Wacom Intuos
®
3 User’s Manual for Windows
®
& Macintosh
®
English version 2.0, August 26, 2005
Copyright
©
WACOM Company, Limited, 2005
All rights reserved. No part of this manual may be reproduced except for your express personal use. Wacom reserves
the right to revise this publication without obligation to provide notification of such changes. Wacom does its best to
provide current and accurate information in this manual. However, Wacom reserves the right to change any
specifications and product configurations at its discretion, without prior notice and without obligation to include such
changes in this manual.
Reuse, recycling, and recovery.
You are urged to recycle this product when replacing it with a newer
product or when it has outlived its useful life by bringing it to an appropriate collection point for recyclable materials in
your community or region. By doing this, you can help improve the environment of your community as well as minimize
the potential negative effects created should any hazardous substance that may possibly be present within waste
material reach the environment during the disposal process.
Within the European Union, users are required not to dispose of Waste Electrical and Electronic Equipment (WEEE)
as unsorted municipal waste, according to the Directive 2002/96/EC of the European Parliament and of the Council of
27 January 2003, or the corresponding local laws of the Member States. Products for which this is applicable will be
marked with the WEEE symbol shown at the beginning of this note unless this is not feasible because of the size or the
function of the product. Wacom products are subject to the Directive 2002/96/EC and therefore you should always
collect them separately and bring them to the appropriate collection point in your community or region.
Tool ID, QuickPoint, and DuoSwitch are trademarks, and Intuos, Penabled, and Wacom are registered trademarks of
WACOM Company, Limited.
Adobe, Reader, and Photoshop are either registered trademarks or trademarks of Adobe Systems Incorporated in the
United States and/or other countries. Microsoft and Windows are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries. Apple, the Apple logo, and Macintosh are registered
trademarks of Apple Computer, Inc., registered in the U.S. and other countries. Any additional company and product
names mentioned in this documentation may be trademarked and/or registered as trademarks. Mention of third-party
products is for information purposes only and constitutes neither an endorsement nor a recommendation. Wacom
assumes no responsibility with regard to the performance or use of these products.
ExpressKey is a registered trademark of Ginsan Industries, Inc., and is used with permission.
Watch for the Penabled logo to ensure you
are getting the natural feel and superior
performance of Wacom’s patented cordless
and battery-free pen technology.
I
NDEX
C
ONTENTS
I
NDEX
C
ONTENTS
3
3
CONTENTS
About the manual 5
Navigating the manual 6
WORKING WITH INTUOS3 7
Intuos3 tablet features 8
Intuos3 input tools 9
Intuos3 optional tools 10
Setting up your work area 11
Using the Grip Pen 12
Holding the pen 12
Pointing 13
Clicking 14
Dragging 14
Using the side switch 15
Drawing with pressure-sensitivity 16
Drawing with tilt 16
Erasing 17
Eye-hand coordination exercise 18
Using the mouse 19
Using the Airbrush and Art Pen 20
Working with the tablet 21
Using ExpressKeys 22
Using the Touch Strips 23
CUSTOMIZING 24
Opening the control panel 24
Control panel overview 25
Control panel settings 26
Customizing the pen 27
Adjusting tip feel and double-click 28
Adjusting eraser feel 29
Advanced tip and eraser pressure settings 30
Customizing tool buttons 31
Button functions 32
Customizing tilt sensitivity 35
Customizing the mouse 36
Customizing mouse buttons 36
Customizing the mouse fingerwheel 37
Tablet to screen mapping 38
Pen mode 38
Mouse mode 39
Orientation 39
Screen area 40
Force proportions 41
Tablet area 42
Mapping to multiple monitors 43
Customizing the tablet functions 44
Customizing ExpressKeys 45
Customizing tablet Touch Strips 46
Advanced Touch Strip settings 49
Customizing the Pop-up Menu 50
Working with multiple tools 51
Working with application-specific settings 52
Creating an application-specific setting 53
Changing settings for a specific tool
and application 54
Removing application-specific settings 54
TROUBLESHOOTING 55
Testing your tablet 56
Testing your tools 57
Testing the ExpressKeys 58
Testing the tablet Touch Strips 58
Testing a pen 59
Testing a mouse 60
Troubleshooting tables 61
General problems 61
Windows-specific problems 64
Macintosh-specific problems 64
C
ONTENTS
I
NDEX
C
ONTENTS
I
NDEX
C
ONTENTS
4
4
Technical support options 65
Obtaining driver downloads 66
APPENDIX 67
Caring for your tablet and tools 67
Replacing the pen tip 68
Uninstalling the software 68
Changing the tablet mode 69
Installing multiple tablets 69
Intuos3 lens cursor 70
Customizing the lens cursor 71
Testing the lens cursor 71
Working with AutoCAD 72
Configuring AutoCAD for a Wintab
compatible digitizer 72
Configuring tablet menus and screen pointing
areas in AutoCAD 73
Calibrating Intuos3 for AutoCAD 74
Product specifications 75
General specifications for all Intuos3 tablets 75
Intuos3 4x5 / A6 tablet (model PTZ-430) 75
Intuos3 6x8 / A5 tablet (model PTZ-630) 75
Intuos3 6x11 / A5 Wide tablet
(model PTZ-631W) 75
Intuos3 9x12 / A4-regular tablet
(model PTZ-930) 76
Intuos3 12x12 / A4 Oversize tablet
(model PTZ-1230) 76
Intuos3 12x19 / A3 Wide tablet
(model PTZ-1231W) 76
Intuos3 Grip Pen (model ZP-501E) 76
Intuos3 mouse (model ZC-100) 76
Intuos3 Airbrush (model ZP-400E) 76
Intuos3 Ink Pen (model ZP-130) 77
Intuos3 Art Pen (model ZP-600) 77
Intuos3 Classic Pen (model ZP-300E) 77
Intuos3 lens cursor (model ZC-210) 77
Product information 78
Ordering parts and accessories 78
Other parts and accessories 80
Radio and television interference 81
FCC notice 81
CE declaration 81
License and Warranties
(Worldwide, Except for Europe, Africa
and Middle East) 82
Software License 82
Limited Warranty (U.S.A. and Canada) 82
Warranty Service in the U.S.A. and Canada 83
Warranty on Sales Outside of U.S.A.
and Canada 84
License and Warranty
(Europe, Africa and Middle East) 85
Software License Agreement 85
Entitlement to Use the Software 85
Limited Warranty 85
GLOSSARY 87
INDEX 89
I
NDEX
C
ONTENTS
I
NDEX
C
ONTENTS
5
5
About the manual
This interactive User’s Manual provides quick access to information about Intuos3. Just click on a navigation
button or highlighted word to move through the document. The information is common to Windows and
Macintosh computers, and Windows screen captures are shown unless otherwise noted.
• In the contents you can go directly to a topic by clicking on it.
•Working with Intuos3 is the learning chapter, and introduces you to the many capabilities of your Intuos3
pen tablet. It describes the various tablet models, the features and functions of each Intuos3 tool, and
includes exercises for new users.
•Customizing describes how you can change the control panel settings to optimize your Intuos3 tablet
and tools for the way you like to work.
• Want to test your tablet and tools? Need troubleshooting guidelines? Troubleshooting is where you will
find the answers to most common questions.
• The appendix includes a variety of information: tips on caring for your tablet and tools, a how-to on
uninstalling the software, your license and warranty, and more. Also included are tips on working with
AutoCAD. If you are using more than one tablet on your computer, you will find instructions on adding
and working with multiple tablets.
Note:
This manual does not contain information on installing your tablet. Please refer to your product Quick
Start Guide and to the automated software installer (located on the Wacom Tablet CD) for details on
installing your Wacom tablet.
If you are new to electronic documentation, be sure to read navigating the manual.
Here are some other points to keep in mind:
• The tablet size descriptions shown within this manual reflect usage for both the USA and European
markets, and are separated by a “/ “. For example, in the descriptor “4x5 / A6”, “4x5” is the tablet sizing
descriptor for markets in the USA. “A6” is the descriptor for European markets. Within this manual, USA
tablet size descriptors are always shown before the “/ “.
•S
MALL
CAPITAL
LETTERS
are used to identify the names of keyboard keys, dialog boxes, and control panel
options.
• Remember that you can always use the Adobe Reader zoom-in tool to increase the size of the manual
on your display screen.
• The following kinds of information are not included with this product: information about your specific
computer hardware or operating system, or information about your application software. Your best
source for this information is the set of manuals and disks that came with your hardware, operating
system, or application.
• Many graphics applications have built-in support for Intuos3 features (such as pressure-sensitivity, tilt,
airbrush simulation, and fingerwheel input for the Intuos3 mouse). You can find a listing of applications
that support these features at Wacom’s web site (see product information). For information on how best
to use Intuos3 features within a specific application, refer to the instructions in that application’s
manuals.
I
NDEX
C
ONTENTS
I
NDEX
C
ONTENTS
6
6
Navigating the manual
Use the navigation controls to move through the manual:
Go to front page.
Go to table of contents.
Go to index.
Go back to previous view.
Page back, or page forward.
Go to beginning of section.
Go to topic.
Topic continued.
Adobe Reader provides you with additional tools for using and printing the manual. Refer to the Adobe
Reader help for more information.
CONTENTS
INDEX
HEADING TEXT
topic
I
NDEX
C
ONTENTS
I
NDEX
C
ONTENTS
7
7
WORKING WITH INTUOS3
This section introduces you to the Intuos3 professional pen tablet. Intuos3 consists of a tablet that serves as
your work area and the Intuos3 input tools you use on the tablet. The quickest way to learn about Intuos3 is
to become familiar with its appearance and features. If you are new to using a pen tablet, read the following
sections to learn about your Intuos3 tools and how to use them with the tablet.
Note:
Intuos3 tools will only work on an Intuos3 tablet. They will not work on an Intuos or Intuos2 series
tablet. Likewise, older Intuos or Intuos2 input tools will not work on your Intuos3 tablet.
Intuos3 tablet features
Intuos3 input tools
Setting up your work area
Using the Grip Pen
Using the mouse
Using the Airbrush and Art Pen
Working with the tablet
W
ORKING
WITH
I
NTUOS
3
I
NDEX
C
ONTENTS
I
NDEX
C
ONTENTS
8
8
Intuos3 tablet features
Note: Intuos3 6x8 / A5 tablet shown. To learn more about your
tablet, see working with the tablet. For a complete listing of Intuos3
tablets, see ordering parts and accessories.
Touch Strip controls.
Note: 4x5 / A6 tablet
models come equipped
with ExpressKeys and a
single Touch Strip
located to the left of the
tablet’s active area.
Status LED.
Tablet work surface.
Identifies the tablet
active area.
Cable.
Recessed cable
tracks on the back
of the tablet allow
the cable to exit
the top or left of
the tablet.
Pen stand.
Customizable
ExpressKeys.
W
ORKING
WITH
I
NTUOS
3
I
NDEX
C
ONTENTS
I
NDEX
C
ONTENTS
9
9
Intuos3 input tools
Various input tools are available for your tablet. All Intuos3 tools are cordless, batteryless, and
ergonomically designed. Each tool also features a unique Tool ID, which enables you to work with multiple
tools and to customize each tool differently.
The Intuos3 Grip Pen is a pressure-sensitive freehand tool for image editing and creating natural-looking
pen and brush strokes.
If you prefer to use a mouse for general navigation, pointing, and clicking, just set aside your Intuos3 pen
and place the Intuos3 mouse on the tablet – the mouse is cordless and symmetrically designed so you can
use it just as easily in your left or right hand.
Eraser.
Replaceable nib
(standard or stroke tip).
DuoSwitch (rocker style).
Intuos3 Grip Pen.
Rubberized
grip area.
Intuos3 mouse.
Programmable buttons can be
customized for the way you like to work.
Fingerwheel. An integrated
middle button and rolling
wheel that can be used for
up and down scrolling in the
active window. It can also
be customized to perform a
variety of button functions.
Note: Some product configurations may not include the Intuos3 mouse.
W
ORKING
WITH
I
NTUOS
3
I
NDEX
C
ONTENTS
I
NDEX
C
ONTENTS
10
10
Intuos3 optional tools
Like the Intuos3 Grip Pen, the optional Airbrush is a pressure-sensitive freehand tool for image editing and
creating natural-looking pen and brush strokes.
For information on these and other available Intuos3 tablets, tools, or parts and accessories, see ordering
parts and accessories. Visit Wacom’s web site for a list of applications supporting the Art Pen rotation and
Airbrush fingerwheel features. See product information.
Intuos3 Airbrush (optional accessory).
Eraser.
Replaceable nib.
Side switch.
Fingerwheel.
Replaceable nib
(standard or inking tip).
Intuos3 Ink Pen (optional accessory).
The Ink Pen is pressure-sensitive and comes with
replaceable inking cartridges. With the Ink Pen you
can write or draw as you do with a regular pen – just
place a sheet of paper on your tablet and everything
you write will be captured on paper and on your
computer.
Intuos3 Art Pen (optional accessory).
The pressure-sensitive Art Pen also responds to the tilt and rotation you
apply to the pen. With practice you can create almost any type of brush
effect or marker stroke. The Art Pen comes with chisel-shaped nibs in both
hard plastic and felt material for simulating different pen and brush feels.
W
ORKING
WITH
I
NTUOS
3
I
NDEX
C
ONTENTS
I
NDEX
C
ONTENTS
11
11
Setting up your work area
To minimize fatigue, organize your work area so you can work comfortably. Position your tablet, input tools,
and keyboard so they are easily accessible without unnecessary reaching. Your monitor should be
positioned so you can view it comfortably with a minimum of eyestrain. For best results, orient the tablet so
the screen cursor follows the same direction as your hand movements on the tablet.
Note:
Wacom makes no representation, promise or guarantee that Wacom products will cure or prevent, in
whole or in part, mouse-induced repetitive stress symptoms, injuries or conditions. Individual results may
vary. Always obtain competent medical advice to determine the most appropriate treatment for your specific
situation.
See working with the tablet for additional information.
Here are some other points to keep
in mind:
• Take short breaks between
tasks to stretch and relax your
muscles.
• Use a gentle grip when working
with your tools.
• Alternate tasks and tools
throughout the day.
• Maintain a good posture at all
times. Minimize awkward
postures and repetitive
movements that cause
discomfort.
• Change your position if you feel
any discomfort due to your work
position.
W
ORKING
WITH
I
NTUOS
3
I
NDEX
C
ONTENTS
I
NDEX
CONTENTS 12
12
Using the Grip Pen
The Intuos3 Grip Pen is cordless, batteryless, and pressure sensitive. There are four basic techniques for
using the pen: pointing, clicking, double-clicking, and dragging. With a bit of practice, using the pen will
become second nature to you. If you are unfamiliar with using the pen, try the exercises on the following
pages.
Holding the pen
Pointing
Clicking
Dragging
Using the side switch
Drawing with pressure-sensitivity
Drawing with tilt
Erasing
Eye-hand coordination exercise
Holding the pen
Hold the Intuos3 pen like you would a normal pen or pencil. Make sure the DuoSwitch is in a convenient
location where you can toggle it with your thumb or forefinger, but not accidently press the switch while
drawing. You can tilt the pen in any way that feels most comfortable for drawing.
Position for drawing. Position for erasing.
Your tablet comes with a free-standing pen stand that is used to
hold your pen when it is not in use. Position the pen stand within
easy reach of your tablet. When you are between tasks, store the
pen either horizontally or vertically in the pen stand; this makes the
pen available for quick, easy access when you are working.
Important: When the Intuos3 pen is not in use, place it in
the pen stand or lay it flat on your desk. To maintain the
sensitivity of your pen tip, do not store the pen in a container
where it will rest on its tip or eraser. Leaving an Intuos3 tool
on the tablet may interfere with screen cursor positioning
when using other pointing devices. Also, leaving the pen on
the tablet when not in use can prevent your computer from
going to sleep.
WORKING WITH INTUOS3
INDEX
CONTENTS
INDEX
CONTENTS 13
13
Pointing
The Intuos3 pen positions the pointer (or cursor) on your screen. You can position the screen cursor two
different ways, like a pen (PEN mode) or like a mouse (MOUSE mode).
• In PEN mode, the tablet’s active area is a mapped representation of your computer screen where every
point on the active area corresponds to exactly one point on the display screen; wherever you place the
pen on the tablet, the screen cursor will jump to the corresponding point on the screen. This is the
default setting for the pen.
