Vivint KF01 Keyfob System Interface User Manual

Vivint. Inc. Keyfob System Interface Users Manual

Users Manual

The Vivint Secure Key Remote (SKEY1) works with any
Vivint Security System,
allowing users to
control their system with the touch of a button. Combining style
and convenience, the SKEY1 allows you to
arm, disarm, and control another device
in your system
anywhere within transmission range of the touchscreen panel. Users
enjoy the ease of disarming their system as they
pull up to their house or arming it
on the
ir way out the door.
T
he SKEY1 also provides reliable security by letting you send a panic signal to the
panel when the first and third buttons are held down.
All signals are encrypted,
providing an extra
level of security. The sleek design of the SKEY1 allows it to easily fit
on a key ring
, or in a pocket or purse.
Secure Key Remote
(V
-SKEY1-345)
Quick Reference
Programming Instructions
(
For more details, go to the Support page at: Vivint.com, and the KIM site at: corp.vivint.com/sites/KIM/)
Use the following guidelines t
o add an SKEY1 device to the Vivint system and program the operating mode:
• Add each SKEY1 into the panel as a non-supervised sensor.
• Secure Key Remotes must be "learned" into the panel. SKEY1 devices will not function properly in Secure
Mode if the sensor ID is manually entered into the panel.
MODE PROGRAMMING:
While the panel is learning in the SKEY1 (you must be within 5 feet/1.5 m of the panel), perform these steps:
• Hold the Disarm button as you insert the battery. The LED will turn on solid red indicating the SKEY1 is
ready to have its operating mode set by pressing one of the four buttons:
• Disarm — Standard Mode (the LED blinks once to indicate successful mode selection)
• Arm Staying — Standard Mode + GDR1 (the LED blinks twice)
• Arm Leaving — Secure Mode (the LED blinks three times)
• Asterisk (*) — Secure Mode + GDR1 (the LED blinks four times)
IMPORTANT: Secure Mode should always be used when possible. Once the SKEY1 is placed in Secure
Mode
with a Vivint Control Panel, it cannot be changed to either Standard Mode.
Installer Test
Press any of the buttons (for approximately 2 seconds) to send test signals to the panel when it is in Test Mode.
User Test
Test
each button's functionality by holding the button down separately (for approximately 2 seconds) until the
red LED flashes. (NOTE: If the panel is NOT in Test Mode, the signals will activate the actual designated event.)
Button Functionality
Disarm button: Press until the red LED illuminates to disarm the system.
Arm Staying button: Press until the red LED illuminates to arm in stay mode.
Arm Leaving button: Press until the red LED illuminates to arm in away mode.
Asterisk (*) button: Can be programmed to control other devices via the panel.
Disarm and Arm Leaving buttons: Hold down both buttons until the red
LED begins blinking rapidly (for about 4 seconds) to send a panic signal
to the panel only if the panel is configured to do so.
Specifications
Wireless Signal Range
Battery
Battery Life
Transmitter Frequency
Code Outputs
Supervisory Interval
Operating Temperature Limits
Relative Humidity
PRINT INSTRUCTIONS: REFERENCE SHEET V-SKEY1-345 P/N 77-000035-001 REV 1.1 |
INK:
BLACK | MATERIAL: 20 LB MEAD BOND | SIZE: 5.50" X 8.50" SCALE 1:1 |
FOLDS: TRI-FOLD VERTICAL, TRI-FOLD HORIZONTAL (TO FIT IN BOX)
Battery Installation
To install or replace the battery, insert a coin into the top
left corner slot and carefully twist to open the device.
NOTE: The red LED will blink 1-4 times upon battery insertion, indicating the operating mode of the SKEY1.
Use only the recommended replacement battery type (see Specifications).
FCC and Industry Canada Regulatory Declarations*
CAUTION:
Unauthorized changes or modifications could void the user’s authority to operate the equipment.
This device has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of FCC Rules and Industry Canada
license
-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation of the device.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This e
quipment generates, uses,
and can radiate radio frequency energy and
, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation
. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encou
raged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/television technician for help.
PRUDENCE
: Changements ou modifications pourraient annuler le droit de l'utilisateur à utiliser l'équipement non autorisées.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une
antenne d'un type et d'un gain maximal
(ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectriqu
e à l'intention des autres
utilisateurs, il faut choisir le type d'antenne et son gain de s
orte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité
nécessaire à l'établissement d'une communication satisfaisante.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux
conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en co
mpromettre le fonctionnement.
Ces limites sont conçues pour fournir une protection raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet équipement
génère, utilise et peut émettre une énergie de radiofréquence et, s'il n'e
st pas installé et utilisé conformément aux instructions, il peut causer des
interférences nuisibles aux communications radio. Cependant, il n'existe aucune garantie que des interférences no se produiro
nt pas dans une
installation particulière. Si cet équi
pement provoque des interférences nuisibles à la réception radio ou télévision, ce qui peut être déterminé en
mettant l'équipement hors et sous tension, l'utilisateur est encouragé à essayer de corriger l'interférence par une ou plusie
urs des mesures suiva
ntes:
• Réorienter ou déplacer l'antenne de réception.
• Augmentez la distance entre l'équipement et le récepteur.
• Connecter l'équipement à une sortie sur un circuit différent de celui sur lequel le récepteur est branché.
• Consulter le revendeur ou un technicien radio / télévision expérimenté pour de l'aide.
FCC ID:
2AAAS-KF01, IC ID: 10941A-KF01
*For more compliance and warranty information, visit: www.vivint.com
WARNING! The polarity of the battery must be observed (as shown in the image).
Improper handling of lithium batteries may result in heat generation, explosion, or fire,
which may lead to personal injury. Replace only with the same or equivalent battery type
as recommended by the manufacturer.
AVERTISSEMENT! La polarité de la batterie doit être observée (comme indiqué dans
l'image). Une mauvaise manipulation des piles au lithium peut conduire à la production
de chaleur, une explosion ou un incendie, ce qui peut entraîner des blessures. Remplacez-
le par le même type ou équivalent de la batterie tel que recommandé par le fabricant.
Batteries must not be recharged, disassembled
, or disposed of in fire.
Disposal of
used batteries must be made in accordance with the waste recovery and recycling
r
egulations in your area.
Keep away from small children. If batteries are swallowed,
promptly see a doctor.
California Only:
This Perchlorate warning applies ONLY to Manganese Dioxide Lithium cells sold or
distributed in California, USA. Perchlorate material special handling may apply.
(For more information,
visit:
www.dtsc.ca.gov/hazardouswaste/perchlorate)
© 2014 Vivint Inc. All Rights Reserved. | www.vivint.com | M/N: KF01 | Doc P/N: 77-000035-001 Rev. 1.1
Wireless Product Notice
Wireless communications hardware provides reliable communication; however, there are limitations whi
ch must be observed.
• The transmitters are required to comply with all applicable wireless rules and regulations. As such, they have limited
transmitter power and limited range.
• Wireless signals may be blocked by radio signals that occur on or near their operating frequencies.
