Wasp Barcode Technologies WDT92 WDT92 - Rugged Mobile Computer with bar code reader User Manual wdt92 ra

Wasp Barcode Technologies WDT92 - Rugged Mobile Computer with bar code reader wdt92 ra

Users Manual

Wasp Barcode Technologies
1400 10th Street
Plano, TX 75074
Telephone: 866-547-9277
Fax: 214-547-4101
©2018 Wasp Barcode Technologies. • ALL RIGHTS RESERVED. •
An Unpublished Work - All rights reserved. No part of the contents of this documentation or the procedures described
therein may be reproduced or transmitted in any form or by any means without prior written permission of Wasp
Barcode Technologies or its subsidiaries or affiliates ("Wasp"). Owners of Wasp products are hereby granted a non-
exclusive, revocable
license to reproduce and transmit this documentation for the purchaser's own internal business purposes. Purchaser
shall not remove or alter any proprietary notices, including copyright notices, contained in this documentation and shall
ensure that all notices appear on any reproductions of the documentation. Should future revisions of this manual be
published, you can acquire printed versions by contacting your Wasp representative.
Electronic versions may either be downloadable from the Wasp Barcode Technologies website (www.waspbarcode.com)
or provided on appropriate media. If you visit our website and would like to make comments or suggestions about this or
other Wasp publications, please let us know via the "Contact" page.
Disclaimer
Wasp Barcode Technologies ("Wasp") reserves all rights with respect to its trademarks, service marks, logos, and other
indicia ("Marks"). Any unauthorized use of any Wasp-owned Mark, or any use of a mark that is confusingly similar to, or
likely to cause confusion with, an Wasp-owned Mark, would constitute infringement of Wasp’s exclusive trademark
rights.
Logo of Wasp and Wasp "bug" are registered trademarks.
WDT92 is a registered trademark of Wasp Barcode Technologies.
All other brand and product names mentioned herein are for identification purposes only and may be trademarks or
registered trademarks of their respective owners.
Patents
See the Safety & Regulatory Addendum for patent list.
WDT92 - 2D Imager
This product is covered by one or more of the following patents:
Design patents: EP001942723, EP002421560, USD676850, USD677663, USD697067, USD704711, USD737822, USD779491,
ZL201230127985.6, ZL201230128017.7, ZL201430286638.7
Utility patents: EP0999514B1, EP0996284B1, EP1128315B1, EP1172756B1, EP1396811B1, EP1413971B1, EP1804089B1,
EP2315156B1, EP2517148B1, EP2649555B1, IT1396943, JP4435343B2, JP5192390B2, US6412698, US6415978,
US6512218, US6808114, US6877664, US6997385, US7053954, US7234641, US7387246, US8113430, US8888003,
US8915443, ZL200680050007.8, ZL200980163411.X.
WDT92 - 1D Imager
This product is covered by one or more of the following patents:
Design patents: EP001942723, EP002696088, USD676850, USD677663, USD697067, USD704711, ZL201230127985.6,
ZL201230128017.7, ZL201530439997.6
Utility patents: EP1128315B1, EP1396811B1, EP1413971B1, EP1797521B1, EP2517148B1, EP2649555B1, IT1396943,
US6098883, US6412698, US6415978, US6808114, US6997385, US7387246, US7506816, US8888003, US8915443,
ZL200980163411.X.
Cleaning The Device
Periodically clean the WDT92 device using a soft cloth slightly dampened with only water or Isopropyl Alcohol (70%).
Do not use any other cleaning agents (e.g. different alcohol, abrasive or corrosive products, solvents) or abrasive pads to
clean the device.
WDT92
Rugged Mobile Computer with 1D/2D Imager
Safety & Regulatory Addendum
852001240 (Rev. A) September 2018
General Safety Rules
Power Supply
The device is intended to be supplied by a self-contained rechargeable Lithium Ion battery pack
(UL listed LPS/SELV power source) and/or by UL Listed/CSA Certified Power Unit LPS/SELV
power source which supplies power directly to the unit via the micro USB connector of the cable.
