WINIA Electronics 7NF6LMO700N Microwave Oven User Manual KOR 6L653A
Dongbu Daewoo Electronics Corporation Microwave Oven KOR 6L653A
Contents
- 1. User Manual
- 2. user manual
user manual
Before operating this oven, please read these instructions completely.
OPERATING INSTRUCTIONS
& COOK BOOK
MICROWAVE OVEN
KOR-6L653A
1
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can result in
harmful exposure to microwave energy. It is important not to defeat or tamper with the safety
interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or
loosened), (3) door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified service personnel.
TABLE OF CONTENTS
• PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY.................................1
•
IMPORTANT SAFETY INSTRUCTIONS..........................................................................................................................2
•
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT .........................................................................................3
•
GROUNDING INSTRUCTIONS ........................................................................................................................................3
• I
NSTALLATION...................................................................................................................................................................4
•
SPECIFICATIONS ..............................................................................................................................................................5
•
FEATURES DIAGRAM.......................................................................................................................................................6
•
OPERATION PROCEDURE..............................................................................................................................................7
•
CARE OF YOUR MICROWAVE OVEN............................................................................................................................8
•
BEFORE YOU CALL FOR SERVICE ...............................................................................................................................9
•
CARE AND CLEANING......................................................................................................................................................9
•
QUESTIONS AND ANSWERS........................................................................................................................................10
•
COOKING INSTRUCTIONS ............................................................................................................................................11
•
USE YOUR MICROWAVE OVEN SAFELY ...................................................................................................................12
•
ARCING.............................................................................................................................................................................12
•
MICROWAVING PRINCIPLES........................................................................................................................................13
•
HOW MICROWAVES COOK FOOD .....................................................................................................................13
•
CONVERSION CHARTS ........................................................................................................................................13
•
COOKING TECHNIQUES................................................................................................................................................14
•
DEFROSTING CHART.....................................................................................................................................................15
•
COOKING & REHEATING CHART.................................................................................................................................16
•
VEGETABLE CHART.......................................................................................................................................................17
•
RECIPES...........................................................................................................................................................................18
2
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive
microwave energy:
11. Read all instructions before using the appliance.
12. Read and follow the specific “PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” found on page 1.
13. This appliance must be grounded. Connect only to
properly grounded outlet. See “GROUNDING
INSTRUCTIONS” found on page 3.
14. Install or locate this appliance only in accordance
with the provided installation instructions.
15. Some products such as whole eggs and sealed
containers - for example, closed glass jars are able
to explode and should not be heated in this oven.
16.
Use this appliance only for its intended use as
described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type of
oven is specifically designed to heat, cook, or dry
food. It is not designed for industrial or laboratory use.
17. Only allow children to use the oven without
supervision when adequate instructions have been
given so that the child is able to use the oven in a
safe way and understands the hazards of improper
use.
18. Do not operate this appliance if it has a damaged
cord or plug, if it is not working properly, or if it has
been damaged or dropped.
19. This appliance should be serviced only by qualified
service personnel.
Contact nearest authorized service facility for
examination, repair or adjustment.
10.
Do not cover or block any openings on the appliance.
11. Do not store this appliance outdoors. Do not use this
product near water — for example, near a kitchen
sink, in a wet basement, near a swimming pool, or
similar locations.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not let cord hang over edge of table or counter.
15. When cleaning surfaces of door and oven that
comes together on closing the door, use only mild,
non-abrasive soaps or detergents applied with a
sponge or soft cloth.
16. To reduce the risk of fire in the oven cavity:
a) Do not overcook food. Carefully attend appliance
when paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
b) Remove wire twist-ties from paper or plastic bags
before placing bag in oven.
c) If materials inside the oven ignite, keep oven
door closed, turn oven off, and disconnect the
power cord, or shut off power at the fuse or circuit
breaker panel.
d) Do not use the cavity for storage purposes. Do
not leave paper products, cooking utensils, or
food in the cavity when not in use.
17. Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without
appearing to be boiling due to surface tension of the
liquid. Visible bubbling or boiling when the container
is removed from the microwave oven is not always
present. THIS COULD RESULT IN VERY HOT
LIQUIDS SUDDENLY BOILING OVER WHEN A
SPOON OR OTHER UTENSIL IS INSERTED INTO
THE LIQUID.
To reduce the risk of injury to persons:
a) Do not overheat the liquid.
b) Stir the liquid both before and halfway through
heating it.
c) Do not use straight-sided containers with narrow
necks.
d) After heating, allow the container to stand in the
microwave oven for a short time before removing
the container.
e) Use extreme care when inserting a spoon or
other utensil into the container.
18. Do not use this microwave oven to heat corrosive
chemicals (for example, sulfides and chlorides).
Vapors from such corrosive chemicals may interact
with the contact and springs of the safety interlock
switches thereby rendering them inoperable.
19. Keep the waveguide cover clean at all times.
Wipe the oven interior with a soft damp cloth after
each use. If you leave grease or fat anywhere in the
cavity it may overheat, smoke or even catch fire
when next using the oven.
20. Never heat oil or fat for deep frying as you cannot
control the temperature and doing so may lead to
overheating and fire.
21.
Do not operate the oven without the glass tray in
place. Be sure it is properly sitting on the rotating
base.
