REPLACEMENT TRANSMITTER
Model 471H, 1 Button Learning Transmitter
The system comes with one programmed trans-
mitter. The receiver can store up to 4 different
transmitter codes in memory. Additional transmitters
can be ordered by contacting your local dealer. Use
the following to add a transmitter to the system. The
following is a basic sequence of steps to remember
whenever programming transmitters:
1. Fuses. Remove both fuses from the control
module fuse holders, then re-insert into the fuse
holders.
2. Key. Turn the ignition to the ON position. The
parking lights will turn On.
3. Program. Press and hold the program button on
the control module. The parking lights will flash
Off and then back On to ackdowledge program
mode.
Note: If the parking lights did not flash the transmitter
learn was not successful. Return and repeat from step
1 this procedure.
To add additional transmitters (within 10-seconds of
the first transmitter) press and hold the button on the
additional transmitter.
FCC/ID Notice
This device complies with Part 15 of FCC rules. Operation
is subject to the following conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesirable
operation.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate this device.
