Voxx Electronics DEI7656A One way transmitter SST car remote starter User Manual
DEI Headquarters, Inc. One way transmitter SST car remote starter
User Manual
![](/img.php?id=2183181&img=bg1.png)
![](/img.php?id=2183181&img=bg2.png)
![](/img.php?id=2183181&img=bg3.png)
© 2013 Directed. All Rights Reserved
GASRS1554 2013-07
Auto Start ASRS-1554FBK 1-Way Remote User Guide
Thank you for purchasing this Auto Start Remote Transmitter. This guide provides a general description of operations for Auto Start Remote Start and
Security Systems.
LOCK: Locks the DOORS and arms the STARTER KILL (if installed).
UNLOCK: Unlocks the DOORS and disarms the STARTER KILL (if installed). Activates the AUX 1 output if Priority Door
Access is configured.
TRUNK: Opens the TRUNK or activates the AUX 3 output. Note: Trunk option must be installed.
START: Remote starts or stops the engine. Gets the system into Cold Weather mode by pressing the AUX button and then
pressing and holding the START/STOP button for 3 seconds.
AUX: This button serves as a second function button. This button allows assigning different functions to any of the other four
buttons.
Remote Pairing
Procedure Confirmations
1. Pressandhold“AUX”buttonuntiltheremotegeneratesalongbeep. The LED will start flashing every 2 seconds for a period of 30 seconds.
2. TurnthekeytoIGNON
3. Pressreleaseandthenpressandholdtheantennaprogrammingbutton
untiltheLEDstartflashingrapidly.
The Parking lights will stay ON for 20 seconds. From this point, the installer
has 20 seconds to complete steps 4-5.
4. TurnthekeytoIGNOFF/ON/OFF.The parking light should turn OFF.
5. Pressandreleaselockbutton.The parking lights will start flashing to confirm successful learning of the
remote.
6. Press“AUX”buttononceORleavetheremoteinactivefor30seconds.
Note: To learn the remote to a second car that has the same system, in STEP4, press the TRUNK button instead of the LOCK button.
Government Regulations
This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) This device must accept any interference received, including interference that may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
To satisfy FCC RF exposure compliance requirements, this device should be used in hand-held, hand operated configurations only. The device and its
antenna must maintain a separation distance of 20 cm or more from the person’s body, except for the hand and wrists, to satisfy RF exposure
compliance. This device is designed to be used in a person’s hands and its operating configurations do not support normal transmissions while it is
carried in pockets or holsters next to a person’s body.
Canada Statements
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Les changements ou modifications non approuvés expressément par la partie responsable de la conformité pourrait annuler l'autorité de l'utilisateur à
faire fonctionner l'équipement.
![](/img.php?id=2183181&img=bg4.png)
© 2013 Directed. All Rights Reserved
GGSRS1554 2013-07
Auto Start GSRS-1554FBK 1-Way Remote User Guide
Thank you for purchasing this Auto Start Remote Transmitter. This guide provides a general description of operations for Auto Start Remote Start and
Security Systems.
LOCK: Locks the DOORS and arms the STARTER KILL (if installed).
UNLOCK: Unlocks the DOORS and disarms the STARTER KILL (if installed). Activates the AUX 1 output if Priority Door Access
is configured.
TRUNK: Opens the TRUNK or activates the AUX 3 output. Note: Trunk option must be installed.
START: Remote starts or stops the engine. Gets the system into Cold Weather mode by pressing the AUX button and then
pressing and holding the START/STOP button for 3 seconds.
AUX: This button serves as a second function button. This button allows assigning different functions to any of the other four
buttons.
Remote Pairing
Procedure Confirmations
1. Pressandhold“AUX”buttonuntiltheremotegeneratesalongbeep. The LED will start flashing every 2 seconds for a period of 30 seconds.
2. TurnthekeytoIGNON
3. Pressreleaseandthenpressandholdtheantennaprogrammingbutton
untiltheLEDstartflashingrapidly.
The Parking lights will stay ON for 20 seconds. From this point, the installer
has 20 seconds to complete steps 4-5.
4. TurnthekeytoIGNOFF/ON/OFF.The parking light should turn OFF.
5. Pressandreleaselockbutton.The parking lights will start flashing to confirm successful learning of the
remote.
6. Press“AUX”buttononceORleavetheremoteinactivefor30seconds.
Note: To learn the remote to a second car that has the same system, in STEP4, press the TRUNK button instead of the LOCK button.
Government Regulations
This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) This device must accept any interference received, including interference that may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
To satisfy FCC RF exposure compliance requirements, this device should be used in hand-held, hand operated configurations only. The device and its
antenna must maintain a separation distance of 20 cm or more from the person’s body, except for the hand and wrists, to satisfy RF exposure
compliance. This device is designed to be used in a person’s hands and its operating configurations do not support normal transmissions while it is
carried in pockets or holsters next to a person’s body.
Canada Statements
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Les changements ou modifications non approuvés expressément par la partie responsable de la conformité pourrait annuler l'autorité de l'utilisateur à
faire fonctionner l'équipement.
![](/img.php?id=2183181&img=bg5.png)
© 2013 Directed. All Rights Reserved
GOBRS1554 2013-07
Auto Start OBRS-1554FBK 1-Way Remote User Guide
Thank you for purchasing this Orbit Remote Transmitter. This guide provides a general description of operations for Orbit Remote Start and Security
Systems.
LOCK: Locks the DOORS and arms the STARTER KILL (if installed).
UNLOCK: Unlocks the DOORS and disarms the STARTER KILL (if installed). Activates the AUX 1 output if Priority Door Access
is configured.
TRUNK: Opens the TRUNK or activates the AUX 3 output. Note: Trunk option must be installed.
START: Remote starts or stops the engine. Gets the system into Cold Weather mode by pressing the AUX button and then
pressing and holding the START/STOP button for 3 seconds.
Orbit: This button serves as a second function button. This button allows assigning different functions to any of the other four
buttons.
Remote Pairing
Procedure Confirmations
1. Pressandhold“Orbit”buttonuntiltheremotegeneratesalongbeep. The LED will start flashing every 2 seconds for a period of 30 seconds.
2. TurnthekeytoIGNON
3. Pressreleaseandthenpressandholdtheantennaprogrammingbutton
untiltheLEDstartflashingrapidly.
The Parking lights will stay ON for 20 seconds. From this point, the installer
has 20 seconds to complete steps 4-5.
4. TurnthekeytoIGNOFF/ON/OFF.The parking light should turn OFF.
5. Pressandreleaselockbutton.The parking lights will start flashing to confirm successful learning of the
remote.
6. Press“Orbit”buttononceORleavetheremoteinactivefor30seconds.
Note: To learn the remote to a second car that has the same system, in STEP4, press the TRUNK button instead of the LOCK button.
Government Regulations
This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) This device must accept any interference received, including interference that may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television, which can be determined by turning the equipment OFF and ON, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
To satisfy FCC RF exposure compliance requirements, this device should be used in hand-held, hand operated configurations only. The device and its
antenna must maintain a separation distance of 20 cm or more from the person’s body, except for the hand and wrists, to satisfy RF exposure
compliance. This device is designed to be used in a person’s hands and its operating configurations do not support normal transmissions while it is
carried in pockets or holsters next to a person’s body.
Canada Statements
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Les changements ou modifications non approuvés expressément par la partie responsable de la conformité pourrait annuler l'autorité de l'utilisateur à
faire fonctionner l'équipement.
