated, as follows: DEV UPDATING NNN.
For detailed instructions on Adding Devices, Deleting Devices, Replacing Devices and Defining
Defaults see the PowerMaster-10 Installer Guide.
5. OPERATION
Initiate Panic Alarm: Press ARM AWAY and ARM HOME together
for 2 seconds.
Arming Latchkey: Press ARM AWAY/HOME twice.
Arm AWAY/HOME: Press AWAY or HOME button once.
Status: Press '' button once.
A
B
C
D
E
A. ARM "AWAY"
B. ARM "HOME"
C. LED
D. DISARM
E. AUX
Figure 2: Operation
6. MAINTENANCE
6.1 Replacing the Battery
A replacement 3V battery, CR-2032, is available from hardware and
electrical supply stores. Replace the battery as shown in Figure 3.
Caution! Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the manufacturer's
instructions.
1
A
3
2
B
CD
1. Remove backside screw and open the cover.
2. Using the screwdriver, push out the battery from its holder and
install new battery (polarity "+" as shown).
3. Test the unit by momentarily pressing one of the Transmit buttons
– the LED should light. Put back the cover and re-attach it with the
screw.
A. Button pad (make sure that it remains in its place).
B. LED indicator.
C. Battery holder.
D. Battery
Figure 3: Battery Replacement
6.2 Cleaning
The keyfob may get dirty if touched with greasy fingers. Clean it only
with a soft cloth or sponge moistened lightly with a mixture of water
and mild detergent, and wipe it dry immediately.
The use of abrasives of any kind is strictly forbidden. Also never
use solvents such as kerosene, acetone or thinner.
7. TESTING A NEW UNIT
Since the KF-234 PG2 is supplied with the battery already installed,
the unit is practically ready to be tested.
A. Stand 3 m (10 ft) away from a target control panel (or wireless
control panel) and press the ARM AWAY button (see Fig. 2).
Verify that the red LED lights upon transmission and that the
green LED lights upon acknowledgement from the
PowerMaster-10.
B. Make sure that the control panel responds as programmed and as
AUX A
AUX A
instant
![](/img.php?id=1408110&img=bg3.png)
D1821
3
stated in the control panel’s instruction manual.
8. MISCELLANEOUS COMMENTS
8.1 Product Limitations
Visonic Ltd. wireless systems are very reliable and are tested to high
standards. However, due to their low transmitting power and limited
range (required by FCC and other regulatory authorities), there are
some limitations to be considered:
A. Control panels may be blocked by radio signals occurring on or near
their operating frequencies, regardless of the code selected.
B. Wireless equipment should be tested regularly to determine
whether there are sources of interference and to protect against
faults.
![](/img.php?id=1408110&img=bg4.png)
4 D-302416
WARRANTY
Visonic Limited (the “Manufacturer") warrants this product only (the "Product") to the
original purchaser only (the “Purchaser”) against defective workmanship and materials
under normal use of the Product for a period of twelve (12) months from the date of
shipment by the Manufacturer.
This Warranty is absolutely conditional upon the Product having been properly installed,
maintained and operated under conditions of normal use in accordance with the
Manufacturers recommended installation and operation instructions. Products which
have become defective for any other reason, according to the Manufacturers discretion,
such as improper installation, failure to follow recommended installation and operational
instructions, neglect, willful damage, misuse or vandalism, accidental damage, alteration
or tampering, or repair by anyone other than the manufacturer, are not covered by this
Warranty.
The Manufacturer does not represent that this Product may not be compromised and/or
circumvented or that the Product will prevent any death and/or personal injury and/or
damage to property resulting from burglary, robbery, fire or otherwise, or that the Product
will in all cases provide adequate warning or protection. The Product, properly installed
and maintained, only reduces the risk of such events without warning and it is not a
guarantee or insurance that such events will not occur.
THIS WARRANTY IS EXCLUSIVE AND EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, OBLIGATIONS OR LIABILITIES, WHETHER WRITTEN, ORAL,
EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, OR OTHERWISE. IN NO CASE SHALL
THE MANUFACTURER BE LIABLE TO ANYONE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS WARRANTY OR ANY OTHER
WARRANTIES WHATSOEVER, AS AFORESAID.
