Wavetrend Technologies TGM-A Active Duo RFID Tag TGM-A User Manual
Wavetrend Technologies Limited Active Duo RFID Tag TGM-A
User Manual
© 2012 Wavetrend Europe Limited | All Rights Reserved | All specifications are subject to change without notice.
Europe, Australasia and Middle East – Corporate Office USA, Canada and South America
+44 (0)20 8614 7779 +1 (703) 539 8502
Micro Tag
TGM-
A
251666944
Personnel
Beacon tag transmitting a unique ID & data at pre-set intervals
Ultra long-range transmitter
Anti-tamper alert option
Motion sensor option
IP64 Housing
Compact size
The TGM-A ActivDuo Tag is an extremely small active tag that continuously transmits a unique ID number, which can be
detected by Wavetrend® reader. An internal battery powers the tag and Wavetrend’s patented ultra low power use design
ensures longer battery life at higher rates of transmission than any other brand of active RFID tag. Various preset transmission
intervals are available.
Best Usage
Guide
KEY FEATURES BUSINESS BENEFITS
Tag can be configured to hold standard
26-bit Wiegand numbering
Allows tag to be used with existing access control
systems separately or together with the active RFID
system.
Configurable settings include:
Site/vendor ID
Tag ID
Tag Age Counter
Various transmission repetition intervals
Tamper Alarm
A unique code that can be allocated by Wavetrend to
each customer on request. Readers can be set to
ignore tags with incorrect site codes.
4.2 billion tag ID’s are available per site code.
The Age Counter allows for advance notification of
the end of battery life and for the unique identification
for each transmission made by the tag.
Different status transmission intervals allow tags to be
used in diverse applications while offering the best
battery life spans in the market.
Provides instant notification of unauthorized attempts
to remove a tag from an asset.
Collision avoidance algorithm
Reduces loss of data caused by simultaneous
transmissions from multiple tags.
Ultra low power consumption
Typical lifespan of 3 years at 15 second beacon rate
Sealed to IP64 standards
Splash Proof
© 2012 Wavetrend Europe Limited | All Rights Reserved | All specifications are subject to change without notice.
Europe, Australasia and Middle East – Corporate Office USA, Canada and South America
+44 (0)20 8614 7779 +1 (703) 539 8502
Micro Tag
TGM-
A
The TGM-A Micro Tag has a unique omni
directional antenna design allowing the tag
to be read from all directions and to be
deployed equally well on metallic and non
metallic assets.
Optimum read range is achieved on metal
with a 10% reduction on non metals.
It should be noted that due to its physical
size the micro tag has a smaller battery than
other tags in the range, for monitoring
applications it is recommended to use the
TGM-A set at 30 seconds. This allows the
user to extend the life of the tag whilst still
detecting any motion events.
Model Range
The tags can be ordered using the part
numbers listed below:
L-Series
TGM-A
TGMS-A
Ordering & Further Information
For more information on purchasing the
Activ TGM-A Tag
please email
Wavetrend’s Sales team:
sales@wavetrend.net
For more information on Wavetrend® visit
our website.
Specifications
IP Information
Wavetrend and the Wavetrend logo are either registered trademarks or trademarks of Wavetrend
Technologies Limited in the United States and/or other countries. All other
trademarks are the property of
their respective owners. The product(s) described in this document are protected by various patents held
by Wavetrend. Refer to the URL www.wavetrend.net/IPR for inf
ormation on all patents and trademarks
held, and for Wavetrend's Policy on Intellectual Property Rights.
Typical Applications
Environmental
Operating temperature
Storage temperature
Humidity
: -30°C to +85°C
: -40°C to +90°C
: 5% to 90% (non-condensing)
Physical
Size
Weight
Colour
Material
: 29 x 25 x 7 mm
: 7g
: Grey
: ABS
Radio Frequency
Transmit Frequency
Range
: 433.92 MHz
: 1 to 50 + meters (actual range is determined by the
choice of reader & antenna used to detect the tag and
the environment it is used in)
Electrical
Power
: Internally powered by lithium battery
Accessories
TA-TGM
TA-TGM-AT
All sold in packs of 10
: Tag attachment kit
: Tamper alerting tag attachment kit
FCC Statement of Conformity
Wavetrend , TGM-A Active Duo ,
FCC ID: 06XTGM-A
This device complies with Part 15 of the FCC rules subject to the following three conditions:
1) This device may not cause harmful interference.
2) This device must accept all interference received, including interference that may cause
undesired operation.
3) This device is for commercial use only and intended for use in a confined area with an
appropriate system receiver
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