The device could be also used with Certified Accessories (Dock/Cradle). The Dock/Cradle
accessories are intended to be supplied by a UL Listed/CSA Certified Power Unit LPS/SELV which
supplies power via the power connector of the cable.
Any changes or modifications to equipment, not expressly approved by Wasp could void the
user's authority to operate the equipment.
Battery Information
By default, the main battery pack is disconnected at the factory to avoid damage due to
excessive draining.
The rechargeable battery pack is less than half of full charge when delivered. Charge the battery
pack as indicated in the Quick Start Guide or in the User Manual, before using the WDT92
terminal.
The battery pack autonomy varies according to many factors, such as the frequency of barcode
scanning, RF usage, battery life, storage, environmental conditions, etc.
Close to the limits of the working temperature, some battery performance degradation may
occur.
The WDT92 should be charged at an ambient temperature between 0 - 35º C (32 to 95 ºF) to
achieve the maximum charging rate.
Never charge the device battery in a closed space where excessive heat can build up.
As a safety precaution, the battery may stop charging to avoid overheating.
The WDT92 may get warm during charging; this is normal and does not mean a malfunction.
Even if the storage temperature range is wider, it is recommended to store the terminal and the
batteries at environmental temperature, in order to achieve the longest battery life.
Battery Safety Guidelines
NOTE
Read carefully the WDT92 user manual (available at
www.waspbarcode.com
) before
performing any type of connection to the WDT92.
The user is responsible for any damage caused by incorrect use of the equipment or by
inobservance of the indication supplied in the user manual.
CAUTION
Before using the devices and the battery packs, read this Addendum carefully.
Use only the components and accessories supplied by the manufacturer for
the specific WDT92 being used.
Do not attempt to disassemble the WDT92 device, as it does not contain parts
that can be repaired by the user. Any tampering will invalidate the warranty.
When replacing the battery pack or at the end of the operative life of the
WDT92 device, disposal must be performed in compliance with the laws in
force in your jurisdiction.
Do not submerge the WDT92 in liquid products.
For further information or support, refer to the Wasp web site:
www.waspbarcode.com.
CAUTION
Do not incinerate, disassemble, short terminals, or expose to high temperature. Risk of fire and
explosion. Use specified charger only. Risk of explosion if the battery is replaced by an incorrect
type. Dispose of batteries as required by local authorities.
CAUTION
Avoid storing batteries for long periods in a state of full charge or very low charge.
We recommend charging the battery pack every two to three months to keep its charge at a
moderate level to maximize battery life.
Annual replacement of rechargeable battery pack avoids possible risks or abnormalities and
ensures maximum performance.
WARNING
Use only Wasp approved batteries and accessories for battery charging.
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Il y a risque d’explosion si la batterie est remplacée par une batterie de type incorrect.
Mettre au rebut les batteris usagées confor mément aux instructions.
WARNING
Installing, charging and/or any other action should be done by authorized personnel and
following this manual.
The battery pack may get hot, explode, ignite, and/or cause serious injury if exposed to
abusive conditions.
If the battery pack is replaced with an improper type, there is risk of explosion.
Do not place the battery pack in or near a fire or other heat source; do not place the battery
pack in direct sunlight, or use or store the battery pack inside unventilated areas in hot
weather; do not place the battery pack in microwave ovens, in clothes dryers, in high pressure
containers, on induction cook surfaces or similar devices. Doing so may cause the battery pack
to generate heat, explode or ignite. Using the battery pack in this manner may also result in a
loss of performance and a shortened life expectancy.
To power the cradle, use only a Wasp approved power supply. The use of an alternative power
supply will void the product warranty, may cause product damage and may cause heat, an
explosion, or fire.
The area in which the units are charged should be clear of debris and combustible materials or
chemicals.
Do not use the battery pack of this terminal to power devices other than this device.
Immediately discontinue use of the battery pack if, while using, charging or storing the battery
pack, the battery pack emits an unusual smell, feels hot, changes colour or shape, or appears
abnormal in any other way.
Do not short-circuit the battery pack contacts connecting the positive terminal and negative
terminal. This might happen, for example, when you carry a spare battery pack in your pocket
or purse; accidental short–circuiting can occur when a metallic object such as a coin, clip, or
pen causes direct connection of the contacts of the battery pack (these look like metal strips
on the battery pack). Short–circuiting the terminals may damage the battery pack or the
connecting object.
