1. Users Manual
2. User Manual

User Manual

ENGLISH FRANÇAIS

Need help? www.weboost.com Customer Support 866-294-1660

Mon. - Fri. 6 am to 7 pm, Sat. & Sun. 8 am to 5 pm (MST)

Drive 4G-X™

Cellular Signal Booster

ENGLISH

Need help? www.weboost.com Customer Support 866-294-1660

Mon. - Fri. 6 am to 7 pm, Sat. & Sun. 8 am to 5 pm (MST)

Contents

Package Contents .......................................................3

Optional Accessories ....................................................3

Before Getting Started ...................................................3

Install .................................................................3

Understanding the Lights .................................................5

Alternate Antenna Installations ............................................5

Additional FAQ ..........................................................7

Safety Guidelines .......................................................9

Signal Booster Specifications ............................................11

Warranty .......................................................Back Cover

Installation Instructions for the Following weBoost Signal Boosters:

Drive 4G-XTM SmarTech ® Signal Booster

! !

THE ALUMINUM CASING OF YOUR SIGNAL BOOSTER

WILL ADJUST TO THE TEMPERATURE OF ITS

ENVIRONMENT, BUT IS DESIGNED TO PROTECT THE

SIGNAL BOOSTER TECHNOLOGY. FOR EXAMPLE, IN THE SUMMER,

THE SIGNAL BOOSTER CASE MAY BE AS HOT AS 150 DEGREES

INSIDE YOUR VEHICLE. THESE HIGH TEMPERATURES WILL NOT

DAMAGE THE SIGNAL BOOSTER, NOR DO THEY POSE A FIRE

RISK TO THE VEHICLE. AGAIN, BE SURE TO PLACE YOUR SIGNAL

BOOSTER IN A LOCATION WITH ADEQUATE VENTILATION AND AWAY

FROM DIRECT SUNLIGHT OR MOISTURE.

THE Drive 4G-X SIGNAL BOOSTER

MAY REMAIN ON, IN VEHICLES

WHOSE 12V DC POWER SOURCES

DO NOT AUTOMATICALLY SHUTDOWN WHEN THE

VEHICLE IS TURNED OFF. THIS COULD RESULT IN

DISCHARGING THE VEHICLES BATTERY IN ONE

TO TWO DAYS.

ENGLISH

Need help? www.weboost.com Customer Support 866-294-1660

Mon. - Fri. 6 am to 7 pm, Sat. & Sun. 8 am to 5 pm (MST)

Before Getting Started

Before you install your Drive 4G-X Booster

and start enjoying improved cellular

reception please do the following:

1. Read through all the installation

steps. This will help you know what to

expect from start to nish.

2. Watch the YouTube video

demonstrating the Drive 4G-X Signal

Boost installation at:

weboost.com/us/drive4G-Xvideo.

3. Familiarize yourself with all materials

in your product package. This will

allow you to know which pieces are

referenced in the instructions.

Install

You can install your Drive 4G-X Signal

Booster in your vehicle using the following

steps. NOTE: Before completing your

installation, create a “soft” installation by

putting the components of your Drive 4G-X

Signal Booster in place and testing the

operation before mounting equipment.

1. Install the Outside Antenna. Select a

location on top of the car that is:

• Near the center of the vehicle’s roof.

• At least 12 inches from any other

antennas.

• Free of obstructions.

• At least 6 inches from any windows

(including sunroofs).

• At least 8 inches from any people.

The Outside Antenna must be

installed vertically on a metallic

surface.

Kit Configuration

weBoost manufactures a wide variety of antennas to help you customize your Signal Booster for your specific application. See your dealer or

visit www.weboost.com for more information.

Package Contents

Power Supply

6V/2A

(859913)

NMO Mount

Antenna

(311112-17410)

Slim Low Profile

w/10’ RG174

(301152)

Drive 4G-XTM

Signal Booster

4G Marine

Antenna

(304416/304420)

Mini-Mag

Antenna

(301126)

4G Trucker

Antenna

Mirror Mount

(304414)

Optional Antenna Kits

4G Trucker

Antenna

Spring Mount

(304415)

ENGLISH

Need help? www.weboost.com Customer Support 866-294-1660

Mon. - Fri. 6 am to 7 pm, Sat. & Sun. 8 am to 5 pm (MST)

Vehicle Roof

2. Run the Outside Antenna cable into

the car. The cable is strong enough

that it may be shut in most vehicle

doors without damaging the cable.

