Von Duprin 105676 Rev 0415 33/3547A

User Manual: Von Duprin 33/3547A Parts Manual

Open the PDF directly: View PDF PDF.
Page Count: 21

33/3547A,
33/3549A,
& 33/3550A
Series Exit
Devices
Service manual
33/3547A
33/3549A
33/3550A
2 • Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual
INDEX
33/3547A, 33/3549A, & 33/3550AWDC Devices
Basic Device ................................................................................................................................................
Panic Concealed Vertical Rods and Latches ..............................................................................................
Fire Concealed Vertical Rods and Latches .................................................................................................
Panic and Fire Aluminum and Metal Door Concealed Vertical Cables and Latches ................................
Panic and Fire Wood Door Concealed Vertical Cables and Latches .......................................................
LBR (Less Bottom Rod) / LBL (Less Bottom Latch) Fire Latch Kit ................................................................
Baseplate Assembly ......................................................................................................................................
Variations of the Basic Device
CD (Cylinder Dogging) ..................................................................................................................
HD-EL (Hex Dogging/Electric Latch Retraction) .............................................................................
EL (Electric Latch Retraction) .........................................................................................................
SS (Signal Switch) ..........................................................................................................................
RX (Request to Exit) ..................................................................................................................
LX (Latch Bolt Monitoring) .........................................................................................................
ALK (Exit Alarm Kit) ........................................................................................................................
General Information
Introduction ......................................................................................................................................................
How to Order ...................................................................................................................................................
Part Number Changes .....................................................................................................................................
Finishes ...........................................................................................................................................................
Outside Trim Functions ...................................................................................................................................
Strikes ..............................................................................................................................................................
INTRODUCTION
This manual contains a listing of replaceable parts and assemblies for the 33/3547A Concealed Vertical Rod Exit
Devices and the 33/3549A / 33/3550AWDC Concealed Vertical Cable Exit Devices. 33 Series and 35 Series devices
are almost identical. The 33 Series has a grooved case; the 35 series has a smooth case.
HOW TO ORDER
Some parts are sold separately. Other items are available as part of a kit or multiple quantity package. For the best
possible service when ordering replacement parts or assemblies, please provide the following information:
 3DUWQXPEHURUDVVHPEO\QXPEHU
 'HVFULSWLRQ
 4XDQWLW\1HHGHG
 )LQLVKGHVLUHGLIDYDLODEOHILQLVKHG
 'DWHRIRULJLQDOSXUFKDVHLINQRZQ
To find out the name of your local Von Duprin distributor or sales representative, contact:
Von Duprin Division
Allegion
2720 Tobey Drive
Indianapolis, IN 46219
Phone: (877) 671-7011
PART NUMBER AND AVAILABILITY CHANGES
This manual was designed to help illustrate the replacement parts and kits that are available for sale. Because of
changes to the product and/or manufacturing process, part numbers and availability can change over time.
