Compatible with the
following systems:
Python 502
Python 702
Python 902
Replacement
Transmitter
REPLACEMENT TRANSMITTER
Model 7141P, 4 Button, Stealth Code Remote
The following Learn Routine can be used to program this replacement transmitter to the system. In order to enter
the Learn Routine, the system’s Valet/Program switch must be plugged into the BLUE port.
1. Door. Open a door.
2. Key. Turn the key to the ON position.
3. Choose. Within 5 seconds press and release the
Valet/Program button the number of times corre-
sponding to the desired channel listed below.
Once you have selected the channel, press the
Valet/Program button once more and hold it. The
LED will flash the same number of times as the
channel selected and the siren (if connected) will
chirp to confirm the selected channel. Do NOT
release the button.
4. Transmit. While holding the Valet/program
button, press the button from the transmitter you
wish to assign to that channel. The unit will chirp
(if horn or siren connected) to confirm that the
transmitter has been taught to the receiver
5. Release. Once the code is learned you can release
the Valet/Program button and remove the key.
Channel Number Function
with remote start without remote start
1 7 Auto-learn Standard Configuration
2 8 Auto-learn Single-Button Configuration
11 9 Delete All Transmitters
Standard Configuration
A remote that has been programmed to an standard
configuration will use separate buttons for arm and
disarm similar to a factory keyless entry. Using the
expanded configuration, the transmitter buttons are
assigned to the following functions:
Lock Icon Button
The lock icon button arms and locks the system.
Unlock Icon Button
The unlock icon button disarms and unlocks the
system.
AUX Icon Buttons
The AUX icon button operates channel 2.
Siren (or Star) Icon Button
The siren (or star) icon button operates Panic only.
Unlock and Lock (or Star) Icon Buttons
When pressed together, the lock and unlock (or
star) icon buttons operate channel 3.
P Button (on the back of the transmitter)
Used to enter the Transmitter's programming menu.
(See Security/ Remote Start manual for details).
FCC/ID Notice
This device complies with Part 15 of FCC rules.
Operation is subject to the following conditions: (1)
This device may not cause harmful interference,
and (2) This device must accept any interference
received, including interference that may cause unde-
sired operation.
CAUTION! Changes or modifications not expressly
approved by the party responsible for compliance could
void the user's authority to operate this device.
MADE IN TAIWAN
©2006 Directed Electronics, Vista CA 92081
All rights reserved.
P/N 7141P 10-06
P/N 7141P
Python 1-Way Transmitter