SAVE THESE INSTRUCTIONS
3
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, the grounding plug reduces the risk of
electric shock by providing an escape wire for electric current. This appliance is equipped with a cord having a
grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and
grounded.
WARNING:
This equipment generates and uses ISM frequency energy and if not installed and used properly, that is in
strict accordance with the manufacturer's instructions, may cause interference to radio and television
reception.
It has been type-tested and found to comply with limits for an ISM Equipment pursuant to part 18 of FCC
Rules, which are designed to provide reasonable protection against such interference in a residential
installation.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the followings.
• Reorient the receiving antenna of radio or television.
• Relocate the Microwave oven with respect to the receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so that microwave oven and receiver are on
different branch circuits.
THE MANUFACTURER is not responsible for any radio or TV interference caused by
UNAUTHORIZED MODIFICATION to this microwave oven. It is the responsibility of the user to correct
such interference.
WARNING:
Improper use of the grounding can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not completely understood, or if
doubt exists as to whether the appliance is properly grounded, and either :
(1) If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding
plug, and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the
extension cord shall be equal to or greater than the electrical rating of the appliance.
or
(2) Do not use an extension cord, if the power supply cord is too short, have a qualified electrician or
serviceman install an outlet near the appliance.
WARNING:
Do not cut or remove the third (ground) prong from the power cord under any circumstances.
4
INSTALLATION
1. Examine the oven after unpacking.
Check for damage such as a misaligned door, broken door or dent in the cavity.
If any damage is visible, DO NOT INSTALL, and notify your dealer immediately.
2. Level, flat location.
Install the microwave oven on a level, flat surface.
3. Ventilation.
Do not block air vents. If they are blocked during operation, the oven may overheat and eventually cause a
failure.
For proper ventilation, allow 3 inches of space between oven top, sides, rear and adjacent surfaces.
4. Away from radio and TV sets.
Poor television reception and radio interference may result if the oven is located close to a TV, radio, antenna,
feeder, etc.
Place the oven as far from them as possible.
5. Away from heating appliances and water taps.
Keep the oven away from heat, steam or splashing liquids. These things can adversely affect oven wiring and
contacts.
6. Power supply.
• Check your local power source.
This microwave oven requires a current of approximately 9.5 amperes, 120Volts, 60Hz grounded outlet.
1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping
over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised in their use.
3. If a long cord or extension cord is used:
• The marked electrical rating of the cord set or extension cord should be at least as great as the electrical
rating of the appliance.
• The extension cord must be a grounding type 3-wire cord.
• The longer cord should be arranged so that it will not drape over the counter top or tabletop where it can be
pulled on by children or tripped over unintentionally.
7. The minimum height of free space necessary above the top surface of the oven is about 4 inches.
When use 3-pronged plug
3-prong Receptacle
Receptacle
Box cover
3-prong plug
When use grounding adaptor, make sure
the receptacle box is fully grounded.
Receptacle Box Cover
Receptacle
Grounding
Lead
Grounding
Adaptor
“THE CANADIAN ELECTRICAL CODE DOES NOT ALLOW THE USE OF THE GROUNDING ADAPTOR”
5
SPECIFICATIONS
POWER SUPPLY 120V AC, 60Hz SINGLE PHASE WITH
GROUNDING
INPUT POWER 1100 W
MICROWAVE ENERGY OUTPUT 700 W
FREQUENCY 2,450 MHz
OUTSIDE DIMENSIONS (W H D) 17.6 10.6 13.2 in
CAVITY DIMENSIONS (W H D) 11.6 8.3 11.9 in
CAVITY VOLUME 0.7 cu.ft
NET WEIGHT APPROX. 22.5 lbs.
TIMER 35min. DUAL SPEED
POWER SELECTIONS 5 Levels
* Specifications are subject to change without notice.
17.6
10.6
13.2
6
11Door latch - When the door is closed, it will
automatically shut off. If the door is opened while
the oven is operating, the magnetron will
automatically shut off.
22Door seal - The door seal surfaces prevent
microwaves escaping from the oven cavity.
33Oven cavity
44Control panel
55Coupler- This fits over the shaft in the center of the
oven cavity floor.
This is to remain in the oven for all cooking.
66Roller guide - This must always be used for
cooking together with the glass cooking tray.
77Glass cooking tray - Made of special heat resistant
glass. The tray must always be in proper position
before operating. Do not cook food directly on the
tray.
88Viewing screen - Allows viewing of food.
The screen is designed so that light can pass
through, but not the microwave.
99Waveguide cover - Protects the microwave outlet
from splashes of cooking foods.
00Safety interlock system
qqVariable Power Control Knob - Used to select a
microwave power level.
wwTimer knob - Used in setting cooking time for all
functions.
eeOven lamp - Automatically turns on during oven
operating.
FEATURES DIAGRAM
12 3 4 8 90
ew567
q
7
OPERATION PROCEDURE
1. Plug power supply cord into 120V AC 60Hz power
outlet.
2. After placing the food in a suitable container, open
the oven door and put it on the glass tray.
The glass tray and roller guide must always be in
place during cooking.
3. Close the door. Make sure that it is firmly closed.
The oven door can be opened at any time during
operation by pulling the door handle. The oven
will automatically shut off.
4. Set the variable power control knob to the desired
power level.
