OWNER’S GUIDE
MODEL
The company behind Viper® Auto Security
Systems is Directed.
Since its inception, Directed has had one
purpose, to provide consumers with the fin-
est vehicle security and accessories avail-
able. The recipient of nearly 100 patents and
Innovations Awards in the field of advanced
electronic technology.
Quality Directed products are sold and ser-
viced throughout North America and around
the world.
Call (800) 876-0800 for more information
about our products and ser vic es.
Directed is committed to delivering
world class quality products and
services that excite and delight our
customers.
®
NO ONE DARES
COME CLOSE ®
4816V
4616V
© 2015 Directed. All rights reserved. G4816VML 2015-02
Vista, CA 92081
www.viper.com
![](/img.php?id=2629035&img=bg2.png)
i
© 2015 Directed. All rights reserved.
Congratulations
Congratulations on the purchase of your remote start system. Reading
this Owner’s Guide prior to using your system will help maximize the
use of your system and its many features. For any additional questions
please contact your authorized Directed dealer or contact Directed at
1-800-753-0600. (U.S. only) or 1-800-361-7271 (Canada only)
Additional support is also available at: http://support.directed.com
Important Information
Government Regulations and Safety information
Read the Government Regulations and Warning! Safety
First sections of this manual prior to operating this system.
Warning! Failure to heed this information can result in
death, personal injury or property damage and may also
result in the illegal use of the system beyond its intended
purpose.
Your Warranty
Your system comes with a warranty. The warranty terms are detailed at
the end of this guide. Make sure that you receive the proof of purchase
from your dealer, indicating the product was installed by an authorized
Directed dealer.
Replacement remote controls
Please see your authorized dealer or visit us at www.directedstore.com
to order additional remote controls. Your 2-way remote control model /
part number is 7816, and your 1-way is 7616.
![](/img.php?id=2629035&img=bg3.png)
ii © 2015 Directed. All rights reserved.
Battery Information
The remote controls are powered by coin cell batteries (CR-2016) that
can be purchased at most retailers. Your 2-way remote uses two bat-
teries, and the 1-way only uses one. The operating range diminishes as
the battery charge depletes.
Replacing the Battery
1. If present, remove the small screw on the back of the remote.
2. Use a small flat blade screw driver and insert it into the slot located
along the bottom of the remote, near the key ring. Carefully pry
open the case.
3. Gently slide out the used batteries to remove them from the holding
clip. Orient the new batteries for the correct polarity and insert
into holding clip.
4. Reposition case parts, and snap together by pressing firmly and
evenly on the front and back. Reinstall screw (if applicable).
Battery Disposal
Directed cares about the environment. If you need to dispose
of the battery, please do so in accordance with your munici-
pal requirements for battery disposal or return to Directed.
![](/img.php?id=2629035&img=bg4.png)
Contents
Congratulations .................................................................................................i
Important Information .........................................................................................i
Government Regulations and Safety information ............................................ i
Your Warranty ...........................................................................................i
Replacement remote controls .......................................................................i
Battery Information ............................................................................................ ii
Replacing the Battery ................................................................................ii
Battery Disposal .......................................................................................ii
Using Your System ...........................................................................................2
Commands At a Glance ............................................................................2
Start Engine .............................................................................................2
Unlock Doors ...........................................................................................2
Stop Engine .............................................................................................2
Car Finder ...............................................................................................3
Using Remote Start ............................................................................................3
Key Takeover............................................................................................3
Safety Features .........................................................................................4
Pit Stop ....................................................................................................4
Optional Rear Defogger ............................................................................5
Optional Starter Anti-Grind Circuitry ...........................................................5
Disabling the Remote Start System ..............................................................5
Rapid Resume Logic .........................................................................................5
Remote Programming ........................................................................................6
Programming Options ........................................................................................6
Patent Information .............................................................................................7
Government Regulations ....................................................................................8
Warning! Safety first .........................................................................................9
Installation ...............................................................................................9
Remote Start Capable ...............................................................................9
Interference ............................................................................................10
Upgrades ..............................................................................................10
Water/Heat Resistance ...........................................................................11
Limited lifetime consumer warranty ....................................................................12
![](/img.php?id=2629035&img=bg5.png)
2© 2015 Directed. All rights reserved.
Using Your System
Commands At a Glance
System State Press/Release Press/Hold for 3 sec.
ENGINE OFF START ENGINE CAR FINDER
ENGINE ON UNLOCK DOORS STOP ENGINE
Start Engine
When the engine is OFF, press and release the remote control button
to start the engine. The remote plays* the remote start activation tones
and the green LED flashes once.
