WINIA Electronics 7NF22MO1200 MICROWAVE OVEN User Manual
Dongbu Daewoo Electronics Corporation MICROWAVE OVEN Users Manual
Users Manual
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
IMPORTANT SAFETY INSTRUCTIONS.
READ ALL INSTRUCTIONS BEFORE USING.
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or
to prevent property damage, personal injury, or loss of life.
IMPORTANT SAFETY INSTRUCTIONS.
This microwave oven is not approved or tested for marine use.
Use this appliance only for its intended purpose as described in this Owner’s Manual.
■Read and follow the specific precautions in the
Precautions to Avoid Possible Exposure to Excessive
Microwave Energy section above.
■This appliance must be grounded. Connect only
to a properly grounded outlet. See the Grounding
Instructions section on page 4.
■Install or locate this appliance only in accordance with
the provided installation instructions.
■Be certain to place the front surface of the door three
inches or more back from the countertop edge to avoid
accidental tipping of the appliance in normal usage.
■Do not mount this appliance over a sink.
■Do not mount the microwave oven over or near any
portion of a heating or cooking appliance.
■Do not store anything directly on top of the microwave
oven surface when the microwave oven is in operation.
■Do not operate this appliance if it has a damaged power
cord or plug, if it is not working properly, or if it has
been damaged or dropped. If the power cord is
damaged, it must be replaced by General Electric Service
or an authorized service agent using a power cord
available from General Electric.
■Do not cover or block any openings on the appliance.
■Use this appliance only for its intended use as described
in this manual. Do not use corrosive chemicals or vapors
in this appliance. This microwave oven is specifically
designed to heat, dry or cook food, and is not intended
for laboratory or industrial use.
■Do not store this appliance outdoors. Do not use this
product near water—for example, in a wet basement,
near a swimming pool or near a sink.
■Keep power cord away from heated surfaces.
■Do not immerse power cord or plug in water.
■Do not let power cord hang over edge of table
or counter.
■To reduce the risk of fire in the oven cavity:
– Do not overcook food. Carefully attend appliance
if paper, plastic or other combustible materials are
placed inside the oven while cooking.
– Remove wire twist-ties and metal handles from paper or
plastic containers before placing them in the oven.
– Do not use the oven for storage purposes. Do not leave
paper products, cooking utensils or food in the oven
when not in use.
– If materials inside the oven should ignite, keep the oven
door closed, turn the oven off and disconnect the power
cord, or shut off power at the fuse or circuit breaker
panel. If the door is opened, the fire may spread.
■See door surface cleaning instructions in the
Care and cleaning of the microwave oven section
of this manual.
■This appliance should be serviced only by qualified
service personnel. Contact nearest authorized service
facility for examination, repair or adjustment.
■As with any appliance, close supervision is necessary
when used by children.
SAVE THESE INSTRUCTIONS
WARNING!
(a) Do Not Attempt to operate this oven with the door
open since open-door operation can result in harmful
exposure to microwave energy. It is important not to
defeat or tamper with the safety interlocks.
(b) Do Not Place any object between the oven front face
and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
(c) Do Not Operate the oven if it is damaged. It is
particularly important that the oven door close
properly and that there is no damage to the:
(1) door (bent),
(2) hinges and latches (broken or loosened),
(3) door seals and sealing surfaces.
(d) The Oven Should Not be adjusted or repaired by
anyone except properly qualified service personnel.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
2
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
ARCING
If you see arcing, press the CLEAR/OFF pad and correct the problem.
Arcing is the microwave term for sparks in the oven.
Arcing is caused by:
■Metal or foil touching the side of the oven.
■Foil not molded to food (upturned edges act like
antennas).
■Metal, such as twist-ties, poultry pins or gold-
rimmed dishes, in the microwave.
■Recycled paper towels containing small metal
pieces being used in the microwave.
FOODS
■Do not pop popcorn in your microwave oven
unless in a special microwave popcorn accessory
or unless you use popcorn labeled for use in
microwave ovens.
■Some products such as whole eggs and sealed
containers—for example, closed jars—will
explode and should not be heated in this
microwave oven. Such use of the microwave oven
could result in injury.
■Do not boil eggs in a microwave oven. Pressure
will build up inside egg yolk and will cause it to
burst, possibly resulting in injury.
■Operating the microwave with no food inside for
more than a minute or two may cause damage to
the oven and could start a fire. It increases the
heat around the magnetron and can shorten the
life of the oven.
■Foods with unbroken outer “skin” such as
potatoes, hot dogs, sausages, tomatoes, apples,
chicken livers and other giblets, and egg yolks
should be pierced to allow steam to escape during
cooking.
■SUPERHEATED WATER
Microwaved water and other liquids do not always
bubble when they reach the boiling point. They can
actually get superheated and not bubble at all.
