User instrUctions
The clear™440 SerieS
c4-PA
ric
receiver-in-cAnAl
2 3
GENERAL
Your hearing aid
(To be filled out by the hearing care professional)
Date: _________________________________
Battery size: ___________________________
Ear-set: _______________________________
Closed ear-tip
Open ear-tip
Custom ear-tip
Ear-tip size: Left Right
Earwire size: Left Right
Contents
YOUR HEARING AID..................................... 2
THANK YOU............................................. 6
THE HEARING AID .......................................7
RIGHT/LEFT IDENTIFICATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
ACOUSTIC INDICATORS................................. 8
THE BATTERY .........................................9
INSERTING THE BATTERY............................ 9
LOW BATTERY INDICATION . . . . . . . . . . . . . . . . . . . . . . . . . . 11
TURNING THE HEARING AID ON AND OFF . . . . . . . . . . . . . . . .12
VOLUME ADJUSTMENT .................................13
LOST PARTNER ALARM.................................14
LISTENING PROGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
SWITCHING BETWEEN THE LISTENING PROGRAMS . . . . .17
USING A TELEPHONE...................................18
HEARING AID WITH A CLOSED OR OPEN EAR-TIP . . . . . . . . . . .19
RIGHT/LEFT IDENTIFICATION. . . . . . . . . . . . . . . . . . . . . . . . . . . 20
POSITIONING THE HEARING AID AND EAR-TIP . . . . . . . . . . . . 21
REMOVING THE HEARING AID AND EAR-TIP . . . . . . . . . . . . . 22
CLEANING ........................................... 23
THE HEARING AID..................................24
THE EAR-SET......................................24
THE EARWIRE .....................................24
THE EAR-TIP.......................................25
CHANGING THE EAR-SET ..............................27
EARWIRE AND EAR-TIP SIZE . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
THE ANCHOR.........................................28
HEARING AID WITH A CUSTOM EAR-TIP . . . . . . . . . . . . . . . . . . 32
RIGHT/LEFT IDENTIFICATION. . . . . . . . . . . . . . . . . . . . . . . . . . . 33
POSITIONING THE HEARING AID AND CUSTOM EAR-TIP. . . 34
REMOVING THE HEARING AID AND CUSTOM EAR-TIP . . . . . 35
CLEANING ...........................................36
THE HEARING AID.................................. 37
THE EAR-SET...................................... 37
THE EARWIRE ..................................... 37
THE CUSTOM EAR-TIP ..............................38
IF THE EARWIRE NEEDS TO BE REPLACED. . . . . . . . . . . . . . . 39
NANOCARE WAX GUARD...............................40
CHANGING THE NANOCARE WAX GUARD . . . . . . . . . . . . . . . .41
ACCESSORIES.........................................44
IN CASE OF MALFUNCTION ............................. 45
CARING FOR YOUR HEARING AID . . . . . . . . . . . . . . . . . . . . . . . . 47
GOOD ADVICE AND WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . 49
REGULATORY INFORMATION............................ 53
4 5
GENERAL
6 7
GENERAL
thank You...
...for choosing a Widex hearing aid.
Your hearing aid is designed with high-quality sound,
ease, comfort and freedom of choice in mind.
We hope you will be pleased with your new Widex
hearing aid.
All illustrations in this booklet
show a right-ear hearing aid.
the hearing aid
The illustration below shows the hearing aid with
earwire.
Microphoneopenings
Onofffunction
Nailgrip
Earwire
Receiver
LED
IMPORTANT
This booklet contains important information and instructions.
Please read this booklet carefully before you start using the hear-
ing aid.
Your hearing aid, ear-set and accessories may not look exactly
as illustrated in this booklet. We also reserve the right to make
any changes considered necessary.
1.
2.
3.
5.
4.
6.
Below, your hearing care professional can tick the
ear-piece solution chosen for you.