See "Using Remote Start" on page 3 for more feature details.
Unlock Doors
When the engine is ON, press and release the remote control but-
ton. The doors unlock, the parking lights flash, the horn sounds (if con-
nected) as confirmation. The remote confirms* unlocking with 2 short
beeps and a green LED flash.
Note: Horn honk may be an optional feature that requires additional
parts and labor.
Stop Engine
When the engine is ON, press and hold the remote control button for
3 seconds. The engine stops running and the parking lights turn off.
The remote plays* the remote start shut off tones and the orange LED
flashes 1 time.
* Remote confirmations (playing tones, LED flashes) are only available
on the 2-way remote control (model 7816).
![](/img.php?id=2629035&img=bg6.png)
3
© 2015 Directed. All rights reserved.
Car Finder
When the engine is OFF, press and hold the remote control button for
three seconds. The parking lights flash ten times. The remote responds*
with 1 short beep and the orange LED on the remote flashes once.
Using Remote Start
Important! (1) Never remotely start the vehicle with the ve-
hicle in gear, and (2) Never remotely start the vehicle with
the key in the ignition.
Starting the Engine:
1. Press and release the remote control button.
2. The engine will START and the parking lights will turn on. The re-
mote responds* with the remote start On tones and the green LED
on the remote flashes once.
3. The parking lights stay on as visual confirmation while the engine
is ON. The default runtime is 12 minutes and can be shortened or
extended by the installer.
If you wish to warm or cool the vehicle interior set the climate controls
to the desired temperature prior to starting.
* Remote confirmations (playing tones, LED flashes) are only available
on the 2-way remote control (model 7816).
Key Takeover
When you are ready to drive the vehicle:
1. Unlock the doors
2. Enter the vehicle. Do not step on the foot brake
![](/img.php?id=2629035&img=bg7.png)
4© 2015 Directed. All rights reserved.
3. Insert the key, turn it to the run (not start) position. Step on the foot
brake. The remote start is disabled and the parking lights turn off.
4. Begin driving.
Note If your vehicle uses a Smart Key or PTS (Push-To-Start) sys-
tem, please refer to the vehicle specific instructions included
with the owner's guide of the interface module or consult
your authorized dealer.
Safety Features
The following safety features will disable the remote start when acti-
vated or not allow the engine to start if not properly set before starting.
• Foot Brake is depressed
• Hood is open
• Shut down toggle switch is OFF
• Engine over-rev protection (Tachometer mode only)
Pit Stop
This remote start can keep the engine running during short trips away
from the vehicle.
Enabling Pit Stop mode:
1. Park in a well ventilated area.
2. With the engine running set the transmission in the park position.
3. Press and release the remote control button, the parking lights turn
on to confirm.
4. Turn off the ignition and remove the key, the engine continues
running.
5. Exit the vehicle, the engine runs for the programmed runtime.
![](/img.php?id=2629035&img=bg8.png)
5
© 2015 Directed. All rights reserved.
Note If your vehicle uses a Smart Key or PTS (Push-To-Start) sys-
tem, please refer to the vehicle specific instructions included
with the owner's guide of the interface module or consult
your authorized dealer.
Optional Rear Defogger
If connected, the Defogger circuit automatically activates after remote
starting the vehicle.
Optional Starter Anti-Grind Circuitry
This system includes an anti-grind circuit that can prevent damage to
the starter motor if the key is turned to the start position while the engine
is ON.
Note: Anti-grind circuitry only works when the remote start system is
op er at ing the motor.
Disabling the Remote Start System
When the Shutdown Switch is set to the OFF position, remote engine
starting is defeated. DO this when the vehicle is being serviced or
driven by someone unfamiliar with remote start system operations.
Location Of Shutdown Switch: _________________________
Rapid Resume Logic
This Directed system stores its current state to non-volatile memory. If
power is lost and then reconnected the system recalls the stored state
from memory.
![](/img.php?id=2629035&img=bg9.png)
6© 2015 Directed. All rights reserved.
Remote Programming
1. Turn key to the ON position
2. Within 10 seconds, press and release Valet button one time.
3. Within 10 seconds, press and hold the Valet button. The LED on the mod-
ule flashes one time and the horn honks (if connected) to confirm entry into
remote programming. Do not release the valet button.
4. Press the button on the remote control. The horn honks to confirm the remote
has been programmed.
5. Release the Valet button.
6. Turn the key to the Off position. The horn sounds one long honk to confirm
that remote programming has been exited.
The programming routine exits if any of the following occurs:
• The ignition is turned off
• There is no activity for 30 seconds
• The Valet button is pressed too many times
Programming Options
Programming options control your system's normal operational set-up.
