ViviCam 5118v2 Digital Camera

User Manual

Windows and the Windows logo are registered trademarks of Microsoft Corporation.

All other trademarks are the property of their respective companies.

Table of Contents

Introduction .................................................................................................................................. 2

What‟s Included ............................................................................................................................ 2

Parts of the Camera ..................................................................................................................... 3

Initial Camera Setup ..................................................................................................................... 4

Main Camera Modes .................................................................................................................... 8

Camera Technical Specifications .................................................................................................. 9

Computer System Requirements – WINDOWS OS ................................................................... 10

Computer System Requirements – MAC OS ............................................................................. 10

Powering the Camera On/Off ...................................................................................................... 11

Changing Camera Mode ............................................................................................................. 11

Navigating the Menus................................................................................................................. 12

Photo Capture Mode .................................................................................................................. 13

Photo Playback Mode ................................................................................................................ 29

Video Capture Mode .................................................................................................................. 35

Video Playback Mode ................................................................................................................. 47

Installing the Software ................................................................................................................ 51

Connecting the Camera to the Computer ................................................................................... 52

Getting Photos and Videos from your Camera to Your Computer .............................................. 53

Get started!................................................................................................................................. 54

Transfer media from my camera to my computer manually (Using Windows) ............................ 54

Transfer media from my camera to my computer manually (Using Macintosh) .......................... 55

Camera Maintenance ................................................................................................................. 55

Sakar Warranty Card .................................................................................................................. 56

Technical Support ....................................................................................................................... 57

Troubleshooting .......................................................................................................................... 57

Introduction

Thank you for purchasing this camera. Everything you need to take quality digital photos and

videos is included with your camera.

Vivitar makes capturing those special moments as easy as possible.

Please read this manual carefully first in order to get the most out of your digital camera.

Note: Your camera needs an SD Memory card (up to 32GB) for normal use.

SD Memory cards are not included and need to be purchased separately.

What’s Included

1. Digital Camera

2. USB cable

3. Vivitar Experience Image Manager

software Installation CD

4. Wrist Strap

Note: SD Memory Card and batteries not included.

Parts of the Camera

1. Power Button

12. ViviLink / Down Button

2. Shutter Button

13. Flash Light

3. LCD Screen

14. USB Slot

4. LED

15. Tripod Socket

5. Zoom Out

16. Digital Lens

6. Zoom In

17. Battery Compartment

7. MODE button

18. SD Memory Card Slot

8. SET button

19. MACRO Switch

9. Scene / Left Button

20. Wrist Strap Connector

10. Flash / Up / Slide Show

21. Self-Timer LED

11. Delete / Right Button

Initial Camera Setup

Installing the Batteries

Installing the Memory Card

 Insert 2 AA (1.5V) batteries. Alkaline

batteries recommended (not included).

 SD Memory card (up to 32GB)

needed for normal use.

Turning On the Camera

Using the Camera

Selecting

the modes

Accessing the menu

When powering the camera ON for the first time the camera will take you through the INITIAL

CAMERA SETUP.

Powering the Camera ON

1) Batteries

Make sure the batteries have been inserted properly into your digital camera, according to

the polarity shown inside the battery compartment.

Use 2x AA (1.5v) batteries. Alkaline batteries are recommended. (Batteries not included.)

Note:

 Remove the batteries from the camera when not in use for an extended period.

 Do not mix alkaline and non-alkaline batteries.

 Some features, such as Flash, will not work if the battery power level is low.

 When the battery power is low the battery icon turns red and the camera will

automatically turn off a few seconds later.

 The energy status of the power is displayed on LCD as shown below:

Full battery power Medium battery power Low battery power

2) SD Card

Make sure an SD card has been properly inserted into your camera. (SD card not included.)

To properly insert the SD Card:

Push the SD card into the slot in the direction shown on the camera (see SD icon by the SD

card slot). Push the SD card until you hear a slight clicking sound. This indicates the SD

card has been inserted correctly.