For a cleaner look, carefully pull down

the door seal, run the cable under

the seal, and push the seal back into

place. This method reduces wear

on the cable as the door opens and

closes.

3. Install the Low-Prole Inside Antenna.

• Identify a place on the right side of

the driver’s seat to mount the Inside

Antenna. The location should be at

least 18 inches but no more than

36 inches from where the cellular

device will be used.

• Install the Inside Antenna at the

same angle as the cell phone when

held in use or near the laptop’s

cellular data card to maximize signal

strength.

For a more professional look, you

can install the Inside Antenna

underneath a car seat cover or

upholstery.

• When you have tested the

functionality of your Signal Booster,

mount the Inside Antenna by peeling

off the backing of the Velcro® and

attach it to your selected location

on the seat and secure the Inside

Antenna.

4. Place and connect the Drive 4G-X

Signal Booster.

• Select a location for the Signal

Booster that is free from excessive

heat, direct sunlight and moisture

and that has proper ventilation.

Good locations include underneath

a seat or under the dashboard.

• Connect the wire from the Outside

Antenna to the port labeled “Outside

Antenna” on the Signal Booster.

Power

Adapter

From Outside

Antenna

From Inside

Antenna

• Connect the wire from the Inside

Antenna to the port labeled “Inside

Antenna” on the Signal Booster.

• Plug the power adapter into

vehicle’s 12V DC power supply

and attach the cord to the side of

Power Booster labeled “Power.”

NOTE: Do NOT connect the power

to the Signal Booster until you have

connected both the Inside and

Outside Antennas.

• Power up your Signal Booster by

ipping the switch on the back of

the DC power adapter on. A red

light should appear on the power

adapter.

Note: The Drive 4G-X Signal Booster

may remain on, in vehicles whose 12V

DC power sources do not automatically

shutdown when the vehicle is turned

off. This could result in discharging the

vehicles battery in one to two days.

Note: Some 12V DC power sources are

shut down when the vehicle ignition is

turned to off. Refer to your vehicle owners

manual for specics related to your

vehicle.

Note: The aluminum casing of your Signal

Booster will adjust to the temperature of its

environment, but is designed to protect the

Signal Booster technology. For example,

in the summer, the Signal Booster case

may be as hot as 150 degrees inside your

vehicle. These high temperatures will

NOT damage the Signal Booster, nor do

they pose a re risk to the vehicle. Again,

be sure to place your Signal Booster in a

location with adequate ventilation and away

from direct sunlight or moisture.

ENGLISH

Need help? www.weboost.com Customer Support 866-294-1660

Mon. - Fri. 6 am to 7 pm, Sat. & Sun. 8 am to 5 pm (MST)

Lights Off

1. Check connections on the power

supply to see that it is rmly plugged

into both the Drive 4G-X and the

power source.

2. If using a DC power supply in your

vehicle, ensure the power supply is

properly inserted. Then check the

12 volt power from the car socket

and the fuse. Replace the fuse if

necessary.

3. If using a power strip in a building,

ensure the power strip is plugged

in and turned on and that power is

coming from the outlet.

NOTE: The Signal Booster can be reset by

disconnecting and reconnecting the power

supply.

For additional descriptions on

troubleshooting, see the install video at

weboost.com/us/drive4G-Xvideo .

Alternate Outside Antenna

Installation: NMO Mount

Select a location for mounting the antenna.

The best location would be centered on the

vehicle roof, although other locations are

acceptable.

Roof mount only: For mounting the

antenna to the roof of your vehicle, use

weBoost #905814 (3/8 in. w/RG58 cable)

or #907414 (3/8 in. w/RG174 cable), which

must be purchased separately (A). Drill a

hole in the desired location for mounting.

The size of the hole should be 3/8 in.

The plastic washer (B) should be placed

over the threads of the NMO mount (A).

From the inside of the vehicle, insert the

threaded portion of the mount up through

the hole in the vehicle.

From the top of the vehicle, screw the

threaded nut (D) onto the mount threads

coming up through the roof and tighten

until secure.

The black rubber washer (C) should now

be positioned around the threaded nut.

Working from the inside of the vehicle,

securely route and position the cable

provided.

Troubleshooting &

Understanding Lights

The Signal Boost includes four indicator

lights on the front of the Drive 4G-X. The

indicator lights will either be green or red.

