ELEMNT BOLT GPS Bike Computer
The ELEMNT BOLT is the newest installation in the range of bike computers offered by Wahoo Fitness,
giving you plenty of functionality plus enabling you to measure your performance with ease. The feature
filled ELEMNT BOLT is the new, even more streamlined wireless bike computer in the series, enabling you
to do all the things you expect from a bike computer plus more.
The ELEMNT BOLT Bike Computer is designed to be used in conjunction with the ELEMNT companion
app, a free app which allows you to maximize the potential of the ELEMNT BOLT and makes getting the
most out of your workout an easier task.
As a stand alone device, the ELEMNT BOLT gathers information on temperature, elevation, location &
speed. By adding in additional sensors, the ELEMNT BOLT can gather a wealth of information to expand
your reporting ability on your workout.
Use with or without your smartphone when performing a workout and enjoy quick and easy automated up-
load of your rides when connected to wifi.
iOS: This product is designed for use on the iPhone 4s and newer, iPad 3rd gen
and newer, iPad mini, iPad Air, and iPod 5th gen and newer.
Android: This product is designed for use with Android devices compliant with the
Bluetooth 4.0 protocol running version 4.3 or newer & must allow Third
Party App Access to the Bluetooth 4.0 (Smart) Radio.
NOTE: Wahoo Fitness has not tested complete compatibility with all Android devices matching this
description. Please download the app from the Google Play Store to ensure that it installs on your
device before purchasing a product.
This product is shipped with the following:
• ELEMNT BOLT bike computer
• Standard Micro USB
• 2 x bike mounts (Stem & Aero Out-Front)
• Quickstart guide
• Important Product Info Guide
Setting Up:
This setup guide is intended to assist with readying your ELEMNT BOLT for first use and pairing
to the ELEMNT companion app.
ELEMNT BOLT Bike Computer:
1. Remove from packaging.
2. Turn on by pressing the power button located on the left side of the device. After first time load-
ing, a QR code will be displayed. You are now ready to start setting up the ELEMNT BOLT
with the ELEMNT companion app on your smartphone.
NOTE: Although the ELEMNT BOLT ships with approximately 50% charge, for best results, it is
recommended that the device be charged fully before performing your first workout.
PAIRING THE ELEMNT TO YOUR SMARTPHONE:
iOS USERS:
1. Download the ELEMNT companion app from the App Store.
2. Open the ELEMNT companion app & watch the introductory welcome video or skip to contin-
ue. Make sure you have bluetooth enabled on your mobile device.
3. Select Start to proceed with pairing the companion app to your ELEMNT BOLT.
4. If not turned on already, turn your ELEMNT BOLT on by pressing the button located on the left
hand side of the device.
5. Pair your ELEMNT BOLT with your smartphone by scanning the QR code displayed on the
ELEMNT BOLT. (Simply place the ELEMNT BOLT in front of your phone camera.)
NOTE: The ELEMNT companion app requires access to the camera in order to scan the QR
code. Please enable access to the camera when prompted.
6. When the dialogue box appears, select Pair to complete the pairing process.
7. The ELEMNT companion app will now display the login page. Log in by signing up to the Wa-
hoo Fitness Cloud or use your Facebook login to proceed.
NOTE: Login is necessary to backup your data and sync between devices. This step can be
skipped, but will be required in order to view your data on other devices.
8. Connect the ELEMNT BOLT to a wifi network to enable essential services such as:
• update of your device
• upload rides
• download maps & load routes
9. Log in to your favorite fitness sites and ELEMNT BOLT will automatically upload your rides
over wifi. Alternatively, select Next and add these later.
10. Complete a basic profile to be used with the ELEMNT BOLT. This information will be used to
calculate metrics such as calories and HR zones. Alternatively, select Next and add these later.
11. Enable Live Track if desired to allow you to see other riders on the ELEMNT BOLT and allows
other ELEMNT users to see you. Additionally, you can also share a link with family and friends
to view your location online.
12. If you choose to enable Live Track, you can also automatically share your location with others.
Add recipients via email to continue or select Next.
