Voxx Electronics NAH2202 2 Buttons OOK Remote User Manual
DEI Headquarters, Inc. 2 Buttons OOK Remote
User Manual
DOC. 1.00 - AS-2272- - May 30, 2008 - - MO - Assembled in Canada
MANUAL / AUTOMATIC TRANSMISSION MULTI-CHANNEL
REMOTE STARTER SYSTEM
AS-2272
User Guide
WARNING
It is the responsibility of the vehicle operator to ensure that their
vehicle is parked in a safe and responsible manner.
1. a) Manual transmission: When leaving the vehicle, it is the user’s
responsibility to ensure that the gearshift lever is in the NEUTRAL position
and the parking brake is engaged in order to avoid accidents upon remote
starting.
b) Automatic transmission: When leaving the vehicle, it is the user’s
responsibility to ensure that the gearshift lever is in “Park” in order to avoid
accidents upon remote starting.
(Note: Make sure that the automatic vehicle cannot start in "Drive".)
2. It is the user's responsibility to ensure that the remote starter is disabled or
put into valet mode before servicing.
FCC USER NOTICE (U.S.A.):
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this
equipment. Such modifications could void the user's authority to operate the equipment.
P. 2 User Guide
Table of contents
Introduction ...............................................................2
Vehicle Presets.......................................................... 2
Heater and Heated Seat ........................................2
Windshield Wipers, Radio and Headlights............. 2
Arming the Starter Kill..............................................3
Remote Starting Your Vehicle .................................3
Setting Your Vehicle Into Ready Mode..................3
Remote-starting......................................................4
Driving Off ..............................................................4
Remote starter features............................................ 4
Idle Mode................................................................ 4
Valet Mode .............................................................5
Panic Mode ............................................................6
Cold Weather Mode ...............................................6
Advanced Features: Installation-programmable
options ....................................................................... 6
Passive or Active Arming of the Starter Kill ...........6
Remote Door Locks ...............................................6
Ignition-controlled Door Locks ...............................6
Secure Lock ...........................................................6
Remote Trunk Release .......................................... 7
Turbo Mode ............................................................ 7
Engine Run Time ...................................................7
Troubleshooting Poor Transmitting Range Issues8
LIMITED LIFETIME WARRANTY .............................. 9
Introduction
This module is a state-of-the-art remote car starter system. With many advanced functions, this product
will satisfy any one of the user’s expectations from high-end commodity systems, without neglecting the
standard features commonly offered by entry-level starters.
Please note:
Button Ι is for the STOP functions (by default).
Button ΙΙ is for the START functions (by default).
Buttons Ι & ΙΙ (together) are for the TRUNK release function.
The LED and the valet button are optional.
Vehicle Presets
Heater and Heated Seat
When leaving the vehicle it is recommended to preset the accessory controls in preparation for the next
remote start. Settings for the blower motor (fan), front and rear, as well as heated seats (if equipped)
should not be left on HIGH. It is recommended to leave the settings on LOW or MEDIUM instead.
Windshield Wipers, Radio and Headlights
Certain vehicles require the radio and / or windshield wipers and / or headlights circuits to become
energized while running under remote start. When leaving the vehicle you must ensure that the
windshield wipers and headlights switches are OFF. Leaving the headlights switch ON on certain types of
vehicles could cause them to remain ON even after remote starter shutdown, resulting in a dead battery.
User Guide P. 3
Arming the Starter Kill
Note: It can only be activated if button Ι is programmed as LOCK or UNLOCK button.
The Starter Kill (if installed) can be configured by the installer either to Passive Mode (so as to arm
automatically) or Active Mode (so as to require the user’s intervention for arming). By default, your
Remote Car Starter is configured to Passive Mode.
¾ Passive mode:
• To arm the Starter Kill, press the Ι button on the transmitter, OR
• In Passive Mode, the Starter Kill will also automatically arm 1 minute (by default) or 3 minutes (if
configured this way) after the ignition is turned OFF or once the last door is closed (if the doors are
monitored).
- The LED on the antenna will flash quickly during the countdown preceding the activation
of the Starter Kill.