5. Set the operating time by turing the timer knob to
the desired cook time and the microwave cooking
starts.
• If setting the timer control for less than
2 minutes, turn it past 2 minutes and then back
to the desired time.
6. Microwave energy will be turned off automatically
when the timer knob reaches “OFF”. Then food
can be taken out of the oven.
• To prevent the oven from operating with the
door open, your microwave oven is fitted with
safety door interlock switches.
• If you wish to inspect the food while it is cooking
simply open the door. The oven will
automatically stop cooking. To continue
cooking, you simply close the door.
• If you wish to stop cooking, simply turn the timer
knob to the “OFF” position. Cooking can be
reset at any time during the cooking cycle by
turning the timer control.
• Do not let the timer continue to operate after
removing or when there is no food.
This section includes useful information about oven operation.
Warm 120W
Defrost 210W
Medium 390W
Medium high 560W
High 700W
SYMBOL POWER
LEVEL OUTPUT
POWER
8
CARE OF YOUR MICROWAVE OVEN
The oven should be cleaned regularly and any food deposits removed.
Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly result in a hazardous situation.
Turn the oven off before cleaning.
Keep the inside of the oven clean. When food
spatters or spilled liquids adhere to oven walls,
wipe with a damp cloth. Mild detergent may be
used if the oven gets very dirty. The use of harsh
detergent or abrasives is not recommended.
The outside oven surface should be cleaned with
soap and water, rinsed and dried with a soft cloth.
To prevent damage to the operating parts inside
the oven, water should not be allowed to seep into
the ventilation openings.
If the Control Panel becomes wet, clean with a
soft, dry cloth. Do not use harsh detergents or
abrasives on Control Panel.
If steam accumulates inside or around the outside
of the oven door, wipe with a soft cloth. This may
occur when the microwave oven is operated under
high humidity conditions and in no way indicates
malfunction of the unit.
It is occasionally necessary to remove the glass
tray for cleaning. Wash the tray in warm sudsy
water or in a dishwasher.
The roller guide and oven cavity floor should be
cleaned regularly to avoid excessive noise.
Simply wipe the bottom surface of the oven with mild
detergent water or window cleaner and dry. The
roller guide may be washed in mild sudsy water.
1
2
3
4
5
6
7
ROLLER GUIDE
Glass Tray Roller Guide
The ROLLER GUIDE and oven floor should be
cleaned frequently to prevent excessive noise.
The ROLLER GUIDE MUST ALWAYS be used
for cooking together with the Glass Tray.
1
2
GLASS TRAY
DO NOT operate the oven without the Glass Tray
in place.
DO NOT use any other Glass Tray with this oven.
If Glass Tray is hot, ALLOW TO COOL before
cleaning or placing it in water.
DO NOT cook directly on the Glass Tray.
(Except for popcorn)
1
2
3
4
9
BEFORE YOU CALL FOR SERVICE
Refer to following checklist, you may prevent an unnecessary service call.
* The oven doesn’t work :
1. Check that the power cord is securely plugged in.
2. Check that the door is firmly closed.
3. Check that the cooking time is set.
4. Check for a blown circuit fuse or tripped main circuit
breaker in your house.
* Sparking in the cavity :
1. Check utensils. Metal containers or dishes with metal
trim should not be used.
2. Check that metal skewers or foil does not touch the
interior walls.
If there is still a problem, contact the service station.
A list of these stations is included in the oven.
CARE AND CLEANING
Although your oven is provided with safety features, it
is important to observe the following:
1. It is important not to defeat or tamper with safety
interlocks.
2. Do not place any object between the oven front
face and the door or allow residue to accumulate
on sealing surfaces. Wipe the sealing area
frequently with a mild detergent, rinse and dry.
Never use abrasive powders or pads.
3. When opened, the door must not be subjected to
strain, for example, a child hanging on an opened
door or any load could cause the oven to fall
forward to cause injury and also damage to the
door. Do not operate the oven if it is damaged, until
it has been repaired by a competent service
technician. It is particularly important that the oven
closes properly and that there is no damage to the:
i) Door(bent)
ii) Hinges and Hookes(broken or loosened)
iii) Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by
anyone except a properly competent service
technician.
5. The oven should be cleaned regularly and any food
deposits removed;
6. Failure to maintain the oven in a clean condition
could lead to deterioration of the surface that could
adversely affect the life of the appliance and
possibly result in a hazardous situation;
10
QUESTIONS AND ANSWERS
* Q :I accidentally ran my microwave oven
without any food in it. Is it damaged?
* A : Running the oven empty for a short time will
not damage the oven. However, it is not
recommended.
* Q :Can the oven be used with the glass tray or
roller guide removed?
* A : No. Both the glass tray and roller guide must
always be used in the oven before cooking.
* Q :Can I open the door when the oven is
operating?
* A : The door can be opened anytime during the
cooking operation. Then microwave energy will
be instantly switched off and the time setting
will maintain until the door is closed.
* Q :Why do I have moisture in my microwave
oven after cooking?
* A : The moisture on the side of your microwave
oven is normal. It is caused by steam from
cooking food hitting the cool oven surface.
* Q :Does microwave energy pass through the
viewing screen in the door?
* A : No. The metal screen bounces back the energy
to the oven cavity. The holes are made to allow
light to pass through. They do not let
microwave energy pass through.