4-5
6-7
8-9
10-11
12-13
14
15
4-5
16
17
17
18-19
18-19
20
2
2
2
3
3
3
Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual • 3
386DT*** 386NL**
360T-BE* 360L
388NL-OP****
OUTSIDE TRIM FUNCTIONS
360L-BE*
360L-DT***
360T
33A/35A SERIES FINISHES
US3
US4
US10
US15
US26
US26D
US28
313AN
315AN
605
606
612
619
625
626
628
710
711
Polished Brass
Dull Brass
Dull Bronze
Satin Nickel
Polished Chrome
Dull Chrome
Anodized Alum. (Clear)
Anodized Alum. (313)
Dark Bronze
Anodized Alum. (Black)
U.S. Std
Reference BHMA
Reference Description
“BE” (Blank Escutcheon) no
cylinder used - lever always active
“NL” (Night Latch) rigid lever - key
retracts latch bolt
“DT” (Dummy Trim) rigid lever for
pull operation
“NL-OP” (Optional Pull) needs to be
added
*
**
***
****
33/3547A STRIKES
Screw Pkg 900285
338 Strike (Top)
Standard Panic or
Fire Exit Hardware
385A Strike
(Bottom)
Panic or Fire
Exit Hardware
304L Strike
(Bottom)
Panic or Fire
Exit Hardware
283 Strike (Top)
Wood Frame
Screw 964191
33/3549A STRIKES
23945223
249 Top Strike Kit
Standard Panic or
Fire Exit Hardware
Includes top latch
mounting
screws
24007411
349 Bottom Strike Kit
Standard Panic or Fire
Exit Hardware
3FP0116A001-GL
338 Strike Filler Plate
(Top) used for
47 Series retrofit
33/3550A STRIKES
24664997
450 Bottom Strike Kit
Standard Panic or
Fire Exit Hardware
Includes bottom latch mounting
screws
24665002
150 Top Strike Kit
Standard Panic or
Fire Exit Hardware
Includes shims and top latch
mounting screws
47244841
WDC Strike Filler Plate
(Top) used for
47 Series retrofit
4 • Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual
1
17
16
17
14
10B
11
13
9
7B
6
18
8
10
7A
PANIC
ONLY
PANIC ONLY
PANIC ONLY
15
10A
CD Conversion Kit
33A Series - 050115
35A Series - 050132
Hex Dogging Kit
33A Series - 050114
35A Series - 050117
3
5
1
3B
2
4
3C
3A
Fire or Less Dogging
Cover Plate Kit
33A Series - 050133
35A Series - 050109
7B
7B 7B
12A
7
12
33/3547A & 33/3549A PANIC DEVICE
33/3547A-F & 33/3549A-F FIRE DEVICE
Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual • 5
Item No. Quantity Part No. Description Finish
1 900619 33A/35A Series Mounting Pkg. (1-3/4 & 2-1/4)
1 1 090085 227 Dog Key 5/32” Hex (Pkg of 10)
1 1 090005 227 Dog Key 5/32” Hex (Pkg of 2)
2 1 090040 Hex Dog Shaft (Pkg of 2)
3 1 107813 gkP gnitnuoM rednilyC
3A 1 050525 ralloC rednilyC
3B 1 050490 Cylinder Locating Washer - CD/SS
3C 1 050526 Cylinder Locknut
4 1 090046 CD Dogging Plug (Pkg of 2)
5 1 090045 CD Actuator Arm (Pkg of 2)
6 1 *PBKIT 33A/35A Series Push Bar Retrofit Kit - 3’ Door
6 1 *PBKIT 33A/35A Series Push Bar Retrofit Kit - 4’ Door
7 1 050014 33A/35A Series End Cap Kit
7A 1 050524 Impact Resistant End Cap Bracket
7B 1 090036 Cover Plate Anti-rattle Spring (Pkg of 10)
8 1 900597 Device End Cap and C/Case Screw Pkg.
9 1 050486 33A Series Mechanism Case - 3’ Door
9 1 050487 33A Series Mechanism Case - 4’ Door
9 1 050488 35A Series Mechanism Case - 3’ Door
9 1 050489 35A Series Mechanism Case - 4’ Door
10 1 050529 33A/35A Series Control Link Pin & Ret. Ring
10A 1 090031 Control Link Pin (Pkg of 10)
10B 1 090107 Retaining Ring (Pkg of 10)
11 2 090037 #8-32 x 3/8” Baseplate Screw (Pkg of 10)
12 1 050530 Mechanism Case Bracket Kit
12A 2 090073 Mechanism Case Bracket Screw (Pkg of 10)
13** 1 050405 33/3547A & 33/3549A C/Case Less Cover
14 1 050474 33A Series Cover Plate - Center Case Side
14 1 050475 35A Series Cover Plate - Center Case Side
15 1 050485 33/3547A & 33/3549A C/Case Cover Kit
16 1 050491 Shock Absorber & Holder Assembly
17 2 090049 Push Bar Guide (Pkg of 10)
18 4 900892 Center Case Cover Screws (Pkg of 4)
X in “Finish” column designates finished items; finish must be specified when ordering.
