Wave Multimedia YUNTAB-H8 MID User Manual
Shenzhen Wave Multimedia Co.,LTD MID
User manual
User Manual
Model:H8
Brand:YUNTAB
CONTENTS
Assembling---------------------------------------------------------------------------------------------------- 1 -
Unpack------------------------------------------------------------------------------------------------------- 1 --
Charge the battery ----------------------------------------------------------------------------------------- 1 -
Getting started ----------------------------------------------------------------------------------------------- 2 -
Device layout ----------------------------------------------------------------------------------------------- 2 -
Turn your device on and off------------------------------------------------------------------------------ 2 -
Airplane mode---------------------------------------------------------------------------------------------- 2 -
Use the touch panel---------------------------------------------------------------------------------------- 3 -
Home screen ------------------------------------------------------------------------------------------------ 4 -
Task bar------------------------------------------------------------------------------------------------------ 4 -
Notification panel------------------------------------------------------------------------------------------ 5 -
Lock & unlock the screen -------------------------------------------------------------------------------- 6 -
Security ------------------------------------------------------------------------------------------------------ 6 -
Auto rotation------------------------------------------------------------------------------------------------ 6 -
Enter text ---------------------------------------------------------------------------------------------------- 6 -
Manage applications--------------------------------------------------------------------------------------- 7 -
Reset tablet-------------------------------------------------------------------------------------------------- 7 -
Communication---------------------------------------------------------------------------------------------- 7 -
Contacts------------------------------------------------------------------------------------------------------ 9 -
Messaging------------------------------------------------------------------------------------------------- 10 -
Email ------------------------------------------------------------------------------------------------------ - 11 -
Gmail------------------------------------------------------------------------------------------------------- 12 -
Web---------------------------------------------------------------------------------------------------------- - 13 -
Browser---------------------------------------------------------------------------------------------------- 13 -
Play Store-------------------------------------------------------------------------------------------------- 14 -
Talk--------------------------------------------------------------------------------------------------------- 14 -
Entertainment--------------------------------------------------------------------------------------------- - 14 -
Gallery ----------------------------------------------------------------------------------------------------- 14 -
Music------------------------------------------------------------------------------------------------------- 16 -
Camera----------------------------------------------------------------------------------------------------- 16 -
Tools--------------------------------------------------------------------------------------------------------- - 18 -
Calendar --------------------------------------------------------------------------------------------------- 18 -
Alarm ------------------------------------------------------------------------------------------------------ 19 -
File Manager---------------------------------------------------------------------------------------------- 19 -
Sound Recorder ------------------------------------------------------------------------------------------ 19 -
Calculator ------------------------------------------------------------------------------------------------- 19 -
Connectivity ----------------------------------------------------------------------------------------------- - 20 -
USB Connection ----------------------------------------------------------------------------------------- 20 -
Wi-Fi ------------------------------------------------------------------------------------------------------- 20 -
Safety Precautions---------------------------------------------------------------------------------------- - 21 -
Care & Maintenance------------------------------------------------------------------------------------- - 22 -
Assembling
Unpack
Check your product box for the following items.
Tablet
User manual
Adapter
You can purchase additional accessories from your local retailer.
Charge the battery
Before using the device for the first time, you must charge the battery.
1． You can charge the device with a travel adapter or by connecting the device to a PC with a
USB cable.
2． Battery full icon is shown when finished if your device is off.
Warning：Use only original batteries and chargers. Unapproved chargers or cables can cause
batteries to explode or damage your device.
- 1 -
Getting started
Device layout
Icon
Function
Remark
Press and hold for 2 seconds to turn on or turn off
the device.
Power
Lock
Press to lock the device.
Reset
Press and hold for 10 seconds to reset the device.
Volume keys
Adjust the device volume.
TF Card
Inset the Micro SD Card
Turn your device on and off
To turn on your device, press and hold the power key.
To turn off your device, press and hold the power key, and then tap OK.
Airplane mode
To use only your device’s non-network services, switch to flight mode. Please follow the
instructions below to turn on flight mode:
Tap SettingsWIRELESS & NETWORKSMoreAirplane mode from application list to create a
checkmark.
