Dongbu Daewoo Electronics Corporation MICROWAVE OVEN
User Manual
Before operating this oven, please read these instructions completely.
OPERATING
INSTRUCTIONS
MICROWAVE OVEN
KOR-63CS
1
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper with the
safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damaged to the: (1) door (bent), (2) hinges and latches(broken or
loosened), (3) door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified service.
• IMPORTANT SAFETY INSTRUCTIONS.
• READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. ............................................................................2
• FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT ...........3
• GROUNDING INSTRUCTIONS...............................................................................................................................3
• INSTALLATION ........................................................................................................................................................4
• FEATURES DIAGRAM.............................................................................................................................................5
• FEATURES DIAGRAM (CONTINUED) ...................................................................................................................6
• OPERATION PROCEDURE ....................................................................................................................................7
• CONTROLS..............................................................................................................................................................8
SENSOR COOK.......................................................................................................................................................8
AUTO DEFROST......................................................................................................................................................9
TIME DEFROST.....................................................................................................................................................10
TIME COOK ...........................................................................................................................................................11
KITCHEN TIMER ...................................................................................................................................................12
SPEEDY COOK .....................................................................................................................................................13
MINUTE PLUS .......................................................................................................................................................14
CLOCK ...................................................................................................................................................................14
HELP ......................................................................................................................................................................15
NIGHT LIGHT ........................................................................................................................................................16
TO STOP THE OVEN WHILE THE OVEN IS OPERATING ................................................................................16
• CARE OF YOUR MICROWAVE OVEN.................................................................................................................17
• QUESTIONS AND ANSWERS ..............................................................................................................................18
• BEFORE YOU CALL FOR SERVICE ....................................................................................................................19
• CARE AND CLEANING .........................................................................................................................................19
• SPECIFICATIONS..................................................................................................................................................19
• COOKING INSTRUCTIONS ..................................................................................................................................20
• USE YOUR MICROWAVE OVEN SAFELY ..........................................................................................................21
• ARCING..................................................................................................................................................................21
• MICROWAVING PRINCIPLES ..............................................................................................................................22
• HOW MICROWAVES COOK FOOD .....................................................................................................................22
• CONVERSION CHARTS .......................................................................................................................................22
• COOKING TECHNIQUES......................................................................................................................................23
• DEFROSTING GUIDE............................................................................................................................................24
• COOKING & REHEATING CHART .......................................................................................................................25
• VEGETABLE CHART.............................................................................................................................................27
• RECIPES ................................................................................................................................................................28
TABLE OF CONTENTS
2
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive
microwave energy:
11. Read all instructions before using the appliance.
12. Read and follow the specific “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” found on page 1.
13. This appliance must be grounded. Connect only to
properly grounded outlet. See “GROUNDING
INSTRUCTIONS” found on page 3.
14. Install or locate this appliance only in accordance with the
provided installation instructions.
15. Some products such as whole eggs and sealed
containers - for example, closed glass jars-are able to
explode and should not be heated in this oven.
16. Use this appliance only for its intended use as described
in this manual. Do not use corrosive chemicals or vapors
in this appliance. This type of oven is specifically
designed to heat, cook, or dry food. It is not designed for
industrial or laboratory use.
17. Only allow children to use the oven without supervision
when adequate instructions have been given so that the
child is able to use the oven in a safe way and
understands the hazards of improper use.
18. Do not operate this appliance if it has a damaged cord or
plug, if it is not working properly, or if it has been
damaged or dropped.
19. This appliance should be serviced only by qualified
service personnel.
Contact nearest authorized service facility for
examination, repair or adjustment.
10. Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this
product near water — for example, near a kitchen sink, in
a wet basement, near a swimming pool, or similar
locations.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not let cord hang over edge of table or counter.
15. Either:
a) When cleaning surfaces of door and oven that comes
together on closing the door, use only mild, non-
abrasive soaps or detergents applied with a sponge or
soft cloth . or
b) When separate cleaning instructions are provided, See
door surface cleaning instructions on.
16. To reduce the risk of fire in the oven cavity:
a) Do not overcook food. Carefully attend appliance when
paper, plastic, or other combustible materials are
placed inside the oven to facilitate cooking.
b) Remove wire twist-ties from paper or plastic bags
before placing bag in oven.
c) If materials inside the oven ignite, keep oven door
closed, turn oven off, and disconnect the power cord,
or shut off power at the fuse or circuit breaker panel.
d) Do not use the cavity for storage purposes. Do not
leave paper products, cooking utensils, or food in the
cavity when not in use.
17. Do not use this microwave oven to heat corrosive
chemicals (for example, sulfides and chlorides). Vapours
from such corrosive chemicals may interact with the
contact and springs of the safety interlock switches
thereby rendering them inoperable.
18. Keep the waveguide cover clean at all times.
Wipe the oven interior with a soft damp cloth after each
use. If you leave grease or fat anywhere in the cavity it
may overheat, smoke or even catch fire when next using
the oven.
19. Never heat oil or fat for deep frying as you cannot control
the temperature and doing so may lead to overheating
and fire.
20. Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing to
be boiling due to surface tension of the liquid. Visible
bubbling or boiling when the container is removed from
the microwave oven is not always present. THIS COULD
RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING
OVER WHEN A SPOON OR OTHER UTENSIL IS
INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
a) Do not overheat the liquid.
b) Stir the liquid both before and halfway through heating
it
c) Do not use straight-sided containers with narrow
necks.
d) After heating, allow the container to stand in the
microwave oven for a short time before removing the
container.
e) Use extreme care when inserting a spoon or other
utensil into the container.
21. Do not operate the oven without the glass tray in place. Be
sure it is properly sitting on the rotating base.
SAVE THESE INSTRUCTIONS
3
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, the grounding plug reduces
the risk of electric shock by providing an escape wire for electric current. This appliance is equipped
with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that
is properly installed and grounded.
WARNING:
This equipment generates and uses ISM frequency energy and if not installed and used
properly, that is in strict accordance with the manufacturer's instructions, may cause
interference to radio and television reception.
It has been type-tested and found to comply with limits for an ISM Equipment pursuant to part
18 of FCC Rules, which are designed to provide reasonable protection against such
interference in a residential installation.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the followings.
• Reorient the receiving antenna of radio or television.
• Relocate the Microwave oven with respect to the receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so that microwave oven and receiver are
on different branch circuits.
THE MANUFACTURER is not responsible for any radio or TV interference caused by
UNAUTHORIZED MODIFICATION to this microwave oven. It is the responsibility of the user to
correct such interference.
WARNING:
Improper use of the grounding can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not completely
understood, or if doubt exists as to whether the appliance is properly grounded, and either :
(1) If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade
grounding plug, and a 3-slot receptacle that will accept the plug on the appliance. The marked
rating of the extension cord shall be equal to or greater than the electrical rating of the
appliance. or
(2) Do not use an extension cord, if the power supply cord is too short, have a qualified electrician
or serviceman install an outlet near the appliance.
(3) Do not cut or remove the third (ground) prong from the power cord under any circumstances.
4
INSTALLATION
1. Examine the oven after unpacking.
Check for damage such as a misaligned door, broken door or dent in the cavity.
If any damage is visible, DO NOT INSTALL, and notify your dealer immediately.
2. Level, flat location.
Install the microwave oven on a level, flat surface.
3. Ventilation.
Do not block air vents. If they are blocked during operation, the oven may overheat and eventually
cause a failure.
For proper ventilation, allow 3 inches of space between oven top, sides, rear and adjacent surfaces.
4. Away from radio and TV sets.
Poor television reception and radio interference may result if the oven is located close to a TV, radio,
antenna, feeder, etc.