* To order, specify device type, size, and finish. Example PBKIT 33A 3’ US28
** Device mounting screws 900619 included
33/3547A & 33/3549A PANIC DEVICE
33/3547A-F & 33/3549A-F FIRE DEVICE
X
X
X
X
X
X
X
X
X
X
X
X
X
X
6 • Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual
33/3547A PANIC VERTICAL RODS AND LATCHES
33/3548A
Top Latch Kit
Std - 050494
EL - 050516
5
7
4
2
6
10
12
13
14
8
11
ES33/3547A
Top Latch
Assembly
050128
Rod Extension
Assembly
051808
33/3548A
Bottom Latch
Assembly
050495
9
10
7
1
6
3
13
15
3
5
4
20
Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual • 7
33/3547A PANIC VERTICAL RODS AND LATCHES
17
18
19
19
33/3547A Top Latch 33/3547A Bottom Latch
Item No. Quantity Part No. hsiniFnoitpircseD
* 1 050047 33/3548A Latch Retrofit Kit (non EL)
* 1 050048 33/3548A-F Latch Retrofit Kit (non EL)
* 1 050522 EL33/3548A Latch Retrofit Kit
* 1 050523 EL33/3548A-F Latch Retrofit Kit
1** 1 050493 33/3547A Bottom Latch Kit
2** 1 050492 33/3547A Top Latch Kit
3 2 109324 33/3547A Latch Mtg Bracket Kit
3 2 112868 33/3548A Latch Mtg Bracket Kit
4 6 090059 Latch Bracket Mtg Screw (Latch)
5 6 090061 Latch Bracket Mtg Screw (Metal Door)
5 6 900856 Latch Bracket Mtg Screw (Wood Door)
6 2 090063 Retaining Ring (Pkg of 10)
7 2 090064 Latch Link Pin (Pkg of 10)
8 1 050519 Adjustable Top Rod 6’8” - 8’4” Door
9 1 050520 Adjustable Bottom Rod Kit
10 2 090071 33/3547A Rod Connecting Screw
10 2 090072 33/3548A Rod Connecting Screw
11 1 106222 XgkP esaeleR tehctaR
12 1 090070 Ratchet Release Screw
13 2 900620 Rod Adjusting Pkg
13 2 900898 33/3547A Adjusting Screw LBR Package
14 2 969989 Rod Connector Extension Bracket
15 2 972408 Rod Connector Screw
16 1 090065 Bolt Return Spring
17 1 090066 Top Latch Compression Spring (Pkg of 10)
18 1 090069 Ratchet Lever Spring (Pkg of 2)
19 1 090062 Btm Latch Case Spirol Pin (Pkg of 10)
20 1 970978 33/3547A Ratchet Release Spacer 1/8”
X in “Finish” column designates finished items; finish must be specified when ordering.
*Retrofit kit includes items 1-3 to convert 33/3547A to 33/3548A.
**Each latch kit (item 1-2) includes only one latch mtg bracket kit (item 3). For service
replacement only. Refer to retrofit kits to convert 33/3547A to 33/3548A.
