Willis Electric AL69W Laser Projector Red & Green & Blue(With Remote) User Manual 69 W Instruction Manual
Willis Electric Co., Ltd. Laser Projector Red & Green & Blue(With Remote) 69 W Instruction Manual
Users Manual
REMOTE CONTROL
Remote Control Instructions
1. Remove insulating tape from the battery compartment before use.
This remote is RF and receiving distance allowance is 8 meters.
Battery installation:
1. Slide battery cover o.
2. Insert a "CR2025" (3 volt) battery.
3. is show mode.
5. Mode Switchover: Steady, ash.
Motor Speed Down.
Motor Speed Up.
2. is to turn on/o.
6. are buttons to control light moving mode.
There are four mode options:
STATIC, SLOW, FASTER and FASTEST.
Press the button , show light laser projector will ash thrice
and timer function is canceled.
7. Press the button , show light laser projector will ash thrice.
Reset Timer Function: 2h 4h 6h 8h
1. Connect the power adapter to the laser light projector.
The adapter input voltage is AC120V.
2 . Press the button to switch mode/turn on
3. Press and hold the button to turn o.
4. Built-in timer function: 2h / 4h / 6h / 8h
. Red
. Green
. Blue
. White
. Yellow
. Purple
. Azure
WARNING: This is not a toy and is not intended for use by children.
(A) Do not dispose of the battery in re as the battery may leak
and explode.
(B) Do not mix old and new batteries and do not mix alkaline,
standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.
(C) Exhausted batteries are to be removed from the product.
(D) Dispose of battery properly by following directions on battery.
(E) Use CR2025 battery only. Use of other batteries may damage
remote control.
(F) Safe for indoor use.
(G) Do not expose the Remote Control to moisture.
If the remote control does not work, check battery.
REMOTE CONTROL
LASER PROJECTOR FUNCTION
Button Mode
1. When turn on the laser and short press the button to
switchover to cycle the 7 colors as bellow:
2. Press and hold the button to turn o under working
status.
3. Short press the button to turn on under power o
function, would recover to the mode before powor
o stake.
Safety Attention
1. Turn o 30 minutes after working 6 hours to last the lifetime
of product.
2. This product is mainly used for outdoor with waterproof Ip65.
It has excellent radiating ease. Put it far away from the ammable
objects or liquids.
3. Please use show light laser projector power adapter to support the
light. If you need to change a new adapter, please check the
parameter of our adapter before you buy a new one.
SAFETY INSTRUCTIONS
CAUTION
1. Danger-laser radiation when open.
2. Avoid direct exposure to beam.
3. Avoid direct eye exposure.
4. Laser radiation-do not stare into beam or view directly with
optical instruments.
5. The use of optical instruments with this product will increase
eye hazard.
6. Use of controls or adjustments or performance of procedures
other than those specied herein may result in hazardous
radiation exposure.
IMPORTANT!
Do not point the show light laser projector to the airplane or up
in the sky.
FEDERAL COMMUNICATIONS COMMISSION (FCC)
STATEMENT
FCC Caution: Changes or modications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures: - Reorient or
relocate the receiving antenna. - Increase the separation between the
equipment and receiver. - Connect the equipment into an outlet on
a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
Ground Stake
Mode/ Power
Laser hole
Holder
PRODUCT SPECIFICATION
Laser Classication: Class IIIa
Laser Wavelength: Red 635 nm, green 532 nm
Power: UL & CUL Adapter 12V, 2A
Operation: Indoor/Outdoor
Operating Temperature: -15°F to 90°F
（-26°C to 32°C）
Projection Coverage: 30 ft x 30 ft
Dimensions: 22.5 in x 5.75 in x 5.75 in
Cord Length: 3 ft
Warranty: One Year Limited
1034048
#
LASER RADIATION,
AVOID DIRECT EYE EXPOSURE,
DO NOT STARE INTO BEAM OR VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS,
CALSS IIIa LASER PRODUCT
MAX OUTPUT<5 mW
WAVELENGTHS 532-650 NM
Please only use manufacture
provided power supply
Built-in timer function:
6h ON / 18h OFF
Version: 2018 Made in china
Multi-color laser light
Seven color with movement
Instruction Manual
MADE IN CHINA
White Color Color
White Color Color
4. the buttons to change the color.
the button to control the white laser.
switching color mode.
automatic color mode circulation
White
White
Color
Color
Color
Color
Show
Show
Show
11
www.ishowtree.com
Scan & See Me!
- French:
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitationestautorisée aux deux conditions
suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi
le brouillageest susceptible d'encompromettre le fonctionnement.
