DISHWASHERS 2010

2

Since 1999 Whirlpool Corporation has

donated a range and an ENERGY STAR®

qualifi ed refrigerator to every new

Habitat home built in North America.

Together, we can eliminate substandard

housing, one family at a time. Join us.

As part of Whirlpool Corporation's

ongoing commitment to well-managed

forests, all of the paper in this catalog

comes from forests in compliance with

the Forest Stewardship Council standards

for Responsible Forest Management.

ALWAYS INNOVATING. NEVER COMPROMISING.

Many Whirlpool Corporation

products are proudly assembled in

the U.S.A. Whirlpool Corporation

employs more than 20,000 American

workers to provide our world-class

appliances and exceptional service.

Cover Model: GU2475XTVY

Whirlpool Corporation World Headquarters in Benton Harbor, MI, U.S.A.

Whirlpool brand appliances are designed to give you the unmatched effi ciency and performance

that makes us the time-tested leader in the industry. Our appliances demonstrate our passion for

innovation through advanced technology and intuitive design. With nearly 100 years of appliance

experience, we're devoted to our ongoing pursuit of perfection.

Our dishwashers offer consistent cleaning, larger capacity and the industry's best resource effi ciency,

so you can clean even more dishes in fewer loads while saving money on utility bills.

whirlpool.com 3

4 Effi ciency

6 Whirlpool Gold® Dishwashers

12 Whirlpool® Dishwashers

18 Portable Dishwasher,

Garbage Disposers &

Trash Compactors

20 Accessories

22 Glossary

24 Specifi cations

4

CONSERVATION REALLY IS THIS EASY

Whirlpool brand is leading the way in providing efficient appliances that

deliver excellent cleaning results while using less water and less energy.

Our commitment to making eco-friendly appliances continues with a

full lineup of ENERGY STAR® qualified dishwashers and innovations like

the Resource Saver™ wash system and the Eco cycle. Not only that, we’re

dedicated to providing advanced solutions that save one of the most

precious resources—your time.

whirlpool.com

EFFICIENCY

5

HOW RESOURCE SAVER™ DISHWASHERS SAVE

Resource Saver

dishwasher

TM

A

B

C

RESOURCE SAVER™

WASH SYSTEM

Dishwashers with this system

feature spray arms equipped

with specially designed

pressurized nozzles that provide

focused cleaning to every dish.

These fan-shaped jets distribute

cleaning power more efficiently,

saving more water and energy

than ever before.

POWERSCOUR™ OPTION

This smart cleaning option uses 36

targeted spray jets in a designated

wash area to tackle your toughest

dishes without using an additional

drop of water.

FILTRATION

The three-stage filtration system in a

Resource Saver™ dishwasher strains water

through a filter plate (A), coarse filter

(B) and fine mesh filter (C) to remove

food particles and other soils.

This unparalleled filtration system is

essential to providing an outstanding

clean while using less water and energy.

Model: GU2800XTVQ

6

*Compared to dishwashers manufactured before 2000. **The CEE Tier system is based on the Consortium for Energy Effi ciency qualifi ed product listings.

Model: GU2475XTVY

POWERSCOUR™ OPTION

Targeted spray jets scour away

baked-on food without soaking

or scrubbing. The PowerScour™

option uses 36 spray jets and

a designated wash area to tackle your

toughest dishes without using an additional

drop of water. No scrubbing by hand. No

more dishes soaking in the sink.

RESOURCE SAVER™ WASH SYSTEM

Deep cleans a full load

of dishes using

1⁄3

less

water and energy.* These

dishwashers exceed

ENERGY STAR® guidelines with an

eco-friendly CEE Tier I** qualification

making Whirlpool Gold® dishwashers with

the Resource Saver™ wash system our most

efficient ever. (Learn how it works on page 5.)

Resource Saver

dishwasher

TM

whirlpool.com 7

ANYWARE™ PLUS SILVERWARE BASKET

Designed to fit in three places for maximum

flexibility. Put it on the front of the rack or in

the door for 100% usable rack space, or use

it in the bottom rack.

FULLY INTEGRATED CONTROLS

Get the ultimate integration of style and

function. Fully integrated electronic controls

add a modern accent to your kitchen. The

control panel is hidden away to provide a

sleek exterior while preventing unwanted

cycle changes or accidental operation.

WHIRLPOOL GOLD® DISHWASHER INNOVATION

NOTE: Not all features are available on all models.

8

All Whirlpool Gold® dishwashers are

guaranteed to clean better and operate

more quietly than your previous model. If

you are not satisfied, Whirlpool Corporation

will take it back and refund the full price.*

Learn more at whirlpool.com.

WHIRLPOOL GOLD® DISHWASHER FEATURES

*Must be returned within 30 days of the purchase date.

Model: GU2475XTVY

whirlpool.com

EFFICIENCY WHIRLPOOL GOLD®

DISHWASHERS WHIRLPOOL® DISHWASHERS PORTABLE DISHWASHER,

DISPOSERS & COMPACTORS ACCESSORIES GLOSSARY SPECIFICATIONS

9

NOTE: Not all features are available on all models.