Green indicates that the booster is

powered and operating at maximum

gain.

Solid Red indicates that the booster

has shut off on the associated

frequencies to prevent oscillation

(feedback).

Green/red Blinking indicates that the

booster is operating at a reduced gain

to prevent oscillation (feedback).

Fixing Red Light Issues

If one or more lights on the Signal Boost

are red:

1. Make sure all connections are tight.

2. Increase the distance between the

outside antenna and the Drive 4G-X,

by moving them horizontally and/or

vertically farther apart until the light(s)

change to green. Remember to keep

the antenna at least 6 inches from

any window or sunroof.

3. Follow the same steps for a green/red

blinking light until the light goes solid

green.

4. If more separation is not possible and

the coverage of the booster is too

small with a green/red blinking light

indicating reduced gain, contact the

weBoost Customer Support Team for

assistance: 866-294-1660.

ENGLISH

Need help? www.weboost.com Customer Support 866-294-1660

Mon. - Fri. 6 am to 7 pm, Sat. & Sun. 8 am to 5 pm (MST)

Screw the NMO antenna assembly (E) into

place on top of the vehicle.

Vehicle Surface

(B) Plastic Washer

(A) NMO Connector

Cable

(D) Threaded Nut

(E) NMO Antenna

Assembly

Rubber Seal

Drilled Hole

To Booster

Alternate Outside Antenna

Installation: RV/Trucker Antenna

Select a suitable location to install the

antenna on your RV, as high on the vehicle

as possible and at least 12 inches away

from any other antenna. For best results,

use weBoost 3-Way Mount (#901104).

This bracket will enable you to mount the

antenna on a mirror or attach it to the side

of your RV.

If you are installing on a mirror, clamp the

mount to the mirror support and tighten the

four nuts and bolts. If you are mounting

directly to the side of your RV, remove

the nuts, bolts and the smaller half of the

mount and use the four holes in the larger

half to attach it ush to the side of the RV,

using screws or bolts, nuts and washers

appropriate for your particular installation.

RV / Trucker Antenna

Mount & Hardware

To Booster

ENGLISH

Need help? www.weboost.com Customer Support 866-294-1660

Mon. - Fri. 6 am to 7 pm, Sat. & Sun. 8 am to 5 pm (MST)

Additional FAQ:

What hours can I contact customer support?

Customer Support can be reached from Mon. -

Fri. 6 am to 7 pm, Sat. & Sun. 8 am to 5

pm (MST), by calling (866-294-1660), or by email,

at support@weboost.com

How does weather affect the performance of

my outside antenna?

Water vapor (e.g. rain, fog, snow or other

precipitation) creates an effective lter to cellular

signal. In times of heavy precipitation, you may

see less performance.

What’s the difference between the 800 MHz

and the 1900 MHz bands? How do I know

which MHz band my cell phone uses?

The Drive 4G-X works with all major North

American cellular providers on the 800 & 1900

MHz frequencies. Traditionally, 800/1900MHz are

associated with voice and 3G data; while 700MHz

and 1700/2100MHz are associated with 4G data.

Carrier Frequency Use

We recommend visiting www.wirelessadvisor.com

(United States) or http://bit.ly/1mQf2Gl (Canada)

for information regarding the frequency band

used by your cell service provider in a specic

geographical location.

Alternate Outside Antenna

Installation: Marine Antenna

The weBoost Marine Antenna should

be mounted as high as possible with no

obstructions. Marine antennas work on

a “line-of-sight” basis, so the higher your

antenna is, the farther it can receive a

signal. This gives you a greater range for

your cellular communications.

Once the mounting bracket is attached to

your boat, yach, etc., attach antenna to

the mounting bracket and then attach the

connecting cable to the location of your

Signal Booster.