- 2 -
Use the touch panel
You can operate the icon, button, keyboard by the touch panel.
Including：
Touch:
To access an application, touch it with your finger.
For example: Touch an application icon, you can open
the application.
Touch and Hold:
To enter the available options for an item, touch and hold
the item.
Slide/Swipe:
Slide the screen to scroll up and down the applications,
images, web pages… at your convenience. You could
slide the screen horizontally too.
Drag:
Place your finger on the screen to drag an object to
another location.
Pinch/Spread:
Place your fingers of one hand on the screen surface and
draw them apart or together to scale an element on the
screen.
- 3 -
Home screen
You can bring all the items (applications, shortcuts, folders and widgets) you love or use most
frequently to your Home screen for quick access. Press the Home key to switch to Home screen.
Home screen is provided in an extended format to allow more space for adding applications,
shortcuts etc. Slide the Home screen horizontally left and right to get a complete view of the
Home screen. The white short line at the lower part of the screen indicates which screen you are
viewing..
Task bar
The task bar is shown at the bottom of the screen. It displays commonly used option buttons,
battery level indicator, current time and other indicator icons.
1
2
3
4
5
Return to previous screen.
Return to home screen.
View the applications you have accessed recently.
Open application menu
Display notification icons. Tap the notifications area to open the notification panel.
- 4 -
5
5
5
5
5
5
5
5
4
1
5
2
5
3
5
Notification panel
Tap the notifications area to open the notification panel shown below. You can access a list of
notifications.
Tap icon to activate or deactivate wireless connection features and other settings.
Indicator icons
Icon
Definition
Icon
Definition
Open WiFi available
Flight mode activated
WiFi connected
Uploading
data
Downloading data
Connected to PC
Alarm activated
BT connected
New email
New text or multimedia message
Battery power level
Music being played
- 5 -
Lock & unlock the screen
To unlock the screen, tap and hold the lock icon, then drag it to the unlock area where the unlock
icon is.
To lock the screen manually, press Power key.
Security
You can protect your device and data by setting screen lock or encrypting your tablet.
Set a screen lock
To set a screen lock, tap SettingsSecurityScreen lock from application list.
None：Deactivate the screen lock.
Slide：Slide to unlock the screen.
PIN：Enter a numeric PIN to unlock. When prompted, enter the PIN to unlock the
screen.
Pattern：Draw a pattern to unlock. Follow the instructions to draw your lock
pattern. When prompted, draw the pattern to unlock the screen.
Password：Enter a passcode to unlock. When prompted, enter the passcode to
unlock the screen.
Screen time-out
Select SettingsDisplaySleep from application list, you can set the time before the screen
times out and goes into lock mode. ( you have not entered any characters or made other
selections).
Auto rotation
If you rotate the device while using some features, the interface will automatically rotate as well.
To prevent the interface from rotating, open the notifications panel and select Auto-rotate
screen
, then scroll it to Off.
Enter text
You can enter text by selecting characters on the virtual keyboard.
Tap the text input field to display the virtual keyboard. To hide the keyboard, tap
at the task
- 6 -
bar.
To change the text input method, tap
at the task bar.
From a text field, you can use the copy and paste feature for fast inputting.
Manage applications
To manage the applications installed on your device, tap SettingsApp.
1.
To uninstall an application, select DOWNLOADED, then select an item and tap Uninstall, tap
OK to confirm.
2.
To stop or change the settings of an application, select RUNNING or ALL, then select an item
and tap the option you need.
Reset tablet
You can reset system and desktop settings to their original values by the following steps:
1.
2.
3.
Select SettingsBackup & reset from application list.
Tap Factory data reset.
If you want to erase all data on your tablet, such as music, pictures, and other data, tap Erase
SD card checkbox to create a checkmark.
4.
Tap Reset tablet.
The device resets to the factory default settings automatically.
Warning!: Factory data reset will erase all data from your device and SD card, including your
google account, system and application data and settings, and downloaded applications.
Communication
Phone
To use calling functions, tap Phone from application list.
Make calls
To make calls, you can use any of the three ways:
Enter numbers by using the virtual numeric keypad on the screen
Make a call from call log.