* Q :Why do eggs sometimes pop?
* A : When baking or poaching eggs, the yolk may
pop due to steam build-up inside the yolk
membrane. To prevent this, simply pierce the
yolk with a toothpick before cooking. Never
cook eggs without piercing their shells.
* Q :Why this standing time recommended after
the cooking operation has been completed?
* A : Standing time is very important.
With microwave cooking, the heat is in the
food, not in the oven. Many foods build up
enough internal heat to allow the cooking
process to continue, even after the food is
removed from the oven. Standing time for joints
of meat, large vegetables and cakes is to allow
the inside to cook completely, without
overcooking the outside.
* Q :What does “standing time” mean?
* A : “Standing time” means that food should be
removed from the oven and covered for
additional time to allow it to finish cooking. This
frees the oven for other cooking.
* Q :Why does my oven not always cook as fast
as the microwave cooking guide says?
* A : Check your cooking guide again, to make sure
you’ve followed directions exactly ; and to see
what might cause variations in cooking time.
Cooking guide times and heat settings are
suggestions, to help prevent over-cooking... the
most common problem in getting used to a
microwave oven.
Variations in the size, shape and weights and
dimensions could require longer cooking time.
Use your own judgement along with the
cooking guide suggestions to check whether
the food has been properly cooked just as you
would do with a conventional cooker.
* Q :Will the microwave oven be damaged if it
operates while empty?
* A : Yes. Never run it empty.
* Q : Can I operate my microwave oven without
the turntable or turn the turntable over to
hold a large dish?
* A : No. If you remove or turn over the turntable,
you will get poor cooking results. Dishes used
in your oven must fit on the turntable.
* Q : Is it normal for the turntable to turn in either
direction?
* A : Yes. The turntable rotates clockwise or
counterclockwise, depending on the rotation of
the motor when the cooking cycle begins.
* Q : Can I pop popcorn in my microwave oven?
How do I get the best results?
* A : Yes. Pop packaged microwave popcorn
following manufacture’s guidelines. Do not use
regular paper bags. Use the “listening test” by
stopping the oven as soon as the popping
slows to a “pop” every 1 or 2 seconds. Do not
repop unpopped kernels. Do not pop popcorn
in glass cookware.
11
COOKING INSTRUCTIONS
Utensil Guide
Only use utensils that are suitable for use in microwave ovens.
To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected
or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the utensil is marked
microwave-safe, you do not need to worry. The following table lists various of utensil and indicates whether and
how they should be used in a microwave oven.
●: Recommended use
▲ : Limited Use
✕: Not Recommended
Aluminium foil
Crust plate
China and earthenware
Disposable polyester
cardboard dishes
Fast-food packaging
• Polystyrene cups containers
• Paper bags or newspaper
• Recycled paper or metal trims
Glassware
• Oven-to-table ware
• Fine glassware
• Glass jars
Metal
• Dishes
• Freezer bag twist ties
Paper
• Plates, cups, napkins and
Kitchen paper
• Recycled paper
Plastic
• Containers
• Cling film
• Freezer bags
Wax or grease-proof paper
Utensil Safe Comments
Can be used in small quantities to protect areas against
overcooking. Arcing can occur if the foil is too close to
the oven wall or if too much foil is used.
Do not preheat for more than 8minutes.
Porcelain, pottery, glazed earthenware and bone china
are usually suitable, unless deco-rated with a metal trim.
Some frozen foods are packaged in these dishes.
Can be used to warm food. Overheating may cause the
polystyrene to melt.
May catch fire.
May cause arcing.
Can be used, unless decorated with a metal trim.
Can be used to warm foods or liquids.
Delicate glass may break or crack if heated suddenly.
Must remove the lid. Suitable for warming only.
May cause arcing or fire.
For short cooking times and warming. Also to absorb
excess moisture.
May cause arcing.
Particularly if heat-resistant thermoplastic. Some other
plastics may warp or discolour at high temperatures. Do
not use Melamine plastic.
Can be used to retain moisture. Should not touch the
food.
Take care when removing the film as hot steam will
escape.
Only if boilable or oven-proof. Should not be airtight.
Prick with a fork, if necessary.
Can be used to retain moisture and prevent spattering.
▲
●
●
●
●
✕
✕
●
●
●
✕
✕
●
✕
●
●
▲
●
12
USE YOUR MICROWAVE OVEN SAFELY
General Use
Do not attempt to defeat or tamper with safety
interlocks.
Do not place any object between the oven front frame
and the door or allow residue to build up on sealing
surfaces. Wipe with a mild detergent, rinse and dry.
Never use abrasive powders or pads.
Do not subject the oven door to strain or weight such
as a child hanging on an open door.
This could cause the oven to fall forward resulting in
injury to you and damage to the oven.
Do not operate the oven if door seals or sealing
surfaces are damaged; or if door is bent; or if hinges
are loose or broken.
Do not operate the oven empty. This will damage the
oven.
Do not attempt to dry clothes, newspapers or other
materials in the oven. They may catch on fire.
Do not use recycled paper products as they may
contain impurities which may cause sparks or fires.
Do not hit or strike the control panel with hard objects.
This can damage the oven.
Food
Never use your microwave oven for home canning.
The oven is not designed for proper home canning.