Note:

 After the camera is powered on, an SD icon will appear on the LCD display. If you do not

see the SD icon on the display, please check if the card was inserted properly.

 Make sure the SD card is not locked (check the lock switch on the side of the SD card). If

the SD card is locked this will prevent the camera from saving captured photos to the SD card.

3) Power On

Press the POWER button to turn on the camera.

Setting the Camera Language

1) You will first be prompted to select a language for the camera. The Language selection

menu will appear. Select the language of your choice by pressing the UP and DOWN

direction control buttons. Then press the SET button to confirm the selection.

2) After selecting a language, you will be asked if you would like to continue with the initial

camera setup. A message will appear: “Continue with Camera Setup?”

Select “Yes” to continue or “No” to exit the setup.

Note: If you select “No” and decide to leave the camera setup, the camera will be set to its default

settings. These settings can be adjusted at any time manually through the menus in the camera.

Setting the Date and Time

The next step in the initial camera setup is to set the date and time on the camera.

Set the Date and Time as desired by pressing the RIGHT and LEFT direction control buttons to

choose the specific setting and the UP and DOWN buttons to change each setting.

Once you have completed setting the time and date, press the SET button to confirm the

selection and move to the next part of the camera setup.

Setting the ViviLink Default Option

Once the Date and Time have been set, you will be asked to set the default ViviLink destination

for photos and videos taken with your camera.

The ViviLink technology allows you to quickly and easily upload your camera‟s photos and videos

to the social networks of your choice with the accompanying software application.

1) First you will be asked to choose the default ViviLink social network for Photos. Press the

UP or DOWN buttons to highlight the desired default social network and press the SET

button to confirm the selection.

2) Next you will be asked to choose the default ViviLink social network for Videos. Press the

UP or DOWN buttons to highlight the desired default social network and press the SET

button to confirm the selection.

3) After the ViviLink Video option is confirmed the camera is now ready to use.

Main Camera Modes

Your camera has different modes for the various camera functions.

You can switch modes by pressing the MODE button on your camera after the camera has been

powered ON.

Photo Capture Mode

Use this mode to capture pictures with your camera.

This is the default mode when the camera is powered ON.

To take a picture, aim your camera as desired and press the Shutter button.

The picture will be automatically saved to your camera‟s memory card.

To access the various menus for the Photo Capture mode, press the SET button while in

the Photo Capture mode.

Video Capture Mode

Use this mode to capture videos with your digital camera.

After turning on your camera, press the MODE button once to open the Video Capture

mode. To take a video, aim your camera as desired and press the Shutter button to start

the record. A red record indicator will appear on the LCD screen while record is in progress.

To stop the record, press the Shutter button again. The video will be automatically saved to

your camera‟s memory card.

To access the various menus for the Video Capture mode, press the SET button while in the

Video Capture mode.

Playback Mode (Photos & Videos)

Use this mode to view and manage the photos and videos on your camera.

After turning on your camera, press the MODE button twice to open the Playback mode for

photos and videos. You can scroll through the photos and videos that you‟ve previously

taken to view, edit or delete them as desired.

To access the various menus for the Playback mode for photos and videos, press the SET

button while in the Playback mode.

Camera Technical Specifications

Image Sensor

CMOS Sensor

Image Resolution

2592x1944(5M) / 2048x1536(3M) /1920x1080(2M-HD) /

640x480(VGA)

Video Resolution

640X480 pixels (30 fps), 320X240 pixels (30 fps)

File Format

JPEG/AVI

Internal Memory

1 Test Photo Use Only

External Memory

SD Card (up to 32GB)

LCD Display

1.5 Inch TFT

Lens

f=5.1mm F2.8

Zoom

4X Digital Zoom

Exposure

-3.0EV ~ +3.0EV

White Balance

Auto, Daylight, Cloudy, Fluorescent , Incandescent

ISO

Auto / 100 / 200 / 400

Scene

Auto, Night Scenery, Night Portrait, High Sensitivity

Flash

No Flash, Forced On, Auto Flash, Red Eye Reduction

Self-Timer

2, 5 or 10 second delay

Print Photos

Yes

Macro

Yes, Manual Switch

Interface

USB 2.0

System Requirements

Windows XP (SP 3), Vista (SP1) and 7 / Mac OSX v10.5.x and

above

Battery

2 * AA (1.5V) batteries

Working Temperature

0~40 ℃

Computer System Requirements – WINDOWS OS

To be able to download photos and videos to your PC using the Vivitar Experience Image