• In MOUSE mode, the default setting for the Intuos3 mouse, you move the cursor with a “pick up and slide”
action similar to using a traditional mouse.
Try moving the screen cursor by lifting the pen and
placing the pen tip in a new location on the tablet.
The cursor instantly jumps to the new location.
6 mm (0.25 inch)
Hints:
• If you are used to working with a mouse and find that using a pen is somewhat difficult,
try the eye-hand coordination exercise.
• Pointing is easier when you orient the tablet so the screen cursor follows the same
direction as your hand movements on the tablet.
When positioning the screen cursor and operating the side
switch, the pen tip needs to be within 6 mm (0.25 inch) of
the tablet surface. You do not need to touch the tablet with
the pen tip in order to move the screen cursor or use the
side switch.
All Intuos3 tools, including the mouse, work only over the
active area of the tablet.
WORKING WITH INTUOS3
INDEX
CONTENTS
INDEX
CONTENTS 14
14
Clicking
You typically click to highlight or select something on the screen, and double-click to open it.
Clicking. To click, tap the pen tip once on the tablet, or press the pen tip on the tablet with enough force to
register a click. (There is no audible pen tip “click” sound.) Try clicking on a folder icon by moving the screen
cursor over the icon and pressing down on the pen tip. The folder should highlight when you press.
Double clicking. To double-click, quickly tap the tablet twice in the same place with the pen tip. This is like
clicking twice with a mouse button. Try double-clicking on a folder icon to open it.
Dragging
Dragging is used to select and move objects on the screen. To drag, first point to an object. Then press the
pen tip to the tablet and slide it across the tablet surface. The selected object will move across the screen.
To select text, move the screen cursor to the beginning of a text line, then drag the pen across the tablet until
the text is highlighted.
Hints:
• Press the upper side switch to double-click. This is easier than
tapping twice with the pen tip, and is the preferred method of
double-clicking with a pen.
•Windows: You can make navigating with the pen easier by
configuring Windows to select when the pen is over an icon and
to launch the icon with a single click. To turn on this feature:
Open a folder, select the TOOLS pull-down menu, and FOLDER
OPTIONS.... From the GENERAL tab select the option SINGLE-
CLICK TO OPEN AN ITEM (POINT TO SELECT).
First, try moving an icon on the screen. Then, within a
document, select some text by pressing and dragging
the pen tip across the text.
WORKING WITH INTUOS3
INDEX
CONTENTS
INDEX
CONTENTS 15
15
Using the side switch
The Intuos3 Grip Pen is equipped with a DuoSwitch. This switch has two programmable functions that can
be selected by rocking the switch in either direction. You can use the DuoSwitch whenever the pen tip is
within 6 mm (0.25 inch) of the tablet’s active area. You do not have to touch the pen tip to the tablet in order
to use the switch.
To assign new switch functions, see customizing tool buttons.
Hint:
• Press the upper side switch to double-click. This is easier than tapping twice with the
pen tip.
• Use a right-click to bring up application-specific or icon-specific menus.
Note: The DuoSwitch on the Grip Pen can be removed if you do not need the switch
functionality. See other parts and accessories for information on ordering an alternate pen
grip for use with the side switch removed.
The upper switch position is set to DOUBLE CLICK, and
the lower switch is set to RIGHT CLICK by default.
WORKING WITH INTUOS3
INDEX
CONTENTS
INDEX
CONTENTS 16
16
Drawing with pressure-sensitivity
The Intuos3 pen responds to the nuance and inflection of your hand movements, enabling you to create
natural-looking pen and brush strokes. Many graphics applications have drawing tools that respond to the
pressure you place on the pen. For example, in some drawing programs sliders are used to vary brush
characteristics (width, color, and opacity). These characteristics can be controlled much better by the pen’s
pressure-sensitivity – you can vary line width, blend colors, and change opacity with the pressure you exert
upon the pen.
Drawing with tilt
As with pressure-sensitivity, the tablet recognizes when you tilt the pen from vertical to inclined positions.
In some drawing applications, tilt can be used to control line shape and thickness. This is like working with
an airbrush where tilt can be used to make a line thin when the tool is vertical, or wide when the tool is tilted.
In other applications, you can adjust tilt to define brush characteristics such as width, color and opacity.
To adjust the amount of pen tilt required to produce a desired tilt effect in your application, see customizing
tilt sensitivity. Visit our web site for a list of applications that support tilt. See product information.
To draw with pressure-sensitivity, first select a pressure-
sensitive tool from your application’s tool palette. Then draw
along the surface of the tablet while applying various amounts
of pressure downward on the tip of the pen. Press hard for
thick lines or dense color. Press gently for thin lines or softer
color. To adjust the tip feel, see adjusting tip feel and double-
click.
Visit our web site for a list of graphics applications that support
pressure. See product information.
To test tilt, draw a curve in a graphics application (such as
Painter) that supports tilt. Be sure that the tilt function in
your application is active, then change the tilt of the pen as
you draw to vary the shape and thickness of the brush
stroke.
As an example, when the brush shape dynamics in
Photoshop have been configured for tilt operation, tilting
the pen results in an elongated pattern. This simulates
the effects of an airbrush spray that is angled away from
the paint surface.
WORKING WITH INTUOS3
INDEX
CONTENTS
INDEX
CONTENTS 17
17
Erasing
The eraser on the Intuos3 pen works like the eraser on a pencil. In graphics applications that support the
pen’s eraser, you can erase intuitively and naturally. When you use the pen’s eraser, the application will
automatically switch to the eraser tool. In applications that support pressure-sensitivity, you can select
pressure-sensitive tools in an application’s tool palette to vary the width and depth of your erasures as you
change the amount of pressure you exert upon the pen.
For Windows, you can also use the eraser in many standard office applications. The eraser will not be
pressure sensitive in these applications, but you can use it to select and delete text or spreadsheet cells.
For information on customizing your eraser, see adjusting eraser feel.
Visit our web site for a list of graphics applications that support the eraser (see product information). If the
eraser is not supported in an application, you can still use the eraser for navigating and drawing.
WORKING WITH INTUOS3
INDEX
CONTENTS
INDEX
CONTENTS 18
18
Eye-hand coordination exercise
If you use a mouse, you may remember how long it took to get used to positioning the screen cursor.
Your Intuos3 Grip Pen, likewise, will take a bit of practice to master the technique of positioning the screen
cursor in PEN mode. This may seem difficult at first, but it is more natural and faster than in MOUSE mode.
This exercise is designed to retrain your eye-hand coordination for using the pen:
1. Open any graphics application. Use the line tool to draw a rectangular grid with line spacings of about
20-25 mm (3/4 to 1 inch). You can use your traditional mouse to do this.
2. Choose a free-hand tool in your application and use the pen to draw a dot at each grid intersection.
3. Draw an X at each grid intersection.
4. Now draw a circle around each intersection. Your screen should look like this:
5. Clear your screen and make a simple drawing of your own. The more you use your Intuos3 pen, the
easier drawing and navigation will become.
WORKING WITH INTUOS3
INDEX
CONTENTS
INDEX
CONTENTS 19
19
Using the mouse
The Intuos3 mouse is a cordless, batteryless, maintenance-free mouse that works on any Intuos3 tablet.
Important: When the Intuos3 mouse is not in use, place it on your desk. Leaving an Intuos3 tool on
the tablet may interfere with screen cursor positioning when using other pointing devices, or may
prevent your computer from going to sleep.
To learn how to adjust the mouse behavior for your preferences, see customizing the mouse.
The left button is set to CLICK by default, and
is the primary button used for selecting.
The right button is set to RIGHT
CLICK by default, and displays
a context menu when pressed.
The left and right side buttons are set for BACK and
FORWARD functionality within your Internet browser.
The fingerwheel can be rolled, or pressed down for an
additional button function.
•Rolling. By default, rolling the fingerwheel will scroll in
most windows and applications. Move the fingerwheel
forward to scroll up, and back to scroll down. You can also
set the fingerwheel to issue a custom keystroke for each
notch of wheel movement. This is useful when working
with repetitive functions, such as zooming in Photoshop or
moving forward and backward within your Internet
browser.
•Wheel button. Press down on the wheel to perform a
button click. The wheel button is set to middle-click by
default. Hint: For MS Office applications that support
a wheel mouse, press the CTRL key and move
the fingerwheel to zoom in and out.
Note: Some product configurations may not include the Intuos3 mouse.
WORKING WITH INTUOS3
INDEX
CONTENTS
INDEX
CONTENTS 20
20
Using the Airbrush and Art Pen
The optional Intuos3 Airbrush works like the pen, but also includes a fingerwheel for an additional degree of
control. With proper software support, you can simulate realistic airbrushing. For example, tilting the
Airbrush can cause the spray pattern to elongate and feather out. Rolling the fingerwheel can adjust the
spray intensity, and pressure on the tip can control the brush size.
All other functions work similarly to the pen. For additional information, see using the Grip Pen.
Important: When the Airbrush is not in use, lay it flat on your desk. To maintain the sensitivity of
your Airbrush tip, do not store the Airbrush in a container where it will rest on its tip. Leaving an
Intuos3 tool on the tablet may interfere with screen cursor positioning when using other pointing
devices.
Hold the Airbrush with your thumb and middle finger. The fingerwheel should be in a convenient location for
you to roll it with your index finger. Tilt the Airbrush to find a comfortable position that allows you to paint and
draw with pressure-sensitivity.
The optional Intuos3 Art Pen responds to the pressure, tilt, and rotation you apply to the pen.
Visit Wacom’s web site to learn where to purchase an Intuos3 Airbrush or Art Pen, and which applications
currently support the Airbrush fingerwheel or Art Pen rotation. See product information.
Roll the fingerwheel backwards to increase ink flow
or brush size, and forward to reduce it.
Your index finger should operate the wheel
independently of the pressure you apply to the tip.
For Windows, the side switch is set for a RIGHT CLICK by
default. For Macintosh, the switch is set for DOUBLE CLICK.
The Art Pen supports 360 degrees of rotation around the pen axis. As you
draw within an application that supports rotation-sensitivity, simply twist
the Art Pen to create lines that narrow or broaden. For example, while
painting you can vary the rotation of a non-circular brush to change the
stroke thickness.
Depending on the brush shape characteristics you have selected in your
application, you can simulate calligraphy pens, broad felt tip markers, and
any other non-circular brushes or tools.
Be sure to see the Intuos3 Tips and Tricks located on the Wacom Tablet
CD for more information on using the Art Pen.
WORKING WITH INTUOS3
INDEX
CONTENTS
INDEX
CONTENTS 21
21
Working with the tablet
The middle area of the Intuos3 tablet is the working, or active, area for the pen and mouse. Rest your hand
on the tablet and then work with the pen on the active area of the tablet just as if you were using a ball point
pen on a piece of paper. Wherever you place your pen on the tablet active area, the screen cursor will jump
to the corresponding point on the screen. See using the Grip Pen and using the mouse for more information
about using your input devices on the tablet.
To speed up your workflow in graphics and other applications, all Intuos3 tablets feature ExpressKeys and
Touch Strip(s) located next to the tablet’s active area. While using the pen with your dominant hand on the
active area, you can simultaneously use your other hand to operate the ExpressKeys or Touch Strip.
For example, you can change the properties of your tool without removing your hands from the Intuos3
tablet. (Note that 4x5 / A6 tablet models come with ExpressKeys and a single Touch Strip located to the left
of the tablet’s active area.)
ExpressKeys. Press the customizable
ExpressKeys to perform frequently used
functions or keystrokes. By default, the
keys emulate keyboard modifier keys.
In Photoshop, this provides quick access
to the grabber hand and alternate tools.
6x8 / A5 tablet shown.
Touch Strip. Slide your finger over the Touch Strips to zoom,
scroll, or perform custom keystroke actions. By default, the
Touch Strips enable you to zoom in most graphics applications
and to scroll in other applications. You can also set them to
issue custom keystrokes. For example, you might set a Touch
Strip function to change brush sizes when working in
Photoshop.
ExpressKeys.
Touch Strip.
WORKING WITH INTUOS3
INDEX
CONTENTS
INDEX
CONTENTS 22
22
Using ExpressKeys
Press the ExpressKeys with your secondary hand to toggle between tools or change tool properties while
you are using your primary hand to work with your pen on the Intuos3 tablet. The default settings were
chosen to optimize your workflow in Photoshop and other graphics applications, using the following modifier
keys:
Button 1: CTRL modifier key for Windows. COMMAND (Apple key) for Macintosh.
Button 2: SHIFT modifier key.
Button 3: ALT modifier key for Windows. OPTION modifier key for Macintosh.
Button 4: SPACE key (spacebar).
The ExpressKeys are fully customizable, enabling you to make the best possible use of them. You may want
to consider the following ways of working with the ExpressKeys:
• Set a pair of keys to commonly used keystrokes, such as [ and ] to decrease and increase your brush
size in Photoshop.
• Set a key to a commonly used keyboard shortcut in order to open files or start an application.
• If you prefer not to (or cannot) use the side switches on your Intuos3 pen, then set a key to right- or
double-click.
• Choose from any of the other available functions.
See customizing ExpressKeys for more details on the available key settings.
If you require different key functions in different applications, you can easily set up application-specific
settings for the tablet controls. See creating an application-specific setting for more information.
6x8 / A5 tablet shown.
2
31
4
2
3
4
1
The ExpressKeys are chordable. For example, pressing keys 3 and 1 together
simulates ALT+CTRL in Windows, or OPTION+COMMAND on Macintosh systems.
Tips:
• In Photoshop, pressing the spacebar (key 4 on your Intuos3 tablet) switches the
currently selected tool to the hand tool and lets you pan (move) the image within
the application window.
• In Photoshop and many other graphics applications, the ALT, CTRL, and SHIFT
modifier keys modify a tool or switch to a complementary tool while the modifier
key is pressed.
WORKING WITH INTUOS3
INDEX
CONTENTS
INDEX
CONTENTS 23
23
Using the Touch Strips
Slide your finger over the Touch Strip to quickly zoom in or out, scroll up or down, or perform other functions
with your secondary hand while using your dominant hand to work with your pen or mouse. You can also set
each Touch Strip to issue custom keystrokes. For example, you might set a Touch Strip action to cycle
through layers when working in Photoshop. You can use the Touch Strips in three different ways:
•Standard operation: Slide your finger up or down to zoom, scroll, or issue the assigned keystroke
function.
•Continuous operation: Press and hold your finger at either end of the Touch Strip to continuously
scroll. This is useful for scrolling through long documents or web pages.
•Single step operation: Press and release your finger at either end of the Touch Strip to zoom, scroll, or
issue the assigned keystroke function one step at a time.
By default, the Touch Strips enable you to zoom in most graphics applications and to scroll in other
applications. Each Touch Strip can be independently customized to meet your needs.
Tip: Photoshop users who frequently change brush sizes may want to assign the [ and ] keys to a Touch
Strip. Sliding your finger up or down the Touch Strip will then change the brush size without the need to
reach for the keyboard or access the Photoshop BRUSHES palette.
See customizing tablet Touch Strips and advanced Touch Strip settings if you would like to customize the
way your tablet Touch Strip(s) work.
6x8 / A5 tablet shown.
To use the tip of your Intuos3 pen to operate the Touch Strip, rest the pen tip against
the edge of the Touch Strip adjacent to the tablet’s active area. Then press hard
enough to issue a click and move the pen tip up or down along the Touch Strip edge.
(Only the inside edge of the Touch Strip responds to pen input.)
Press and hold here for
continuous operation, or
press and release for
single step operation.
INDEX
CONTENTS
INDEX
CONTENTS 24
24
CUSTOMIZING
After you master the basics of using your Intuos3 professional pen tablet, you may want to customize the
way Intuos3 works. This chapter describes how to use the Wacom Tablet control panel to adjust your
Intuos3 tablet and tool settings.
Advanced users can learn how to further optimize Intuos3 by creating application-specific settings.
Opening the control panel
Control panel overview
Control panel settings
Opening the control panel
To open the control panel, use the Intuos3 tool you wish to customize on the tablet:
•Windows. Click on the Windows START button and choose ALL PROGRAMS. (For Windows 2000, choose
the PROGRAMS group.) Then select WACOM TABLET and choose the WACOM TABLET PROPERTIES option.
•Macintosh. Open SYSTEM PREFERENCES from either the Dock, the Apple menu, or from the
APPLICATIONS folder. Then double-click on the WACOM TABLET icon.
