®120-Volt Electric Compact Dryer

PRODUCT MODEL NUMBERS OVERALL DIMENSIONS

RECESSED AREA AND CLOSET INSTALLATION

EXHAUST VENTING

LDR3822P

Electrical: 120-volt, 60-Hz, AC-only, 15- or

20-amp. electrical supply. A time-delay fuse or

circuit breaker is recommended. Use a separate

electrical circuit.

Exhaust venting: Exhaust your dryer to the

outside. Four-inch diameter vent is required. Rigid

or flexible metal exhaust vent must be used. Do

not use plastic or metal foil vent. Exhaust outlet

hood must be at least 12 inches from the ground

or any object that may be in the path of the

exhaust.

Because Whirlpool Corporation policy includes a continuous commitment to improve

our products, we reserve the right to change materials and specifications without notice.

Dimensions are for planning purposes only. For complete details, see Installation

Instructions packed with product. Specifications subject to change without notice.

Ref. 8562113

09-08-04

†Height with caster is 32¹⁄₂" (82.6 cm)

2378

(60.6 cm)

"

2034

(52.7 cm)

"

31"

(78.7 cm)

†

*

Number of

90° turns

or elbows

Typ e of

vent

Box or

louvered

hoods

Angled

hoods

0Rigid metal

Flexible metal

36 ft (11 m)

28 ft (8.5 m)

26 ft (7.9 m)

22 ft (6.7 m)

1Rigid metal

Flexible metal

26 ft (7.9 m)

18 ft (5.5 m)

16 ft (4.9 m)

12 ft (3.7 m)

2Rigid metal

Flexible metal

16 ft (4.9 m)

8 ft (2.8 m)

6 ft (1.8 m)

2 ft (0.6 m)

4"

(10.2 cm)

2.5"

(6.4 cm)

Louvered style Angled style

4"

(10.2 cm)

4"

(10.2 cm)

Box hood style

A. Recessed area

B. Side view - closet or confined area

C. Closet door with vents

A B C

in.

in.

A. Side view - closet or confined area

B. Recessed area

BA

Recessed or closet installation - Dryer only Recessed or closet installation - Stacked

Closet confined area

For closet installation with a

door, minimum ventilation

openings in the top and bottom

of the door are required.

Louvered doors with equivalent

air openings are acceptable.

*Most installations require a

minimum 5-1/2 in. (14.0 cm)

clearancebehind the dryer for the

exhaust vent with elbows.

1. Select the route that will provide the straightest and most direct path outdoors.

Plan the installation to use the fewest number of elbows and turns. When using

elbows or making turns, allow as much room as possible. Bend vent gradually to

avoid kinking. Avoid 90° turns when possible.

2. Determine vent length.

The maximum length of the exhaust system depends upon:

• The type of vent (rigid metal or flexible metal).

• The number of elbows used.

• Type of hood.

See the exhaust vent length chart that matches your hood type for the maximum

vent lengths you can use.

3. Determine the number of elbows you will need.

IMPORTANT: Do not use vent runs longer than specified in the Vent Length Chart.

In the column listing the type of metal vent you are using (rigid metal or flexible

metal), find the maximum length of metal vent on the same line as the number of

elbows.