Do not apply voltages to the battery pack contacts.
Do not pierce the battery pack with nails, strike it with a hammer, step on it or otherwise
subject it to strong impacts, pressures, or shocks.
Do not disassemble or modify (i.e. bend, crush or deform) the battery pack. The battery pack
contains safety and protection devices, which, if damaged, may cause the battery pack to
generate heat, explode or ignite.
Wireless and Radio Frequencies Warnings
Laser Safety
The following information applies to Laser Aiming System, used on WDT92 variants with 2D
imager.
The laser light is visible to the human eye and is emitted from the window indicated in the figure
below.
LASER LIGHT - DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
MAX OUTPUT RADIATION 1 mW
COMPLIANT WITH EN 60825-1 (2007) and EN 60825-1 (2014)
WARNING
In case of leakage of liquid from the battery, avoid contact with liquid the skin or eyes. If the
contact occurs, immediately wash the affected area with water and consult a doctor.
Do not solder directly onto the battery pack.
Do not expose the battery pack to liquids.
Avoid any knocks or excessive vibrations. If the device or the battery is dropped, especially on
a hard surface, you should take it to the nearest Authorised Repair Centre for inspection
before continuing to use it.
If your device stops working for any reason, do not use its battery on other electronic devices
without a prior check and approval by an Authorised Repair Centre.
Do not replace the battery pack when the device is turned on.
Do not remove or damage the battery pack’s label.
Do not use the battery pack if it is damaged in any part.
Battery pack usage by children should be supervised.
Collect and recycle waste batteries separately from the device in compliance with European
Directive 2006/66/EC, 2011/65, 2002/96/EC and subsequent modifications, with US and
China regulatory laws and regulations about the environment.
WARNING
Use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications or attachments could damage the product and may violate laws and
regulations.
Most modern electronic equipment is shielded from RF signals. However, certain electronic
equipment may not be shielded against the RF signals generated by WDT92.
Wasp recommends persons with pacemakers or other medical devices to follow the same
recommendations provided by Health Industry Manufacturers Associations for mobile
phones.
Persons with pacemakers:
Should ALWAYS keep this device more than twenty five (25) cm from their
pacemaker and/or any other medical device;
Should not carry this device in a breast pocket;
Should keep the device at the opposite side of the pacemaker and/or any other
medical device;
Should turn this device OFF or move it immediately AWAY if there is any
reason to suspect that interference is taking place.
Should ALWAYS read pacemaker or any other medical device guides or should
consult the manufacturer of the medical device to determine if it is adequately
shielded from external RF energy.
In case of doubt concerning the use of wireless devices with an implanted medical device,
contact your doctor.
Turn this device OFF in health care facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities may use equipment that could be
sensitive to external RF energy.
RF signals may affect improperly installed or inadequately shielded electronic systems in
motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You
should also consult the manufacturer of any equipment that has been added to your vehicle.
An air bag inflates with great force. DO NOT place objects, including either installed or portable
wireless equipment, in the area over the air bag or in the air bag deployment area. If a
vehicle’s wireless equipment is improperly installed and the air bag inflates, serious injury
could result.
Turn off the device when in any area with a potentially explosive atmosphere. Observe
restrictions and follow closely any laws, regulations, warnings and best practices on the use
of radio equipment near fuel storage areas or fuel distribution areas, chemical plants or where
any operation involves use of explosive materials.
Do not store or carry flammable liquids, explosive gases or materials with the device or its
parts or accessories.
Areas with a potentially explosive atmosphere are often, but not always, clearly marked or
shown.
Sparks in such areas could cause an explosion or fire, resulting in injury or even death.
NOTE
The artwork below may be only a draft. Please refer to the label attached to the product for
information about certification marks.
Laser Warning Label
Printed Data Label
Marks Label
Scan Window
This document is an addendum to the Quick
Start Guide (QSG) for this product. See the QSG
for additional product information.
©2018 Wasp Barcode Technologies. All rights reserved.