After you have opened the Wacom Tablet control panel, you can begin customizing Intuos3.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 25
25
Control panel overview
Use the Wacom Tablet control panel to customize Intuos3.
As you explore the control panel, experiment with different settings to find what works best for you.
Any changes you make will take effect immediately, but you can always click DEFAULT to return a tab to the
factory settings. See control panel settings for more information on the features and functions of each tab.
Tool Tips are available for most control panel items. Simply position the screen cursor over an item and let it
rest there; in a few moments the Tool Tip will pop up.
Additionally, your keyboard tab and arrow keys can be used to navigate the control panel.
Tabs display
customizable settings
for the selected tool.
Displays a dialog
box containing
information about
the tablet and tablet
software, including
an option to access
the DIAGNOSTICS
dialog box.
The DEFAULT button
resets the selected
tab to its default
settings.
The upper portion of the control panel displays icons representing your
TABLET, TOOLs, and the APPLICATIONs with customized tool settings.
Choose FUNCTIONS to
customize your tablet
control and Pop-up
Menu settings.
Choose PEN to
customize your
Intuos3 pen settings.
Choose MOUSE to
customize your
Intuos3 mouse
settings.
Displays advanced options. Displays this User’s Manual.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 26
26
Control panel lists and tabs: The control panel TABLET, TOOL, and APPLICATION lists allow you to select the
tablet, tool, or application for which you want to change settings. To change tool settings, open the control
panel using the tool you wish to customize. The tool will be automatically selected in the TOOL list, and the
appropriate tabs will be displayed. To customize settings for a different tool, select it from the TOOL list by
clicking on its icon (the appropriate tabs will be displayed). See customizing the pen, customizing the
mouse, and customizing the tablet functions for more information.
Note: The control panel APPLICATION list is for advanced users; it is not necessary to select or add
applications in order to customize your Intuos3 tool(s).
Control panel settings
Use these sections as a reference when working with the Wacom Tablet control panel; they provide detailed
information about each tab and some of the more complex topics. Many of the sections also contain useful
customizing tips.
Customizing the pen
Customizing the mouse
Tablet to screen mapping
Customizing the tablet functions
Customizing the Pop-up Menu
Working with multiple tools
Working with application-specific settings
The TABLET list displays an icon for any
supported tablet that has been installed on
your system. All settings shown below this
list apply to the selected tablet.
The TOOL list displays an icon for the tablet
FUNCTIONS, and for each Intuos3 tool that has
been used on the tablet. When a new tool is
first used on the tablet it is automatically
added to the tool list, and functions with the
default settings. See also working with
multiple tools.
The APPLICATION list lets you define tool
settings that only apply to a specific
application. See working with application-
specific settings.
Your current selections are highlighted.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 27
27
Customizing the pen
Customizing your Intuos3 pen is easy. First open the Wacom Tablet control panel using the pen. The pen
will be selected in the TOOL list and the appropriate tabs will be displayed. Select a tab and choose from the
available options.
Adjusting eraser feel
Adjusting tip feel and double-click
Customizing tilt sensitivity
Customizing tool buttons
Tablet to screen mapping
Working with application-specific settings
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 28
28
Adjusting tip feel and double-click
To adjust the tip sensitivity of your Intuos3 pen, select the PEN tab. To create broad brush strokes or to click
with a light touch, use a soft tip setting. For maximum control while drawing thin lines, use a firm tip setting.
Customizes the amount of pressure
needed to click or draw. Drag the
slider to a softer or firmer setting.
Press down on the tablet with your
pen tip to test the current tip feel
setting. You can use the CURRENT
PRESSURE bar to determine how
hard you must press on the pen to
reach maximum pressure.
Displays the tip FEEL DETAILS dialog
box where you can further
customize the tip sensitivity.
Hints:
• Use a soft TIP FEEL for a wider range of pressure values with most pressure-sensitive
applications.
• In some applications a soft pressure setting can make the pen overreact – any small
press on the pen is magnified on the screen. If you experience this, try a firmer TIP
FEEL setting.
• Double-clicking: To make double-clicking easier, expand the tap area that accepts a
double-click (the double-click distance).
Note: A large double-click distance may cause a delay at the beginning of your
brushstrokes in some drawing applications. If you notice such effects, try setting a
smaller double-click distance and using the side switch to double-click (see using the
side switch). You can also set one of the ExpressKeys to double-click.
Returns the tab settings
to their factory default
conditions.
Adjusts the size of the double-click area.
A larger setting makes double-clicking
easier.
Drag the slider to the OFF position if you
do not want double-click assist.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 29
29
Adjusting eraser feel
To adjust the eraser sensitivity of your Intuos3 pen, select the ERASER tab. To erase with a broad stroke or to
click with a light touch, use a soft eraser setting. For maximum control while erasing, use a firm eraser
setting.
Select the button functions to
perform when using the eraser.
Returns the tab
settings to their factory
default conditions.
Customizes the amount of pressure
needed to erase. Drag the slider to a
softer or firmer setting.
Displays the eraser FEEL DETAILS
dialog box where you can further
customize the eraser sensitivity.
With your screen cursor positioned
over an empty area of your desktop,
press down on the tablet with your
tool’s eraser to test the current
eraser feel setting. You can use the
CURRENT PRESSURE bar to
determine how hard you must press
on the eraser to reach maximum
pressure.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 30
30
Advanced tip and eraser pressure settings
To further customize tip or eraser pressure settings, from the PEN or ERASER tab click on the DETAILS...
button to display the FEEL DETAILS dialog box. The options within this dialog box enable you to change the
tip or eraser pressure sensitivity and click threshold settings independently. (In the PEN and ERASER tabs,
these settings are adjusted simultaneously with the TIP FEEL or ERASER FEEL slider.)
Important: The TIP FEEL or ERASER FEEL slider overrides the detail pressure settings. If you
customize the detail settings, then drag the slider, your detail settings will be removed.
Drag the slider to adjust
the click threshold level.
This setting determines
the amount of force
required to generate a tip
click.
Using your pen tip or
eraser, make several
strokes within the box to
test the results of your
changes.
Drag the slider to select a
pressure sensitivity setting.
If you have a soft touch and
want to achieve full pressure
without having to apply full
force to your pen, choose a
softer setting.
The PROFILE graphically
displays the selected
pressure SENSITIVITY curve
and CLICK THRESHOLD
settings.
A curve that increases
quickly makes the pen feel
more sensitive.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 31
31
Customizing tool buttons
Select the PEN tab to change the functions assigned to the side switch and tip of your Intuos3 pen.
Each tool button can be set to simulate a variety of mouse functions; the pull-down menus enable you to
choose the function that will be performed.
Select the function to perform
when pressing the upper or
lower side switch.
When you bring the pen tip
within 6 mm (0.25 inch) of the
tablet surface without touching
the tablet and press the upper or
lower side switch, the selected
function occurs.
Hint: To make double-clicking
easier, set the side switch to
double-click automatically by
selecting DOUBLE CLICK.
Double-click here to change the
function assigned to the pen tip.
• At least one tool button
should be set to the CLICK
function.
• The tip must be set to CLICK
in order to draw in most
graphics applications.
Returns the tab settings to their
factory default conditions.
Note: For the precise placement of right- and middle-clicks, you can
enable the SIDE SWITCH EXPERT MODE. Select the OPTIONS... button
at the bottom of the control panel to display the OPTIONS dialog box.
(SIDE SWITCH EXPERT MODE is the default setting on Tablet PCs.)
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 32
32
Button functions
The following list describes the options available for tool button, tablet control, or Pop-up Menu settings.
Please note that not all options are available for all controls.
CLICK. This option simulates a primary
mouse button click. Be sure at least one
button performs this function so you can
always navigate and click.
DOUBLE CLICK. Simulates a double-click.
For easier double-clicking, use this
function instead of tapping twice with the
tip of your pen.
MIDDLE CLICK. Simulates a middle mouse
button click.
RIGHT CLICK. Simulates a right mouse
button click, which displays a context
menu.
CLICK LOCK. Simulates holding down the
primary mouse button. Press the tool
button once to initiate click lock. Press the
button again to release click lock. Click
lock is useful for dragging objects or
selecting blocks of text.
4TH CLICK (FORWARD). Simulates a 4th
mouse button click, which on Windows
systems typically issues the FORWARD
command in browser applications.
5TH CLICK (BACK). Simulates a 5th mouse
button click, which typically issues the
BACK command in browser applications.
APPLICATION DEFINED. Reports only the
button number to the application. This is
for applications, such as CAD programs,
that have built-in support for the Intuos3
mouse or optional lens cursor.
DEFAULT. Returns a button to its default
setting.
DISABLED. Disables the button function.
ERASE. Default setting for the eraser.
See erasing for information on using the
eraser.
INK TOGGLE. (Macintosh.) Toggles the Ink
ANYWHERE function of Inkwell on and off.
Inkwell automatically recognizes and
converts your handwriting into text and
inserts it into a document. Note that Ink
must be turned on for this function to work.
See your Macintosh help for information
on working with Inkwell.
KEYSTROKES.... Enables you to simulate
keystrokes.
MODE TOGGLE.... Toggles between PEN
and MOUSE mode.
MODIFIER.... Enables you to simulate
modifier keys.
OPEN/RUN.... Opens an application, file, or
script.
POP-UP MENU. Displays a Pop-up Menu
on your screen. See customizing the Pop-
up Menu for more information.
PRESSURE HOLD. Locks the pressure at
the current pressure level until the button
is released. For example, you can paint
with pressure-sensitivity until you reach
the brush size that you like. You can then
press the button and continue painting with
the same size brush until the button is
released.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 33
33
•KEYSTROKES.... Enables you to simulate keystrokes. Selecting this option displays the DEFINE
KEYSTROKE dialog box where you can enter a keystroke or keystroke sequence to play back.
•OPEN/RUN.... Opens a dialog box where you can select a specific application, file, or script to launch.
You can manually enter a keystroke or keystroke
combination in the KEYS entry box. Keystroke
combinations can include letters, numbers,
function keys (such as F3) and modifier keys
(such as SHIFT, ALT, or CTRL for Windows, or
SHIFT, OPTION, COMMAND, and CONTROL for
Macintosh).
You can also select special keystrokes or
keystroke combinations from the ADD SPECIAL
drop-down menu. When you make a selection it
is added to the KEYS entry box.
After defining a keystroke or keystroke
sequence, click OK.
Important: Because the ENTER
(Windows) and RETURN (Macintosh)
keys can be selected as a defined
keystroke, they cannot be used to select
OK. You must use your Intuos3 tool to
click on the OK button.
If prompted, enter a name for the keystroke
definition. The name will be displayed with the
respective control or in the Pop-up Menu list, as
applicable.
You can create different keystroke functions for
different applications. See working with
application-specific settings for more
information.
Clears the
keystroke
entry box.
Deletes only the last entry
in the keystroke entry box.
Click BROWSE... to locate an application, file,
or script to launch. The selection you make
appears in the APPLICATION TO RUN box.
Click OK to accept the selection. The dialog
box will close and the OPEN/RUN... option
you have selected will be assigned as your
tool button option. If your selection is for the
Pop-up Menu, it will be displayed in the Pop-
up Menu list.
The next time you press the tool button or
make a selection from the Pop-up Menu, the
defined application, file, or script will launch.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 34
34
•MODE TOGGLE.... Toggles between PEN mode and MOUSE mode. When first setting a tool button to
MODE TOGGLE..., the MOUSE MODE dialog box is displayed where you can adjust the mouse acceleration
and speed.
•MODIFIER.... Enables you to simulate modifier key(s) (such as SHIFT, ALT, or CTRL for Windows, or SHIFT,
OPTION, COMMAND, and CONTROL for Macintosh). Many applications use modifier keys to constrain the
size or placement of objects. Selecting this option displays the DEFINE MODIFIER dialog box where you
can assign one or more modifier key functions. After choosing the modifier function(s), click OK.
Sets the screen cursor
acceleration when in
MOUSE mode.
Sets the screen cursor tracking speed when in MOUSE mode
Note: MOUSE mode settings can be accessed from a number of different locations within
the control panel. However, for each input tool and application that you are customizing,
only one MOUSE ACCELERATION and SPEED setting can be made.
In addition to choosing one or
more modifier key options, you
can select the CLICK box if you
want a mouse click to occur
whenever you press the tool
button.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 35
35
Customizing tilt sensitivity
To adjust the tilt sensitivity of your Intuos3 pen, select the PEN tab. Tilt sensitivity determines how far you
have to tilt the tool to produce the maximum tilt effect in your tilt-sensitive applications; you need to tilt the
pen less at high sensitivity than at low sensitivity. Like pressure-sensitivity, tilt can be assigned to control
brush characteristics. Your tilt setting applies to both the tip and eraser of your tool.
Visit Wacom’s web site for a list of applications that currently support tilt. See product information.
Drag the slider to increase or
decrease TILT SENSITIVITY. Then test
your new setting in an application
that supports tilt to be sure you are
getting the desired effect.
Note: Tilt is direction-sensitive and
can be used in some applications to
control brush orientation.
Returns the tab settings to their
factory default conditions.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 36
36
Customizing the mouse
Customizing your Intuos3 mouse is easy. First open the Wacom Tablet control panel using the mouse. The
MOUSE tool will be selected in the TOOL list, and the appropriate tabs will be displayed. Select a tab and
choose from the available options.
Customizing mouse buttons
To modify your Intuos3 mouse button settings, use your mouse to open the Wacom Tablet control panel and
select the MOUSE tab. As with the Intuos3 pen, you can select a function to perform for each button from the
pull-down menus. See button functions for a description of the available options.
Customizing mouse buttons
Customizing the mouse fingerwheel
Mouse mode settings
Working with application-specific settings
Note: To configure the Intuos3 mouse for left handed
use, simply reassign the button functions as needed.
Select the function to perform when pressing a button.
The mouse buttons are chordable;
you can press two or more buttons
simultaneously. For example, if you
program one button to simulate the
CTRL key and another to simulate an
ALT keystroke, when you press both
buttons a CTRL+ALT is simulated.
Returns the tab settings to their
factory default conditions.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 37
37
Customizing the mouse fingerwheel
By default, the fingerwheel controls scrolling in most windows and applications. To customize the
fingerwheel, use your Intuos3 mouse to open the Wacom Tablet control panel and select the MOUSE tab.
When you select the KEYSTROKES option, the keystroke(s) that you set will be sent once for each notch of
wheel movement. To learn which keystroke shortcuts are supported by a particular application, review the
documentation that came with the application.
Returns the tab settings
to their factory default
conditions.
These options control the fingerwheel
function. You can set the FUNCTION to
SCROLL, KEYSTROKES, or DISABLED.
The default setting is to SCROLL.
When you select SCROLL from the
FUNCTION pull-down menu, the tab
displays the custom scroll options.
Choose a scrolling speed that will be
used for each notch of wheel
movement. Roll the fingerwheel
forward to scroll up, and back to scroll
down.
When you select one or more COMBINE WITH: modifier key options, the selected
option(s) will be sent to the application along with each scroll event. For example,
this can be used to create custom zooming or other actions within an application.
Macintosh: The available options are OPTION, COMMAND (Apple key), CONTROL, and
SHIFT.
When you select KEYSTROKES, the tab displays the
custom keystrokes options.
To customize the keystrokes that will be sent for each
notch of wheel movement in a particular direction,
click on a keystrokes button to enter a keystroke
function. The new keystroke setting will be displayed
on the CLICK TO SET button.
The KEYSTROKES option is useful when working with
repetitive functions, such as zooming in Photoshop or
moving forward and backward within your Internet
browser.
Hint: To double the speed of a keystroke action, enter the keystroke
sequence twice within the DEFINE KEYSTROKE dialog box.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 38
38
Tablet to screen mapping
To change the relationship between tool movement on your tablet surface and cursor movement on the
monitor screen, select the MAPPING tab. The MODE options control how the screen cursor moves:
• Select PEN mode to set the screen cursor so that its movement corresponds with the position of your
Intuos3 tool on the tablet – wherever you place your tool on the tablet, the cursor will jump to a
corresponding point on the screen. This is known as absolute positioning, and is the default setting for
all pens.
• Select MOUSE mode to move the screen cursor with a “pick up and slide” motion similar to using a
traditional mouse. This is the default setting for the mouse.
Pen mode
The default MODE for the Intuos3 pen is PEN mode.
In PEN mode, the MAPPING tab looks like this:
The MODE you select controls how the screen cursor moves. In PEN mode,
the screen cursor moves with absolute positioning.
