Wavetec FZCO WT-ECF Controller User Manual

Wavetec FZCO Controller Users Manual

Users Manual

ECF GEN 2 - REV. 0F
WITH BUILT-IN SOUND AMPLIFIER
RELEASE NOTES V 1.0
5TH JUNE, 2014
PREPARED BY:
The Technology Company
Release Notes Document
PDU Display Garbage Page 2 of 8
REVISION CHART
Version
Primary Author(s)
Description of Version
Date Completed
1.0
Rameez Qasim
ECF _Gen 2 with Amplifier and reset
PCB
5th June, 2014
Release Notes Document
PDU Display Garbage Page 3 of 8
Contents
1. Release Content ............................................................................................................................. 4
1.1 Release Contents ................................................................................................................... 4
2. Improvements ................................................................................................................................ 5
2.1 Sections Improved: ............................................................................................................... 5
2.2 Changes: .................................................................................................................................... 5
2.3 Network Connectivity Diagram ........................................................................................ 6
3. Testing Scope .................................................................................................................................. 7
3.1 Test Environment: ................................................................................................................ 7
3.2 Test cases & Result: .............................................................................................................. 7
4. Contact Us ........................................................................................................................................ 8
Release Notes Document
PDU Display Garbage Page 4 of 8
1. RELEASE CONTENT
1.1 Release Contents
The release consists of the following:
1. EQ controller Gen 2 with built-in Amplifier
Release Notes Document
PDU Display Garbage Page 5 of 8
2. IMPROVEMENTS
2.1 Sections Improved:
- The feedback from Sales and CSE prompted the need of incorporating a built-in Audio
Amplifier in addition to existing option of external amplifier. The built-in amplifier
would serve small waiting areas with less hassle for installation.
.
2.2 Changes:
- A volume knob at the rear panel is available for adjusting the sound level
- 2 speakers of 8 ohm each can be connected to 2 RJ45 connectors available on the rear
panel marked as “Sound”
- Non-Amplified Audio is still available to be used with external Amplifier and Speakers if
needed.
Release Notes Document
PDU Display Garbage Page 6 of 8
2.3 Network Connectivity Diagram
Release Notes Document
PDU Display Garbage Page 7 of 8
3. TESTING SCOPE
3.1 Test Environment:
EQ set-up for 4 counters, with following configuration:
2 Bar SDU, in Dual-Line mode – Powered by 5V Adaptor
1 Cube SDU – Powered by 5V Adaptor
3 CDU – Powered by Active Hub
1 PDU – Powered by Active Hub
1 TDU-Lite – Powered by 12V Adaptor
2 Hard-TSU – Powered by Active Hub
1 Soft-TSU – Powered by Active Hub
Configuration Description:
PDU acts as CDU
Bar SDU, Cube SDU and CDU connected with 1 separate Active Hub, with 12V input
power supply.
Hard TSU and TDU-Lite connected with 1 separate Active Hub, with 12V input power
supply.
PDU connected with 1 separate Active Hub, with 5V input power supply.
3.2 Test cases & Result:
S.No.
Test case
No. of
Cycles
Test Result/Output
1
Display on PDU, without any corrupted
image?
100
100/100 - Passed
2
All CDUs, PDU & SDUs updated every
time & correctly?
100
100/100 – Passed
3
Calling sound always synced with calling?
100
100/100 – Passed
4
Ticket issuance from TDU Lite
100
100/100 – Passed
Release Notes Document
PDU Display Garbage Page 8 of 8
4. CONTACT US
In case you may require further assistance, please contact us at support.int@wavetec.com
Warning：
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation. changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
NOTE: This device and its antenna(s) must not be co-located or operation in
conjunction with any other antenna or transmitter.