Closed ear-tip Open ear-tip Custom ear-tip
8 9
GENERAL
RIGHT/LEFT IDENTIFICATION
The arrow shows the position of the
identification mark (red mark = right
and blue mark = left).
ACOUSTIC INDICATORS
The hearing aid may be set to produce a signal to in-
dicate the use of certain functions. The signal may be
a spoken message or tones adjusted by the hearing
care professional in consultation with you. The signal
can also be deactivated.
Adjusting volume Tone* Off
Confirming program
button use
Clicking
sound Off
Changing program Message Tones Off
Starting up the hearing aid Message Tone Off
Warning about low battery Message 4 tones Off
Warning about lost partner Message Off
Service reminder Message Off
* bold indicates standard setting
THE BATTERY
We recommend zinc-air batteries. Use a size 10 bat-
tery for the hearing aid.
To obtain replacement batteries, please consult your
hearing care professional. It is important to take note
of the expiry date and the recommendations regard-
ing disposal of used batteries on the battery pack.
INSERTING THE BATTERY
Before inserting a new battery into the
hearing aid, remember to remove the ad-
hesive tab. Once the tab has been re-
moved, the battery will start functioning
after a few seconds. Do not use batteries
on which there is a sticky residue from
the tab or other unwanted substance.
Use the nail grip to gently swing the bat-
tery drawer open. Do not press the draw-
er beyond the open position.
10 11
GENERAL
Place the battery in the drawer as illustrated, so that
the plus (+) sign on the battery is facing towards you
when you hold the hearing aid as shown. You can use
the battery magnet provided to steer the battery
into place.
If the battery drawer does not close easily, the bat-
tery is incorrectly inserted.
When changing battery, it is a good idea to hold the
hearing aid over a table.
LOW BATTERY INDICATION
An acoustic indicator will sound when the battery is
nearly exhausted, unless this function has been disa-
bled (see page 8). Exactly how long the hearing aid
will function after the low battery indication varies
from one case to another. We recommend that you
always have a spare battery with you.
Never leave an exhausted battery in the hearing aid.
Exhausted batteries may leak, damaging the hearing
aid.
IMPORTANT
Your hearing aid may stop functioning, for instance if the battery
is exhausted. You should be aware of this possibility, in particular
when you are in traffic or are otherwise dependent on warning
signals.
12 13
GENERAL
TURNING THE HEARING AID ON AND OFF
The battery drawer of the hearing aid also functions
as the on/off switch.
Close the battery drawer to turn on
the hearing aid. An acoustic indicator
will indicate that the hearing aid has
been switched on unless this function
has been disabled.
Open the battery drawer to turn off
the hearing aid.
Please remember to turn off the hear-
ing aid when it is not in use. Remove
the battery if the hearing aid will not
be used for several days.
VOLUME ADJUSTMENT
The hearing aid volume is adjusted automatically in
accordance with your sound environment.
Ordinarily, you cannot fine tune the volume in your
hearing aid. However, if you have a remote control,
the option of fine tuning becomes available.
Any volume adjustment via the remote control will
affect both hearing aids.
For any adjustment of the steps in which volume in-
creases or decreases, consult your hearing care pro-
fessional.
If you have a remote control, please also refer to the
user instructions for this.
IMPORTANT
If the volume in the hearing aid is generally too loud or too weak,
or the reproduced sounds are distorted, or if you would like any
further information, consult your hearing care professional.
14 15
GENERAL
LOST PARTNER ALARM
(Note: Only applicable if this feature has been acti-
vated by your hearing care professional).
If one of your hearing aids falls off your ear, and/or
the battery is exhausted, a spoken message will
sound in the other hearing aid after 8 seconds and a
diode will flash on both hearing aids.
When the lost hearing aid is repositioned, and/or the
battery is exchanged, the diodes stop flashing.
For use with mobile phones, see page 51.
LISTENING PROGRAMS
By default, your hearing aid has one listening pro-
gram (Master).
If you have a remote control, five of the following
programs, including Master, can be made available,
plus the special Zen program called Zen+. Please also
refer to the user instructions for your remote control.