Select a TABLET AREA for tablet to
screen mapping.
Select the ORIENTATION of your
tablet.
Note: The ORIENTATION setting
is tablet-specific, and applies to
all tools and applications.
Other MAPPING settings can be
customized for a specific tool
and application.
SCREEN AREA. Select a monitor
screen area for tablet to screen
mapping.
FORCE PROPORTIONS.
When checked, forces a
proportional tablet to screen
mapping relationship.
Returns the tab settings to their
factory default conditions.
The tablet-to-screen image dynamically updates
to illustrate the selected mapping relationship.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 39
39
Mouse mode
The default MODE for the Intuos3 mouse is MOUSE mode.
With MOUSE mode selected, the MAPPING tab looks like this:
Note: You can also switch between PEN mode and MOUSE mode by using the screen Pop-up Menu.
See customizing the Pop-up Menu for more information. If you frequently switch between PEN mode and
MOUSE mode, you can assign the MODE TOGGLE... function to one of your tool buttons.
Orientation
You can choose a different tablet ORIENTATION and then physically rotate your tablet to match the selection
you have made. This feature can be useful if you prefer to work with the tablet controls on the bottom or
either side of your tablet, or if you are working with a tall monitor.
•LANDSCAPE. Tablet orientation is horizontal, with the tablet status LED at the top. This is the default
setting.
•PORTRAIT. Rotate the tablet 90 degrees clockwise so the tablet status LED is located on the right side.
•LANDSCAPE FLIPPED. Rotate the tablet 180 degrees so the tablet status LED is located near the bottom.
•PORTRAIT FLIPPED. Rotate the tablet 90 degrees counter-clockwise so the tablet status LED is located
on the left side.
After making changes, verify you have the correct setting for your tablet orientation. Do this by moving your
tool “up” on the tablet – the screen cursor should move up as well.
Note: The orientation you select applies to all tools and applications.
The MODE you select controls how the screen cursor moves. In MOUSE mode,
the screen cursor moves with relative positioning.
Select a slower or faster screen
cursor tracking speed when in
MOUSE mode.
Sets the screen cursor acceleration
when in MOUSE mode.
Select the ORIENTATION of your
tablet.
Note: Except for tablet
ORIENTATION, all mapping
settings apply to a specific
Intuos3 tool.
Returns the tab settings to their
factory default conditions.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 40
40
Screen area
In the MAPPING tab, the SCREEN AREA options allow you to define which portion of the display screen your
tablet will map to:
•FULL. When selected, the entire monitor(s) area is mapped. This is the default setting. See mapping to
multiple monitors for more information.
•PORTION.... When selected, this option allows you to select a portion of the display for tablet to screen
mapping. Selecting PORTION... brings up the PORTION OF SCREEN dialog box.
•MONITOR. When selected, the entire area of a single monitor that you choose is mapped. If more than
one monitor is connected to your system, an option will be available for each monitor detected.
Choose a method for defining a portion of the display:
• Drag corners of the foreground graphic to select the screen
area. The background graphic represents the entire screen
area.
• Move the screen cursor to select the screen area. Select the
CLICK TO DEFINE SCREEN AREA button. As you define
PORTION OF SCREEN, follow any MESSAGE prompts to set the
portion of your display screen that will be used for mapping.
• Enter pixel values for the TOP, LEFT, BOTTOM, and RIGHT
boundary of the display screen area. Values are measured
from the top left corner of the display. Be sure to follow any
MESSAGE prompts.
After defining a portion of the screen, you may need to use a
different input device to access other portions of the screen area.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 41
41
Force proportions
Check or uncheck the MAPPING tab’s FORCE PROPORTIONS box to determine the tablet to screen mapping
relationship.
When FORCE PROPORTIONS is checked, the correct vertical
and horizontal proportions are maintained between the
tablet and display. Drawing a circle on the tablet results in
a circle on the display screen. Depending on your settings,
some portions of the tablet active area may no longer be
usable when this option is selected.
When FORCE PROPORTIONS is unchecked, the correct
scale or proportions are not maintained. The selected
tablet area is mapped to the selected display area.
Drawing a circle on the tablet may create an ellipse on
the display screen. This is the default setting for all tools.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 42
42
Tablet area
The MAPPING tab’s TABLET AREA options allow you to define the tablet area that will be mapped to the screen
area:
•FULL. When selected, the entire active area of the tablet is used for tablet to display mapping. This is
the default setting.
•PORTION.... When selected, this option allows you to select a portion of the tablet’s active area for tablet
to screen mapping. Selecting PORTION... brings up the PORTION OF TABLET dialog box.
Choose a method for defining a portion of the tablet:
• Drag corners of the foreground graphic to select the tablet
area that will be mapped to your selected screen area.
The background graphic represents the tablet.
• Use your tool on the tablet to select the tablet area.
Select the CLICK TO DEFINE TABLET AREA button. As you
define PORTION OF TABLET, follow any MESSAGE prompts
to set the portion of your tablet that will be used for
mapping.
• Enter count values for the TOP, LEFT, BOTTOM, and RIGHT
boundary of the tablet area. Values are measured from
the top left corner of the tablet’s active area. A count
equals one line of tablet resolution. Be sure to follow any
MESSAGE prompts.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 43
43
•QUICKPOINT LEFT and QUICKPOINT RIGHT. These options (available for Intuos3 9x12 / A4-regular,
12x12 / A4 Oversize, and 12x19 / A3 Wide tablets) divide the tablet into two independent areas: a large
area for drawing, and a small area for quick navigation. Both areas are mapped to the screen area
defined in the PORTION OF SCREEN dialog box, or to the entire display by default. These options can also
be selected and deselected using the screen Pop-up Menu. See customizing the Pop-up Menu for more
information.
Mapping to multiple monitors
When you are working with more than one monitor, your tablet will map to the monitors based upon how
your system is configured. By default, if more than one monitor is in use and you are in extended monitor
mode, the tablet will map to all monitors as if they were one large display. If you are in mirror mode, the
tablet will map to the entire space on each monitor and the screen cursor will be displayed on each monitor
simultaneously.
Please refer to your hardware and operating system documentation for details on configuring your computer
and operating system for use with multiple monitors.
After you have correctly configured your computer for use with multiple monitors, you can then adjust the
tablet mapping by opening the Wacom Tablet control panel and changing the appropriate options.
Note: The QuickPoint area and drawing area are indicated by crop marks on the tablet work surface.
Drawing areas
QUICKPOINT LEFT sets the
QuickPoint area to the lower
left corner of the tablet.
QUICKPOINT RIGHT sets the
QuickPoint area to the lower
right corner of the tablet.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 44
44
Customizing the tablet functions
It is as easy to customize your Intuos3 tablet as it is to customize the Intuos3 pen or mouse. Simply open
the Wacom Tablet control panel and select the FUNCTIONS icon in the TOOL list. Select a tab to customize,
and change settings using the available options.
Customizing ExpressKeys
Customizing tablet Touch Strips
Customizing the Pop-up Menu
Working with application-specific settings
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 45
45
Customizing ExpressKeys
Each key can be customized to perform a modifier, keystroke, or other function. When you select the
ExpressKeys tab, the currently selected function of each key appears in the corresponding pull-down menu.
See using ExpressKeys for the default key settings, and button functions for a description of the available
options.
To customize a key, select an item from the corresponding pull-down menu. Note that only the LEFT key
group will be available when you are working with a 4x5 / A6 tablet.
Note: ExpressKeys functions can be defined for use with specific applications, and any changes you make
on this tab apply to the currently selected item in the control panel’s APPLICATION list. Unless you define
application-specific settings, the tab settings will apply to all applications.
Use the pull-down menus to
choose a function that will be
performed when the key is
pressed.
Your choice will be displayed
either within the pull-down menu
or beneath the menu.
Returns the tab
settings to their factory
default conditions.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 46
46
Customizing tablet Touch Strips
When you select the tablet TOUCH STRIP tab, the currently set function of each Touch Strip is displayed.
Each Touch Strip can be customized to issue zooming, scrolling, or keystroke actions. You can also disable
a Touch Strip until you choose to assign a new function or renew the default settings. Note that only the
LEFT Touch Strip group will be available when you are working with a 4x5 / A6 tablet. Using the Touch Strips
gives you additional information on working with the Touch Strips.
Note: Touch Strip functions can be defined for use with specific applications, and any changes you make on
this tab apply to the currently selected icon in the control panel’s APPLICATION list.
To customize a Touch Strip, choose a
Touch Strip FUNCTION to perform
when the Touch Strip is in use.
•AUTO SCROLL/ZOOM is the default
setting for each Touch Strip.
When selected, the Touch Strip
zooms in most graphics
applications and scrolls in most
other applications.
• Choose SCROLL to set custom
Touch Strip scroll settings.
• Choose ZOOM to set custom
Touch Strip zoom settings.
• Choose KEYSTROKES to define
Touch Strip keystroke settings.
• Choose DISABLED if you would like
to deactivate the Touch Strip.
Click to display the ADVANCED TOUCH STRIP SETTINGS dialog box
where you can enable or disable special Touch Strip function
areas. Advanced Touch Strip settings gives you additional
details.
Choose a Touch Strip scrolling speed.
Returns the tab and any
advanced Touch Strip
settings to their factory
default conditions.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 47
47
•Touch Strip scroll settings. Each tablet Touch Strip can be customized to issue scrolling only actions.
When SCROLL is selected, an up or down motion on the Touch Strip will cause a scroll up or down action
in most applications.
Note: Some applications may interpret scrolling events as zoom events, or may ignore scrolling
completely.
When you select SCROLL from a
Touch Strip’s FUNCTION pull-down
menu, the tab displays the custom
scroll options for that Touch Strip.
Choose a Touch Strip scrolling
speed.
When you select one or more
COMBINE WITH: modifier key
options, the selected option(s) will
be sent to the application along
with each scroll event. This can be
used, for example, to create
custom zooming or other actions
within an application.
Macintosh: The available options
are OPTION, COMMAND (Apple key),
CONTROL, and SHIFT.Tip: To zoom images around the current position of the screen cursor
when working in Photoshop CS2, select the Touch Strip SCROLL option.
Then in Photoshop CS2 select EDIT, PREFERENCES, and GENERAL
OPTIONS. In the dialog box that appears, check the option ZOOM WITH
SCROLL WHEEL and click OK.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 48
48
•Touch Strip zoom settings. Each tablet Touch Strip can be customized to issue zoom only actions.
When ZOOM is selected, an up or down motion on the Touch Strip will cause a zoom in or out action in
most graphics applications.
Note: Some applications may interpret zoom events as scrolling events, or may ignore zooming
completely.
•Touch Strip keystroke settings. Each tablet Touch Strip can be customized to issue custom keystroke
actions. After you have customized the Touch Strip for KEYSTROKES functionality, a single keystrokes
action will be sent for each Touch Strip event.
Note: To learn which keystroke shortcuts are supported by a particular application, review the
documentation that came with the application.
When you select KEYSTROKES
from a Touch Strip’s FUNCTION
pull-down menu, the tab displays
the custom keystrokes options
for that Touch Strip.
To customize the keystrokes that
will be sent when you move your
finger or tool tip in either
direction along the Touch Strip,
click on a button to enter a
keystroke function. The new
keystroke setting will be
displayed as the new CLICK TO
SET: button name.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 49
49
Advanced Touch Strip settings
The tablet Touch Strips can be further customized within the ADVANCED TOUCH STRIP SETTINGS dialog box.
When you click on the TOUCH STRIP tab’s
ADVANCED... button, the ADVANCED TOUCH STRIP
SETTINGS dialog box is displayed. The settings
within this dialog box are global, and apply to all
applications.
If you prefer not to use the continuous and single
step operations of the Touch Strip, you can disable
them by deselecting this box. This option is selected
by default.
Using the Touch Strips gives you more information
on working with the special function areas.
Check the LEFT or RIGHT box to disable touch
input for a Touch Strip while still allowing you to
control the Touch Strip with your Intuos3 pen.
Use these settings to avoid accidental operation
of a Touch Strip as you move your hand over the
Touch Strip area. The boxes are unchecked by
default. Resets the dialog box options to
their original default conditions.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 50
50
Customizing the Pop-up Menu
Use the POP-UP MENUS tab to define the available functions on the Pop-up Menu list.
To display the Pop-up Menu, set one of your tool buttons to the POP-UP MENU function. Whenever you press
that button, the Pop-up Menu is displayed. Select from available items in the Pop-up Menu by clicking on
them. To close the Pop-up Menu without making a selection, click outside of the Pop-up Menu.
Displays a list of functions that have been added to the
Pop-up Menu. To change the order of an item, drag it to a
new location. Double-click on an item to make edits.
Menu options enable you to change the
appearance (FONT SIZE and POP-UP FONT)
of the Pop-up Menu.
Returns all tab settings to their
default values.
Important: This action
will delete all Pop-up
Menu items that have
been defined.
Removes the
selected item
from the list.
Select a button
functions option to
add to the Pop-up
Menu list.
Notes:
PEN MODE places your tool
in PEN mode.
MOUSE MODE places your
tool in MOUSE mode.
When adding MOUSE
mode to the Pop-up Menu
list, the MOUSE MODE
dialog box is displayed
where you can adjust the
mouse acceleration and
speed.
The QUICKPOINT LEFT and
QUICKPOINT RIGHT options
are available for Intuos3
9x12 / A4-regular and
larger tablets.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 51
51
Working with multiple tools
The Wacom Tablet control panel is designed to help you customize and keep track of your Intuos3 tool
settings. The tool you use to open the control panel is automatically selected, and the appropriate tabs for
that tool are displayed.
To add a tool to the control panel’s TOOL list, simply use the tool on your Intuos3 tablet.
• When a new tool is placed on the tablet for the first time, it will function with the appropriate default
settings for that tool, and not the custom settings of other tools, even if they are identical devices. If the
Wacom Tablet control panel is open, the tool is automatically added to the TOOL list and you can
customize the tool by changing the tab settings.
• When you select a tool that you have added to the TOOL list, the appropriate tab settings for that tool are
displayed. Any changes you make to the tab settings will then apply to that tool. Your changes take
effect immediately.
To remove a selected tool from the TOOL list, click on the TOOL list’s [ – ] button. In the dialog box that
appears, click DELETE to confirm your selection. The selected tool is removed from the list, along with any
custom settings you may have created for it. (A removed tool can be added back to the TOOL list by placing
it back onto the tablet.)
Note: The FUNCTIONS icon cannot be removed from the TOOL list.
The TOOL list displays an
icon for the tablet
FUNCTIONS and for each
Intuos3 tool that has been
used on the tablet.
Each Intuos3 tool has a Tool ID that makes it unique.
Any custom settings apply only to the specific tool for
which they were made. Identical Intuos3 tools will
appear as numbered devices. The selected tool is
highlighted.
Removes the
selected tool.
The FUNCTIONS
icon cannot be
deleted.
The button is
inactive when there
is only one item in
the list.
If application-specific
settings have not been
added, the ALL icon is
displayed and the tool
settings apply to all
applications. Tab settings apply only to the
selected tool and application.
Tip: You can give each tool a different name by double-clicking
on the tool’s icon and entering a new name. For example,
“Drawing Pen” or “Paint Brush”. You cannot rename the
FUNCTIONS icon.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 52
52
Working with application-specific settings
You may wish to customize a tool for use with a particular application. For example, you may want a firm
pen tip pressure setting in one application and a soft pressure setting in another. The APPLICATION list
enables you to add an individual application to the list and then customize your tool settings for that
application.
• When no application-specific settings have been created and a tool is selected from the TOOL list, the
APPLICATION list displays the ALL icon containing tool settings that apply to all of your applications. In the
example below, no application-specific settings have been added for the Intuos3 mouse so the ALL icon
is displayed and the mouse will have the same settings in all applications.
• When application-specific settings are added to the APPLICATION list, the ALL icon changes to ALL
OTHERS, and an application icon is displayed for the newly added application(s). In the following
example, application-specific settings have been added for the pen for both Photoshop and Painter.
In the example above, if you select the ALL OTHERS icon and make changes to the tab settings, your
changes will apply to the PEN in all applications except Photoshop and Painter, which have their own
specific pen settings. If you select the icon for PHOTOSHOP and make changes to the tab settings, your
changes will apply only to the pen while you are using Photoshop. Likewise, if you select the PAINTER
icon and make changes to the tab settings, those changes will only apply while you are using Painter.