Improperly canned food may spoil and be dangerous to
consume.
Always use the minimum recipe cooking time. It is
better to undercook rather than overcook foods.
Undercooked foods can be returned to the oven for
more cooking. If food is overcooked, nothing can be
done.
Heat small quantities of food or foods with low moisture
carefully. These can quickly dry out, burn or catch on
fire.
Do not heat eggs in the shell. Pressure may build up
and eggs can explode.
Potatoes, apples, egg yolks and sausages are
examples of food with non-porous skins.
These must be pierced before cooking to prevent
bursting.
Do not attempt to deep fat fry in your microwave oven.
Always allow a standing time of at least 20 seconds
after the oven has been switched off to allow the
temperature to even out, stir during heating, if
necessary, and ALWAYS stir after heating. To prevent
eruptive boiling and possible scalding, you should put a
spoon or glass stick into the beverages and stir before,
during and after heating.
Do not leave the oven unattended while popping corn.
Do not pop corn in a paper bag unless it is the
commercially prepared Microwave Popcorn product.
The kernels can overheat and ignite a brown paper
bag.
Do not put packaged Microwave Popcorn bags directly
on the oven tray. Place the package on a microwave
safe glass or ceramic plate to avoid overheating and
cracking the oven tray.
Do not exceed the Microwave Popcorn manufacturers
suggested popping time.
Longer popping does not yield more popcorn but it can
result in scorch, burn of fire. Remember, the Popcorn
bag and tray can be too hot to handle. Remove with
caution and use pot holders.
ARCING
If you see arcing, turn the knob timer the point “0” and correct the problem.
Arcing is the microwave term for sparks in the oven.
Arcing is caused by:
• Metal or foil touching the side of the oven.
• Foil not molded to food (upturned edges act like
antennas).
• Metal, such as twist-ties, poultry pins, or gold rimmed
dishes, in the microwave.
• Recycled paper towels containing small metal pieces
being used in the microwave.
13
MICROWAVING PRINCIPLES
Microwave energy has been used in this country to cook and reheat food since early experiments with RADAR in
World War ll. Microwaves are present in the atmosphere all the time, both naturally and manmade sources. Manmade
sources include radar, radio, television, telecommunication links and car phones.
CONVERSION CHARTS
HOW MICROWAVES COOK FOOD
Then they pass through the
cooking containers to be
absorbed by the water
molecules in the food, all
foods contain water to a more
or lesser extent.
The microwaves cause the water molecules to vibrate
which causes FRICTION, i.e. HEAT. This heat then
cooks the food. Microwaves are also attracted to fat and
sugar particles, and foods high in these will cook more
quickly. Microwaves can only penetrate to a depth of 11/2
- 2 inches(4-5cm) and as heat spreads through the food
by conduction, just as in a traditional oven, the food
cooks from the outside inwards.
In a microwave oven,
electricity is converted
into microwave by the
MAGNETRON.
The microwaves bounce
off the metal walls and
the metal door screen.
Oven Cavity Magnetron
Waveguide
Turntable
REFLECTION
TRANSMISSION
ABSORPTION
Microwave Water Molecule Absorption Vibration
WEIGHT MEASURES
15 g 1/2oz.
25 g 1 oz.
50 g 2 oz.
100 g 4 oz.
175 g 6 oz.
225 g 8 oz.
450 g 1 lb.
VOLUME MEASURES
30 ml 1 fl.oz.
100 ml 3 fl.oz.
150 ml 5 fl.oz. (1/4 pt)
300 ml 10 fl.oz. (1/2 pt)
600 ml 20 fl.oz. (1pt)
SPOON MEASURES
1.25 ml 1/4tsp
2.5 ml 1/2tsp
5 ml 1 tsp
15 ml 1 tbsp
FLUID MEASUREMENTS
1 Cup = 8 fl.oz. = 240 ml
1 Pint = 16 fl.oz. (UK 20 fl.oz.) = 480 ml (UK 560 ml)
1 Quart = 32 fl.oz. (UK 40 fl.oz.) = 960 ml (UK 1120 ml)
1 Gallon = 128 fl.oz. (UK 160 fl.oz.) = 3840 ml (UK 4500 ml)
14
STANDING TIME
Dense foods e.g. meat, jacket potatoes and cakes,
require standing time(inside or outside of the oven) after
cooking, to allow heat to finish conducting to cook the
center completely. Wrap meat joints and jacket potatoes
in aluminium foil while standing. Meat joints need approx.
10-15 minutes, jacket potatoes 5 minutes. Other foods
such as plated meal, vegetables, fish etc require 2-5
minutes standing. After defrosting food, standing time
should also be allowed. If food is not cooked after
standing time, return to the oven and cook for additional
time.
MOISTURE CONTENT
Many fresh foods e.g. vegetables and fruit, vary in their
moisture content throughout the season, particularly
jacket potatoes. For this reason cooking times may have
to be adjusted. Dry ingredients e.g. rice, pasta, can dry
out during storage so cooking times may differ.
DENSITY
Porous airy foods heat more quickly than dense heavy
foods.
CLING FILM
Cling film helps keep the food moist and the trapped
steam assists in speeding up cooking times. Pierce
before cooking to allow excess steam to escape. Always
take care when removing cling film from a dish as the
build-up of steam will be very hot.