Manager Software, you will need the following minimum configuration:

 Microsoft® Windows XP with Service Pack 3, Windows Vista with Service Pack 1 or Windows 7

 Pentium® 4 processor (or above)

 512 MB of RAM, with 250 MB of free hard disk space

 16-bit Color monitor, 1024 X 768 recommended screen resolution

 CD-ROM Drive

 QuickTime® 6 or higher

 Microsoft® Internet Explorer 7 or higher

 Windows Media Player 10 or higher

 DirectX 9 or higher

 Internet connection required

Computer System Requirements – MAC OS

To be able to download photos and videos to your Macintosh using the Vivitar Experience Image

Manager Software, you will need the following minimum configuration:

 Intel processor running Mac OS X v10.5.x or later

 256 MB RAM, 250 MB free hard disk space

 Display: 1024 x 768 or higher-resolution monitor

 QuickTime® 6 or higher

 Internet connection required

Powering the Camera On/Off

 Make sure the batteries have been inserted properly into your digital camera. If your camera

comes with a rechargeable lithium battery, make sure it is fully charged before the first use.

 Make sure an SD card has been inserted into your camera.

(SD card up to 32GB - SD Card not included)

Powering the camera ON

Press the Power button to turn your camera ON.

 After powering on, the camera emits a sound and the LED light turns on briefly.

 The LCD screen turns on with your camera in Photo Capture mode to start.

Powering the camera OFF

While the camera is on, you can press the Power button again at any point to turn your

camera OFF.

 A “Goodbye” screen appears and then the camera will power off completely.

Note: Your digital camera also has an Auto Power Off feature that will automatically turn off your

camera after a specific period of time that your camera is left idle. The Auto Power Off settings

can be set from the Auto Power Off settings menu (in either Photo Capture Mode or Video

Capture Mode).

Changing Camera Mode

Your camera has three main modes:

1) Photo Capture Mode - Use this mode to capture photos with your camera.

2) Video Capture Mode - Use this mode to capture videos with your camera.

3) Playback Mode (for photos and videos) - Use this mode to view the photos and videos

you have already taken with your camera.

 When the camera is first powered ON, the Photo Capture Mode will be active.

 The icons that appear on the LCD screen are the best default settings so that you can begin to

capture and enjoy clear quality photos.

To change the active camera mode, make sure the camera is powered ON and press the MODE

button.

When in Photo Capture Mode, this icon will display on the top-left corner of the LCD display

When in Video Capture Mode, this icon will display on the top-left corner of the LCD display

When in Playback Mode, this icon will display on the top-left corner of the LCD display

Navigating the Menus

Each camera mode has a set of menus specific to that mode.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll between the various menus for

the current mode.

3) Press the UP or DOWN direction control buttons to highlight the desired menu selection.

4) Press the SET button to confirm and save the highlighted menu option.

5) If the selection can be remembered by the camera, a selection icon will appear to the

right of the selected menu option. Changes made to these options will remain as is until you

decide to change them again at a later time.

6) Some menu options are single-use functions that are not remembered by the camera and

do not display this icon when selected.

7) At any time you can press the MODE button to exit the menus and return to the previous

screen.

Photo Capture Mode

The Photo Capture mode allows you to capture pictures with your digital camera.

Taking a Picture

1) While in Photo Capture mode, use the LCD display on the back of the camera to direct the

camera at the scene you would like to capture.

2) Press the T/Zoom In and W/Zoom Out buttons to zoom in/out if desired.

You can magnify your subject up to 4 times using the digital zoom.