Logo of Wasp and Wasp "bug" are registered
trademarks.
www.waspbarcode.com
ENGLISH
The following information is provided to comply with the rules imposed by international authorities and refers to the correct use of
your device.
STANDARD LASER SAFETY REGULATIONS
This product conforms to the applicable requirements of both CDRH 21 CFR 1040 and EN 60825-1 at the date of manufacture.
For installation, use and maintenance, it is not necessary to open the device.
The product utilizes a low-power laser diode. Although staring directly at the laser beam momentarily causes no known biological
damage, avoid staring at the beam as one would with any very strong light source, such as the sun. Avoid that the laser beam hits the
eye of an observer, even through reflective surfaces such as mirrors, etc.
ITALIANO
Le seguenti informazioni vengono fornite dietro direttive delle autorità internazionali e si riferiscono all’uso corretto del terminale.
NORMATIVE STANDARD PER LA SICUREZZA LASER
Questo prodotto risulta conforme alle normative vigenti sulla sicurezza laser alla data di produzione: CDRH 21 CFR 1040 e EN 60825-
1.
Non si rende mai necessario aprire l’apparecchio per motivi di installazione, utilizzo o manutenzione.
Il prodotto utilizza un diodo laser a bassa potenza. Sebbene non siano noti danni riportati dall’occhio umano in seguito ad una
esposizione di breve durata, evitare di fissare il raggio laser così come si eviterebbe qualsiasi altra sorgente di luminosità intensa, ad
esempio il sole. Evitare inoltre di dirigere il raggio laser negli occhi di un osservatore, anche attraverso superfici riflettenti come gli
specchi.
DEUTSCH
Die folgenden Informationen stimmen mit den Sicherheitshinweisen überein, die von internationalen Behörden auferlegt wurden,
und sie beziehen sich auf den korrekten Gebrauch vom Terminal.
NORM FÜR DIE LASERSICHERHEIT
Dies Produkt entspricht am Tag der Herstellung den gültigen EN 60825-1 und CDRH 21 CFR 1040 Normen für die Lasersicherheit.
Es ist nicht notwendig, das Gerät wegen Betrieb oder Installations- und Wartungs-Arbeiten zu öffnen.
Der Produkt benutzt eine Laserdiode. Obwohl zur Zeit keine Augenschäden von kurzen Einstrahlungen bekannt sind, sollten Sie es
vermeiden für längere Zeit in den Laserstrahl zu schauen, genauso wenig wie in starke Lichtquellen (z.B. die Sonne). Vermeiden Sie
es, den Laserstrahl weder gegen die Augen eines Beobachters, noch gegen reflektierende Oberflächen zu richten.
FRANÇAIS
Les informations suivantes sont fournies selon les règles fixées par les autorités internationales et se réfèrent à une correcte
utilisation du terminal.
NORMES DE SECURITE LASER
Ce produit est conforme aux normes de sécurité laser en vigueur à sa date de fabrication: CDRH 21 CFR 1040 et EN 60825-1.
Il n’est pas nécessaire d’ouvrir l’appareil pour l’installation, l’utilisation ou l’entretien.
Le produit utilise une diode laser. Aucun dommage aux yeux humains n’a été constaté à la suite d’une exposition au rayon laser.
Eviter de regarder fixement le rayon, comme toute autre source lumineuse intense telle que le soleil. Eviter aussi de diriger le rayon
vers les yeux d’un observateur, même à travers des surfaces réfléchissantes (miroirs, par exemple).
ESPAÑOL
Las informaciones siguientes son presentadas en conformidad con las disposiciones de las autoridades internacionales y se refieren
al uso correcto del terminal.
NORMATIVAS ESTÁNDAR PARA LA SEGURIDAD LÁSER
Este aparato resulta conforme a las normativas vigentes de seguridad láser a la fecha de producción: CDRH 21 CFR 1040 y EN 60825-
1.
No es necesario abrir el aparato para la instalación, la utilización o la manutención.
ITALIANO DEUTSCH FRANÇAIS ESPAÑOL
LA LUCE LASER È VISIBILE ALL'OCCHIO
UMANO E VIENE EMESSA DALLA
FINESTRA INDICATA NELLA FIGURA.