**According to a leading consumer magazine.

NYLON DISH RACKS

Durable nylon rack coating resists rust and

helps prevent scratching. These long-lasting

nylon racks stand the test of time and

help keep dishes from being chipped.

QUIET PARTNER™ SOUND PACKAGES

Whirlpool brand dishwashers offer

many levels

of sound-reducing insulation. The Quiet Partner™

V

sound package minimizes dishwasher noise for

our quietest dishwashers ever.

GLASS XPRESS™

& SPEED WASH CYCLES

Wash glassware or lightly soiled items in just

30 minutes with the Glass Xpress™ cycle. When

you need clean dishes in a hurry, use the Speed

Wash cycle and run a full load in just one hour—

less than half the time of other wash cycles.

ADAPTIVE WASH CYCLE

Uses dual sensors to determine the size of

the load and the dirtiness of the dishes. It

automatically selects the appropriate cleaning

level and cycle duration to save both time

and water.

EZ-2-LIFT™ ADJUSTABLE

UPPER RACK

Easily adjust the upper rack 2

"

up or down to

fit larger items in the lower or the upper rack.

NSF CERTIFIED SANI RINSE OPTION

Makes sure dishes are thoroughly disinfected

with a high temperature rinse. This option is

certified by NSF International for sanitization,

eliminating 99.999% of food soil bacteria.

TALL TUB DESIGN

Lets you load tall and odd-shaped items in

both racks. An additional 3

"

of interior space

compared to standard tub models makes room

for extra-large items in the lower rack and

plates or sports bottles in the upper rack.

FEWEST REPAIRS

Whirlpool® dishwashers are designed to

endure repeated use so you can save money

on maintenance and repairs. No one has fewer

dishwasher repairs 13 years in a row.**

10

GU2475XTV

Q | B | Y

Quiet Partner™ IV sound package

Fully integrated electronic controls

ENERGY STAR® qualifi ed

Slate plastic Tall Tub

5-level SheerClean™ direct feed wash system

Adaptive Wash cycle

Glass Xpress™ cycle

PowerScour™ option

NSF Certifi ed Sani Rinse option

Nylon racks

Adjustable upper rack

AnyWare™ Plus silverware basket

GU2300XTV

Q | B | T | S

PowerScour™ option

ENERGY STAR® qualifi ed

Slate plastic Tall Tub

Quiet Partner™ III sound package

5-level SheerClean™ direct feed wash system

Adaptive Wash cycle

Glass Xpress™ cycle

NSF Certifi ed Sani Rinse option

Nylon racks

Adjustable upper rack

AnyWare™ Plus silverware basket

WHIRLPOOL GOLD® DISHWASHERS

All Whirlpool Gold®

dishwashers

are ENERGY STAR® qualifi ed to

help conserve natural resources

and save money on utility bills.

The Sani Rinse option is certifi ed by NSF

International for sanitization, eliminating

99.999% of food soil bacteria.

If you are not completely satisfi ed that your

new Whirlpool Gold® dishwasher is quieter

and cleans better than your previous model,

Whirlpool Corporation will take it back

within 30 days of the date of purchase and

refund the full price to you.

All Whirlpool Gold® dishwashers feature electronic controls and control locks.

GU2275XTV

Q | B | Y

ENERGY STAR® qualifi ed

Slate plastic Tall Tub

Quiet Partner™ III sound package

5-level SheerClean™ direct feed wash system

Fully integrated electronic controls

Adaptive Wash cycle

Glass Xpress™ cycle

NSF Certifi ed Sani Rinse option

Nylon racks

Adjustable upper rack

AnyWare™ Plus silverware basket

Feature descriptions can be found in the glossary on pages 22–23.

Blue highlight denotes a step-up feature.

whirlpool.com

EFFICIENCY WHIRLPOOL GOLD®

DISHWASHERS WHIRLPOOL® DISHWASHERS PORTABLE DISHWASHER,

DISPOSERS & COMPACTORS ACCESSORIES GLOSSARY SPECIFICATIONS

11

GU3600XTV

Q | B | Y

ENERGY STAR® qualifi ed – CEE Tier I rated*

Resource Saver™ wash system

Quiet Partner™ V sound package

Adaptive Wash cycle

Speed Wash cycle

PowerScour™ option

NSF Certifi ed Sani Rinse option

EZ-2-Lift™ adjustable upper rack

AnyWare™ Plus silverware basket

Stainless Steel Tall Tub

Nylon racks

GU2800XTV

Q | B | T | S | Y

ENERGY STAR® qualifi ed – CEE Tier I rated*

Resource Saver™ wash system

Quiet Partner™ V sound package

Speed Wash cycle

EZ-2-Lift™ adjustable upper rack

Slate plastic Tall Tub

Adaptive Wash cycle

PowerScour™ option

NSF Certifi ed Sani Rinse option

Nylon racks

AnyWare™ Plus silverware basket

*The CEE Tier system is based on the Consortium for Energy Effi ciency qualifi ed product listings.