Make a call from contacts.
- 7 -
Answer a call
To answer a call, drag the circled button to the green button.
Decline or end a call
To decline a call, drag the circled button to the red button.
To end a call in progress, tap the red button.
Call settings
To change call settings, tap the option button at the upper right.
1.
Ringtone & Vibrate
You can set different ringtones for incoming calls. Select Phone ringtone to open a list of
ringtones, select the desired ringtone, and then select OK to confirm.
Tap Vibrate when ringing to create a checkmark and the tablet vibrates to notify you of
incoming calls.
2.
3.
Dial pad touch tones
Tap Dial pad touch tones to create a checkmark and your device will sound a tone once you
tap the dial pad.
Voice mail
With the call divert network service, you can direct incoming calls to your voice mailbox.
Tap Service to set your voice mail service provider.
Tap Setup to set your voice mail number.
Tap Sound to set the desired ringtone for your voice mail.
Tick the box next to Vibrate and the tablet vibrates to notify you of a voice mail.
4.
5.
Fixed Dialing Numbers
If FDN mode is activated, your device will restrict outgoing calls, except for the numbers
stored in the FDN list.
Quick responses
Quick response is a feature to reject the call with the predefined messages.
Tap one of the pre-written messages to be displayed when you want the call to be rejected,
then tap OK.
6.
7.
Call forwarding
Call diverting is a network feature to send incoming calls to another number that you specify.
Call waiting
If call waiting is activated, the network notifies you of a new incoming call while you have a
call in progress or you can make a new call during a call.
- 8 -
Contacts
Tap People from application list to access contacts.
Groups：List all your contacts by group.
All：List all your contacts saved in the device memory.
Favorites：List the contacts that you have set as favorites or the contacts that you
have sent message to or dialed.
1.
2.
3.
4.
1.
2.
3.
4.
1.
2.
3.
4.
1.
2.
3.
4.
Add new contact
Access People.
Tap
.
Enter necessary fields.
Tap DONE.
Edit a contact
To edit a contact, scroll to the contact you want to change.
Tap the option button at the upper right
Change necessary fields.
Tap DONE.
, then select Edit.
Create new group
Tap the option button at the upper right
.
Tap
at the upper right.
Enter a category name.
Tap DONE.
Rename group
To rename the group, scroll to the group you want to change.
Tap
at the upper right or tap the option button and then select Edit.
Enter a new category name.
Tap DONE.
Import/Export contacts
- 9 -
2.
Import from SD card
To import contact files (in vcf format) from a memory card to your device, tap the option
button at the upper right and then select Import/ExportImport from SD card, select a
memory location and contact files to import and select OK.
Export to SD card
3.
4.
To export contacts from your device to a memory card, tap the option button at the upper
right and then select Import/ExportExport to SD card, select OK to confirm.
Share visible contacts
With this feature, you can send the visible contacts via Email.
Search for contacts
1.
Tap
at the title bar from contact list screen, enter the desired information, then your
device shows the result.
2.
Tap the search icon at the upper left from home screen, enter the contact’s name or number,
your device shows the result immediately.
Messaging
Learn to create and send a text or multimedia message, and view or manage messages that you
have sent or received.
1.
2.
1.
2.
View messages
Tap Messaging from application list.
Tap the message to view the detailed information.
Create and send SMS
Tap NEW MESSAGE.
In To field, enter the recipient’s mobile phone numbers manually. If you enter more
than one number, separate the numbers with a comma.
In Type message, enter the text of the message.
3.
4.
Tap
to send the message.
Create and send MMS
Multimedia message can include pictures, sound and text.
1.
2.
Tap NEW MESSAGE.
at the title bar.
Tap
- 10 -
3.
Select one of the items below.
Pictures: Insert image.
Capture picture：Capture new picture and insert the picture.
Videos: Insert video clip.
Capture video: Capture new video clip and insert the video clip.
Audio: Insert sound clip.
Record audio: Record sound clip and insert the sound clip.
Slideshow: Add more than one slide.
4.
In To field, enter the recipient’s mobile phone numbers or email addresses manually. If
you enter more than one number or email, separate them with a comma.