Place the oven as far from them as possible.
5. Away from heating appliances and water taps.
Keep the oven away from heat, steam or splashing liquids. These things can adversely affect oven
wiring and contacts.
6. Power supply.
This microwave oven requires a power supply of approximately 20 Amperes, 120 Volts, 60Hz
and a grounded outlet. A short power cord is provided to reduce the risk of the user becoming
entangled in or tripping over a longer cord. Longer cord sets or extension cords are available
and may be used if care is exercised in their use.
If an extension cord is used, the marked electrical rating of the cord should be at least as great
as the electrical rating of the oven.
The extension cord must be a grounding-type 3-wire cord. The longer cord should be arranged
so that it will not drape over the table top or counter where it can be pulled on by children or tripped
over unintentionally.
7. The minimum height of free space necessary above the top surface of the oven is 100mm.
When use 3-pronged plug
3-prong Receptacle
Receptacle
Box cover
3-prong plug
When use grounding adaptor, make sure
the receptacle box is fully grounded.
Receptacle Box Cover
Receptacle
Grounding
Lead
Grounding
Adaptor
“THE CANADIAN ELECTRICAL CODE DOES NOT ALLOW THE USE OF THE GROUNDING ADAPTOR”
5
1. Door latch-When the door is closed it will
automatically shut off. If the door is opened
while the oven is operating, the magnetron
will automatically shut off.
2. Door seal-The door seal maintains the
microwave within the oven cavity and
prevents microwave leakage.
3. Oven cavity
4. Spatter shield-Protects the microwave
outlet from splashes of cooking foods.
5. Safety interlock system-Prevents the oven
from operating while the door is opened.
The oven will only operate with the door fully
closed. When the door is open, the oven turns
off and will only start again after the door is
closed.
6. Door release button-Pushing this button
stops oven operation and opens the door.
7. Glass cooking tray-Made of special heat
resistant glass. The tray must always be
in proper position before operating.
Do not cook food directly on the tray.
8. Roller guide-Supports the glass cooking tray.
9. Door screen-Allows viewing of food.
The screen is designed so that light
can pass through, but not the microwaves.
FEATURES DIAGRAM
2
9
1
6
5437
8
6
FEATURES DIAGRAM (continued)
4
6
5
q
9
8
2
3
e
0
1
7
w
1Time set pad - Used to set the cooking
time and the present time.
2Display - Cooking time, power level,
indicators and present time are displayed.
3Sensor cook - Used to automatically
compute the microwave power and
cooking time for foods.
4Help - Used to help you to operate the
oven easily.
5Time DEF. - Used to defrost food. (for
time)
6Auto DEF. - Used to defrost food.(for
weight)
7Minute plus - Used to cook at 100% or to
increase the cooking time by simply
touching the pad.
8Clock - Used to set clock.
9Power - Used to set power level/Used to
increase (or decrease) the cooking time for
Sensor cooking.
0Kitchen timer - Used as a minute timer, to
delay the start of cooking, or to set a
holding time after cooking.
qStop/Clear - Used to stop the oven
operation or to erase all entries.
wStart /Speedy cook - Used to start the
oven operation/used to increase the reheat
time by 30 seconds.
eNight Light - Used to turn ON/OFF the
Night Light.
7
WATTAGE OUTPUT CHART
• The power - level is set by touching the POWER pad. The chart shows the display, the power level and
the percentage of power.
OPERATION PROCEDURE
This section includes useful information about oven operation.
1. Plug power supply cord into a standard 3 - pronged 20 Amp, 120V AC 60Hz power outlet.
2. After placing the food in a suitable container, open the oven door and put it on the glass tray.
2. The glass tray and roller guide must always be in place during cooking.
3. Shut the door. Make sure that it is firmly closed.
1
The oven light is on only when the micro-
wave oven is operating.
2
The oven door can be opened at any time
during operation by pushing the door release
button on the control panel. The oven will
automatically shut off.
3
Each time a pad is touched, a BEEP will
sound to acknowledge the touch.
4
The oven automatically cooks on full power
unless set to a lower power level.
5
The display will show “ HAVE A NICE
COOKING TIME PRESS CLEAR ” when the
oven is plugged in.
6
Time clock returns to the present time when
the cooking time ends.
7
When the STOP/CLEAR pad is touched
during the oven operation, the oven stops
cooking and all information retained.
To erase all information (except the present
time), touch the STOP/CLEAR pad once
more. If the oven door is opened during the
oven operation, all information is retained.
8
If the START pad is touched and the oven
does not operate, check the area between
the door and door seal for obstructions and
make sure the door is closed securely.
The oven will not start cooking until the door
is comletely closed or the program has been
reset.
Make sure the oven is properly installed and
plugged into the electrical outlet.
Touch POWER pad Power level (Display) Approximate Percentage
of Power
once HIGH 100%
twice PL-9 90%
3 times PL-8 80%
4 times PL-7 70%
5 times PL-6 60%
6 times PL-5 50%
7 times PL-4 40%
8 times PL-3 30%
9 times PL-2 20%
10 times PL-1 10%
11 times PL-0 0%
8
CONTROLS
SENSOR COOK
Sensor is a semi-conductor device that detects the vapor (moisture and humidity) emitted from the food
as it heats. The sensor adjusts the cooking time and power level for various foods and quantities and you
don’t need to enter the weight or quantity of the food. Follow the steps below for easy sensor cooking.
1. Touch REHEAT pad.
(This example shows “REHEAT”
menu and other menus have the
same procedures. Please refer to
the SENSOR COOK CHART
below.)
The SENSOR indicator appears and “REHEAT” is
displayed. After 2 seconds, SENSOR indicator blinks
and the oven starts cooking. When the sensor detects
the vapor emitted from the food, remainder of cooking
time appears with a beep and the display counts down
the remaining time. When the cooking ends, the
SENSOR indicator disappears and you will hear a
beep.
REHEAT
SENSOR COOK CHART
Use only popcom packaged for micro
wave oven use. Try several brands to
decide which you like the best. Do not
try to pop unpopped kernels.
Place in casserole. Cover with lid for
tender vegetables. Use plastic wrap
cover for tender-crisp vegetables. After
cooking, stir, if possible, let stand,
covered, for 2 to 5 minutes.
Pierce. Place on paper-towel-lined
turntable. After cooking, remove from
oven, wrap in aluminum foil and let
stand 5 to 10 minutes.
Place in dish or casserole slightly larg
er than amount to be reheated. Flatte
n, if possible. Cover with lid, plastic w
rapor wax paper. Use covers such as
plastic wrap or lids with larger quantiti
es of more dense foods such as stew
s. After reheating, stir well, if possible.
Foods should be very hot. If not, con
tinue to heat with variable power and
time. After stirring, re-cover and allow
to stand 2 to 3 minute.
Use this pad for frozenconvenience
foods. It will give satisfactory results for
most brands. You may wish to try
several and choose your favorite.
Remove package directions for
covering. After cooking, let stand,
covered, for 1 to 3 minutes.
Arrange in ring around shallow glass
dish (roll fillet with edges underneath).
Cover with plastic wrap. After cooking,
let stand, covered for 3 minutes.