- Once the activation countdown expires, the LED will send a series of quick double
flashes to indicate that the Starter Kill is now armed.
• To disarm the Starter Kill, press the Ι button on the transmitter.
- The Starter Kill will automatically rearm itself after 1 minute (by default) or 3 minutes (if
configured this way) if no door is left opened (if the doors are monitored) and the ignition
is not turned ON.
¾ Active Mode:
• To arm the Starter Kill, press the Ι button on the transmitter.
- The parking lights will flash once.
- The LED on the antenna will flash slowly.
- If remote door locks are installed, this will also lock the doors.
• To disarm the Starter Kill, press the Ι button on the transmitter.
- The parking lights will flash twice.
- The LED on the antenna will remain OUT.
- If remote door locks are installed, this will also unlock the doors.
Remote Starting Your Vehicle
If your vehicle has an automatic transmission, simply press the ΙΙ button to remote start or the
Ι button to stop your vehicle. Skip the next steps on to “Remote-starting”.
Setting Your Vehicle Into Ready Mode
If your vehicle has a manual transmission you must read the following indications. In order to start the
vehicle by remote, the unit must first be set to Ready Mode. If the unit is not set to Ready Mode, it
cannot remote start the vehicle.
Please note that Ready Mode can be enabled by the remote or the handbrake, depending on the
option that was selected by your installer. Therefore, you must follow the appropriate procedure
between the two described below in order to set your vehicle into Ready Mode.
Once the system is set to Ready Mode, the vehicle can be remote started and stopped at any time. The
system will exit Ready Mode if a door, the hood or the trunk is opened, if the brake pedal is pressed, if
the parking brake is disengaged or if the ignition key is turned to the IGNITION ON (RUN) position.
P. 4 User Guide
To set the system to Ready Mode:
If Ready Mode is enabled by remote If Ready Mode is enabled by handbrake
1. Ensure that all the doors, hood and trunk are closed. Make sure that the gear selector is in the neutral
position.
2. With the engine already running, apply the
parking brake once and release the brake
pedal.
Make sure to release the brake pedal.
2. With the engine already running, apply the
parking brake twice and release the brake
pedal.
Make sure to release the brake pedal.
The parking lights will flash 3 times
quickly and remain lit.
Skip to step 4.
3. Within 20 sec. of engaging the parking brake,
press and hold Ι or ΙΙ on the transmitter.
The parking lights will flash 3 times
quickly and remain lit.
-
4. Remove the key: the engine will continue running.
5. Exit the vehicle and close all doors, hood and trunk.
6. Press for approx. 1 second either button: Ι or ΙΙ.
Note: The vehicle will also enter Ready Mode once the engine run time expires.
Remote-starting
Press the ΙΙ button for approximately 1 second. The parking lights will come ON to inform you that the
remote starter has received your signal. Approximately 5 seconds later, the engine will start. The
parking lights will remain ON during the pre-programmed run time of the engine.
If the vehicle does not start at the first attempt, the system will shut down, wait a few seconds and try to
start the engine again. If your vehicle is equipped with an automatic transmission, there will be 3 start
attempts before the system gives up.
Driving Off
With the vehicle running under remote control, press the button Ι to disarm the security system (if
button Ι is programmed as LOCK or UNLOCK button). Enter the vehicle and do the following:
1. Turn the ignition key to the IGNITION ON (RUN) position. (Do not turn the key to the CRANK position
while the engine is running. This will cause the starter motor to re-engage.)
2. Press the brake pedal to disengage the remote starter unit.
You are now ready to drive off.
Remote starter features
Idle Mode
Convenience feature: Idle Mode allows you to keep the engine running and the doors locked
while you stop, for example, at a convenience store or for a short delivery.
This feature allows you to let the remote starter take control of the vehicle (i.e. no Key in the Ignition
Switch) while the engine is running.
To leave the vehicle in Idle Mode if your vehicle has an automatic transmission:
1. With the engine running, make sure to release the brake pedal and press the ΙΙ button on the
remote control until the parking lights come on.