In Type message field, enter the text of the message.
5.
6.
Tap
to send the message.
Email
To receive and send mail, you must have a remote mailbox service. This service may be offered by
Your device is compliant with applicable internet standards for
a
service provider.
POP3/IMAP/Exchange.
Before you can send or receive mail on your device, you need to set up an email account and
define the email settings correctly. You can define more than 1 mailbox.
1.
2.
3.
Set up your email
Tap Email from application list.
You can use mailbox guide to set up your mailbox, tap Next until it’s done.
If you need to add another email account, tap the option button at the upper
rightSettingsADD ACCOUNT, then set up the email account with the mailbox guide.
When you are finished setting up the email account, the email messages are downloaded to
your device. If you have created more than two accounts, you can switch between email
accounts. Select an account name at the top left of the screen and select the one you want
to retrieve messages from.
1.
2.
Delete your email account
Open the application list and select Email.
Tap the option button at the upper right, then select Settings and the email account you
- 11 -
want to delete.
3.
4.
1.
2.
3.
Tap Remove account.
Tap OK to confirm.
Create and send email
Open Email application.
Tap
.
In To field, enter the recipient’s email addresses manually and separate them with a comma.
Add more recipients by tapping Cc/Bcc.
4.
5.
6.
To insert attachments, tap the option button at the upper right and select Attach file.
Enter the subject and the text.
Tap SEND to send the email.
Gmail
You can retrieve new email messages from the Google Mail webmail service to your inbox. Before
you can send or receive mail on your device, you need to set up a Gmail account.
Create a Gmail account
If you don’t have a Google Account, tap New, then follow the on-screen instructions to create a
new one.
Set up a Gmail account
If you want to add an existing account, tap Existing, enter your email address and password,
and then select Next, when you are finished setting up the email account, the email
messages are downloaded to your device.
View email messages
1.
When you open the email account, the amount of unread email messages is displayed at the
title bar and the unread email messages are displayed in bold.
To view an email message, tap it.
2.
3.
To mark an important email message, tap the star icon below the date. To cancel the mark,
tap the star icon again.
1.
2.
Create and send an email
Tap
.
In To field, enter the recipient’s email addresses manually and separate them with a comma.
- 12 -
Add more recipients by tapping Cc/Bcc.
3.
4.
5.
To insert attachments, tap the option button at the upper right and select Attach file.
Enter the subject and the text.
Tap SEND to send the email.
Web
Browser
Tap Browser from application list to access to the web.
1.
2.
Browser webpages
Select Browser to launch a specified homepage.
To access a specific webpage, select the URL input field, enter the web address of the
webpage, and select Go.
3.
To zoom in, place two fingers on the screen and spread them apart. To zoom out, move
your fingers closer together. You can also double-tap the screen.
Add windows
You can have multiple windows open at one time.
1.
2.
3.
1.
2.
3.
To add a new window, tap
at the title bar.
To open up a window, tap the title of the window.
To close the window, tap
at the title bar.
Set homepage
Tap the option button at the upper right.
Select SettingsGeneralSet homepage.
Enter the web address of the desired webpage.
Add bookmarks
While navigating a website, tap
later.
to add current URL to your bookmark list and easily access it
View bookmarks and history
to open the bookmark list and the recent history. Tap a bookmark or any entry to
Tap
display the webpage.
Customize browser
- 13 -
To make adjustments in your browser settings, tap the option button at the upper right, and
then select Settings.
Play Store
Play Store allows you to easily download an abundance of applications directly to your device.
Before using the Play Store, you must have a Google Account.
1.
2.
3.
4.
From the application list, tap Play Store.
Sign in to your Google Account.
Search for and download applications as desired.
Follow the on-screen instructions.
Note
All applications offered by Play Store are developed by third party. To get the
information about the developers, you can read the descriptions of each application.
Our company is not liable for performance issues caused by third-party applications.
Talk
Google Talk is a free web-based application for instant text, voice and video chats. Before
using the Google Talk, you must have a Google Account.
1.
2.
3.
4.
From the application list, tap Talk.
Set up a Google account or sign in, follow the on-screen instructions.