**According to a leading consumer magazine.

Resource Saver

dishwasher

TM

GU3100XTV

Q | B | S

Stainless Steel Tall Tub

ADA compliant

ENERGY STAR® qualifi ed

Quiet Partner™ IV sound package

5-level SheerClean™ direct feed wash system

Nylon racks

In-the-Rack silverware basket

Resource Saver

dishwasher

TM

S | Stainless SteelT | Biscuit Y | Monochromatic

Stainless Steel

AVAILABLE COLORS

B | BlackQ | White

Complete product specifi cations can be found on pages 24–25.

Whirlpool® dishwashers are designed to

endure repeated use so you can save money

on maintenance and repairs. No one has

fewer dishwasher repairs 13 years in a row.**

12

ECO CYCLE

This cycle on select models helps save

money on energy bills and is our most

efficient dishwasher cycle.† It's great for

cleaning lightly to moderately soiled dishes.

ENERGY STAR® QUALIFICATION

Whirlpool® dishwashers exceed

government standards to help conserve

natural resources and save money on utility

bills. Models DU1010XTX and DU1030XTX

surpass ENERGY STAR® qualification with

an eco-friendly CEE Tier I* rating—

no dishwashers are more efficient.**

*The CEE Tier system is based on the Consortium for Energy Effi ciency qualifi ed product listings.

**Based on ENERGY STAR® qualifi cations among leading dishwasher brands MSRP $399 and below. †Available on Whirlpool® models $399 and below.

Model: DU1030XTXS

whirlpool.com 13

1-HOUR WASH CYCLE

Delivers great wash performance in nearly

half the time.†† This hour-long cycle lets you

thoroughly clean your dirtiest dishes when

you are in a rush.

TALL TUB DESIGN

Lets you load tall and odd-shaped items

in both racks. An additional 3

"

of interior

space compared to standard tub models

makes room for even more extra-large

pans and dishes. Select models feature

the tallest tubs available among leading

dishwasher brands MSRP $399 and below.

WHIRLPOOL® DISHWASHER INNOVATION

NOTE: Not all features are available on all models.

††Compared to normal cycle with lightly soiled loads.

14

Whirlpool® dishwashers are designed to

endure repeated use so you can save money

on maintenance and repairs. No one has fewer

dishwasher repairs 13 years in a row.*

WHIRLPOOL® DISHWASHER FEATURES

*According to a leading consumer magazine.

Model: DU1055XTVS

whirlpool.com

EFFICIENCY WHIRLPOOL GOLD®

DISHWASHERS WHIRLPOOL® DISHWASHERS PORTABLE DISHWASHER,

DISPOSERS & COMPACTORS ACCESSORIES GLOSSARY SPECIFICATIONS

15

NOTE: Not all features are available on all models.

ANYWARE™ PLUS

SILVERWARE BASKET

Designed to fit in three places for maximum

flexibility. Put it on the front of the rack or in

the door for 100% usable rack space, or use it

in the bottom rack.

NYLON DISH RACKS

Durable nylon rack coating resists rust and

helps prevent scratching. These long-lasting

nylon racks stand the test of time and help keep

dishes from being chipped.

QUIET PARTNER™ SOUND PACKAGES

Whirlpool brand dishwashers offer many levels

of quiet operation with this system of

sound-reducing insulation.

NSF CERTIFIED SANI RINSE OPTION

Makes sure dishes are thoroughly disinfected

with a high temperature rinse. This option is

certified by NSF International for sanitization,

eliminating 99.999% of food soil bacteria.

AUTO SOIL SENSOR

Optimizes every cycle for reliable cleaning

results. When activated, this sensor measures

soil in the wash water to determine how dirty

dishes are, then adjusts the cycle accordingly.

It automatically recalibrates the load after

every 250 cycles for maximum performance.

SHEERCLEAN™ DIRECT FEED

WASH SYSTEM

Channels water up and out of the back and top

of the dishwasher to powerfully clean from four to

five different angles. The filter keeps wash water

clean and delivers sparkling-clean dishes every

time. With no cleaning tower in the middle of the

tub, there's more room for larger loads of dishes.

16

DU1010XTX

Q | B | T | D

ENERGY STAR® qualifi ed – CEE Tier I rated*

White plastic Tall Tub

Quiet Partner™ I sound package

4-level SheerClean™ direct feed wash system

Control lock

1-Hour Wash cycle

Vinyl racks

In-the-Rack silverware basket

Feature descriptions can be found in the glossary on pages 22–23.

WHIRLPOOL® DISHWASHERS

All Whirlpool® dishwashers feature electronic controls.

DU1030XTX

Q | B | T | S

Eco cycle

NSF Certifi ed Sani Rinse option

Adjustable, In-the-Rack silverware basket

ENERGY STAR® qualifi ed – CEE Tier I rated*

White plastic Tall Tub

Quiet Partner™ I sound package

4-level SheerClean™ direct feed wash system

1-Hour Wash cycle

Vinyl racks

All Whirlpool®

dishwashers

are ENERGY STAR® qualifi ed to

help conserve natural resources

and save money on utility bills.

The Sani Rinse option is certifi ed by NSF

International for sanitization, eliminating

99.999% of food soil bacteria.

Blue highlight denotes a step-up feature.

*The CEE Tier system is based on the Consortium for Energy Effi ciency qualifi ed product listings.

whirlpool.com

EFFICIENCY WHIRLPOOL GOLD®

DISHWASHERS WHIRLPOOL® DISHWASHERS PORTABLE DISHWASHER,

DISPOSERS & COMPACTORS ACCESSORIES GLOSSARY SPECIFICATIONS

17

DU1300XTV

Q | B | T | S

Nylon racks

ENERGY STAR® qualifi ed

White plastic Tall Tub

Quiet Partner™ II sound package

5-level SheerClean™ direct feed wash system

Auto soil sensor

Control lock

Soak & Scour option

NSF Certifi ed Sani Rinse option

AnyWare™ Plus silverware basket

DU1055XTV

Q | B | T | D | S

Quiet Partner™ II sound package

5-level SheerClean™ direct feed wash system

Auto soil sensor

Control lock

Soak & Scour option

AnyWare™ Plus silverware basket

ENERGY STAR® qualifi ed

White plastic Tall Tub

NSF Certifi ed Sani Rinse option

Vinyl racks

S | Stainless SteelT | Biscuit D | Universal SilverB | BlackQ | White

AVAILABLE COLORS

**According to a leading consumer magazine.

Complete product specifi cations can be found on pages 24–25

Whirlpool® dishwashers are designed to

endure repeated use so you can save money

on maintenance and repairs. No one has

fewer dishwasher repairs 13 years in a row.**

18

DP1040XTX

Q | B

ENERGY STAR® qualifi ed

White plastic Tall Tub

Quiet Partner™ I sound package

4-level SheerClean™ direct feed wash system

Electronic controls

Eco cycle

1-Hour Wash cycle

Vinyl racks

In-the-Rack silverware basket

*GC1000PE and GC2000PE also available with plug and cord.

PORTABLE DISHWASHER

GC1000XE/PE*

1

⁄

3

-HP motor

Locked-in mounting

Continuous-feed operation

Overload protector

Manual reset

Feature descriptions can be found in the glossary on pages 22–23.

GC5000XE

3

/

4

-HP motor

Stainless steel grinding wheel

Sound insulation

Locked-in mounting

Continuous-feed operation

Overload protector

Manual reset

GC2000XE/PE*

1

/

2

-HP motor

Locked-in mounting

Continuous-feed operation

Overload protector

Manual reset

GARBAGE DISPOSERS

Blue highlight denotes a step-up feature.

whirlpool.com

EFFICIENCY WHIRLPOOL GOLD®

DISHWASHERS WHIRLPOOL® DISHWASHERS PORTABLE DISHWASHER,

DISPOSERS & COMPACTORS ACCESSORIES GLOSSARY SPECIFICATIONS

19

TRASH COMPACTORS

TU800SPP

Q | B

1.4 cu. ft. capacity

Undercounter

Knob On/Off/Start

Touch-Toe™ drawer opener

Easy Rollers™ installation wheels

1

⁄

3

-HP motor

4-to-1 Compaction ratio

GX900QPP

Q | B | T | S

Touch pad controls

Clean Touch™ console

˝Hidden˝ removable key control knob

Tilt-Away trash basket

1.4 cu. ft. capacity

Undercounter

Touch-Toe™ drawer opener

Easy Rollers™ installation wheels

1

⁄

3

-HP motor

4-to-1 Compaction ratio

TRASH COMPACTOR FEATURES

All Whirlpool® trash compactors feature a wrap-around drawer panel, automatic anti-jam,

front levelers/rear rollers, bag retainer buttons, side release bin and tilt switch.

TOUCH PAD CONTROLS

No dials to turn. No switches to flip. Touch pad

controls make trash compacting easy with the

simple touch of a button.

TOUCH-TOE™ DRAWER OPENER

A light tap of the toe does the trick to release

the trash compactor drawer when your hands

are full. HIDE THE TRASH

Minimize trips to the trash can with a built-in

trash compactor that organizes and streamlines

your kitchen.

Complete product specifi cations can be found on pages 26–27.

Blue highlight denotes a step-up feature.

GC900QPP

Q | B

Convertible freestanding-to-built-in

1.4 cu. ft. capacity

Touch pad controls

Clean Touch™ console

Touch-Toe™ drawer opener

˝Hidden˝ removable key control knob

Easy Rollers™ installation wheels

1

⁄

3

-HP motor

4-to-1 Compaction ratio

Tilt-Away trash basket

20

DISHWASHER CUSTOM PANELS & OPTIONAL ACCESSORY KITS

MOUNTING KITS

WHITE BISCUIT BLACK STAINLESS STEEL

MODELS: DU1055XTV, DU1300XTV, GU2275XTV, GU2300XTV, GU2475XTV, GU2800XTV, GU3100XTV & GU3600XTV

4" Console Trim Kit*4396200 4396201 4396199

4" Wrap Around Panel 8171777

Side Panel Kit 8171656 8171658 8171657 8171659

*Trim Kit accommodates both a framed and frameless custom panel design.

6

"

custom panels for models DU1010XTX, DU1030XTX and DP1040XTX are not available at this time.

Power Cord (all models) Part #4317824.

MODEL: GU3600XTV

Floor Mounting Kit 8171477

MODELS: DU1030XTX & DP1040XTX

Side Mounting Kit 4396194

To acquire pricing information, order Whirlpool® cleaning accessories, and determine delivery time,

visit whirlpool.com/accessories or call 1-800-462-3819.

ACCESSORIES

For easy dishwasher

installation, choose one

of these mounting kits.

Part #8171477

HOSES

HOSE MODEL NUMBER

4' Red EPDM hose W10278625RP

5' Red EPDM hose W10278626RP

6' Red EPDM hose W10278627RP

6' Braided hose W10278635RP

6' Red EPDM hose W10278627RC

6' Braided hose W10278636RC

Hoses include brass elbow, brass swivel and gooseneck fi ttings.

Part #W10278625RP

whirlpool.com

EFFICIENCY WHIRLPOOL GOLD®

DISHWASHERS WHIRLPOOL® DISHWASHERS PORTABLE DISHWASHER,

DISPOSERS & COMPACTORS ACCESSORIES GLOSSARY SPECIFICATIONS

21

SMALL ITEMS BASKET

Fits all Whirlpool® dishwashers. It holds baby

items, jar lids and other small utensils that would

normally slip through the dishwasher rack.

(3370993RB)

CLEANING & CONVENIENCE

AFFRESH™ DISHWASHER

& DISPOSAL CLEANER

Use once a month or as needed for a cleaner,

fresher dishwasher and disposal. These

innovative tablets help prevent odor and

remove stubborn stains. (W10282479)

WHITE DISHWASHER RACK REPAIR KIT

This kit has everything you need to repair your

dishwasher rack tines. It contains 150 tine tips,

a 4-oz bottle of vinyl touch-up paint/adhesive

with a brush and instruction sheet. (4396838RC)

SMALL ITEMS BAG

Holds extra-small utensils, contact cases and

other small items that would normally slip

through the dishwasher rack. (8519716)

SWIVEL GOOSENECK FITTING

Space-saving 90˚ design makes this 3/4

"

x 3/8

"

elbow hose fitting perfect for easy dishwasher

installation. A 3/8

"

brass compression fitting is

included. (W10273460)

3-PRONG DISHWASHER

POWER SUPPLY KIT

This straight, 6

'

kit fits dishwashers from most

major brands and includes a power cord, wire

nuts and instructions. (4317824RP)

22

1-Hour Wash cycle

Delivers great wash performance in nearly half the

time.* This hour-long cycle lets you thoroughly clean

your dirtiest dishes when you are in a rush.

ADA Compliant

Provides adjustable height from 321/2

"

to 341/2

"

, making

this dishwasher ideal for height constrained installation

and compliant with the Americans with Disabilities Act.

Adaptive Wash cycle

Uses dual sensors to determine the size of the load

and the soil level of dishes. It automatically selects the

appropriate cleaning level and cycle duration to save

time, water and energy.

Adjustable upper rack

Manually raise or lower the upper rack to better fi t tall

or odd-shaped items in either rack.

AnyWare™ Plus silverware basket

Designed to fi t in three places for maximum fl exibility.

Put it on the front of the rack or in the door for 100%

usable rack space, or use it in the bottom rack.

Auto soil sensor

Optimizes every cycle for reliable cleaning results.

This sensor measures soil in the wash water to

determine how dirty dishes are, then adjusts the

cycle accordingly. It automatically recalibrates the

load after every 250 cycles for maximum performance.

CEE Tier qualifi cation

Based on the Consortium for Energy Efficiency

(CEE) qualified product listings, our most efficient

dishwashers are rated Tier I. These models feature

advanced water and energy savings and may qualify

for rebates from local utility companies.

China cycle

Cares for lightly soiled items or china and crystal.

During the cycle, the wash action repeatedly pauses

for several seconds to allow for adequate soak time

and even gentler cleaning.

Clean & Quiet Guarantee

If you are not completely satisfi ed that your new

Whirlpool Gold® dishwasher is quieter and cleans

better than your previous model, Whirlpool

Corporation will take it back within 30 days of the

date of purchase and refund the full price to you.

Clean Touch™ console (Trash Compactor)

Wipes down easily with the simple swipe of a cloth.

This console features a smooth surface without

dials or switches.

Control lock

Disables buttons on the control pad to help prevent

accidental operation or children from starting or

stopping the dishwasher.

Cup shelf

Allows you to stack two levels of coffee

mugs or to secure delicate glassware

when used as a stemware holder during

the wash cycle.

Delay Wash option

Wash dishes according to your schedule. This option

lets you delay washing for up to 6 hours during

off-peak hours when utility rates may be lower.

Easy Rollers™ installation wheels (Trash Compactor)

Helps provide easy maneuverability as the compactor

is positioned into place.

Eco cycle

This cycle on select models helps save energy and

is our most effi cient dishwasher cycle.** It's great for

cleaning lightly to moderately soiled dishes.

ENERGY STAR® qualifi ed

Exceeds government standards to help conserve

natural resources and save money on utility bills.

EZ-2-Lift™ Adjustable upper rack

Easily adjust the upper rack 2

"

up or down to

fi t larger items in either rack.

Fold-down tines

Secures dishes during the wash cycle or

can be folded down to create space for

larger items.

Fully integrated electronic controls

Add a modern accent to your kitchen.

The control panel is hidden away

to provide a sleek exterior while

preventing unwanted cycle changes

or accidental operation.

Glass Xpress™ cycle

Washes glassware or lightly soiled items—like plastic

containers, water bottles and lids —in just 30 minutes.

Heated Dry option

Dries dishes thoroughly. Once this option is complete,

dishes are ready for storage.

GLOSSARY

*Compared to normal cycle with lightly soiled loads. **Available on Whirlpool® models $399 and below.

whirlpool.com

EFFICIENCY WHIRLPOOL GOLD®

DISHWASHERS WHIRLPOOL® DISHWASHERS PORTABLE DISHWASHER,

DISPOSERS & COMPACTORS ACCESSORIES GLOSSARY SPECIFICATIONS

23

High Temperature Wash option

Choose this option when additional sanitization of

items like baby bottles, glassware or dishes is required.

Light item clip/Side clip

Secures lightweight items during the

wash cycle and prevents items from

falling out of the basket. They also stop

cups and other small containers from

fl ipping over and fi lling with water.

NSF Certifi ed Sani Rinse option

Sanitizes dishes by eliminating 99.999% of food soil

bacteria, as certifi ed by NSF International.

Pots & Pans cycle

Provides powerful cleaning for dirty pots and pans

by adding extra wash time to the cycle.

PowerScour™ option

Uses 36 targeted spray jets in a designated wash area

to scour away baked-on foods without soaking or

scrubbing. From casserole dishes to pots and pans,

clean a wide variety of items simultaneously—all

without using an additional drop of water.

Quiet Partner™ sound packages

Whirlpool brand dishwashers offer many levels of

quiet operation with this system of sound-reducing

insulation. The Quiet Partner™ V sound package

minimizes dishwasher noise for our quietest

dishwasher ever.†

Resource Saver™ dishwasher

Deep cleans a full load of dishes using

1⁄3

less water

and energy.†† Provides excellent cleaning fi rst in the

upper rack, then the lower, to reduce the amount

of water used. With an eco-friendly CEE Tier I

qualifi cation, Whirlpool Gold® Resource Saver™

dishwashers are our most effi cient ever.

Rinse Only cycle

Gives your dishes a quick refresh. Whether they’re

brand new or rarely used, dishes come out clean.

SheerClean™ wash system

Channels water up and out of the back and top of the

dishwasher to powerfully clean from multiple different

angles. The fi lter keeps wash water clean and delivers

sparkling-clean dishes every time.

Slate interior

Reduces the appearance of visible tub

stains, wash after wash. Sophisticated

slate styling gives the dishwasher an

attractive, premium look.

Soak & Scour option

Gently soaks, powerfully cleans and then soaks

again to remove tough soils from dishes so you

don’t have to.

Speed Wash cycle

Perfect when you need clean dishes in a hurry. Run

a full cycle in just one hour—that’s less than half the

time of other wash cycles.

Stainless steel interior

Adds a sleek, smooth texture to the interior of the

dishwasher. Stainless steel provides

higher heat

retention to further improve drying performance,

while also offering a high-end look.

Tall Tub design

Allows you to load tall and

odd-shaped items in both racks.

An additional 3

"

of interior space

compared to standard tub models

makes room for extra-large items

in the lower rack and plates or sports

bottles in the upper rack.

Tilt-away trash basket (Trash Compactor)

Tilts to the right of the compactor, making it easier to

unload and clean.

Touch-Toe™ drawer opener (Trash Compactor)

Provides hands-free opening. A light tap of the toe

does the trick, releasing the drawer with ease.

†Models GU2800XTV and GU3600XTV. ††Compared to dishwashers manufactured before 2000.

24

WHI R L P O O L® D I S H WAS H ERS

SPECIFIC ATIO NS AND CUTOUT DIMENSIONS

MODEL DU1010XTX DU1030XTX DU1055XTV DU1300XTV

Replaces model DU930PWS

ENERGY STAR

®

qualified CEE Tier I

*

CEE Tier I

*

••

Tall Tub design ••••

Tub material Plastic – White Plastic – White Plastic – White Plastic – White

Sound package Quiet Partner

™

I Quiet Partner

™

I Quiet Partner

™

II Quiet Partner

™

II

Built-in dishwasher

••••

DISHWASHER SYSTEM

5-level SheerClean

™

direct feed wash system •

•

4-level SheerClean

™

direct feed wash system

••

Auto soil sensor

••

Electronic controls

•••

•

Control lock

•

••

Console size 6" 6" 4" 4"

CYCLES

Eco

•

1-Hour Wash

••

Pots & Pans

••

••

Normal

••

••

Light

••

Rinse Only

••

•

OPTIONS

Soak & Scour

••

NSF Certified Sani Rinse

••

•

High Temperature Wash

•••

•

Heated Dry

•••

•

Delay Wash 4 Hour 4 Hour 2-4-6 Hour 2-4-6 Hour

RACK FLEXIBILITY

Rack coating

Vinyl Vinyl Vinyl

Nylon

Light item clips •

Cup shelves •

Silverware basket

In-the-Rack Adjustable, In-the-Rack AnyWare

™

Plus AnyWare

™

Plus

COLOR AVAILABILITY

White (Q)

••

••

Black (B)

••••

Biscuit (T)

••

•

•

Universal Silver (D)

•

•

Stainless Steel (S)

•

•

•

DIMENSIONS

Height (A)

33

7

⁄

8

"–34½" 33

7

⁄

8

"–34½"

33

7

⁄

8

"–34½" 33

7

⁄

8

"–34½"

Width (B)

23

7

⁄

8

"23

7

⁄

8

"

23

7

⁄

8

"

23

7

⁄

8

"

Depth (C)

24½" 24½"

24½"

24

½

"

24"

34"

24"

*The CEE Tier system is based on the Consortium for

Energy Efficiency qualified product listings.

whirlpool.com

EFFICIENCY WHIRLPOOL GOLD®

DISHWASHERS WHIRLPOOL® DISHWASHERS PORTABLE DISHWASHER,

DISPOSERS & COMPACTORS ACCESSORIES GLOSSARY SPECIFICATIONS

25

WHI R L P O O L G O LD ® D IS H WASH ERS

SPECIFIC ATIO NS AND CUTOUT DIMENSIONS

*The CEE Tier system is based on the Consortium for

Energy Efficiency qualified product listings.

MODEL GU2275XTV GU2300XTV GU2475XTV GU2800XTV GU3100XTV GU3600XTV

ENERGY STAR

®

qualified

••

•CEE Tier I

*

•CEE Tier I

*

Tall Tub design

••

••••

30-Day Clean &

Quiet guarantee

••

••••

Tub material Plastic – Slate Plastic – Slate Plastic – Slate Plastic – Slate Stainless Steel Stainless Steel

Sound package Quiet Partner

™

III Quiet Partner

™

III Quiet Partner

™

IV Quiet Partner

™

V Quiet Partner

™

IV Quiet Partner

™

V

ADA compliant •

DISHWASHER SYSTEM

Resource Saver

™

wash system ••

5-level SheerClean

™

direct feed wash system

••

••

Auto soil sensor

•••••

Electronic controls Fully Integrated

•

Fully Integrated •••

Control lock

••

••

•

•

CYCLES

Adaptive Wash

••

•••

Glass Xpress

™

••

•

Speed Wash ••

Pots & Pans

••

••••

Normal

••

••••

China

•••

••

Light •

Heavy •

Rinse Only

•••

•••

OPTIONS

PowerScour

™

••

••

Soak & Scour

•

NSF Certified Sani Rinse

•••

••

High Temperature Wash

•••

•••

Heated Dry

•••

•••

Delay Wash 4 Hour 2-4-6 Hour 4 Hour 2-4-6 Hour 2-4-6 Hour 2-4-6 Hour

RACK FLEXIBILITY

Nylon rack coating

•••

•••

Adjustable upper rack

•••

EZ-2-Lift

™

EZ-2-Lift

™

Light item clips

•

••

2 Side clips ••

Cup shelves

•

•••

2 Upper rack fold-down tines

•••

••

Lower rack fold-down tines

•

PowerScour

™

PowerScour

™

PowerScour

™

PowerScour

™

Silverware basket AnyWare

™

PlusAnyWare

™

Plus AnyWare

™

Plus AnyWare

™

Plus In-the-Rack AnyWare

™

Plus

COLOR AVAILABILITY

White (Q)

•••

•••

Black (B)

••••••

Biscuit (T)

•

•

Stainless Steel (S)

•

•

•

Monochromatic

Stainless Steel (Y)

••

••

DIMENSIONS

Height (A)

33

7

⁄

8

"–34½" 33

7

⁄

8

"–34½" 33

7

⁄

8

"–34½"

33

7

⁄

8

"–34½"

32

1

⁄

2

"–34½"

33

7

⁄

8

" – 34½"

Width (B)

23

7

⁄

8

"23

7

⁄

8

"23

7

⁄

8

"

23

7

⁄

8

"

23

7

⁄

8

"23

7

⁄

8

"

Depth (C)

24½" 24½" 24½"

24½"

24"

24½"

26

MODEL DP1040XTX

ENERGY STAR

®

qualified •

Tall Tub design •

Tub material Plastic – White

Sound package Quiet Partner

™

I

Portable •

DISHWASHER SYSTEM

4-level SheerClean

™

direct feed wash system •

Electronic controls •

Control lock •

CYCLES

Eco •

1-Hour Wash •

Pots & Pans •

Normal •

Rinse Only •

OPTIONS

High Temperature Wash •

Heated Dry •

Delay Wash 4-Hour

RACK FLEXIBILITY

Rack coating

Vinyl

Silverware basket

In-the-Rack

COLOR AVAILABILITY

White (Q) •

Black (B) •

DIMENSIONS

Height (A)