DIE LASER-STRAHLUNG IST FÜR DAS
MENSCHLICHE AUGE SICHTBAR UND
WIRD AM STRAHLAUS TRITTSFENSTER
AUSGESENDET (SIEHE BILD).
LE RAYON LASER EST VISIBLE À L'OEIL
NU ET IL EST ÉMIS PAR LA FENÊTRE
DÉSIGNÉE SUR L'ILLUSTRATION DANS
LA FIGURE.
A LUZ LÁSER ES VISIBLE AL OJO
HUMANO Y ES EMITIDA POR LA
VENTANA INDICADA EN LA FIGURA.
LUCE LASER NON FISSARE IL FASCIO
APPARECCHIO LASER DI CLASSE 2
MASSIMA POTENZA D'USCITA: 1 mW
LUNGHEZZA D'ONDA EMESSA: 630~680
nm
CONFORME A EN 60825-1 (2007) e EN
60825-1 (2014).
LASERSTRAHLUNG NICHT IN DEN
STRAHL BLICKEN PRODUKT DER
LASERKLASSE 2 MAXIMALE
AUSGANGSLEISTUNG: 1 mW
WELLENLÄGE: 630~680 nm
ENTSPR. EN 60825-1 (2007) und EN
60825-1 (2014).
RAYON LASER EVITER DE REGARDER LE
RAYON APPAREIL LASER DE CLASSE 2
PUISSANCE DE SORTIE: 1 mW
LONGUEUR D'ONDE EMISE: 630~680 nm
CONFORME A EN 60825-1 (2007) et EN
60825-1 (2014).
RAYO LÁSER NO MIRAR FIJO EL RAYO
APARATO LÁSER DE CLASE 2 MÁXIMA
POTENCIA DE SALIDA: 1 mW
LONGITUD DE ONDA EMITIDA:
630~680 nm
CONFORME A EN 60825-1 (2007) y EN
60825-1 (2014).
WARNING
Do not attempt to open or otherwise service any components in the optics cavity. Opening or servicing any part of the optics cavity by
unauthorized personnel may violate laser safety regulations. The optics system is a factory only repair item.
Use of controls or adjustments or performance of procedures other than those specified herein may result in exposure to hazardous
visible laser light.
Use of optical systems with the scanner will increase eye hazard. Optical instruments include binoculars, microscopes, eye glasses and
magnifying glasses.
ATTENZIONE
Non tentare di accedere allo scomparto contenete i componenti ottici o di farne la manutenzione.
L’apertura dello scomparto, o la manutenzione di qualsiasi parte ottica da parte di personale non autorizzato, potrebbe violare le norme
della sicurezza. Il sistema ottico può essere riparato solamente alla fabbrica.
L'utilizzo di procedure o regolazioni differenti da quelle descritte nella documentazione può provocare un'esposizione pericolosa a luce
laser visibile.
L’uso di strumenti ottici assieme allo scanner può aumentare il pericolo di danno agli occhi. Tali strumenti ottici includono cannocchiali,
microscopi, occhiali e lenti di ingrandimento.
ACHTUNG
Unter keinen Umständen darf versucht werden, die Komponenten im Optikhohlraum zu öffnen oder auf irgendwelche andere Weise zu
warten. Das Öffnen bzw. Warten der Komponenten im Optikhohlraum durch unbefugtes Personal verstößt gegen die Laser-
Sicherheitsbestimmungen. Das Optiksystem darf nur werkseitig repariert werden.
Jegliche Änderungen am Gerät sowie Vorgehensweisen, die nicht in dieser Betriebsanleitung beschrieben werden, können ein gefährliches
Laserlicht verursachen.
Die Verwendung von Optiksystemen mit diesem Scanner erhöht die Gefahr einer Augenbeschädigung. Zu optischen Instrumenten gehören
unter anderem Ferngläser, Mikroskope, Brillen und Vergrößerungsgläser.
ATTENTION
LNe pas essayer d’ouvrir ou de réparer les composants de la cavité optique. L’ouverture de la cavité optique ou la réparation de ses
composants par une personne non qualifiée peut entraîner le nonrespect des règles de sécurité relatives au laser. Le système optique ne
peut être réparé qu’en usine.