The following Digital Zoom Indicator appears on the LCD screen:

Note: The actual shape of the zoom buttons may vary per camera model.

3) Click the Shutter button to take the picture.

4) The picture will automatically be saved to the memory or SD card.

Photo Capture Mode Quick Function Buttons

Your digital camera has a four-directional pad that functions as Quick Function buttons:

Button

Function

Left

Scene Selection – Opens the Scene menu

Flash Options – Toggles the Flash options appearing on the LCD

Right

Delete – Opens the „Delete This Photo‟ option and allows you to view and

delete the last photo taken as well as previously captured photos

Down

ViviLink – Opens the ViviLink for Photos menu

Other

Shutter

Captures the photo

SET

 Opens the menu options for Photo Capture Mode

 Saves your selected menu option

Note: To navigate through the Menus, use the UP/DOWN/LEFT/RIGHT directions

control buttons.

MODE

 Toggles between the Photo Capture Mode, Video Capture Mode and

Playback Mode

 Exits the menu screen

Zooms In

Zooms Out

Flash Options

There are several Flash options available on your camera. The options appear on the Photo

Capture Mode LCD screen in sequence.

To change the Flash mode, press the UP Quick Function button until you arrive at your desired

settings.

Important: When using Flash, stand between 8 to 10 feet away from the scene you would like to

capture.

Note: The MACRO mode must be turned OFF when you want to use the Flash.

 To turn off MACRO mode: Slide the MACRO Switch down to the mountain icon .

 When MACRO is OFF, the mountain icon appears on the LCD display.

Flash Type

Description

Forced Off (Default)

 No flash will appear.

 Use this when you do not want to activate Flash.

Auto Flash

 When you want the camera to determine if Flash is needed, select

Auto Flash.

 The flash will automatically turn on according to the lighting

conditions.

 When the LED light stops blinking, the Flash is ready for use.

Note: In some cameras, an initial flash appears to test your lighting

conditions. If flash is needed, a second flash will appear upon taking

the photo.

Forced On

 The flash is enabled for each photo.

 Note: If you use this option in a well lit environment, your photo

may be appear too bright/light (overexposed).

Red Eye

 Eliminates the red-eye effect in a photo caused by flash.

Macro Switch /

MACRO ON:

Your camera contains a Macro Switch that allows you to manually enable or disable the Macro

mode on your camera. While using the Macro mode, you can capture images at close range (15

~ 30 cm). To turn the Macro mode ON, slide the Macro Switch up on the side of your camera to

the flower icon .

 When enabled, the Macro mode will allow your camera to focus on an object that is close to

the camera.

 The flower icon will appear on the LCD and indicates that the Macro mode is ON.

 The Macro Light will also be lit, indicating the Macro feature is ON.

To turn Macro mode OFF:

 Slide the Macro Switch down on the side of the camera to the mountain icon.

 When Macro mode is off, images can be captured from 1.5m - ∞ (infinity).

Note:

 The Macro mode must be turned OFF when you want to use the following features of your

camera: Flash.

 Slide the Macro Switch to the mountain icon to turn Macro mode OFF. The mountain

icon will appear on the LCD display.

Photo Capture Mode Menus

The following are the menus that appear in your camera‟s Photo Capture Mode:

Scene Menu

The Scene Menu allows you to choose scene settings that let your camera to adapt properly to

your current environment.

Note: When selecting the HIGH SENSITIVITY Option, by default the camera switches off the

FLASH automatically (if it‟s ON) to optimize the picture quality. If however, you would like to

override it and manually turn ON the flash – you can do so.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Scene menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen.

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Image Resolution Menu

The Image Resolution menu allows you to choose the desired size of the images taken by your

camera. Keep in mind that images with a higher resolution will also take up more of your

camera‟s memory.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Image Resolution

menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen.

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Image Quality Menu

The Image Quality menu allows you to select the desired quality level of the images taken by your

camera. Keep in mind that images with a higher image quality level will also take up more

memory on your camera.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Image Quality

menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen.