Superheated liquid will bubble up out of the cup when
it is moved or when something like a spoon or tea bag
is put into it.
To prevent this from happening and causing injury, do
not heat any liquid for more than 2 minutes per cup.
After heating, let the cup stand in the microwave for
30 seconds before moving it or putting anything into it.
■Avoid heating baby food in glass jars, even with
the lid off. Make sure all infant food is thoroughly
cooked. Stir food to distribute the heat evenly.
Be careful to prevent scalding when warming
formula. The container may feel cooler than the
formula really is. Always test the formula before
feeding the baby.
■Don’t defrost frozen beverages in narrow-necked
bottles (especially carbonated beverages). Even if
the container is opened, pressure can build up.
This can cause the container to burst, possibly
resulting in injury.
■Spontaneous boiling—Under certain special
circumstances, liquids may start to boil during or
shortly after removal from the microwave oven.
To prevent burns from splashing liquid, we
recommend the following: before removing the
container from the oven, allow the container to
stand in the oven for 30 to 40 seconds after the
oven has shut off. Do not boil liquids in narrow-
necked containers such as soft drink bottles, wine
flasks, and especially narrow-necked coffee cups.
Even if the container is opened, excessive steam
can build up and cause it to burst or overflow.
■Hot foods and steam can cause burns. Be careful
when opening any containers of hot food,
including popcorn bags, cooking pouches and
boxes. To prevent possible injury, direct steam
away from hands and face.
■Do not overcook potatoes. They could dehydrate
and catch fire, causing damage to your oven.
■Cook meat and poultry thoroughly—meat to at
least an INTERNAL temperature of 160°F and
poultry to at least an INTERNAL temperature of
180°F. Cooking to these temperatures usually
protects against foodborne illness.
WARNING!
3
4
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
MICROWAVE-SAFE COOKWARE
Make sure all cookware used in your microwave
oven is suitable for microwaving. Most glass
casseroles, cooking dishes, measuring cups, custard
cups, pottery or china dinnerware which does not
have metallic trim or glaze with a metallic sheen can
be used. Some cookware is labeled “suitable for
microwaving.”
■If you are not sure if a dish is microwave-safe,
use this test: Place in the oven both the dish
you are testing and a glass measuring cup filled
with 1 cup of water—set the measuring cup either
in or next to the dish. Microwave 30–45 seconds
at high. If the dish heats, it should not be used
for microwaving.
If the dish remains cool and only the water in
the cup heats, then the dish is microwave-safe.
■If you use a meat thermometer while cooking,
make sure it is safe for use in microwave ovens.
■Do not use recycled paper products. Recycled
paper towels, napkins and waxed paper can
contain metal flecks which may cause arcing
or ignite. Paper products containing nylon or
nylon filaments should be avoided, as they may
also ignite.
■Some styrofoam trays (like those that meat is
packaged on) have a thin strip of metal
embedded in the bottom. When microwaved,
the metal can burn the floor of the oven or ignite
a paper towel.
■Do not use the microwave to dry newspapers.
■
Not all plastic wrap is suitable for use in
microwave ovens. Check the package for
proper use.
■Paper towels, waxed paper and plastic wrap
can be used to cover dishes in order to retain
moisture and prevent spattering. Be sure to
vent plastic wrap so steam can escape.
■Cookware may become hot because of heat
transferred from the heated food. Pot holders
may be needed to handle the cookware.
■“Boilable” cooking pouches and tightly closed
plastic bags should be slit, pierced or vented as
directed by package. If they are not, plastic could
burst during or immediately after cooking,
possibly resulting in injury. Also, plastic storage
containers should be at least partially uncovered
because they form a tight seal. When cooking
with containers tightly covered with plastic wrap,
remove covering carefully and direct steam away
from hands and face.
■Use foil only as directed in this guide. TV dinners
may be microwaved in foil trays less than 3/4″
high; remove the top foil cover and return the
tray to the box. When using foil in the microwave
oven, keep the foil at least 1 inch away from the
sides of the oven.
■Plastic cookware—Plastic cookware designed for
microwave cooking is very useful, but should be
used carefully. Even microwave-safe plastic may
not be as tolerant of overcooking conditions as
are glass or ceramic materials, and may soften or
char if subjected to short periods of overcooking.
In longer exposures to overcooking, the food
and cookware could ignite.
Follow these guidelines:
Use microwave-safe plastics only and use
them in strict compliance with the cookware
manufacturer’s recommendations.
Do not microwave empty containers.
Do not permit children to use plastic
cookware without complete supervision.
3
2
1
WARNING!
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
ADAPTER PLUGS
Usage situations where appliance’s power cord will be disconnected infrequently.