THE MANUFACTURER SHALL IN NO EVENT BE LIABLE FOR ANY SPECIAL,
INDIRECT, INCIDENTAL, CONSEQUENTIAL OR PUNITIVE DAMAGES OR FOR
LOSS, DAMAGE, OR EXPENSE, INCLUDING LOSS OF USE, PROFITS, REVENUE,
OR GOODWILL, DIRECTLY OR INDIRECTLY ARISING FROM PURCHASER’S USE
OR INABILITY TO USE THE PRODUCT, OR FOR LOSS OR DESTRUCTION OF
OTHER PROPERTY OR FROM ANY OTHER CAUSE, EVEN IF MANUFACTURER
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
THE MANUFACTURER SHALL HAVE NO LIABILITY FOR ANY DEATH, PERSONAL
AND/OR BODILY INJURY AND/OR DAMAGE TO PROPERTY OR OTHER LOSS
WHETHER DIRECT, INDIRECT, INCIDENTAL, CONSEQUENTIAL OR OTHERWISE,
BASED ON A CLAIM THAT THE PRODUCT FAILED TO FUNCTION.
However, if the Manufacturer is held liable, whether directly or indirectly, for any loss or
damage arising under this limited warranty, THE MANUFACTURER'S MAXIMUM
LIABILITY (IF ANY) SHALL NOT IN ANY CASE EXCEED THE PURCHASE PRICE OF
THE PRODUCT, which shall be fixed as liquidated damages and not as a penalty, and
shall be the complete and exclusive remedy against the Manufacturer.
When accepting the delivery of the Product, the Purchaser agrees to the said conditions
of sale and warranty and he recognizes having been informed of.
Some jurisdictions do not allow the exclusion or limitation of incidental or consequential
damages, so these limitations may not apply under certain circumstances.
The Manufacturer shall be under no liability whatsoever arising out of the corruption
and/or malfunctioning of any telecommunication or electronic equipment or any programs.
The Manufacturers obligations under this Warranty are limited solely to repair and/or
replace at the Manufacturer’s discretion any Product or part thereof that may prove
defective. Any repair and/or replacement shall not extend the original Warranty period.
The Manufacturer shall not be responsible for dismantling and/or reinstallation costs. To
exercise this Warranty the Product must be returned to the Manufacturer freight pre-paid
and insured. All freight and insurance costs are the responsibility of the Purchaser and
are not included in this Warranty.
This warranty shall not be modified, varied or extended, and the Manufacturer does not
authorize any person to act on its behalf in the modification, variation or extension of this
warranty. This warranty shall apply to the Product only. All products, accessories or
attachments of others used in conjunction with the Product, including batteries, shall be
covered solely by their own warranty, if any. The Manufacturer shall not be liable for any
damage or loss whatsoever, whether directly, indirectly, incidentally, consequentially or
otherwise, caused by the malfunction of the Product due to products, accessories, or
attachments of others, including batteries, used in conjunction with the Products. This
Warranty is exclusive to the original Purchaser and is not assignable.
This Warranty is in addition to and does not affect your legal rights. Any provision in this
warranty which is contrary to the Law in the state or country were the Product is supplied
shall not apply.
Warning! The user must follow the Manufacturer’s installation and operational
instructions including testing the Product and its whole system at least once a week and
to take all necessary precautions for his/her safety and the protection of his/her property.
01/08
W.E.E.E. Product Recycling Declaration
For information regarding the recycling of this product you must contact the company from which you orignially purchased it. If you are discarding this product and not
returning it for repair then you must ensure that it is returned as identified by your supplier. This product is not to be thrown away with everyday waste.
Directive 2002/96/EC Waste Electrical and Electronic Equipment.
VISONIC LTD. (ISRAEL): P.O.B 22020 TEL-AVIV 61220 ISRAEL. PHONE: (972-3) 645-6789, FAX: (972-3) 645-6788
VISONIC INC. (U.S.A.): 65 WEST DUDLEY TOWN ROAD, BLOOMFIELD CT. 06002-1376. PHONE: (860) 243-0833, (800) 223-0020.
FAX: (860) 242-8094
VISONIC LTD. (UK): UNIT 6 MADINGLEY COURT CHIPPENHAM DRIVE KINGSTON MILTON KEYNES MK10 0BZ. TEL: (0870) 7300800
FAX: (0870) 7300801. TEL: (0870) 7300800 FAX: (0870) 7300801 PRODUCT SUPPORT: (0870) 7300830
VISONIC GmbH (D-A-CH): KIRCHFELDSTR. 118, D-40215 DÜSSELDORF, TEL.: +49 (0)211 600696-0, FAX: +49 (0)211 600696-19
VISONIC IBERICA: ISLA DE PALMA, 32 NAVE 7, POLÍGONO INDUSTRIAL NORTE, 28700 SAN SEBASTIÁN DE LOS REYES, (MADRID), ESPAÑA.
TEL (34) 91659-3120, FAX (34) 91663-8468. www.visonic-iberica.es
INTERNET: www.visonic.com
VISONIC LTD. 2010 KF-234 PG2 D-302416 (preparation for revision 1, 11/10) R
