• Durable, Attractive Cabinet: Designed using
galvanizedsteel.Thedoorisalsogalvanizedsteel,with
apolyesterurethanenish.The950hoursaltspraynish
resistscorrosion50%betterthancomparableunits.The
plasticdrainpaniscorrosion-resistant.
• Multi-poised:Canbeusedinhorizontal,upow,downow
andverticalapplications.
• Increased Efficiencies: Air conditioning efciencies
upto24.5SEER.Heatpumpefcienciesupto22SEER.
• ECM Variable Speed Motor:Advancedtechnologyallows
forautomaticselectionofcoolingairowsandheating
airowstomatchanyapplication.
• Quiet Blower Operation:Extraquietandsmoothblower
onandoffcycles.
• Reduced air stratification: This results in improved
airqualitybyoptimizinghumidityremovalandltration
capabilities.
• Ease-of-Service:Plug-inwireconnectionsandbuilt-in
lterrackmakestheairhandlereasytoservice.
• Plug-in Heater Kits:Availablein5kw-30kw
• Air Handler Control Board:Controlstime-sequencing
ofheatstageswitheld-selectablesequencetiming.
• Breaker Accessibility:Breakeraccessiblefromfrontof
unitwhenheaterisapplied.
• No Fasteners on Sides or Back:Smoothsurfacesfor
easeofinstallation.
• Cabinet Insulation: 1" insulation with an R-value of
4.2contributestoquietoperationandpreventscabinet
sweatingindifcultapplications.
• Designed to meet the requirements 610.2.A.2:Meets
Floridabuildingcoderequirementsforairleakage.
• Anteater Coil Technology: Copper alloy with zinc
additivestostopformicarycorrosion.
B6VMAI Series
24.5 SEER Residential System
Indoor Sections
Variable Speed Air Handler
C6 Series
Residential Indoor Coils with EXV
FEATURES and BENEFITS
– Thisproductcarriesa5-yearallpartswarranty.When
installedwithamatchedoutdoorunit,theairhandler
will carry the outdoor system warranty. See current
warrantydocumentorvisitourconsumerwebsitefor
warrantydetails.
WARRANTY
TECHNICAL
SPECIFICATIONS
2
MODEL IDENTIFICATION CODE
Indoor Air
Handler
Electrical Code
K=208/230-60-1
Nominal
Capacity
(00)Btuh
Configuration:
M=Multipoise
Motor:
V=VariableSpeed
B 6 V
Design
Series
Cabinet Identifier
B=193/4"Width
C=221/2"Width
M A I 36 K - B
Anteater Coil
Technology
DIMENSIONS
3/4”
3/4”
3/4”
13”
1 7/8" K.O.
11/8” K.O.
(typ.)
11/4”
15/8”
17/8” 11/4”
3 1/4”
2 5/8”
11/8” K.O.
(typ.)
13/4” K.O.
(typ.)
1 7/8”
3 5/8”
5 5/8”
DETAIL “D”
3 1/4”
2 1/4”
15 1/4”
13”
SUCTION
LIQUID
“W”
1 1/8”
1 7/8”
7/8" K.O.
“H”
22"
“A”
Electronic
Metering Device
3
SPECIFICATIONS
Model Number
B6VMA- *I24K-B *I36K-B *I48K-C
Nominalcooling
capacity-BTUh124,000 36,000 48,000
Metering
Device EXV EXV EXV
MaximumAvailable
AuxilaryHeat 20 20 30
NominalBlowerSize
(Dia.xWidth) 11x8 11x8 11x10
Motor
Hp-speeds-type 1/2-VS 1/2-VS 3/4-VS
FilterSize(supplied
internallterrack)218x20x1 18x20x1 20x20x1
ApproximateShipping
Weight,lbs 111 114 154
Height,“H”,in. 43-5/16 49-5/16 55-15/16
Width,“W”,in. 19-11/16 19-11/16 22-7/16
SupplyAirOutlet
Dimension,in.
12-7/8x
18-1/4
12-7/8x
18-1/4
12-7/8x
21
Ref.ConnectionSiz-
es,in.(suc./liq.) 3/4-3/8 7/8-3/8 7/8-3/8
RangeSCFM 500-1110 500-1110 680-1800
1SeecurrentAHRIDirectoryforcertiedcombinations
andratings.www.ahridirectory.org
2Filterisnotsuppliedwithunit.