16
8 • Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual
33/3547A-F FIRE VERTICAL RODS AND LATCHES
33/3548A
Top Latch
Assembly
Std - 050494
EL - 050516
5
7
4
2
6
10
12
13
8
11
Rod Extension
Assembly
051808
33/3548A
Bottom Latch
Assembly
050495
9
10
7
1
6
3
13
14
15
4
3
5
20
Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual • 9
Item No. Quantity Part No. hsiniFnoitpircseD
* 1 050047 33/3548A Latch Retrofit Kit-(non EL)
* 1 050048 33/3548A-F Latch Retrofit Kit-(non EL)
* 1 050522 EL33/3548A Latch Retrofit Kit
* 1 050523 EL33/3548A-F Latch Retrofit Kit
1** 1 050493 33/3547A Bottom Latch Kit
2** 1 050492 33/3547A Top Latch Kit
3 2 109324 33/3547A Latch Mtg Bracket Kit
3 2 112868 33/3548A Latch Mtg Bracket Kit
4 6 090059 Latch Bracket Mtg Screw (Latch)
5 6 090061 Latch Bracket Mtg Screw (Metal Door)
5 6 900856 Latch Bracket Mtg Screw (Wood Door)
6 2 090063 Retaining Ring (Pkg of 10)
7 2 090064 Latch Link Pin (Pkg of 10)
8 1 050519 Adjustable Top Rod 6’8” - 8’4” Door
9 1 050520 Adjustable Bottom Rod Kit
10 2 090071 33/3547A Rod Connecting Screw
10 2 090072 33/3548A Rod Connecting Screw
11 1 106222 XgkP esaeleR teh
ctaR
12 1 090070 Ratchet Release Screw
13 2 900620 Rod Adjusting Pkg
13 2 900898 33/3547A Adjusting Screw LBR Package
14 2 969989 Rod Connector Extension Bracket
15 2 972408 Rod Connector Screw
16 1 090065 Bolt Return Spring
17 1 090066 Top Latch Compression Spring (Pkg of 10)
18 1 090069 Ratchet Lever Spring (Pkg of 2)
19 4 090062 Btm Latch Case Spirol Pin (Pkg of 10)
20 1 970978 33/3547A Ratchet Release Spacer
X in “Finish” column designates finished items; finish must be specified when ordering.
*Retrofit kit includes items 1-3 to convert 33/3547A to 33/3548A.
**Each latch kit (item 1-2) includes only one latch mtg bracket kit (item 3). For service
replacement only. Refer to retrofit kits to convert 33/3547A to 33/3548A.
33/3547A-F FIRE VERTICAL RODS AND LATCHES
17
18
19
19
33/3547A Top Latch 33/3547A Bottom Latch
16
10 • Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual
33/3549A & 33/3549-F
VERTICAL CABLES AND LATCHES (ALUMINUM AND METAL DOOR)
3
1
2
Cable Removal Tool
Qty 1 Pkg of
10
4 5
Spacer Block Kit
Pkg of
2
6
Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual • 11
33/3549A & 33/3549A-F
VERTICAL CABLES AND LATCHES (ALUMINUM AND METAL DOOR)
Item No. Quantity Part No. hsiniFnoitpircseD
*A cable removal tool is included with the assembly.
Each latch assembly includes two latch mounting brackets.
Top Latch Assembly
Bottom Latch Assembly
33/3549 Center Slide Assembly
(Aluminum and Metal Door)
Cable Removal Tool
Cable Removal Tool (Pkg of 10)
Spacer Block Kit (Pkg of 2)
24090110
24090128
24090136
24008773
24090706
24231516
1*
2
3
4
5
6
1
1
1
1
10
2
12 • Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual
33/3550AWDC & 33/3550AWDC-F (WOOD DOOR CONCEALED)
VERTICAL CABLES AND LATCHES
1
2
5
6
7
3
4
Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual • 13
50WDC Top Latch Kit
50WDC Bottom Latch Kit
33/3550AWDC Center Slide Kit