ANDROID USERS:
1. Download the ELEMNT companion app from the Google Play store.
2. Open the ELEMNT companion app & watch the introductory welcome video or skip to contin-
ue. Make sure you have bluetooth turned on.
3. Select “Start” to proceed with pairing the companion app to your ELEMNT BOLT.
4. If not turned on already, turn your ELEMNT BOLT on by pressing the button located on the left
hand side of the device.
5. Pair your ELEMNT BOLT with your smartphone by scanning the QR code displayed on the
ELEMNT BOLT. (Simply place the ELEMNT BOLT in front of your phone camera.)
NOTE: The ELEMNT companion app requires access to the camera in order to scan the QR
code. Please enable access to the camera if prompted.
6. The ELEMNT companion app will now display the login page. Log in by signing up to the Wa-
hoo Fitness Cloud to proceed.
NOTE: Login is necessary to backup your data and sync between devices. This step can be
skipped, but will be required in order to view your data on other devices.
7. Connect the ELEMNT BOLT to a wifi network to enable essential services such as update of
your device, upload rides, download maps & load routes.
8. Log in to your favorite fitness sites and ELEMNT BOLT will automatically upload your rides
over wifi. Alternatively, select Next and add these later.
9. Complete a basic profile to be used with the ELEMNT BOLT. This information will be used to
calculate metrics such as calories and HR zones. Alternatively, select Next and add these later.
10. Enable Live Track if desired to allow you to see other riders on the ELEMNT BOLT and allows
other ELEMNT users to see you. Additionally, you can also share a link with family and friends
to view your location online.
11. If you choose to enable Live Track, you can also automatically share your location with others.
Add recipients via email to continue or select Next.
After initial installation, the ELEMNT BOLT will perform a step-by-step tour. Read up on how to
use or select “Skip tour” to exit. Your ELEMNT BOLT is now set up and ready for action.
Attaching your ELEMNT BOLT to your Bike:
The ELEMNT BOLT comes with two mounts to use, depending on your preference:
• Aero Out-Front Mount
• Stem Mount
Choose the mount that best suits your riding style so that you can easily see the screen and access
the buttons safely. Take care when tightening to ensure that the ELEMNT BOLT will be secure
during your ride. For best results, tighten periodically to maintain a secure hold.
INSTALLING THE Aero OUT-FRONT MOUNT:
The Aero Out-Front Mount was designed to be used specifically with the ELEMNT BOLT to gen-
erate the most aerodynamic advantage. The Aero Out-Front Mount consists of a single mount, se-
cured with an allen key bolt (3mm).
NOTE: Allen key not supplied.
1. Begin by removing/loosening the allen key bolt so the Aero Out-Front Mount can slide over one
side of your handlebars.
2. When seated in your preferred location, replace/tighten the allen key bolt until the Aero Out-
Front Mount is securely fastened. The Wahoo logo should be facing upwards (and facing toward
you if you were seated on the bike). Your mount is ready to use.
INSTALLING THE STEM MOUNT:
• The Stem Mount consists of the following items:
• 4 x zip-ties
• Plastic Stem Mount
• Rubber Mount insert
1. Ensure that the Rubber Mount insert is sitting flush with the Plastic Stem Mount. The bike mount
is now ready to be installed.
2. Place the bike mount in alignment on the stem of your bicycle, ensuring that the rubber insert
side is facing down and the Wahoo logo is on top and facing towards you (if you were seated on the
bike). NOTE: This mount can also be installed on your handlebars if required.
3. Thread two of the zip-ties through the holes provided in the bike mount and tighten securely
around the bicycle stem.
4. When tightened to your satisfaction, trim any excess zip-tie cables. Your mount is ready to use.
TO INSTALL THE ELEMNT BOLT ON THE BIKE MOUNT:
1. Align the ELEMNT BOLT mount connector (on the back of the ELEMNT BOLT) with the bike
mount. The ELEMNT BOLT should be perpendicular to the bike mount, with the Wahoo logo on
the ELEMNT BOLT facing away from you.