ENGLISH

Need help? www.weboost.com Customer Support 866-294-1660

Mon. - Fri. 6 am to 7 pm, Sat. & Sun. 8 am to 5 pm (MST)

Mobile Antenna Kit

Options

Inside Antenna Options

Slim Low Profile

301152 - w/ 10’ RG174

Low Profile

311106 - w/ 10’ RG58

Outside Antenna Options

Mini-Mag

301126 w/ 12.5 RG174 cable- SMA

12” Mag Mount

311128 w/ 12.5’ RG174

314202 w/ 12.5’ RG174

311703 w/ 12.5’ RG174

Trucker Antenna

304415 w/15’ RG58

304414 w/15’ RG58

Trucker Antenna

311701 w/10.5’ RG58

311101 w/10.5’ RG58

Trucker Antenna

311119 w/13.5’ RG58

311133 w/13.5’ RG58

Marine Antenna

311130-5810 w/10.5’ RG58

Marine Antenna

304416 w/20’ RG58

304420 w/20’ RG58

Glass Mount

311102 w/14’ RG58

NMO Antenna

Kit 314203-5810

• 800/900/1900 NMO Antenna

• 10’ RG58 Cable

Kit 311112-17410

• 800/1900 NMO Antenna

• 14’ RG174 Cable

Kit 314203-17410

• 800/900/1900 NMO Antenna

• 14’ RG174 Cable

Kit 311104-17410

• 800/900/1900 NMO Antenna

• 10’ RG174 Cable

Kit 311104-5810

• 800/900/1900 NMO Antenna

• 10’ RG58 Cable

Kit 311112-5810

• 800/1900 NMO Antenna

• 10’ RG58 Cable

Fixed Antenna Kit

Options

Inside Antenna Options

Kit 309900-50N

• 2- Wall Panel antennas

• 1- 50 ohm 3-Way Splitter

Kit 309905-50N

• 3- Wall Panel Antennas

• 3- 2-Way 50 Ohm Splitters

Kit 309902-75F

• 2- Wall Panel Antennas

• 1-3-Way 75Ohm Splitter

Kit 309903-75F

• 3- Wall Panel Antennas

• 3- 2-Way 75Ohm Splitters

Kit 309904-75F

• 1- Wall Panel Antenna

• 1- 2-Way 75 Ohm Splitter

Kit 301121-40010

• 50 Ohm Dome Antenna

• 10’ LMR400

Kit 311135-40060

• 50 Ohm Wall Panel Antenna

• 60’ LMR400

Kit 301151-0610

• 75 Ohm Dome Antenna

• 10’ RG6 Cable

Kit 311135-5820

• 50 Ohm Wall mount Panel

Antenna

• 20’ RG58 Cablet

Kit 301151-1110

• 75 Ohm Dome Antenna

• 10’ RG11 cable

Kit 311155-1150

• 75 Ohm Wall mount Panel

Antenna

• 50’ RG11 Cable

Kit 311155-0630

• 75 Ohm Wall mount Panel

Antenna

• 30’ RG11 Cable

50 Ohm Outside Antenna Kit

Kit 311203-5820

• Omni-Directional antenna

• 20’ RG58 Cable

Kit 311203-5820

• Omni-Directional antenna

• 20’ RG58 Cable

Kit 314453-5825

• 50 Ohm Pole Mount Panel

Antenna

• 25’ RG58 Cable

Kit 314411-5825

• 50 Ohm Wide Band Directional

• 25’ RG58 Cable

Kit 314411-40075

• 50 Ohm Wide Band Directional

Antenna

• 75’ LMR400 Cable

Kit 311203-40020

• Omni-Directional antenna

• 20’ LMR400 Cable

Kit 311129-400100

• 800 MHz Yagi Antenna

• 100’ LMR400 Cable

Kit 311129-5840

• 800 MHz Yagi Directional

• 40’ RG58 Cable

Kit 311129-400100

• 800 MHz Yagi Antenna

• 100’ LMR400 Cable

Kit 314453-40075

• 50 Ohm Pole Mount Panel

Antenna

• 75’ LMR400 Cable

Kit 301111-400170

• Yagi Directional w/ N-Female

• 170’ LMR400

Kit 311124-5830

• 1900 MHz Yagi Antenna

• 30’ RG58 Cable

75 Ohm Outside Antenna Kit

Kit 301111-0675

• Yagi Directional Antenna

• 75’ RG6 Cable

• N-Male to F-Female adapter

Kit 311201-0620

• Omni Antenna w/ F-Female

• 20’ RG6 Cable

Kit 311129-0660

• 800 MHz Yagi Directional

• 60’ RG6 Cable

• N-Male to F-Female adapter

Kit 311124-0650

• 1900 MHz Yagi Directional

• 50’ RG6 Cable

• N-Male to F-Female adapter

Kit 314473-0640

• 75 Ohm Pole Mount Panel Antenna

• 40’ RG6 Cable

Kit 311141-0620

• 75 Ohm Grey Brick Antenna

• 20’ RG6 Cable

Kit 301111-11140

• Yagi Directional Antenna

• 140’ RG11 Cable

• N-Male to F-Female adapter

Kit 311201-1120

• Omni Directional w/ F-Female

• 20’ RG11 Cable

Kit 311129-11110

• 800 MHz Yagi Directional

• 110’ RG11 Cable

• N-Male to F-Female adapter

Kit 311124-1180

• 1900 MHz Yagi Directional

• 80’ RG11 Cable

• N-Male to F-Female adapter

Kit 314473-1175

• 75 Ohm Pole Mount Panel Antenna

• 75’ RG11 Cable

Kit 314475-0630

• 75 Ohm Wide Band Directional

• 30’ RG6 Cable

Kit 314475-1175

• 75 Ohm Wide Band Directional

• 75’ RG11 Cable

Kit 311141-1120

• 75 Ohm Grey Brick Antenna

• 20’ RG11 Cable

ENGLISH

Need help? www.weboost.com Customer Support 866-294-1660

Mon. - Fri. 6 am to 7 pm, Sat. & Sun. 8 am to 5 pm (MST)

BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider

and have your provider’s consent. Most wireless providers consent to the use of

signal boosters. Some providers may not consent to the use of this device on their

network. If you are unsure, contact your provider.

You MUST operate this device with approved antennas and cables as specified by

the manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any

person.

You MUST cease operating this device immediately if requested by the FCC or a

licensed wireless service provider.

WARNING. E911 location information may not be provided or may be inaccurate

for calls served by using this device.

This is a CONSUMER device.

Safety Guidelines

WARNING: The inside panel and dome antennas must have 6’ of separation distance

from all active users, and the low profile antennas must have 18” of separation

distance from all active users.

WARNING: Connecting the Signal Booster directly to the cell phone with use of an adapter

will damage the cell phone.

WARNING: Use only the power supply provided in this package. Use of a non-

weBoost product may damage your equipment.

WARNING: The Signal Booster unit is designed for use in an indoor, temperature-

controlled environment (less than 150 degrees Fahrenheit). It is not intended

for use in attics, vehicles or similar locations subject to temperatures in excess

of that range.

WARNING: The Outside Antenna must be installed no higher than 10 meters (32’9”) above

ground.

RF SAFETY WARNING: Any antenna used with this device must be located at least 8

inches from all persons.

FOR MORE INFORMATION ON REGISTERING YOUR SIGNAL BOOSTER WITH YOUR

WIRELESS PROVIDER, PLEASE SEE BELOW:

• Sprint: http://www.sprint.com/legal/fcc_boosters.html

• T-Mobile/MetroPCS: https://support.t-mobile.com/docs/DOC-9827

• Verizon Wireless: http://www.verizonwireless.com/wcms/consumer/register-signal-booster.html

• AT&T: https://securec45.securewebsession.com/attsignalbooster.com/

• U.S. Cellular: http://www.uscellular.com/uscellular/support/fcc-booster-registration.jsp

ENGLISH

Need help? www.weboost.com Customer Support 866-294-1660

Mon. - Fri. 6 am to 7 pm, Sat. & Sun. 8 am to 5 pm (MST)

Notes:

_____________________________________________________________

ENGLISH

Need help? www.weboost.com Customer Support 866-294-1660

Mon. - Fri. 6 am to 7 pm, Sat. & Sun. 8 am to 5 pm (MST)

Signal Booster Specifications

Drive 4G-X

Product Number 460021

FCC / IC / Model PWO460021 / 4726A-460021 / 460021

Connectors SMA

Antenna Impedance 50 Ohms

Frequency 698-716 MHz, 729-756 MHz, 777-786 MHz, 824-894 MHz,

1850-1995 MHz, 1710-1755 MHz / 2110-2155 Mhz

Passband Gain (typical) 700 MHz Band 12/17

45.8

700 MHz Band 13

46.8

800 MHz Band 5

46.8

1700/2100 MHz

Band 4

45.2

1900 MHz

Band 2

44.6

20 dB Bandwidth (MHz) 700 MHz Band 12/17 700 MHz Band13 800 MHz Band 5 1700/2100 MHz