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Self-Timer Menu

The Self-Timer menu allows you to set a delay between the time that the camera‟s Shutter button

is pressed and the actual capture of the picture.

This is an optimal feature if you don‟t just want to take the picture but would also like to be in the

picture yourself. Just set the desired Self-Timer delay, press the Shutter button on your camera

and position yourself in front of the camera as desired.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Self-Timer menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen.

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

White Balance Menu

The White Balance feature allows your camera to adjust the coloring of the captured images

depending on the type of light source in the current environment.

Properly adjusting the White Balance setting to match your current environment will allow the

camera to properly balance the colors in the images that are taken with your camera.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the White Balance

menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Color Effect Menu

You can choose to add a color effect to the images taken with your camera.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Color Effect

menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Image Sharpness Menu

You can set the level of sharpness in the images taken with your camera. The sharpness level

dictates if the edges of objects in the image are more or less distinct.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Image Sharpness

menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Light Exposure Menu

The Light Exposure setting helps you control the amount of light that enters your camera‟s lens.

This setting should be adjusted when the environment is lighter or darker than normal.

When the environment has more light than is needed, reduce the exposure setting (by using the

negative - count) to reduce the amount of light allowed into the lens by your camera.

If the environment has less light (darker) than is needed, increase the exposure setting (by using

the positive + count) to increase the amount of light allowed into the lens by your camera.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Light Exposure

menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

ISO Menu

The ISO menu allows you to set the level of sensitivity that your camera has to light in the

surrounding environment. When the ISO level is increased, the image sensor in your camera will

be more sensitive to light and allow you to capture images in lower-light situations. The higher

sensitivity to light however, may reduce the quality of the images that are taken.

When the ISO is reduced, the image sensor in your camera will be less sensitive to light and will

optimize the image quality in environments with bright lighting.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the ISO menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Metering Menu

The Metering setting will affect how your camera focuses when capturing an image. Depending

on your selection, the camera will be more sensitive to focusing on particular areas in the display

and adjust the image color and lighting accordingly.

Center – Averages the light metered from the entire frame, but giving greater weight to the

subject in the center

Multi – Used in standard conditions the camera divides and adjusts the settings of the image into

several zones for light metering such as complex light conditions, position of subject, brightness,

background, direct light and scenes

Spot – Meters the area within the spot point frame at the center of the LCD to set the exposure

on the subject in the center of the monitor.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Metering menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen.

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Language Menu

You can select your camera‟s language setting by selecting the desired language from the

Language menu.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Language menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Date/Time Menu

When you capture an image with your camera, the image will include a time stamp with the date

and time that the image was taken.

The Date/Time menu allows you to set your camera‟s date and time as desired. You can also

disable the timestamp for future images that will be taken with your camera.

On – The timestamp will appear on photos taken

Off – The date stamp will not appear on photos taken

To Enable/Disable the Timestamp:

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Date/Time menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

To Set the Date and Time:

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Date/Time menu.

3) Press the UP or DOWN direction control buttons to highlight the “Date Setup” menu option,

then press the SET button to select the option.

4) The “Date Setup” submenu will open.

5) Scroll through the window with the RIGHT and LEFT navigation buttons.

6) For each field in the menu, use the UP and DOWN navigation buttons to set the date and time.

7) When you have finished setting the date and time, press the SET button to save your

settings and return to the previous mode.

8) Press the MODE button to exit the menu without saving your settings and return to your

previous screen.

Silent Mode Menu

You have the option of activating the camera‟s Silent mode to disable all of the sound effects

(except for beeps heard during the Self-Timer countdown) that the camera emits when

performing camera functions.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Silent Mode menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Auto Power Off Menu

You can use the Auto Power Off feature in order to conserve you camera‟s battery life. The

designated time represents when your camera will automatically power off.

When the camera sits idle for the designated period of time, the camera will shut off completely

and will need to be powered on again with the power button before the next use.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Auto Power Off menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Frequency Menu

The options in the Frequency menu represent the frequency of the electrical current in

fluorescent lighting sources in your locale. If your camera is set to a frequency that does not

match your country‟s electric current, you may see waves on the images taken by your camera.