Master Standard
Music For listening to music
TV For listening to the TV
Comfort Attenuates background noise
Reverse focus Focus on sounds from behind
Audibility Extender Makes high-frequency sounds
audible
Zen Randomly plays harmonic tones.
Contains one style
Compound programs
The Master program in one ear
and Zen, Audibility Extender or
Reverse focus in the other
Zen+ Special Zen program with up to
three different Zen styles.
Accessed via a long press (two
sec.) on the remote control
program toggle key
16 17
GENERAL
If your needs change over time, the combination of
listening programs can be altered.
The Zen program may be used with amplification so
that both the surrounding sounds and the Zen tones
are heard together. Or, it may be used alone (without
amplification) in quiet when you are not required to
hear surrounding sounds.
The duration of the Zen play time can be set by your
hearing care professional according to your needs.
IMPORTANT
Use of the different Zen programs may interfere with hearing sur-
rounding sounds including speech. The programs should not be
used when hearing such sounds is important. Switch the hearing
aid to a non-Zen program in those situations.
SWITCHING BETWEEN THE LISTENING PROGRAMS
Each time you change program via a remote control,
an acoustic indicator will sound unless this function
has been disabled.
Program Messageoroneshortbeep
Program Messageortwoshortbeeps
Program Messageorthreeshortbeeps
Program Messageoronelongandoneshort
beep
Program Messageoronelongandtwoshort
beeps
Zen Messageortone
If you change program, the change will apply to both
your hearing aids.
18 19
HEARING AID WITH A CLOSED OR OPEN EAR-TIP
USING A TELEPHONE
When using a telephone, we
recommend that you hold the
telephone against your head
at an angle above your ear,
rather than directly against the
ear. If the sound is not optimal,
try moving the telephone ear-
piece to a slightly different po-
sition.
hearing aid with a Closed or
open ear-tip
Earwire
Anchor(whereapplicable)
Receiver
NanoCarewaxguard
Closedear-tip
5a. Sound bore
5b. Vent
Openear-tip
2.
3.
1.
4.
6.
5. 5a.
5b.
20 21
HEARING AID WITH A CLOSED OR OPEN EAR-TIP
RIGHT/LEFT IDENTIFICATION
The earwire is available in different
lengths for the right and left ear, respec-
tively. The individual size is printed on
the ear-set (see arrow). Red print indi-
cates that it is for the right ear, and blue
print that it is for the left ear.
POSITIONING THE HEARING AID AND EAR-TIP
Place the hearing aid behind the ear, so that the ear-
wire rests comfortably on the ear, close to your head.
Insert the ear-tip into the ear canal while holding the
lower part of the earwire.
IMPORTANT
The anchor should always be used with the hearing aid with an
open ear-tip. If the hearing aid is not secured by the anchor, it
may fall off your ear and be lost. With a closed ear-tip, the anchor
should only be used if this is necessary to further secure the ear-
set/hearing aid.
Remember to check at regular intervals that the hearing aid and
the ear-set are positioned correctly.
22 23
HEARING AID WITH A CLOSED OR OPEN EAR-TIP
REMOVING THE HEARING AID AND EAR-TIP
Remove the hearing aid from its position behind the
ear.
Carefully pull the ear-tip out of the ear canal, while
holding the lower part of the earwire.
CLEANING
The following cleaning accessories are available for
the hearing aid and ear-set.
Cloth
Longwaxremovingtool(forclosedear-tiponly)
Shortwaxremovingtool(forclosedear-tiponly)
Brush
Contact your hearing care professional if you need
additional supplies of cleaning accessories.
2. 3. 4.1.
24 25
HEARING AID WITH A CLOSED OR OPEN EAR-TIP
THE HEARING AID
Clean the hearing aid after use
with the cloth provided. Never
use water or cleaning solutions
to clean the hearing aid.