Because of potential safety hazards under certain conditions,
we strongly recommend against the use of an adapter plug. However, if
you still elect to use an adapter, where local codes permit, a TEMPORARY
CONNECTION may be made to a properly grounded two-prong wall
receptacle by the use of a UL listed adapter which is available at most
local hardware stores.
The larger slot in the adapter must be aligned with the larger slot in
the wall receptacle to provide proper polarity in the connection of the
power cord.
CAUTION: Attaching the adapter ground terminal to the wall receptacle cover screw does not ground
the appliance unless the cover screw is metal, and not insulated, and the wall receptacle is grounded
through the house wiring.
You should have the circuit checked by a qualified electrician to make sure the receptacle is properly
grounded.
When disconnecting the power cord from the adapter, always hold the adapter with one hand. If this
is not done, the adapter ground terminal is very likely to break with repeated use. Should this happen,
DO NOT USE the appliance until a proper ground has again been established.
Usage situations where appliance’s power cord will be disconnected frequently.
Do not use an adapter plug in these situations because frequent disconnection of the power cord places
undue strain on the adapter and leads to eventual failure of the adapter ground terminal. You should have
the two-prong wall receptacle replaced with a three-prong (grounding) receptacle by a qualified electrician
before using the appliance.
Ensure proper ground
and firm connection
before use.
TEMPORARY
METHOD
Align large
prongs/slots
(Adapter plugs not
permitted in Canada)
5
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of
an electrical short circuit, grounding reduces the
risk of electric shock by providing an escape wire
for the electric current.
This appliance is equipped with a power cord
having a grounding wire with a grounding plug.
The plug must be plugged into an outlet that is
properly installed and grounded.
Consult a qualified electrician or service technician
if the grounding instructions are not completely
understood, or if doubt exists as to whether the
appliance is properly grounded.
If the outlet is a standard 2-prong wall outlet,
it is your personal responsibility and obligation
to have it replaced with a properly grounded
3-prong wall outlet.
Do not under any circumstances cut or remove
the third (ground) prong from the power cord.
We do not recommend using an extension cord
with this appliance. If the power cord is too short,
have a qualified electrician or service technician
install an outlet near the appliance. (See
EXTENSION CORDS section.)
For best operation, plug this appliance into its
own electrical outlet to prevent flickering of lights,
blowing of fuse or tripping of circuit breaker.
WARNING—Improper use of the grounding plug can result in a risk of electric shock.
6
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
EXTENSION CORDS
A short power supply cord is provided to reduce the risks resulting from becoming entangled in or tripping
over a longer cord.
Extension cords may be used if you are careful in using them.
If an extension cord is used—
The marked electrical rating of the extension cord should be at least as great as the electrical rating of
the appliance;
The extension cord must be a grounding-type 3-wire cord and it must be plugged into a 3-slot outlet;
The extension cord should be arranged so that it will not drape over the countertop or tabletop
where it can be pulled on by children or tripped over unintentionally.
If you use an extension cord, the interior light may flicker and the blower sound may vary when the
microwave oven is on. Cooking times may be longer, too.
3
2
1
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
7
About the features of your microwave oven.
Consumer SupportTroubleshooting Tips
Operating InstructionsSafety Instructions
Throughout this manual, features and appearance may vary from your model.
1200 Watts
Features of the Oven
Door Latches.
Window with Metal Shield. Screen allows
cooking to be viewed while keeping
microwaves confined in the oven.
Convenience Guide.
Touch Control Panel Display.
Door Latch Release. Press latch release to
open door.
Removable Turntable. Turntable and support
must be in place when using the oven. The
turntable may be removed for cleaning.
Removable Turntable Support. The turntable
support must be in place when using
the oven.
NOTE: Rating plate, oven vent(s) and oven light are located
on the inside walls of the microwave oven.
Optional Accessories
Available at extra cost from your GE supplier.
Choose the appropriate Installation Kit below to
convert this oven to a built-in wall oven.
For 27″installations:
Model Kit
JE2160BF JX2127BF
JE2160CF JX2127CF
JE2160SF JX2127SF
JE2160WF JX2127WF
For 30″installations:
Model Kit
JE2160BF JX2130BF
JE2160CF JX2130CF
JE2160SF JX2130SF
JE2160WF JX2130WF
You can microwave by time, with the sensor features or with the auto feature.
8
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
About the features of your microwave oven.
Cooking Controls
Time Features
Press Enter
TIME COOK Amount of cooking time
Press once or twice
TIME DEFROST Amount of defrosting time
EXPRESS COOK Starts immediately!
POWER LEVEL Power level 1 to 10
ADD 30 SEC Starts immediately!
Sensor Features and Auto Features
Press Enter
POPCORN Starts immediately!
VEGETABLE Starts immediately!
Press once (fresh vegetables)
Press twice (frozen vegetables)
Press three times (canned vegetables)
REHEAT Starts immediately!
BEVERAGE Starts immediately!