Most options do not require additional parts, but some may require
installation labor.
The following is a list of the programmable options, with the factory
settings in bold.
• Your system can be programmed to allow the vehicle to run for
up to 60 minutes when remote started. Can be set up to minute
increments by your installer.
• Parking lights flashing or constant. Your system can be pro-
grammed to flash or turn on the parking lights constantly during the
entire remote start operation.
![](/img.php?id=2629035&img=bga.png)
7
© 2015 Directed. All rights reserved.
• Ignition switch controlled door locking on or OFF. With this feature
on, the doors will lock 3 seconds after the ignition key is turned on,
and unlock when the key is turned off.
Important: The door lock option must be installed for this feature to
work.
Patent Information
This product is covered by one or more of the following United States
patents:
Remote Start Patents:
5,349,931; 5,872,519; 5,914,667; 5,952,933; 5,945,936;
5,990,786; 6,028,372; 6,467,448; 6,561,151; 7,191,053;
7,483,783
Vehicle Security Patents:
5,467,070; 5,532,670; 5,534,845; 5,563,576; 5,646,591;
5,650,774; 5,673,017; 5,712,638; 5,872,519; 5,914,667;
5,952,933; 5,945,936; 5,990,786; 6,028,505; 6,452,484
Other patents pending.
![](/img.php?id=2629035&img=bgb.png)
8© 2015 Directed. All rights reserved.
Government Regulations
This device complies with Part 15 of FCC rules. Operation is subject to the fol-
lowing two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates and can radiate radio frequency ener-
gy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television, which can
be determined by turning the equipment OFF and ON, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for
help.
Warning: Changes or modifications not expressly approved by the party re-
sponsible for compliance could void the user’s authority to operate this device.
Canada Statements
This device complies with Industry Canada licence-exempt RSS standard(s). Op-
eration is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interfer-
ence that may cause undesired operation of the device.
![](/img.php?id=2629035&img=bgc.png)
9
© 2015 Directed. All rights reserved.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d'en compromettre le fonctionnement.
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Les changements ou modifications non approuvés expressément par la partie
responsable de la conformité pourrait annuler l'autorité de l'utilisateur à faire
fonctionner l'équipement.
Warning! Safety first
The following safety warnings must be observed at all times:
Installation
Due to the complexity of this system, installation of this product must only be
performed by an authorized Directed dealer.
Remote Start Capable
When properly installed, this system can start the vehicle via a command signal
from the remote control. Therefore, never operate the system in an enclosed area
or partially enclosed area without ventilation (such as a garage). When parking
in an enclosed or partially enclosed area or when having the vehicle serviced,
the remote start system must be disabled using the installed toggle switch. It
is the user’s sole responsibility to properly handle and keep out of reach from
children all remote control remote controls to assure that the system does not
unintentionally remote start the vehicle. THE USER MUST INSTALL A CARBON
MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO
10 © 2015 Directed. All rights reserved.
THE VEHICLE. ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO
THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE STORAGE AREA MUST
AT ALL TIMES REMAIN CLOSED. These precautions are the sole responsibility
of the user.
Use of this product in a manner contrary to its intended mode of operation may
result in property damage, personal injury, or death. (1) Never remotely start the
vehicle with the vehicle in gear, and (2) Never remotely start the vehicle with
the keys in the ignition. The user must also have the neutral safety feature of the
vehicle periodically checked, wherein the vehicle must not remotely start while
the car is in gear. This testing should be performed by an authorized Directed
dealer in accordance with the Safety Check outlined in the product installation
guide. If the vehicle starts in gear, cease remote start operation immediately and
consult with the authorized Directed dealer to fix the problem.
After the remote start module has been installed, contact your authorized dealer
to have him or her test the remote start module by performing the Safety Check
outlined in the product installation guide. If the vehicle starts when performing
the Neutral Safety Shutdown Circuit test, the remote start unit has not been
properly installed. The remote start module must be removed or the installer must
properly reinstall the remote start system so that the vehicle does not start in gear.
All installations must be performed by an authorized Directed dealer.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN
GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERAT-
ING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT
IN PROPERTY DAMAGE OR PERSONAL INJURY. YOU MUST IMMEDIATELY
CEASE THE USE OF THE UNIT AND SEEK THE ASSISTANCE OF AN AU-
THORIZED Directed DEALER TO REPAIR OR DISCONNECT THE INSTALLED
REMOTE START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR
PAY FOR INSTALLATION OR REINSTALLATION COSTS.