2. Insert the ELEMNT BOLT mount connector into the bike mount.
3. Twist one quarter turn clockwise to secure.
TO REMOVE THE ELEMNT BOLT FROM THE BIKE MOUNT:
1. To remove, grip the ELEMNT BOLT securely and twist one quarter turn anticlockwise.
2. Lift the ELEMNT BOLT out of the bike mount.
Getting to Know your ELEMNT BOLT:
The ELEMNT BOLT interface consists of the following buttons:
Power Button (left side button): Use to power on/off or access the main menu. Easily add your
sensors at any time by tapping the power button and selecting the Add a Sensor.
History Button (bottom left button): Use to display recent workout history and weekly report.
More detailed workout information is available through the companion app when you connect to
wifi (upload of workouts is automatic).
The History button is also used to stop a workout or start a new lap during your ride.
Start Button (bottom center button): Use to start/pause/resume a workout, or toggle Main Menu
items on/off.
Page Button (bottom right button): Press the ‘Page’ button to switch between workout data,
climbing and navigation pages.
Menu Toggle (right side up/down buttons): Use to navigate the Main Menu or quickly see more
or less data by zooming in or out on any page when performing a workout.
LED indicators: LED indicators provide a quick way to see if you’re on pace with important per-
formance metrics. LED indicators can be set to indicate speed, power or HR.
Speed: The middle LED is your current average performance, LEDs to the right mean
higher than average and LEDs to the left mean below average.
Power: The LEDs will indicate your current power zone from left to right. Between 6 and 8
zones may be configured.
HR: The LEDs will indicate your current Heart Rate zone, from left to right.
Additionally, the LEDs are also used for notifications, page indication, turn by turn directions and
Strava Live Segments.
Settings Menu:
Backlight: Toggle On/Off/5 Seconds.
Location: Set to Indoor/Outdoor. (Will turn off GPS and elevation when indoors.)
LEDs: Toggle On/Off.
Sensors: View added sensors or add a new sensor. The ELEMNT BOLT will
automatically try to connect when you hold your compatible sensor nearby.
Forget Phone: Use this function to forget the current pairing and display a QR code to
enable phone pairing again.
System Info: Displays ELEMNT BOLT ID, version and performs advanced functions
such as manual update, enable factory reset or run setup:
Version: Displays current version and enables manual update over wifi.
Factory Reset: Restores settings to factory default. Warning: Will delete
all workouts stored on the device.
Run Setup: Enables selection of language, units, timezone, time & date.
Compliance Info: Displays ELEMNT BOLT compliance information.
Other Features & Points to Note:
Battery Life:
The ELEMNT BOLT is charged by using the Micro USB cable provided. When fully charged, the
ELEMNT BOLT will function for up to 15 hours.
NOTE: Running the backlight and LEDs continuously will diminish the battery at an accelerated
rate. For maximal battery life, use the backlight only when necessary and turn off LED notifica-
tions.
CHARGING YOUR BATTERY:
1. Gently remove the silicon dust cap covering the charging port on your ELEMNT BOLT.
2. Insert the plug of the Micro USB cable into the charging port.
3. Connect the Micro USB cable to a suitable power source to charge. e.g. a computer USB port,
or if using in conjunction with an AC adapter, to a wall outlet.
4. When charged, remove the Micro USB cable from the charging port.
5. Replace the silicon dust cap, ensuring that it is seated firmly to prevent moisture or dust from
entering the device.
NOTE: For best results and battery life, always charge to full capacity when possible. Additionally,
take care when handling the silicon dust cap. Always clean and dry the area surrounding the charg-
ing port thoroughly if it becomes wet or dirty, and do not plug into a power source until the area is
free of moisture or debris. Corrosion and damage to the ELEMNT BOLT may occur if not handled
correctly.
UPLOADING WORKOUTS:
The workout information displayed on the ELEMNT BOLT at the end of your ride only represents
a small portion of the data that is available for review. To access more information, upload your
workouts to the companion app or your preferred compatible application or website.