Menu pad Display Amount User Guide Procedure
before
operation in operation (When touching Help pad)
Popcorn “POPCORN” “P-CORN” 1.5-3.5 OZ “WEIGHT RANGE 1.5 TO 3.5 OZ”
Fresh “FRESH “FS-VEG” 0.25-1.5 LB “COVER DISH WITH LID OR
Vegetable VEGETABLE” VENTED PLASTIC WRAP
WEIGHT RANGE 0.25 TO 1.5 LB”
Reheat “REHEAT” “REHEAT” 4-36 OZ “COVER DISH WITH LID OR
VENTED PLASTIC WRAP
WEIGHT RANGE4 TO 36 OZ”
Baked “BAKED “POTATO” 2-5 “RANGE 2 TO 5 POTATO”
Potato POTATO” POTATOES
Frozen “FROZEN “DINNER” 7-12 OZ “COVER DISH WITH LID OR
Dinner DINNER” VENTED PLASTIC WRAP
WEIGHT RANGE 7 TO 12 OZ”
Fish Fillet “FISH “FILLET” 0.25-1.5 LB “COVER DISH WITH LID OR
FILLET” VENTED PLASTIC WRAP
WEIGHT RANGE 0.25 TO 1.5 LB”
9
AUTO DEFROST
AUTO DEFROST lets you easily defrost food by eliminating guess work in determining defrosting time.
Follow the steps below for easy defrosting.
The DEFROST indicator appears and “AUTO
DEFROST 1-GROUND MEAT 2-ROAST 3-
POULTRY 4-FISH SELECT NUMBER” is
displayed in sequence. “NUMBER” blinks three
times.
The displays are as follows and “LB” blinks
three times.
1. Touch AUTO DEF. pad.
2. Touch number pad for the
food you want to defrost.
AUTO
DEF.
3. Touch number pads for weight
within the proper range.
(Please refer to the above
“User Guide”)
4. Touch Start pad.
The selected weight appears and “PRESS
START” is displayed. “START” blinks three
times.
The chosen menu is displayed and the
DEFROST indicator starts blinking to show the
oven is in the defrost mode. Then the display is
changed into cooking time and counts down the
remaining time. When the defrosting time ends,
you will hear a beep.
NOTE: If you enter an incorrect weight out of
range, “RANGE ERROR PRESS
CLEAR” is displayed with a beep
sound.
Auto Defrost menu Display User Guide (When touching Help pad)
1. GROUND MEAT “GROUND MEAT -- ENTER WEIGHT IN LB” “WEIGHT RANGE 0.5 TO 3.0 LB”
2. ROAST “ROAST -- ENTER WEIGHT IN LB” “WEIGHT RANGE 2.0 TO 3.5 LB”
3. POULTRY “POULTRY -- ENTER WEIGHT IN LB” “WEIGHT RANGE 1.0 TO 3.0 LB”
4. FISH “FISH -- ENTER WEIGHT IN LB” “WEIGHT RANGE 0.5 TO 1.5 LB”
* AUTO DEFROST CHART
NOTE: 1. Any sensor cooking selection can be programmed with more or less time adjustment. In case of cooking more
food than the quantity listed in the chart, touch the POWER pad once after touching one of sensor cook menus
and before the oven beginning to start. In case of cooking less food, touch POWER pad twice.
2. If you touch POWER pad during operation, the display shows the present power level and then returns to the
chosen menu.
3. Each menu has a cooking hint. Touch Help pad before the oven starts operating and the display will show the
above mentioned user guides.
4. If “SENSOR PREHEAT ERROR1 PRESS CLEAR” is displayed with a beep sound while you choose the sensor
menu pad, turn off & on the oven and then try to use the oven again after 2 minutes. If there is still this error,
contact the qualified service man.
5. If “SENSOR PRESET ERROR3 PRESS CLEAR” is displayed with a beep sound during operation, turn off & on
the oven and then try to use the oven again after 2 minutes.
10
TIME DEFROST
When TIME DEFROST is selected, the automatic cycle divides the defrosting time into periods of
alternating defrost and stand times by cycling on and off.
1. Touch TIME DEF. pad.
2. Touch number pads for the
desired defrosting time.
3. Touch Start pad.
The DEFROST indicator appears and “TIME
DEFROST--ENTER DEFROST TIME” is
displayed. “TIME” blinks three times.
The selected time appears and “PRESS
START” is displayed. “START” blinks three
times.
“TIME DEFROST” is displayed and the
DEFROST indicator starts blinking to show the
oven is in the defrost mode. Then the display is
changed into cooking time and counts down the
remaining time. When the defrosting time ends,
you will hear a beep.
NOTE:
Your oven can be programmed for 59
minutes 99 seconds. (59:99)
If you try to set an incorrect time over
59 minutes 99 seconds, “RANGE
ERROR PRESS CLEAR” is
displayed with a beep sound.
TIME
DEF.
11
TIME COOK
1. Touch POWER pad.
program the desired power
level. (Please refer to the
wattage output chart in the
page 7.)
2. Touch number pads for the
cooking time.
3. Touch Start pad.
“SELECT POWER LEVEL OR COOKING TIME
DEFAULT POWER LEVEL HIGH” is displayed.
“HIGH” blinks three times.
The selected time appears and “PRESS
START” is displayed. “START” blinks three
times.
The display is changed into cooking time and
counts down the remaining time. When the
cooking time ends, you will hear a beep.
POWER
NOTE: Your oven can be programmed for
59 minutes 99 seconds. (59:99)
If you try to set an incorrect time over
59 minutes 99 seconds, “RANGE
ERROR PRESS CLEAR” is
displayed with a beep sound.
NOTE: 1. Using lower power level increases the cooking time which is recommended for foods such
as cheese, milk and slow cooking of meats.
2. Repeat the above procedures twice for time cook in two stages.
3. If the power pad is touched during operation, the present power level will appear in the
display window.
12
KITCHEN TIMER
1. Touch KITCHEN TIMER pad.
2. Touch number pads for the
time you want to count down.
3. Touch Start pad.
The TIMER indicator appears and “ENTER
TIME” is displayed. “TIME” blinks three times.
The selected time appears and “PRESS
START” is displayed. “START” blinks three
times.
The TIMER indicator starts blinking.
The display is changed into the time in kitchen
timer mode and counts down the remaining
time.
When kitchen timer mode ends, you will hear a
beep.
KITCHEN
TIMER
HOW TO USE AS A MINUTE TIMER
1. Touch KITCHEN TIMER pad.
2. Touch number pads for the
time you want to delay.
3. Touch POWER pad and
program the desired power
level.
4. Touch number pads for the
time to be cooked.
5. Touch Start pad.
The TIMER indicator appears and “ENTER
TIME” is displayed. “TIME” blinks three times.
The selected time appears and “PRESS
START” is displayed. “START” blinks three
times.
“SELECT POWER LEVEL OR COOKING TIME
DEFAULT POWER LEVEL HIGH” is displayed.
“HIGH” blinks three times.
The selected time appears and “PRESS
START” is displayed. “START” blinks three
times.
The Timer indicator starts blinking.
The display is changed into the time in kitchen
timer mode and counts down the remaining
time.
When kitchen timer mode ends, the display
counts down the time in cooking mode. When
the cooking mode ends, you will hear a beep.
KITCHEN
TIMER
HOW TO USE TO DELAY THE START OF COOKING
13
1. Program the desired defrost or
time cook.
2. Touch KITCHEN TIMER pad.
3. Touch number pads for the
time you want to hold.
4. Touch Start pad.
The TIMER indicator appears and “ENTER
STANDING TIME” is displayed. “TIME” blinks
three times.
The selected time appears and “PRESS
START” is displayed. “START” blinks three
times.
The oven is in the defrosting or time cooking
mode and the display is changed into the time in
respective mode. (In defrost mode, DEFROST
indicator blinks.) When the defrost or time cook
mode ends, TIMER indicator starts blinking and
the display counts down the remaining time in
kitchen timer mode. When the mode ends, you
will hear a beep.
KITCHEN
TIMER
HOW TO USE TO SET A HOLDING TIME
NOTE: 1. Your oven can be programmed for 59 minutes 99 seconds. (59:99) If you try to set an
incorrect time over 59 minutes 99 seconds, “RANGE ERROR PRESS CLEAR” is displayed
with a beep sound.
