SRX-SL Headset
Quick Start Guide
Aller à www.honeywellaidc.com pour le français.
Vai a www.honeywellaidc.com per l'italiano.
Gehe zu www.honeywellaidc.com für Deutsch.
Ir a www.honeywellaidc.com para español.
Para Português, acesse www.honeywellaidc.com.
Перейти на русскоязычный сайт www.honeywellaidc.com.
Pro češtinu jdi na www.honeywellaidc.com.
Pre slovenčinu choď na www.honeywellaidc.com.
Türkçe için lütfen www.honeywellaidc.com sayfasını ziyaret ediniz.
Idź na stronę : www.honeywellaidc.com po quick start w języku polskim.
如要到中国 www.honeywellaidc.com（简体）。
www.honeywellaidc.com
SRXSL-QS Rev (a)
5/16
Getting Started
Assemble
Align notches and snap together
eModule
Headband Assembly
Mute
Power
Volume Up
Volume Down
LED
Charge
Note: Charge before first use.
Insert cable and charge for a minimum of three hours.
Disconnect cable when done charging.
Power On
Press 1/2 second.
Mute
Use the Mute button or:
• Rotate the microphone boom up 90º to mute.
• Rotate the microphone back down to unmute.
Pairing
When powered on, the headset is discoverable and connectable.
If the headset has previously paired with a device, press the power
button a second time after the headset is powered on to reconnect
with that device.
LED and Tones
Complete LED and tone details are in the Hardware Reference.
Common LED modes and associated tones:
LED Device State Tones
Solid Green
(USB not plugged in)
Discoverable and con-
nectable
High pitch double
beep at start up
Off
(USB not plugged in)
Off Low pitch double
beep at power off
Flashing Blue
(every 1.5 seconds)
Paired and connected Three ascending
tones on connect
Flashing Red
(every 1.5 seconds)
Paired and connected,
battery low
Five low then high
alternating tones
Rapid flashing blue
(three flashes)
Paired and connected,
incoming call
Ascending scale
ring tone
Solid Red
(USB plugged in)
USB charging, Blue-
tooth disabled
N/A
Solid Green
(USB plugged in)
USB charging, charge
complete
N/A
Off
(USB plugged in)
Not charging, connect-
ed device in suspend
N/A
Buttons
Complete button functions are in the Hardware Reference.
Common button functions:
SRX-SL Important Information
This Important Information section contains safety, regulatory, and warranty
information. Find other Vocollect SRX-SL documentation at: www. honey-
wellaidc.com
Safety and Handling
Honeywell Vocollect Solutions devices and wireless headsets are designed
to be compliant with the rules and regulations in the locations into which they
are sold and are labeled as required.
Button Result
Power
(Device off)
Press 1/2 second to turn on
Power
(Device on)
Press 5 or more seconds to turn off
Volume up Raise volume
Volume down Lower volume
Power
(Device on)
Press 1 second to start voice recognition
app
Power
(incoming call)
Momentary press answers call,
One second press rejects call
Power
(active call)
Momentary press ends call,
One second press transfers call
Mute
(active call or voice
app)
Mutes/unmutes microphone
Caution: Changes or modifications not expressly approved by the
manufacture could void the user's authority to operate the equipment.
Attention: Les changements ou modifications non expressément approuvés
par la fabrication pourraient annuler l'autorité de l'utilisateur à utiliser l'équi-
pement .