SHAPE
Even shapes cook evenly. Food cooks better by
microwave when in a round container rather than square.
SPACING
Foods cook more quickly and evenly if spaced apart.
NEVER pile foods on top of each other.
STARTING TEMPERATURE
The colder the food, the longer it takes to heat up. Food
from a fridge takes longer to reheat than food at room
temperature.
LIQUIDS
All liquids must be stirred before and during heating.
Water especially must be stirred before and during
heating, to avoid eruption. Do not heat liquids that have
previously been boiled. DO NOT OVERHEAT.
TURNING & STIRRING
Some foods require stirring during cooking. Meat and
poultry should be turned after half the cooking time.
ARRANGING
Individual foods e.g. chicken portions or chops, should
be placed on a dish so that the thicker parts are towards
the outside.
QUANTITY
Small quantities cook faster than large quantities, also
small meals will reheat more quickly than large portions.
PIERCING
The skin or membrane on some foods will cause steam
to build up during cooking. These foods must be pierced
or a strip of skin should be peeled off before cooking to
allow the steam to escape. Eggs, potatoes, apples,
sausages etc, will all need to be pierced before cooking.
DO NOT ATTEMPT TO BOIL EGGS IN THEIR
SHELLS.
COVERING
Cover foods with microwave cling film or a lid. Cover fish,
vegetables, casseroles, soups. Do not cover cakes,
sauces, jacket potatoes or pastry items.
COOKING TECHNIQUES
15
BEEF
Mized beef 1 lb./450g
Stew Meat 11/2lbs./675g
Loin Roast 2 lbs./900g
Patties 4 (4 oz..110g )
PORK
Loin Roast 2 lbs./900g
Spareibs 1 lb. 450g
Chops 4 (5 oz./140g)
Minced 1lb./450g
POULTRY
Whole Chicken
21/2lbs./1125g
Chicken Breasts
1lb./450g
Fryer Chicken(cut up)
2lbs./900g
Chicken Thighs
11/2lbs./675g
FISH & SEAFOOD
Whole Fish 1lb./450g
Fish Fillets 11/2lb./675g
Shrimp 1/2lb./225g
Item & Weight Defrosting Time Standing Time Special Techniques
DEFROSTING CHART
8-10 min.
13-15 min.
17-20 min.
7-9 min.
17-20 min.
8-10 min.
9-11 min.
8-10 min.
20-24 min.
8-10 min.
17-19 min.
12-15 min.
6-8 min.
11-13 min.
3-4 min.
15-20 min.
25-30 min.
45-60 min.
15-20 min.
45-60 min.
25-30 min.
25-30 min.
15-20 min.
45-90 min.
15-30 min.
25-30 min.
15-30 min.
15-20 min.
15-20 min.
10-15 min.
* The times are approximate because freezer temperatures vary.
Break apart and remove thawed portions with
fork.
Separate and rearrange once.
Turn over after half the time.
Shield as needed.
Turn over after half the time.
Turn over after half the time.
Shield as needed.
Separate and rearrange once.
Separate and turn over once.
Break apart and remove thawed portions with
fork.
Break side down. Turn over after half the
time. Shield as needed.
Separate and rearrange once.
Separate and rearrange once.
Separate and rearrange once.
Turn over after half the time.
Shield as needed.
Separate and turn over once.
Separate and rearrange once.
16
Item Power Level Cooking Time Per lb./450g
MEAT
Beef
Standing / rolled Rib - Rare P-80 6-8 min.
- Medium P-80 7-9 min.
- well done P-80 8-10 min.
Ground Beef (to brown for casserole) P-HI 4-6 min.
Hamburgers, Fresh or defrosted
(4oz. Each/100g) 2 patties P-HI 3-4 min.
4 patties P-HI 4-5 min.
Pork
Loin, Leg P-80 8-10 min.
Bacon 4 slices P-HI 3-4 min.
6 slices P-HI 4-5 min.
NOTE: The above times should be regarded only as a guide, Allow for difference in individual lasts and
preferences. The times may vary due to the shape, cut, and composition of the meat.
POULTRY
Chicken
Whole P-HI 7-9 min.
Breast(boned) P-80 6-8 min.
portions P-80 7-9 min.
Turkey
Whole P-HI 9-11 min.
NOTE : The above times should be regarded only as a guide. Allow for difference in individual tastes and
preferences. The times may vary due to the shape, cut, and composition of the food.
FRESH FISH
COOKING & REHEATING CHART
Item Power Cooking Time Method Standing
Level Per lb./450g Time
Fish Fillets P-HI 4-6 min. Add 15-30 ml(1-2 Tbsp) 5-7 min.
Whole Mackerel, P-HI 4-6 min. - 6-8 min.
Cleaned and Prepared
Whole Trout, Cleaned P-HI 5-7 min. - 6-8 min.
and Prepared
Salmon Steaks P-HI 5-7 min. Add 15-30 ml(1-2 Tbsp) 6-8 min.
ITEM POWER LEVEL Cooking Time Standing Time
Lasagna
1 serving(10 1/2 oz./300g) P-HI 6-8 min.
Place lasagna on microwaveable plate.
Cover with plastic wrap and vent.
Casserole
1 cup P-HI 2-4 min.
Cook covered in, microwaveable dish(casserole).