2. The KITCHEN TIMER function has no relation to the clock setting.
3. If the power pad is touched during operation, the present power level will appear in the
display window.
1. Touch SPEEDY COOK pad. If you touch SPEEDY COOK pad once,
“ :30” appears and the oven starts cooking. The
display counts down the cooking time.
When the time ends, you will hear a beep.
START/
SPEEDY COOK
SPEEDY COOK
SPEEDY COOK allows you to cook at 100% (full power) by simply touching SPEEDY COOK pad. By
repeatedly touching SPEEDY COOK pad, you can also extend the cooking time to 5 minutes by 30
seconds.
KITCHEN TIMER (continued)
14
MINUTE PLUS
MINUTE PLUS allows you to cook at 100% or to increase the cooking time during time cooking by simply
touching the Minute Plus pad. Each time Minute Plus pad is touched, the cooking time is extended by 1
minute to a maximum of 59 minutes.
NOTE: 1. If you selected 12 hour clock system, this digital clock allows you to set from 1:00 to 12:59.
If you selected 24 hour clock system, this digital clock allows you to set from 0:00 to 23:59.
2. If you attempt to enter an incorrect time, the time will not be set and an error signal tone will
sound. Touch CLOCK pad and re-enter the correct time.
MINUTE
PLUS
If you touch MINUTE PLUS pad once, “1:00”
appears and the oven starts cooking. The
display counts down the cooking time.
When the time ends, you will hear a beep.
1. Touch MINUTE PLUS pad.
CLOCK
This is a 12 hour clock system.
“12 HOUR MODE--ENTER TIME” is displayed
and “TIME” blinks three times.
The selected time appears and “PRESS
CLOCK” is displayed. “CLOCK” blinks three
times.
The colon starts blinking and the display shows
the present time.
1. Touch CLOCK pad.
2. Enter the correct time of day by
touching the time set pads.
3. Touch CLOCK pad.
NOTE: This oven has multiple clock system.
If you want 24 hour clock system,
use help function and set 24 hour
clock system before this step.
CLOCK
15
HELP
HELP provides 6 features which enable you to use the oven easily.
If “ON” mode is set, the display turns off except during operation.
This oven can be set for three languages - ENGLISH, FRENCH, SPANISH.
ENERGY SAVE
3 LANGUAGE
This function prevents unwanted oven operation such as by small children.
This allows you to choose the weight unit between LB and G.
If “OFF” mode is set, you can operate the oven with no audible signal.
This allows you to choose the clock mode between 12 and 24 hour clock system.
CHILD LOCK
LB, G
BEEP
CLOCK MODE
1. Touch HELP pad.
2. Touch number pad for the
necessary function.
(Please refer to the HELP
FUNCTION CHART below.)
3. Enter the number for the
desired mode.
NOTE: If you touch Help pad after choosing Sensor Cook, the display will show the user guides of
respective foods. If you want to select the above help functions, first of all, touch Help pad and
choose the desired mode.
Help Function Display Default
1. CHILD LOCK “CHILD LOCK 1-ON 2-OFF SELECT NUMBER” OFF
2. LB, G “WEIGHT UNIT 1-LB 2-G SELECT NUMBER” LB
3. BEEP “BEEP 1-ON 2-OFF SELECT NUMBER” ON
4. CLOCK MODE “CLOCK MODE 1-12 HR 2-24 HR SELECT NUMBER” 12 HOUR
5. ENERGY SAVE “ENERGY SAVE 1-ON 2-OFF SELECT NUMBER” OFF
6. 3 LANGUAGE “3 LANGUAGE 1-ENGLISH 2-FRENCH 3-SPANISH SELECT NUMBER” ENGLISH
* HELP FUNCTION CHART
The displays are as shown in the chart below
and “NUMBER” blinks three times.
The HELP indicator appears and “HELP
FUNCTION 1-CHILD LOCK 2-LB, G 3-BEEP 4-
CLOCK MODE 5-ENERGY SAVE 6-3
LANGUAGE SELECT NUMBER” is displayed in
sequence. “NUMBER” blinks three times.
The display shows the chosen mode and returns
to the present time.
HELP
16
TO STOP THE OVEN WHILE THE OVEN IS OPERATING
1. Touch STOP/CLEAR pad.
• You can restart the oven by touching START pad.
• Touch STOP/CLEAR pad once more to erase all instructions.
• You must enter in new instructions.
2. Open the door.
• You can restart the oven by closing the door and touching START pad.
NOTE: Oven stops operating when door is opened.
NIGHT LIGHT
NIGHT
LIGHT
If you touch NIGHT LIGHT pad onec, the night
light turns ON.
If you touch NIGHT LIGHT pad again, the night
lisht turns OFF.
1. Touch NIGHT LIGHT pad.
2. Touch NIGHT LIGHT pad
again.
NOTE: 1. Night light will be automatically off during cooking operation. (except kitchen timer).
2. If you turn on the night light after the clock setting, night light will be automatically off after
10 hour.
17
CARE OF YOUR MICROWAVE OVEN
Turn the oven off before cleaning.
Keep the inside of the oven clean. When food
spatters or spilled liquids adhere to oven
walls, wipe with a damp cloth. Mild detergent
may be used if the oven gets very dirty. The
use of harsh detergent or abrasives is not
recommended.
The outside oven surface should be cleaned
with soap and water, rinsed and dried with a
soft cloth. To prevent damage to the operating
parts inside the oven, water should not be
allowed to seep into the ventilation openings.
If the Control Panel becomes wet, clean with
a soft, dry cloth. Do not use harsh detergents
or abrasives on Control Panel.
If steam accumulates inside or around the
outside of the oven door, wipe with a soft
cloth. This may occur when the microwave
oven is operated under high humidity
conditions and in no way indicates
malfunction of the unit.
It is occasionally necessary to remove the
glass tray for cleaning. Wash the tray in warm
sudsy water or in a dishwasher.
The roller guide and oven cavity floor should
be cleaned regularly to avoid excessive noise.
Simply wipe the bottom surface of the oven
with mild detergent water or window cleaner
and dry. The roller guide may be washed in
mild sudsy water.
1
2
3
4
5
6
7
ROLLER GUIDE
Glass Tray Roller Guide
The ROLLER GUIDE and oven floor should
be cleaned frequently to prevent excessive
noise.
The ROLLER GUIDE MUST ALWAYS be
used for cooking together with the Glass Tray.
1
2
GLASS TRAY
DO NOT operate the oven without the Glass Tray
in place.
DO NOT use any other Glass Tray with this oven.
If Glass Tray is hot, ALLOW TO COOL before
cleaning or placing it in water.
DO NOT cook directly on the Glass Tray.
(Except for popcorn)
1
2
3
4
18
* Q :I accidentally ran my microwave oven
without any food in it. Is it damaged?
* A : Running the oven empty for a short time will
not damage the oven. However, it is not
recommended.
* Q :Can the oven be used with the glass tray
or roller guide removed?
* A : No. Both the glass tray and roller guide must
always be used in the oven before cooking.
* Q :Can I open the door when the oven is
operating?
* A : The door can be opened anytime during the
cooking operation. Then microwave energy
will be instantly switched off and the time
setting will maintain until the door is closed.
* Q :Why do I have moisture in my microwave
oven after cooking?
* A : The moisture on the side of your microwave
oven is normal. It is caused by steam from
cooking food hitting the cool oven surface.
* Q :Does microwave energy pass through
the viewing screen in the door?
* A : No. The metal screen bounces back the
energy to the oven cavity. The holes are
made to allow light to pass through. They do
not let microwave energy pass through.