L'utilisation de procédures ou réglages différents de ceux donnés ici peut entraîner une dangereuse exposition à lumière laser visible.
L’utilisation d’instruments optiques avec le scanneur augmente le danger pour les yeux. Les instruments optiques comprennent les
jumelles, les microscopes, les lunettes et les verres grossissants.
ATENCIÓN
No intente abrir o de ninguna manera dar servicio a ninguno de los componentes del receptáculo óptico. Abrir o dar servicio a las piezas del
receptáculo óptico por parte del personal no autorizado podría ser una violación a los reglamentos de seguridad. El sistema óptico se
puede reparar en la fábrica solamente.
La utilización de procedimientos o regulaciones diferentes de aquellas describidas en la documentación puede causar una exposición
peligrosa a la luz láser visible.
El uso de sistemas ópticos con el escáner aumentará el riesgo de daños oculares. Los instrumentos ópticos incluyen binoculares,
microscopios, lentes y lupas.
El aparato utiliza un diodo láser a baja potencia. No son notorios daños a los ojos humanos a consecuencia de una exposición de
corta duración. Eviten de mirar fijo el rayo láser así como evitarían cualquiera otra fuente de luminosidad intensa, por ejemplo el sol.
Además, eviten de dirigir el rayo láser hacia los ojos de un observador, también a través de superficies reflectantes como los espejos.
.
LED Class
LED illuminators integrated in the 1D and 2D imager are classified as "EXEMPT RISK GROUP" according to IEC62471.
FCC/IC Labeling
FCC Compliance
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)this device may not cause harmful interference, and
(2)this device must accept any interference received, including interference that may cause undesired operation.
NOTICE:
This device is restricted to indoor use when operated in the 5.15 to 5.25 GHz frequency range.
Changes or modifications made to this equipment not expressly approved by Wasp may void the FCC authorization to operate this
equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
ISED Compliance
NOTICE:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1)this device may not cause harmful interference, and
(2)this device must accept any interference received, including interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre
le fonctionnement.
CAUTION
(i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-
channel mobile satellite systems;
(ii) high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350MHz and 5650-5850 MHz and that
these radars could cause interference and/or damage to LE-LAN devices.
AVERTISSEMENT:
(i) les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de
réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux;
(ii) les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5
250-5 350 MHz et 5 650-5 850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
Radiofrequency Radiation Exposure Information
This device was tested for handheld and body-worn conditions, according to international Standards covering human exposure to
electromagnetic fields from radio devices.
More information about the relevant Standards for SAR measurement methods and procedures may be found in the CE DoC included
in the product user manual available at www.waspbarcode.com website and at the FCC public listing www.fcc.gov under the FCC IDs
specified in the FCC/IC labeling section.
US and Canada
For body worn operation, this device has been tested and meets the FCC/ISED RF exposure guidelines for use with an accessory that
contains no metal and the positions the handset a minimum of 0 cm from the body. Use of other enhancements may not ensure
compliance with FCC/ISED RF exposure guidelines.
Cet équipement peut être installé et utilisé à une distance minimale de 0 cm entre le radiateur et votre corps.
The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter,
expect those approved under the filing.
FCC ID: C53WDT92
IC: 11678A - WDT92
HVIN: WDT92 WB HH
Radio Technologies and Frequency Bands
WDT92 incorporates the following radio technologies and supports the corresponding Frequencies and Radio-Frequency
transmitted power, as specified below:
Radio Technology Frequency Bands
WLAN IEEE 802.11b/g/n
SISO 20MHz channels bandwidth (HT-20)
MIMO support 20MHz channels bandwidth (HT-20)
2.4GHz Frequency Bands:
2.412 – 2.462 MHz
WLAN IEEE 802.11a/n
SISO 20MHz and 40Mhz channels bandwidth (HT-20 and HT-40)
5GHz Frequency Bands:
5.180 – 5.240 MHz
5.260 – 5.320 MHz
5.500 – 5.700 MHz
5.735 – 5.825 MHz
Bluetooth® V4.0 – EDR/LE 2402-2480Mhz

Navigation menu