Upload preferences are managed via the companion app. (Automatic upload of workouts can be se-
lected via the Settings menu, and manual uploads can be managed via the Results menu.) Transfer
of workouts occurs automatically or manually whenever a wifi signal is present, sending data to
whichever apps or sites have been preauthorized to receive them. However, the Micro USB can also
be used to manually transfer workout data from the ELEMNT BOLT to another device.
• For PC users: Plug in your ELEMNT BOLT to your PC via the Micro USB and the internal
memory will function just like a flash drive. NOTE: European Windows 10 requires a patch:
https://www.microsoft.com/en-us/download/details.aspx?id=19153
• For Mac Users: An additional application is required to function as an interface - contact sup-
port@wahoofitness.com for more information.
Updating your Device:
App & firmware updates will be installed automatically when a wifi signal is present. Alternatively,
manual installation of app and firmware updates can be accessed via the Settings menu if required.
To perform a manual update:
1. Open the Settings menu on the ELEMNT BOLT.
2. Open System Info menu.
3. Scroll down to Check For Updates.
4. Select Check and download an update, if available. The Version information will read Up to
Date if no updates are available at this time.
NOTE: Automatic updates will only be performed after initial installation or just prior to powering
off, to prevent interfering with your use of the ELEMNT BOLT.
ALERTS/NOTIFICATIONS:
The ELEMNT BOLT can work in conjunction with your smartphone and display notifications dur-
ing your workout, as per your preference. If activated, phone calls, SMS and email alerts (iOS only)
will be temporarily displayed during your ride, and be accessible from the Settings menu. Dismiss
each alert from the Settings menu to view additional alerts. Turn this function on or off by access-
ing the Settings menu on your companion app.
NOTE: This feature requires you to have your phone with you during your ride.
Measuring Temperature:
The ELEMNT BOLT measures temperature during your workout, but occasionally may display
temperatures that differ from the true temperature of your surroundings. For example, this may oc-
cur when the device is placed in direct sunlight, is being charged via an external battery or subject
to sudden changes in temperature.
Multiple Same-Sensors & Data Management:
In the event that multiple same-information sensors are being employed (e.g. two speed sensors),
the ELEMNT BOLT uses a quality of data hierarchy to determine which sensors will be used to
gather data during your workout. In this scenario, if one sensor should fail, the ELEMNT BOLT
will automatically switch to the next data source and continue data gathering. Manual selection of a
duplicated data source is not available.
Adding Sensors:
Add sensors to gather more information during your workout and get a more comprehensive report
about your ride. Sensors can gather a multitude of information such as speed, heart rate, cadence,
power and much more. Adding a new sensor to your ELEMNT BOLT is as simple as waking up
your sensor & opening the Settings menu to access the Add a Sensor function. Place the sensor
close to the ELEMNT BOLT and you will be prompted to save after a few seconds. If you have
many close sensors then you will see a More option (bottom right button).
If you start your workout without waking up your additional paired sensors, you can still wake them
and they will begin to send data. Additionally, you can pair a new sensor at any time, even during a
workout.
ELEMNT companion App:
The ELEMNT companion app consists of four main areas: Ride, Results, Profile & Settings. To-
gether with your ELEMNT BOLT, the companion app enables you to record and personalize your
workout, view in depth data regarding your ride and share information with other apps and people.
Once set up, the ELEMNT BOLT does not require your smartphone to be nearby to record a
workout. However, please note that if using certain functions or sensors (e.g. alerts, Live Track),
they may require the smartphone to be nearby in order to operate. Plan your ride accordingly.
Ride:
The Ride menu enables you to manage your ride via the ELEMNT companion app and easily view
sensors, routes and more.
Before the ride: Use the Ride menu to configure your ride, select a route, or check your sensor sta-
tus.
During the ride: Use the Ride menu to see an up to date summary of your ride, select/change
routes, navigate to points of interest and view a map of your ride.
Sensors:
In the Ride menu, you can access and view the connection status of your paired sensors from the
top of the page. Select one of the sensor icons at the top of the page to view the Saved Sensors or to
add a new sensor. The ELEMNT companion app will allow you to add new sensors and manage
existing ones by using the auto detect function - just make sure your sensor is awake and nearby.
