Appendix I: Manual
Please refer to the following pages.
T2/T2x Version and Compliance
Information
Note: This page contains information about Talkman® devices that adhere to the
Restriction of Hazardous Substances (RoHS) directive set forth by the European Union, as
well as information about Talkman devices that were for sale before this directive and are
non-RoHS compliant. Differences between the types of devices are noted.
Version
Declaration of Conformity
Regulatory Policy Compliance
o Talkman® T2 Federal Communications Commission Compliance
o CE Marking & European Compliance
o Brazilian Compliance
Specific Absorption Rate (SAR)Level
Version
For version information, please consult the Help | About menu option of any Vocollect
application or check the release notes that accompanied the Vocollect Management
Software.
Software Release Version
Vocollect VoiceConsole Consult the release notes.
Talkman® T2/T2x Terminal
Software Consult the release notes.
Terminal Manager Consult the Help | About menu
option.
Operator Manager Consult the Help | About menu
option.
Declaration of Conformity
Click here to view the Declaration of Conformity for the non-RoHS compliant Talkman T2/T2x
devices with charger and battery charger.
Click here to view the Declaration of Conformity for the RoHS compliant Talkman T2x device
with charger and battery charger.
Regulatory Policy Compliance
Talkman T2/T2x Federal Communications Commission Compliance
CE Marking & European Compliance
Talkman T2/T2x Federal Communications
Commission Compliance
This device complies with Part 15 (b) of the Federal Communications Commission (FCC)
Rules.
This product has been tested to the following standards:
Standard
European Union/
Manufacturers
declaration of
Conformity. EMC
Directive
89/336/EEC and
amendment
92/31/EEC
Emissions -EN
55022: 1998: Class B:
Limits & Methods of Measurement of Radio
Disturbance Characteristics of Information
Technology Equipment
Immunity -EN 55024:1998:
Electromagnetic Compatibility-Immunity of
Information Technology Equipment (ITE), which
consists of:
EN61000-4-2; ESD
EN61000-4-3; Radiated Immunity
EN61000-4-6; Conducted Immunity
EN61000-4-11; Voltage Interruptions
United
States/Federal
Communications
Commission
FCC Part 15, Class B:
Code of Federal Regulations, Title 47
Telecommunication
Part 15-Radio Frequency Devices
Canada/Industry
Canada
ICES-003:
Industry Canada Interference-Causing Equipment
The non-RoHS compliant T2/T2x product may contain one of these radio devices. See
device label.
Card Manufacturer and
P/N
Vocollect
Talkman FCC ID
#
Vocollect
Talkman
Canadian ID #
Symbol-LA-3021- 101-US
2Mbps 100mW
H9PLA3021-100
MQOTT600-
22300
2570A-TT600T2
Symbol-LA-4121- 1020-
US
MQOTT600-
35300
2570A-TT600
T2x_RoHS_DeclarationofConformity
H9PLA4121
Lucent-PC24E-H-FC
WorldCard
MQOTT500-
33300
230-391152A
CISCO- AIR-PCM350
LDK102040
MQOTT600-
40300
2570A-TT600
Vocollect Wi-Fi
600-2400-032
MQOTT600-
50300
2570A-TT60-
50300
The RoHS compliant T2x product may contain one of these radio devices. See device
label.
Card Manufacturer and
P/N
Vocollect
Talkman FCC ID
#
Vocollect
Talkman
Canadian ID #
Summit SDC-CF10G MQOTT601-10000
2570A-TT601100
The T5 terminal contains an integrated Wi-Fi/Bluetooth chip.
The Talkman product is separately approved for:
1. FCC Part 15 Subpart C
2. Industry Canada RSS211 and RSS139
3. ETSI 300-328, ETSI 300-826, EN 60950
4. Approved for use in the following countries: U.S.A., Canada, all EU and EEA
member states, Mexico, Brazil, Australia, and South Africa.
The Talkman T2/T2x is nominally a Class B digital device, pursuant to Part 15 of the FCC
Rules.
Caution: Exposure to Radio Frequency Radiation.
The Talkman T2/T2x terminal contains an internal low-power radio. The radiated output
power of the radio is far below the FCC radio frequency exposure limits. Nevertheless,
the Talkman T2/T2x terminal shall be used in such a manner that the potential for
human contact with the radio antenna during normal operation is minimized. The
terminal should not be used if the case is open or if the internal antenna is exposed.
When not in use, the Talkman T2/T2x terminal should be powered off. In addition, the
terminal should be worn in accordance with the instructions for this device.
Vocollect terminals are designed to be compliant with the rules and regulations in the
locations into which they are sold and are labeled as required. Vocollect terminals are
type approved and do not require the user to obtain license or authorization before using
them. Changes or modifications not expressly approved by Vocollect, Inc. could void the
user's authority to operate the equipment.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classes B est conforme à la norme NMB-003 du Canada.
0336
Warning: The Talkman T2/T2x terminal is a class B product. In a domestic
environment, this product may cause radio interference in which case the user may
be required to take adequate measures.
Part 15 (b) of the Federal Communications Commission
(FCC) Rules
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CE Marking & European Compliance
Products intended for sale within the European Union are marked with the
CEMark, which indicates compliance to applicable Directives and European
Normes (EN) as follows. Amendments to these Directives or ENs are included.