50Hz – UK, Europe and Australia

60Hz – US, Canada and South America

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Frequency menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Format Memory Card Menu

You can use the Format Memory Card menu to delete all of the content that is currently on your

camera‟s memory card.

Keep in mind that formatting the memory card will permanently delete all of the content on

your camera’s memory card.

This option will delete all of the content at one time. If you would like to delete individual images,

use the delete menu in the camera‟s Playback mode.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Format Memory

Card menu.

3) Press the UP or DOWN direction control buttons to highlight the menu options.

4) To exit without formatting the card, select „Cancel‟ and press the SET button.

5) To proceed with the format, select “Yes” and press the SET button.

You will be asked to confirm the formatting of the memory card.

 Select “No” to exit without formatting.

 Select “Yes” and press the SET button to begin the format.

The memory card will be completely formatted.

Firmware (Factory Default Settings) Menu

Use this menu to view the Firmware version on your camera or to reset your camera settings to

the Factory Default Settings.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Firmware menu.

3) The “Default Setting” is selected.

4) Press the SET button to reset the camera to the factory default settings.

5) You will be asked to confirm the resetting to the factory default settings.

 Select “No” to exit the menu and return to the previous mode without resetting to the

default settings.

 Select “Yes” and press the SET button to proceed with the reset.

You will then automatically exit the menu and return to the previous mode with the digital

camera settings set to the Factory Default Settings.

Note: After RESETTING to the default settings, it is recommended to select your system

Language, Date/Time and ViviLink for Photos and Videos. If you do not, the next time your

camera is powered on, you will be prompted to define those settings.

Photo Playback Mode

The Playback Mode allows you to review and edit photos and videos that you‟ve already taken

with you camera.

 When you first turn on the camera, the camera will be in Photo Capture mode by default.

 Press the MODE button twice to open the Playback Mode.

 The latest captured image appears on the LCD screen. If there are no images stored, a

message (No File) appears.

Viewing Photos on Your Camera

1) Select your Photo:

 Once in Playback Mode, press the LEFT or RIGHT direction buttons to scroll through the

images on your camera‟s memory card until you find the image you would like to view.

 Each captured image (video and photo) is displayed on the LCD screen.

 Photos appear with a „JPG‟ icon on the top left of the LCD screen.

2) Zooming In/Out of your selected Photo:

 Press the T / Zoom In button to Zoom In and magnify the selected photo.

Use the UP / DOWN / LEFT / RIGHT direction buttons to navigate around the photo.

 Press the W/Zoom Out button to Zoom Out of the selected photo.

Use the UP / DOWN / LEFT / RIGHT direction buttons to navigate around the photo.

Thumbnail View

Easily navigate and select the image you wish to view by using the Thumbnail View.

The images on your camera will be displayed in a 3 X 3 matrix where you can use the direction

buttons to scroll and select images from the thumbnails.

1) Press the W/Zoom Out button.

All the images on your camera will appear in the Thumbnail View.

2) Use the UP / DOWN / LEFT / RIGHT direction buttons to scroll and select the image you

wish to view.

3) Press the SET button to enlarge the selected image full size.

Photo Playback Mode Quick Function Buttons

Your digital camera has a four-directional pad that functions as Quick Function buttons.

Quick Function Button

Function

Left

Displays the PREVIOUS image

Views all the Photos as a Slide Show with 3, 5 or 10 second

intervals. To exit the Slide Show, press any button.

Right

Displays the NEXT image

Down

ViviLink – Opens the ViviLink for Photos menu

Other

W/Zoom out

Opens Thumbnail View

 To Navigate in the Thumbnail View: press the UP / DOWN /

LEFT / RIGHT direction buttons

 To select a JPG in the Thumbnail View: press the SET

button

SET

 Opens the menu options for Photo Playback Mode

 Saves your selected menu option

Note: To navigate through the Menus, use the

UP/DOWN/LEFT/RIGHT directions control buttons.