4 cups P-HI 7-9 min.
Stir once halfway through cooking.
Mashed potatoes
1 cup P-HI 3-5 min.
Cook covered in, microwaveable dish(casserole).
4 cups P-HI 7-9 min.
Stir once halfway through cooking.
Baked beans
1 cup P-HI 3-5 min.
Cook covered in, microwaveable dish(casserole).
Stir once halfway through cooking.
Ravioli or pasta in sauce
1 cup P-HI 4-5 min.
Cook covered in, microwaveable dish(casserole).
4 cups P-HI 8-10 min.
Stir once halfway through cooking.
Sandwich roll or bun
1 roll P-HI 20-30 sec.
Wrap in paper tower and place on glass
microwaveable rack
* Note : Do not use recycled paper towels.
17
VEGETABLE CHART
Use a suitable glass Pyrex bowl with lid. Add 30-45ml cold water(2-3 tbsp.) for every 250g unless another water
quantity is recommended - see table. Cook covered for the minimum time - see table.
Continue cooking to get the result you prefer. Stir once during and once after cooking. Add salt, herbs or butter
after cooking. Cover during a standing time of 3 minutes.
Hint : cut the fresh vegetables into even sized pieces. The smaller they are cut, the quicker they will cook.
All vegetables should be cooked using full microwave power.
Cooking Guide for frozen vegetables
Cooking Guide for fresh vegetables
Broccoli 1/2lb./250g 2-3 min
1 lb./500g 4-6 min
Brussels sprouts 1/2lb./250g 3-4 min
Carrots 1/2lb./250g 2-3 min
Cauliflower 1/2lb./250g 2-3 min
1 lb./500g 4-6 min
Courgettes 1/2lb./250g 2-3 min
Egg plants 1/2lb./250g 2-3 min
Leeks 1/2lb./250g 2-3 min
Mushrooms 0.3 lb./125g 1-2 min
1/2lb./250g 2-4 min
Onions 1/2lb./250g 2-3 min
Pepper 1/2lb./250g 2-4 min
Potatoes 1/2lb./250g 3-5 min
1 lb./500g 6-8 min
Turnip cabbage 1/2lb./250g 4-6 min
Vegetables Weight Time Comments
Prepare even sized florets.
Arrange the stems to the centre.
Add 60-75ml(5-6tbsp.) water.
Cut carrots into even sized slices.
Prepare even sized florets.
Cut big florets into halves. Arrange stems to the centre.
Cut courgettes into slices. Add 30ml(2tbsp.) water or a knob of
butter. Cook until just tender.
Cut egg plants into small slices and sprinkle with 1 tablespoon
lemon juice.
Cut leeks into thick slices.
Prepare small whole or sliced mushrooms. Do not add any
water. Sprinkle with lemon juice. Spice with salt and pepper.
Drain before serving.
Cut onions into slices or halves. Add only 15ml(1tbsp.) water.
Cut pepper into small slices.
Weigh the peeled potatoes and cut them into similar sized halves
or quarters.
Cut turnip cabbage into small cubes.
spinach 0.3 lb./125g 2-3 min
broccoli 1/2 lb./250g 3-4 min
Peas 1/2 lb./250g 2-3 min
Green beans 1/2 lb./250g 3-5 min
Mixed vegetables 1/2 lb./250g 3-5 min
(carrots/peas/corn)
Mixed vegetables 1/2 lb./250g 4-6 min
(Chinese style)
Vegetables Weight Time Instructions
Add 15ml(1tbsp.) cold water.
Add 30ml(2 tbsp.) cold water.
Add 15ml(1 tbsp.) cold water.
Add 30ml(2t tbsp.) cold water.
Add 15ml(1ttbsp.) cold water.
Add 15ml(1 tbsp.) cold water.
18
TOMATO & ORANGE SOUP
1 oz.(25g) butter
1 medium onion, chopped
1 large carrot & 1 large potato, chopped
13/4lb(800g) canned, chopped tomatoes
juice and grated rind of 1 small orange
11/2pints(900ml) hot vegetable stock
salt and pepper to taste
1. Melt the in a large bowl on P-HI for 1 minute.
2. Add the onion, carrot and potato and cook on P-HI
for 6 minutes. stir halfway through cooking.
3. Add the tomatoes, orange juice, orange rind and
stock. Mix thoroughly. Season with salt and pepper
to taste. Cover the bowl and cook on P-HI for 18
minutes. stir 2-3 times during cooking, until the
vegetables are tender.
4. Blend and serve immediately.
FRENCH ONION SOUP
1 large onions, sliced
1 tbsp (15ml) corn oil
2 oz.(50g) plain flour
2 pints(1.2 liters) hot meat
or vegetable stock
salt and pepper to taste
2 tbsp (30ml) parsley, chopped
4 thick slices French bread
2 oz.(50g) cheese, grated
1. Place the onion and oil a bowl, mix well and cook on
P-HI for 2 minutes.
2. Stir in the flour to make a paste and gradually add
stack. Season and add the parsley.
3. Cover the bowl and cook on P-70 for 20 minutes.
4. Pour the soup into serving bowls, submerge bread
and sprinkle generously with cheese.
5. Cook on P-70 for 2 minutes, until the cheese has
melted.