When you create application-specific settings, you are creating a separate group of settings for the selected
tool and application. See the following sections for additional details:
Creating an application-specific setting
Changing settings for a specific tool and application
Removing application-specific settings
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 53
53
Creating an application-specific setting
To create an application-specific setting, first choose the tablet and tool for which you want to create an
application-specific setting. Then click on the APPLICATION list’s [ + ] button to display the ADD APPLICATION
FOR CUSTOM SETTINGS dialog box.
After adding an application, its icon appears in the APPLICATION list whenever the respective tool is selected
in the TOOL list. Select the application and then customize the control panel tab settings for your tool and the
selected application.
Once you have created application-specific settings, applications that have not been customized in this
manner will use the tool settings for ALL OTHERS.
Tip: First customize settings for one application. When you feel comfortable with the process, you can
create more application-specific settings.
Choose from one of two methods
to select an application:
• Open the application for which
you want to create custom
settings, and then select that
application from the
CURRENTLY OPEN
APPLICATIONS box.
•BROWSE to select the
executable file of any
application installed on your
computer.
Your selection is added to the
SELECTED APPLICATION box.
Click OK to complete the process.
Note: If two programs have the
same executable file name, they
will share the same customized
settings.
Displays the name
of the selected
application.
Click OK to accept
your selection and
close the dialog
box.
CUSTOMIZING
INDEX
CONTENTS
INDEX
CONTENTS 54
54
Changing settings for a specific tool and application
To change tool settings for a specific application, select the tool and the application and then customize the
tab settings.
Removing application-specific settings
To remove an application-specific setting:
1. In the TOOL list, select the tool from which you want to remove the application-specific setting. Then, in
the APPLICATION list select the application you want to remove from the list.
2. Click on the APPLICATION list’s [ – ] button. In the dialog box that appears, click DELETE to confirm your
selection. The selected application is removed from the list, along with any custom tool settings that you
may have created for it.
Hint: To quickly remove all application-specific settings from a single tool, remove the tool from the TOOL list.
Then place the tool back on the tablet. The tool will be added back to the TOOL list using the default settings.
INDEX
CONTENTS
INDEX
CONTENTS 55
55
TROUBLESHOOTING
Most of the time your tablet will work flawlessly. But if you are having trouble, Wacom recommends you do
the following:
1. Look in the troubleshooting tables. Your problem may be described there and you can try the solution
offered.
2. Open the Wacom tablet Read Me file for late-breaking information.
3. Test your tablet and input tools. See testing your tablet and testing your tools.
4. If you are having a compatibility conflict between Intuos3 and a new hardware or software product, check
if a newer Wacom tablet software driver is available. See obtaining driver downloads for information on
downloading an updated software driver. Wacom periodically updates the software driver to maintain
compatibility with new products.
5. Check the FAQs (Frequently Asked Questions) on the Wacom web site for your region.
6. If you have tried the suggestions in this manual and still cannot resolve the problem, then contact
Wacom for Technical Support. See the Read Me file for information on where to obtain support for your
region.
T
esting your tablet
Testing your tools
Troubleshooting tables
Technical support options
Obtaining driver downloads
TROUBLESHOOTING
INDEX
CONTENTS
INDEX
CONTENTS 56
56
Testing your tablet
Make sure your computer is turned on, the operating system has finished loading, and the tablet is properly
connected to an active powered USB port. Then try the following tests:
1. Check the tablet. The tablet’s blue status LED will light whenever the tablet is properly connected and
your computer has registered it as a USB device. If the LED is on, continue with step 2.
If the status LED does not glow when the computer is on and the system has fully loaded, then:
• Make sure the tablet USB cable is securely connected to an active USB port on your computer.
Intuos3 requires that you connect to a primary USB port (located directly on your computer) or to a
powered USB hub.
• If you are connecting the tablet to a powered USB hub, be sure the USB hub is properly connected to
your computer and is active.
• Connect the tablet to a different powered USB port or try connecting to the powered USB port on
another computer.
Note: For best results when troubleshooting no power to the tablet (status LED does not light), Wacom
recommends plugging the tablet directly into the system USB port located on your computer.
Temporarily eliminate any external hubs in use until you determine that the system recognizes the tablet
and that it is functional. When the tablet is working properly, it is usually fine to then move the tablet to a
powered USB hub.
If the tablet status LED does not illuminate after your computer is on and has finished booting up, your
USB port may be disabled. It may be necessary to check your system BIOS setting to verify that you
have connected the tablet to an active USB port.
See also testing your tools for detailed test information.
2. Check the Grip Pen.
• Move your pen across the active area of the tablet; the screen cursor should move in the
corresponding direction on your monitor or display screen.
• Press the pen tip against the surface of the tablet. The status LED should turn from blue to green.
• Next, without applying pressure to the pen tip, hold the pen tip within approximately 6 mm (0.25 inch)
of the tablet surface and press the side switch. The status LED should again change from blue to
green.
• Turn the pen over and press the eraser against the surface of the tablet; the status LED should
change from blue to green. See testing your tools for detailed test information.
3. Check any other tool(s). See testing your tools.
If these tests fail, you may have a defective input tool or tablet. See technical support options.
TROUBLESHOOTING
INDEX
CONTENTS
INDEX
CONTENTS 57
57
Testing your tools
If your tool does not work as you expect, it is a good idea to first check the assigned functions or to reset the
tool to its default condition. A quick way to reset a tool to the default settings is to remove it from the TOOL
list by clicking on the list’s [ – ] button. After the tool has been removed, place it back onto the tablet and the
tool will be re-added to the TOOL list with its default settings.
Open the Wacom Tablet control panel and click on the ABOUT button. In the dialog box that appears, click on
the DIAGNOSE... button to open the DIAGNOSTICS dialog box. The DIAGNOSTICS dialog box displays dynamic
information about the tablet hardware and pointing devices. This information is used when testing your
tablet and tools.
If you have more than one tablet connected to your system, be sure to select the tablet for which you are
testing your tool in the TABLET INFO column.
Note: When testing your tool buttons, if a button is set to POP-UP MENU or OPEN/RUN..., that function will
occur when the button is pressed. In this case you may want to change that button’s function before testing.
Testing the ExpressKeys
Testing the tablet Touch Strips
Testing a pen
Testing a mouse
TROUBLESHOOTING
INDEX
CONTENTS
INDEX
CONTENTS 58
58
Testing the ExpressKeys
1. With the DIAGNOSTICS dialog box open, observe the TABLET INFO column as you test the ExpressKeys.
If you have more than one tablet connected to your system, be sure to select the tablet in the TABLET
INFO column.
2. Test the keys on your tablet by clicking them one at a time. Each time you press a key, its number will be
displayed next to either the LEFT KEYS or RIGHT KEYS category, depending on which keys group you are
testing.
When you are done, click on the CLOSE button to exit the dialog box.
Testing the tablet Touch Strips
1. With the DIAGNOSTICS dialog box open, observe the TABLET INFO column as you test the tablet Touch
Strip(s). If you have more than one tablet connected to your system, be sure to select the tablet in the
TABLET INFO column.
2. First, slide your finger up or down along the entire length of the Touch Strip you want to test. As you
touch and move your finger along the Touch Strip, a number will indicate the current finger position for
the respective Touch Strip next to LEFT TOUCH STRIP or RIGHT TOUCH STRIP.
3. Next, slide the pen tip up or down along the Touch Strip edge closest to the tablet’s active area. As you
move the tool tip along this area of operability, a number will indicate the current pen position for the
respective Touch Strip next to LEFT TOUCH STRIP or RIGHT TOUCH STRIP.
4. When you are done, click on the CLOSE button to exit the dialog box.
TROUBLESHOOTING
INDEX
CONTENTS
INDEX
CONTENTS 59
59
Testing a pen
1. While observing the POINTING DEVICE INFO column, bring your Intuos3 tool within 6 mm (0.25 inch) of the
tablet’s active area. A value for PROXIMITY, the DEVICE NAME, DEVICE TYPE, and a DEVICE S/N (serial
number) should be displayed. If you have more than one tablet connected to your system, be sure to
select the tablet for which you are testing your tools in the TABLET INFO column.
2. Move your tool along the tablet surface. The X and Y DATA values should change to reflect the tool
position.
3. Test your Intuos3 pen switches. The tablet’s status LED should change color from blue to green each
time you click with the tool tip, press the side switch, or press the tool’s eraser to the tablet.
• Click on the tablet surface with the tool tip – the SWITCHES state and PRESSURE value should change.
(PRESSURE should change from approximately 0% with no pressure applied to approximately 100%
when full pressure is applied.)
• Next, press the side switch without pressing the tip to the tablet – the SWITCHES state should change.
(For the Intuos3 pen, do this for both positions of the DuoSwitch.)
• Press the tool’s eraser to the tablet – the SWITCHES state and PRESSURE value will change.
(PRESSURE should change from approximately 0% with no pressure applied to approximately 100%
when full pressure is applied.)
• For the Airbrush, move the fingerwheel forward – the WHEEL value should decrease to a value of
approximately 0 when the fingerwheel is all the way forward. Move the fingerwheel backward – the
WHEEL value should increase to approximately 1000 when the fingerwheel is all the way back.
4. Test tilt for the x-axis by moving the pen from a vertical position toward the right; the X TILT value should
change from approximately 0 to +60. Now move the tool to the left of vertical; the X TILT value should
change from approximately 0 to -60.
5. Test tilt for the y-axis by moving the pen from a vertical position toward the bottom of the tablet; the Y
TILT value should change from approximately 0 to +60. Now move the tool toward the top of the tablet;
the Y TILT value should change from approximately 0 to -60.
6. If you are testing an Art Pen, test pen rotation by holding the pen vertically and twisting it around its axis.
The displayed ROTATION value should change.
7. When you are done, click on the CLOSE button to exit the dialog box.
Pen Tip = 1, DuoSwitch (lower position) = 2, DuoSwitch (upper position) = 3,
Eraser = 1
Airbrush Tip = 1, Side Switch = 2, Eraser = 1
TROUBLESHOOTING
INDEX
CONTENTS
INDEX
CONTENTS 60
60
Testing a mouse
1. With the DIAGNOSTICS dialog box open, place the Intuos3 mouse on the tablet’s active area and test the
buttons by clicking each button. The tablet status LED should change color, and the SWITCHES state
should change for each button you click.
2. When the DIAGNOSTICS dialog box is first opened the WHEEL status should be 0. Move the fingerwheel
backward. The WHEEL status should change from 0 to +1.
3. Move the fingerwheel forward. The WHEEL status should change to -1.
4. When you are done, click on the CLOSE button to exit the dialog box.
123
54
Intuos3 mouse
TROUBLESHOOTING
INDEX
CONTENTS
INDEX
CONTENTS 61
61
Troubleshooting tables
If you encounter problems with your Intuos3 tools or tablet, refer to the following tables. Your problem may
be described here, and you can try the solution offered. Be sure you refer to the Read Me file for the latest
information updates.
For additional information, visit Wacom’s web site at http://www.wacom.com/productsupport and follow the
links to the FAQs.
General problems
Windows-specific problems
Macintosh-specific problems
General problems
The computer does not
have an available USB
port.
Check if there is an available USB port on a powered USB hub. If none are
available you will need to add a powered USB hub.
The tablet status LED is
off.
Verify that your tablet’s USB cable is plugged into a primary USB port
(directly into your computer) or into a powered USB hub. If you are
connecting to a powered USB hub device, make sure the hub is connected
to an active USB port and that the hub is active.
After plugging in the tablet,
a message appears
indicating that the USB
device needs more power
than is available.
Make sure the tablet is plugged into a primary USB port on your computer
or into a powered USB hub attached to your computer.
The pen works only in
MOUSE mode, and does
not draw with pressure-
sensitivity.
The tablet driver software was not installed or did not load properly.
Make sure the tablet driver software is installed and functioning. Insert the
Wacom Tablet CD into your computer and install the driver software for the
tablet.
The pen does not draw
with pressure-sensitivity.
Some applications require that you turn on the pressure capabilities within
the application or selected tool before the pen will respond as a pressure-
sensitive tool.
Clicking is difficult. Try using a lighter TIP FEEL (see adjusting tip feel and double-click).
TROUBLESHOOTING
INDEX
CONTENTS
INDEX
CONTENTS 62
62
Double-clicking is difficult. Be sure you are quickly tapping the tablet twice in the same place on the
tablet’s active area.
Using the side switch to double-click is recommended (review the
techniques in clicking). See also adjusting tip feel and double-click.
Set one of the ExpressKeys to DOUBLE CLICK and use it to issue double-
clicks.
Try increasing the TIP DOUBLE CLICK DISTANCE (see adjusting tip feel and
double-click).
Try using a lighter TIP FEEL (see adjusting tip feel and double-click).
Windows: Try setting your system to launch programs with a single click.
See clicking.
The pen selects
everything, will not stop
drawing.
Open the Wacom Tablet control panel and go to the PEN tab. Move the TIP
FEEL slider toward FIRM, or select the DETAILS... button and increase the
CLICK THRESHOLD setting. If this does not help, see testing your tools.
The eraser selects
everything or will not stop
erasing.
Open the Wacom Tablet control panel and go to the ERASER tab. Move the
ERASER FEEL slider toward FIRM, or select the DETAILS... button and
increase the CLICK THRESHOLD setting. If this does not help, see testing
your tools.
You notice a delay at the
beginning of pen strokes.
Try decreasing the TIP DOUBLE CLICK DISTANCE (see adjusting tip feel and
double-click). If that does not work, try dragging the TIP DOUBLE CLICK
DISTANCE slider to the OFF position in order to turn off double-click assist.
You have to press hard
with the pen when clicking
or drawing.
Open the Wacom Tablet control panel and go to the PEN tab. Move the TIP
FEEL slider toward SOFT, or select the DETAILS... button and decrease the
SENSITIVITY and CLICK THRESHOLD settings
The pen tip does not
function.
Make sure the status LED changes from blue to green when the tip is
pressed. If it does not, you may have defective hardware (see testing your
tools).
Check the control panel’s PEN tab and verify that the tip is assigned to a
CLICK function.
Changing the function
settings for the Intuos3
tools has no effect.
Make sure that you change the settings for the tool and the application that
you are using. See working with multiple tools and working with application-
specific settings.
TROUBLESHOOTING
INDEX
CONTENTS
INDEX
CONTENTS 63
63
The side switch does not
work.
Be sure you press the side switch when the pen tip is within 6 mm (0.25
inch) of the tablet’s active area – do this without pressing down on the pen
tip.
From the Wacom Tablet control panel, verify that the side switch is set to the
function you are expecting to occur for the application and tool that you are
using. Verify also that the SIDE SWITCH EXPERT MODE option is deselected.
(This option is accessed by clicking on the control panel OPTIONS... button.)
Make sure the tablet status LED changes from blue to green when you
press the side switch. If it does not, you may have defective hardware (see
testing your tools).
The screen cursor jumps
back.
Do not place an Intuos3 tool on the tablet when it is not in use, or when you
are using another pointing device. Leaving your tool on the tablet may
interfere with screen cursor positioning when using other input devices.
Cannot move the cursor
where you want to on the
screen, or the line you are
drawing does not line up
with the location of the
pointer in paint
applications.
Open the Wacom Tablet control panel and go to the MAPPING tab. Verify that
PEN mode is selected and that the SCREEN AREA is set to FULL for the
selected tool and application. If this does not help, click on the DEFAULT
button to reestablish tablet to screen mapping. If you are still having
difficulty, remove the tablet preferences (see next tip).
You suspect the tablet
preferences may be
corrupted, or want to make
certain that all settings are
at their factory defaults.
Delete the tablet preferences as follows:
Windows: Do a Search or Find for the TABLET.DAT file and delete it.
The file should be in your Windows\System32 folder. Then restart your
computer. When the tablet driver loads, it will create a new preferences file
with the factory default settings.
Macintosh OS X: For a single user, delete the tablet preferences by first
choosing your HOME folder from the GO menu. Then open your home
LIBRARY folder. Within your home LIBRARY folder, open the PREFERENCES
folder and delete the COM.WACOM.TABLETPREFERENCES file. Log out, then
log back in. When the tablet driver loads it will create a new preferences file
with the factory defaults.
For multiple users, delete all tablet preferences by first opening the main
APPLICATIONS folder. Then open the TABLET folder and run the
REMOVETABLET utility. When the utility starts, click on the REMOVE ALL
PREFERENCE FILES button. Log out, then log back in. When the tablet driver
loads, it will create new preferences files with the factory defaults.