ELECTRICAL DATA
ACCESSORIES
Accessory Kit Description Cabinet Size Order
Number
B C
Down-owadaptorkit
X 919321
X 919322
Singlecircuitadaptorfor2circuit
breakers X X 913874
Singlecircuitadaptorfor3circuit
breakers n/a X 913556
240V Single-Phase Heater Kit Application
Nominal
KW
Matched Units Order Number
24K-B
36K-B
48K-C
With
Circuit
Breakers
Without
Circuit
Breakers
5 X X 904407 904406
8 X X 904409 904408
10 X X 904412 904411
15 X X 904414 n/a
20 X X 904416 n/a
25 n/a X 921609 n/a
30 n/a X 921610 n/a
240 VAC, 50 & 60Hz Single Phase 208 VAC, 60Hz Single Phase
Aux. Heat Installed
(Nom. KW) NONE 005H 008H 010H 015H 020H 025H 030H NONE 005H 008H 010H 015H 020H 025H 030H
Single
Circuit
Min. Circuit Amp. 5.8 30.8 44.8 55.8 80.8 105.8 130.8 155.8 5.8 27.4 39.4 49.0 70.7 92.3 113.9 135.6
Maximum
Over-current
Rating
15 40 50 60 90 125 150 175 15 30 40 50 80 100 125 150
Multiple Circuit
Circuit A
Min. Circuit Amp. 5.8 30.8 44.8 55.8 55.8 55.8 55.8 55.8 5.8 27.4 39.4 49.0 49.0 49.0 49.0 49.0
Maximum
Over-current
Rating
15 40 50 60 60 60 60 60 15 30 40 50 50 50 50 50
Circuit B
Min. Circuit Amp. - - - - 25.0 50.0 50.0 50.0 - - - - 21.6 43.3 43.3 43.3
Maximum
Over-current
Rating
- - - - 30 60 60 60 - - - - 25 50 50 50
Circuit C
Min. Circuit Amp. - - - - - - 25.0 50.0 - - - - - - 21.6 43.3
Maximum
Over-current
Rating
- - - - - - 30 60 - - - - - - 25 50
833D-0812 (Replaces 833D-1211)
MODEL IDENTIFICATION CODE
C 6 BH - I 36 C B
Cabinet Identifier
B=17.5"Width
C=21.0"Width
D=24.5"Width
C = Cased Coil
Nominal
Capacity
(000)Btuh
Coil
BH = Horizontal Ready Coil
Design
Series
I = R-410A EXV
Model C6BH I24-B I36-B I36-C I48-C I48-D
FaceArea(ft^2) 4.18 5.58 5.58 6.42 6.42
Rows 3 3 3 3 3
Finsperinch 14 14 14 14 14
RefrigerantFlowControl EXV EXV EXV EXV EXV
NominalAirow(cfm) 800 1,200 1,200 1,500 1,600
Pressuredropatnominal
airow(inw.c.) 0.12 0.21 0.21 0.30 0.30
Connections:
Inches
LiquidLine 3/8 3/8 3/8 3/8 3/8
SuctionLine 3/4 3/4 7/8 7/8 7/8
COIL DATA TABLES
Cabinet
Identifier
Overall Top
Opening
Bottom
Opening
Horizontal
Drain Pan
Extension
W H A B C
B I24 171/2 26 161/8 83/8 23/4
B I36 171/2 26 161/8 83/8 23/4
C I36 21 26 195/8 117/8 31/4
C I48 21 30 195/8 117/8 23/4
D I48 241/2 30 231/8 153/8 31/4
Cased Coil Dimensions Figure1.CasedCoil
Figure2.HorizontalLeftCongurationwith
DrainPanExtension
20
3
/
4
C
C6 COIL
W
H
OW
5/8
20 3/4
HL
HS
4
17 1/4
NOTE: Requires use
of a 2-stage variable
speed FG7 Furnace.
GENERAL TERMS OF LIMITED WARRANTY
8000PhoenixParkway|O'Fallon,MO63368-3827
Specicationsandillustrationssubjecttochangewithoutnoticeandwithoutincurringobligations.PrintedinU.S.A(08/2012)
NORDYNEwillfurnishareplacementforanypartofthisproductwhichfailsinnormaluseandservicewithinthe
rstveyearsofinstallation,inaccordancewiththetermsofthewarranty.
ForcompletedetailsoftheLimitedWarranty,includingapplicabletermsandconditions,seeyourlocalinstalleror
contacttheNORDYNEwarrantydepartmentforacopy.
www.westinghousehvac.com