* Q : Why do eggs sometimes pop?
* A : When baking or poaching eggs, the yolk
may pop due to steam build-up inside the
yolk membrane. To prevent this, simply
pierce the yolk with a toothpick before
cooking. Never cook eggs without piercing
their shells.
* Q : Why this standing time recommended
after the cooking operation has been
completed?
* A : Standing time is very important.
With microwave cooking, the heat is in the
food, not in the oven. Many foods build up
enough internal heat to allow the cooking
process to continue, even after the food is
removed from the oven. Standing time for
joints of meat, large vegetables and cakes is
to allow the inside to cook completely,
without overcooking the outside.
* Q :What does “standing time” mean?
* A : “Standing time” means that food should be
removed from the oven and covered for
additional time to allow it to finish cooking.
This frees the oven for other cooking.
* Q : Why does my oven not always cook as
fast as the microwave cooking guide
says?
* A : Check your cooking guide again, to make
sure you’ve followed directions exactly ; and
to see what might cause variations in
cooking time. Cooking guide times and heat
settings are suggestions, to help prevent
over-cooking... the most common problem in
getting used to a microwave oven.
Variations in the size, shape and weights
and dimensions could require longer cooking
time. Use your own judgement along with
the cooking guide suggestions to check
whether the food has been properly cooked
just as you would do with a conventional
cooker.
* Q : Will the microwave oven be damaged if it
operates while empty?
* A : Yes. Never run it empty.
* Q : Can I operate my microwave oven
without the turntable or turn the turntable
over to hold a large dish?
* A : No. If you remove or turn over the turntable,
you will get poor cooking results. Dishes
used in your oven must fit on the turntable.
* Q : Is it normal for the turntable to turn in
either direction?
* A : Yes. The turntable rotates clockwise or
counterclockwise, depending on the rotation
of the motor when the cooking cycle begins.
* Q : Can I pop popcorn in my microwave
oven? How do I get the best results?
* A : Yes. Pop packaged microwave popcorn
following manufacture’s guidelines. Do not
use regular paper bags. Use the “listening
test” by stopping the oven as soon as the
popping slows to a “pop” every 1 or 2
seconds. Do not repop unpopped kernels.
Do not pop popcorn in glass cookware.
QUESTIONS AND ANSWERS
19
POWER SUPPLY 120V 60Hz 20A, SINGLE PHASE WITH EARTHING
MICROWAVE POWER CONSUMPTION 1400 W
MICROWAVE ENERGY OUTPUT 950 W, FULL MICROWAVE POWER
MICROWAVE FREQUENCY 2450MHz
OUTSIDE DIMENSIONS (W X H X D) 465 x 279 x 368mm (18.3 x 11.0 x 14.5 in)
CAVITY DIMENSIONS (W X H X D) 290 x 211 x 306mm (11.4 x 8.3 x 12.0 in)
NET WEIGHT APPROX. 12Kg (26.5 lbs)
TIMER 59 min. 99 sec.
POWER SELECTIONS 10 LEVELS
* Specifications are subject to change without notice.
SPECIFICATIONS
CARE AND CLEANING
Although your oven is provided with safety features, it is important to observe the following:
1. It is important not to defeat or tamper with safety
interlocks.
2. Do not place any object between the oven front
face and the door or allow residue to accumulate
on sealing surfaces. Wipe the sealing area
frequently with a mild detergent, rinse and dry.
Never use abrasive powders or pads.
3. When opened, the door must not be subjected to
strain, for example, a child hanging on an opened
door or any load could cause the oven to fall
forward to cause injury and also damage to the
door. Do not operate the oven if it is damaged,
until it has been repaired by a competent service
technician. It is particularly important that the
oven closes properly and that there is no damage
to the:
i) Door(bent)
ii) Hinges and Hookes(broken or loosened)
iii) Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by
anyone except a properly competent service
technician.
5. The oven should be cleaned regularly and any
food deposits removed;
6. Failure to maintain the oven in a clean condition
could lead to deterioration of the surface that
could adversely affect the life of the appliance and
possibly result in a hazardous situation.
BEFORE YOU CALL FOR SERVICE
Refer to following checklist, you may prevent an unnecessary service call.
* The oven doesn’t work :
1. Check that the power cord is securely plugged in.
2. Check that the door is firmly closed.
3. Check that the cooking time is set.
4. Check for a blown circuit fuse or tripped main
circuit breaker in your house.
* Sparking in the cavity;
1. Check utensils. Metal containers or dishes with
metal trim should not be used.
2. Check that metal skewers or foil does not touch
the interior walls.
If there is still a problem, contact the service station.
A list of these stations is included in the oven.
DO NOT ATTEMPT TO SERVICE THE OVEN YOURSELF !
20
COOKING INSTRUCTIONS
Utensil Guide
Only use utensils that are suitable for use in microwave ovens.
To cook food in the microwave oven, the microwaves must be able to penetrate the food, without
being reflected or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the
utensil is marked microwave-safe, you do not need to worry. The following table lists various of utensil
and indicates whether and how they should be used in a microwave oven.
●: Recommended use
▲ : Limited Use
✕: Not Recommended
Utensil Safe Comments
Aluminium foil
Crust plate
China and earthenware
Disposable polyester
cardboard dishes
Fast-food packaging
• Polystyrene cups containers
• Paper bags or newspaper
• Recycled paper or metal trims
Glassware
• Oven-to-table ware
• Fine glassware
• Glass jars
Metal
• Dishes
• Freezer bag twist ties
Paper
• Plates, cups, napkins and
Kitchen paper
• Recycled paper
Plastic
• Containers
• Cling film
• Freezer bags
Wax or grease-proof paper
Can be used in small quantities to protect areas against
overcooking. Arcing can occur if the foil is too close to
the oven wall or if too much foil is used.
Do not preheat for more than 8minutes.
Porcelain, pottery, glazed earthenware and bone china
are usually suitable, unless deco-rated with a metal trim.
Some frozen foods are packaged in these dishes.
Can be used to warm food. Overheating may cause the
polystyrene to melt.
May catch fire.
May cause arcing.
Can be used, unless decorated with a metal trim.
Can be used to warm foods or liquids.
Delicate glass may break or crack if heated suddenly.
Must remove the lid. Suitable for warming only.
May cause arcing or fire.
For short cooking times and warming. Also to absorb
excess moisture.
May cause arcing.
Particularly if heat-resistant thermoplastic. Some other
plastics may warp or discolour at high temperatures. Do
not use Melamine plastic.
Can be used to retain moisture. Should not touch the
food.
Take care when removing the film as hot steam will
escape.
Only if boilable or oven-proof. Should not be airtight.
Prick with a fork, if necessary.
Can be used to retain moisture and prevent spattering.
▲
●
●
●
●
✕
✕
●
●
●
✕
✕
●
✕
●
●
▲
●
21
USE YOUR MICROWAVE OVEN SAFELY
General Use
Do not attempt to defeat or tamper with safety
interlocks.
Do not place any object between the oven front frame
and the door or allow residue to build up on sealing
surfaces. Wipe with a mild detergent, rinse and dry.
Never use abrasive powders or pads.
Do not subject the oven door to strain or weight such
as a child hanging on an open door.
This could cause the oven to fall forward resulting in
injury to you and damage to the oven.
Do not operate the oven if door seals or sealing
surfaces are damaged; or if door is bent; or if hinges
are loose or broken.
Do not operate the oven empty. This will damage the
oven.
Do not attempt to dry clothes, newspapers or other
materials in the oven. They may catch on fire.
Do not use recycled paper products as they may
contain impurities which may cause sparks or fires.