0336
Important Notice:
This device is a 2.40 to 2.48GHz RF
device intended for office and light
industrial use in all EU and EFTA member
states.
Applicable Directives
Electromagnetic Compatibility Directive 89/336/EEC
EN 55022: 1998 Class B
T2x_RoHS_DeclarationofConformity
EN 55025: 1998
AUS B DK FIN
F D GR IRE
I LUX NL P
E S UK
Note: This device is also authorized for use in all EFTA member states (CH, ICE, LI, NOR).
Made in the U.S.A.
Vocollect Inc.
Pittsburgh, PA
Brazilian Compliance
Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar
interferência a sistemas operando em caráter primário
Specific Absorption Rate (SAR) Level - RoHS compliant
The RoHS compliant Talkman T2x has been SAR tested. The maximum SAR value measured was
0.306 W/kg.
We the undersigned affirm that the electrical equipment manufactured by us fulfills the
requirements of the R&TTE
Directive 1999/5/EC.
Last revision: May 31, 2006
Manufacturers
Name: Vocollect, Inc
Manufacturers
Address
703 Rodi Road
Pittsburgh, Pa 15235
Country USA
Certify and declare under our sole responsibility that the following equipment:
Product description /
Intended use
Vocollect® T2x
EU / EFTA Member states
intended for
use.
Approved for use in all EU and EFTA member states.
Note: New members may be omitted or subject to change. For an up to date
official list please contact the EU government offices.
Other Country approvals US, Canada
Members with Restrictive
use
Belgium, France and Italy may have restrictions on outdoor use
Manufacturer Vocollect, Inc.
Brand Vocollect
Type T2x
Model(s) TT-601_R WF ETSI
Is tested and conforms with the essential requirements for the protection of health and safety of the user and any
person and
Electromagnetic Compatibility, as included in the following standards.
T2x_RoHS_DeclarationofConformity
Standards to which the
Conformity is
declared:
EN 60950-1 Information Technology Equipment - Safety
EN 300 328 Electromagnetic Compatibility and Radio Spectrum Matters
EN 301-489-1/17 Electromagnetic Compatibility Standard for Radio Equipment
and services
Technical Features and
Characteristics:
Operating Frequency Range 2400-2483.5 MHz
Measured RF output peak power (E.I.R.P) 18.2dBm
Modulation Methods DSSS
Spurious emissions level less than -31.8 dBm operating (30 MHz to 1 GHz)
Spurious emissions level less than -64.3 dBm in standby (30 MHz to 1 GHz)
Technical construction file is kept at the following address:
Vocollect, Inc
703 Rodi Road
Pittsburgh, Pa 15235
U.S.A.
Phone: 412-829-8145
Fax: 412-829-0972
Contact:
Joesph R. Lesik
Senior Compliance Engineer
We the undersigned affirm that the electrical equipment manufactured by us fulfills the requirements of the EMC
Directive 89/336/EEC as amended by 92/31/EEC and 93/68/EEC and the Low Voltage Directive 73/23/EEC
Last revision: March 29, 2005
Manufacturers Name: Vocollect, Inc
Manufacturers Address: 703 Rodi Road
Pittsburgh, Pa 15235
Country USA
Certify and declare under our sole responsibility that the following equipment:
Product description / Intended use Talkman® T2 wearable computer and Talkman® T2x wearable computer
with
terminal charger and battery charger. Voice directed data acquisition
device
operating in the 2.4Ghz ISM frequency band. Unit contains a pre-approved
OEM
WLAN radio card.
EU / EFTA Member states intended
for
use.
Approved for use in all EU and EFTA member states.
Note: New members may be omitted or subject to change. For an up to
date
official list please contact the EU government offices.
Other Country approvals Brazil, Mexico, Australia, Canada, South Africa
Members with Restrictive use None
Manufacturer Vocollect, Inc.
Brand Talkman
Type T2, T2x
Model(s) TT-600, TT-601, CM-601, CM-602
Is tested and conforms with the essential requirements for the protection of health and safety of the user and any
person and
Electromagnetic Compatibility, as included in the following standards.
Standards to which the Conformity is
declared:
Class B limits as defined by CISPR11
EN 55022:1998 to include Conducted and Radiated Emissions
EN 55024:1998 to include: EN 61000-3-3:1994, EN 61000-3-2:1995,
EN 61000-4-2:1995, EN 61000-4-3:1996, ENV 50204:1996
EN 61000-4-4:1995, EN 61000-4-5:1995, EN 61000-4-6:1996
EN 61000-4-11:1994, EN 60950 and ETS 301 489-1/-17, AS/NZS3548
This product will contain a device, which complies with the essential radio test suites so that it effectively uses the
frequency spectrum allocated to terrestrial/space and radio communication and orbital resources so to as avoid
harmful interference and safety as included in the following standards:
Standard to which the internal OEM
radio card comply.
ETS 300-826
ETS 300-328
FCC-15.247, IEC-003
Technical construction file is kept at the following address:
Vocollect, Inc
703 Rodi Road
Pittsburgh, Pa 15235
U.S.A.
Phone: 412-829-8145
Fax: 412-829-0972
Contact:
Mike Davis
Director of Quality
Document- 695121 revision 03
Copyright 1998-2005 Vocollect, Inc. All Rights Reserved

Navigation menu