33/3550AWDC-F Fire Kit
33/3550AWDC Lift Finger Kit
Top Cable 6'8"-7'0" WDC
Top Cable 7'1"-8'0" WDC
Top Cable 8'1"-9'0" WDC
Top Cable 9'1"-10'0" WDC
Bottom Cable WDC
48968820
48968838
48973309
48968879
24685562
24648180
24647273
24647281
24647299
24647265
1
2
3
4
5
6
6
6
6
7
1
1
1
1
1
1
1
1
1
1
Item No. Quantity Part No. hsiniFnoitpircseD
33/3550AWDC & 33/3550AWDC-F (WOOD DOOR CONCEALED)
VERTICAL CABLES AND LATCHES
14 • Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual
33/3547-F LBR (LESS BOTTOM ROD)
33/3549-F LBL (LESS BOTTOM LATCH)
33/3550AWDC-F LBL (LESS BOTTOM LATCH)
FIRE LATCH KIT
LBR/LBL Fire Latch/Strike Kit
LBR/LBL Fire Strike Plug
50WDC Fire Pin Kit
050171
050509
48968887
1
2
3
1
1
1
Item No. Quantity Part No. hsiniFnoitpircseD
2
1
Note: 499F Strike
(not shown)
is included with
P/N 050171
3
Note: 33/3550AWDC-F LBL
requires P/N 050171
in addition to these
components
Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual • 15
Item No. Quantity Part No. Description Finish
1 1 090043 Dogging adapter (Pkg of 2)
2 1 090042 Dogging adapter spring (Pkg of 2)
3 1 090041 Dogging spring (Pkg of 2)
4 1 090040 Hex dogging shaft (Pkg of 2)
5 1 090044 Dogging hook (Pkg of 2)
6 1 090039 Latch return spring (Pkg of 10)
7 4 090038 Rubber bumper (Pkg of 4)
8 1 050491 Shock absorber
764
5
1
2
3
33/3547A, 33/3549A, & 33/3550A PANIC DEVICE BASEPLATE ASSEMBLY
1
21
Item No. Quantity Part No. Description Finish
1 4 090038 Rubber bumper (Pkg of 4)
2 1 090039 Latch return spring (Pkg of 10)
3 1 050491 Shock absorber
33/3547A-F, 33/3549A-F, & 33/3550A-F FIRE DEVICE
BASEPLATE ASSEMBLY
8
3
16 • Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual
Item No. Quantity Part No. Description Finish
*Kit includes items 1-11 plus new control link, retaining ring, and baseplate screws.
4
2
1
3
6
9
5
11
10
7
812 13 14
HD-EL3347A/HD-EL3547A, HD-EL3349A/HD-EL3549A, &
HD-EL3350A/HD-EL3550A
HEX DOGGING/ELECTRIC LATCH
RETRACTION OPTION - PANIC DEVICE ONLY
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
*
*
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
050531
050532
110388
050534
050536
050537
050538
050539
050540
050541
050542
050543
990599
990857
990858
050384
050385
EL Dogging Rod Kit - 3’ device
EL Dogging Rod Kit - 4’ device
EL 6’ Cable and Connector
EL Potted Module
HD-EL Solenoid
HD-EL Solenoid Plunger
EL Dogging Rod Retainer
EL Receptacle Connector - 2 Position
EL Female Terminal
HD-EL Dog Screw
HD-EL Solenoid Bracket
HD-EL Dogging Spring
EL Plug Connector - 2 Position
EL Receptacle Connector - 3 Position
EL Plug Connector - 3 Position
HD-EL Conversion Kit - 3’
HD-EL Conversion Kit - 4’
Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual • 17
SS3347A/SS3547A, SS3349A/SS3549A, & SS3350A/SS3550A SERIES
SIGNAL SWITCH OPTION
EL3347A/EL3547A, EL3349A/EL3549A, & EL3350A/EL3550A
ELECTRIC LATCH RETRACTION OPTION
Item No. Quantity Part No. Description Finish
*Kit includes items 1-7 plus new control link pin, retaining ring, and baseplate screws.