Do not hit or strike the control panel with hard objects.
This can damage the oven.
Food
Never use your microwave oven for home canning.
The oven is not designed for proper home canning.
Improperly canned food may spoil and be dangerous
to consume.
Always use the minimum recipe cooking time. It is
better to undercook rather than overcook foods.
Undercooked foods can be returned to the oven for
more cooking. If food is overcooked, nothing can be
done.
Heat small quantities of food or foods with low
moisture carefully. These can quickly dry out, burn or
catch on fire.
Do not heat eggs in the shell. Pressure may build up
and eggs can explode.
Potatoes, apples, egg yolks and sausages are
examples of food with non-porous skins.
These must be pierced before cooking to prevent
bursting.
Do not attempt to deep fat fry in your microwave oven.
Always allow a starding time of at least 20 seconds
after the oven has been switched off to allao the
temperature to even out, stir during heating, if
necessary, and ALWAYS stir after heating. To prevent
eruptive boiling and possible scalding, you should put
a spoon or glass stick into the beverages and stir
before, during and after heating.
Do not leave the oven unattended while popping corn.
Do not pop corn in a paper bag unless it is the
commercially prepared Microwave Popcorn product.
The kernels can overheat and ignite a brown paper
bag.
Do not put packaged Microwave Popcorn bags
directly on the oven tray. Place the package on a
microwave safe glass or ceramic plate to avoid
overheating and cracking the oven tray.
Do not exceed the Microwave Popcorn manufacturers
suggested popping time.
Longer popping does not yield more popcorn but it
can result in scorch, burn of fire. Remember, the
Popcorn bag and tray can be too hot to handle.
Remove with caution and use pot holders.
ARCING
If you see arcing, touch STOP/CLEAR pad and correct the problem.
Arcing is the microwave term for sparks in the
oven.
Arcing is caused by:
• Metal or foil touching the side of the oven.
• Foil not molded to food (upturned edges act like
antennas).
• Metal, such as twist-ties, poultry pins, or gold
rimmed dishes, in the microwave.
• Recycled paper towels containing small metal
pieces being used in the microwave.
22
MICROWAVING PRINCIPLES
Microwave energy has been used in this country to cook and reheat food since early experiments with
RADAR in World War ll. Microwaves are present in the atmosphere all the time, both naturally and manmade
sources. Manmade sources include radar, radio, television, telecommunication links and car phones.
CONVERSION CHARTS
In a microwave oven,
electricity is converted
into microwave by the
MAGNETRON.
REFLECTION The microwaves bounce
off the metal walls and
the metal door screen.
TRANSMISSION Then they pass through
the cooking containers to
be absorbed by the water
molecules in the food, all
foods contain water to a
more or lesser extent.
ABSORPTION
The microwaves cause the water molecules to
vibrate which causes FRICTION, i.e. HEAT. This
heat then cooks the food. Microwaves are also
attracted to fat and sugar particles, and foods high
in these will cook more quickly. Microwaves can
only penetrate to a depth of 11/2 - 2 inches(4-5cm)
and as heat spreads through the food by
conduction, just as in a traditional oven, the food
cooks from the outside inwards.
WEIGHT MEASURES
15 g 1/2oz.
25 g 1 oz.
50 g 2 oz.
100 g 4 oz.
175 g 6 oz.
225 g 8 oz.
450 g 1 lb.
HOW MICROWAVES COOK FOOD
▲
▲▲
VOLUME MEASURES
30 ml 1 fl.oz.
100 ml 3 fl.oz.
150 ml 5 fl.oz. (1/4 pt)
300 ml 10 fl.oz. (1/2 pt)
600 ml 20 fl.oz. (1pt)
SPOON MEASURES
1.25 ml 1/4tsp
2.5 ml 1/2tsp
5 ml 1 tsp
15 ml 1 tbsp
FLUID MEASUREMENTS
1 Cup = 8 fl.oz. = 240 ml
1 Pint = 16 fl.oz. (UK 20 fl.oz.) = 480 ml (UK 560 ml)
1 Quart = 32 fl.oz. (UK 40 fl.oz.) = 960 ml (UK 1120 ml)
1 Gallon = 128 fl.oz. (UK 160 fl.oz.) = 3840 ml (UK 4500 ml)
23
STANDING TIME
Dense foods e.g. meat, jacket potatoes and
cakes, require standing time(inside or outside of
the oven) after cooking, to allow heat to finish
conducting to cook the center completely. Wrap
meat joints and jacket potatoes in aluminium foil
while standing. Meat joints need approx. 10-15
minutes, jacket potatoes 5 minutes. Other foods
such as plated meal, vegetables, fish etc require
2-5 minutes standing. After defrosting food,
standing time should also be allowed. If food is
not cooked after standing time, return to the oven
and cook for additional time.
MOISTURE CONTENT
Many fresh foods e.g. vegetables and fruit, vary
in their moisture content throughout the season,
particularly jacket potatoes. For this reason
cooking times may have to be adjusted. Dry
ingredients e.g. rice, pasta, can dry out during
storage so cooking times may differ.
DENSITY
Porous airy foods heat more quickly than dense
heavy foods.
CLING FILM
Cling film helps keep the food moist and the
trapped steam assists in speeding up cooking
times. Pierce before cooking to allow excess
steam to escape. Always take care when
removing cling film from a dish as the build-up of
steam will be very hot.
SHAPE
Even shapes cook evenly. Food cooks better by
microwave when in a round container rather than
square.
SPACING
Foods cook more quickly and evenly if spaced
apart. NEVER pile foods on top of each other.
STARTING TEMPERATURE
The colder the food, the longer it takes to heat up.
Food from a fridge takes longer to reheat than
food at room temperature.
LIQUIDS
All liquids must be stirred before and during
heating. Water especially must be stirred before
and during heating, to avoid eruption. Do not heat
liquids that have previously been boiled. DO NOT
OVERHEAT.
TURNING & STIRRING
Some foods require stirring during cooking. Meat
and poultry should be turned after half the
cooking time.
ARRANGING
Individual foods e.g. chicken portions or chops,
should be placed on a dish so that the thicker
parts are towards the outside.
QUANTITY
Small quantities cook faster than large quantities,
also small meals will reheat more quickly than
large portions.
PIERCING
The skin or membrane on some foods will cause
steam to build up during cooking. These foods
must be pierced or a strip of skin should be
peeled off before cooking to allow the steam to
escape. Eggs, potatoes, apples, sausages etc,
will all need to be pierced before cooking. DO
NOT ATTEMPT TO BOIL EGGS IN THEIR
SHELLS.
COVERING
Cover foods with microwave cling film or a lid.
Cover fish, vegetables, casseroles, soups. Do not
cover cakes, sauces, jacket potatoes or pastry
items.
COOKING TECHNIQUES
24
▶Do not defrost covered meat. Covering might allow
cooking to take place. Always remove outer wrap and
tray. Use only containers that are microwave-safe.
▶Begin defrosting whole poultry breast-side-down.
Begin defrosting roasts fat-side-down.
▶The shape of the package alters the defrosting time.
Shallow rectangular shapes defrost more quickly than
a deep block.
▶After 1/3of the defrost time has elapsed, check the
food. Toy may wish to turn over, break apart,
rearrange or remove thawed portions of the food.
▶During defrost, the oven will prompt you to turn the
over. At this point, open oven door and check the
food. Follow the techniques listed below for optimum
defrost results.
Then, close oven door, touch the START pad to
complete defrosting.
▶When defrosted, food should be cool, but softened in
all areas. If still slightly icy, return to microwave oven
very briefly, or let stand a few minutes. After
defrosting, allow food to stand 5-60 minutes if there
are any icy areas.
