The Science of Security™
Clifford 1-Way Transmitter
PN 7642X
Compatible with the
following systems:
20.5X
50.5X
Compatible with
![](/img.php?id=826291&img=bg2.png)
REPLACEMENT TRANSMITTER
Model 7642X, 4 Button Companion Remote for Responder SST
2007-07
P/N 7642X
MADE IN CHINA
©2007 Directed Electronics.
Vista CA 92081
All rights reserved.
The following Learn Routine can be used to program this replacement transmitter to the system. In order to enter
the Learn Routine, the system’s Valet/Program switch must be plugged into the BLUE port.
1. Door. Open a door.
2. Key. Turn the key to the ON position.
3. Choose. Within 5 seconds press and release
the Valet/Program button once. Press the Valet/
Program button once more and hold it. The LED
will flash one time and the siren (if connected) will
chirp to confirm the selected channel. Do NOT
release the button.
4. Transmit. While holding the Valet/program
button, press the arm button from the transmitter
you wish to assign to that channel. The unit will
chirp (if horn or siren connected) to confirm that
the transmitter has been taught to the receiver
5. Release. Once the code is learned you can release
the Valet/Program button and remove the key.
Standard Configuration
A remote that has been programmed to a stan-
dard configuration that will use separate buttons for
arm and disarm similar to a factory keyless entry.
Using this configuration, the transmitter buttons are
assigned to the following functions:
Lock Icon Button
The lock icon button arms and locks the system.
Unlock Icon Button
The unlock icon button disarms and unlocks the
system.
AUX Icon Buttons
The AUX icon button operates channel 2.
Star Icon Button
The star icon button operates Remote Start.
FCC/ID Notice
This device complies with Part 15 of FCC rules.
Operation is subject to the following conditions: (1)
This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired opera-
tion.
CAUTION! Changes or modifications not expressly
approved by the party responsible for compliance
could void the user's authority to operate this device.