Photo Playback Mode Menus

The following are the menus that appear in your camera‟s Photo Playback Mode:

Delete Menu

While in the Playback Mode, you can delete pictures from your camera through the Delete menu.

1) View the photo you would like to delete.

2) Press the SET button to open the menus for the Photo Playback mode.

3) Press the LEFT or RIGHT direction control buttons to scroll and select the Delete menu.

4) Press the UP or DOWN direction control buttons to scroll through the menu options.

5) To delete the selected photo:

Select “Delete This Photo?” and press SET button.

You will be asked to confirm the deletion of the photo.

 If you would like to proceed with deleting the current image: select „Yes‟ and press the

SET button to confirm. The photo will be deleted and you will exit the menu and return to

the Playback mode.

 If you do not want to delete the current image, select „No‟ and press the SET button. The

photo will not be deleted and you will exit the menu and return to the Playback mode.

6) To delete all the images (videos and photos) you have saved on your SD Memory card:

Select „Delete All Images‟ and press the SET button.

 If you would like to proceed with deleting all the videos and photos, select „Yes‟ and press

the SET button to confirm.

All of your images will be permanently deleted.

A blank „No Files Exist‟ screen will appear.

Press the MODE button to exit the „No Files Exist‟ screen and return to Photo Capture

mode.

Remember: All images will be deleted except images that are Protected/Locked. To

delete a locked image, first unlock the image, then select delete.

 If you do not want to delete all of your videos and photos, select „No‟ and press the SET

button. All images will remain on your SD card and you will exit the menu and return to

the Playback mode.

ViviLink Menu

The ViviLink technology allows you to quickly and easily upload your camera‟s photos and videos

to the social networks of your choice with the accompanying Vivitar Experience Image Manager

application.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the ViviLink menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select the desired option.

5) A selected option icon will appear on the selected item.

6) An icon will appear on the image with the selected ViviLink destination site when you return

to the Playback display.

7) Remember that the ViviLink feature is deactivated by default. A ViviLink destination will only

be assigned to a photo or video if you manually set it from this menu or from the ViviLink

menu in Capture mode (accessible with the ViviLink Quick-Function button in Capture

mode).

8) Changing the ViviLink destination site will also make the selected site the new default

ViviLink option. A new default can be selected at any time through this menu.

9) Press the LEFT or RIGHT button to select the next menu item.

10) Press the MODE button to exit the menu and return to your previous mode.

Rotate Menu

Use this menu to rotate the pictures that you‟ve taken with your camera.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Rotate menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) The selected picture will now appear rotated in the Playback mode.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

Protect/Lock Menu

Pictures and Videos taken with your camera can be protected or “locked” to prevent any deletion

or alteration being made to the files.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Protect/Lock

menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select the desired option.

5) Press the LEFT or RIGHT button to select the next menu item.

6) Press the MODE button to exit the menu and return to your previous mode.

7) Any image that is locked will display a lock symbol on the LCD screen when viewing that

image in the playback mode. Photos that are not locked will not display the lock symbol.

8) Remember that you cannot delete or edit photos while they are locked.

Print This Photo Menu

You can use the Print Photos menu to print the photos that are on your camera directly to a

Pictbridge compatible printer.

1) Scroll through your pictures and find the one you would like to print.

2) Press the SET button to open the menus for the current mode.

3) Press the LEFT or RIGHT direction control buttons to scroll and select the Print This Photo

menu.

4) Press the UP or DOWN direction control buttons to scroll through the menu options.

5) Press the SET button when highlighting the “Print This Photo” option to print the selected

photo.

6) You will be asked to connect the camera to the Pictbridge printer.

7) Connect the USB cable provided in the package from the camera to the Pictbridge port of

the printer.

8) Once connected, follow the instructions on the printer to proceed with the printing process.

9) Select the “Cancel” option to exit the menu and return to the previous mode.