Poultry and fish may be placed under running cool
water until defrosted
➪Turn over : Roast, ribs, whole poultry, turkey breasts,
hot dogs, sausages, steaks, or chops.
➪Rearrange : Break apart or separate steaks, chops,
hamburger patties, ground meat, chicken or seafood
pieces, chunks of meat such as stew beef.
➪Shield : Use small strips of aluminum foil to protect
thin areas or edges of unevenly shaped foods such as
chicken wings. To prevent arching, do not allow foil to
come within 1-inch of oven walls or door.
➪Remove : To prevent cooking, thawed portions should
be removed from the oven at this point. This may
shorten defrost time for food weighing less than 3
lbs.(1350g).
DEFROSTING GUIDE
DEFROSTING CHART(by Time Defort)
Item & Weight Defrosting Time Standing Time Special Techniques
BEEF Minced beef
1 lb./450g
Stew Meat
1
1/2
lbs./675g
Patties
4(4oz./110g)
PORK Spareribs
1 lb./450g
Chops
4(5oz./125g)
Minced pork
1 lb./450g
POULTRY
Whole Chicken
2
1/2
lbs./1125g
Chicken Breasts
1 lbs./450g
Fryer Chicken(cut up)
2 lbs./900g
Chicken Thights
1
1/2
lbs./675g
FISH & SEAFOOD
Whole Fish
1 lb./450g
Fish Fillets
1
1/2
lb./675g
Shrimp
1/2
lb./225g
6-8 min.
11-13 min.
6-8 min.
7-9 min.
6-8 min.
6-8 min.
18-22 min.
6-8 min.
16-18 min.
12-14 min.
6-8 min.
11-13 min.
2-4 min.
15-20 min.
25-30 min.
15-20 min.
25-30 min.
25-30 min.
15-20 min.
45-90 min.
15-30 min.
25-30 min.
15-30 min.
15-20 min.
15-20 min.
15-20 min.
Break apart and remove thawed portions
with fork.
Separate and rearrange once.
Turn over after half the time.
Separate and rearrange once.
Separate and turn over once.
Break apart and remove thawed portions
with fork.
Break side down. Turn over after half the
time. Shield as needed.
Separate and rearrange once.
Separate and rearrange once.
Separate and rearrange once.
Turn over after half the time.
Shield as needed.
Separate and turn over once.
Separate and rearrange once.
* The times are approximate because freezer temperatures vary.
25
Item Power Cooking Time Special Instruction
Level Per lb./450g
MEAT
Beef joint-Rare P-80 5-7 min.
-Medium P-80 6-8 min.
-well done P-80 7-9 min.
Pork Joint P-HI 8-10 min.
Bacon joint P-HI 6-8 min.
POULTRY
Whole chicken P-HI 6-8 min.
Portions chicken P-80 5-7 min.
Breast (boned) P-80 5-7 min.
FISH
Fish Fillets P-HI 3-5 min.
Whole Mackerel, P-HI 3-5 min.
Cleaned and prepared
Whole Trout, Cleaned P-HI 3-5 min.
& Prepared
Salmon steaks P-HI 3-5 min.
NOTE : The above times should be regarded only as a guide. Allow for difference in individual tastes
and preferences. The times may vary due to the shape, cut, and composition of the food.
Frozen meat, poultry and fish must be thoroughly thawed before cooking.
COOKING & REHEATING CHART
Cooking chart
- Chilled meat and poultry should be removed from
the refrigerator at least 30 minutes before
cooking.
- Always let the meat and poultry stand, covered
after cooking.
- Brush a little oil or melted butter over the fish, or
add 15~30ml(1-2 tbsp) lemon juice, wine, stock,
milk or water.
- Always let the fish stand, covered, after cooking
26
Reheating chart
• Baby food particularly needs to be checked carefully before serving to prevent burns.
• When heating pre-packaged ready-cooked foods, always follow the pack instructions carefully.
• If you freeze foods which were bought from the fresh or chilled counters, remember that they should
be thoroughly thawed before following the heating instructions on the packed. It’s worth putting a
note on them so that other members of the household will remember too.
• Remember metal ties and transfer food from foil containers before reheating.
• Chilled(refrigerated) food takes longer to reheat than food at room temperature (such as just-cooled
food or food from the store cupboard).
• All foods should be reheated using full microwave power.
Item Cooking time Special Instructions
Baby food 20 sec.
128g jar
Baby milk
100ml / 4fl.oz. 20-30 sec.
225ml / 8fl.oz. 40-50 sec.
Sandwich roll or bun
1 roll 20-30 sec.
Lasagna
1 serving 4-6 min.
(10
1/2
oz./300g)
Casserole
1 cup 1
1/2
-3 min.
4 cups 5-7 min.
Mashed potatoes
1 cup 2-3 min.
4 cups 6-8 min.
Baked beans
1 cup 2-3 min.
Ravioli or pasta in sauce
1 cup 3-4 min.
4 cups 7-10 min.
Empty into a small serving bowl.
Stir well once or twice during heating.
Before serving, check the temperature carefully.
Stir or shake well and pour into a sterilized bottle.
Before serving, shake well and check the temperature carefully.
Wrap in paper towel and place on glass microwaveable rack.
*Note : Do not use recycled paper towels.
Place lasagna on microwaveable plate.
Cover with plastic wrap and vent.
Cook covered in microwaveable casserole.
Stir once halfway through cooking.
Cook covered in microwaveable casserole.
Stir once halfway through cooking.
Cook covered in microwaveable casserole.
Stir once halfway through cooking.
Cook covered in microwaveable casserole.
Stir once halfway through cooking.
27
VEGETABLE CHART
Use a suitable glass pyrex bowl with lid. Add 30-45ml cold water(2-3 tbsp.) for every 250g unless
another water quantity is recommended - see table. Cook covered for the minimum time - see table.
Continue cooking to get the result you prefer. Stir once during and once after cooking. Add salt, herbs
or butter after cooking. Cover during a standing time of 3 minutes.
Hint : cut the fresh vegetables into even sized pieces. The smaller they are cut, the quicker they will
cook.
All vegetables should be cooked using full microwave power.
Cooking Guide for fresh vegetables
Vegetables Weight Time Comments
Broccoli
1/2
lb./250g 2-3 min
1 lb./500g 3-5 min
Brussels sprouts
1/2
lb./250g 2-3 min
Carrots
1/2
lb./250g 2-3 min
Cauliflower
1/2
lb./250g 2-3 min
1 lb./500g 3-5 min
Courgettes
1/2
lb./250g 2-3 min
Egg plants
1/2
lb./250g 2-3 min
Leeks
1/2
lb./250g 2-3 min
Mushrooms 0.3 lb./125g 1-2 min
1/2
lb./250g 2-3 min
Onions
1/2
lb./250g 2-3 min
Pepper
1/2
lb./250g 2-4 min
Potatoes
1/2
lb./250g 2-3 min
1 lb./500g 6-8 min
Turnip cabbage
1/2
lb./250g 4-6 min
Prepare even sized florets.
Arrange the stems to the centre.
Add 60-75ml(5-6tbsp.) water.
Cut carrots into even sized slices.
Prepare even sized florets. Cut big florets into
halves. Arrange stems to the centre.
Cut courgettes into slices. Add 30ml(2tbsp.) water
or a knob of butter. Cook until just tender.
Cut egg plants into small slices and sprinkle with 1
tablespoon lemon juice.
Cut leeks into thick slices.
Prepare small whole or sliced mushrooms. Do not
add any water. Sprinkle with lemon juice. Spice
with salt and pepper. Drain before serving.
Cut onions into slices or halves. Add only
15ml(1tbsp.) water.