1
2
Item No. Quantity Part No. Description Finish
1 1 050544 SS Cable
2 1 050545 SS Housing
3 1 990601 SS Plug Connector - 6 Position
4 1 990602 SS Receptacle Connector - 6 Position
34
1
45
10
9
3
8
7
6
2
1
1
2
3
4
5
6
7
8
9
10
*
*
1
1
1
1
1
1
1
2
1
1
1
1
1
050531
050532
110388
050534
050535
050538
050539
050540
990599
990857
990858
050070
050078
EL Dogging Rod Kit - 3’ device
EL Dogging Rod Kit - 4’ device
EL 6’ Cable and Connector
EL Potted Module
EL Solenoid Assembly
EL Dogging Rod Retainer
EL Receptacle Connector
EL Female Terminal
EL Plug Connector - 2 Position
EL Receptacle Connector - 3 Position
EL Plug Connector - 3 Position
EL Conversion Kit - 3’
EL Conversion Kit - 4’
18 • Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual
1
2
LX Switch
RX Switch
Wire Colors
Violet, Gray, White
(for Low Current
Violet, Gray, Black)
Wire Colors
Red, Yellow, Blue
(for Low Current
Green, Yellow, Blue)
78
7
33/3547A, 33/3549A, & 33/3550 LX (LATCH BOLT MONITOR) &
RX (REQUEST TO EXIT) OPTIONS
Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual • 19
Item No. Quantity Part No. hsiniFnoitpircseD
1 1 050254 LX Switch Kit 3’ Device
1 1 050255 LX Switch Kit 4’ Device
1 1 050247 LX-EL Switch Kit
1 1 050283 LX-LC (Low Current) Switch Kit 3’ Device
1 1 050285 LX-LC (Low Current) Switch Kit 4’ Device
1 1 050287 LX-LC-EL (Low Current) Switch Kit
2 1 050251 RX Switch Kit
2 1 050281 RX-LC (Low Current) Switch Kit
3 1 050256 LX-RX Switch Kit 3’ Device
3 1 050257 LX-RX Switch Kit 4’ Device
3 1 050259 LX-RX-EL Switch Kit
3 1 050289 LX-RX-LC (Low Current) Sw. Kit 3’ Device
3 1 050291 LX-RX-LC (Low Current) Sw. Kit 4’ Device
3 1 050293 LX-RX-LC-EL (Low Current) Switch Kit
2 & 4 1 050270 RX-2 Switch Kit
4 1 050271 RX-AUX Switch Kit
5 1 964558 8-32 x 5/16” PPHMS
6 1 964019 #8 Washer
7 1 090099 Pine Tree Clip (Pkg of 10)
8 1 971091 LX Actuator
3
4
LX-RX Switch
RX-AUX Switch
Wire Colors
Red, Yellow, Blue
(for Low Current
Green, Yellow, Blue)
Wire Colors
Violet, Gray, White
(for Low Current
Violet, Gray, Black)
Wire Colors
Red, Yellow, Blue
(for Low Current
Green, Yellow, Blue)
7
56
33/3547A, 33/3549A, & 33/3550A LX (LATCH BOLT MONITOR) &
RX (REQUEST TO EXIT) OPTIONS
20 • Von Duprin • 33/3547A, 33/3549A, & 33/3550A Series Exit Devices Service Manual
EMERGENCY EXIT ONLY
ALARM WILL SOUND
3
33/3547A, 33/3549A, & 33/3550A ALK EXIT ALARM KIT
R
A
M
R
A
M
I
D
S
54
Item No. Quantity Part No. Description Finish
1 1 111795 ALK PCB Assembly
2 1 050525 XralloC rednilyC
3 1 969122 ALK Alarm Device Sign
4 1 969349 ALK Arming Label
5 1 969350 ALK Disarming Label
6 1 969354 Retainer Nut
7 1 970594 ALK Cylinder Spacer
8 1 090036 Cover Plate Anti-rattle spring (Pkg of 10)
9 1 971556 ALK Switch Actuator
10 1 971557 ALK Cylinder Bracket
11 1 990637 ALK Battery
12 1 050406 33A Series ALK Cover Plate Kit X
12 1 050407 35A Series ALK Cover Plate Kit X
X in “Finish” column designates finished items; finish must be specified when ordering.
8
1
11
12
2
10
7
6
9
© 2015 Allegion
105676, Rev. 04/15
www.allegion.com/us
Allegion (NYSE: ALLE) is a global pioneer in safety and security, with leading brands
like CISA®, Interfl ex®, LCN®, Schlage® and Von Duprin ®. Focusing on security
around the door and adjacent areas, Allegion produces a range of solutions for
homes, businesses, schools and other institutions. Allegion is a $2 billion company,
with products sold in almost 130 countries.
For more, visit www.allegion.com.

Navigation menu