When the hearing aid is not in
use, the battery drawer should
be left open, so as to ventilate
the hearing aid and allow it to
dry.
THE EAR-SET
Make sure that your ear-set is clean and free of ear-
wax, moisture and the like. Never use alcohol or oth-
er cleaning solutions to clean the ear-set.
THE EARWIRE
Clean the earwire with the cloth
after use. Never use water or
cleaning solutions to clean the
earwire.
THE EAR-TIP
Closed ear-tip: First change the
NanoCare wax guard (see pages
40-43), then use the wax guard
holder to push the receiver out of
the ear-tip.
Clean the vent with the long wax
removing tool (no. 2), as illustrat-
ed.
Clean the sound bore with the
short wax removing tool (no. 3),
as illustrated.
If necessary, the closed or open ear-tip
can be rinsed thoroughly in lukewarm
water, when disconnected from the rest
of the ear-set. Allow it to dry overnight.
Never use cleaning solutions to clean the
ear-tip.
IMPORTANT
The receiver must never come into contact with water.
26 27
HEARING AID WITH A CLOSED OR OPEN EAR-TIP
If dirt has gathered on the receiver, use the cloth to
remove it.
Place the new/clean ear-tip on the ear-set. It is very
important to ensure that the ear-tip is firmly secured.
Closed ear-tip
The right/left identification mark should still be visi-
ble. See arrow.
Open ear-tip
CHANGING THE EAR-SET
The ear-set should be changed as required. The life
of an ear-set is individual. Consult your hearing care
professional for advice on how often you should
change your ear-set.
For further supplies of ear-sets, or if the ear-tip size
no longer fits your ear, contact your hearing care
professional.
28 29
HEARING AID WITH A CLOSED OR OPEN EAR-TIP
EARWIRE AND EAR-TIP SIZE
The ear-set must fit your ear exactly in order to en-
sure a good and comfortable fit.
Your hearing care professional will choose the cor-
rect earwire length and ear-tip size, and help you to
trim the anchor if your ear-set solution requires an
anchor.
On page 2 of this booklet your hearing care profes-
sional can write down the sizes selected for you.
THE ANCHOR
The anchor is supplied separately
from the rest of the ear-set and can
be used in different ways. Firstly,
we show how the anchor can be
used without prior trimming:
Pull the pointed end of the an-
chor through the upper hole on
the receiver located at the end
of the earwire. The angled grip
should be pointing towards the
hearing aid.
Continue pulling until the anchor
is stopped by the grip at the end.
Your ear-set is now ready for use and
is positioned so that it rests comfort-
ably in your ear.
30 31
HEARING AID WITH A CLOSED OR OPEN EAR-TIP
The anchor can also be trimmed to fit your ear:
Pull the pointed end of the an-
chor through the upper hole on
the receiver located at the end
of the earwire. The angled grip
should be pointing towards the
hearing aid.
Continue pulling until the an-
chor is stopped by the grip at
the end. Now turn the ear-set
around.
Then guide the pointed end of
the anchor through the lower
hole to form a loop.
When the loop is the correct
size, cut any excess off, leaving
only the loop.
The anchor loop has the correct size when it sup-
ports the position of the ear-tip in the ear canal, and
the ear-set sits securely in and on the ear.
Take great care to cut off all the excess
so that the end of the anchor loop is
flush with the small hole and there are
no sharp edges.
Use the tip of your finger to check for sharp edges. If
part of the anchor sticks out through the hole, creat-
ing an uneven surface, this may cause irritation of the
ear.
32 33
HEARING AID WITH A CUSTOM EAR-TIP
hearing aid with a Custom
ear-tip
Earwire
Receiver(attheendoftheearwireinsidethe
customear-tip)
Customear-tipwithextractioncord
NanoCarewaxguard
Vent(optional)
1.
3.
4.
5. 2.
IMPORTANT
Never attempt to disconnect the earwire from the custom ear-tip.
