The Science of Security
™
CClliiffffoorrdd RReessppoonnddeerr CCoommppaanniioonn RReemmoottee
PN 472X
Compatible with the
following systems:
RRSS33
RRSS11..55
RRSS33..55
22..55XX
Note: The RS3 requires alter-
nate programming.
TM
1. Open a door. (The GREEN wire, H1/5, or the VIOLET, H1/7
must be connected.)
2. Key. Turn the ignition on. (The heavy gauge PINK wire of
the relay satellite must be connected.)
3. Select the receiver channel. Press and release the
Valet®/Program switch the number of times necessary to
access the desired channel. Once you have selected a chan-
nel, press and HOLD the Valet®/Program switch once more.
The siren will chirp and the LED will blink the number of times
corresponding to the channel that has been accessed.
NOTE:
Alternate programming is required for RS3. Consult the
RS3 Owner’s or Installation Guide for details.
Channel No. Function
1 Auto Learn Standard Configuration (default)
2 Arm only
3 Disarm only
4 Silent Mode™/Remote Valet®/Trunk Release
5 Remote Start
6 Channel 4
7 Channel 5
8 Short Run/Turbo
9 Timer Mode
10 Arm/Disarm/Panic
11 Panic Only
12 Delete all transmitters
Channels Two, Three and Eleven: Channels Two through
Eleven are used to assign the arm, disarm and panic functions
to separate buttons on the remote control.Teaching a button to
Channel Two erases all information about that remote from
memory. Any auxiliary functions that are desired will have to be
reprogrammed. Similarly, if the remote is set up to use the sep-
arate arm, disarm and panic channels and a button from that
remote is entered into Channel Two, the remote will be erased
from memory, and the system will only recognize the button
that was entered into Channel Two.
Channel Twelve: If any transmitter button from a known trans-
mitter is programmed to Channel Twelve, all transmitters will be
erased from memory and will revert to the default feature set-
tings. (See Features Menu section of this guide.) This is useful
in cases when one of the customer's transmitters is lost or
stolen. This will erase any lost or stolen transmitters from the
system's memory. It can also be used to start from scratch if
the transmitter buttons were programmed incorrectly.
4. Press the transmitter button. While HOLDING the
Valet®/Program switch, press the button from the transmitter
that you wish to assign to that channel. The unit will chirp indi-
cating successful programming. It is not possible to teach a
transmitter button to the system more than once.
5. Release. Once the code is learned, the Valet®/Program
button can be released. You can advance from one channel to
another by releasing the Valet® /Program button and tapping it
to advance channels and then HOLDING it. For example, if
you want to program Channel Three after programming
Channel One, release the Valet®/Program button. Press it
twice and release it to advance to Channel Three. Then press
it once more and HOLD it. The siren will chirp three times to
confirm it is ready to receive the code from the transmitter.
Learn Routine™ will be exited if:
Ignition is turned off.
Door is closed.
Valet®/Program button is pressed too many times.
More than 15 seconds elapses between steps.
One long chirp indicates that Learn Routine™ has been exited.
This device complies with Part 15 of FCC rules.
Operation is subject to the following conditions: (1)
This device may not cause harmful interference, and
(2) This device must accept any interference
received, including interference that may cause
undesired operation. Changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to
operate this device.
MADE IN TAIWAN
©2002 Directed Electronics, Inc. Vista CA 92083
All rights reserved.
P/N 472X 6/03
CClliiffffoorrdd RReessppoonnddeerr CCoommppaanniioonn RReemmoottee
PN 472X
To program your new transmitter:
