1
GB
VT 265 VT 275VT 295
www.whirlpool.com
2GB
GB
B
INSTALLATION
PRIOR TO CONNECTING
ENSURE THAT THE APPLIANCE IS NOT DAMAGED. Check
that the oven door closes  rmly against the
door support. Empty the oven and clean the
interior with a soft, damp cloth.
AFTER CONNECTING
THE EARTHING OF THIS APPLIANCE is compulso-
ry. The manufacturer will accept no re-
sponsibility for injury to persons, animals
or damage to objects arising from the
non-observance of this requirement.
The manufacturers are not liable for any
problems caused by the user’s failure to ob-
serve these instructions.
DO NOT OPERATE THIS APPLIANCE if it has a
damaged mains cord or plug, if it is not
working properly, or if it has been dam-
aged or dropped. Do not immerse the
mains cord or plug in water. Keep the
cord away from hot surfaces. Electrical
shock,  re or other hazards may result.
CHECK THAT THE VOLTAGE on the rating
plate corresponds to the voltage in your
home.
THE OVEN CAN BE OPERATED ONLY if the oven door is
rmly closed.
PLACE THE OVEN ON A STABLE, EVEN
SURFACE that is strong enough to
hold the oven and the food
utensils you put in it. Use
care when handling.
POSITION THE OVEN AT A DISTANCE from other heat-
ing sources. For su cient ventilation there
must be a space of at least 20 cm above the
oven. Ensure that the space underneath, above
and around the oven is empty to allow for
proper air ow. The microwave oven shall not
be placed in a cabinet.
POOR TELEVISION RECEPTION and radio interference
may result if the oven is lo-
cated close to a TV, radio
or aerial.
N
DO NOT REMOVE THE MICROWAVE INLET PROTECTION
PLATES located on the side of
the oven cavity wall. They
prevent grease & food parti-
cles from entering the mi-
crowave inlet channels.
DO NOT USE EXTENSION CORD:
IF THE POWER SUPPLY CORD IS TOO SHORT, have a
quali ed electrician or serviceman install
an outlet near the appliance.
WARNING: Improper use of the grounding
plug can result in a risk of electric shock. Con-
sult a qualified electrician or serviceman if the
grounding instructions are not completely un-
derstood, or if doubt exists as to whether the
microwave oven is properly grounded.
3
GB
THE APPLIANCES ARE NOT INTENDED to be operat-
ed by means of an external timer or sepa-
rate remote-control system.
ONLY ALLOW CHILDREN to use the appliance
without adult supervision after adequate
instructions have been given, so that the
child is able to use the appliance in a safe
way and understands the hazards of im-
proper use. Children should be supervised
when using other heatsources (if avail-
able) separately or in
combination with mi-
crowaves due to the
high temperatures gen-
erated.
THIS APPLIANCE IS NOT INTENDED FOR use by per-
sons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge, un-
less they have been given supervision or in-
struction concerning use of the appliance
by a person responsible for their safety.
CHILDREN SHOULD BE SUPERVISED to ensure that
they do not play with the appliance.
IMPORTANT SAFETY INSTRUCTIONS
DO NOT HEAT, OR USE FLAMMABLE MATERIALS in
or near the oven. Fumes can create a  re
hazard or explosion.
DO NOT USE YOUR MICROWAVE oven for drying
textiles, paper, spices, herbs, wood,  ow-
ers, fruit or other combustible materials.
Fire could result.
DO NOT OVER-COOK FOOD. Fire could result.
DO NOT LEAVE THE OVEN UNATTENDED, espe-
cially when using paper, plastic or oth-
er combustible materials in the cook-
ing process. Paper can char or burn and
some plastics can melt if used when
heating foods.
Do not leave the oven unattended if you
are using a lot of fat or oil since they can
overheat and cause a fire!
IF MATERIAL INSIDE / OUTSIDE THE OVEN SHOULD
IGNITE OR SMOKE IS OBSERVED, keep oven
door closed and turn the oven o . Dis-
connect the power cord or shut o pow-
er at the fuse or circuit breaker panel.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
DO NOT USE YOUR MICROWAVE
oven for heating anything in
airtight sealed contain-
ers. The pressure increas-
es and may cause damage
when opening or may explode.
EGGS
DO NOT USE YOUR MICROWAVE oven for cook-
ing or reheating whole eggs with or
without shell since they may
explode even after microwave
heating has ended.
THE DOOR SEALS AND THE DOOR SEAL AREAS must
be regularly inspected for damage. If these
areas are damaged the appliance should
not be operated until it has been repaired
by a trained service technician.
DO NOT USE corrosive chemicals or va-
pors in this appliance. This type of oven
is speci cally designed to heat or cook
food. It is not designed for industrial or
laboratory use.
DO NOT HANG OR PLACE heavy items on the
door as this can damage the oven open-
ing and hinges. The door handle should
not be used for hanging things on.
4GB
GENERAL
THIS APPLIANCE IS DESIGNED FOR DOMESTIC USE ONLY!
THE APPLIANCE SHOULD NOT BE OPERATED without food
in the oven when using microwaves. Operation in
this manner is likely to damage the appliance.
IF YOU PRACTICE OPERATING the oven, put a glass
of water inside. The water will absorb the mi-
crowave energy and the oven will not be dam-
aged.
REMOVE WIRE TWIST-TIES from paper or
plastic bags before placing bag in
the oven.
DEEPFRYING
DO NOT USE YOUR MICROWAVE oven for deep-frying,
because the oil temperature cannot be
controlled.
LIQUIDS
E.G. BEVERAGES OR WATER. Overheating the liquid
beyond boiling point can occur
without evidence of bubbling.
This could result in a sudden
boil over of the hot liquid.
To prevent this possibility the
following steps should be taken:
1. Avoid using straight-sided containers with
narrow necks.
2. Stir the liquid before placing the container
in the oven and let the teaspoon remain
in the container.
3. After heating, allow standing for a short
time, stirring again before carefully re-
moving the container from the oven.
AFTER HEATING BABY FOOD or liquids in a
baby bottle or in a baby food
jar, always stir and check the
temperature before serving.
This will ensure that the heat is evenly distributed
and the risk of scalding or burns can be avoided.
Ensure the Lid and the Teat is removed be-
fore heating!
PRECAUTIONS
USE HOT PADS OR OVEN MITTS to prevent
burns, when touching containers, oven
parts, and pan after cooking. Accessi-
ble parts may become hot during use,
young children should be kept away.
DO NOT USE THE CAVITY for any storage purposes.
THE VENTILATION OPENINGS on the oven must not be
covered. Blocking the air intake or exhaust vents
may cause damage to the oven and poor cook-
ing results.
DO NOT STORE or use this appliance outdoors.
DO NOT USE this product near a kitchen sink, in
a wet basement, or near a swimming pool, or
similar.
5
GB
CRISP HANDLE
USE THE SUPPLIED SPECIAL CRISP
HANDLE to remove the hot Crisp
plate from the oven.
CRISPPLATE
PLACE THE FOOD DIRECTLY ON THE CRISP-PLATE.
Always use the Glass turn-
table as support when us-
ing the Crisp-plate.
DO NOT PLACE ANY UTENSILS on
the Crisp-plate since it will quickly
become very hot and is likely to cause
damage to the utensil.
THE CRISP-PLATE may be preheated before use
(max. 3 min.). Always use the Crisp function
when preheating the crisp-plate.
LARGE VESSELS
USE THE TURNTABLE STOP button when cooking
with vessels that is so large that they can not
turn freely in the oven. This function can only
be used when cooking with microwaves only.
The button will
not work with
other functions.
ACCESSORIES
GENERAL
IF ACCESSORIES CONTAINING METAL comes in contact
with the oven interior, while the oven is in op-
eration, sparking can occur and the oven could
be damaged.
TURNTABLE SUPPORT
USE THE TURNTABLE SUPPORT under the
Glass turntable. Never put any oth-
er utensils on the turntable sup-
port.
Fit the turntable support in the oven.
GLASS TURNTABLE
USE THE GLASS TURNTABLE with all cooking meth-
ods. It collects the dripping juic-
es and food particles that other-
wise would stain and soil the in-
terior of the oven.
Place the Glass turntable on the turntable
support.
ENSURE THAT THE UTENSILS YOU USE are oven proof
and allow microwaves to
pass through them before
cooking.
WHEN YOU PUT FOOD AND ACCESSORIES in the micro-
wave oven, ensure that they do not come in
contact with the interior of the oven.
This is especially important with accesso-
ries made of metal or metal parts.
ALWAYS ENSURE that the turntable is able to turn
freely before starting the oven. If the turntable
isn’t able to turn freely you should use a small-
er vessel.
THERE ARE a number of accessories available on
the market. Before you buy, ensure they are
suitable for microwave use.
6GB
-+
Jet
Defrost
Jet Menu
Crisp
Micro Grill Crisp
e
w
q
KITCHEN TIMER
USE THIS FUNCTION when you need a kitchen timer to measure ex-
act time for various purposes such as cooking eggs or letting the
dough rise before baking etc.
q PRESS THE CLOCK BUTTON.
w TURN THE ADJUST KNOB TO SET THE TIME to measure.
e PRESS THE START BUTTON.
FLASHING COLONS indicate that the timer is running.
ONE PRESS ON THE CLOCK BUTTON displays how much is left on the Timer.
Its displayed for 3 seconds and then returns to displaying the cook-
ing time (If you are currently cooking).
TO STOP THE KITCHEN TIMER when it is operating in the background of
another function, you must  rst recall it to the foreground by press-
ing the Clock button and then stop it by pressing the Stop button.
AN ACOUSTIC SIGNAL will be heard when the timer has  nished to count
down.
START PROTECTION / CHILD LOCK
THIS AUTOMATIC SAFETY FUNCTION IS ACTIVATED ONE
MINUTE AFTER the oven has returned to
“stand by mode“. (The oven is in
“stand by” when the 24-hour clock is
displayed or if the clock has not been
set, when the display is blank).
THE DOOR MUST BE OPENED AND CLOSED e.g. putting
food into it, before the safety lock is released.
Else the display will show DOOR.
dOOR
7
GB
-+
Jet
Defrost
Jet Menu
Crisp
Micro Grill Crisp
PAUSE OR STOP COOKING
TO PAUSE COOKING:
THE COOKING CAN BE PAUSED to
check, turn or stir the food
by opening the door. The
setting will be maintained
for 10 minutes.
IF YOU DONT WANT TO CONTINUE COOKING:
REMOVE THE FOOD, close the door and
press the STOP button.
NOTE: After cooking ends, the cavity lamp is on
before pressing STOP button, it’s normal.
TO CONTINUE COOKING:
CLOSE THE DOOR and press the Start button
ONCE. The cooking is resumed from
where it was paused.
PRESSING THE START BUTTON TWICE will
increase the time by 30 seconds.
A BEEP WILL SIGNAL once a minute for 10 minutes
when the cooking is  nished. Press the STOP
button or open the door to
cancel the signal.
NOTE: The oven will only
hold the settings for 60 seconds if the door is
opened and then closed after the cooking is
nished.
THE CLOCK IS SET and in operation.
IF YOU WISH TO REMOVE THE CLOCK from the display once it has been set,
simply press the Clock button again for 3 seconds and then press
the Stop button.
TO REINSTATE THE CLOCK, follow the above procedure.
NOTE: KEEP THE DOOR OPEN WHILE SETTING THE CLOCK. This gives you 10
minutes to complete the setting of the Clock. Otherwise, each step
must be accomplished within 60 seconds.
CLOCK
WHEN THE APPLIANCE IS FIRST PLUGGED IN or after a power failure, it will
enter clock setting mode automatically.
q PRESS THE CLOCK BUTTON (3 seconds) until the left-hand digit
(hours) flicker.
w TURN THE ADJUST KNOB to set the hours.
e PRESS THE CLOCK BUTTON AGAIN. (The two right hand digits (min-
utes) flicker).
r TURN THE ADJUST KNOB to set the minutes.
t PRESS THE CLOCK BUTTON AGAIN.
q
e
t
w
r
8GB
MICROWAVES ONLY
POWER SUGGESTED USE:
JET
(800 W)
REHEATING OF BEVERAGES, water, clear soups, co ee, tea or other food with a high water
content. If the food contains egg or cream choose a lower power.
650 W COOKING OF sh, meat, vegetables etc.
500 W MORE CAREFUL COOKING e.g. high protein sauces, cheese and egg dishes and to  nish cook-
ing casseroles.
350 W SIMMERING STEWS, melting butter.
160 W DEFROSTING. Softening butter, cheeses.
90 W SOFTENING Ice cream.
-+
Jet
Defrost
Jet Menu
Crisp
Micro Grill Crisp
e
w
q
COOK & REHEAT WITH MICROWAVES
USE THIS FUNCTION for normal cooking and reheating, such as vegeta-
bles,  sh, potatoes and meat.
ONCE THE COOKING PROCESS HAS BEEN STARTED:
The time can easily be increased in 30-second steps by pressing
the Start button. Each press increases the time with 30 seconds.
You may also alter the time by turning the adjust knob to increase
or decrease the time.
CHOOSING POWER LEVEL
q PRESS THE MICRO BUTTON to set the power.
w TURN THE ADJUST KNOB to set the cooking time.
e PRESS THE START BUTTON.
9
GB
-+
Jet
Defrost
Jet Menu
Crisp
Micro Grill Crisp
THIS FUNCTION IS USED for quick reheating of food with a high water
content such as clear soups, co ee or tea.
JET START
q PRESS THE START BUTTON.
THIS FUNCTION AUTOMATICALLY STARTS with maximum microwave power
level and the cooking time set to 30 seconds. Each additional press
increases the time with 30 seconds. You may also alter the time by
turning the adjust knob to increase or decrease the time after the
function has started.
MANUAL DEFROST
FOLLOW THE PROCEDURE for cook & reheat with mi-
crowaves” and choose power level 160 W when
defrosting manually.
CHECK AND INSPECT THE FOOD REGULARLY. Experi-
ence will give you the times needed for vari-
ous amounts.
TURN LARGE JOINTS halfway through the defrost-
ing process.
FROZEN FOOD IN PLASTIC BAGS, plastic  lms or card-
board packages can be placed directly in the
oven as long as the package has no met-
al parts (e.g. metal twist ties).
THE SHAPE OF THE PACKAGE alters the de-
frosting time. Shallow packets defrost
more quickly than a deep block.
SEPARATE PIECES as they begin to defrost.
Individual slices defrost more easily.
SHIELD AREAS OF FOOD with small
pieces of aluminum foil if they
start to become warm (e.g.
chicken legs and wing tips).
BOILED FOOD, STEWS AND MEAT SAUCES defrost
better if stirred during defrosting time.
WHEN DEFROSTING it is better to under-
thaw the food slightly and allow the
process to  nish during standing time.
STANDING TIME AFTER DEFROSTING ALWAYS IMPROVES
the result since the temperature will then be
evenly distributed throughout the food.
q
10 GB
-+
Jet
Defrost
Jet Menu
Crisp
Micro Grill Crisp
e
w
q
JET DEFROST
USE THIS FUNCTION for defrosting Meat, Poultry, Fish, Vegetables and
Bread. JET Defrost should only be used if the net weight is between
100 g- 2.5 kg.
ALWAYS PLACE THE FOOD on the glass turntable.
q PRESS THE JET DEFROST BUTTON repeatedly to select food class.
w TURN THE ADJUST KNOB to set the weight of the food.
e PRESS THE START BUTTON.
MIDWAY THROUGH THE DEFROSTING PROCESS the oven stops and prompts
you to TURN FOOD.
Open the door.
Turn the food.
Close the door and restart by pressing
the Start button.
NOTE: The oven continues automatically after 2 min. if the food
hasn’t been turned. The defrosting time will be longer in this case.
11
GB
THIS FUNCTION NEEDS TO KNOW the net weight of the food.
FROZEN FOODS:
IF THE WEIGHT IS LESSER OR GREATER THAN REC-
OMMENDED WEIGHT: Follow the procedure
for “Cook & Reheat with microwaves”
and choose 160 W when defrosting.
FROZEN FOODS:
IF THE FOOD IS WARMER than deep-freeze
temperature (-1C), choose lower
weight of the food.
IF THE FOOD IS COLDER than deep-freeze
temperature (-1C), choose higher
weight of the food.
JET DEFROST
FOOD CLASS AMOUNT HINTS
qMEAT 100G - 2KGMinced meat, cutlets, steaks or roasts.
wPOULTRY 100G - 2.5KGChicken whole, pieces or fillets.
eFISH 100G - 1.5KGWhole, steaks or fillets.
rVEGETABLES 100G - 1.5KGMixed vegetables, peas, broccoli etc.
tBREAD 100G - 1KGLoaf, buns or rolls.
FOR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves” and choose 160 W when
defrosting.
12 GB
-+
Jet
Defrost
Jet Menu
Crisp
Micro Grill Crisp
e
w
q
GRILL
USE THIS FUNCTION TO quickly give a pleasant brown surface to the
food.
q PRESS THE GRILL BUTTON.
w TURN THE ADJUST KNOB to set the cooking time.
e PRESS THE START BUTTON.
PRESSING THE GRILL BUTTON DURING COOKING switches the Grill element
on and o . The timer will continue to count down when the Grill el-
ement is turned o .
ENSURE THAT THE UTENSILS used are heat resistant and ovenproof be-
fore grilling with them.
DO NOT USE PLASTIC utensils when grilling. They will melt. Items of
wood or paper are not suitable either.
13
GB
GRILL COMBI
POWER SUGGESTED USE:
650 W COOKING Vegetables & Gratins
350 - 500 W COOKING Poultry & Lasagne
160 - 350 W COOKING Fish & frozen gratins
160 W COOKING Meat
90 W GRATINATING fruit
0 W BROWNING only during cooking
-+
Jet
Defrost
Jet Menu
Crisp
Micro Grill Crisp
e
wq
GRILL COMBI
USE THIS FUNCTION TO cook such food as Gratin’s, Lasagne, Poultry and
Baked potatoes.
q PRESS THE GRILL BUTTON .
w PRESS THE MICRO BUTTON to set the power.
e TURN THE ADJUST KNOB to set the cooking time..
r PRESS THE START BUTTON.
DURING OPERATION you can switch the Grill element on/o by press-
ing the Grill button. The Max. possible microwave power level
when using the Grill is limited to a factory-preset level.
CHOOSING POWER LEVEL
IT IS POSSIBLE to switch the microwaves o by reducing the micro-
wave power level to 0 W. When 0 W is reached, the oven switches to
Grill only mode.
ENSURE THAT THE UTENSILS used are heat resistant and ovenproof be-
fore grilling with them.
DO NOT USE PLASTIC utensils when grilling. They will melt. Items of
wood or paper are not suitable either.
r
14 GB
CRISP
USE THIS FUNCTION TO reheat and cook pizzas and other dough based
food. It is also good for frying bacon and eggs, sausages, hamburg-
ers etc.
ENSURE that the Crisp-plate is correctly placed in the middle of the
Glass turntable.
USE OVEN MITTENS
or the special Crisp handle supplied when
removing the hot Crisp-plate.
BE CAREFUL, NOT TO TOUCH the ceiling beneath the Grill element.
DO NOT PLACE THE HOT CRISP-PLATE on any surface susceptible to heat.
THE OVEN AND THE CRISP-PLATE become very hot when using this
function.
q PRESS THE CRISP BUTTON.
w TURN THE ADJUST KNOB to set the cooking time.
e PRESS THE START BUTTON.
IT IS NOT POSSIBLE TO CHANGE OR SWITCH the Power level or Grill on/o ,
when using the Crisp function.
ONLY USE the supplied Crisp plate with this func-
tion. Other available Crisp plates on the market
will not give the correct result when using this
function.
THE OVEN AUTOMATICALLY use Microwaves and Grill in order to heat the
Crisp-plate. This way the Crisp-plate will rapidly reach its working
temperature and begin to brown and crisp the food.
Jet
Defrost
Jet Menu
Crisp
Stop Jet
Start
Micro Grill Crisp
-+
e
w
q
15
GB
IF THE DOOR ISNT OPENED AT THIS TIME (WITHIN 2 MINUTES) THE OVEN WILL:
ADD Stop and go to “stand by mode“.
STIR Continue the cooking process. End result
may not be optimal in this case.
TURN Continue the cooking process. End result
may not be optimal in this case.
Open the door.
Add, Stir or turn the food.
Close the door and restart by pressing the Start button.
JET MENU CRISP
USE THIS FUNCTION TO cook various types of frozen food.
THE OVEN WILL automatically select cooking method, time and pow-
er needed.
q PRESS THE JET MENU CRISP BUTTON repeatedly to set the food class
(see table).
w TURN THE ADJUST KNOB to set the weight of the food.
e PRESS THE START BUTTON.
SOME FOOD CLASSES REQUIRE the food to be added, turned or stirred
during cooking (varies between models). In these cases the oven
will stop and prompt you to perform the needed action.
-+
Jet
Defrost
Jet Menu
Crisp
Micro Grill Crisp
e
w
q
16 GB
JET MENU CRISP
FOOD CLASS RECOMMENDED
AMOUNT
ACCESSORIES TO USE DURING
COOKING
qRICE 300G - 650GINSERT THE EMPTY CRISP PLATE. ADD FOOD
WHENADD FOODIS DISPLAYED
STIR FOOD
wPASTA 250G - 550GINSERT THE EMPTY CRISP PLATE. ADD FOOD
WHENADD FOODIS DISPLAYED
STIR FOOD
eBUFFALO WINGS /
CHICKEN NUGGETS
250G - 500GUSE CRISP PLATE TURN FOOD
rFRENCH FRIES 250G - 500GUSE CRISP PLATE STIR FOOD
tPIZZA 250G - 750GUSE CRISP PLATE
yQUICHE 250G - 600GUSE CRISP PLATE
uBREADED FISH /
FISH STICKS
250G - 500GINSERT THE EMPTY CRISP PLATE. ADD FOOD
WHENADD FOODIS DISPLAYED
TURN FOOD
iCORDON BLEU/
CHICKEN CUTLETS
1 - 4 PCS (100-
125G A PCS)
INSERT THE EMPTY CRISP PLATE. ADD FOOD
WHENADD FOODIS DISPLAYED
TURN FOOD
FOR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight,
you should follow the procedure for “Cook and reheat with microwaves”.
NOTE:
Small amounts of oil or butter can be placed on the Crisp Plate during preheating.
17
GB
w
-+
Jet
Defrost
Jet Menu
Crisp
Micro Grill Crisp
q
1 CUP IS EQUAL TO 150 ml of beverage.
THE JET BEVERAGE FUNCTION PROVIDES you with an easy way to quickly re-
heat 1-4 cups of beverage.
JET BEVERAGE
q PRESS THE JET BEVERAGE BUTTON repeatedly to select the amount
of cups to be reheated.
w PRESS THE START BUTTON.
FOR AVOIDING over-boiling, place a teaspoon in the cup.
18 GB
MAINTENANCE & CLEANING
CLEANING IS THE ONLY MAINTENANCE normally re-
quired. It must be carried out with the micro-
wave oven disconnected.
FAILURE TO MAINTAIN THE OVEN in a clean condition
could lead to deterioration of the surface that
could adversely a ect the life of the appliance
and possibly result in a hazardous situation.
DO NOT USE METAL SCOURING PADS,
ABRASIVE CLEANSERS, steel-
wool pads, gritty wash-
cloths, etc. which can
damage the control pan-
el, and the interior and exterior oven sur-
faces. Use a cloth with a mild detergent
or a paper towel with spray glass cleaner.
Apply spray glass cleaner to a paper towel.
DO NOT SPRAY directly on the oven.
AT REGULAR INTERVALS, especially
if spill overs have occurred, re-
move the turntable, the turnta-
ble support and wipe the base of
the oven clean.
THIS OVEN IS DESIGNED to operate with the turnta-
ble in place.
DO NOT operate the microwave oven
when the turntable has been removed
for cleaning.
DISHWASHER SAFE:
TURNTABLE SUPPORT.
GLASS TURNTABLE.
DO NOT USE STEAM CLEANING APPLIANCES when
cleaning your microwave oven.
USE A SOFT AND DAMP CLOTH with mild detergent
to clean the interior surfaces, front and rear of
the door and the door opening.
DO NOT ALLOW GREASE or food particles to
build up around the door.
FOR STUBBORN STAINS, boil a cup of water in the
oven for 2 or 3 minutes. Steam will soften the
marks.
ADDING SOME LEMON JUICE to a cup of water, plac-
ing this on the turntable and boiling for a few
minutes can eliminate odors inside the oven.
THE GRILL ELEMENT does not need cleaning since
the intense heat will burn o any splashes, but
the ceiling beneath it may need regular clean-
ing. This should be done with a soft and damp
cloth with mild detergent.
If the Grill is not used regularly, it should be run
for 10 minutes a month to burn off any splash-
es, in order to reduce the risk of fire.
CRISP HANDLE
CAREFUL CLEANING:
THE CRISP-PLATE should be cleaned in mild, de-
tergent water. Heavily soiled areas can be
cleaned with a scouring cloth
and a mild cleanser.
ALWAYS let the crisp-plate
cool o before cleaning.
DO NOT immerse or rinse with water while
the crisp-plate is hot. Quick cooling may
damage it.
DO NOT USE STEEL-WOOL PADS. This will
scratch the surface.
THE OVEN should be cleaned regularly and
any food deposits removed.
19
GB
TROUBLE SHOOTING GUIDE
IF THE OVEN DOES NOT WORK, do not make a service
call until you have made the following checks:
The Turntable and turntable support is in
place.
The Plug is properly inserted in the wall
socket.
The Door is properly closed.
Check your Fuses and ensure that there is
power available.
Check that the oven has ample ventilation.
Wait for 10 minutes, then try to operate the
oven once more.
Open and then close the door before you
try again.
THIS IS TO AVOID unnecessary calls for which you
will be charged.
When calling for Service, please give the serial
number and type number of the oven (see Ser-
vice label). Consult your warranty booklet for
further advice.
IF THE MAINS CORD NEEDS REPLACING it should
be replaced by the original
mains cord, which is avail-
able via our service organi-
zation. The mains cord may
only be replaced by a trained
service technician.
SERVICE ONLY TO BE CARRIED OUT
BY A TRAINED SERVICE TECHNICIAN.
It is hazardous for anyone oth-
er than a trained person to carry
out any service or repair opera-
tion, which involves the remov-
al of any cover, which gives protec- tion
against exposure to microwave energy.
DO NOT REMOVE ANY COVER.
ENVIRONMENTAL HINTS
THE PACKING BOX may be fully re-
cycled as con rmed by the re-
cycling symbol. Follow lo-
cal disposal regulations. Keep
potentially hazardous pack-
aging (plastic bags, polysty-
rene etc.) out of the reach of chil-
dren.
THIS APPLIANCE is marked according to the Euro-
pean directive 2002/96/EC on Waste Electrical
and Electronic Equipment (WEEE). By ensuring
this product is disposed of correctly, you will
help prevent potential negative consequences
for the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product.
THE SYMBOL on the product, or on the docu-
ments accompanying the
product, indicates that this
appliance may not be treat-
ed as household waste. In-
stead it shall be handed over
to the applicable collection
point for the recycling of elec-
trical and electronic equip-
ment.
DISPOSAL must be carried out
in accordance with lo-
cal environmental regula-
tions for waste disposal.
FOR MORE DETAILED INFORMATION about treatment,
recovery and recycling of this product, please
contact your local city o ce, your household
waste disposal service or the shop where you
purchased the product.
BEFORE SCRAPPING, cut o the mains cord so that
the appliance cannot be connected to the
mains.
20 GB
GB
461965272943
IN ACCORDANCE WITH IEC 60705.
THE INTERNATIONAL ELECTROTECHNICAL COMMISSION has developed a standard for comparative testing of
heating performance of di erent microwave ovens. We recommend the following for this oven:
Whirlpool is a registered trademark of Whirlpool, USA
Test Amount Approx. time Power level Container
12.3.1 1000 G14 MIN 650 W PYREX 3.227
12. 3.2 475 G5 ½ MIN 800 W PYREX 3.827
12.3.3 900 G16 MIN 650 W PYREX 3.838
12. 3.4 1100 G20-22 MIN GRILL + 650 W PYREX 3.827
13.3 500 G 3 MIN 6 SEC JET DEFROST

Navigation menu