Routes:
Routes are intended to make navigating during your workout a breeze. There are a variety of ways
that routes can be created, from simple navigation to a destination, through to using previous
workout history or even importing routes from a preferred site.
Create Route:
There are two ways to make use of the Routes function - either in Outdoor or Indoor mode, depend-
ing on the kind of workout being performed:
In Outdoor mode: GPS and elevation detection is enabled for live tracking and workout
data recording.
In Indoor mode: GPS and elevation is disabled, as these functions are not required for in-
door training.
Use the Routes function to easily select a route for use on the road, or for indoor training as per
your workout needs:
• Search for Location: Got somewhere you want to go, but no planned route? Use this
feature to enable the Take Me Anywhere function, which will plan your route accordingly
from A to B and send it to the ELEMNT BOLT.
To make a new route:
1. Use the search tab to look for a location or tap a spot on the map to create a route.
2. Tap Select to sync the selected route with the ELEMNT BOLT.
NOTE: The ELEMNT BOLT must be turned on and connected via wifi in
order to receive routes from the companion app.
To remove a saved route:
1. Tap the route and either select Clear Route or Change Route to select a new destination.
• Create From History: You can create your own route for navigation or KICKR indoor
riding by selecting a ride from your saved history:
1. Select a ride from your displayed history to make into a new route.
2. A prompt will appear to enter a name for the route you are creating. Enter a name and
select ‘Done’.
3. Your new route will now be uploaded to your ELEMNT BOLT.
NOTE: The ELEMNT BOLT must be turned on and connected via wifi in
order to receive routes from the companion app.
• Sync From Web: You can authorize the following sites in order to automatically receive
routes to the ELEMNT BOLT:
• Strava
• RideWithGPS
• Komoot
• BestBikeSplit
NOTE: You must login & authorize access to the above sites in order to use this feature.
• Import File: Tap to open instructions on how to import a GPX or TCX file to your
ELEMNT BOLT:
1. Select a GPX/TCX file from a website, email attachment, dropbox folder, etc.
2. Tap on the GPX/TCX file, select ‘open in’.
3. Select ‘Copy to ELEMNT’.
NOTE: Your ELEMNT BOLT must have wifi connection and you must be
logged into your Wahoo Fitness account.
Once you have created a route and synced the details with ELEMNT BOLT, press Start on the EL-
EMNT BOLT to begin a workout and view navigation. Navigation will be displayed on the Routes
page on the ELEMNT BOLT, and within the Ride page on the companion app while the ride is in
progress. A basic summary will be displayed in the companion app in addition to the ride naviga-
tion.
Additionally, you can modify your route at any time by selecting the route name at the top of the
page to either clear the route, or change to an alternative route.
When your workout is complete and the ELEMNT BOLT syncs with the companion app, the Re-
sults page will be displayed on the companion app to show a detailed summary of your workout.
All Routes:
If you have imported or created a route for use on the ELEMNT BOLT, it will be displayed here
with a basic summary of the information regarding the ride.
Share Live Track Link: Export a link at any time containing your Live Tracking information with
friends or family to let them see where you’re at on your ride.
Results:
Displays your workout data and ride statistics. Select any workout to view more information. Addi-
tionally, manually upload your data to a third party app of your choice by selecting the Sharing icon
located in the top right corner of the screen.
NOTE: You will need to login and authorize sharing of information with the desired app in order to
export information.
You can delete a workout at any time by:
• iOS: Selecting Edit or swiping left. Using the Edit function enables you to multiple-select items
to be deleted. Select Delete to confirm.
• Android: Long press on the selected ride. Select Delete to confirm.
NOTE: Using the Edit function enables you to multiple-select items to be deleted.
Profile:
Edit your personal information or make modifications to your preferred settings here.
From the Profile page you can:
• Log in to the Wahoo Cloud: to enable automatic updates, backup and syncing of workout data.
• Access your Linked Accounts: to share workout data with the authorized apps of your choice.
• Edit your Profile: Create a profile by recording your personal information. Entering your details
enables fitness calculations such as calorie burn.
• FTP: Use the default or enter your Functional Threshold Power, if known.
• Heart Rate Zones: Use the default or enter your Heart Rate Zones, if known.
Settings:
1. Sensors & Data:
• Access this menu for the following functions:
• Customize Pages
• Set Up Sensors
• LEDs & Sound
Customize Pages:
Using the ELEMNT companion app, you can reconfigure the existing workout pages or configure
up to 5 personalized workout pages to be displayed on your ELEMNT BOLT.
To customize your ELEMNT BOLT display:
1. Ensure the ELEMNT BOLT is powered on and nearby.
2. Open the Settings menu in the companion app.
3. In the Sensors & Data menu, open the customize pages tab.
4. Toggle each desired workout page on or off for display on the ELEMNT BOLT.
To reconfigure a workout page:
1. Select a workout page to edit.
2. To change the data displayed as per your preference:
iOS: Tap to change a data field or drag to reorder.
Android:
1. Tap on an existing field to change your selection.
2. Use the Edit function to drag and reorder or delete data fields. (Select the blue handle to drag or
the red minus to delete.)
3. Select Done when finished, and use the Back button to exit.
To configure a new workout page:
1. Select Add Custom Page.
2. Name the new page when prompted and select Done to proceed.
3. Select 9 data fields to be displayed:
iOS:
• Tap to nominate the 9 data fields to be displayed and select Save.
• Tap to open the page you created and drag to reorder your preferences.
• When finished, select the Back button to exit.
Android:
• Select Add Data Field to choose a data type.
• Tap on an existing field to change your selection.
• Use the Edit function to drag and reorder or delete data fields. (Select the blue handle to drag or
the red minus to delete.)
• Select Done when finished, and use the Back button to exit.
To delete a workout page:
1. Select Edit or swipe left (iOS only) to nominate screens to be deleted.
2. Select Delete to confirm.
NOTE: The default workout pages cannot be deleted.
To restore workout pages to default:
1. Select Reset Pages.
2. Select Reset when prompted to return all pages to the default setting.
Set Up Sensors
Use sensors with the ELEMNT BOLT to collect & display more data during your workout. If you
have additional sensors like a power meter or heart rate monitor, you can add a new sensor from the
Settings menu on the companion app or on the ELEMNT BOLT itself.
TO ADD A NEW SENSOR:
1. Open the Settings menu on the companion app.
2. Select Set Up Sensors from the Sensors & Data menu.
3. The ELEMNT companion app will automatically begin to search for compatible sensors, just
make sure your sensor is awake and nearby.
4. Any available sensors will appear as a list. Tap on an unsaved sensor & select Save Sensor to
add it. The saved sensor(s) will be displayed in the Sensors menu.
TO FORGET A SENSOR:
1. Open the Settings menu on the companion app.
2. Select Set Up Sensors from the Sensors & Data menu.
3. Select the sensor to delete & select Forget Sensor to confirm.
LEDs & Sound
Toggle the LEDS and sound alerts on or off as per your preference.
2. Location & Maps
• Manage Maps: Manually add, remove and update map packs on your ELEMNT BOLT. You
will need a wifi connection to download maps, make sure you are prepared before you travel.
• Live Track: Toggle Live Track on to enable those with access privileges to see your location.
You will need to login or create a Wahoo Fitness cloud account to enable Live Track. If enabled,
share the link provided with anyone you wish to see your location during your ride.
• Auto Share Tracking Link (iOS only): Additionally, you can set up an Auto Share function on
your ELEMNT BOLT so that your friends and family will know your location each time you ride.
Simply nominate who to notify and the ELEMNT BOLT will do the rest.
• Always Rotate Map: Enable to have the map rotate so that you are always heading towards the
top of the display.
• Strava Live Segments: Connect with Strava to use Live Segments, automatically upload your
rides and more.
4. Ride
Toggle personal preferences for display during your workout.
• Auto Pause: Set as On for default, the Auto Pause function is used to prevent workout data from
being recorded during periods of inactivity. Workout recording will resume automatically with
detectable activity. Turn this function Off if all information, including inactivity, is to be record-
ed.
• Auto Lap: Set as Off for default, the Auto Lap function can be set to a given distance or time de-
pending on your preferences.