POTATO Starts immediately!
CHICKEN/FISH Starts immediately!
Press once (chicken pieces)
Press twice (fish)
Press Enter
AUTO DEFROST Food weight
Check the Convenience Guide before you begin.
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
About changing the power level.
The power level may be entered or
changed immediately after entering the
time for Time Cook.
Press TIME COOK.
Enter cooking time.
Press POWER LEVEL.
Select desired power level 1–10.
Press START.
Variable power levels add flexibility to
microwave cooking. The power levels on the
microwave oven can be compared to the
surface units on a range. Each power level
gives you microwave energy a certain
percent of the time. Power level 7 is
microwave energy 70% of the time. Power
level 3 is energy 30% of the time. Most
cooking will be done on High which gives
you 100% power. ¤Æ¤Æ¤Ä ¤Æ¤Äpower level10 will cook
faster but food may need more frequent
stirring, rotating or turning over. A lower
setting will cook more evenly and need less
stirring or rotating of the food. Some foods
may have better flavor, texture or
appearance if one of the lower settings is
used. Use a lower power level when cooking
foods that have a tendency to boil over,
such as scalloped potatoes.
Rest periods (when the microwave energy
cycles off) give time for the food to
“equalize” or transfer heat to the inside
of the food. An example of this is shown
with power level 3—the defrost cycle. If
microwave energy did not cycle off, the
outside of the food would cook before
the inside was defrosted.
Here are some examples of uses for various
power levels:
High10: Fish, bacon, vegetables, boiling
liquids.
Med-High 7: Gentle cooking of meat and
poultry; baking casseroles and reheating.
Medium 5: Slow cooking and tenderizing
for stews and less tender cuts of meat.
Low 2 or 3: Defrosting; simmering; delicate
sauces.
Warm 1: Keeping food warm; softening
butter.
5
4
3
2
1
About the time features.
Time Cook
Allows you to microwave for any time up to
99 minutes and 99 seconds.
High power level is automatically set, but you
may change it for more flexibility.
Press TIME COOK.
Enter cooking time.
Change the power level if you don’t
want full power. (Press POWER LEVEL.
Select a desired power level 1–10.)
Press START.
You may open the door during Time Cook
to check the food. Close the door and press
START to resume cooking.
Time Cook II
Lets you change power levels automatically
during cooking. Here’s how to do it:
Press TIME COOK.
Enter the first cook time.
Change the power level if you don’t
want full power. (Press POWER LEVEL.
Select a desired power level 1–10.)
Press TIME COOK again.
Enter the second cook time.
Change the power level if you don’t
want full power. (Press POWER LEVEL.
Select a desired power level 1–10.)
Press START.
At the end of Time Cook I, Time Cook II
counts down.
7
6
5
4
3
2
1
4
3
2
1
9
Vegetable Amount Time Comments
Asparagus
(fresh spears) 1 lb. 5 to 8 min., In 1
1
⁄
2
-qt. casserole, place 1/4 cup water.
Med-High (7)
(frozen spears) 10-oz. package 4 to 7 min. In 1-qt. casserole.
Beans
(fresh green) 1 lb. cut in half 10 to 14 min. In 1
1
⁄
2
-qt. casserole, place 1/2 cup water.
(frozen green) 10-oz. package 4 to 8 min. In 1-qt. casserole, place 2 tablespoons water.
(frozen lima) 10-oz. package 4 to 8 min. In 1-qt. casserole, place 1/4 cup water.
Beets
(fresh, whole) 1 bunch 16 to 21 min. In 2-qt. casserole, place 1/2 cup water.
Broccoli
(fresh cut) 1 bunch (1
1
⁄
4
to 1
1
⁄
2
lbs.) 5 to 9 min. In 2-qt. casserole, place 1/2 cup water.
(fresh spears) 1 bunch (1
1
⁄
4
to 1
1
⁄
2
lbs.) 7 to 10 min. In 2-qt. casserole, place 1/4 cup water.
(
frozen,
chopped) 10-oz. package 4 to 7 min. In 1-qt. casserole.
(frozen spears) 10-oz. package 4 to 7 min. In 1-qt. casserole, place 3 tablespoons water.
Cabbage
(fresh) 1 medium head (about 2 lbs.) 6 to 9 min. In 1
1
⁄
2
- or 2-qt. casserole, place 1/4 cup water.
(wedges) 5 to 9 min. In 2- or 3-qt. casserole, place 1/4 cup water.
Carrots
(fresh, sliced) 1 lb. 4 to 8 min. In 1
1
⁄
2
-qt. casserole, place 1/4 cup water.
(frozen) 10-oz. package 3 to 7 min. In 1-qt. casserole, place 2 tablespoons water.
Cauliflower
(flowerets) 1 medium head 7 to 10 min. In 2-qt. casserole, place 1/2 cup water.