STIR FRIED VEGETABLES
1 tbsp(15ml) sunflower oil
2 tbsp (30ml) soy sauce
1 tbsp (15ml) sherry
1"(2.5cm) root ginger,
peeled and finely grated
2 medium carrots, cut into fine strips
4 oz.(100g) button mushrooms,
chopped
2 oz.(50g) beansprouts
4 oz.(100g) mange-tout
1 red pepper, seeded and thinly sliced
4 spring onions, chopped
4 oz.(100g) canned water chestnuts,
sliced
1/4 head of chinese leaves, thinly sliced
1. Place the oil, soy sauce, sherry, ginger, garlic and
carrots in a large bowl, mix thoroughly
2. Cover and cook on P-HI for 5-6 minutes, stirring
once.
3. Add the button mushrooms, beansprouts, mange-
tout, red pepper, spring onions, water chestnuts and
chinese leaves. Mix thoroughly.
4. Cook on P-HI for 6-7 minutes, until the vegetables
are tender. Stir 2-3 times during cooking.
Stir fried vegetables are ideally served with meat or
fish.
HONEYED CHICKEN
4 boneless chicken breasts
2 tbsp(30ml) clear honey
1 tbsp(15ml) whole grain mustard
1/2 tsp(2.5ml) dried tarragon
1 tbsp(15ml) tomato puree
1/4 pint(150ml) chicken stock
1. Place the chicken breasts in a casserole dish.
2. Mix all remaining ingredients together and pour over
the chicken. Salt and pepper to taste.
3. Cook on P-HI for 13-14 minutes. Rearrange and
coat the chicken with the sauce twice during
cooking.
RECIPES
19
BLUE CHEESE & CHIVE JACKETS
2 baking potatoes,
(approx.9 oz.(250g) each)
2 oz.(50g) butter
4 oz.(100g) blue cheese, chopped
1 tbsp(15ml) fresh chives, chopped
2 oz.(50g) mushrooms, sliced
salt and pepper to taste
1. Prick each potato in several places. Cook on P-HI for
12-13 minutes. Halve and scoop the flesh into a
bowl, add the butter, cheese, chives, mushrooms,
salt and pepper, mix thoroughly.
2. Pile mixture into the potato skins and place in a flan
dish, on the rack.
3. Cook on P-50 for 10 minutes.
WHITE SAUCE
1 oz.(25g) butter
1 oz.(25g) plain flour
1/2 pint(300ml) milk
salt and pepper to taste
1. Place the butter in a bowl and cook on P-HI for 1
minute, until melted.
2. Stir in the flour and whisk in the milk. Cook on P-HI for
4-5 minutes, stirring every 2 minutes until thick and
smooth. Season with salt and pepper to taste.
STRAWBERRY JAM
11/2 lb.(675g) strawberries, hulled
3 tbsp(45ml) lemon juice
11/2 lb.(675g) caster sugar
1. Place strawberries and lemon juice in a very large
bowl, heat on P-HI for 5 minutes, or until the fruit has
softened. Add sugar, mix well.
2. Cook on P-70 for 30-35 minutes, until setting point*is
reached, stir every 4-5 minutes.
3. Pour into hot, clean jars. Cover, seal and label.
* setting point : To determine setting point, place 1
tsp(5ml)jam onto chilled saucer. Allow to stand for 1
minute. Move surface of jam gently with your finger, if
the surface wrinkles setting point has been reached.
PLAIN MICROWAVE CAKE
4 oz.(100g) margarine
4 oz.(100g) sugar
1 eggs
4 oz.(100g) self raising flour, sifted
2-3 tbsp(30-45ml) milk
1. line the base of 8" (20.4cm) cake dish with grease-
proof paper.
2. Cream the margarine and sugar together until light
and fluffy. Beat in the eggs and fold in the sifted flour
alternately with the milk.
3. Pour into prepared container. Cook on P-HI for 4-5
minutes, until a skewer comes out cleanly.
4. Leave the cake to stand for 5 minutes before turning
out.
OMELETTS
1/2 oz.(15g) butter
4 eggs
6 tbsp(90ml) milk
salt & pepper
1. Whisk together eggs and milk.
2. Place butter in 10"(26cm) flan dish. Cook on P-HI for 1
minute, until melted. Coat the dish with the melted
butter.
3. Pour omelette mixture into flan dish. Cook on P-HI for
2 minutes. whisk mixture and cook again on P-HI for 1
minutes.
20
SCRAMBLED EGG
1/2 oz.(15g) butter
2 eggs
2 tbsp(30ml) milk
salt & pepper
1. Melt the butter in a bowl on P-HI for 1 minute.
2. Add the eggs, milk and seasoning and mix well.
3. Cook on P-HI for 3 minutes, stirring every 30 seconds.
SAVORY MINCE
1 small onion, diced
1 clove garlic, crushed
1 tsp(5ml) oil
7 oz.(200g) can chopped tomatoes
1 tbsp(15ml) tomato puree
1 tsp(5ml) mixed herbs
8 oz.(225g) minced beef
salt and pepper
1. Place onion, garlic and oil in casserole, and cook on
P-HI for 2 minutes or until soft.
2. Place all other ingredients in casserole. Stir well.
3. Cover and cook on P-HI for 5 minutes then P-50 for
10-15 minutes or until the meat is cooked.