• Backlight: Set as Off for default, the backlight can be adjusted to be turned on for 5 seconds at a
time, or always on to improve visibility.
5. WIFI
The ELEMNT BOLT requires access to a wifi connection in order to perform automatic workout
uploads, firmware updates and download routes. Access to wifi is essential for proper functioning
of the ELEMNT BOLT.
• Wifi Network: Use this function to select a network to join.
• Automatic Upload: Toggle On to enable automatic upload of all rides to authorized websites
whenever ELEMNT BOLT is in wifi range.
6. Alerts
Alerts from your smartphone can be displayed as popups on the ELEMNT BOLT during a ride
when linked. Toggle Phone Calls, Messages and Email (iOS only) alerts as preferred. Additionally,
use the Do Not Disturb function to nominate a period of time when alerts will be disabled. You
must have your smartphone nearby and the ELEMNT companion app open in order to receive
alerts.
7. Config
Enable auto shutdown as per your preference.
8. Info
Displays the current version information for the ELEMNT BOLT. Additionally, if you need to un-
pair the ELEMNT BOLT, you can do so here.
UNPAIRING/PAIRING FOR IOS USERS:
A) BASIC UNPAIRING/PAIRING:
1. Open the Settings menu on the companion app.
2. While the ELEMNT BOLT is still connected, select Unpair ELEMNT BOLT from the Settings
menu. This will bring up a prompt recognizing that the ELEMNT BOLT is no longer paired to
the companion app, but still connected to the iPhone.
3. The prompt will ask whether you would like to pair again (does not require a QR code). Accept,
and the ELEMNT BOLT will pair to the companion app.
4. Alternatively, you may completely remove the ELEMNT BOLT and begin again, see Advanced
Unpairing/Pairing.
B) ADVANCED UNPAIRING/PAIRING:
1. On the ELEMNT BOLT, open the Settings menu and select Forget Phone. This will forget the
phone and cause the ELEMNT BOLT to reboot and return to the default workout screen. (If you
have the companion app open, you may notice during this time that the ELEMNT companion
app will say that it is searching.)
2. Open the ELEMNT BOLT Settings menu and select Pair Phone. A QR code will be displayed.
3. Open the companion app and select Unpair ELEMNT BOLT (either from the Settings menu, or
displayed on screen if the companion app is already open). The companion app will recommend
you also remove the pairing from the iPhone Bluetooth menu* and then prompt you to scan the
QR code displayed on the ELEMNT BOLT.
4. Hold the ELEMNT BOLT up to the phone camera to scan the QR code.
5. A prompt will appear on the companion app requesting to pair the ELEMNT BOLT with your
phone. Select Pair to complete the pairing process. If you do not select Pair (by allowing a
timeout) or you select Cancel, pairing will not proceed and you will need to select Pair Phone
again on the ELEMNT BOLT.
If the ELEMNT BOLT is not currently connected to the companion app, a searching screen will be
displayed on your smartphone. On this screen there will be an option to Unpair ELEMNT BOLT.
Unpairing your ELEMNT BOLT will prompt the companion app to begin the pairing process again.
Turn on your ELEMNT BOLT and continue as above from Step 2.
*NOTE: Although recommended, removing the existing pairing from your phone (accessible via
the iOS bluetooth settings) is not essential. You will notice that if you do not remove this pairing,
multiple entries will appear in your My Devices listing. These additional (defunct) entries can be
deleted at any time. To do this, open the phone Settings menu, access the Bluetooth menu and for-
get the unwanted ELEMNT BOLT pairing from My Devices.
UNPAIRING/PAIRING FOR ANDROID USERS:
1. Open the Settings menu on the companion app.
2. While the ELEMNT BOLT is still connected, select Unpair ELEMNT from the Settings menu.
3. A prompt will ask whether you would like to pair again. Accept, and the ELEMNT BOLT will
ask you to follow the prompts to pair to the ELEMNT BOLT:
4. Open the Settings menu on the ELEMNT BOLT.
5. Select Pair Phone.
6. Hold the QR code displayed on the ELEMNT BOLT up to the camera on your smartphone. The
ELEMNT BOLT will pair with your smartphone after a moment or two.