Cut pepper into small slices.
Weigh the peeled potatoes and cut them into
similar sized halves or quarters.
Cut turnip cabbage into small cubes.
Cooking Guide for frozen vegetables
Vegetables Weight Time Instructions
spinach 0.3 lb./125g 1-2 min
broccoli
1/2
lb./250g 2-3 min
Peas
1/2
lb./250g 2-3 min
Green beans
1/2
lb./250g 3-4 min
Mixed vegetables
1/2
lb./250g 2-4 min
(carrots/peas/corn)
Mixed vegetables
1/2
lb./250g 3-5 min
(Chinese style)
Add 15ml(1tbsp.) cold water.
Add 30ml(2 tbsp.) cold water.
Add 15ml(1 tbsp.) cold water.
Add 30ml(2t tbsp.) cold water.
Add 15ml(1ttbsp.) cold water.
Add 15ml(1 tbsp.) cold water.
28
TOMATO & ORANGE SOUP
1 oz.(25g) butter
1 medium onion, chopped
1 large carrot & 1 large potato, chopped
13/4lb(800g) canned, chopped tomatoes
juice and grated rind of 1 small orange
11/2pints(900ml) hot vegetable stock
salt and pepper to taste
1. Melt the in a large bowl at P-HI for 1 minute.
2. Add the onion, carrot and potato and cook at P-
HI for 6 minutes. stir halfway through cooking.
3. Add the tomatoes, orange juice, orange rind and
stock. Mix thoroughly. Season with salt and
pepper to taste. Cover the bowl and cook at P-HI
for 10 minutes. stir 2-3 times during cooking, until
the vegetables are tender.
4. Blend and serve immediately.
FRENCH ONION SOUP
1 large onions, sliced
1 tbsp (15ml) corn oil
2 oz.(50g) plain flour
2 pints(1.2 liters) hot meat
or vegetable stock
salt and pepper to taste
2 tbsp (30ml) parsley, chopped
4 thick slices French bread
2 oz.(50g) cheese, grated
1. Place the onion and oil a bowl, mix well and cook
at P-HI for 2 minutes.
2. Stir in the flour to make a paste and gradually
add stack. Season and add the parsley.
3. Cover the bowl and cook at P-80 for 12 minutes.
4. Pour the soup into serving bowls, submerge
bread and sprinkle generously with cheese.
5. Cook at P-80 for 2 minutes, until the cheese has
melted.
STIR FRIED VEGETABLES
1 tbsp(15ml) sunflower oil
2 tbsp (30ml) soy sauce
1 tbsp (15ml) sherry
1"(2.5cm) root ginger,
peeled and finely grated
2 medium carrots, cut into fine strips
4 oz.(100g) button mushrooms,
chopped
2 oz.(50g) beansprouts
4 oz.(100g) mange-tout
1 red pepper, seeded and thinly sliced
4 spring onions, chopped
4 oz.(100g) canned water chestnuts,
sliced
1/4 head of chinese leaves, thinly sliced
1. Place the oil, soy sauce, sherry, ginger, garlic
and carrots in a large bowl, mix thoroughly
2. Cover and cook at P-HI for 3-4 minutes, stirring
once.
3. Add the button mushrooms, beansprouts,
mange-tout, red pepper, spring onions, water
chestnuts and chinese leaves. Mix thoroughly.
4. Cook at P-HI for 4-5 minutes, until the
vegetables are tender. Stir 2-3 times during
cooking.
Stir fried vegetables are ideally served with
meat or fish.
HONEYED CHICKEN
4 boneless chicken breasts
2 tbsp(30ml) clear honey
1 tbsp(15ml) whole grain mustard
1/2 tsp(2.5ml) dried tarragon
1 tbsp(15ml) tomato puree
1/4 pint(150ml) chicken stock
1. Place the chicken breasts in a casserole dish.
2. Mix all remaining ingredients together and pour
over the chicken. Salt and pepper to taste.
3. Cook at P-HI for 10-12 minutes. Rearrange and
coat the chicken with the sauce twice during
cooking.
RECIPES
29
BLUE CHEESE & CHIVE JACKETS
2 baking potatoes,
(approx.9 oz.(250g) each)
2 oz.(50g) butter
4 oz.(100g) blue cheese, chopped
1 tbsp(15ml) fresh chives, chopped
2 oz.(50g) mushrooms, sliced
salt and pepper to taste
1. Prick each potato in several places. Cook at P-HI
for 6-8 minutes. Halve and scoop the flesh into a
bowl, add the butter, cheese, chives,
mushrooms, salt and pepper, mix thoroughly.
2. Pile mixture into the potato skins and place in a
flan dish, on the rack.
3. Cook at P-80 for 8 minutes.
WHITE SAUCE
1 oz.(25g) butter
1 oz.(25g) plain flour
1/2 pint(300ml) milk
salt and pepper to taste
1. Place the butter in a bowl and cook at P-HI for 1
minute, until melted.
2. Stir in the flour and whisk in the milk. Cook at P-
HI for 2-4 minutes, stirring every 2 minutes until
thick and smooth. Season with salt and pepper
to taste.
STRAWBERRY JAM
11/2 lb.(675g) strawberries, hulled
3 tbsp(45ml) lemon juice
11/2 lb.(675g) caster sugar
1. Place strawberries and lemon juice in a very
large bowl, heat at P-HI for 5 minutes, or until the
fruit has softened. Add sugar, mix well.
2. Cook at P-80 for 14-16 minutes, until setting
point*is reached, stir every 4-5 minutes.
3. Pour into hot, clean jars. Cover, seal and label.
* setting point : To determine setting point, place 1
tsp(5ml)jam onto chilled saucer. Allow to stand for
1 minute. Move surface of jam gently with your
finger, if the surface wrinkles setting point has
been reached.
PLAIN MICROWAVE CAKE
4 oz.(100g) margarine
4 oz.(100g) sugar
1 eggs
4 oz.(100g) self raising flour, sifted
2-3 tbsp(30-45ml) milk
1. line the base of 8" (20.4cm) cake dish with
grease-proof paper.
2. Cream the margarine and sugar together until
light and fluffy. Beat in the eggs and fold in the
sifted flour alternately with the milk.
3. Pour into prepared container. Cook at P-HI for 3-
4 minutes, until a skewer comes out cleanly.
4. Leave the cake to stand for 5 minutes before
turning out.
OMELETTS
1/2 oz.(15g) butter
4 eggs
6 tbsp(90ml) milk
salt & pepper
1. Whisk together eggs and milk. Season.
2. Place butter in 10"(26cm) flan dish. Cook at P-HI
for 1 minute, until melted. Coat the dish with the
melted butter.
3. Pour omelette mixture into flan dish. Cook at P-
HI for 2 minutes. whisk mixture and cook again
at P-HI for 1 minutes.
30
SCRAMBLED EGG
1/2 oz.(15g) butter
2 eggs
2 tbsp(30ml) milk
salt & pepper
1. Melt the butter in a bowl at P-HI for 1 minutes.
2. Add the eggs, milk and seasoning and mix well.
3. Cook at P-HI for 2 minutes, stirring every 30
seconds.
SAVORY MINCE
1 small onion, diced
1 clove garlic, crushed
1 tsp(5ml) oil
7 oz.(200g) can chopped tomatoes
1 tbsp(15ml) tomato puree
1 tsp(5ml) mixed herbs
8 oz.(225g) minced beef
salt and pepper
1. Place onion, garlic and oil in casserole, and cook
at P-HI for 2 minutes or until soft.
2. Place all other ingredients in casserole. Stir well.
3. Cover and cook at P-HI for 4 minutes then P-80
for 4-6 minutes or until the meat is cooked.