RIGHT/LEFT IDENTIFICATION
The earwire is available in different lengths for the
right and left ear, respectively. The individual size is
printed on the ear-set. Red print indicates that it is
for the right ear, and blue print that it is for the left
ear.
The custom ear-tip has ”Widex” printed
on it (see arrow). Red print indicates that
it is for the right ear, and blue print that it
is for the left ear.
34 35
HEARING AID WITH A CUSTOM EAR-TIP
POSITIONING THE HEARING AID AND CUSTOM
EAR-TIP
Insert the custom ear-tip into the ear canal while
holding the lower part of the earwire. It may also
help to pull the outer ear backwards and upwards
with the opposite hand.
Place the hearing aid behind the ear, so that the
hearing aid and earwire rest comfortably on the ear,
close to your head.
REMOVING THE HEARING AID AND CUSTOM
EAR-TIP
Remove the hearing aid from its position behind the
ear.
Take hold of the extraction cord and carefully pull the
custom ear-tip out of the ear canal.
IMPORTANT
Do not pull the earwire to remove your hearing aid. Use the ex-
traction cord.
36 37
HEARING AID WITH A CUSTOM EAR-TIP
CLEANING
The following cleaning accessories are available for
the hearing aid and ear-set.
Cloth
Brush
Waxremovingtool
Contact your hearing care professional if you need
additional supplies of cleaning accessories.
3.
2.1.
THE HEARING AID
Clean the hearing aid after use
with the cloth provided. Never
use water or cleaning solutions
to clean the hearing aid.
When the hearing aid is not in
use, the battery drawer should
be left open, so as to ventilate
the hearing aid and allow it to
dry.
THE EAR-SET
Make sure that your ear-set is clean and free of ear-
wax, moisture or the like. Never use alcohol or other
cleaning solutions to clean the ear-set.
THE EARWIRE
Clean the earwire with the
cloth after use. Never use wa-
ter or cleaning solutions to
clean the earwire.
38 39
HEARING AID WITH A CUSTOM EAR-TIP
THE CUSTOM EAR-TIP
If dirt has gathered on the
custom ear-tip, use the small
brush or cloth to remove it.
Do not clean the wax guard.
If it is plugged, change it
(see pages 40-43).
If your ear-tip is provided
with a vent, use the wax re-
moving tool to clean the
vent.
IF THE EARWIRE NEEDS TO BE REPLACED
Changing the earwire for the custom ear-tip requires
special tools and experience. We recommend that
you consult your hearing care professional when the
earwire needs replacement. Do not attempt to do it
yourself.
If the custom ear-tip no longer fits your ear, contact
your hearing care professional.
IMPORTANT
The custom ear-tip, in which the receiver is placed, must never
come into contact with water.
40 41
GENERAL
nanoCare wax guard
The NanoCare wax guard helps to protect the hear-
ing aid against earwax. Always use NanoCare wax
guards with your hearing aid. Otherwise the warran-
ty for your hearing aid will be void.
The NanoCare wax guard system consists of the fol-
lowing parts:
Holder
Removalhook
Waxguard
3.
2.
1.
CHANGING THE NANOCARE WAX GUARD
See the illustrations for your ear-tip type
Hearing aid with a closed ear-tip
The wax guard can be changed with or without the
ear-tip being attached to the earwire.
Hearing aid with a custom ear-tip
Do NOT remove the ear-tip from the earwire.
Hearing aid with an open ear-tip
Remove the ear-tip from the earwire.
1. Insert the removal hook into the used wax guard
placed in the sound outlet.
2. Pull the wax guard straight out.
Closed ear-tip
(Also applies to the custom ear-tip)
Open ear-tip
1. 2.
1. 2.
IMPORTANT
Do not attempt to clean or reuse a wax guard. This could damage
your hearing aid and/or cause the wax guard to become dis-
lodged in your ear.
42 43
GENERAL
Now turn the holder around so
that the used wax guard is away
from the receiver and the new one
is in position to be inserted.