11
© 2015 Directed. All rights reserved.
This product is designed for fuel injected, automatic transmission ve-
hicles only. Use of this product in a standard transmission vehicle is
dangerous and contrary the product's intended use.
Interference
All radio devices are subject to interference which could affect proper
performance.
Upgrades
Any upgrades to this product must be performed by an authorized
Directed dealer. Do not attempt to perform any unauthorized modifica-
tions to this product.
Water/Heat Resistance
This product is not designed to be water and/or heat-resistant. Please
take care to keep this product dry and away from heat sources. Any
damage from water or heat will void the warranty.
![](/img.php?id=2629035&img=bgf.png)
12 © 2015 Directed. All rights reserved.
Limited lifetime consumer warranty
Directed Electronics. (“Directed”) promises to the original purchaser to repair or replace (at
Directed’s election) with a comparable reconditioned model any Directed unit (hereafter the
“unit”), excluding without limitation the siren, the remote transmitters, the associated sensors
and accessories, which proves to be defective in workmanship or material under reason-
able use during the lifetime of the vehicle provided the following conditions are met: the
unit was purchased from an authorized Directed dealer, the unit was professionally installed
and serviced by an authorized Directed dealer; the unit will be profession¬ally reinstalled
in the vehicle in which it was originally installed by an authorized Directed dealer; and the
unit is returned to Directed, shipping prepaid with a legible copy of the bill of sale or other
dated proof of purchase bearing the following information: consumer’s name, telephone
number and address; the authorized dealers name, telephone number and address; com-
plete product description, including accessories; the year, make and model of the vehicle;
vehicle license number and vehicle identification number. All components other than the
unit, including without limitation the siren, the remote transmitters and the associated sensors
and accessories, carry a one-year warranty from the date of purchase of the same. ALL
PRODUCTS RECEIVED BY DIRECTED FOR WARRANTY REPAIR WITHOUT PROOF OF
PURCHASE FROM AN AUTHORIZED DEALER WILL BE DENIED. This warranty is non-
transferable and is automatically void if: the unit’s date code or serial number is defaced,
missing or altered; the unit has been modified or used in a manner contrary to its intended
purpose; the unit has been damaged by accident, unreasonable use, neglect, improper
service, installation or other causes not arising out of defects in materials or construction.
The warranty does not cover damage to the unit caused by installation or removal of the
unit. Directed, in its sole discretion, will determine what constitutes excessive damage and
may refuse the return of any unit with excessive damage.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUDING
BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF
MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND WARRANTY OF NON-
INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND
DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME
FOR IT ANY DUTY, OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.
DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY AND ALL ACTS
OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. DIRECTED
SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS AGAINST POSSIBLE
THEFT. DIRECTED IS NOT OFFERING A GUARANTEE OR INSURANCE AGAINST
VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS;
AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING
WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS
WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR
REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND.
13
© 2015 Directed. All rights reserved.
IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY,
THE VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.
CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN
THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED
SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER’S PURCHASE
PRICE OF THE UNIT. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES
WHATSOEVER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,
INCIDENTAL DAMAGES, DAMAGE TO VEHICLE, DAMAGES FOR THE LOSS OF TIME,
LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY
AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER
A LIMITED WARRANTY TO REPLACE OR REPAIR THE CONTROL MODULE SUBJECT TO
THE CONDITIONS AS DESCRIBED HEREIN. THIS WARRANTY IS VOID IF THE UNIT
HAS NOT BEEN PURCHASED FROM DIRECTED, OR AN AUTHORIZED DIRECTED
DEALER, OR IF THE UNIT HAS BEEN DAMAGED BY ACCIDENT, UNREASONABLE USE,
NEGLIGENCE, ACTS OF GOD, NEGLECT, IMPROPER SERVICE, OR OTHER CAUSES
NOT ARISING OUT OF DEFECT IN MATERIALS OR CONSTRUCTION.
Some states do not allow limitations on how long an implied warranty will last or the exclu-
sion or limitation of incidental or consequential damages. This warranty gives you specific
legal rights and you may also have other rights that vary from State to State.
This warranty is only valid for sale of product(s) within the United States of America and
in Canada. Product(s) sold outside of the United States of America or Canada are sold
“AS-IS” and shall have NO WARRANTY, express or implied.
For further details relating to warranty information of Directed products, please visit the
support section of Directed’s website at: www.directed.com
This product may be covered by a Guaranteed Protection Plan (“GPP”). See your
authorized Directed dealer for details of the plan or call Directed Customer Service at
1-800-876-0800.
920-10011-01 2011-06