Select Add friend, enter a friend’s email address and select Send invitation.
When your friend accepts the invitation, he or she is added to your friend list. You can
start talking.
Entertainment
Gallery
To view or organize your images and video clips, or edit and send your files to other devices, or
set photos as wallpapers, select Gallery from application list.
Note: It takes a few more minutes to enter this application if you store more files.
Supported file formats
- 14 -
Type
Format
Audio
Video
MP3,MP2, AMR,AWB,APE,M4A, MIDI, OGG,WAV,FLAC,3GP (Need Licence:AAC, WMA)
MPEG4-SP, H.264/AVC,H.263,3GP,3G2,MP4,MKV,AVI,
Note: Some files may not play properly depending on how they are encoded.
1.
2.
3.
View a photo
Select a folder.
Select a photo to view. To view more photos, scroll left or right.
To zoom in, place two fingers on the screen and spread them apart. To zoom out, move
fingers closer together. You can also double-tap the screen.
4.
5.
6.
7.
To start a slideshow, tap
at the title bar.
To view the details of a file, tap the option button, then select Details.
To share a photo with others via Email, Gmail or Messaging, tap
at the title bar.
To set a photo as wallpaper, tap the option button at the upper rightselect Set picture
asWallpaperdrag the slides of the crop box to create the crop area, then tap Crop.
To set a photo as a caller ID, tap the option button at the upper rightselect Set picture
asContact photoContactsCreate a new contact or select an existing contactdrag
the slides of the crop box to create the crop area, then tap Crop.
8.
Edit a photo
1.
To crop the image, tap the option button at the upper right, then select Crop.
To move the crop box, tap and hold the crop box and drag it to the desired location.
To add or subtract from the selection border of the crop box, drag the crop box to
the desired size.
When you are finished, tap Save.
2.
To edit photos and apply various effects, tap the option button at the upper right, then
select Edit.
1.
2.
3.
Play a video
Select a folder.
Select a video to play.
Control playback with the virtual keys.
- 15 -
Music
With Music, you can play music files. The music player supports the following file formats: MP3,
AAC, APE, WMA, OGG, WAV, M4A and so on.
Note: Some files may not play properly depending on how they are encoded.
Add music files to your device
Start by transferring files to your device or memory card.
1.
2.
Play music
Select a music file.
Control playback with the virtual keys.
The current list of songs are randomly shuffled for playback.
Return back to the current list of songs
Repeats the current playing song.
1.
2.
3.
4.
5.
1.
2.
3.
Create a playlist
Tap and hold a music file.
Select Add to playlist.
Select New.
Enter a name.
Tap Save.
Delete a playlist
Tap Playlists.
Tap and hold the playlist you want to delete.
Select Delete.
Camera
With the camera function, you can capture photos and take videos.
1.
2.
Capture a photo
Open the application list and select Camera.
Before taking a picture, you need to know some settings.
- 16 -
Place two fingers on the screen and spread them apart or move fingers closer together to
zoom in or zoom out.
Icon
Definition
Settings
Change to video mode.
take photos
Tap to switch between the front and rear camera lenses
Smile Mode
Change to panorama mode to take a landscape photo.
3.
4.
Aim the lens at the subject and tap
automatically to the folder DCIM.
to take a photo. The photo is saved
Select the image viewer icon at the upper right to view the pictures.
- 17 -
Record a video
1.
Open the application list and select Camera. Tap
to change to video mode.
2.
Tap
to start recording. The length of the video recording is restricted by the
available space on your storage.
Tap to stop recording. The video is saved automatically to the folder DCIM.
3.
4.
After recording videos, select the image viewer icon at the upper right to view the
recorded videos.
Tools
Calendar
With the Calendar feature, you can consult the calendar by day, week, or month, create events,
and set an alarm to act as a reminder, if necessary.
To access the calendar, tap Calendar from application list.
1.
To create an event, tap
.
Fill in the fields, and set category, date, time & an alarm.
After you finish, select DONE.
2.
3.
You can view calendar in different views, Day, Week, Month and All.
To delete an entry, tap the event to open it, and then select
OK.
- 18 -
Alarm
From application list, tap Clock, and then select
.