2. Remove the key and exit the vehicle. The engine will continue running.
3. Lock the doors if needed.
Note: The engine will continue running until the user re-enters the vehicle or until the expiration of the
engine run time.
User Guide P. 5
If your vehicle has a manual transmission, Idle Mode can be activated through the same routine
as that used for Ready Mode (see earlier in this Guide); at the last step, the buttons Ι & ΙΙ are
pressed together.
Note: If the pre-programmed run-time expires or if the user shuts down the engine by remote control,
the vehicle will enter Ready Mode.
Caution!!! Do not leave children or pets unattended in a vehicle standing in Idle Mode.
Valet Mode
When your vehicle is in Valet Mode, the remote starter function is disabled. If the vehicle needs to be
serviced, or if you park it indoors, the Valet Mode will prevent the engine from being remote-started
accidentally.
¾ Any of the following features will put your remote car starter into Valet Mode:
• Ignition Valet: This feature allows you to put your system into Valet Mode by
using the ignition key.
• Valet switch: This feature allows you to put your system into Valet Mode by using a
push button switch (optional).
To put the system i n t o Valet Mode
• To put the system i n t o Valet mode using the KEY (Ignition Valet Mode):
a. Insert the ignition key into the ignition switch. Within 10 sec., turn the key 5 times
successively into the IGNITION/RUN and OFF positions.
The parking lights will flash three times.
b. Turn the ignition OFF
The LED on the antenna will come ON solid to indicate that the vehicle has successfully
entered Valet mode.
• To put the system i n t o Valet mode using the PUSH BUTTON SWITCH (Valet Switch Mode):
a. Insert the ignition key into the ignition switch.
b. Turn the key into the ON position
c. Within 5 seconds, press the push button switch until the parking lights flash 3 times.
d. Release the push button and turn the ignition to the OFF position.
The LED on the antenna will come ON solid to indicate that the vehicle has successfully
entered Valet mode.
To put the system o u t o f Valet Mode
• To put the system o u t o f Valet mode using the KEY (Ignition Valet Mode):
a. Insert the ignition key into the ignition switch. Within 10 sec., turn the key 5 times
successively into the IGNITION/RUN and OFF positions.
The parking lights will flash twice.
b. Turn the ignition OFF
The LED on the antenna will flash quickly to indicate that the vehicle is now out of Valet
mode.
• To put the system o u t o f Valet mode using the PUSH BUTTON SWITCH (Valet Switch
Mode):
a. Insert the ignition key into the ignition switch.
b. Turn the key into the ON position
c. Press the push button switch until the Parking lights flash twice.
d. Release the push button and turn the ignition to the OFF position.
The LED on the antenna will flash quickly to indicate that the vehicle is now out of Valet
mode.
P. 6 User Guide
Panic Mode
Note: Panic mode can only be activated if the horn option has been adequately installed and
programmed by your installer. Button Ι has to be programmed as LOCK and UNLOCK.
In an emergency situation, you can activate panic mode by pressing and holding the Ι button for
approximately 3 seconds until the horn honk starts and the parking lights flash. This will:
• shut down the engine
• unlock or lock the doors (with the Ι button)
• disarm the Starter Kill and
• activate the horn for 25 sec.
Panic Mode will automatically shut down after 25 sec.
Note: To stop panic mode before the end of its delay, press the Ι button until the sound signal
stops.
Cold Weather Mode
If your vehicle has a manual transmission, Ready mode should be set before entering cold weather
mode. When cold weather mode is active, the engine starts every 2 hours and runs for 3 minutes (or for
8 or 20 minutes with diesel engines). Cold weather mode automatically ends after 24 hours (or 12
starts).
To enter Cold Weather Mode:
• Press and hold the ΙΙ button for 3 seconds or until the parking lights flash three (3) times.
To exit Cold Weather Mode, do any one of the following actions:
• Open the hood.
• Start the engine by remote.
• Start the engine with the key.
• Press and hold the ΙΙ button for three seconds (the parking lights will flash once).
To verify whether the system is in Cold Weather Mode (automatic transmissions only):
• Press the brake pedal:
• If the vehicle is in cold weather mode, the parking lights will stay on while the pedal is pressed.