Note: Do not manually remove the WACOM TABLET.PREFPANE file from the
main LIBRARY PREFERENCEPANES folder. This file is only to be removed
when uninstalling the tablet software driver, and then only when using the
REMOVETABLET utility.
TROUBLESHOOTING
INDEX
CONTENTS
INDEX
CONTENTS 64
64
Windows-specific problems
Macintosh-specific problems
The computer does not go
to sleep.
When you are not using your Intuos3 input tool(s), remove them from the
tablet surface or the tablet will continue to send data, keeping the computer
awake.
When using the tablet the
screen cursor is very
erratic or jumps around.
On rare occasions the tablet may receive interfering radio frequencies from
a computer monitor or nearby AM radio station. If you notice interference
from a monitor, try moving the tablet at least 6 inches away from the
monitor, or change the monitor refresh rate or monitor resolution.
The Intuos3 pen does not
work on the tablet Touch
Strip.
Remember that the pen is active in a narrow band along the Touch Strip
edge closest to the tablet’s active area.
After changing right- and
left- handed settings in the
computer’s mouse control
panel, the pen tip no longer
functions properly and
Intuos3 mouse tool button
functions are reversed.
This action will reverse the right and left button settings on your Wacom
tools. Restart Windows for your Wacom tool settings to be correctly
recognized.
Windows XP. After
installing the tablet on a
system with multiple users,
the tablet only works on
the primary user desktop.
Reboot the system after installing the tablet on a system with multiple users.
At startup, a dialog box
appears telling you that
either the driver failed to
load or the tablet
preferences have not yet
been created.
The tablet was not detected at startup. Make sure the USB interface cable
is securely connected and that the status LED on the tablet is blue. If your
tablet is plugged into a powered USB hub, make sure the hub is connected
and active.
From the GO menu, select APPLICATIONS and open the UTILITIES folder.
Launch the APPLE SYSTEM PROFILER and select the DEVICES AND VOLUMES
tab. A USB tablet should be displayed by the profiler. If a USB tablet was
not found, check the USB tablet cable connection or try plugging the tablet
into a different USB port.
If you are still having problems, open the OS X Disk Utility application and
run REPAIR DISK PERMISSIONS from the FIRST AID tab. If this does not help,
contact Wacom for Technical Support. See technical support options.
TROUBLESHOOTING
INDEX
CONTENTS
INDEX
CONTENTS 65
65
Technical support options
If you have a problem with your Wacom tablet, first check the tablet installation guide to be sure the unit is
installed correctly. Then review the troubleshooting procedures within this manual; your problem may be
described there and you can try the solution(s) offered.
If you cannot find the answer in this manual, you may find updated information about your problem in the
Read Me file for your platform (located on the Wacom Tablet CD). You can also check the product FAQs
(Frequently Asked Questions) on the Wacom web site for your region.
If you cannot solve the problem and you think your Wacom tablet is not working properly, contact the Wacom
support staff for the area where your product was purchased. See the Wacom tablet Read Me file, located
on the Wacom Tablet CD, for contact information. If you have an Internet connection you can download the
latest software drivers from the Wacom web site for your region. See obtaining driver downloads for your
region.
When you call, you should be at your computer with the following information available:
• This manual.
• Tablet serial and model number. (Look on the bottom of the tablet.)
• Driver version number. (See the Wacom Tablet CD or click on the Wacom Tablet control panel ABOUT
button.)
• The make and model of your computer, and operating system version number.
• A list of peripheral devices attached to your computer.
• The software application and version you were using then the problem occurred.
• The exact wording of any error message that appeared on your screen.
• What happened and what you were doing when the problem occurred.
• How you tried to solve the problem.
Inkwell does not work
correctly with tablet.
There may be a problem with the Inkwell preferences. Remove the
damaged preference files as follows. They will be recreated when you
enable handwriting recognition.
1. From the Apple menu, choose SYSTEM PREFERENCes, SHOW ALL, and
INK. Then turn off handwriting recognition.
2. From the GO menu, choose your HOME. Open the LIBRARY and
PREFERENCES folders. Then remove the following preferences:
• com.apple.ink.framework.plist
• com.apple.ink.inkpad.plist
• com.apple.ink.inkpad.sketch
3. Go back to SYSTEM PREFERENCES and INK, and then enable handwriting
recognition.
4. Test the Inkwell function using your Wacom tablet and pen.
5. If this procedure does not resolve your problem with Inkwell, contact
Apple Support for further assistance. Wacom is not the software
manufacturer for Inkwell and we are limited in our abilities to support a
third party software application.
TROUBLESHOOTING
INDEX
CONTENTS
INDEX
CONTENTS 66
66
Obtaining driver downloads
Wacom periodically updates the tablet software driver to maintain compatibility with new products. If you are
having a compatibility problem between Intuos3 and a new hardware or software product, it may be helpful
to download a new Wacom tablet software driver (when available) from the Internet.
USA, Canada, Central and South America
Europe, Middle East and Africa
Japan
Asia Pacific (English)
China
Worldwide Web: http://www.wacom.com/productsupport Software updates.
Worldwide Web: http://www.wacom-europe.com Software updates.
Anonymous FTP Site: ftp://ftp.wacom-europe.com/pub/ Software updates.
Worldwide Web: http://tablet.wacom.co.jp Software updates. (Japanese)
Worldwide Web: http://www.wacom.com/ap Software updates. (English)
Worldwide Web: http://www.wacom.com.cn Software updates.
(Simplified Chinese)
INDEX
CONTENTS
INDEX
CONTENTS 67
67
APPENDIX
This section contains information and tips on caring for your tablet and tools, instructions on how to uninstall
the tablet software, your license and warranty, and more.
Caring for your tablet and tools
Uninstalling the software
Changing the tablet mode
Installing multiple tablets
Intuos3 lens cursor
Working with AutoCAD
Product specifications
Product information
Ordering parts and accessories
Radio and television interference
License and Warranties (Worldwide, Except for
Europe, Africa and Middle East)
License and Warranty (Europe, Africa
and Middle East)
Caring for your tablet and tools
Keep your Intuos3 tools and tablet surface clean. Dust and dirt particles can stick to your tools and cause
scratching and wear to the tablet’s high-gloss surface. Regular cleaning with a soft, damp cloth will help
prolong the life of your tablet surface and tools; you can also dampen the cloth using a very mild soap diluted
with water. Do
not
use volatile liquids, such as paint thinner or benzene, because they may damage the
plastic case.
Keep your tablet and tools in a clean, dry place and avoid extremes in temperature. Room temperature is
best. Also, your Intuos3 tools and tablet are not made to come apart. Twisting the pen case can break the
pen. Taking apart the product will void your warranty.
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 68
68
Replacing the pen tip
The pen tip (nib) will wear with normal use. When the nib gets too short or develops a flat point, you can
replace it with another nib. Simply clasp the old nib with a tweezer, needle-nosed plier, or similar instrument
and pull it straight out of the pen. Then slide the end of the new nib straight into the barrel of the pen – firmly
push the nib until it stops.
Note: Stroke nibs are spring-loaded, providing additional tactile feedback when you are working with the
Intuos3 pen or Airbrush. Stroke nibs are gray in color and are installed in the same manner as a standard
pen nib.
To order replacement parts, see other parts and accessories.
Uninstalling the software
Follow the appropriate procedure below to remove the Wacom tablet driver software from your system.
Important: When you remove the Wacom tablet driver software from your system, any other Wacom
tablet connected to your computer will no longer operate with full Wacom tablet functionality.
Windows XP: Click START. In the start menu, select CONTROL PANEL. Then select ADD OR REMOVE
PROGRAMS. In the ADD OR REMOVE PROGRAMS window, choose WACOM TABLET DRIVER and click on the
CHANGE OR REMOVE PROGRAMS button. Follow the prompts to remove the tablet driver.
Windows 2000:
1. Click the Windows START button. Then choose SETTINGS and CONTROL PANEL.
2. In the CONTROL PANEL window, double-click on the ADD/REMOVE PROGRAMS icon. In the dialog box that
appears, choose the WACOM TABLET DRIVER option.
3. Click on the ADD/REMOVE... button and follow the prompts to remove the tablet driver.
Macintosh OS X:
From the FINDER, choose APPLICATIONS from the GO menu and open the TABLET folder. Double-click on the
REMOVETABLET icon and select the REMOVE TABLET SOFTWARE button. After the removal is completed, click
OK.
Important: When the
Intuos3 pen is not in
use, place it in the pen
stand or lay it flat on
your desk. When the
optional Airbrush is not
in use, lay it flat on your
desk. To maintain the
sensitivity of your pen or
Airbrush tip, do not store
the tools in a container
where they will rest on
their tip or eraser.
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 69
69
Changing the tablet mode
Within the control panel’s TABLET list, double-click on the tablet icon to display the TABLET MODE dialog box.
The TABLET MODE setting applies to all tools and applications.
Installing multiple tablets
The TABLET list displays an icon for any supported tablet that has been detected on your system, and allows
you to select the tablet for which your changes will apply.
To add a new tablet, connect it to your computer.
• For USB tablets, the system searches the USB ports. When the new tablet is found, it is automatically
initialized.
• If multiple tablets are installed, the tablet used to open the Wacom Tablet control panel is selected as the
default tablet.
To remove one of multiple tablets from the driver, in the Wacom Tablet control panel select the tablet to
be deleted and click on the [ – ] button next to the TABLET list. Note that you will need to restart your
computer before you can re-add the tablet to the driver.
Recommended for
graphics applications.
This is the default
condition.
Maximum data rate.
Required by some
handwriting recognition
software.
Select a tablet icon for which to
customize tool and application
settings.
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 70
70
Intuos3 lens cursor
Available for use with 12x12 / A4 Oversize and 12x19 / A3 Wide tablet models, the lens cursor is an ideal
tool for entering precise coordinate position information into your computer. The lens cursor reports the
position of the cross-hair to the computer. This makes the lens cursor especially useful for tracing and
digitizing drawings into graphics and CAD applications.
The left button is set to
CLICK by default, and is
the primary button used
for selecting.
The middle button is
set to MIDDLE CLICK
by default.
The right button is set to RIGHT CLICK by default,
and displays a context menu when pressed.
Rotate lens for best viewing angle.
The left and right side rear buttons are set for BACK and
FORWARD functionality within your Internet browser.
Working with application-specific settings
Lens cursor equipped with programmable buttons.
The default setting for the Intuos3 lens cursor is MOUSE mode, enabling you
to move the screen cursor with a “pick up and slide” action similar to using a
traditional mouse. When using the lens cursor to digitize a drawing, the
lens cursor must be set to PEN mode.
Important: When the lens cursor is not in use, place it on your
desk. Leaving an Intuos3 tool on the tablet may interfere with
screen cursor positioning when using other pointing devices.
For order information on this and other available Intuos3 tools, see ordering
parts and accessories.
Mouse mode settings
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 71
71
Customizing the lens cursor
To modify your Intuos3 lens cursor button settings, use your lens cursor to open the Wacom Tablet control
panel and select the MOUSE tab. As with the Intuos3 pen, you can select a function to perform for each
button from the pull-down menus. See button functions for a description of the available options.
The lens cursor buttons are chordable; you can press two or more buttons simultaneously. For example, if
you program one button to simulate the CTRL key and another to simulate an ALT keystroke, when you press
both buttons a CTRL+ALT is simulated.
Note: To configure the Intuos3 lens cursor for left handed use, simply reassign the button functions as
needed.
Testing the lens cursor
1. With the DIAGNOSTICS dialog box open, place the Intuos3 lens cursor on the tablet’s active area and test
the buttons by clicking each button. The tablet status LED should change color, and the SWITCHES state
should change for each button you click.
2. When you are done, click on the CLOSE button to exit the dialog box.
123
54
Intuos3 lens cursor
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 72
72
Working with AutoCAD
AutoCAD can support the Intuos3 tablet as a Windows system pointing device or as a Wintab compatible
digitizer. By default, AutoCAD is configured to use Intuos3 as a system pointing device. If you will be using
Intuos3 with tablet menus or to digitize drawings to proper scale, you will need to follow the procedures
below.
Note: To configure the lens cursor or mouse for left handed use in AutoCAD or similar applications, open the
Wacom Tablet control panel, click on OPTIONS... and select LEFT in the HANDEDNESS group.
Configuring AutoCAD for a Wintab compatible digitizer
1. Start AutoCAD. Open the TOOLS menu and select OPTIONS.
2. From the OPTIONS window, select the SYSTEM tab.
3. Under CURRENT POINTING DEVICE, select the Wintab compatible digitizer option.
4. Decide from which device AutoCAD will accept input. Choose an option from the ACCEPT INPUT FROM
section:
•DIGITIZER ONLY. The AutoCAD drawing editor only accepts input from Intuos3.
•DIGITIZER AND MOUSE. The AutoCAD drawing editor accepts input from both Intuos3 and your
mouse.
5. Click OK to close the OPTIONS window.
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 73
73
Configuring tablet menus and screen pointing areas in AutoCAD
A screen pointing area is a rectangular region on the tablet surface where the tablet acts like a system
mouse. When the pointer is within a screen pointing area, the tablet can access windows, menus, and other
applications outside AutoCAD’s drawing area. You can configure both a fixed and floating screen pointing
area.
Before you configure the tablet, its entire surface is the fixed screen pointing area. AutoCAD recommends
that you change the size of the fixed screen pointing area so that a small screen area on your tablet maps to
the entire monitor screen. AutoCAD also recommends that you select the default tablet menus, columns,
and rows they provide.
After you configure the tablet menus, AutoCAD prompts you for the fixed and floating screen pointing areas.
This allows you to designate a tablet area as a Windows system pointer.
The fixed screen pointing area is disabled when you digitize points into AutoCAD with TABLET MODE ON.
This is due to the fixed correspondence between the tablet and AutoCAD’s drawing area. To access menus
from the tablet, you must use the floating screen pointing area. This allows you to access a menu from
anywhere on the tablet surface, and to toggle it off when finished. You can define a tool button to toggle the
floating screen area on and off.
Important. The floating screen pointing area takes precedence over menu areas, Tablet Mode On,
and the fixed screen pointing area.
1. From the DRAWING EDITOR, open the TOOLS menu (OPTIONS menu for Release 13).
2. Select TABLET, and then CONFIGURE.
3. Define tablet menu areas. Follow the prompts at the bottom of the AutoCAD Drawing Editor. Type the
number of tablet menu areas you want (0-4) and press ENTER. If you do not want to use a menu
template, type 0 (zero). Digitize the upper-left, lower-left, and lower-right corners of the menu area and
then press ENTER. Next, enter the number of columns and press ENTER. Now enter the number of rows
and press ENTER. Repeat for each menu area.
4. Define the fixed screen pointing area. By default, the entire tablet is a fixed screen pointing area. If you
are using a menu template, you should re-specify the fixed screen pointing area to match the template.
Continue to follow the prompts at the bottom of the AUTOCAD DRAWING EDITOR screen.
5. Define the floating screen pointing area – it allows you to access all areas of the screen. The floating
screen pointing area takes precedence over TABLET MODE ON, the fixed screen pointing area, and the
menu areas. Continue to follow the prompts at the bottom of the AUTOCAD DRAWING EDITOR screen.
Please check your AutoCAD documentation for additional information.
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 74
74
Calibrating Intuos3 for AutoCAD
If you are using Intuos3 to digitize a drawing, you will need to calibrate Intuos3 with the paper drawing’s
coordinate system. The calibration allows you to digitize points from the paper drawing into the appropriate
coordinate system of your drawing file.
1. From the DRAWING EDITOR, open the TOOLS menu (OPTIONS menu for Release 13).
2. Choose the TABLET and CALIBRATE options, then:
• Digitize point #1 on the paper drawing. Then enter the xy coordinate from the paper drawing at the
digitized point.
• Digitize point #2 on the paper drawing. Then enter the xy coordinate from the paper drawing at the
digitized point.
• Digitize more points if necessary. More than four points may take more time than expected for
AutoCAD to compute the best-fitting projective transformation.
3. Press ENTER when you are done.
When Intuos3 has been configured as a digitizer and calibrated, you can use CTRL+T to toggle between
using Intuos3 as a digitizer and as a Windows system pointer.