Band 4

1900 MHz

Band 2

Typical

Maximum

30.6

35.2

31.0

35.2

37.9

39.9

79.2

79.8

77.3

83.2

Power output for single cell

phone (Uplink) dBm

700 MHz Band 12/17 700 MHz Band13 800 MHz Band 5 1700 MHz Band 4 1900 MHz

Band 2

24.84 24.35 23.4 21.3 24.43

Power output for single cell

phone (Downlink) dBm

700 MHz Band 12/17 700 MHz Band13 800 MHz Band 5 2100 MHz 1900 MHz

Band 2

2.87 2.79 2.8 2.0 1.92

Power output for multiple

received channels

(Uplink) dBm

No. Tones

Maximum Power

700 MHz

Band12/17

700 MHz

Band13

800 MHz

Band 5

1700 MHz

Band 4

1900 MHz

Band 2

225.4 23.9 22.9 22.8 24.9

321.8 20.4 19.4 19.3 21.3

419.3 17.9 16.9 16.8 18.8

517.4 16.0 15.0 14.8 16.9

615.8 14.4 13.4 13.2 15.3

Power output for multiple

received channels

(Downlinklink) dBm

Maximum Power

No. Tones 700 MHz

Band12/17

700 MHz

Band13

800 MHz

Band 5 2100 MHz 1900 MHz

Band 2

24.8 5.6 5.4 6.3 4.5

31.3 2.1 1.9 2.8 0.9

4-1.2 -0.4 -0.6 0.3 -1.6

5-3.2 -2.4 -2.6 -1.6 -3.5

6-4.7 -4.0 -4.2 -3.2 -5.1

Noise Figure 5 dB nominal

Isolation > 90 dB

Power Requirements 6 V 2 A

Each Signal Booster is individually tested and factory set to ensure FCC compliance. The Signal Booster cannot be adjusted without factory

reprogramming or disabling the hardware. The Signal Booster will amplify, but not alter incoming and outgoing signals in order to increase coverage

of authorized frequency bands only. If the Signal Booster is not in use for five minutes, it will reduce gain until a signal is detected. If a detected

signal is too high in a frequency band, or if the Signal Booster detects an oscillation, the Signal Booster will automatically turn the power off on

that band. For a detected oscillation the Signal Booster will automatically resume normal operation after a minimum of 1 minute. After 5 (five) such

automatic restarts, any problematic bands are permanently shut off until the Signal Booster has been manually restarted by momentarily removing

power from the Signal Booster. Noise power, gain, and linearity are maintained by the Signal Booster’s microprocessor.

The Manufacturer’s rated output power of this equipment is for single carrier operation. For situations when multiple carrier signals are present, the

rating would have to be reduced by 3.5 dB, especially where the output signal is re-radiated and can cause interference to adjacent band users.

This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device.

This device complies with Part 15 of FCC rules. Operation is subject to two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not

expressly approved by weBoost could void the authority to operate this equipment.

The term “IC” before the radio certification number only signifies that Industry Canada technical specifications were met.

3301 East Deseret Drive, St. George, UT 84790

web: www.weboost.com email: support@weboost.com

phone: 866-294-1660 local: 435-673-5021 fax: 435-656-2432

2-Year Warranty

weBoost Signal Boosters are warranted for two (2) years against defects in workmanship and/or materials. Warranty

cases may be resolved by returning the product directly to the reseller with a dated proof of purchase.

Signal Boosters may also be returned directly to the manufacturer at the consumer’s expense, with a dated proof of

purchase and a Returned Material Authorization (RMA) number supplied by weBoost. weBoost shall, at its option,

either repair or replace the product. weBoost will pay for delivery of the repaired or replaced product back to the

original consumer if located within the continental U.S.

This warranty does not apply to any Signal Boosters determined by weBoost to have been subjected to misuse,

abuse, neglect, or mishandling that alters or damages physical or electronic properties.

Failure to use a surge protected AC Power Strip with at least a 1000 Joule rating will void your warranty.

RMA numbers may be obtained by contacting Customer Support at 866-294-1660.

Disclaimer: The information provided by weBoost is believed to be complete and accurate. However, no responsibility is

assumed by weBoost for any business or personal losses arising from its use, or for any infringements of patents

or other rights of third parties that may result from its use.

weBoost products covered by U.S. patent(s) and pending application(s)

For patents go to: weboost.com/us/patents

Wilson Electronics 460021 Model 460021 Signal Booster User Manual

Wilson Electronics, LLC Model 460021 Signal Booster

Contents

User Manual

Navigation menu

Namespaces

Views

Navigation
