WEIKING TECHNOLOGY ZK606 Bluetooth Speaker User Manual BT236
SHENZHEN WEIKING TECHNOLOGY CO.,LTD Bluetooth Speaker BT236
15_BT236 UserMan
Volume UP
BT236
Volume Down
Press “ ”，“ ” buttons simultaneously until LED
Indicator fast blinking blue to disconnect the current
connected device, and go into new Bluetooth-paring
mode.
Power-on/off
Play/Pause/Mute(Aux-in mode)
BT236
Flash Blue & Green
• Bluetooth Version: 4.2
• Suport:A2DPV1.2,AVRCPV1.4,HPV1.6,HSPV1.2
• Wireless work distance:10meters
• Rated Power: 2 x 5W
• Driver Unit: 2 xφ48mm (4Ω,12W)
• Frequency response: 100Hz-18kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion (3.7V/2000mAh)
• DC input voltage/current: 5V ±0.25V /2A
• Playtime: 6-8 hours (varies by volume level and content)
• Battery charge time: 3-4 hours
• Dimensions: 158.5 x 65 x62.5 mm
• Weight: 355g
TheTWS technology enables you to use two speakers
pairing via Bluetooth to create a wireless dual-channel
system to deliver true stereo sound effect.
TWS connection operation
1.Place the two speakers near each other (the distance
should not be over 10 meters).
2.Power on the two speakers, double click the button
button on one speaker as MASTER speaker (playback
left channel ), the LED indicator fast blinking blue and
green, then the two speaker will pair to each other
automatically (The other speaker will be as SLAVE
speaker and playback right channel)
3.Once paired, the MASTER speaker LED indicator
slow flash blue.
TWS (True Wireless Stereo)
Function
Disconnect the TWS connection
Press“ ”, “ ” button on one of the speaker simultaneously
until LED Indicator fast blinking blue to disconnect the
TWS connection.
Overvivew of Speaker
Charging
• 1 xSpeaker
• 1x Micro-USB Cable
• 1 xAUX Cable (Ф3.5mm)
• 1x User Manual
Package Includes
USB Changing Port
Aux-In
LED
Note:
• When power on, the speaker automatically reconnects to
the last mobile device it was connected to. (The
speaker can memorize maximum of 8 paired devices ).
• The speaker will automatically shut down after 10
minutes in pairing mode if no devices are paired for power
saving.
Play / Pause………………Click
Volume Up……………Click
Volume Down………Click
Next track…………Press and Hold
Previous track…………Press and Hold
Switch Bluetooth mode/Aux-in mode…………Click
Answer an incoming call…………Click
Reject an incoming call…………Press and Hold
End the current call……………Click
Redial last-called number…………Press and Hold
NOTE: This equipment has been tested and found to comply with the
limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are
designed to provide reasonable protection against harmful interference
in a
residential installation. This equipment generates uses and can radiate
radio
frequency energy and, if not installed and used in accordance with the
instructions,
may cause harmful interference to radio communications. However, there
is no
guarantee that interference will not occur in a particular
installation. If this
equipment does cause harmful interference to radio or television
reception, which
can be determined by turning the equipment off and on, the user is
encouraged to
try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party
responsible for compliance
could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may
cause undesired operation.