1.
Tap
to add alarm.
Tap the numeric pad to set alarm time, and then select AM or PM, when you are
finished, tap OK.
Tap the time to change alarm time.
2.
3.
Set alarm time, repeat cycle, and alarm ringtone, taps OK after finished.
Tap“cancel” to shut down the alarm, and tap” ring again” , then the alarm will stop
ringing for a few minutes.
4.
5.
Untick the clock to stop using the clock.
Long taping the clock then it can be deleted.
File Manager
Many features of the device, such as images, videos, documents, received attachments and
downloaded files or applications, use memory to store data. With File manager, you can store
and browse files and folders in your device, or edit, move, copy files; you can send files to
compatible devices as well.
Note:
1.
2.
Some files formats are not supported depending on the software of the device.
Some files may not play properly depending on how they are encoded.
Sound Recorder
With Recorder, you can record a voice memo. From application list, tap Recorder.
1.
2.
3.
To record a voice memo, tap
To pause the recording, tap
.
.
To listen to a voice recording that you just recorded, tap
.
Calculator
With this feature, you can use the device as a calculator. The calculator provides the basic
arithmetic functions. Tap the virtual numeric and calculation keys to perform a calculation.
- 19 -
Connectivity
USB Connection
You can connect your device to a PC and use it as a removable disk, which allows you access the
file directory.
1.
If you want to transfer files from or to a memory card, insert a memory card into the
device.
2.
3.
4.
5.
6.
With a USB cable, connect your device to a PC.
Open the notification panel, select USB connected.
Tap Turn on USB storage.
Open the folder to view files.
Copy files from the PC to the memory card.
Wi-Fi
With Wi-Fi, you can connect to the internet or other network devices anywhere an access point
or wireless hotspot is available.
1.
2.
1.
Activate the Wi-Fi feature
From application list, tap Settings.
In the field of WIRELESS & NETWORKS, turn on the Wi-Fi feature.
Find and connect to Wi-Fi
Once the Wi-Fi feature is activated, the device automatically search for available Wi-Fi
connection.
2.
3.
4.
Select a network.
Enter a password for the network (if necessary).
Select Connect.
- 20 -
Safety Precautions
Read these simple guidelines before using your device. Not following them may be dangerous or
illegal.
Aircraft
Switch off in aircraft and follow any restrictions. Wireless devices can cause interference in
aircraft.
Vehicles
Never use your device while driving. Place it in a safe place.
Position your device within easy reach. Be able to access your device without removing your
eyes from the road.
Electronic devices
In some circumstances your device may cause interference with other devices.
Potentially explosive environments
Switch off your device when in any area with a potentially explosive atmosphere, and obey
all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in
bodily injury or even death.
Pacemakers and other medical devices
Pacemaker manufacturers recommend that a minimum separation of 8 inches be maintained
between a wireless device and a pacemaker to avoid potential interference with the
pacemaker.
Operation of any radio transmitting equipment, including wireless phones may interference
with the functionality of inadequately protected medical devices. Consult a physician or the
manufacturer of the medical device to determine if they are adequately shielded from
external RF energy or if you have any questions.
Switch off your device in heath care facilities when any regulations posted in these areas
instruct you to do so.
Operating environment
When connecting to other device, read its user guide for detailed safety instructions.
not connect incompatible products.
Do
Do not place your device in the air bag deployment area.
Use the device only in its normal operating positions as explained in the product
documentation.
Always switch off your device when its use is prohibited or when it may cause interference
and danger.
Areas with posted regulations
Switch off your device when any regulations posted in these areas instruct you to do so.
- 21 -
Care & Maintenance
Use only manufacturer-approved accessories. Use general accessories may shorten the life of
your device or cause device to malfunction.
Keep your device dry. Humidity and all types of liquids may damage device parts or electronic
circuits.
Do not use or store the device in dusty, dirty areas.
Do not store the device in hot or cold areas.
Do not store your device near magnetic fields.
Do not store your device with such metal objects as coins, keys and necklace.
Do not drop your device or cause impacts to your device.
- 22 -
FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used
in portable exposure condition without restriction.