(fresh, whole) 1 medium head 7 to 14 min. In 2-qt. casserole, place 1/2 cup water.
(frozen) 10-oz. package 3 to 7 min. In 1-qt. casserole, place 2 tablespoons water.
Corn
(frozen kernel) 10-oz. package 2 to 6 min. In 1-qt. casserole, place 2 tablespoons water.
Corn on the cob
(fresh) 1 to 5 ears 11
/4to 4 min. In 2-qt. glass baking dish, place corn. If corn is in
per ear husk, use no water; if corn has been husked, add
1/4 cup water. Rearrange after half of time.
(frozen) 1 ear 3 to 6 min. Place in 2-qt. oblong glass baking dish.
2 to 6 ears 2 to 3 min. Cover with vented plastic wrap. Rearrange after
per ear half of time.
Mixed vegetables
(frozen) 10-oz. package 2 to 6 min. In 1-qt. casserole, place 3 tablespoons water.
Peas
(fresh, shelled) 2 lbs. unshelled 7 to 9 min. In 1-qt. casserole, place 1/4 cup water.
(frozen) 10-oz. package 2 to 6 min. In 1-qt. casserole, place 2 tablespoons water.
Potatoes
(fresh, cubed, white) 4 potatoes (6 to 8 oz. each) 9 to 11 min. Peel and cut into 1-inch cubes. Place in 2-qt.
casserole with 1/2 cup water. Stir after half of time.
(fresh, whole, sweet 1 (6 to 8 oz.) 2 to 4 min. Pierce with cooking fork. Place in the oven, 1″
or white) apart, in circular arrangement. Let stand 5 minutes.
Spinach
(fresh) 10 to 16 oz. 3 to 6 min. In 2-qt. casserole, place washed spinach.
(frozen, chopped and leaf)
10-oz. package 3 to 6 min. In 1-qt. casserole, place 3 tablespoons water.
Squash
(fresh, summer, and yellow)
1 lb. sliced 3 to 5 min. In 11⁄2-qt. casserole, place 1/4 cup water.
(winter, acorn or butternut)
1 to 2 squash
(about 1 lb. each)
5 to 9 min. Cut in half and remove fibrous membranes. In
2-qt. glass baking dish, place squash cut-side-down.
Turn cut-side-up after 4 minutes.
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
About the time features.
10
Cooking Guide for Time Cook
NOTE: Use ¤¤Ä¤Ä ¤Ä¤Ä¤Ä Ä¤Ä¤Ä ¤¤Ä¤Ç¤Ä¤Ç ¤Älevel 10¤ unless otherwise noted.
Food Time Comments
Breads, Cakes
Bread, buns or rolls (1 piece) 1/4 min.
Sweet rolls (approx. 12 oz.) 2 to 4 min. Rearrange after half the time.
Fish and Seafood
Fillets, frozen (1 lb.) 6 to 9 min.
Shellfish, small pieces
(1 lb.)
3 to 7 min. Place block in casserole. Turn over and break up after half the time.
Fruit
Plastic pouch—1 or 2 1 to 5 min.
(10-oz. package)
Meat
Bacon (1 lb.) 2 to 5 min. Place unopened package in oven. Let stand 5 minutes after defrosting.
Franks (1 lb.) 2 to 5 min. Place unopened package in oven. Microwave just until franks can be separated.
Let stand 5 minutes, if necessary, to complete defrosting.
Ground meat (1 lb.) 4 to 6 min. Turn meat over after first half of time.
Roast: beef, lamb, veal, pork
9 to 12 min.
Use power level 1.
per lb.
Steaks, chops and cutlets 4 to 8 min. Place unwrapped meat in cooking dish. Turn over after first half of time and shield
per lb. warm areas with foil. After second half of time, separate pieces with table knife.
Let stand to complete defrosting.
Poultry
Chicken, broiler-fryer, cut up
14 to 19 min.
Place wrapped chicken in dish. Unwrap and turn over after first half of time. After
(21⁄2to 3 lbs.)
second half of time, separate pieces and place in cooking dish. Microwave 2 to 4
minutes more, if necessary. Let stand a few minutes to finish defrosting.
Chicken, whole (21⁄2to 3 lbs.)
20 to 24 min.
Place wrapped chicken in dish. After half the time, unwrap and turn chicken over.
Shield warm areas with foil. To complete defrosting, run cold water in the cavity
until giblets can be removed.
Cornish hen 7 to 12 min. Place unwrapped hen in the oven breast-side-up. Turn over after first half of time.
per lb. Run cool water in the cavity until giblets can be removed.
Turkey breast (4 to 6 lbs.) 3 to 8 min. Place unwrapped breast in microwave-safe dish breast-side-down. After first half
per lb. of time, turn breast-side-up and shield warm areas with foil. Defrost for second
half of time. Let stand 1 to 2 hours in refrigerator to complete defrosting.