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 75
75
Product specifications
General specifications for all Intuos3 tablets
Intuos3 4x5 / A6 tablet (model PTZ-430)
Intuos3 6x8 / A5 tablet (model PTZ-630)
Intuos3 6x11 / A5 Wide tablet (model PTZ-631W)
Coordinate resolution 200 lpmm (5080 lpi)
Accuracy, pen +/- 0.25 mm (0.010 in)
Accuracy, mouse +/- 0.5 mm (0.020 in)
Accuracy, lens cursor +/- 0.15 mm (0.006 in)
Tilt range (all pens) +/- 60 degrees (+/- 50 degrees on Intuos3 4x5 / A6 tablets)
Reading height 6 mm (0.25 in)
Maximum report rate 200 points per second
ExpressKeys stroke 1 mm (0.04 in), approximately
Touch Strips (L x W) 52 mm (2.0 in) x 12 mm (0.47 in)
Communication interface USB
Connector USB A
Cable length 2.5 m (8.2 ft)
Power requirements DC 5V, less than 300 mA, from primary USB port or powered USB hub
Power consumption Less than 1.4 watts
Operating temperature 5 to 40 degrees C (41 to 104 degrees F)
Storage temperature -10 to +60 degrees C (14 to 140 degrees F)
Operating relative humidity 20% to 80% noncondensing
Storage relative humidity 20% to 90% noncondensing
Certification and compliance FCC class B, VCCI class B, CE, BSMI, MIC, C-Tick, SASO
Active area (W x D) 127.0 x 101.6 mm (5.0 x 4.0 in)
Physical size (W x D x H) 238.5 x 217.0 x 13.0 mm (9.4 x 8.5 x 0.5 in)
Weight 600 g (1.32 lb), approximately
Active area (W x D) 203.2 x 152.4 mm (8.0 x 6.0 in)
Physical size (W x D x H) 345.0 x 261.5 x 13.0 mm (13.6 x 10.3 x 0.5 in)
Weight 1 kg (2.2 lb), approximately
Active area (W x D) 271.0 x 158.8 mm (10.68 x 6.26 in)
Physical size (W x D x H) 417.6 x 262.0 x 14.0 mm (16.5 x 10.3 x 0.6 in)
Weight 1.4 kg (3.1 lb), approximately
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 76
76
Intuos3 9x12 / A4-regular tablet (model PTZ-930)
Intuos3 12x12 / A4 Oversize tablet (model PTZ-1230)
Intuos3 12x19 / A3 Wide tablet (model PTZ-1231W)
Intuos3 Grip Pen (model ZP-501E)
Intuos3 mouse (model ZC-100)
Intuos3 Airbrush (model ZP-400E)
The Airbrush is an optional accessory.
Active area (W x D) 304.8 x 228.6 mm (12.0 x 9.0 in)
Physical size (W x D x H) 439.5 x 340.0 x 14.0 mm (17.3 x 13.4 x 0.6 in)
Weight 1.8 kg (3.96 lb), approximately
Active area (W x D) 304.8 x 304.8 mm (12.0 x 12.0 in)
Physical size (W x D x H) 439.5 x 429.3 x 37 mm (17.3 x 16.9 x 1.5 in)
Weight 2.1 kg (4.62 lb), approximately
Active area (W x D) 508.0 x 317.5 mm (20.0 x 12.5 in)
Physical size (W x D x H) 622.5 x 429.3 x 37.0 mm (24.5 x 16.9 x 1.5 in)
Weight 3.0 kg (6.60 lb), approximately
Pressure levels 1024 levels
Eraser tip travel 1.3 mm (0.05 in), approximately
Physical size (L x D) 174.8 x 14.8 mm (6.89 x 0.58 in)
Weight 17g (0.60 oz), approximately
Physical size (L x D x H) 112.0 x 58.0 x 38.0 mm (4.41 x 2.28 x 1.50 in)
Weight 105 g (3.7 oz), approximately
Button stroke 1 mm (0.04 in), approximately
Fingerwheel type Rotation, 24 clicks per revolution
Fingerwheel travel 10 mm (0.39 in)
Fingerwheel resolution 1024 levels
Pressure levels 1024 levels
Eraser tip travel 1.3 mm (0.05 in), approximately
Physical size (L x W x D) 162.5 x 17.5 x 32.5 mm (6.40 x 0.69 x 1.28 in)
Weight 23.1 g (0.81 oz), approximately
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 77
77
Intuos3 Ink Pen (model ZP-130)
The Ink Pen is an optional accessory.
Intuos3 Art Pen (model ZP-600)
The Art Pen is an optional accessory.
Intuos3 Classic Pen (model ZP-300E)
The Classic Pen is an optional accessory.
Intuos3 lens cursor (model ZC-210)
The lens cursor is an optional accessory for use with the Intuos3 12x12 / A4 Oversize and 12x19 / A3 Wide
tablet models.
Pen tip travel 0.2 mm (0.008 in) or less
Pressure levels 1024 levels
Physical size (L x D) 151.5 x 12.5 mm (5.97 x 0.49 in)
Weight 12 g (0.42 oz), approximately
Pen tip travel 0.2 mm (0.008 in) or less
Pressure levels 1024 levels
Physical size (L x W x D) 146.7 x 15.5 x 12.5 mm (5.78 x 0.61 x 0.49 in)
Weight 14 g (0.49 oz), approximately
Pen tip travel 0.1 mm (0.004 in) or less
Pressure levels 1024 levels
Eraser tip travel 1.3 mm (0.05 in), approximately
Physical size (L x D) 150.7 x 12.2 mm (5.94 x 0.48 in)
Weight 12 g (0.42 oz), approximately
Physical size (L x D x H) 159 x 66 x 33 mm (6.26 x 2.60 x 1.30 in)
Weight 75 g (2.65 oz), approximately
Button stroke 1 mm (0.04 in), approximately
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 78
78
Product information
To learn more about which software applications are currently tablet enhanced to support the pressure-
sensitivity, tilt-sensitivity, eraser, and other special functionality of your Intuos3 tablet and tools, visit the
Wacom web site for your region:
Ordering parts and accessories
Your Intuos3 professional pen tablet is the ultimate master tool for creative professionals. The tablet,
combined with your Intuos3 Grip Pen and other available Intuos3 tools, enables you to paint more intuitively,
illustrate better, and edit imagery faster than ever before. Each Intuos3 Grip Pen and accessory features
Tool ID, which means they always remember your preferences and work together seamlessly. To further
expand the features of Intuos3, be sure to check out the accessories described on the following pages.
To purchase parts and accessories, refer to the tablet Read Me file and see who to call for your region.
You can also do the following:
To purchase parts and accessories in the USA or Canada, call 1.888.884.1870 (toll-free) or visit
Wacom’s web site at http://www.wacomdirect.com (USA only).
To purchase parts and accessories in Europe, call +49 (0)180 500 03 75 or send an email to
parts@wacom-europe.com. Or, visit www.wacom-europe.com/solutionstore. You can also contact your
local dealer, distributor, or Technical Support using the appropriate number for your region.
To purchase parts and accessories in other countries, please contact your local dealer or distributor.
USA, Canada, Central and South America http://www.wacom.com/productinfo
Europe, Middle East and Africa http://www.wacom-europe.com
Japan http://tablet.wacom.co.jp
Asia Pacific (English) http://www.wacom.com/ap
China (Simplified Chinese) http://www.wacom.com.cn/chanpin
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 79
79
Intuos3 Grip Pen (ZP-501E). Sensitive to pressure and tilt, the Grip Pen is an all-purpose
tool for use in drawing, erasing, and mouse operations. The easy-to-use DuoSwitch gives
you two programmable switch functions. The pressure-sensitive pen has an ergonomic,
waisted and rubberized grip area, optimum weight and balance, and superior tip sensitivity,
making it the most natural freehand tool.
Intuos3 mouse (ZC-100). The cordless, batteryless, five button mouse is an ideal tool for
performing any task you may have done previously with a standard mouse. It includes an
integrated middle button and rolling fingerwheel that can be used for up and down scrolling, or
it can be programmed for a variety of other actions.
Intuos3 Airbrush (ZP-400E). A true digital airbrush, the pressure-sensitive Intuos3 Airbrush
incorporates a pressure-sensitive tip and eraser, tilt sensitivity, and a fingerwheel that
provides an additional degree of control over the application of digital paint.
Intuos3 Ink Pen (ZP-130). This pressure- and tilt-sensitive drawing pen was created to
provide immediate feedback at your pen tip on the drawing as well as on your computer
screen. The pressure-sensitive Ink Pen comes with inking cartridges and two polyacetal tips
for inkless drawing. It has a pressure-sensitive tip, but no eraser and no side switches.
Note: When you purchase an Ink Pen, it comes with a blank nib in the pen. Use the nib puller
(silver ring) to gently remove the blank nib from the pen. Then insert one of the silver-colored
cartridges that come with the Ink Pen. The cartridge tip has a waxy coating that you will need
to rub off before you can begin inking.
Intuos3 Art Pen (ZP-600). This specialty pen provides 360 degrees of barrel rotation and,
like the Intuos3 Grip Pen, it is pressure and tilt sensitive. Combining these features with a
unique chisel-shaped nib makes the Intuos3 Art Pen the most realistic tool for emulating
brushes, markers, and calligraphic pens.
Intuos3 Classic Pen (ZP-300E). This pen has the same feature set as the Intuos3 Grip Pen,
but with a slimmer profile that does not include a rubberized grip.
Intuos3 lens cursor (ZC-210). Available for use with 12x12 / A4 Oversize and 12x19 / A3
Wide tablet models, the lens cursor is a precise coordinate position input tool. It is ideal for
tracing and digitizing drawings, for CAD processes, or for vector design applications where
the precise input of coordinate information is critical. The moveable lens can be swung from
left to right for comfortable positioning while you work.
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 80
80
Other parts and accessories
For order information, see ordering parts and accessories.
Description Part Numbers
Pen stand, for Grip Pen PST-A034
Replacement nibs for Grip Pen, Airbrush, or Classic Pen
Standard nibs (white) PSI-A007
Stroke nibs
Stroke nibs are spring-loaded, providing additional tactile feedback
when you are working with the Grip Pen. Airbrush, or Classic Pen.
Stroke nibs are gray in color and are installed in the same manner
as a standard pen nib. See replacing the pen tip.
PSI-A042
Felt nibs PSI-A043
Intuos3 Grip Pen accessory kit. Includes pen grip (for pen use without
side switch), replacement side switch, 5 standard nibs, 5 stroke nibs,
5 felt nibs, and a nib extractor tool.
FUZ-A118
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 81
81
Radio and television interference
The equipment described in this manual generates, uses, and can radiate radio-frequency energy. If it is not installed
and used properly—that is, in strict accordance with Wacom instructions—it may cause interference with radio and
television reception.
FCC notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
You can determine whether the tablet is causing interference by powering it off. If the interference stops, it was
probably caused by the tablet.
If your tablet does cause interference to radio or television reception, you may be able to correct the interference by
using one or more of the following measures:
• Rotate the television or radio antenna until the interference stops.
• Move the tablet farther away from the television or radio.
• Plug the tablet and computer into an outlet that is on a different circuit from the television or radio.
If necessary, consult your Wacom dealer or an experienced radio/television technician for help.
Changes or modifications to this product not authorized by Wacom could void the FCC Certification and negate your
authority to operate the product.
CE declaration
The Intuos® 3 digitizing tablets, models PTZ-430, PTZ-630, PTZ-631W, PTZ-930, PTZ-1230, and PTZ-1231W have
been tested and found to comply to the following harmonized European Norms:
• EN 55024 (electromagnetic immunity)
• EN 55022 Class B (electromagnetic emissions)
Based on the results of these tests, Wacom declares that the above mentioned devices conform to Article 10.1 of the
European Council Directive 89/336/EEC, and their amendment Directive 93/68/EEC, and indicates this conformity by
the CE-sign on each device.
The device must be installed and operated always in strict accordance to the instructions given in this handbook.
Any changes or modifications to this product that were not specifically authorized by Wacom will invalidate this
declaration.
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 82
82
License and Warranties
(Worldwide, Except for Europe, Africa and Middle East)
Software License
This legal document is an agreement between you, the end-user, and Wacom Technology Corporation (Wacom).
1. Grant of License.
The enclosed product includes computer programs embedded in firmware and accompanying
diskette or CD-ROM (the “Software”). The Software is licensed, not sold, to you for use only with Wacom products
upon the terms of this license, and Wacom reserves any rights not expressly granted to you. Wacom grants to you a
non-exclusive right to use this copy of the Software in conjunction with a Wacom product at a single location.
2. Ownership of Software.
Although you may own the product in which the Software is originally recorded, Wacom
retains ownership of the Software itself. You acknowledge that the Software is Wacom’s property, and contains
valuable confidential, unpublished information developed or acquired by Wacom at great expense, including data
processing algorithms, innovations and concepts. The Software is protected by copyright and other federal and state
laws. You agree to use your reasonable best efforts to protect the Software from unauthorized reproduction,
distribution, disclosure, use, or publication.
3. Copy Restrictions.
Unauthorized copying of the Software is expressly forbidden.
4. Use Restrictions.
You may not decompile, reverse assemble, disassemble or reverse engineer the Software.
5. Termination.
This License is effective until terminated. This License will terminate automatically without notice from
Wacom if you fail to comply with any provisions of the License.
6. Miscellaneous.
This License is governed by the laws of the United States of America and the state of Washington
except in Asia Pacific and by the laws of Japan for Asia Pacific.
Limited Warranty (U.S.A. and Canada)
Wacom warrants the product, to the original consumer purchaser, except for the Software and consumable items such
as the pen nibs, to be free from defects in materials and workmanship under normal use and service for a period of two
(2) years, from the date of original retail purchase, as evidenced by a copy of the receipt and registration with Wacom
by mail or online within 30 days of purchase.
The Software is licensed “as is.” Wacom makes no warranty with respect to its quality or performance. Wacom cannot
guarantee you uninterrupted service or the correction of any errors.
Upon discovery of a defect in the product, except in the Software, within the Warranty Period, you should contact
Wacom Technical Support via telephone, email, or fax to obtain an RMA (Return Merchandise Authorization) number
and instructions for shipping the product to a service location designated by Wacom. You should send the product,
shipping charges prepaid, to the designated service location, accompanied by the return authorization number, your
name, address and telephone number, proof of purchase date, and a description of the defect. Wacom will pay for
return shipping by United Parcel Service or by an equivalent service as chosen by Wacom.
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 83
83
Wacom’s sole obligation and entire liability under this warranty shall be, at Wacom’s option, either the repair or
replacement of the defective product or parts thereof of which Wacom is notified during the Warranty Period; provided,
however, that you are responsible for (i) the cost of transportation of the product to the designated service location and
(ii) any loss or damage to the product resulting from such transportation.
Wacom shall have no responsibility to repair or replace the product if the failure of the product has resulted from
accident, abuse, misuse, negligence, or unauthorized modification or repair, or if it has been handled or stored other
than in accordance with Wacom’s storage instructions.
Any descriptions, drawings, specifications, samples, models, bulletins, or similar material, used in connection with the
sale of the product, shall not be construed as an express warranty that the product will conform or comply with your
requirements.
EXCEPT FOR THE LIMITED WARRANTY DESCRIBED ABOVE, THERE ARE NO OTHER WARRANTIES MADE BY
WACOM ON THIS PRODUCT. NO ORAL OR WRITTEN INFORMATION OR ADVICE GIVEN BY WACOM, ITS
DEALERS, DISTRIBUTORS, AGENTS, OR EMPLOYEES SHALL CREATE A WARRANTY OR IN ANY WAY
INCREASE THE SCOPE OF THIS WARRANTY, AND YOU MAY NOT RELY ON ANY SUCH INFORMATION OR
ADVICE. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
WHICH VARY FROM STATE TO STATE.
WACOM LIMITS THE DURATION OF ANY LEGALLY IMPLIED WARRANTIES INCLUDING IMPLIED WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, TO THE DURATION OF WACOM’S
EXPRESS WARRANTY. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
NEITHER WACOM NOR ANYONE ELSE WHO HAS BEEN INVOLVED IN THE CREATION, PRODUCTION, OR
DELIVERY OF THIS PRODUCT SHALL BE LIABLE FOR ANY DIRECT, CONSEQUENTIAL, OR INCIDENTAL
DAMAGES (INCLUDING DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF
BUSINESS INFORMATION AND THE LIKE) ARISING OUT OF THE USE OF OR INABILITY TO USE SUCH
PRODUCT, EVEN IF WACOM HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. SOME STATES
DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
In the event that any of the above limitations are held unenforceable, Wacom’s liability for any damages to you or any
party shall not exceed the purchase price you paid, regardless of the form of any claim.