Advanced Features: Installation-programmable options
Caution: The programming of your system should be left to a professional. Changing any one of
the settings may affect the operation of your Remote Car Starter. Please note that the following
programmable options may require additional parts and labor.
Passive or Active Arming of the Starter Kill
See section “Arming the Starting Kill” earlier in this guide.
Remote Door Locks
If your Remote Car Starter was installed with the Remote Door Locks option, you will have the
convenience of remote keyless entry. See section “Arming the Starter Kill”, earlier in this Guide, for
further instructions on remote door locking and unlocking.
Ignition-controlled Door Locks
This is an added security feature. If your remote starter was installed with the ignition-controlled door
locks option, the doors will automatically lock as soon as the key is turned to the IGNITION ON (RUN)
position while the brakes are pressed. The remote car starter will also lock any door that was unlocked
and opened (then closed) the next time the break pedal is pressed. When the key is turned to the OFF
position, the doors will automatically be unlocked.
Secure Lock
(Only for certain vehicles.) Before your vehicle can be remote-started, the factory security system must
first be disarmed. The secure lock feature may be required on certain vehicle models with factory
security systems that automatically unlock the doors when the security system is disarmed.
User Guide P. 7
To keep your vehicle protected when the factory security system is disarmed for a remote start, secure
lock will relock your doors as soon as the vehicle is started. Once the engine is shut down by remote or
after its runtime has expired, secure lock will also rearm your factory security system and relock the
doors.
Remote Trunk Release
If your system was installed with the remote trunk release option, you can open your trunk by pressing
the Ι & ΙΙ buttons (simultaneously) on the remote transmitter. Vehicles must have an electric trunk
switch or a remote trunk button on the vehicle’s OEM transmitter for this option to be compatible with
the module.
Turbo Mode
If Turbo Mode is configured at installation, it will allow a turbocharger to idle down after the user leaves
the vehicle: the unit will take over the vehicle and keep it running for 60 seconds (or until it is shut down
by remote control), then shut down the engine.
If your vehicle has an automatic transmission, proceed as follows to set the system to Turbo
Mode:
1. With the engine running, make sure to release the brake pedal and press the buttons Ι & ΙΙ on the
transmitter until the parking lights come ON.
2. Remove the key from the ignition switch. The engine will continue running.
3. Exit the vehicle and close all doors, hood and trunk.
4. Press the buttons Ι & ΙΙ to lock the doors (the engine will shut down after 60 seconds).
Note: If your vehicle has a manual transmission, Turbo Mode can be activated only if button Ι is
programmed as LOCK or UNLOCK button. Turbo Mode is activated through the same routine as that
used for Ready Mode; at the last step, the button Ι is pressed.
Note: The vehicle will enter Ready Mode once the engine run time expires.
Engine Run Time
If you have a gas engine, your remote starter can be programmed to run the engine for 3, 15, or
25 minutes (15 minutes by default). If you have a diesel engine, the remote starter can be programmed
to run the engine for 8, 20, or 30 minutes (20 minutes default).
P. 8 User Guide
Troubleshooting Poor Transmitting Range Issues
Many factors may affect the operating range of the transmitter. Some of these are:
• The condition of the battery in the transmitter.
• The operating environment (for example: downtown radio-frequency noise, airports, cellular phone
towers…).
• Metal: any type of metal will affect operating range. This includes the vehicle itself.
• The shape of the vehicle can affect range as well (vans in general have less range).
• The shape of the roof and A-pillars brings about considerable radio-frequency deflection (in this case
the signal from the remote control). As a result, the direction in which the vehicle is facing in relation
to the remote control can affect the range. Straight on (standing in front of the vehicle) generally
gives you the greatest range; the second best performance is from the back. Using the remote
control from either side of the vehicle will usually give the lowest range.
• The range will be significantly lower in a crowded parking lot than in open space.
• The transmitter’s antenna may be partially covered by the user’s fingers. Always hold the transmitter
high, approximately at shoulder height, and ensure that your fingers are not covering the antenna.
