Vivint. Inc. 345 MHz Repeater Users Manual
Vivint >
Users Manual
The
Vivint 345 MHz Repeater (RPTR1) is a receiver/transmitter device with an internal antenna
that
extends the range of a Vivint wireless home security and automation system.
It does this by
listening for
alarm, status, and control signals from the 345 MHz wireless sensors (i.e., motion
detectors, door/window sensors,
fire/smoke and CO detectors, etc.), and repeating those signals
to
the control panel.
The 345 MHz Repeater
includes supervisory features so it can report relevant current status
information
such as tamper, AC power loss, low battery, bad battery, or loss of supervision.
The RPTR1 can
repeat signals from Vivint, 2GIG/Linear, and Honeywell 345 MHz sensors and
devices
. Only one 345 MHz repeater should be added to a system.
The repeater
device contains a rechargeable battery that can provide up to 30 hours of backup
standby power when prim
ary (external) power is lost.
This document includes installation
, usage, and test instructions, as well as technical specifications
and regulatory
declarations.
345 MHz Repeater
(V
-RPTR1-345)
Quick Reference
PRINT INSTRUCTIONS: REFERENCE SHEET V-RPTR1-345 P/N 77-600007-001 REV 1.0 |
INK:
BLACK | MATERIAL: 20 LB MEAD BOND | SIZE: 8.50" X 11.00" SCALE 1:1 |
FOLDS:
BI-FOLD VERTICAL, BI-FOLD HORIZONTAL (TO FIT IN BOX)
Front View (Cover Off):
Installation Instructions
(For more details about adding wireless sensors to the system, see product
Installation
documentation at the Knowledge In Motion site:
corp.vivint.com/sites/KIM/)
Mounting
the repeater device:
1. Remove the front cover by gently lifting the cover piece from the main body.
2. Connect the provided external power supply to the back of the repeater device,
and push the cable snugly into the slot (under the cable retention tabs
) so that the
device can be mounted flat against the surface of the wall.
3. Mount the repeater in the selected location (see Installation Tips). Use the single
round screw hole at the top of the device to insert the screw. Make sure to use a
screw anchor in the wall, and tighten the screw to securely attach the repeater.
(You may want to tighten the screw and then back it off a bit so that the repeater
can swing freely enough to self-straighten.)
4. Remove the battery pull tab to activate the backup battery. The blinking red TX
light indicates the repeater is transmitting signals between the system sensors and
the control panel.
(NOTE: The green PWR light does not turn on unless there is power from an
external power supply.)
5. Plug the power supply into an unswitched wall outlet.
6. Replace the front cover by pressing it directly onto the mounted repeater casing
and pushing gently until it clicks into place indicating it is securely closed.
INSTALLATION TIPS:
• Install the repeater in a location near an AC power outlet.
• To maximize wireless range, the r
epeater should be installed on a wall in the portrait
orientation, and located generally halfway between the most distant system
sensors
(e.g., sensors that are not communicating reliably) and the control panel.
• Install only one repeater device per Vivint system.
Back View:
Installer Test
Remove the Repeater front cover to trigger a tamper alert which sends a signal from the repeater to the control panel to conf
irm proper operation. Test the
sensors and detectors furthest from the control panel by triggering the sensor or pressing a test button or tamper on each de
vice.
Specifications
Wireless Signal Range
350 feet (106.7 m), open air
Batteries
Lithium-Ion Cylindrical 3.6 V 2200 mAh (non-servicable battery)
Battery Life
3-5 years under normal usage
Transceiver Frequency
345 MHz
Code Outputs
Supervisory, Tamper, Low Battery, Bad Battery, Wall Adapter Disconnect
Supervisory Interval
70 minutes (4 hours for panel to report supervision failure)
Operating Temperature Limits
32° to 120°F (0° to 49°C)
Relative Humidity
5-95% Non-Condensing
Battery Activation
The battery for the
repeater is a non-servicable rechargeable lithium-ion battery that is pre-installed inside the device. The battery provides backup power (for up to 30
hours)
when the power supply is disconnected and/or during a power outage.
Do not remove or tamper with the battery in any way. To activate the battery:
1. Pull out the battery pull tab to create a contact between the battery and the circuit board. The blinking red TX light indicates the repeater is transmitting signals. As
mentioned, from a non-powered state the battery will not engage until external power in applied.
2. Plug the power supply into the connector on the back of the device. Plug the AC/DC power supply into the AC power outlet. The solid green
PWR light indicates power
is being provided (not backup battery power).
FCC and Industry Canada Regulatory Declarations*
CA
UTION! Unauthorized changes or modifications could void the user’s authority to operate the equipment.
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rule
s and Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation of the device.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This e
quipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the inst
ructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or telev
ision reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/television technician for help.
PRUDENCE!
Changements ou modifications pourraient annuler le droit de l'utilisateur à utiliser l'équipement non autorisées.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres ut
ilisateurs, il faut choisir le type d'antenne et son gain de
sorte que la puissance isotrope rayonn
ée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitatio
n est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Ces limit
es sont conçues pour fournir une protection raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet équipement génère, utilise et peut
émettre une énergie de radiofréquence et, s'il n'est pas installé et utilisé conformément
aux instructions, il peut causer des interférences nuisibles aux communications radio.
Cependant, il n'existe aucune garantie que des interférences no se produiront pas dans une installation particulière. Si cet
équipement provoque des interférences nuisibles à la
réception radio ou télévision, ce qui peut être déterminé en mettant l'équipement hors et sous tension, l'utilisateur est enc
ouragé à essayer de corriger l'interférence par une ou
plusieurs des mesures suivantes:
• Réorienter ou déplacer l'antenne de réception.
• Augmentez la distance entre l'équipement et le récepteur.
• Connecter l'équipement à une sortie sur un circuit différent de celui sur lequel le récepteur est branché.
• Consulter le revendeur ou un technicien radio / télévision expérimenté pour de l'aide.
FCC ID:
2AAAS-RP01
IC ID:
10941A-RP01
WARNING! This battery is not servicable. Do not remove the battery cover. Improper handling of lithium batteries may result in heat generation, explosion, or fire,
which may lead to personal injury.
AVERTISSEMENT! Une mauvaise manipulation des piles au lithium peut conduire à la production de chaleur, une explosion ou un incendie, ce qui peut entraîner des
blessures.
Batteries must not be disassembled or disposed of in fire.
Disposal of used batteries must be made in accordance with the waste recovery and recycling regulations in your area.
Keep away from small children. If batteries are swallowed, promptly see a doctor.
© 2015 Vivint Inc. All Rights Reserved. | www.vivint.com | 1-800-216-5232 | Device M/N: RP01 | Doc P/N: 77-600007-001 Rev. 1.0
Wireless Product Notice
Wireless communications hardware provides reliable communication; however, there are some limitations which must be observed.
• The transmitters are required to comply with all applicable wireless rules and regulations. As such, they have limited transmitter power and limited range.
• Wireless signals may be blocked by radio signals that occur on or near the wireless operating frequencies.