3. Insert the holder into the opening of the sound
outlet and gently press the wax guard onto the
receiver.
4. Pull the holder straight out. The new wax guard
will automatically detach from the holder and
remain in place.
Closed ear-tip
(Also applies to the custom ear-tip)
Open ear-tip
4.3.
4.3.
Discard the holder with the
used wax guard.
The frequency with which the NanoCare wax guard
should be changed varies from one individual to an-
other.
If you have any questions regarding your NanoCare
wax guard, please contact your hearing care profes-
sional.
IMPORTANT
If the wax guard fits loosely, discard it and insert another. If the
wax guard becomes dislodged while the ear-tip is placed in the
ear canal, please contact your physician. Do not try to remove the
wax guard from your ear canal yourself.
44 45
GENERAL
aCCessories
A variety of assistive listening devices are available
for your hearing aid.
For help in determining whether you could benefit
from a remote control or other accessories, please
consult your hearing care professional.
in Case of malfunCtion
Problem Potential cause Solution
The hearing
aid is dead
The hearing aid is
not turned on
Make sure the battery
drawer is closed
The earwire is
broken
Contact your hearing
care professional
The battery is dead
or does not work
Insert a new battery in
the hearing aid
The NanoCare wax
guard is blocked
Change the wax guard
The hearing
aid volume is
not powerful
enough
The battery is nearly
exhausted
Insert a new battery in
the hearing aid
The NanoCare wax
guard is blocked
Change the wax guard
Your ear is blocked
by earwax
Contact your ENT
doctor/physician
Your hearing may
have changed
Contact your hearing
care professional
46 47
GENERAL
Problem Potential cause Solution
The hearing
aid whistles
continuously
Your ear is blocked
by earwax
Contact your ENT
doctor/physician
The earwire is yellow
and stiff
Contact your hearing
care professional
The ear-tip is not
correctly placed in
your ear canal
Take the ear-tip out and
reinsert it
The ear-tip fit is too
loose
Contact your hearing
care professional
The receiver is not
adequately secured
in the ear-tip
Closed and open ear-
tip: Replace the ear-tip.
If the problem persists,
contact your hearing
care professional
Custom ear-tip:
Contact your hearing
care professional
The receiver is
inserted in the
wrong hole
Closed ear-tip: Remove
the ear-tip and insert
the receiver as
illustrated on page 26.
Caring for Your hearing aid
The hearing aid is a valuable object and should be
treated with care. Here are some things you can do
to prolong the life of your hearing aid:
• Turn off your hearing aid when it is not in use. Re-
move the battery if the hearing aid will not be used
for several days.
• When the hearing aid is not in use, keep it in its
case in a cool, dry location out of reach of children
and pets.
• Do not expose the hearing aid to extreme temper-
atures or high humidity.
• Do not wear your hearing aid while in the shower
or swimming, or when using a hair dryer, perfume
or other sprays.
• In environments with high humidity, a Widex dry-
ing kit may be used daily to reduce the amount of
moisture inside the hearing aid. See the instruc-
tions enclosed with the Widex drying kit.
48 49
GENERAL
• Never try to open or repair the hearing aid your-
self.
• Do not wear your hearing aid during X-rays, scans
or radiation treatments. Other types of radiation,
such as that in a microwave oven, can also damage
your hearing aid. Radiation from, for example,
room surveillance equipment, burglar alarms and
mobile phones is weaker and will not damage the
hearing aid.
• Widex hearing aids are not certified for use in
mines or other areas with explosive gases.
good adviCe and warnings
Hearing aids and batteries can be dangerous if
swal lowed or used improperly. Swallowing or
improper use can result in severe injury or even
fatalities. In case of ingestion, contact a physician
immediately.
• Keep hearing aids and their parts, accessories and
batteries out of reach of children and anyone else
who might swallow such items or otherwise cause
injury to themselves. Do not change batteries in
front of them and do not let them see where you
keep your battery supply. Discard used batteries
carefully.