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
11
Defrosting Guide
Time Defrost
Allows you to defrost for a selected length
of time. See the Defrosting Guide for
suggested times. (Auto Defrost explained
in the About the auto feature section.)
Press TIME DEFROST.
Enter defrosting time.
Press START.
When the oven signals, turn food over and
break apart or rearrange pieces for more
even defrosting. Shield any warm areas with
small pieces of foil. The oven will continue
to defrost if you don’t open the door and
turn the food.
A dull thumping noise may be heard
during defrosting. This is normal when
oven is not operating at High power.
Defrosting Tips
■
Foods frozen in paper or plastic can be
defrosted in the package. Closed packages
should be slit, pierced or vented AFTER
food has partially defrosted. Plastic storage
containers should be partially uncovered.
■Family-size, prepackaged frozen dinners
can be defrosted and microwaved. If the
food is in a foil container, transfer it to a
microwave-safe dish.
■Foods that spoil easily should not be
allowed to sit out for more than one hour
after defrosting. Room temperature
promotes the growth of harmful bacteria.
■For more even defrosting of larger foods,
such as roasts, use Auto Defrost. Be sure
large meats are completely defrosted
before cooking.
■When defrosted, food should be cool
but softened in all areas. If still slightly icy,
return to the microwave oven very briefly,
or let it stand a few minutes.
3
2
1
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
About the time features.
12
Express Cook
This is a quick way to set cooking time for
1–6 minutes.
Press one of the Express Cook pads (from
1 to 6) for 1 to 6 minutes of cooking at
power level 10. For example, press the
2pad for 2 minutes of cooking time.
About the auto features.
Auto Defrost
Use Auto Defrost for meat, poultry and
fish. Use Time Defrost for most other frozen
foods.
Auto Defrost automatically sets the
defrosting times and power levels to give
even defrosting results for meats, poultry
and fish weighing up to 6-1/2 pounds.
Press AUTO DEFROST.
Using the Conversion Guide below,
enter food weight. For example,
press pads 1and 2for 1.2 pounds
(1 pound, 3 ounces).
Press START.
(Time Defrost is explained in the About the
time features section.)
There is a handy guide located on the inside
front of the oven.
■Remove meat from package and place
on microwave-safe dish.
■When the oven signals, turn the food
over. Remove defrosted meat or shield
warm areas with small pieces of foil.
■After defrosting, most meats need to
stand 5 minutes to complete defrosting.
Large roasts should stand for about
30 minutes.
3
2
1
Add 30 Seconds
You can use this feature two ways:
■It will add 30 seconds to the time
counting down each time the pad
is pressed.
■It can be used as an express cook for
30 seconds.
Conversion Guide
If the weight of food is stated in pounds and ounces, the ounces must be converted
to tenths (.1) of a pound.
Weight of Food in Ounces Enter Food Weight (tenths of a pound)
1–2 .1
3.2
4–5 .3
6–7 .4
8.5
9–10 .6
11 .7
12–13 .8
14–15 .9
Guide
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
13
Humidity Sensor
The Sensor Features detect the increasing humidity released during cooking. The oven
automatically adjusts the cooking time to various types and amounts of food.
■The proper containers and covers are essential for best sensor cooking.
■Always use microwave-safe containers and cover them with lids or vented plastic wrap.
Never use tight sealing plastic containers—they can prevent steam from escaping and
cause food to overcook.
■Be sure the outside of the cooking containers and the inside of the microwave oven are
dry before placing food in the oven. Beads of moisture turning into steam can mislead
the sensor.
Dry off dishes so they don’t mislead
the sensor.
Vented
Covered
About the sensor features.
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
About the sensor features.
14
Popcorn
To use the Popcorn feature:
Follow package instructions, using
Time Cook if the package is less than
1.75 ounces or larger than 3.5 ounces.
Place the package of popcorn in the
center of the microwave.
Press POPCORN. The oven starts
immediately.
If you open the door while POPCORN
is displayed, a SENSOR ERROR message will
appear. Close the door and press START
immediately.
2
1
Use only with prepackaged
microwave popcorn weighing
1.75 to 3.5 ounces.
Beverage
Press Beverage to heat an 8–10 oz. cup of
coffee or other beverage.
Drinks heated with the Beverage feature may
be very hot. Remove the container with care.
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
15
Reheat
The Reheat feature reheats ¤ ¤¤
of previously cooked foods or a plate of
leftovers.
Place covered food in the oven. Press
REHEAT. The oven starts immediately.
The oven signals when steam is sensed
and the time remaining begins
counting down.
Do not open the oven door until time is
counting down. If the door is opened,
close it and press START immediately.