If the ELEMNT BOLT is not currently connected to the companion app, a searching screen will be
displayed on your smartphone. On this screen there will be an option to Unpair ELEMNT. Unpair-
ing your ELEMNT BOLT will prompt the companion app to begin the pairing process again. Turn
on your ELEMNT BOLT and select Pair on the companion app and then continue as above.
Performing a workout:
Starting your Workout:
1. Turn on your ELEMNT BOLT.
2. Open the ELEMNT companion app on your smartphone for additional features (Live Tracking,
notifications, etc.) Keep your smartphone nearby if performing a workout that requires phone
proximity.
3. After loading, press the Start button to begin your workout.
4. If you have additional paired (and awake) sensors, they will automatically start recording data.
During your Workout:
The ELEMNT BOLT will record temperature, elevation, speed & location plus any additional in-
formation as per your paired sensors. Any cessation of activity will result in the Autopause function
temporarily suspending data recording until activity resumes.
During the workout, there are several functions available:
• Press the Lap button to start a new lap (can be automated on the Companion app determined by
time or distance as per your preferences).
• Press the Pause button at any time to temporarily stop your workout.
• Press the Page button to scroll through the workout pages and maps (displayed as per default or
your preference).
• On the Maps page, use the Route button to open an imported route to use during your workout.
• Use the buttons on the right side of the ELEMNT BOLT to zoom in/out on a given page.
• Use the Settings menu to access notifications.
• If using a KICKR, you can access the KICKR controls as a workout page.
• Ride a Route & Turn By Turn…
• Take Me Anywhere….
• Strava Live Segments…
Ending your Workout:
1. Select Pause and then Stop to end your workout.
2. Select Yes when prompted to confirm.
Your basic workout data will now be available from the History page. Alternatively, connect to wifi
to either automatically or manually upload your data to the companion app for more detailed report-
ing on your workout.
WANT TO CONNECT TO ANOTHER APP?
The ELEMNT BOLT is able to share routes and workout data with a number of compatible third
party apps:
• Health app (iOS only)
• RideWithGPS
• Strava
• TrainingPeaks
• MapMyFitness
• Today’s Plan (Android)
• Komoot
• Best Bike Split
• SportTrack
• Dropbox
Sharing data is as simple as logging in and authorizing the app to enable access and you're away.
Access the Profile menu in the ELEMNT companion app to manage your Linked Accounts.
Troubleshooting:
Resetting the device: Sometimes, your device may require a reset. If not auto-prompted by the EL-
EMNT BOLT, you can perform one manually by doing either of the following:
• Forced Reboot: Hold down the power button for 10 seconds to perform a forced reboot. e.g.
Generally used if the screen becomes non-responsive.
• Factory Reset: Accessible from the Settings menu, restores settings to factory default. Warn-
ing: Will delete all workouts stored on the device.
For more information, check out our support FAQ: http://support.wahoofitness.com/hc/en-us or contact
Support for more information: support@wahoofitness.com
Design Specifications:
• Physical Dimensions (LxWxH): 74.5mm x 47.3mm x 22.1mm
• Display Size: 240 x 320 resolution, 44.2 mm x 33.4 mm, screen size 2.2” diagonal
• Weight: 22 oz
• Battery: lithium ion internal 1500mAh (rechargeable via Micro USB)
• Battery Life: Up to 15 hours
• Waterproof Rating: IPX7
Product Care Information:
Should the ELEMNT BOLT require cleaning, use a moist soft cloth or similar to remove any de-
bris. Strong cleaning agents are not recommended, as this may damage the device or reduce its
lifespan.
The ELEMNT BOLT uses as internal rechargeable battery, which is charged via a micro USB ca-
ble. The rechargeable battery in the ELEMNT BOLT is not removable. Any attempt to remove or
tamper with the battery may void the warranty for this device.
Product Warranty & Returns:
For information on the Wahoo Returns Policy or for product Warranty details:
http://www.wahoofitness.com/returns-and-warranty