• Batteries are very small and can easily be mistaken
for pills or the like. Never put a battery or hearing
aid in your mouth for any reason as you may risk
swallowing it.
CAUTION
Risk of explosion if battery is replaced by an incorrect type or re-
charged. Dispose of used batteries according to the instructions.
50 51
GENERAL
• Never allow others to wear your hearing aid, as this
could cause permanent damage to their hear ing.
• The hearing aid will not restore normal hearing but
can help you to make the best possible use of your
remaining hearing ability. However, you should be
aware that it takes time to get used to a new hear-
ing aid and new sounds.
• When selecting a listening program, please re-
member that there are situations in which it is par-
ticularly important to be able to hear the surround-
ing sounds (e.g. traffic, warning signals).
• The use of hearing aids increases the risk of accu-
mulation of earwax. Contact your physician/ENT
doctor if you suspect that a plug of earwax has ac-
cumulated in your ear. Earwax may not only reduce
your own hearing but also the effect of the hearing
aid considerably. It is a good idea to ask your phy-
sician to clean your ears a couple of times a year.
• The hearing aid is made of modern non-allergenic
materials. Nonetheless, in rare cases skin irritation
may occur. If you notice skin irritation in or around
your ear or ear canal, contact your hearing care
professional.
• Be aware that the use of any type of hearing aid
may involve a slightly increased risk of infection in
the ear canal. An infection can arise as a result of
inadequate ventilation of the ear. We therefore rec-
ommend that you remove the hearing aid and ear-
set from your ear at night to allow the ear canal to
be ventilated. Make sure that you clean and inspect
your hearing aid and ear-set as required. If an in-
fection occurs, you should seek medical attention
and contact your hearing care professional for ad-
vice on how to disinfect the various hearing aid
parts. Do not under any circumstances use alcohol,
chlorine or similar substances.
• Your hearing aid uses a built-in transceiver for co-
ordination between the hearing aids. The magnetic
field strength of the transceiver is very low.
• Your hearing aid has been tested for interference
according to international standards. Nevertheless,
it is possible that unforeseen interference may oc-
cur in the hearing aid due to electromagnetic radi-
ation from other products such as alarm systems
and mobile phones.
52 53
GENERAL
• Although your hearing aid has been designed to
comply with the most stringent international elec-
tromagnetic compatibility standards, the possibili-
ty cannot be excluded that it may cause interfer-
ence with other equipment, such as medical devic-
es.
regulatorY information
Hereby, Widex A/S declares that this C4-PA is in
compliance with the essential requirements and oth-
er relevant provisions of Directive 1999/5/EC.
A copy of the Declaration of Conformity can be found
at: http://www.widex.com
WIDEX • 3540 Lynge
Denmark • www.widex.com
54 55
GENERAL
Federal Communications Commission and Industry
Canada Statement
FCC ID: TTY-C4PA
IC: 5676B-C4PA
This device complies with part 15 of the FCC Rules and
with RSS-210 of Industry Canada. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired opera-
tion.
NOTE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment gene-
rates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instruc-
tions, may cause harmful interference to radio communi-
cations. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct
the interference by one or more of the following mea-
sures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and
receiver.
— Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV
technician for help.
NOTE:
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This
transmitter must not be co-located or operating in con-
junction with any other antenna or transmitter.
This equipment complies with the Industry Canada RF
radiation exposure limits set forth for an uncontrolled
environment as per IC RSS-102 Issue 3.
Changes or modifications to the equipment not expressly
approved by Widex could void the user’s authority to op-
erate the equipment.
56 57
GENERAL
Hearing aids, accessories and batteries
should not be disposed of with normal
household waste. Please consult your na-
tional Widex distributor for advice on
how to dispose of these items.
58 59
GENERAL
¡9 514 0134 001g¤ Printed by HTO / 02-10
9 514 0134 001 #01
¡#01v¤
WIDEX
•
3540 Lynge
Denmark •
www.widex.com