After removing food from the oven, stir, if
possible, to even out the temperature. If the
food is not hot enough, use Time Cook to
reheat for more time. Reheated foods may
have wide variations in temperature. Some
areas may be extremely hot.
Some Foods Not Recommended for Use
With Reheat
It is best to use Time Cook for these foods:
■Bread products.
■Foods that must be reheated uncovered.
■Foods that need to be stirred or rotated.
■Foods calling for a dry look or crisp
surface after reheating.
2
1
Sensor Cooking
Vegetables, Potatoes, Fish, Chicken Pieces
Sensor cooking gives you easy, automatic
results with a variety of foods (see the
Cooking Guide below).
Place covered food in the oven.
Press the food pad. For vegetables,
press the VEGETABLE pad once for
fresh vegetables, twice for frozen
vegetables or three times for canned
vegetables. For chicken or fish, press
the CHICKEN/FISH pad once for chicken
pieces or twice for fish. The oven starts
immediately.
The oven signals when steam is
sensed and the time remaining begins
counting down. Turn or stir the food
if necessary.
Do not open the oven door until time is
counting down. If the door is opened,
close it and press START immediately.
NOTE: If food is not done enough,
use Time Cook to cook for more time.
2
1
Cooking Guide
Canned Vegetables 4–16 oz Cover with lid or vented plastic wrap.
Frozen Vegetables 4–16 oz Follow package instructions for adding
water. Cover with lid or vented plastic wrap.
Fresh Vegetables 4–16 oz Add 1/4 cup water per serving.
Cover with lid or vented plastic wrap.
Potatoes 8–32 oz Pierce skin with fork. Place potatoes
on the turntable.
Fish 4–16 oz Cover with vented plastic wrap.
Chicken Pieces 2–8 pieces Cover with vented plastic wrap.
Food Type Amount Comments
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
About the other features.
16
Help
The HELP pad displays feature information
and helpful hints. Press HELP, then select a
feature pad.
Reminder
The Reminder feature can be used like an
alarm clock, and can be used at any time,
even when the oven is operating. The
Reminder time can be set up to 24 hours
later.
Press REMINDER.
Enter the time you want the oven to
remind you. (Be sure the microwave
clock shows the correct time of day.)
Select AM or PM.
Press REMINDER. When Reminder signal
occurs, press REMINDER to turn it off.
The Reminder time may be displayed
by pressing REMINDER.
NOTE: RM will be displayed to show that the
Reminder is set. To clear the Reminder before it
occurs, press REMINDER, then 0. RM will no
longer be displayed.
4
3
2
1
Scroll Speed
The scroll speed of the display can be
changed. Press and hold the AM/PM pad
about 3 seconds to bring up the display.
Select 1–5 for slow to fast scroll speed.
Delay Start
Delay Start allows you to set the microwave
to delay cooking up to 24 hours.
Press DELAY START.
Enter the time you want the oven to
start. (Be sure the microwave clock
shows the correct time of day.)
Select AM or PM.
Select any combination of Auto Defrost,
Time Defrost and Time Cook.
Press START.
The Delay Start time will be displayed plus
DS. The oven will automatically start at the
delayed time. To cancel the Delay Start
time, press DELAY START.
The time of day may be displayed by
pressing CLOCK.
5
4
3
2
1
Timer On/Off
Timer On/Off operates as a minute timer
and can be used at any time, even when
the oven is operating.
Press TIMER ON/OFF.
Enter the time you want
to count down.
Press TIMER ON/OFF to start.
When the time is up, the oven will signal.
To turn off the timer signal, press TIMER
ON/OFF.
NOTE: The timer indicator will be lit while the
timer is operating.
3
2
1
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
Clock
Press to enter the time of day.
Press CLOCK.
Enter the time of day.
Select AM or PM.
Press CLOCK.
To check the time of day while
microwaving, press CLOCK.
4
3
2
1
Child Lock-Out
You may lock the control panel to prevent
the microwave from being accidentally
started or used by children.
To lock or unlock the controls, press and
hold CLEAR/OFF for about three seconds.
When the control panel is locked, Lwill
appear in the display.
Start/Pause
In addition to clearing sections,
START/PAUSE allows you to stop cooking
without opening the door or clearing
the display.
17
Display On/Off
To turn the clock display on or off, press
and hold 0for about 3 seconds. The
Display On/Off feature cannot be used while
a cooking feature is in use.
Beeper Volume
The beeper sound level can be adjusted.
Press BEEPER VOLUME. Choose 0–3 for
mute to loud.
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
About the other features.
18
Microwave terms.
Arcing Arcing is the microwave term for sparks in the oven. Arcing is caused by:
■metal or foil touching the side of the oven.
■foil that is not molded to food (upturned edges act like antennas).
■metal such as twist-ties, poultry pins, gold-rimmed dishes.
■recycled paper towels containing small metal pieces.