This Limited Warranty is governed by the laws of the United States of America and the state of Washington.
This Limited Warranty is valid for and only applies to products purchased and used inside the United States (and its
territories or possessions) and Canada.
Warranty Service in the U.S.A. and Canada
To obtain Warranty service within the U.S. or Canada contact:
Wacom Technical Support
Phone: 1.360.896.9833
Fax: 1.360.896.9724
E-mail: support@wacom.com
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 84
84
Warranty on Sales Outside of U.S.A. and Canada
For products purchased or used outside of the United States and Canada, the warranty period is one (1) year from the
date of original retail purchase. Upon discovery of a defect in the product, except in the Software, within the Warranty
Period you should contact your local dealer or distributor. In all other respects the terms of the warranty as set forth
above apply to such sales.
Should you have any questions about this Agreement, or if you desire to contact Wacom for any reason, please contact
in writing:
In North and South America contact:
Wacom Technology Corporation
1311 SE Cardinal Court
Vancouver, Washington 98683
U.S.A.
In Japan contact:
WACOM Co., Ltd.
2-510-1 Toyonodai
Otone-Machi, Kitasaitama-Gun
Saitama, 349-1148
Japan
In Asia Pacific contact:
WACOM Co., Ltd.
Harmony Tower 18F, 1-32-2 Hon-Cho,
Nakano-Ku, Tokyo 164-0012
Japan
In Mainland China
(Except Hong Kong) contact:
WACOM China Corporation
Room 611 CNT MANHATTAN BUILDING
No. 6, Chaoyangmen Bei Road. Beijing, China 100027
E-mail: support@wacom.com.cn
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 85
85
License and Warranty
(Europe, Africa and Middle East)
Software License Agreement
Important Notice to Customers
This product contains copyrighted computer programs (“software”) which are the inalienable intellectual property of
WACOM Europe GmbH (“WACOM”). This software is both integrated within the product and also contained on the
accompanying data carrier. The purchase of this product from your dealer does not include WACOM's software and
the associated rights of usage. WACOM grants you, the user, the right to use the software solely in accordance with
the conditions of this software license agreement. By purchasing this product you agree to the terms of this license.
Entitlement to Use the Software
WACOM grants the customer a personal, non-exclusive license to use the software solely in combination with this
product and for the proper operation of this product. This license may be transferred only in connection with this
product.
The use of this software includes solely the permanent or temporary, complete or partial copying of the software by
means of loading, displaying, executing, transmitting or saving for the purpose of executing the commands and data it
contains or of observing, examining or testing the functions of the software.
The customer may not license, lease or loan the software to a third party, nor allow a third party to access the software
in any other way. The customer may not without prior written authorization from WACOM copy, modify, transmit or edit
the software, apart from the actions of copying necessary to create a backup copy and for the purposes outlined in
section 2 above.
The customer may not decompile the software; if the software contains interfaces to software which is not supplied by
WACOM, WACOM shall make the necessary information available to the customer upon request, provided that the
customer can prove his/her entitle-ment to use the software and that he/she agrees to pay the copying and postage
costs.
Limited Warranty
WACOM warrants to you as the original end-user that the product hardware is free from defects in materials and
workmanship under normal use and service for a period of TWO (2) YEARS after the date of purchase (excluding
consumable items such as the pen nibs), provided that they are unused at the time of such purchase. WACOM further
warrants to you the accompanying data media against defects in materials and workmanship for a period of SIX (6)
MONTHS after the date of purchase.
The Software is licensed and distributed “AS IS”. WACOM makes no warranties, expressed or implied, with respect to
its quality, performance, merchantability and fitness for a particular purpose (including related manuals and
documentation). WACOM cannot guarantee you uninterrupted service or the correction of any errors.
Upon discovery of a defect in the product, except in the Software, within the applicable Warranty Period, you should
return them in the original packaging to the place of your original purchase, together with your name, address,
telephone number, a description of the problem and a copy of the original invoice. You are responsible for any loss or
damage to the product resulting from such transportation. WACOM's sole obligation and entire liability under this
warranty shall be, at WACOM's option, either the repair or the replacement of product or parts thereof that prove
defective and that were returned within the applicable Warranty Period.
APPENDIX
INDEX
CONTENTS
INDEX
CONTENTS 86
86
WACOM shall have no responsibility to repair or replace the product if (a), in the opinion of WACOM, the failure of the
product has resulted from accident, abuse, misuse, negligence, misapplication, or unauthorized modification or repair,
or (b) the product has been handled or stored other than in accordance with WACOM's storage instructions, or (c) the
failure is due to normal wear and tear, or (d) you fail to fulfill your obligations as described above.
In case that any claim presented under warranty is found upon investigation to be either outside the duration or the
scope of this warranty, or in case that the product is found to be not defective, then the cost of such investigation and
repair shall be borne by you.
Any descriptions, drawings, specifications, samples, models, bulletins, or similar material, used in connection with the
sale of the product, shall not be construed as an express warranty that the product will conform or comply with your
requirements.
Should any provision of this agreement be declared invalid, that provision shall be treated as separate from the
agreement, and the agreement shall remain in force without limitation in all other respects.
If this product is found to be defective, the purchaser may be entitled to institute legal proceedings against the seller on
grounds of liability for deficiency. The statutory rights indicated with regard to the seller are not limited in any way by
this warranty. Rather, this warranty affords the purchaser rights in addition to those indicated in the present text.
This limited warranty shall apply if the seller's corporate domicile is in the European Union or in Iceland, Norway,
Jersey, Switzerland, Russia, the Ukraine, Rumania, Bulgaria, Croatia, Serbia, Tunisia, Turkey, Syria, the Lebanon,
Jordan, Israel, Egypt, the United Arab Emirates, Iran or South Africa.
This Limited Warranty and Liability is governed by the laws of the Federal Republic of Germany.
Should you have any questions about this Agreement, or if you desire to contact WACOM for any reason, please
contact in writing:
WACOM Europe GmbH
Europark Fichtenhain A9
47807 Krefeld
GERMANY
INDEX
CONTENTS
INDEX
CONTENTS 87
87
GLOSSARY
Active area. The drawing area of the tablet where your Intuos3 tools are detected.
Application-specific settings. Intuos3 tool and tablet settings that have been customized for individual
applications. The Wacom Tablet control panel enables you to customize a tool to behave uniquely in
different applications. Your application-specific settings are in effect whenever you use the application.
See also working with application-specific settings.
Aspect. The ratio between the vertical and horizontal dimension of the tablet or display.
Click force. The amount of force you must apply to the tip of your pen for a click to occur.
Double-click assist. A function of the Wacom Tablet control panel that makes it easier to double-click by
setting the size of the double-click distance.
Double-click distance. The maximum distance (in screen pixels) that the cursor can move between clicks
and still be accepted as a double-click. Increasing the double-click distance makes double-clicking easier,
but may cause a delay in brush strokes in some graphics applications.
Double-click speed. The maximum time that can pass between clicks and still be accepted as a double-
click.
Eraser-aware application. A software application that has built-in support for the Intuos3 eraser. These
applications take advantage of the eraser in different ways, depending on what makes sense for
the application.
Fingerwheel. The control wheel on the Intuos3 mouse and optional Airbrush.
Landscape. A tablet ORIENTATION setting. In landscape orientation, the tablet status LED is oriented to the
top of the tablet. Rectangular tablets will be in a horizontal position. See also portrait.
Mapping. The relationship between your Intuos3 tool position on the tablet and the cursor position on the
monitor screen.
Modifier. Modifier keys include SHIFT, ALT, and CTRL for Windows, or SHIFT, CONTROL, COMMAND, and
OPTION for Macintosh. You can customize your Intuos3 tool to simulate a modifier key.
Mouse acceleration. A setting that allows you to adjust the screen cursor acceleration when your Intuos3
tool is in mouse mode.
Mouse mode. A method for positioning the screen cursor. When you place an Intuos3 tool on the tablet,
you can move the screen cursor with a “pick up and slide” motion similar to using a traditional mouse.
This is known as relative positioning, and is the default setting for the Intuos3 mouse or optional lens cursor.
See also pen mode.
Mouse speed. A setting that allows you to adjust the speed at which your screen cursor moves when your
Intuos3 tool is in mouse mode.
Nib. The replaceable pen tip.
GLOSSARY
INDEX
CONTENTS
INDEX
CONTENTS 88
88
Pen mode. A method of positioning the screen cursor. Wherever you place your Intuos3 tool on the tablet,
the screen cursor will jump to the corresponding point on the screen. This is known as absolute positioning,
and is the default setting for the Intuos3 pen. Also, PEN mode allows you to quickly position the screen
cursor without having to first find it and then move it across the desktop. See also mouse mode.
Pixel. The smallest unit of measure on your monitor screen.
Pop-up Menu. A window that displays a list of keystroke functions and other actions you can perform.
You can customize the buttons of your Intuos3 tools or tablet to display this menu.
Portrait. A tablet ORIENTATION setting. In portrait orientation, the tablet status LED is oriented to the side of
the tablet. Rectangular tablets will be in a vertical position. See also landscape.
Pressure sensitive. A quality of the Intuos3 pen tip and eraser that senses the amount of pressure being
applied. This is used to create natural-looking pen, brush, and eraser strokes in applications that are
pressure-sensitive.
Pressure-sensitive application. Any application that supports pressure-sensitive input.
Proximity. The height above the tablet’s active area where the Intuos3 tools are detected. See also the
pointing section.
QuickPoint. The QuickPoint options divide the tablet into two independent areas: a large area for drawing
and a small area for quick navigation.
Screen cursor. The pointer on the display screen. Screen cursors come in different shapes (such as an I-
beam, arrow, or box), depending on which application you are running.
Tilt sensitive. A quality of the Intuos3 pen tip and eraser that senses the amount of tilt between the tool and
tablet. This is used to create natural-looking pen, brush, and eraser strokes in applications that are tilt-
sensitive.
Tool ID. A feature that makes each Intuos3 tool unique. If you are working with two identical pens, the
tablet will recognize each one as a separate tool. This is particularly useful if you have customized each pen
differently.
USB. Universal Serial Bus. A hardware interface standard for connecting computer peripheral devices.
USB ports support hot-plugging, which allows you to connect or disconnect a USB device without turning off
your computer.
Wintab. An interface standard used by Windows applications for receiving tablet information.
Intuos3 supports all Wintab-compatible applications under Windows.
INDEX
CONTENTS
INDEX
CONTENTS 89
89
INDEX
About the manual 5
Accessories and parts
ordering 78
other parts and accessories 80
Adding a new tool 51
Airbrush
holding 20
replacing the tip 68
using 20
Application-specific settings
changing settings 54
creating 53
removing 54
working with 52
Art Pen, using 20
AutoCAD
calibrating for Intuos3 74
configuring for Intuos3 72
configuring screen pointing areas 73
configuring tablet menus 73
working with 72
Button functions 32
Care, for tools and tablet 67
CE declaration 81
Clicking, how to 14
Control panel
features 25
lists 26
opening 24
settings 26
tabs 26
Customizing
double-click 28
eraser feel 29
advanced 30
mouse 36
buttons 36
fingerwheel 37
pen 27
Pop-up Menu 50
tablet 44
ExpressKeys 45
Touch Strips 46
tablet to screen mapping 38
tilt sensitivity 35
tip feel 28
advanced 30
tool buttons 31
Touch Strips 46
advanced settings 49
keystroke settings 48
scroll settings 47
zoom settings 48
Diagnostics 57
Double-click, customizing 28
Double-clicking, how to 14
Dragging, with pen 14
Drawing
with pressure-sensitivity 16
with tilt 16
Driver downloads, obtaining 66
Environmental conditions 67
Eraser feel, customizing 29
advanced 30
Erasing 17
Eye-hand coordination exercise 18
FCC notice 81
Features
control panel 25
input tools 9
optional tools 10
tablet 8
Fingerwheel, mouse
customizing 37
using 19
Force Proportions 41
Functions, button 32
General problems, troubleshooting 61
INDEX
INDEX
CONTENTS
INDEX
CONTENTS 90
90
Holding
Airbrush 20
pen 12
Information, product 78
Input tools, features 9
Installing multiple tablets 69
Interference, radio and television 81
Lens cursor 70
customizing 71
testing 71
Macintosh-specific problems, troubleshooting 64
Manual, about 5
Mapping to multiple monitors 43
Mode 38
Mouse
buttons, customizing 36
customizing 36
testing 60
using 19
fingerwheel 19
Mouse mode 39
Multiple
monitors, mapping to 43
tablets, installing 69
New tool, adding 51
Nib, replacing 68
Optional tools, features 10
Ordering parts and accessories 78
Orientation 39
Parts and accessories
ordering 78
other 80
Pen
clicking with 14
customizing 27
double-clicking with 14
dragging with 14
drawing
with pressure-sensitivity 16
with tilt 16
erasing with 17
holding 12
pointing with 13
replacing the tip 68
testing 59
using 12
using side switch 15
Pen mode 38
Pointing, with pen 13
Pop-up Menu, customizing 50
Pressure-sensitivity, drawing with 16
Product information 78
Proximity 13
Radio and television interference 81
Removing settings 54
Screen area 40
Settings
changing for specific application and tool 54
control panel 26
removing 54
Side switch, using 15
Software
driver downloads 66
uninstalling 68
Specifications, product 75
12x12 / A4 Oversize tablet 76
12x19 / A3 Wide tablet 76
4x5 / A6 tablet 75
6x11 / A5 Wide tablet 75
6x8 / A5 tablet 75
9x12 / A4-regular tablet 76
Airbrush 76
Art Pen 77
Classic Pen 77
general 75
Grip Pen 76
Ink Pen 77
lens cursor 77
Mouse 76
Tablet
area 42
customizing 44
ExpressKeys
customizing 45
testing 58
using 22
features 8
mode, changing 69
INDEX
INDEX
CONTENTS
INDEX
CONTENTS 91
91
storing 67
testing 56
Touch Strips
customizing 46
testing 58
using 23
working with 21
Tablet to screen mapping, customizing 38
Technical Support, contacting 65
Testing
ExpressKeys 58
mouse 60
pen 59
tablet Touch Strips 58
tablets 56
tools 57
Tilt
drawing with 16
sensitivity, customizing 35
Tip feel, customizing 28
advanced 30
Tip, replacing 68
Tool buttons, customizing 31
Tools, testing 57
Touch Strip
advanced settings 49
customizing 46
keystroke settings 48
scroll settings 47
testing 58
using 23
zoom settings 48
Troubleshooting
general problems 61
Macintosh-specific problems 64
tables 61
Windows-specific problems 64
Uninstalling software 68
Using
Airbrush 20
Art Pen 20
mouse 19
mouse fingerwheel 19
pen 12
Wacom international offices 92
Windows-specific problems, troubleshooting 64
Work area, setting up 11
INDEX
CONTENTS
INDEX
CONTENTS 92
92
Wacom international offices
Wacom Technology Corporation WACOM Europe GmbH
1311 SE Cardinal Court Europark Fichtenhain A9
Vancouver, WA 98683 47807 Krefeld
U.S.A. Germany
Telephone Telephone
General: ++1.360.896.9833 General: ++49.(0)2151.3614.0
Fax: ++1.360.896.9724 Fax: ++49.(0)2151.3614.111
WACOM Co., Ltd. WACOM Co., Ltd.
2-510-1 Toyonodai Asia Pacific Office
Otone-Machi, Kitasaitama-Gun Harmony Tower 18F, 1-32-2 Hon Cho,
Saitama, 349-1148 Nakano-Ku, Tokyo 164-0012
Japan Japan
Telephone
Internet: http://tablet.wacom.co.jp General: +81.3.5309.1513
Fax: 81.3.5309.1514
WACOM China Corporation WACOM Digital Solutions Co., Ltd.
Room 611 CNT MANHATTAN BUILDING Gangnam Telepia B/D 9th Fl, 662-18
No. 6, Chaoyangmen Bei Road. Beijing, China 100027 Yeoksam-dong, Gangnam-gu, Seoul, 135-080
Korea
Telephone Telephone
General: ++86.(0)10.8528.2819 General: +82.2.557.3894
Fax: ++86(0)10.8528.2386 Fax: +82.2.557.3895