• The operating range will be somewhat lower on vehicles equipped with an aftermarket or factory
alarm.
User Guide P. 9
LIMITED LIFETIME WARRANTY
REMOTE STARTERS AND ALARM SYSTEMS:
As the manufacturer, 4366859 Canada Inc. (“Autostart”) warrants to the original consumer purchaser only
(nontransferable) that the remote starter module (control box) shall be free from defects in materials and workmanship
for as long as the original consumer purchaser continuously owns the vehicle in which the remote starter was
originally installed, as specified below:
1) For the first two years after the date of manufacture, as specified by the serial number on the module,
Autostart will replace the remote starter module free of charge with a new remote starter module.
2) For the third year and any consecutive year after the date of manufacture, as specified by the serial number
on the module, Autostart will provide to the original consumer purchaser a new remote starter module, for a
repair charge of $25.00 USD.
In all cases, the consumer must return the remote starter module to the point of purchase, and must provide a copy of the
proof of purchase to said retailer. A remote starter module will be returned to the retailer for the consumer to claim
within a 4 (four)-week period. For case (2), a certified check or money order in the amount of $25.00 USD must
accompany the remote starter module, or the retailer may refuse the return.
ACCESSORIES:
Autostart warrants to the original consumer purchaser only (nontransferable) that it will replace any Autostart
accessory part for a one-year period from date of purchase. Accessories will only be replaced if proven defective in
material or workmanship, and if, when the accessory is returned to the point of purchase, the retailer is provided with a
copy of the proof of purchase. The accessory will be sent to the retailer for the consumer to claim within a 4 (four)-week
period.
THE WARRANTY IS VOID IF:
1) The product has been damaged, altered in any way or tampered with, without the explicit written
consent of an Autostart technician. For remote starter modules, this includes the opening or removal of
the plastic covering of the module, or the removal or alteration of the barcode label on the plastic
covering of the module.
2) The product is damaged due to accident, fire, flood, shipping and handling, misuse, neglect, or other
conditions beyond the control of Autostart.
3) The product has been installed or repaired by anyone other than a certified technician.
4) The product has been improperly installed or used.
THE WARRANTY DOES NOT COVER:
1) Batteries.
2) Scratched or worn transmitter cases.
3) Installation and/or removal charges for all remote starter modules and accessories.
4) Shipping and handling charges incurred for product exchange or replacement.
5) Any material damages other than to the product itself.
6) Harnessing, L.E.D. lights, switches, inverters, relays, etc.
THIS LIMITED LIFETIME WARRANTY SHALL CONSTITUTE THE SOLE LIABILITY OF AUTOSTART FOR
OUR PRODUCTS, AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED. THERE ARE
NO WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. NO PERSON,
FIRM OR CORPORATION IS AUTHORIZED TO ASSUME FOR AUTOSTART ANY OTHER LIABILITY WITH
RESPECT TO THE SALE OR USE OF OUR PRODUCTS. AUTOSTART’S LIABILITY, WHETHER BASED ON
CONTRACT, TORT, WARRANTY, STRICT LIABILITY, OR ANY OTHER THEORY, SHALL NOT EXCEED
THE PRICE OF THE INDIVIDUAL UNIT WHOSE DEFECT FOR DAMAGE IS THE BASIS OF THE CLAIM.
UNDER NO CIRCUMSTANCE WILL AUTOSTART, ITS DISTRIBUTORS OR THEIR AGENTS BEAR ANY
LIABILITY WHATSOEVER FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
The parties hereto elect that any dispute regarding the present document be submitted to the appropriate Court located in the Province of
Quebec, District of Montreal. The parties hereto agree that this document is governed by and interpreted in accordance with the law of Quebec.
If the purchaser is located in a province of Canada other than Quebec, all matters dealing with the warranty of quality will be governed by and
interpreted in accordance with the law of Ontario. If the purchaser is located outside Canada, all matters dealing with the warranty of quality will
be governed by and interpreted in accordance with the United Nations Convention on Contracts for the International Sale of Goods (the “Vienna
Convention”).