Covering Covers hold in moisture, allow for more even heating and reduce cooking time. Venting plastic wrap or
covering with wax paper allows excess steam to escape.
Shielding In a regular oven, you shield chicken breasts or baked foods to prevent over-browning. When microwaving,
you use small strips of foil to shield thin parts, such as the tips of wings and legs on poultry, which would
cook before larger parts.
Standing Time When you cook with regular ovens, foods such as roasts or cakes are allowed to stand to finish cooking or
to set. Standing time is especially important in microwave cooking. Note that a microwaved cake is not
placed on a cooling rack.
Venting After covering a dish with plastic wrap, you vent the plastic wrap by turning back one corner so excess
steam can escape.
Term Definition
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
19
Care and cleaning of the microwave oven.
Helpful Hints
An occasional thorough wiping with a solution of baking soda and water keeps
the inside fresh.
Unplug the cord before cleaning any part of this oven.
How to Clean the Inside
Walls, Floor, Inside Window, Metal and Plastic Parts on the Door
Some spatters can be removed with a paper towel; others may require a damp cloth.
Remove greasy spatters with a sudsy cloth, then rinse with a damp cloth. Do not use
abrasive cleaners or sharp utensils on oven walls.
To clean the surface of the door and the surface of the oven that come together upon
closing, use only mild, nonabrasive soaps or detergents using a sponge or soft cloth.
Rinse with a damp cloth and dry.
Never use a commercial oven cleaner on any part of your microwave oven.
Removable Turntable and Turntable Support
To prevent breakage, do not place the turntable into water just after cooking. Wash it
carefully in warm, sudsy water or in the dishwasher. The turntable and support can be
broken if dropped. Remember, do not operate the oven without the turntable and
support in place.
How to Clean the Outside
Do not use cleaners containing ammonia or alcohol on the microwave oven. Ammonia or
alcohol can damage the appearance of the microwave oven.
Case
Clean the outside of the microwave oven with a sudsy cloth. Rinse with a damp cloth and
then dry. Wipe the window clean with a damp cloth.
Control Panel and Door
Wipe with a damp cloth. Dry thoroughly. Do not use cleaning sprays, large amounts of
soap and water, abrasives or sharp objects on the panel—they can damage it. Some paper
towels can also scratch the control panel.
Door Surface
It is important to keep the area clean where the door seals against the microwave oven.
Use only mild, non-abrasive detergents applied with a clean sponge or soft cloth. Rinse
well.
Power Cord
If the cord becomes soiled, unplug and wash with a damp cloth. For stubborn spots, sudsy
water may be used, but be certain to rinse with a damp cloth and dry thoroughly before
plugging cord into outlet.
20
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
Before you call for service…
Troubleshooting Tips
Save time and money! Review the chart below and you
may not need to call for service.
Problem Possible Causes What To Do
Oven will not start A fuse in your home may be blown •Replace fuse or reset circuit breaker.
or the circuit breaker tripped.
Power surge. •Unplug the microwave oven, then plug it back in.
Plug not fully inserted into wall •Make sure the 3-prong plug on the oven is fully
outlet. inserted into wall outlet.
Door not securely closed. •Open the door and close securely.
Control panel lighted, yet Door not securely closed. •Open the door and close securely.
oven will not start
START pad not pressed after •Press START.
entering cooking selection.
Another selection entered •Press CLEAR/OFF.
already in oven and CLEAR/OFF
pad not pressed to cancel it.
Cooking time not entered after •Make sure you have entered cooking time after
pressing TIME COOK. pressing TIME COOK.
START/PAUSE was pressed accidentally. •Reset cooking program and press START.
Food weight not entered after •Make sure you have entered food weight after
selecting AUTO DEFROST. selecting AUTO DEFROST.
SENSOR ERROR message During the Sensor cooking •Close the door and press START immediately.
appears on display program, the door was opened
before steam could be detected.
Steam was not detected in •Use Time Cook to heat for more time.
maximum amount of time.
Control panel does The control has been locked. •Press and hold CLEAR/OFF for about three
not work (When the control panel is locked, seconds to unlock the control.
an Lwill be displayed.)
Food amount too large Sensor Reheat is for single •Use Time Cook for large amounts of food.
for Sensor Reheat servings of recommended foods.
Things That Are Normal With Your Microwave Oven
■Steam or vapor escaping from around
the door.
■Light reflection around door or outer case.
■Dimming oven light and change in
the blower sound at power levels other
than high.
■Dull thumping sound while oven is
operating.
■TV/radio interference might be noticed
while using the microwave. Similar to the
interference caused by other small
appliances, it does not indicate a problem
with the microwave. Plug the microwave
into a different electrical circuit, move the
radio or TVas far away from the microwave
as possible or check the position and signal
of the TV/radio antenna.