Slide Show Menu

You can view a Slide Show of all the pictures taken with your camera by pressing the UP Quick

Function button while in Playback mode. The Slide Show menu allows you to set the interval

length of time that each picture will display during the slide show.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Slide Show menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) While in Playback mode, press the UP Quick Function button to initiate the slide show.

9) Press any button to exit the slide show and return to the previous mode.

Video Capture Mode

The Video Capture Mode allows you to capture videos with your digital camera.

When the camera is first powered ON, the camera will be in Photo Capture Mode.

Press the MODE button once to access the Video Capture Mode.

Taking a Video

1) While in Video Capture Mode use the LCD display to direct the camera at the scene you

would like to capture.

2) Click the T/Zoom In and W/Zoom Out buttons to better set the camera display if

desired.

Note: The actual shape of these buttons may vary per camera model.

3) Press the Shutter button on the top of the camera to START the video capture.

4) You will see a red icon at the top of the LCD indicating that the record is in progress.

5) To STOP the video record, press the Shutter button again.

6) The video will automatically be saved to the camera‟s memory or SD card.

Video Capture Mode Quick Function Buttons

Your digital camera has a four-directional pad that functions as Quick Function buttons.

Quick Function Button

Function

Left

Scene Selection - Opens the Scene menu

Light Exposure – Opens the Light Exposure menu

Right

Delete - Opens the „Delete This Video‟ option and allows you

to view and delete the last video taken as well as previously

captured videos

Down

ViviLink - Opens the ViviLink for Videos menu

Other

Shutter

STARTS/STOPS the video capture

SET

 Opens the menu options for Video Capture Mode

 Saves your selected menu option

Note: To navigate through the Menus, use the UP/DOWN/LEFT/RIGHT

directions control buttons.

MODE

 Toggles between the Video Capture Mode, Photo Capture

Mode, and Playback Mode

 Exits the menu screen

Zooms In

Zooms Out

Video Capture Mode Menus

The following are the menus that appear in your camera‟s Video Capture Mode:

Scene Menu

The Scene Menu allows you to choose scene settings that let your camera to adapt properly to

your current environment.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Scene menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen.

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Image Resolution Menu

The Image Size menu allows you to choose the desired size of the images taken by your camera.

Keep in mind that images with a larger size will also take up more of your camera‟s memory.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Image Resolution

menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen.

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Image Quality Menu

The Image Quality menu allows you to select the desired quality level of the images taken by your

camera. Keep in mind that images with a higher image quality level will also take up more

memory on your camera.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Image Quality

menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen.

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

White Balance Menu

The White Balance feature allows your camera to adjust the coloring of the captured images

depending on the type of light source in the current environment.

Properly adjusting the White Balance setting to match your current environment will allow the

camera to properly balance the colors in the images that are taken with your camera.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the White Balance

menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen.

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Color Effect Menu

You can choose to add a color effect to the images taken with your camera.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Color Effect

menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Image Sharpness Menu

You can set the level of sharpness in the images taken with your camera. The sharpness level

dictates if the edges of objects in the image are more or less distinct.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Image Sharpness

menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.

Light Exposure Menu

The Light Exposure setting helps you control the amount of light that enters your camera‟s lens.

This setting should be adjusted when the environment is lighter or darker than normal.

When the environment has more light than is needed, reduce the exposure setting (by using the

negative - count) to reduce the amount of light allowed into the lens by your camera.

If the environment has less light (darker) than is needed, increase the exposure setting (by using

the positive + count) to increase the amount of light allowed into the lens by your camera.

1) Press the SET button to open the menus for the current mode.

2) Press the LEFT or RIGHT direction control buttons to scroll and select the Light Exposure menu.

3) Press the UP or DOWN direction control buttons to scroll through the menu options.

4) Press the SET button to select and save the desired option.

5) A selected option icon will appear on the selected item.

6) Press the LEFT or RIGHT button to select the next menu item.

7) Press the MODE button to exit the menu and return to your previous mode.

8) An icon reflecting your selection will display on the LCD screen.

9) Remember that this setting will be saved by your camera until you manually change the

setting or restore the camera‟s default factory settings.
