User Manual

HOW IT WORKS
ALARM #1 has a motion sensor and a light &
sound alarm. This alarm also arms the
other two alarms via wireless signals.
ALARM #2 has a motion sensor, a targeting
lazer and a loud alarm siren. This alarm
sleeps until armed by #1. It will not operate
until #1 has been set off.
ALARM #3 has a motion sensor and a dual
dart launcher. This alarm also sleeps until
armed by #1. It will not operate until #1 has
been set off.
This unique wireless link system protects
your valuables against enemy spies. If
someone enters your room, the alarms wont
go off unless they mess with your stuff and
trigger Alarm #1. They can get in, but they
cant get out!
SETTING UP THE ALARMS
Fully extend the ANTENNAS on all 3 alarms.
Antennas should be pointing straight up for
best results.
1. Set Alarm #1 by placing it on the object
you want to protect. Or, aim it with the
LENS pointing at the objects or area you
want to protect. When movement is
detected, flashing light & sound will go off
and other two alarms will be armed by
wireless signal.
2. Place Alarm #2 to stun the intruder with
its loud siren as he tries to leave. Point the
LENS across the path he will take. After it
is armed, the TARGETING LAZER will be
activated and you will see a red spot on
the wall in the direction where it is
pointed
.
3. Insert a DART into each LAUNCH PORT
on Alarm #3 until it locks into place. Aim
LENS across the path the intruder is likely
to take when fleeing the scene after other
alarms go off. Swivel launcher and tilt up
or down to aim darts. Do not aim at
face level.
4. Turn on POWER SWITCHES of Alarms
#2 and #3 first, and Alarm #1 last. Alarm
#1 has a built-in delay of a few seconds
so you can safely exit the room without
setting the system off.
Ages 6 and Up
70163
Requires 7 AAA (LR03)
batteries, not included.
Important: Please save this instruction sheet.
It contains valuable product information.
TM
TRI-LINK ALARM SYSTEM 70163-4000 PR 3/07
IF YOU HAVE ANY QUESTIONS, PLEASE CONTACT US AT
1-800-247-6570
WWW.WILDPLANET.COM/HELP
Wild Planet Entertainment, Inc., P.O. Box 194087
San Francisco, CA 94119-4087
TM
© 2006 Wild Planet Entertainment, Inc., San Francisco,
CA 94104, USA. All rights reserved. PRINTED IN CHINA.
Product colors and specifications subject to change.
Tri-Link Alarm System
3 Linked Hi-Tech Alarms
TM
ADULTS: INSTALLING BATTERIES
1. Locate battery door on bottom of each alarm.
2. Use small Philips screwdriver to loosen screw, remove
battery door.
3. Install 3 AAA (LR03) batteries in dart launcher, 2 AAA
(LR03) batteries in each of other two alarms.
4. Replace doors, tighten screws.
Important: Observe battery polarity (direction,
+ and )
BATTERY SAFETY
1. Only adults should install and replace batteries.
2. Do not recharge non-rechargeable batteries.
3. Remove dead or exhausted batteries.
4.
Insert batteries correctly. Match positive and
negative signs.
5. The supply terminals are not to be short circuited.
6. Do not use rechargeable batteries.
7. Do not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
8. Do not mix old and new batteries.
9. Only the batteries of the same or equivalent type
recommended to be used.
10. Do not dispose of batteries in a fire; they may explode.
11. Dispose of batteries safely.
Alarms #1 and #2 Dart launcher
#1 MOTION SENSOR #2 LAZER SIREN #3 DART LAUNCHER
Tip: As the intruder
passes Alarm #3, there is
a short delay before the
darts fire. Swivel and tilt
the launcher so that the
darts will launch ahead of
the intruder. You can test
this yourself to see how
far you need to “lead”
your target in this way.
CAUTION: Do not aim at eyes or face. To avoid injury: use only darts designed for this
product. Do not modify darts or launcher.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC ID N3ETRILINK70163
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Power switch
OFF / ON
Pull out grooved ring around Lenses
to narrow each sensors field and
make it less sensitive to movement.
Push in to widen sensors field and
make it more sensitive.
Swivel base
Power switch
Load darts into
launch ports
Lens
Power
switch
Swivel (side-to-side)
Tilt (up/down)
Antenna
Antenna
Antenna
Targeting lazer
Flashing
light
TROUBLESHOOTING
If alarms fail to go off, check that nothing is block-
ing the sensor lenses. The sensor will best detect
movement five feet directly in front of the lens.
Direct sunlight may set off the alarms. Dont face
alarms into very bright light. Also, pulling out
grooved rings will reduce their sensitivity to light.
Make sure all three antennas are fully extended and
pointing straight up.
Remember, Alarms #2 and #3 will not go off unless
Alarm #1 has been set off first.
If alarms still do not go off, replace batteries.
CUSTOMIZE YOUR SYSTEM!
Alarms #2 and #3 are interchangeable. You can place the
Lazer Siren last to stop ’em in their tracks until you get there
to make the bust!
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio/TV technician for help.
