Weccan WECCANTOYS New Jawbreaker User Manual TRU SG H5401 ENG

Weccan Industrial Limited New Jawbreaker TRU SG H5401 ENG

User Manual

The following is just suitable for Heli with GyroscopeGyros in RC helicopters are most commonly used to control unwanted movement on the yaw axis. When an RC helicopter rotates on its yaw axis, the direction the nose points in changes. The yaw gyro's job is to sense any undesired rotation around the yaw axis (clockwise or counter- clockwise rotation when viewed from above) and to automatically correct the orientation of the RC helicopter.THE GYRO WILL ENABLE A STABLE FLIGHT FOR THE HELICOPTER. The safety instructions contained in this manual have to be observed without fail!!Warning with regard to placing the productDo not use this product in an environment where it is exposed to extreme heat or cold, to dust or to damp.Avoid placing the product in an area that is not properly ventilated; do not cover the product and do not place it on carpeting or similar surfaces.Do not place cables behind the product's support. If the cables move (for example as a result of stumbling) the product can fall to the floor!Do not expose the product to direct sunlight, fire or other sources of heat that have an extreme effect on the temperature.Table of ContentsIntended use ............................................................................................................................Safety instructions ...................................................................................................................Unpacking and storing Jaw Breaker .......................................................................................Getting to know Heli .................................................................................................................Assembling Heli .......................................................................................................................Secure the Flight Area .............................................................................................................Flying Heli .................................................................................................................................Taking off .................................................................................................................................Steering ...................................................................................................................................Landing .....................................................................................................................................Trimming ...................................................................................................................................Charging ...................................................................................................................................Battery care information ..........................................................................................................Flying tips ................................................................................................................................Trouble diagnoses ..................................................................................................................Technical data ........................................................................................................................1) Switch the controller ‘ON.2) Switch the helicopter on (‘ON/OFF, switch at the side of the main body).3) Place the helicopter on a flat, hard surface with the tail pointingtowards you. Extend the blades separately, or it may entangle each other and cause the blade to break, or burn out the motor. 4) Make sure to move the left throttle lever to the lowest position first, and then move it forward and backward. By doing this, the controller will be fully forward armed and connected to the helicopter, with the led light turn on. Please do not touch the helicopter when is searching for signal from controller. 1) Move the left lever slowly forward-the blades will start to spin2) As you move the left lever past the halfway point, the helicopter will take off.3) To ascend, move the left lever further forward. To descend, slowly move the left lever backwards.Your Jaw Breaker helicopter is designed for outdoor and indoor playing. Allow a clear space around you in all direction of at least 9.84feet. Make sure to play away from human beings or animals.Outdoor use recommendedBegin on a flat surfaceKeep away from any obstaclesAvoid flying windy weather conditionsKeep your eyes on the helicopter and be sure thehelicopter is within your eyesightHave an adult accompany children whenflyingKeep away from any hard obstacles to avoid anyunnecessary damagesmore than 9.84feetmore than 9.84feetmore than 9.84feetmore than 6.56feetmore than 9.84feetmore than 9.84feetNoseExtendPreparing to take offTaking offFlying HeliSecure the Flight Area1) To turn the helicopter left, move the right hand lever to the left.2) To turn the helicopter right, move the right hand lever to the right.3) To fly the helicopter forwards, move the right hand lever forwards.4) To fly the helicopter backwards, move the right hand lever backwards.To land the helicopter, slowly move the left lever backwards.This helicopter is fitted with one trimmer control. This will allow you to adjust the flight of the helicopter and erase any unexpected turning tendencies.If the helicopter spins, you need to use the TRIM control to adjust the flying.Push the left lever and keep the helicopter flying upwards between 0.5- 1 meter.1) Turn the TRIM leftwards if the helicopter spins right.2) Turn the TRIM rightwards if the helicopter spins left.After trimming adjustment, you can also use the right lever to adjust the direction and stop the spinning. Steering HeliLanding Heli Trimming Heli NotesCharging: Connect the battery to thecharger as shown in the illustration,do not force.1) Never leave helicopter charging near a fire or other source of heat.2) Never leave helicopter unattended during charging.3) Always disconnect from the mains once fully charged, failure to do so WILL DAMAGE THE BATTERY.4) Never disassemble the charger.5) Only use the charge that is provided6) NEVER STORE BATTERY WITHOUT CHARGING FIRST, this will damage the battery.7) Charge for a minimum of 10 minutes after use.Charging This helicopter is powered by dedicated Li-Po battery. Do not attempt to disassemble the battery or replace with any after-market model.1) Use only batteries recommended in this user manual. Ensure that batteries are installed with the correct polarity.2) Batteries should be installed under adult supervision.3) Do not allow the battery to become over heated during charging. 