35

7

⁄

8

"–37"

Width (B)

24

1

⁄

8

"

Depth (C)

24½"

PO RTABLE D ISHWA S H E R

SPECIFIC ATIO NS

DIS H WASHER

CUS TOM PANEL DIMENSIO NS

Cutting Notes for Custom Panels:

1. Custom panel for door cannot exceed 8-lb weight.

2. Upper and lower panels are not the same width.

3. Match woodgrain direction with that of adjacent cabinets.

4. Sand panel edges to provide a smooth finish.

5. Use moisture-resistant sealer on sides and edges of panels to protect

from humidity. (Dishwasher is subject to humidity.)

4

"

Console Models:

DU1055XTV, DU1300XTV, GU2275XTV, GU2300XTV, GU2475XTV,

GU2800XTV, GU3100XTV and GU3600XTV.

STYLE HEIGHT (A) WIDTH (B) THICKNESS (C)

Frameless 4" 25

29

⁄

32

" 23

3

⁄

8

"

3

⁄

4

"

Framed 4" 26" 23

1

⁄

4

"

1

⁄

4

"

6

"

custom panels are not available at this time.

whirlpool.com

EFFICIENCY WHIRLPOOL GOLD®

DISHWASHERS WHIRLPOOL® DISHWASHERS PORTABLE DISHWASHER,

DISPOSERS & COMPACTORS ACCESSORIES GLOSSARY SPECIFICATIONS

27

TR AS H COM PAC TO RS

SPECIFIC ATIO NS AND CUTOUT DIMENSIONS

Electrical Requirements:

Rated load is 11.0 amps, 120 volts, 60 Hz AC.

15-amp (20-amp max.) circuit required.

When local codes permit, any Whirlpool® dishwasher

plus a disposer up to 7.2 amps can be installed on a

single 20-amp circuit. Do not use an extension cord.

Water Pressure — 15 to 120 psi.

Recommended incoming water temperature

— 120°F minimum.

Listed by Underwriters Laboratories.

WARRANTY INFORMATION

1-Year Limited Warranty, Parts and Labor

For complete details, please see the Use & Care Guide

packed with product, ask your dealer or visit whirlpool.com

DIMENSIONS ARE SHOWN

FOR PLANNING PURPOSES ONLY.

For complete information, see Installation

Instructions packed with product.

MODELS TU800SPP GX900QPP GC900QPP

Capacity (cu. ft.) 1.4 1.4 1.4

Convertible freestanding-to-built-in •

Undercounter • •

Touch pad controls • •

Knob On/Off/Start •

Wrap around drawer panel •••

Automatic anti-jam •••

Clean Touch™ console • •

Touch-Toe™ drawer opener •••

“Hidden” removable

key control knob • •

Easy Rollers™ installation wheels •••

1⁄3-HP motor •••

4-to-1 Compaction ratio •••

Front levelers/rear rollers •••

Bag retainer buttons •••

Side release bin •••

Tilt-Away trash basket • •

Tilt switch •••

COLOR AVAILABILITY

White (Q) •••

Black (B) •••

Biscuit (T) •

Stainless Steel (S) •

DIMENSIONS

Height (A)

34

1

⁄

8

"

34

1

⁄

8

"

34

1

⁄

8

"

Width (B)

15

"

15

"

15

"

Depth (C)

24

"

24

"

24

"

243

/4"

341

/4"

151

/8"

18"

*GC1000PE also available with plug and cord. **GC2000PE also available with plug and cord.

GA R B AGE D ISP OS E RS

SPECIFIC ATIO NS AND CUTOUT DIMENSIONS

MODELS GC1000XE/PE*GC2000XE/PE*GC5000XE

Motor 1⁄3-HP 1⁄2-HP 3⁄4-HP

Locked-in mounting • • •

Continuous-feed operation • • •

Stainless steel grinding wheel •

Overload protector • • •

Manual reset • • •

Sound insulation •

DIMENSIONS

A 11

3

⁄

8

" 11

3

⁄

8

" 12

3

⁄

8

"

B 5

15

⁄

16

" 5

15

⁄

16

" 6

15

⁄

16

"

C 4" 4" 4"

D 6

5

⁄

16

" 6

5

⁄

16

" 7

3

⁄

4

"

E 5" 5" 5

3

⁄

4

"

*GC1000PE and GC2000PE also available with plug and cord.

®Registered trademark/™Trademark of Whirlpool, U.S.A. All other trademarks are owned by their respective companies.

©2009 Whirlpool Corporation. All rights reserved. Form No. WD090295. Printed in the U.S.A. 12/09. | whirlpool.com

As part of Whirlpool Corporation's ongoing

commitment to well-managed forests, all of

the paper in this catalog comes from forests in

compliance with the Forest Stewardship Council

standards for Responsible Forest Management.