4) Do not leave the battery charging overnight-switch off once the LED lights on the charger.5) Do not use an after-market charger as this can damage the battery.6) Do not short circuit the charging terminals.PLEASE RETAIN THIS INFORMATION FOR FUTURE REFERENCE.DO:• Make sure battery compartment is secure.• Use batteries of the correct size and type.• Fit batteries correctly observing the plus and minus marks on the battery and compartment.• Replace a whole set of batteries at one time.• Remove dead batteries from equipment.• Remove batteries from appliance before storing.• Please remember that small button cells and AA batteries should be kept away from young children as they could be easily swallowed. Seek medical advice if you believe a cell has been swallowed.DON’T:• Mix different types of batteries.• Mix old and new batteries.• Dispose of batteries in a fire.• Attempt to recharge ordinary batteries.Battery care information Problem Cause SolutionNo control of helicopterHelicopter is not flying high enoughHelicopter lands too quicklyHelicopter spins Recharge your helicopter (see Charging instructions)Push left hand lever fully forwards then fully backwardsDo not fly it in strong wind as this will limit or disturb your controlGently move the left throttle stick backwards when landing. Remember to give a slight burst of power just prior to touch downNo function to controllerPower switch is turned ‘OFF’Low battery in the helicopterLow battery in the controllerController needs to be ‘armed’Switch ‘ON’ controller and helicopter Charge batteries in helicopterReplace battery in controllerTurn controller ‘ON’Blade speed is too slowBattery is not fully chargedLeft throttle stick movedtoo quicklyTrimming adjustmentSee Trimming instructions sectionEase the left throttle stick further forwardTrouble diagnosesController is turned ‘OFF’Strong windy day Turn the helicopter off, then on.It will work again.Helicopter stop by a heavy impact or crash land.1) You can expect a flight time of 5-7 minutes after fully charging the battery.2) When taking off, do not move the left lever too quickly as this will cause the helicopter to topple over. Move the left lever smoothly and continuously forwards until the helicopter takes off.3) When landing, give the helicopter a burst of power just before touching down the floor to slow down the speed and land smoothly.4) Heli has a range of up to 25-30m. Be aware that the presence of electrical interference may reduce this range.5) During your first few flights, try to keep the helicopter close to the ground. This will allow you to cut the throttle and safely land if you become disorientated.6) Always turn the helicopter off immediately after flight.7) After flying and before recharging, always turn the helicopter and controller off.8) When not in use, the battery should be disconnected to avoid battery discharge. 9) Recharge the battery before putting it away.10) Check for any damage: examine everything including blades and landing gear.11) To avoid damage to the motor, always turn the throttle off if the blades become entangled in anything or are prevented from turning, otherwise motors may burn out!!Flying tipsGyro functionSafety instructionsRead the user manual completely before commissioning, then refer to below important information for correct operation.1. To ensure safe operation, the user must comply with the safety instructions and warnings contained in this manual.2. The charger is designed in compliance with protection glass, ensuring that the insulation (of the housing or the output cable) is neither damaged nor destroyed.3. The charger should be kept out of the reach of children!4. Avoid charging operation under adverse ambient conditions. This can lead to damage to the sensitive electronics on the inside of the charger and thus to possible danger for the life of the user. Adverse ambient conditions are:-excessive humidity ( >75% relative, condensing )-wetness and dampness, petrol -dust or combustible gas, vapour or solvents -excessive ambient temperature ( > approx, + 40 °C )In the case of incorrect handling (excessive charging current or incorrect polarity), the charger may be overcharged or destroyed. 5. Never unplug the plug-in power unit from the mains socket by the connecting cable! Only hold it by the housing when disconnecting it.6. Keep transmitting devices (mobile telephone, radios, etc.) away from charger, the transmitter radiation arose can lead to interference in charging operation or to destruction of the charger.7. Never connect your charger to the mains voltage immediately after it has been taken from a cold room to a warm one. The resulting condensation could, under adverse circumstances, destroy the device. Allow the device to reach room temperature before connecting it to the power supply.Never touch the charger with wet or moist hands. There is the risk of a fatal electric shock!The Jaw Breaker helicopter is fastened securely in place to avoid any damage during transit.The helicopter is a delicate device so you must be careful when removing it from the package. Ensure the contents are complete with:1) 1 x helicopter 5) 2 x connectors ( spare part ) 2) 1 x radio controller 6) 2 x tail blades ( spare part )3) 1 x user manual 7) 1 x screw driver4) 4 x main blades ( 1set ,2pcs up & 2pcs lower )( spare part ) Packaging box should be kept for proper storage of the helicopter after each use.Warning: Improper storage of the helicopter may result in the blades bending or warping. This will affect flight performance.Getting to know Jaw BreakerInstalling batteries in the controller of your helicopterUnpacking and storing Heli Connect charging cable to helicopterThe ‘ON/OFF’ switch is located at the side of the main bodyHelicopterMain blade(Dual)StabilizerTail bladeCanopyTrestleON/OFF switchJaw Breaker helicopter is delivered fully assembled and only requires some assembly.See below.Install batteries.1) Pull and take out the battery cover, (pic.1)2) Take off the battery cover from the controller, and then install 6pcs (AA) Alkaline batteries in the batteries cage following the correct indicated polarity, Notice: When the power indicator light goes off it means the power is running out,you should renew the batteries.US_S16_FL_902_A_IM ENGLISH VERSION(BLACK & WHITE) A4 X 12pcs 5F63FD2_New Jawbreaker5F63FD2CONFORMS TO THE SAFETY REQUIREMENTS OF ASTM F963.Do not mix old and new batteries.Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries.Contents and colors may vary.FAST LANE IS A MARK OF (EST UNE MARQUE DE/ES UNA MARCA DE) GEOFFREY, LLC, A SUBSIDIARY OF (UNE FILIALE DE/UNA SUBSIDIARIA DE) TOYS“R”US, INC.© 2016 GEOFFREY, LLCMADE IN CHINA (FABRIQUÉ EN CHINE/FABRICADO EN CHINA)DISTRIBUTED IN THE UNITED STATES BY (DISTRIBUÉ AUX ÉTATS-UNIS PAR/DISTRIBUIDO EN LOS ESTADOS UNIDOS POR) TOYS“R”US, INC., WAYNE, NJ 07470 IMPORTED BY (IMPORTÉ PAR/IMPORTADO POR) TOYS“R”US (CANADA) LTD. (LTÉE), 2777 LANGSTAFF ROAD, CONCORD, ON L4K 4M5DISTRIBUTED IN AUSTRALIA BY (DISTRIBUÉ EN AUSTRALIE PAR/DISTRIBUIDO EN AUSTRALIA POR) TOYS“R”US (AUSTRALIA (AUSTRALIE)) PTY LTD.(LTÉE), REGENTS PARK NSW 2143www.toysrus.com www.toysrus.caCaution: changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:-Reorient or relocate the receiving antenna.-Increase the separation between the equipment and receiver.-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.-Consult the deal or experienced radio /TV technician for help.The adaptor be periodically examined for conditions that may result in the risk of fire, electric shock, or injury to persons and that, in an event such conditions, the adaptor should not be used until properly repaired.The consumer has a significant role to play in reducing the impact of waste electrical and electronic equipment on the environment, through re-using or recycling such equipment.Some of the components used in electrical and electronic equipment may contain hazardous substances that can damage the environment and present a risk to human health if not property disposed of.The crossed out wheelie-bin symbol on the controller is to remind you that waste electrical and electronic products should not be disposed of with household waste. If you are unable to re-use or recycle your product it should be disposed of at a civic amenity site. Alternatively, you may take your old product (of similar function) back to the store where you purchased your new product within 15 days of purchase. You must take proof of purchase of your new product when returning your old product to the store.If the blades are damaged, it may not be repaired but has to be replaced with a new one.Broken plastic parts can be sharp-edged. For your own safety, use protective gloves.Flying time: 5-7 minutesCharging time: 90-110 minutesOperation range: 25-30m/ 82-100feetBattery for the controller: 6 x AA (not included)Battery for helicopter: 3.7V 380 mAhFrequency: 2.4GFeatures:Up/down,forward/backward,turn left/rightMain blade length: 26cm/ 10.23inches Helicopter length: 30cm/ 11.81inches Helicopter height: 15.5cm/ 6.1inches Helicopter weight: 81.5gTechnical DataIntended Use1. The helicopter is delivered ready to fly and does not need to be charged before your first flight. When you first receive it, do not charge it, just fly it. When the helicopter can no longer take off from the ground, let battery cool for 5 minutes before charging. The best performance of helicopter should be after 1st full charge. The performance during discharge process should not be treated as defective.2. This helicopter is delivered with partial-charged Li-Po battery separately, and never over charge the battery. Normally first few charges, will take 1.5-2 hours. Then about 60-70 minutes for a full charge. Once the charging light turns red,remove the charging cable from the helicopter. Let battery cool for 5 minutes before flying.This device complies with Part 15 of the FCC Rules. Operation is subjected to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.1. Before charging, ensure helicopter is switched ‘OFF’.2. Charging via controller 2.1 Pull out the charging cable from the back side of the controller 2.2 Turn ON the controller(Ensure the AA batteries inside controller not low power) 2.3 Plug the charging cable rod pin into the helicopter charging socket at the side of the main body.(ref pic.1) 2.4 When in charging, the Red LED light on the controller turns green; when fully charged the LED light turns red.3. Charging time is about 60-70 minutes.4. Remove the charging cable from helicopter.5. Leave battery to cool for five minutes and the helicopter is ready to fly.Note :Be sure that the battery in the helicopter has cooled down for 10-15 minutes after flying before charging.Examine the adaptor periodically for conditions that may result in the risk of fire, electric shock, orinjury to persons and that, in an event of such conditions, the adaptor should not be used until properly repaired.(pics 1)BC3.7VNOT INCLUDEDxAA8+INCLUDED6JAWBREAKERTMIndicator lightHigh/Low speed mode buttonPower ON/OFFTrimRight function lever(Direction lever)ThrottleswitchONOFFFully forward and backwardRLLRRLLR
